Panasonic ES4036-A3 User manual

1 SCHEMATIC DIAGRAM 2
2 EXPLODED VIEW 3
©2004 Matsushita Electric Works, Ltd. All rights
reserved. Unauthorized copying and distribution is a
violation of law.
ES4036-A3
3 REPLACEMENT PARTS LIST 4
AC/Rechargeable Shaver
Please file and use this manual together with the service manual for Model No. ES4033/ES4035, Order No.
SD0406A47C3.
SPECIFICATIONS
Power source
A
C 100-240V, 50-60Hz (Automatic voltage conversion)
Motor voltage 1.2V DC
Charging time 1 hours
Shavers per charge 10 times (3 minutes shave)
Measurement (H)14.6 x (W)5.7 x (D)4.9 cm
Weight 155g
Supplied accessories Soft case
Cleaning brush
CONTENTS
Page Page
ORDER NO. SD0406A43A3

1 SCHEMATIC DIAGRAM
2
ES4036-A3

2 EXPLODED VIEW
3
ES4036-A3

3 REPLACEMENT PARTS LIST
NOTE:
*A=available as an optional accessory
*B=only available as set
*C=available individually
Ref. No. Parts No. Parts Name & Descriptions Remarks Per Unit
1WES4025X7158 PROTECTIVE CAP (BG) 1
2WES9837EP OUTER FOIL 1
3WES9850EP INNER BLADE *B (2PCS/PK) 2
4WES4035S0047 FOIL FRAME (BG) 1
5WES4035X0207 RETAINING PLATE (BG) 1
6WES4035K1087 TRIMMER DRIVING BAR (BG) 1
7WES725L0327 WATERPROOF RUBBER 1
8WES4036S3058 HOUSING A (BG) 1
9WES4036A3268 LOCK RELEASE BUTTON *B (2PCS/PK) (BG) 2
10 WES4035S0187 SPRING FOR RELEASE BUTTON *B (2PCS/PK) (BG) 2
11 WES4035S3067 HOUSING B (BG) 1
12 WES4036A1508 TRIMMER (BG) 1
13 WES4035L1007 MOTOR ASSEMBLY (BG) 1
14 WES4036L2128 CHASSIS ASSEMBLY (BG) 1
15 WES7026L2508 RECHARGEABLE BATTERY Ni-Mh type (BG) 1
16 WES7025L0977 WASHER W/O-RING SET (BG) 1
17 WES4036A0048 SIDE PANEL (BG) 1
18 WES4036A3128 BOTTOM COVER (BG) 1
18 WES4036A3129 BOTTOM COVER only for Hong Kong (BG) 1
19 WES7025L9707 SCREW *C K2-15 (BG) 5
20 WES626A6057 TAPPING SCREW *C K2-8 (BG) 3
21 WES4033L9008 TAPPING SCREW K2-6 (BG) 1
22 WES7025H3767 SCREW CAP *B (2PCS/PK) (BG) 2
23 WES4035L0967 O-RING *B (5PCS/PK) (BG) 5
24 WES4036S3038 BODY BLOCK (BG) 1
24 WES4036S3039 BODY BLOCK only for Hong Kong (BG) 1
25 WES4036K7662 CHARGING ADAPTOR A-2 PLUG (BG) 1
25 WES4036K7663 CHARGING ADAPTOR C-2 PLUG (BG) 1
25 WES4036K7671 CHARGING ADAPTOR KOREAN PLUG (BG) 1
25 WES4036K7674 CHARGING ADAPTOR C-2 PLUG (only for Hong Kong) (BG) 1
26 WES7025K7007 SOFT CASE (BG) 1
27 WES861B7057 CLEANING BRUSH 1
-WES4036S8008 INDIVIDUAL BOX (BG) 1
-WES4036S8009 INDIVIDUAL BOX only for Hong Kong (BG) 1
-WES4036S8000 INDIVIDUAL BOX only for Taiwan (BG) 1
-WES4036S8108 OPERATING INSTRUCTIONS (BG) 1
4
ES4036-A3
