Panasonic DMR-ES45VP User manual

©2006 Matsushita Electric Industrial Co., Ltd. All
rights reserved. Unauthorized copying and
distribution is a violation of law.
DMR-ES45VP
DMR-ES46VP
Vol. 1
Colour
(S).......................Silver Type
DVD Recorder
ORDER NO.VR0603003CE
B24

1 Safety Precaution 4
1.1. General guidelines 4
1.2. Caution for fuse replacement 4
2 Warning 5
2.1. Prevention of Electrostatic Discharge (ESD) to
Electrostatic Sensitive (ES) Devices 5
2.2. Precaution of Laser Diode 6
2.3. Service caution based on legal restrictions 7
3 Service Navigation 8
3.1. Service Information 8
4 Specifications 9
5 Features 10
5.1. HDAVI Control (HDMI Link) 10
6 Location of Controls and Components 13
6.1. Each Buttons 13
7 Operation Instructions 15
7.1. (DVD) Taking out the Disc from RAM-Drive Unit when the
Disc cannot be ejected by OPEN/CLOSE button 15
7.2. (VHS) Removing Cassette Tape manually 16
8 Service Mode 18
8.1. (DVD) Self-Diagnosis and Special Mode Setting 18
8.2. (VHS) Self-Diagnosis and Special Mode Setting 26
9 Service Fixture & Tools 32
10 Assembling and Disassembling 33
10.1. Disassembly Flow Chart 33
10.2. P.C.B. Positions 34
10.3. Caution with inserting cassette tape when disassembling
the unit 35
10.4. Top Case 36
10.5. Front Panel 36
10.6. Front (L) P.C.B. & Front (R) P.C.B. 37
10.7. RAM / Digital P.C.B. Module 37
10.8. SD Card/DV Jack P.C.B. 39
10.9. VTR Mechanism Unit 39
10.10. Rear Panel & Fan Motor 40
10.11. HDMI P.C.B. 40
10.12. Power & Digital I/F P.C.B. 41
10.13. Main P.C.B. 41
11 Measurements and Adjustments 42
11.1. Service Positions 42
11.2. Caution for Replacing Parts 45
11.3. Standard Inspection Specifications after Making Repairs
48
12 Block Diagram 49
12.1. Power Supply Block Diagram 49
12.2. Analog Video Block Diagram 51
12.3. Analog Audio Block Diagram 53
12.4. Analog Timer Block Diagram 54
12.5. System Control & Servo Block Diagram 55
12.6. HDMI Block Diagram 56
13 Schematic Diagram 57
13.1. Interconnection Schematic Diagram 57
13.2. Power Supply Section (Power & Digital I/F P.C.B.(1/2))
Schematic Diagram (P) 59
13.3. Digital I/F (1/4) Section (Power & Digital I/F P.C.B.(2/2))
Schematic Diagram (IF) 61
13.4. Digital I/F (2/4) Section (Power & Digital I/F P.C.B.(2/2))
Schematic Diagram (IF) 62
13.5. Digital I/F (3/4) Section (Power & Digital I/F P.C.B.(2/2))
Schematic Diagram (IF) 63
13.6. Digital I/F (4/4) Section (Power & Digital I/F P.C.B.(2/2))
Schematic Diagram (IF) 64
13.7. Video (1/4) Section (Main P.C.B.(1/4)) Schematic Diagram
Schematic Diagram (V) 65
13.8. Video (2/4) Section (Main P.C.B.(1/4)) Schematic Diagram
Schematic Diagram (V) 66
13.9. Video (3/4) Section (Main P.C.B.(1/4)) Schematic Diagram
Schematic Diagram (V) 67
13.10. Video (4/4) Section (Main P.C.B.(1/4)) Schematic Diagram
Schematic Diagram (V) 68
13.11. VHS Audio Section (Main P.C.B.(2/4)) Schematic Diagram
(A) 69
13.12. Syscon/Servo/Timer (1/4) Section (Main P.C.B.(3/4))
Schematic Diagram (S) 70
13.13. Syscon/Servo/Timer (2/4) Section (Main P.C.B.(3/4))
Schematic Diagram (S) 71
13.14. Syscon/Servo/Timer (3/4) Section (Main P.C.B.(3/4))
Schematic Diagram (S) 72
13.15. Syscon/Servo/Timer (4/4) Section (Main P.C.B.(3/4))
Schematic Diagram (S) 73
13.16. I/O Tuner Section (1/4) (Main P.C.B.(4/4)) Schematic
Diagram (I) 75
13.17. I/O Tuner Section (2/4) (Main P.C.B.(4/4)) Schematic
Diagram (I) 76
13.18. I/O Tuner Section (3/4) (Main P.C.B.(4/4)) Schematic
Diagram (I) 77
13.19. I/O Tuner Section (4/4) (Main P.C.B.(4/4)) Schematic
Diagram (I) 78
13.20. HDMI Schematic Diagram 80
13.21. SD Card/DV Jack Schematic Diagram 82
13.22. Front (R) Schematic Diagram 83
13.23. Front (L) Schematic Diagram 84
14 Printed Circuit Board 85
CONTENTS
Page Page
2
DMR-ES45VP / DMR-ES46VP

