Panasonic WhisperCeiling FV-05 User manual

Service Manual
PEG0506012CE
Version:0701
CONTENTS
1. Parts Identification
3. Parts List
2.Wiring Diagram
PAGE
1~12
14~19
13
Ceiling Mount Ventilating Fan
Version A
SPECIFICATIONS
FV-05/08/11VQ3,FV-15VQ4
Version B
WARNING
This service information is designed for experienced repair technicians only and is not designed for use by
the general public. It does not contain warnings or cautions to advise non-technical individuals of potential
dangers in attempting to service a product. Products powered by electricity should be serviced or repaired
only by experienced professional technicians. Any attempt to service or repair the product or products dealt
with in this service information by anyone else could result in serious injury or death.
IMPORTANT SAFETY NOTICE
There are special components used in this equipment which are important for safety. These parts are
marked by in the Schematic Diagrams, Exploded Views and Replacement Parts List. It is essential
that these critical parts should by replaced with manufacturer s specified parts to prevent shock, fire
or other hazards. Do not modify the original design without permission of manufacture.
(North American Market)
WhisperCeilingTM
Duct
diameter Noise Power consumption Speed Air deliver at 0.1"WG Weight
(inches) (sones) (W) (rpm) (cfm) Ib.(kg)
Model No. Air
direction VHz
<0.3 13.0 820FV-05VQ3
Exhaust 120 60
FV-11VQ3
50 11.7(5.3)
FV-08VQ3 4 0.3 23.0 730 80 12.6(5.7)
4
14.1(6.4)
4 0.8 31.0 810
Sepcifications are based on HVI standard.
110 13.0(5.9)
FV-15VQ4 6 0.6 32.0 670 150

FV-05VQ3
24(4 PCS)
(22)
(22)
(18)
Details of Capacitor Box
12
14
(3PCS)
13
1
(18) 16 17B
15
(19)
Details of Wiring Section
10
(4PCS)
Main Packing Materials
34
36
33B
37
35
Installation
Instruction
WARRANTY
Installation
Instruction
EnglishEnglishEnglish Spanish/French
(3PCS)
26
25B
20
Details of Junction Box
27
30
(30)
32 (15)
31
28B
29B
Remark: Because of different structure, we divide this model into Version A & Version B.
In Version A, we also divide into Style A & Style B. The change points are mainly
refer to the installation method and the cord section, please pay attention to the
parts which circled with broken line , you can for
details.
refer to the following 3 pages
Fan body
1
45B
47
46
48

FV-05VQ3
Parts For Version A
25AA 25AB
38
39
41
40
LR-03
LP-03
(17A)
Style A
(28A)
(29A) VLR-03
VLP-03
(17B)
Style B
(28B)
(29B)
27
30
(30)
32 (15)
31
28B
29B
27
30
(30)
32
(15)
31
28A
29A
Details of Connector Cord Details of Connector Cord
Details of Junction Box Details of Junction Box
2

FV-05VQ3
43
44
42
Installation Attachment
VLR-03
VLP-03
(17B)
(28B)
(29B)
Details of Connector Cord
27
30
(30)
32 (15)
31
28B
29B
25B
Details of Junction Box
3
Parts For Version B
List For Parts Differentiation
Part name Style A of Version A Style B of Version A Version B
Cord 17A 17B 17B
Frame Assy. 20 20 20
Adapter Assy. 25AA 25AB 25B
Connector Plate 28A 28B 28B
Connector Assy. 29A 29B 29B
Accessory Set 33A 33A 33B
Installation Instruction 45A 45A 45B
Remarks: For your convenience, we list the differentiation parts above, when you need to
order these parts, please judge which version or style is adapt to your machine
first. Especially, if you need to order the Frame Assy. or Adapter Assy.,please
refer to the following 1 page for details.

