Panasonic FV-11VH1 User manual

Service Manual
PEG0609032CE
Version:0701
CONTENTS
1. Parts Identification
3. Parts List
2.Wiring Diagram
PAGE
1~6
9~14
7~8
Ceiling Mount Ventilating Fan
SPECIFICATIONS
(North American Market)
FV-11VH1 FV-11VHL1
WARNING
This service information is designed for experienced repair technicians only and is not designed for use by
the general public. It does not contain warnings or cautions to advise non-technical individuals of potential
dangers in attempting to service a product. Products powered by electricity should be serviced or repaired
only by experienced professional technicians. Any attempt to service or repair the product or products dealt
with in this service information by anyone else could result in serious injury or death.
IMPORTANT SAFETY NOTICE
There are special components used in this equipment which are important for safety. These parts are
marked by in the Schematic Diagrams, Exploded Views and Replacement Parts List. It is essential
that these critical parts should by replaced with manufacturer s specified parts to prevent shock, fire
or other hazards. Do not modify the original design without permission of manufacture.
Remark: The Lighting Section of model FV-11VHL1 have been changed from magnetic ballast to
electronic ballast. If you need to order the service parts in this section, please select the
correct style according to your machine. Please see the Parts Identification for more
information.
Speed* Air deliver
at 0.1"WG Weight
Heat Vent Light N.light (RPM) (CFM) kg(Ib.)
FV-11VH1 -- -- 10
(22)
FV-11VHL1 36 4 11.5
(25.3)
Air
direction VHz
110
* At 0.0" Static pressure,(Pa)
25.5
Power consumption*(W)
921
Exhaust &
circulation 120 60 1424
Model No.

FV-11VH1
1
mm
Inch
60 2
50
40
30
20
10
1
_
2
2
11
_
2
1
1
_
2
Motor(C)
Black
Red
Black
Motor(V)
Black
Red
Black
White
Capacitor
Thermostat
(167 F(75 C))°°
Thermalcutoff
(230 F(110 C))°°
Heater(1400W)
Fuse
(20A)
Capacitor
White
White
Black
Black
White
Green
Earthground
PowerSupply
AC120V60Hz
PowerSupply
AC120V60Hz
Circulation fan unit
Ventilationfan unit
Junction box
Circulation Section
Heater Section
Ventilation Section
1
3(4pcs)
2
4(4pcs)
95(2pcs)
(11)(4pcs)
16
(2pcs)
(11)
(2pcs)
5
(3)
(5pcs)
17
18
19
20
21
96
(96)
97
(3)
(3pcs)
7(2pcs)
98
99
100
101
Junction Box
Section

FV-11VHL1
mm
Inch
60 2
50
40
30
20
10
1
_
2
2
11
_
2
1
1
_
2
Circulation Section
Heater Section
Ventilation Section
1
3(4pcs)
2
4(4pcs)
(11)(4pcs)
16
(2pcs)
(11)
(2pcs)
5
(3)
(5pcs)
17
18
19
20
21
Motor(C)
Black
Red
Black
Motor(V)
Black
Red
Black
White
Capacitor
Thermostat
(167 F(75 C))°°
Thermalcutoff
(230 F(110 C))°°
Heater(1400W) Fuse
(20A)
Capacitor
White
White
Black
Black
White
Green
Earthground
PowerSupply
AC120V60Hz
PowerSupply
AC120V60Hz
Circulationfan unit
Ventilationfan unit
Junctionbox
Electronic
Ballast
Lamp
Lightunit
White
CurrentFuse
Black
NightLamp
PowerSupply
AC120V60Hz
PowerSupply
AC120V60Hz
White
White
Black
Black
2
(13)(4pcs)
97(2pcs)
(3)
(3pcs)
98
(4)(4pcs)
Lighting Section
7(2pcs)
116
Junction Box
Section
117
114 115

