Panasonic ES CV51 User manual
2
GB English����������������� 5
DDeutsch ������������� 23
FFrançais������������� 43
IItaliano��������������� 63
NL Nederlands�������� 81
EEspañol�������������� 99
DK Dansk����������������117
PPortuguês�������� 135
NNorsk ��������������� 153
SSvenska����������� 171
FIN Suomi��������������� 189
PL Polski��������������� 205
CZ ��������������� 223
SK �������� 241
H������������� 259
RO ����������� 277
TR Türkçe�������������� 295
ES-CV51_EU.indb 2 2017/08/04 19:57:08
3
PAN EUROPEAN
GUARANTEE
1103H016PC
Personal Care Products
Operating Instructions
(Household)
Rechargeable Shaver
Model No.
ES-CV51
a
c
b
d
Back
ES-CV51_EU.indb 3 2017/08/04 19:57:09
4
ES-CV51_EU.indb 4 2017/08/04 19:57:09
5
TR RO H SK CZ PL FIN S N P DK E NL I F D GB
Operating Instructions
(Household) Rechargeable Shaver
Model No. ES‑CV51
Thank you for purchasing this Panasonic product.
Safety precautions..................... 8
Intended use ��������������������������������������11
����������������������������12
Preparation�����������������������������������������12
How to use �����������������������������������������13
Cleaning the shaver ��������������������������15
the inner blades���������������������������������16
FAQ �����������������������������������������������������17
Troubleshooting ��������������������������������18
Service������������������������������������������������20
For environmental protection and
������������������������20
������������������������������������21
Contents
ES-CV51_EU.indb 5 2017/08/04 19:57:09
6
Warning
•This appliance can be used by children aged from
8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
•The supply cord cannot be replaced. If the cord is
damaged, the AC adaptor should be scrapped.
ES-CV51_EU.indb 6 2017/08/04 19:57:09
7
TR RO H SK CZ PL FIN S N P DK E NL I F D GB
•This WET/DRY shaver can be used for wet shaving
using shaving lather or for dry shaving. You can use this
watertight shaver in the shower and clean with water.
The following symbol means suitable for use in a bath
or shower.
•Do not use anything other than the supplied AC adaptor
for any purpose. Also, do not use any other product with
the supplied AC adaptor. (See page 12.)
•
power supply unit is required for connecting the electrical
appliance to the supply mains. The type reference of
power supply unit is marked near the symbol.
ES-CV51_EU.indb 7 2017/08/04 19:57:10
8
damage to property, always observe the following safety precautions.
The following symbols are used to classify and describe the
level of hazard, injury, and property damage caused when the
denotation is disregarded and improper use is performed.
DANGER Denotes a potential
hazard that will result in
serious injury or death.
WARNING
Denotes a potential
hazard that could result
in serious injury or death.
CAUTION
Denotes a hazard that
could result in minor injury
or property damage.
The following symbols are used to classify and describe the
type of instructions to be observed.
operating procedure that must not be performed.
operating procedure that must be followed in order to
operate the unit safely.
WARNING
This product
leave in a high temperature environment�
‑
Doing so may cause overheating, ignition, or explosion.
‑
Contact an authorized service centre for repair (battery
change etc).
Never disassemble except when disposing of the
product�
‑
‑
•The main unit, adaptor or cord is deformed or
•The main unit, adaptor or cord smells of burning�
•There is an abnormal sound during use or
charging of the main unit, adaptor or cord�
‑ Immediately request inspection or repair at an
authorized service centre.
Do not connect or disconnect the adaptor to a
household outlet with a wet hand�
‑ Doing so may cause electric shock or injury.
ES-CV51_EU.indb 8 2017/08/04 19:57:10
9
TR RO H SK CZ PL FIN S N P DK E NL I F D GB
WARNING
Do not immerse the AC adaptor in water or wash
with water�
Do not place the AC adaptor over or near water
Never use the appliance if the AC adaptor is
household outlet�
or pinch the cord�
‑
short circuit.
household outlet or the wiring�
‑
Exceeding the rating by connecting too many plugs to
electric power source matched to the rated voltage
indicated on the AC adaptor�
‑
Disconnect the AC adaptor when cleaning the
shaver with water�
‑ Failure to do so may cause electric shock or injury.
plug to prevent dust from accumulating�
‑
caused by humidity.