14.1. Power & Digital I/F P.C.B. 85
14.2. Main P.C.B. 87
14.3. HDMI P.C.B. 92
14.4. SD Card/DV Jack P.C.B. 93
14.5. Front (L) P.C.B., Front (R) P.C.B. 94
15 Miscellaneous 95
15.1. Abbreviations 95
16 Appendix for Schematic Diagram 101
16.1. Voltage and Waveform Chart 101
17 Parts and Exploded Views 109
17.1. Exploded Views 109
17.2. Replacement Parts List 113
3
DMR-ES45VP / DMR-ES46VP

1.1.1. Leakage current cold check
1.Unplug the AC cord and connect a jumper between the two
prongs on the plug.
2.Measure the resistance value, with an ohmmeter, between
the jumpered AC plug and each exposed metallic cabinet
part on the equipment such as screwheads, connectors,
control shafts, etc. When the exposed metallic part has a
return path to the chassis, the reading should be between
1MWand 5.2MW.
When the exposed metal does not have a return path to the
chassis, the reading must be .
Figure 1
1.1.2. Leakage current hot check
(See Figure 1 .)
1.Plug the AC cord directly into the AC outlet. Do not use an
isolation transformer for this check.
2.Connect a 1.5kW, 10 watts resistor, in parallel with a 0.15µF
capacitors, between each exposed metallic part on the set
and a good earth ground such as a water pipe, as shown in
Figure 1.
3.Use an AC voltmeter, with 1000 ohms/volt or more
sensitivity, to measure the potential across the resistor.
4.Check each exposed metallic part, and measure the
voltage at each point.
5.Reverse the AC plug in the AC outlet and repeat each of the
above measurements.
6.The potential at any point should not exceed 0.75 volts
RMS. A leakage current tester (Simpson Model 229 or
equivalent) may be used to make the hot checks, leakage
current must not exceed 1/2 milliampere. In case a
measurement is outside of the limits specified, there is a
possibility of a shock hazard, and the equipment should be
repaired and rechecked before it is returned to the
customer.
1 Safety Precaution
1.1. General guidelines
1.When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated or
damaged by the short circuit.
2.After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly
installed.
3.After servicing, make the following leakage current checks to prevent the customer from being exposed to shock hazards.
1.2. Caution for fuse replacement
4
DMR-ES45VP / DMR-ES46VP

2 Warning
2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatic Sensitive
(ES) Devices
Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called
Electrostatic Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistor-sand
semiconductor "chip" components. The following techniques should be used to help reduce the incidence of component damage
caused by electrostatic discharge (ESD).
1.Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off any ESD on your
body by touching a known earth ground. Alternatively, obtain and wear a commercially available discharging ESD wrist strap,
which should be removed for potential shock reasons prior to applying power to the unit under test.
2.After removing an electrical assembly equipped with ES devices, place the assembly on a conductive surface such as
aluminum foil, to prevent electrostatic charge buildup or exposure of the assembly.
3.Use only a grounded-tip soldering iron to solder or unsolder ES devices.
4.Use only an anti-static solder removal device. Some solder removal devices not classified as "anti-static (ESD protected)" can
generate electrical charge sufficient to damage ES devices.
5.Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ES devices.
6.Do not remove a replacement ES device from its protective package until immediately before you are ready to install it. (Most
replacement ES devices are packaged with leads electrically shorted together by conductive foam, aluminum foil or comparable
conductive material).
7.Immediately before removing the protective material from the leads of a replacement ES device, touch the protective material
to the chassis or circuit assembly into which the device will be installed.
Caution
Be sure no power is applied to the chassis or circuit, and observe all other safety precautions.
8.Minimize bodily motions when handling unpackaged replacement ES devices. (Otherwise hamless motion such as the brushing
together of your clothes fabric or the lifting of your foot from a carpeted floor can generate static electricity sufficient to damage
an ES device).
5
DMR-ES45VP / DMR-ES46VP