FV-11VH1
Detail of Heater Box Wiring
Detail of Circulation Wiring
FV-11VHL1
22
65(2pcs)
23 24
25 26
27
28
29
30
31(2pcs)
32
(2pcs)
33
(33)
35
34
(38)
36
37
38
39
40
41
42
43
44
48
45
46
47
49
50(2pcs)
(65)
(65)
51
(65)
(65)
(65)
(65)
(65)
(65) (65)
(65)
(65)
(65)
(52)
52
53
54
64(4pcs)
(65) (65)
(65) (65)
(65)
(2pcs)
55(2pcs)
(55)
(2pcs)
56
(4pcs)
57(4pcs)
Circulation & Heater Section
3
(60) (32)
(24)
59
(61)
58
(26)
(25)
(38)
(58)
62
(2pcs)
60
(60)
(41)
63
(2pcs)
(42)
61(2pcs)
(61)(2pcs)
(22)
(23)
(65)(2pcs)
(61)
(32)
(61)
(38)
(34)
(35)

Detail of Ventilation Wiring
Ventilation Section
4
66 67
68
69(2pcs)
70
(2pcs)
71
72 73 74
75
76
77
(83)
78(2pcs)
79(2pcs)
80
83
(79)
81
82
87
(2pcs)
(80)
86
(2pcs)
(83)
85
(80)
(85)
84
FV-11VH1
FV-11VHL1
Installation
Instruction
WARRANTY
FORMODEL11VH1FOR MODEL 11VH1
eateat
Vent
Light
Night-light
FORMODEL11VHL1FORMODEL11VHL1
89
88
90
91
92
Packing Section
Main Packing Materials

FV-11VH1
FV-11VHL1
6
8
13
11
(2pcs)
12
(4)
(4)
9
15
(4)(2pcs)
14
93
94
10
9
8
10
13
11
(2pcs)
12
(4)
(4)
14
15
(4)(2pcs)
94
93
95
96
6
(93) (94) (93) (94)
(95)
(96)
For FV-11VH1 For FV-11VHL1
For Wire Details For Wire Details
Junction Box Section
5

Remark: When you need to order the service parts in Lighting Section, please select the correct style
for your machine. You can judge by the shape of the parts, or you can consult the parameter
in the Installation Instruction: In the specification sheet, the power consumption of light in the
electronic ballast is 18W (FDS18E35/4---- printed on the light), but in the magnetic
ballast structure is 13W (FQ13E35.U/2 ).
Because the new structure is different common used in old structure, when you need to order
the service parts in this section, please pay your attention to differentiate them.
structure
----printed on the light
For New Type Lighting Unit Assy. (Electronic Ballast)
99
101
104
(104)
105 107
106(2pcs)
102
103
100
FV-11VHL1
Lighting Section
6
108
110
111
(111)
(105)
113(3pcs)
112
For Old Type Lighting Unit Assy. (Magnetic Ballast)
109
(104)
FQ13E35.U/2
(111)
FDS18E35/4

7
FV-11VH1
Motor(C)
Black
Red
Black
Motor(V)
Black
Red
Black
White
Capacitor
Thermostat
(167 F(75 C))°°
Thermal cutoff
(230 F(110 C))°°
Heater(1400W) Fuse
(20A)
Capacitor
White
White
Black
Black
White
Green
Earth ground
Power Supply
AC120V 60Hz
Power Supply
AC120V 60Hz
Circulation fan unit
Ventilation fan unit
Junction box

FV-11VHL1
8
Motor(C)
Black
Red
Black
Motor(V)
Black
Red
Black
White
Capacitor
Thermostat
(167 F(75 C))°°
Thermal cutoff
(230 F(110 C))°°
Heater(1400W) Fuse
(20A)
Capacitor
White
White
Black
Black
White
Green
Earth ground
Power Supply
AC120V 60Hz
Power Supply
AC120V 60Hz
Circulation fan unit
Ventilation fan unit
Junction box
Electronic
Ballast
Lamp
Light unit
White
Current Fuse
Black
Night Lamp
Power Supply
AC120V 60Hz
Power Supply
AC120V 60Hz
White
White
Black
Black
Remark: This Wiring Diagram is for the new type of Lighting Section(electronic ballast).