Preventing accidents
Do not place within reach of children or infants� Do
not let them use it�
‑ Putting parts or accessories in the mouth may cause
an accident or injury.
vomiting, drink a large amount of water and contact
‑ Failure to follow these instructions may result in
physical problems.
CAUTION
Protecting the skin
blemishes or injured skin�
Do not touch the blade section (metallic section) of
the inner blade�
‑ Doing so may cause injury to skin or hand.
nails when in use�
‑ Doing so may cause injury to skin or reduce the life of
the system outer foil.
ES-CV51_EU.indb 9 2017/08/04 19:57:10
10
CAUTION
deformations before use�
‑ Failure to do so may cause injury to the skin.
Be sure to place the protective cap on the shaver
‑ Failure to do so may cause injury to skin or reduce the
life of the system outer foil.
Note the following precautions
Do not wrap the cord around the adaptor when storing�
‑ Doing so may cause the wire in the cord to break with
Do not allow metal objects or trash to adhere to the
power plug or the appliance plug�
‑
short circuit.
Do not disconnect the adaptor or the appliance plug
‑ Doing so may cause electric shock or injury.
people�
‑
Do not drop or hit against other objects�
‑ Doing so may cause injury.
Disconnect the adaptor from the household outlet
when not charging�
‑
electrical leakage resulting from insulation deterioration.
DANGER
•
other products�
•
removed from the product�
•
•
•Do not let the positive and negative terminals of
metallic objects�
•
•
exposed to high temperatures, such as under
direct sunlight or near other sources of heat�
•Never peel off the tube�
‑
Doing so may cause overheating, ignition, or explosion.
ES-CV51_EU.indb 10 2017/08/04 19:57:10
11
TR RO H SK CZ PL FIN S N P DK E NL I F D GB
WARNING
keep it within reach of children and infants�
‑ The battery will harm the body if accidentally
swallowed.
If this happens, consult a physician immediately.
‑
contact with your eyes.
Do not rub your eyes. Wash immediately with clean
water and consult a physician.
‑
comes in contact with the skin or clothes.
Wash it off thoroughly with clean water and consult a
physician.
Intended use
• Treat yourself to wet lather shaves for at least three weeks and
notice the difference. Your Panasonic WET/DRY shaver
requires a little time to get used to because your skin and beard
need about a month to adjust to any new shaving method.
• Do not bring the system outer foil into contact with hard
objects.
Doing so may damage the blades as they are very thin and
deform easily.
• Do not dry the main unit with a dryer or a fan heater.
Doing so may cause malfunction or deformation of the parts.
• Do not leave the shaver exposed to direct sunlight with the
foil frame detached.
Doing so may deteriorate the waterproof rubber and degrade
waterproof function, which may cause to malfunction.
• Store the shaver in a place with low humidity after use.
Failure to do so may cause malfunction due to condensation
or rust.
• Keep both the inner blades inserted. If only one of the inner
blades is inserted, the shaver may be damaged.
• If you clean the shaver with water, do not use salt water or
hot water. Do not soak the shaver in water for a long period
of time.
ES-CV51_EU.indb 11 2017/08/04 19:57:10
12
A
1Protective cap
2System outer foil
3Foil frame
4Smooth rollers
• They help to glide over
the skin more easily.
5Foil frame release
buttons
6Power switch
7Lamp display
a. Shaving sensor lamp
()
b. Battery capacity
lamp
c.
Switch lock lamp ( )
d. Charge status lamp
()
8Appliance socket
9Outer foil section
:System outer foil
release buttons
;Inner blades
<Trimmer
=Trimmer handle
B AC adaptor (RE7-87)
>Adaptor
?Power plug
@Cord
AAppliance plug
Accessories
CTravel case
DCleaning brush
EOil
FOperating Instructions
GGuarantee Card
Preparation
Charging the shaver
• Turn the shaver off.
• Wipe off any water droplets on the appliance socket.
1 Insert the appliance plug
[BA] into the shaver�
2 Plug the adaptor [B>] into a
household outlet�
• Check that the charge status lamp
() is glowing.
• Charging is completed after
approx. 1 hour.
1
2
3 Disconnect the adaptor after charging is completed�
Note
You cannot operate the shaver while charging.
While charging After charging is completed
The charge status lamp ( )
glows.
The battery capacity lamp
will blink in order of “LOW”,
“MID”, and “HIGH” while the
charging progresses.