2.2. Precaution of Laser Diode
6
DMR-ES45VP / DMR-ES46VP

2.3. Service caution based on legal restrictions
2.3.1. General description about Lead Free Solder (PbF)
The lead free solder has been used in the mounting process of all electrical components on the printed circuit boards used for this
equipment in considering the globally environmental conservation.
The normal solder is the alloy of tin (Sn) and lead (Pb). On the other hand, the lead free solder is the alloy mainly consists of tin
(Sn), silver (Ag) and Copper (Cu), and the melting point of the lead free solder is higher approx.30 degrees C (86°F) more than that
of the normal solder.
Definition of PCB Lead Free Solder being used
The letter of “PbF” is printed either foil side or components side on the PCB using the lead free solder.
(See right figure)
Service caution for repair work using Lead Free Solder (PbF)
· The lead free solder has to be used when repairing the equipment for which the lead free solder is used.
(Definition: The letter of “PbF” is printed on the PCB using the lead free solder.)
· To put lead free solder, it should be well molten and mixed with the original lead free solder.
· Remove the remaining lead free solder on the PCB cleanly for soldering of the new IC.
· Since the melting point of the lead free solder is higher than that of the normal lead solder, it takes the longer time to melt
the lead free solder.
· Use the soldering iron (more than 70W) equipped with the temperature control after setting the temperature at 350±30
degrees C (662±86°F).
Recommended Lead Free Solder (Service Parts Route.)
· The following 3 types of lead free solder are available through the service parts route.
RFKZ03D01K-----------(0.3mm 100g Reel)
RFKZ06D01K-----------(0.6mm 100g Reel)
RFKZ10D01K-----------(1.0mm 100g Reel)
Note
* Ingredient: tin (Sn), 96.5%, silver (Ag) 3.0%, Copper (Cu) 0.5%, Cobalt (Co) / Germanium (Ge) 0.1 to 0.3%
7
DMR-ES45VP / DMR-ES46VP

3 Service Navigation
3.1. Service Information
8
DMR-ES45VP / DMR-ES46VP

4 Specifications
9
DMR-ES45VP / DMR-ES46VP

5.1. HDAVI Control (HDMI Link)
Linked operations by HDAVI Control (HDMI Link)
5.1.1. What is HDMI
HDMI is abbreviation of [High-Definition Multimedia Interface],
and is digital interface standard for next generation TV
corresponding to follows.
1.Non-compressing high quality digital image
2.Digital transmission of multi channel digital audio.
3. Two way communication of control signal of control
straightening between equipments
Pin Name
Pin layout of plug of HDMI cable seen from outside.
5.1.2. Link functions with Equipments
Corresponding Table
Functions
(1) Automatic Input switch
(2) Link of Power
In case setting of [FUNCTIONS] ®[Setup] ®[TV Screen] ®
[Functions of HDMI] ®[Control with HDMI] are on, all above
equipments Link functions are effective.
5.1.3. Outline of Equipments Linked
functions
(1) Automatic Input switch
At starting of playback/ GUI display by DIGA, it turns on
power of VIErA, and it displays picture of DIGA onto screen
of VIErA.
Starting of playback:
It includes automatic playback of DVD-Video and so on.
And it includes picture of screen saver too.
GUI display:
FUNCTIONS, DIRECT NAVIGATOR, TV PROGRAM,
PROG/CHECK, Timer Recording, G-code, Initial setting,
Playback setting, Play list, SD/DVD guide, Warning
messages that user can select and so on.
5 Features
10
DMR-ES45VP / DMR-ES46VP