FV-11VH1
9
No. Part No. Part Name Q'ty Remark
1 FFV1600074S Frame Assy. 1
2 FFV0000040S Adapter Assy. 1
3 FFV7000009S Truss Tap Screw 12
4 FFV7000011S Machine Screw 8 For Fixing Grill Fix Plate & Fix Plate & Wiring Cover
5FFV4610020S Sponge 1 For Electric Insulation,Sticked on Frame Assy.
6 FFV6710009S Wiring Box 1
7 FFV6710010S Wiring Box Sponge A 2 Sticked Between Wiring Box & Frame Assy.
8 FFV6710011S Wiring Box Sponge B 1 Sticked on Wiring Box
9 FFV1300006S Earth Lead Wire 1
10 FFV7020015S Hexagon Nut 1 For Earth
11 FFV7000153S Truss Tap Screw 8
12 FFV0900025S Connector Plate 1
13 FFV0420016S Fix Plate 1 Use For Fixing Connector Plate
14 FFV7030001S Screw Assy. 1 For Earth
15 FFV6710012S Wiring Cover 1
16 FFV7010014S O.T. Washer 2 For Fixing Circulation Section
17 FFV5720015S Scale Tape 1 Sticked on Frame Assy.
18 FFV6730012S Warning Label 1 Sticked on Frame Assy.
19 FFV2260002S HVI Mark 1 Sticked on Frame Assy.
20 FFV4020069S Name Plate 1 Sticked on Frame Assy.
21 FFV6730013S Wiring Label 1 Sticked on Circulation Section
No. Part No. Part Name Q'ty Remark
22 FFV0940005S Current Fuse 1 125V 20A
23 FFV1650001S Fuse Holder 1
24 FFV5850015S Thermostat Assy. 1
25 FFV0940006S Cut Off Plate 1
26 FFV5820026S Terminal 1
27 FFV2220011S Heater Fix Plate Assy. 1 Include 1 Sponge
28 FFV2220013S Heater Assy. 1
29 FFV2220012S Heater 1
30 FFV1600018S Frange Assy. 1
31 FFV0420020S Figuline Tube 2 For Heater & Lead Wire Insulation
32 FFV3450007S Lead Wire Assy. A 2
33 FFV0420019S Fix Plate 2 For Heater Holding
34 FFV0740017S Cord Clip 1
35 FFV0740018S Cord Clip 1
36 FFV2220010S Heater Box Plate 2 1
37 FFV2220009S Heater Box Plate 1 1
38 FFV0720008S Cord Bushing 2
39 FFV2220008S Heater Cover 1
40 FFV1000008S Direction Grill 1
41 FFV0750149S Capacitor 1 220V, 2.5uF
42 FFV0740004H Cord Clip 1
Primary Section
Circulation & Heater Section
!
!
!
!
!
!
!
!
!
!