The battery capacity lamp
and the charge status lamp
() will light up and then
turn off after 5 seconds.
ES-CV51_EU.indb 12 2017/08/04 19:57:10
13
TR RO H SK CZ PL FIN S N P DK E NL I F D GB
Abnormal charging
The charge status lamp ( ) will blink twice every second.
Notes
•
been in use for more than 6 months, the charging time may
change or the charge status lamp ( ) may not glow for a
few minutes. It will eventually glow if kept connected.
• Recommended ambient temperature for charging is
10 °C – 35 °C. It may take longer to charge, or the charge
status lamp ( ) will blink quickly and the battery may fail to
charge properly in extremely high or low temperatures.
• The shaver can be used for approximately 2 weeks with a
full charge.
(Based on one 3‑minute dry‑shave usages per day in an
ambient temperature range of 20 °C – 30 °C.)
The number of usable days varies depending on the
following conditions.
‑ Beard thickness
‑ Pressure applied to the skin
‑ Usage frequency of the sonic vibration cleaning mode
• If there is noise from the radio or other sources while using
or charging the appliance, move to a different location to use
the appliance.
How to use
Shaving beard
1 Press and shave�
• The “shaving sensor”, which automatically
adjusts the power depending on the beard
thickness, will operate.
It will shave with high power on areas
where the beard is heavy, and reduce the
power on areas where the beard is thin, to
reduce burden on the skin.
• The power cannot be turned on when the switch lock
lamp ( ) blinks, as the power switch is locked.
Press the power switch for more than 2 seconds to
unlock.
(See page 14.)
Tips for better shaving
Apply the whole system outer foil
perpendicularly against the skin and
shave by slowly gliding the shaver over
the face against the grain of the beard.
• The beard under the chin and around the
throat can be shaved better by stretching
the skin so the beard will stand.
• To prevent damaging the system
outer foil, do not shave with only a
part of the system outer foil.
ES-CV51_EU.indb 13 2017/08/04 19:57:11
14
2 Press
While using
Approximate amount of battery charge is
displayed as LOW – HIGH.
• It will turn off approximately 5 seconds after operating the switch.
• The shaving sensor lamp ( ) blinks.
When the battery capacity is low
“LOW” blinks when operating the shaver.
• The appliance beeps twice after switched off.
• You can shave 2 to 3 times after “LOW” appears. (This will
differ depending on usage.)
Notes
• The appliance may not operate in an ambient temperature
lower than approximately 5 °C.
• The shaving sensor may not respond depending on the type
and quantity of the shaving gel. This is not abnormal.
• Depending on the beard thickness or the amount of beard
trimmings in the shaver head, the shaving sensor may not react
and the driving sound may not change. This is not abnormal.
• The sonic vibration cleaning mode is activated when the
power switch is pressed for more than 2 seconds while the
shaver is not operating (the switch lock is unlocked). (See
page 15.)
You cannot shave in this mode.
Locking/unlocking the power switch
Locking the power switch
1. Press once
and then release.
• The shaver
starts operating.
2. Press for more
than 2 seconds
until the switch
lock lamp ( )
turns on.
• The shaver will
stop operating.
3. Release .
• The switch
lock lamp
() will
light up for
5 seconds
and turn off.
Unlocking the power switch
1. Press for more than
2 seconds until the switch
lock lamp ( ) turns off.
2. Once the shaver starts
operating, release .
• The switch lock lamp ( )
will turn off.
ES-CV51_EU.indb 14 2017/08/04 19:57:11
15
TR RO H SK CZ PL FIN S N P DK E NL I F D GB
Using the trimmer
1. Slide the trimmer handle up.
2. Press and use.
Press and hold the top knob (a) and
slide the trimmer handle down to
lower the trimmer.
Tips for better usage
Apply the trimmer edge perpendicular to skin gently and move
downward slowly.
Trimming sideburns Pre‑shave of long beards
Cleaning the shaver
We recommend cleaning the shaver after each use.
Cleaning with water
• Turn the shaver off and disconnect the AC adaptor.
1
[A2]�
2 Press for more than
2 seconds to activate the sonic
vibration cleaning mode�
• Splashing of foam is suppressed.
• The battery capacity lamps blink in order.
• After about 20 seconds, it will be
automatically turned off, or you can
turn it off by pressing the power switch.