(2) Seamless GUI
1.Automatic switching to DIGA functions from VIErA
functions
When [operate DIGA] of VIErA functions is selected,
input of VIErA is switched to DIGA input automatically
and it displays DIGA functions.
2.Automatic switching to VIErA operation menu from
DIGA operation menu
It is function that DIGA operation menu is switched off
and VIErA operation menu is switched on when
[RETURN] button of VIErA remote controller is pressed
while first stage of DIGA operation menu is being
displayed,
3.Automatic switch off of GUI display of DIGA when
VIErA input selection/ VIErA operation menu is
displayed
GUI of DIGA is turned off when VIErA input selection is
performed while GUI of DIGA is being displayed.And
GUI of DIGA is turned off and VIErA operation menu is
displayed when VIErA operation menu is displayed
while GUI of DIGA is being displayed.
GUI Display:
Erasable GUI displays above are limited to screen that
are erasable by RETURN button in DIRECT
NAVIGATOR/ TV GUIDE/ FUNCTIONS/ PROGRAM
CHECK/ INITIAL SETTING.
However GUI displays that are not erasable by
RETURN button in FORMAT process/ ERASE process/
DUBBING process/ FINALIZE process/ CUTION
displayed are kept displaying.
(3) Remote Control Operation
Function that operate DIGA by VIErA remote controller
when DIGA screen is displayed on VIErA,
· Buttons of Remote Controller that can be operate by
VIErA remote controller:
,,,, ENTER, RETURN, SUB MENU
(4) Power Link
Power of DIGA is turned off linking to POWER OFF of
VIErA.
· Power of DIGA is not turned on linking to POWER ON
of VIErA.
· It is limited in following cases that DIGA links to POWER
OFF of VIErA.
1.During EE display (While Timer recording is being
executed/ Functions is being displayed are included.)
2.Case that DIGA is playing back (only North America/
Japan)
However except cases below.
· During EE display, but manual recording is being
executing/ during EXT_Link recording.
· During Tray is being opened.
· Case that DIGA is in status that power cannot turn off
(during dubbing, during finalize).
11
DMR-ES45VP / DMR-ES46VP

(5) Timer Recording (Reservation Recording)
When select [Reserve] of TV GUIDE of VIErA, Reservation
information is transmitted by way of HDMI (HDAVI Control),
and reservation registration of DIGA is done.
· In DIGA, it treats as well as a usual program reservation
and Timer Recording reservation.
· Linking reservation from VIErA is not done.
· Recordable media is fixed to HDD
· Recording mode of digital program is fixed to DR and
recording mode of analog program is fixed to SP mode.
(6) Recording right now
When [REC RIGHT NOW] is selected on GUI of VIErA, CH
that is being seen is recorded by DIGA.And when [STOP
RIGHT NOW] is selected on GUI of VIErA, recording of
DIGA is stopped.
· Function of [recording right now] is based on manual
recording of DIGA. But recordable media is fixed to
HDD.
Recording mode is same as latest mode, similarly to
manual recording.
(7) Link with Amp
In system including DIGA, VIErA, Amplifier or Theater,
when [ONE TOUCH THEATER PLAYBACK] button was
pressed, VIErA POWER ON/ Input switch/ audio mute is set
automatically, and audio sound is output from speaker
connected amp.
12
DMR-ES45VP / DMR-ES46VP

6 Location of Controls and Components
6.1. Each Buttons
13
DMR-ES45VP / DMR-ES46VP

14
DMR-ES45VP / DMR-ES46VP

7 Operation Instructions
7.1. (DVD) Taking out the Disc from RAM-Drive Unit when the Disc cannot
be ejected by OPEN/CLOSE button
7.1.1. (DVD) Forcible Disc Eject
7.1.1.1. (DVD) When the power can be turned off.
1.Turn off the power and press [STOP], [CH UP] keys on the front panel simultaneously for 5 seconds.
7.1.1.2. (DVD) When the power can not be turned off.
1.Press [POWER] key on the front panel for over 10 seconds to turn off the power forcibly, and press [STOP] [CH UP] keys on
the front panel simultaneously for 5 seconds.
7.1.2. (DVD) When the Forcible Disc Eject can not be done.
1.Turn off the power and pull out AC cord.
2.Remove the Top Case.
3.Push in SLIDE CAM by Eject Pin(JSJ0484) or minus screw driver (small) to eject tray slightly.
4.Push out Tray by Eject Pin (JZS0484) or minus screw driver (small).
15
DMR-ES45VP / DMR-ES46VP