FV-11VH1
10
No. Part No. Part Name Q'ty Remark
43 FFV0760044S Capacitor Case 1
44 FFV2810001S Joint Plate Assy. 1
45 FFV3730041S Motor Support 1
46 FFV0400072S Blade Assy. 1 Include Fixing Screw
47 FFV0790046S Casing & Plate A 1
48 FFV3700259S Motor Assy. 1 120V,60Hz
49 FFV7000085S Pan Tap Screw 1 For Fuse Holder Fixing
50 FFV7000039S Pan Tapping Screw 2 For Thermostat Fixing
51 FFV7000155S Pan Tapping Screw 1 For Terminal Fixing
52 FFV7010035S Washer 2 Fixing Between Heater Cover & Direction Grill.
53 FFV7010026S Spring Washer 1 For Fixing Direction Grille
54 FFV7000154S Truss Screw 1 For Fixing Direction Grill
55 FFV7000066S Screw 4 For Fixing Capacitor Box & Cord Clip
56 FFV7000025S Truss Tap Screw 4 For Fixing Motor Assy.
57 FFV7000074S Truss Tap Screw 4 For Fixing Motor Support
58 FFV0730024S Cord Assy. C 1 Included in Heater Section
59 FFV5850001S Thermal Cut Off Assy. 1 Included in Heater Section
60 FFV3730042S Motor Cord Assy. 1 Included in Circulation Section
61 FFV2530003S Tie 1 7
62 FFV0900024S Connector 2
63 FFV2240001S Heat Shrink Tube 2
64 FFV7010014S O.T. Washer 4 For Fixing Motor Support
65 FFV7000009S Truss Tap Screw 22
No. Part No. Part Name Q'ty Remark
66 FFV5600002H Shutter Support Assy. 1
67 FFV0790045S Casing 1
68 FFV5510028S Shutter Assy. 1
69 FFV4610002H Sponge 1 2 Sticked on the Casing
70 FFV4610008S Sponge 2 2 Sticked on the Casing
71 FFV5750001S Shutter Support Pole 1
72 FFV7020020S Domed Cap Nut 1 For Fixing Blade
73 FFV7010026S Spring Washer 1 For Fixing Blade
74 FFV6700002H Washer 1 For Fixing Blade
75 FFV0400033H Blade 1
76 FFV4302101H Orifice 1
77 FFV3700053H Motor 1 Fixed to Ventilation.120V,60Hz
78 FFV7000025S Truss Tap Screw 2 For Fixing Motor
79 FFV7000073S Truss screw 3 2pcs For Fixing Orifice,1pcs For Fixing Cord Clip
80 FFV0750014H Capacitor 1 180V 2.8uF
81 FFV6710005S Wiring Cover 1
82 FFV7000133S Truss Tap Screw 1 For Fixing Wring Cover
83 FFV0740017S Cord Clip 2
84 FFV7000018S Truss Tap Screw 1 For Fixing Cord Clip to Orifice
Circulation & Heater Section
Ventilation Section
!
!
!
!
!
!
!
!
!
!

FV-11VH1
11
No. Part No. Part Name Q'ty Remark
85 FFV0730023S Cord Assy. V 1
86 FFV0900024S Connector 2
87 FFV2240001S Heat Shrink Tube 2
No. Part No. Part Name Q'ty Remark
88 FFV4710147S Grille Pad 1
89 FFV4710148S Left Pad 1
90 FFV4710151S Right Pad 1
91 FFV9000317S Packing Case 1
92 FFV0010074S Accessory Set 1 For USA Market
(92) FFV0010116S Accessory Set 1 For CA Market
No. Part No. Part Name Q'ty Remark
93 FFV0900026S Connector Wire C 1
94 FFV0900027S Connector Wire V 1
95 FFV3402106S Grille Fix Plate 2
96 FFV5560019S Spring 2
Grille Assy. 1
Pop Rivet 4
Ventilation Section
FFV3400024S
Grille & Electrical Section
Packing & Accessories Section
97
!
!
!
!
!
No. Part No. Part Name Q'ty Remark
98 FFV2220001S Heater Unit 1
99 FFV0930001S Circulation Unit 1
100 FFV2800001S Junction Box Section 1 For FV-11VH1
101 FFV6400001S Ventilation Unit 1
Section/Unit Order