FV-05VQ3
Attention:
For Version B
For Version A For Version B
25B
Guide For Frame Assy. Order
Differentiation point
Guide For Adapter Assy. Order
Change to
For Version A
Change to
25AB
20
Suspension Bracket
Joist
Fixing Position
25AA
4
Notice: 1.In order to adapt the market demand, the Adapter Assy. has been upgraded to
Version B ,therefore, the Version A part will be provided no longer.
2.If this part in your machine belongs to Version B ,you can order the item 25B
(Part No.:FFV0000029S) directly.
3.If machine belongs to Version A ,you can order the item 25AA
( FFV0000018S ),or item 25AB( FFV0000044S) as usual, then
we will not only the Version B part ,but also provide a set of installation
parts to you, those installation parts will be offered free. However, to finish this
conversion, you need to re-adjust the installation method.
this part in your
Part No.: Part No.:
provide
Notice: The Frame Assy. has been upgraded to Version B, therefore, we can provide the
Version B part at present, If this part in your machine belongs to Version A, when
you receive the Version B part, in order to install successfully, you only need to
re-adjust the fixing position of the Suspension Bracket.
For Reference

FV-08/11VQ3
(25)
(25)
27(4PCS)
(21)
(21) 18 19B
Details of Capacitor Box
15
17
(3PCS)
16
20
(22)
5
Details of Wiring Section
(4PCS)
(3PCS)
29
Main Packing Materials
37
39
40
5
38
28B
23
Details of Junction Box
30
33
(33)
35 (20)
34
31B
32B
Fan body
1
36B
Installation
Instruction
WARRANTY
Installation
Instruction
EnglishEnglishEnglish Spanish/French
48B
50
49
51
Remark: Because of different structure, we divide this model into Version A & Version B.
In Version A, we also divide into Style A & Style B. The change points are mainly
refer to the installation method and the cord section, please pay attention to the
parts which circled with broken line , you can for
details.
refer to the following 3 pages

FV-08/11VQ3
28AA 28AB
41
42
44
43
LR-03
LP-03
(19A)
Style A
(31A)
(32A) VLR-03
VLP-03
(19B)
Style B
(31B)
(32B)
30
33
(33)
35 (20)
34
31B
32B
30
33
(33)
35
(20)
34
31A
32A
Details of Connector Cord Details of Connector Cord
Details of Junction Box Details of Junction Box
6
Parts For Version A

FV-08/11VQ3
Installation Attachment
VLR-03
VLP-03
(19B)
(31B)
(32B)
Details of Connector Cord
30
33
(33)
35 (20)
34
31B
32B
28B
Details of Junction Box
7
Parts For Version B
List For Parts Differentiation
Part name Style A of Version A Style B of Version A Version B
Cord 19A 19B 19B
Frame Assy. 23 23 23
Adapter Assy. 28AA 28AB 28B
Connector Plate 31A 31B 31B
Connector Assy. 32A 32B 32B
Accessory Set 36A 36A 36B
Installation Instruction 48A 48A 48B
Remarks: For your convenience, we list the differentiation parts above, when you need to
order these parts, please judge which version or style is adapt to your machine
first. Especially, if you need to order the Frame Assy. or Adapter Assy.,please
refer to the following 1 page for details.
46
47
45

FV-08/11VQ3
8
Attention:
For Version A For Version B
28B
Guide For Adapter Assy. Order
Change to
28AB
28AA
Notice: 1.In order to adapt the market demand, the Adapter Assy. has been upgraded to
Version B ,therefore, the Version A part will be provided no longer.
2.If this part in your machine belongs to Version B ,you can order the item 28B
(Part No.:FFV0000030S) directly.
3.If machine belongs to Version A ,you can order the item 28AA
( FFV0000019S ),or item 28AB( FFV0000043S) as usual, then
we will not only the Version B part ,but also provide a set of installation
parts to you, those installation parts will be offered free. However, to finish this
conversion, you need to re-adjust the installation method.
this part in your
Part No.: Part No.:
provide
For Version B
Guide For Frame Assy. Order
Differentiation point
Change to
For Version A
23
Suspension Bracket
Joist
Fixing Position
For Reference
Notice: The Frame Assy. has been upgraded to Version B, therefore, we can provide the
Version B part at present, If this part in your machine belongs to Version A, when
you receive the Version B part, in order to install successfully, you only need to
re-adjust the fixing position of the Suspension Bracket.