3 Remove the outer foil section
[A9] and clean with running
water�
• See page 16 for attaching and
removing the outer foil section.
• Splashing is reduced by rinsing the shaver in sonic
vibration cleaning mode.
• After rinsing with water, shake the shaver up and down
for a few times to remove excess moisture and then wipe
off any drops of water with a dry cloth.
ES-CV51_EU.indb 15 2017/08/04 19:57:12
16
4
shaver, and the trimmer
[A<
• Allow the shaver to dry in the
shade, avoid direct sunlight.
5 Lubricate the shaver�
It will keep the movement of the blade
smooth and maintain a comfort shave.
1. Apply one drop of oil to each of the
system outer foils.
2. Raise the trimmer and apply a drop of oil.
3.
seconds.
4. Switch off the shaver, and wipe off any excess oil from
the system outer foil with a soft cloth.
Notes
• Be careful not to hit the main body on the sink or any other object
while draining the water. Failure to do so may cause malfunction.
• Do not wipe with thinners, benzine, alcohol etc.
Doing so may cause malfunction, or cracking or discoloration
of the parts.
Wipe with diluted soapy water.
• Do not use any kitchen or bathroom detergents other than
hand soap.
Doing so may cause malfunction.
Cleaning with the brush
Remove the outer foil section and the inner blades.
(See this page.)
Cleaning with the long brush
Clean the outer foil section
[A9], system outer foil [A2],
the shaver body [A] and the
trimmer [A<] using the long
brush.
Cleaning with the short brush
• Clean the inner blades [A;] using
the short brush by moving it in
direction as illustrated.
• Do not move the short brush
perpendicularly against the blades
as it will damage the inner blades
and affect their sharpness.
the inner blades
system outer foil once every year
inner blades once every two years
Removing the outer foil section
Press the foil frame release buttons [A5] and
lift the outer foil section [A9] upwards.
ES-CV51_EU.indb 16 2017/08/04 19:57:13
17
TR RO H SK CZ PL FIN S N P DK E NL I F D GB
Attaching the outer foil section
After turning the foil frame mark ( ) to the
front, securely attach the outer foil section [A9]
to the shaver until it clicks.
1. Press the system outer foil release
buttons [A:] and pull down the system
outer foil [A2].
• Do not press the system outer foil
release buttons with excessive force.
Doing so may bend the system outer foil,
preventing complete attachment to the
foil frame.
2. Align the foil frame mark ( ) and the system outer foil
mark ( ) and securely attach together until it clicks.
Replacing the inner blades
1. Remove the inner blades [A;] one at a time.
2. Insert the inner blades one at a time.
Note
Do not throw away the foil frame.
FAQ
Question Answer
Will the battery
deteriorate if not used
for an extended period
of time?
The battery will deteriorate if not
used for over 6 months, so make
sure to perform a full charge at
least once every 6 months.
Can I charge the shaver
after every use?
The battery used is a lithium‑ion,
so charging after every use will
have no effect on battery life.
Why should the adaptor be
disconnected after charge?
Charging the battery for more
than 1 hour will not affect
battery performance, but
disconnect the adaptor for
safety and to save energy.
What is the constituent
of the dedicated oil?
Constituent of the oil is liquid
Why does the appliance
beep twice after
switched off?
The sound indicates that the
battery capacity is running low.
Please charge the appliance.
ES-CV51_EU.indb 17 2017/08/04 19:57:14
18
Troubleshooting
Perform the following actions.
If the problems still cannot be solved, contact the store
where you purchased the unit or a service centre authorized
by Panasonic for repair.
Problem Action
The power switch does
not turn ON.
Unlock the switch lock.
(See page 14.)
The shaving sensor
does not respond.
Depending on the beard
thickness or the amount of beard
trimmings in the shaver head,
the shaving sensor may not react
and the driving sound may not
change. This is not abnormal.
The shaving sensor may not
respond depending on the type
and quantity of the shaving gel.
This is not abnormal.
The shaving sensor may not
respond when the remaining
battery capacity is low. If this
happens, recharge the shaver.
Apply oil. (See page 16.)
The shaving sensor may not
respond when there is not
enough oil on the blades.
Problem Action
The shaving sensor
responds even though
the shaver is not in
contact with the skin.
Clean the beard trimmings from
the shaver.
When the shaver is extremely
dirty, remove the foil frame and
wash with water.