FV-11VHL1
12
No. Part No. Part Name Q'ty Remark
1 FFV1600074S Frame Assy. 1
2 FFV0000040S Adapter Assy. 1
3 FFV7000009S Truss Tap Screw 12
4 FFV7000011S Machine Screw 12 For Fixing Grill Fix Plate & Fix Plate & Wiring Cover
5FFV4610020S Sponge 1 For Electric Insulation,Sticked on Frame Assy.
6 FFV6710009S Wiring Box 1
7 FFV6710010S Wiring Box Sponge A 2 Sticked Between Wiring Box & Frame Assy.
8 FFV6710011S Wiring Box Sponge B 1 Sticked on Wiring Box
9 FFV1300006S Earth Lead Wire 1
10 FFV7020015S Hexagon Nut 1 For Earth
11 FFV7000153S Truss Tap Screw 8
12 FFV0900025S Connector Plate 1
13 FFV0420016S Fix Plate 5 Use For Fixing Connector Plate & Louver Section
14 FFV7030001S Screw Assy. 1 For Earth
15 FFV6710012S Wiring Cover 1
16 FFV7010014S O.T. Washer 2 For Fixing Circulation Section
17 FFV5720015S Scale Tape 1 Sticked on Frame Assy.
18 FFV6730012S Warning Label 1 Sticked on Frame Assy.
19 FFV2260002S HVI Mark 1 Sticked on Frame Assy.
20 FFV4020070S Name Plate 1 Sticked on Frame Assy.
21 FFV6730014S Wiring Label 1 Sticked on Circulation Section
No. Part No. Part Name Q'ty Remark
22 FFV0940005S Current Fuse 1 125V 20A
23 FFV1650001S Fuse Holder 1
24 FFV5850015S Thermostat Assy. 1
25 FFV0940006S Cut Off Plate 1
26 FFV5820026S Terminal 1
27 FFV2220011S Heater Fix Plate Assy. 1 Include 1 Sponge
28 FFV2220013S Heater Assy. 1
29 FFV2220012S Heater 1
30 FFV1600018S Frange Assy. 1
31 FFV0420020S Figuline Tube 2 For Heater & Lead Wire Insulation
32 FFV3450007S Lead Wire Assy. A 2
33 FFV0420019S Fix Plate 2 For Heater Holding
34 FFV0740017S Cord Clip 1
35 FFV0740018S Cord Clip 1
36 FFV2220010S Heater Box Plate 2 1
37 FFV2220009S Heater Box Plate 1 1
38 FFV0720008S Cord Bushing 2
39 FFV2220008S Heater Cover 1
40 FFV1000008S Direction Grill 1
41 FFV0750149S Capacitor 1 220V, 2.5uF
42 FFV0740004H Cord Clip 1
Primary Section
Circulation & Heater Section
!
!
!
!
!
!
!
!
!
!

FV-11VHL1
13
No. Part No. Part Name Q'ty Remark
43 FFV0760044S Capacitor Case 1
44 FFV2810001S Joint Plate Assy. 1
45 FFV3730041S Motor Support 1
46 FFV0400072S Blade Assy. 1 Include Fixing Screw
47 FFV0790046S Casing & Plate A 1
48 FFV3700259S Motor Assy. 1 120V,60Hz
49 FFV7000085S Pan Tap Screw 1 For Fuse Holder Fixing
50 FFV7000039S Pan Tapping Screw 2 For Thermostat Fixing
51 FFV7000155S Pan Tapping Screw 1 For Terminal Fixing
52 FFV7010035S Washer 2 Fixing Between Heater Cover & Direction Grill.
53 FFV7010026S Spring Washer 1 For Fixing Direction Grille
54 FFV7000154S Truss Screw 1 For Fixing Direction Grill
55 FFV7000066S Screw 4 For Fixing Capacitor Box & Cord Clip
56 FFV7000025S Truss Tap Screw 4 For Fixing Motor Assy.
57 FFV7000074S Truss Tap Screw 4 For Fixing Motor Support
58 FFV0730024S Cord Assy. C 1 Included in Heater Section
59 FFV5850001S Thermal Cut Off Assy. 1 Included in Heater Section
60 FFV3730042S Motor Cord Assy. 1 Included in Circulation Section
61 FFV2530003S Tie 1 7
62 FFV0900024S Connector 2
63 FFV2240001S Heat Shrink Tube 2
64 FFV7010014S O.T. Washer 4 For Fixing Motor Support
65 FFV7000009S Truss Tap Screw 22
No. Part No. Part Name Q'ty Remark
66 FFV5600002H Shutter Support Assy. 1
67 FFV0790045S Casing 1
68 FFV5510028S Shutter Assy. 1
69 FFV4610002H Sponge 1 2 Sticked on the Casing
70 FFV4610008S Sponge 2 2 Sticked on the Casing
71 FFV5750001S Shutter Support Pole 1
72 FFV7020020S Domed Cap Nut 1 For Fixing Blade
73 FFV7010026S Spring Washer 1 For Fixing Blade
74 FFV6700002H Washer 1 For Fixing Blade
75 FFV0400033H Blade 1
76 FFV4302101H Orifice 1
77 FFV3700053H Motor 1 Fixed to Ventilation.120V,60Hz
78 FFV7000025S Truss Tap Screw 2 For Fixing Motor
79 FFV7000073S Truss screw 3 2pcs For Fixing Orifice,1pcs For Fixing Cord Clip
80 FFV0750014H Capacitor 1 180V 2.8uF
81 FFV6710005S Wiring Cover 1
82 FFV7000133S Truss Tap Screw 1 For Fixing Wring Cover
83 FFV0740017S Cord Clip 2
84 FFV7000018S Truss Tap Screw 1 For Fixing Cord Clip to Orifice
Ventilation Section
Circulation & Heater Section
!
!
!
!
!
!
!
!
!
!