7.2. (VHS) Removing Cassette
Tape manually
When the cassette tape could not be uninstalled from an
electrical malfunction, there are 2 ways to remove a cassette
tape.
7.2.1. (VHS) Removal by compulsory
unloading.
If Service Mode can be activated when the power can not be
turned on, this operation is able.
1.Press [STOP] and [EJECT] button simultaneously for more
than 3 seconds and set the Service Mode to 7.
2.Press [STOP] button in order to unload the mechanism.
(Pay attention to tape slack)
Service Mode Display:
7****(STOP)®70L**(EJECT)
7.2.2. (VHS) Removal by manual
operation by rotating the Loading
Motor with the batteries.
1.Disconnect the AC plug, and remove the Top Panel and the
Front Panel by referring to the Disassembly Procedures.
2.Connect three batteries (1.5V spec.) to the Loading Motor
in series for supplying 4.5V to rotate the Loading Motor as
shown below.
3.Stop unloading just before unloading will be completed as
shown below, and then the tape becomes slack as shown
below.
4.Rotate the S-Reel by a small minus screwdriver to remove
the slack tape as shown below.
5.Then unload again to remove the cassette tape as shown
below.
7.2.3. (VHS) Take out Cassette
Tapemanually after removing the
mechanism
1.Disconnect the AC plug, and remove the Top Case, Front
Panel and the Mechanism by referring to "10 Assembling
and Disassembling"
2.Remove the Screw and remove the Loading Motor as
shown below.
16
DMR-ES45VP / DMR-ES46VP

3.Rotate the Main Cam Gear counter-clockwise until just
before the unloading will be completed as shown below. .
4.Rotate the Capstan Motor clockwise to remove the slack
tape as shown below.
5.Rotate the Main Cam Gear counter-clockwise again to
remove the cassette-tape as shown below.
6.Attach Loading Motor and tighten the screw.
7.Set the Position Switch to EJECT POSITION certainly and
attach the mechanism to chassis as shown below.
17
DMR-ES45VP / DMR-ES46VP

8 Service Mode
8.1. (DVD) Self-Diagnosis and Special Mode Setting
8.1.1. (DVD) Self-Diagnosis Functions
Self-Diagnosis Function provides information for errors to service personnel by “Self-Diagnosis Display” when any error has
occurred.
U**, H** and F** are stored in memory and held.
You can check latest error code by transmitting [0] [1] of Remote Controller in Service Mode.
Automatic Display on FL will be cancelled when the power is turned off or AC input is turned off during self-diagnosis display is ON.
Error Code Diagnosis contents Description Monitor Display Automatic FL display
U30 Remote control code error Display appears when main unit and remote
controller codes are not matched. No display
“*” is remote controller code of the
main unit.
Display for 5 seconds.
U59 Abnormal inner temperature
detected Display appears when the drive temperature exceeds 70°C.
The power is turned off forcibly.
For 30 minutes after this, all key entries are
disabled. (Fan motor operates at the highest
speed for the first 5 minutes. For the
remaining 25 minutes, fan motor is also
stopped.) The event is saved in memory as
well.
No display
“U59 is displayed for 30 minutes.
U61 The unit is carrying out its
recovery process. No display
U88 The unit is carrying out its
recovery process. No display
U99 Hang-up Displayed when communication error has
occurred between Main microprocessor and
Timer microprocessor.
No display
Displayed is left until the
[POWER] key is pressed.
H19 Inoperative fan motor When inoperative fan motor is detected after
powered on, the power is turned off
automatically.
The event is saved in memory.
No display No display
F00 No error information Initial setting for error code in memory
(Error code Initialization is possible with error
code initialization and main unit initialization.)
No display No display
F09 Serial Communication Error
between VHS Microprocessor
and Timer Microprocessor.
Please confirm Serial Communication
terminal of Microprocessor.
NOTE:
If F09 appears just after updating Firmware,
pull off and insert AC plug, then it will
disappear.
No display
F34 Initialization error when main
microprocessor is started up
for program recording
When initialization error is detected after
starting up main microprocessor for program
recording, the power is turned off
automatically.
The event is saved in memory.
No display No display
F58 Drive hardware error When drive unit error is detected, the event is
saved in memory. No display No display
F60 DVD module has not been
started. Defect of Digital P.C.B.
Mode: No change No display
18
DMR-ES45VP / DMR-ES46VP