(See page 15.)
Replace the system outer foil
and/or inner blades.
Expected life of system outer
foil and inner blades:
System outer foil:
Approximately 1 year
Inner blades:
Approximately 2 years
Operating time is short
even after charging.
Apply oil.
This can be improved by cleaning
every time after shaving.
When the number of operations
per charge starts to decrease, the
battery is nearing the end of its life.
Shaver does not operate
even after charging.
Use the appliance in an
ambient temperature
approximately 5 °C or higher.
The battery has reached the
end of its life.
The shaver will not operate with
the AC adaptor connected.
Please use the shaver after it has
AC adaptor disconnected.
ES-CV51_EU.indb 18 2017/08/04 19:57:14
19
TR RO H SK CZ PL FIN S N P DK E NL I F D GB
Problem Action
The driving sound
changes while shaving.
The shaving sensor is operating.
The sound changes depending
on the beard thickness.
Makes a loud sound.
Apply oil.
The blades will not move
smoothly when there is no oil on
the blades, requiring more power.
The shaver makes a high‑pitched
sound due to the linear motor drive.
This does not indicate a problem.
properly attached.
Clean the system outer foil with
the brush.
The odor is getting
stronger.
This can be improved by
cleaning every time after
shaving.
directions.
This can be improved by
cleaning every time after
shaving.
Clean the inner blades with the
brush when shavings are
adhering to the inner blades.
System outer foil gets hot.
Apply oil.
Replace the system outer foil if
it is damaged or deformed.
(See page 17.)
Problem Action
You do not get as close
a shave as before.
This can be improved by cleaning
every time after shaving.
Replace the system outer foil
and/or inner blades.
Expected life of system outer
foil and inner blades:
System outer foil:
Approximately 1 year
Inner blades:
Approximately 2 years
Apply oil.
ES-CV51_EU.indb 19 2017/08/04 19:57:14
20
Service
Contact
Please visit Panasonic web site http://www.panasonic.com or
information or if the shaver or the cord gets damaged.
Replacement parts
Replacement parts are available at your dealer or Service Centre.
Replacement parts for
ES‑CV51
System outer foil and
inner blades WES9036
System outer foil WES9177
Inner blades WES9170
The life of the battery is 3 years. The battery in this shaver is
not intended to be replaced by consumers. Have the battery
replaced by an authorized service centre.
For environmental protection and
This shaver contains a Lithium‑ion battery.
Please make sure that the battery is disposed of at an
Disposal of Old Equipment and Batteries
These symbols on the products, packaging, and/or
accompanying documents mean that used electrical
and electronic products and batteries must not be
mixed with general household waste.
For proper treatment, recovery and recycling of old
products and batteries, please take them to applicable
collection points in accordance with your national
legislation.
By disposing of them correctly, you will help to save
valuable resources and prevent any potential negative
effects on human health and the environment.
For more information about collection and recycling,
please contact your local municipality.
Penalties may be applicable for incorrect disposal of
this waste, in accordance with national legislation.
This symbol might be used in combination with a
chemical symbol. In this case it complies with the
requirement set by the Directive for the chemical
involved.
ES-CV51_EU.indb 20 2017/08/04 19:57:14
Table of contents
Languages:
Other Panasonic Electric Shaver manuals
Panasonic
Panasonic ES-LV9N User manual
Panasonic
Panasonic ES805S User manual
Panasonic
Panasonic ER-412 User manual
Panasonic
Panasonic ES8096 User manual
Panasonic
Panasonic ES4033 User manual
Panasonic
Panasonic ES-BSL4 User manual
Panasonic
Panasonic ER-GD30 User manual
Panasonic
Panasonic ES-8080 User manual
Panasonic
Panasonic ES-8163 User manual
Panasonic
Panasonic ES-RC20 User manual
Panasonic
Panasonic ER-GB96 User manual
Panasonic
Panasonic ES?GA21 User manual
Panasonic
Panasonic ER-GB80 User manual
Panasonic
Panasonic ER-SB40 User manual
Panasonic
Panasonic ES4036 User manual
Panasonic
Panasonic ES-LV9C User manual
Panasonic
Panasonic ES-LF71 User manual
Panasonic
Panasonic ES-LV6U User manual
Panasonic
Panasonic ES-LF50 User manual
Panasonic
Panasonic ER-GB37 User manual