14
FV-11VHL1
No. Part No. Part Name Q'ty Remark
85 FFV0730023S Cord Assy. V 1
86 FFV0900024S Connector 2
87 FFV2240001S Heat Shrink Tube 2
No. Part No. Part Name Q'ty Remark
88 FFV4710147S Grille Pad 1
89 FFV4710148S Left Pad 1
90 FFV4710151S Right Pad 1
91 FFV9000318S Packing Case 1
92 FFV0010074S Accessory Set 1 For USA Market
(92) FFV0010116S Accessory Set 1 For CA Market
No. Part No. Part Name Q'ty Remark
93 FFV0900026S Connector Wire C 1
94 FFV0900027S Connector Wire V 1
95 FFV0900010S Connector Wire N.L 1 Connect to Night Lamp
96 FFV0900011S Connector Wire L 1 Connect to Fluorescent Lamp
97 FFV5560019S Spring 2
Grille Assy. 1
Pop Rivet 8
No. Part No. Part Name Q'ty Remark
99 FFV3460005S Light Fix Plate 1 For New Structure
100 FFV3420013S Lighting Unit Assy. 1 For New Structure
101 FFV3420015S Lighting Unit Sub Assy. 1For New Structure
102 FFV1320001S ESP Mark Label 1 Sticked on Light Unit Assy.,For New Structure
103 FFV4730001S T24 Mark Label 1 Sticked on Light Unit Assy.,For New Structure
104 FFV3420007S Fluorescent Lamp 218W,For New Structure
105 FFV3420005S Night Lamp 1For New & Old Structure
106 FFV7000144S Truss Screw 2 For Fixing New Structure Lighting Unit Assy.
107 FFV7000011S Truss Screw 1For Fixing New Structure Lighting Unit Assy.
108 FFV3460004S Light Fix Plate 1For Old Structure
109 FFV3420003S Lighting Unit Assy. 1For Old Structure
110 FFV3420014S Lighting Unit Sub Assy. 1 For Old Structure
111 FFV3420004S Fluorescent Lamp 2 13W,For Old Structure
112 FFV7000009S Truss Screw 1 For Fixing Old Structure Lighting Unit Assy.
113 FFV7000047S Truss Screw 3 For Fixing Old Structure Lighting Unit Assy.
Lighting Section
FFV3400025S
Grille & Electrical Section
Ventilation Section
98
Packing & Accessories Section
!
!
!
!
!
!
!
!
!
!
!
!
!
!
No. Part No. Part Name Q'ty Remark
114 FFV2220001S Heater Unit 1
115 FFV0930001S Circulation Unit 1
116 FFV2800002S Junction Box Section 1 For FV-11VHL1
117 FFV6400001S Ventilation Unit 1
Section/Unit Order
