Order Number SD0709A58CE
AC/Rechargeable Shaver
Model No. ES4853
Asia
TABLE OF CONTENTS
PAGE PAGE
1 Warning -------------------------------------------------------------- 2
2 Specifications ----------------------------------------------------- 2
3 Troubleshooting Guide ----------------------------------------- 3
4 Disassembly and Assembly Instructions ---------------- 4
5 Schematic Diagram ---------------------------------------------- 7
6 Exploded View and Replacement Parts List ------------ 8

2
1Warning
Caution:
• Pb free solder has a higher melting point that standard solder; Typicall the melting point is 50 - 70°F (30 - 40°C) higher. Please
use a soldering iron with temperature control and adjust it to 750 ± 20°F (400 ± 10°C). In case of using high temperature solder-
ing iron, please be careful not to heat too long.
• Pb free solder will tend to splash when heated too high (about 1100°F / 600°C).
2 Specifications

3
3 Troubleshooting Guide

4
4 Disassembly and Assembly Instructions
4.1. Disassembly Instructions
Follow the procedure below to disassemble the main unit.
1. Remove the cap, the outer foil with foil frame and the
inner blade.
2. Unhook the trimmer handle by inserting something like a
slotted screwdriver into a slit.
NOTE:
Make sure not to scratch or damage on the housing.
3. Remove the trimmer.
4. To remove the trimmer driving bar, press bar outward.
5. Loosen a screw and remove the bottom cover. And take
out the side panels.

5
6. Loosen two screws. Take out the retaining plate and
waterproof rubber with care of breakage. Loosen six
screws.
NOTE:
Do not lose the screw O-rings.
7. Separate the housing B from housing A.
8. Take out the motor and the battery & module assembly
gently from housing A.
NOTE:
Do not lose the washer and O-ring.
9. Take out the battery from the chassis.

6
4.2. Assembly Instructions
NOTE:
Make sure whether there is NO foreign substance sticking around a part covered with waterproof seal.
1. Install the driving A in the motor mounting base after
inserting the motor tip pin into the hole of armature 1 of
the driving A. Then, install the driving head B in the
above assembly after inserting the driving head B axis
into the hole of the armature 2 of the motor.
2. Insert the battery & module assembly into the housing A.
3. Put the motor assembly into the housing A.
4. Set the housing A and B and tighten 6 screws. And
attach the side panels and tighten a screw on bottom.
5. Set the trimmer and the trimmer driving bar.

7
5 Schematic Diagram

Model No. : ES4853 Exploded View
6 Exploded View and Replacement Parts List

Model No. : ES4853 Parts List
Safety
Ref.
No. Part No. Part Name & Description Q'ty Remarks
1 WES4853X7158 PROTECTIVE CAP 1 [BG]
2 WES9835E OUTER FOIL 1
3 WES9850EP INNER BLADE 2
4 WES4853K0047 FOIL FRAME 1 (for BLACK), [BG]
4 WES4853S0048 FOIL FRAME 1 (for SILVER), [BG]
5 WES4853L1087 TRIMMER DRIVING BAR 1 [BG]
6 WES7025L9706 SCREW 4 (K2-15), [BG]
7 WES4853L0207 RETAINING PLATE 1 [BG]
8 WES4035L0966 O-RING 4 [BG]
9 WES4823L0328 WATERPROOF RUBBER 1 [BG]
10 WES4853K3158 HOUSING B 1 (for BLACK), [BG]
10 WES4853S3158 HOUSING B 1 (for SILVER), [BG]
11 WES4853K3987 SIDE PANEL 1 (for BLACK), [BG]
11 WES4853A3988 SIDE PANEL 1 (for SILVER), [BG]
12 WES4853L1247 DRIVING HEAD A 1 [BG]
13 WES4853L1257 DRIVING HEAD B 1 [BG]
14 WES4853L1007 DC MOTOR 1 [BG]
15 WES4853L0027 MOTOR MOUNTING BASE 1 [BG]
16 WES4853L2128 MODULE 1 [BG]
17 WES4853K3128 BOTTOM COVER 1 [BG]
17 WES4853S3128 BOTTOM COVER 1 (for KOREA), [BG]
17 WES4853S3129 BOTTOM COVER 1 (for TAIWAN), [BG]
18 WES8093L9007 TAPPING SCREW 1 (K2-6), [BG]
19 WES4853K1507 TRIMMER 1 (for BLACK), [BG]
19 WES4853S1508 TRIMMER 1 (for SILVER), [BG]
20 WES4853K3168 HOUSING A 1 (for BLACK), [BG]
20 WES4853S3168 HOUSING A 1 (for SILVER), [BG]
21 WES4853K3267 FOIL FRAME RELEASE BUTTON 2 (for BLACK), (2PCS/PK), [BG]
21 WES4853H3268 FOIL FRAME RELEASE BUTTON 2 (for SILVER), (2PCS/PK), [BG]
22 WES4853L2508 RECHARGEABLE BATTERY 1 (NI-CD TYPE), [BG]
23 WES4853L1667 SWITCH CAM 1 [BG]
24 WES626A6057 TAPPING SCREW 4 (K2-8), [BG]
25 WES4853K3038 BODY BLOCK 1 [BG]
25 WES4853S3038 BODY BLOCK 1 (for KOREA), [BG]
25 WES4853S3039 BODY BLOCK 1 (for TAIWAN), [BG]
26 WES4853K7663 CHARGING ADAPTOR 1 (C-2 PLUG), [BG]
26 WES7056K7671 CHARGING ADAPTOR 1 (KS PLUG）, [BG]
26 WES4853K7662 CHARGING ADAPTOR 1 (A-2 PLUG）, [BG]
27 WES7025K7007 SOFT CASE 1 [BG]
28 WES861B7056 CLEANING BRUSH 1 [BG]
- WES4853K8008 INDIVIDUAL BOX 1 (for BLACK), [BG]
- WES4853S8008 INDIVIDUAL BOX 1 (for SILVER), [BG]
- WES4853K8108 OPERATING INSTRUCTIONS 1 [BG]