Error Code Diagnosis contents Description Monitor Display Automatic FL display
UNSUPPO
RT Unsupported disc error *An unsupported format disc was played, although the drive starts normally.
*The data format is not supported, although
the media type is supported.
*Exceptionally in case of the disc is dirty.
“This disc is
incompatible.”
Display for 5 seconds.
NO READ Disc read error *A disc is flawed or dirty.
*A poor quality failed to start.
*The track information could not be read.
“Cannot read.
Please check the
disc.”
HARD
ERR Drive error The drive detected a hard error. “DVD drive error.” Display for 5 seconds.
IR ERR IR communication error [IR ERR] is displayed when communication
between Timer microprocessor and IR
microprocessor fails.
No display
No REC Recording is impossible [No REC] is displayed when recording is
impossible due to the defect, dirt or wound of
media.
No display
SELF
CHECK Restoration operation Since the power cord fell out during a power failure or operation, it is under restoration
operation.
*It will OK, if a display disappears
automatically. If a display does not disappear,
there is the possibility that defective Digital
P.C.B. / RAM drive.
No display
PLEASE
WAIT Unit is in termination process Unit is in termination process now.
“BYE” is displayed and power will be turned
off.
In case “Quick Start” of setup menu is ON, it
is displayed in restoration operation for AC
off.
No display
UNFORM
AT Unformatted disc error You have inserted an unformatted DVD-RAM or DVD-RW that is unformatted or recorded
on other equipment.
8.1.2. (DVD) Special Modes Setting
Item FL display Key operation
Mode name Description Front Key
TEST Mode *All the main unit´s parameters (include tuner)
are initialized. Press [VHS to DVD DUBBING], [REC] and [OPEN/CLOSE] keys
simultaneously for five seconds
when power is off.
Rating password The audiovisual level setting password is
initialized to “Level 8”. Set DRIVE SELECT to [DVD]. While the tray is open, press [REC]
and [PLAY] simultaneously for 5
seconds.
Service Mode Setting every kind of modes for servicing.
*Details are described in “8.1.3. (DVD)
Service Modes at a glance”.
When the power is off, press [VHS
to DVD DUBBING], [OPEN/CLOSE]
and [STOP] keys simultaneously for
5 seconds.
Forced disc eject Removing a disc that cannot be ejected.
The tray will open and unit will shift to P-off
mode.
*When Timer REC is ON, execute " Forced
disc eject " after releasing Timer REC.
While Demonstration Lock is being set, this
Forced disc eject function is not accepted.
The display before execution
leaves. When the power is off, press [STOP] and [CH UP] keys
simultaneously for 5 seconds.
19
DMR-ES45VP / DMR-ES46VP

Item FL display Key operation
Mode name Description Front Key
Forced power-off When the power button is not effective while
power is ON, turn off the power forcibly.
*When Timer REC is ON, execute “Forced
Power-off” after releasing Timer REC.
Display in P-off mode. Press [POWER] key over than 10
seconds.
Aging Perform sequence of modes as * Aging
Description shown below continually. Display following the then mode. When the power is ON, press [CH DOWN], [VHS to DVD DUBBING]
and [OPEN/CLOSE] simultaneously
for over 5 seconds and less than 10
seconds.
NOTE1:
If Unit has not turned into Aging
mode by operations shown above,
execute TEST MODE once and re-
execute operation shown above.
(*All the main unit’s parameters
include tuner are initialized by TEST
mode.)
NOTE2:
If the unit has hung-up because of
pressing keys for over 10 seconds,
once turn off the power, and re-
execute this command.
*When releasing Aging mode, press
[POWER] key.
Aging Contents (Example):
Demonstration
lock/unlock Ejection of the disc is prohibited.
The lock setting is effective until unlocking the
tray and not released by “Main unit
initialization” of service mode.
*When lock the tray.
“LOCK” is displayed for 3 seconds.
When the power is on, press
[STOP] and [POWER] keys
simultaneously for 5 seconds.
Note:
When a disc is not in tray, this
setting is not effective.
*When unlock the tray.
“UNLOCK” is displayed for 3
seconds.
When the power is on, press
[STOP] and [POWER] keys
simultaneously for 5 seconds.
*When press OPEN/CLOSE key
while the tray being locked.
Display “LOCK” for 3 seconds.
Press [OPEN/CLOSE] key while the
tray being locked.
Progressive initialization The progressive setting is initialized to
Interlace. The display before execution leaves. When the power is on (E-E mode), press [STOP] and [VHS to DVD
DUBBING] simultaneously for 5
seconds.
20
DMR-ES45VP / DMR-ES46VP