(25)
(25)
27(4PCS)
FV-15VQ4
(21)
(21) 18 19B
Details of Capacitor Box
15
17
(3PCS)
16
20
(22)
9
Details of Wiring Section
(3PCS)
(3PCS)
Main Packing Materials
37
39
40
38
29
Details of Junction Box
30
33
(33)
35 (20)
34
31B
32B
23
Fan body
28B
1
36B
Installation
Instruction
WARRANTY
Installation
Instruction
EnglishEnglishEnglish Spanish/French
48B
50
49
51
Remark: Because of different structure, we divide this model into Version A & Version B.
In Version A, we also divide into Style A & Style B. The change points are mainly
refer to the installation method and the cord section, please pay attention to the
parts which circled with broken line , you can for
details.
refer to the following 3 pages

28AA
FV-15VQ4
28AB
41
42
44
43
LR-03
LP-03
(19A)
Style A
(31A)
(32A) VLR-03
VLP-03
(19B)
Style B
(31B)
(32B)
30
33
(33)
35 (20)
34
31B
32B
30
33
(33)
35
(20)
34
31A
32A
Details of Connector Cord Details of Connector Cord
Details of Junction Box Details of Junction Box
10
Parts For Version A

FV-15VQ4
Installation Attachment
VLR-03
VLP-03
(19B)
(31B)
(32B)
Details of Connector Cord
30
33
(33)
35 (20)
34
31B
32B
28B
Details of Junction Box
11
Parts For Version B
List For Parts Differentiation
Part name Style A of Version A Style B of Version A Version B
Cord 19A 19B 19B
Frame Assy. 23 23 23
Adapter Assy. 28AA 28AB 28B
Connector Plate 31A 31B 31B
Connector Assy. 32A 32B 32B
Accessory Set 36A 36A 36B
Installation Instruction 48A 48A 48B
Remarks: For your convenience, we list the differentiation parts above, when you need to
order these parts, please judge which version or style is adapt to your machine
first. Especially, if you need to order the Frame Assy. or Adapter Assy.,please
refer to the following 1 page for details.
46
47
45

FV-15VQ4
12
Attention:
For Version B
For Version A For Version B
28B
Guide For Frame Assy. Order
Differentiation point
Guide For Adapter Assy. Order
Change to
For Version A
Change to
28AB
23
Suspension Bracket
Joist
Fixing Position
28AA
Notice: 1.In order to adapt the market demand, the Adapter Assy. has been upgraded to
Version B ,therefore, the Version A part will be provided no longer.
2.If this part in your machine belongs to Version B ,you can order the item 28B
(Part No.:FFV0000031S) directly.
3.If machine belongs to Version A ,you can order the item 28AA
( FFV0000022S ),or item 28AB( FFV0000042S) as usual, then
we will not only the Version B part ,but also provide a set of installation
parts to you, those installation parts will be offered free. However, to finish this
conversion, you need to re-adjust the installation method.
this part in your
Part No.: Part No.:
provide
For Reference
Notice: The Frame Assy. has been upgraded to Version B, therefore, we can provide the
Version B part at present, If this part in your machine belongs to Version A, when
you receive the Version B part, in order to install successfully, you only need to
re-adjust the fixing position of the Suspension Bracket.

FV-05/08/11VQ3
FV-15VQ4
13
Junction box
Motor
Red
White
Black
Capacitor
Green
AC120V 60Hz
Neutral
Live
Earth
Fan body
Power supply
White
Black
White
Black
Green Green

FV-05VQ3
14
3. Parts List
No. Part No. Part Name Q'ty Remark
1 FFV3402111S Grille Assy. 1
2 FFV0790024S Casing 1
3 FFV4610033S Sponge 1 For Casing and Motor Support
4 FFV7020016S Domed Cap Nut 1 For Blade
5 FFV7010003S Spring Washer 1 For Blade
6 FFV7010012S Plain Washer 1 For Blade
7 FFV0400060S Blade 1
8 FFV3730013S Motor Support 1
9 FFV3700178S Motor Assy. 1 120V 60Hz
10 FFV7000025S Screw 4 For Fixing Motor Assy. to Motor Support
11 FFV7000106S Truss Pc Screw 5 For Fixing Motor Support to Casing
12 FFV0750105S Capacitor 1 250V 1.5uF
13 FFV2530001S Insulock Tie 1
14 FFV0900024S Connector 3
15 FFV7030001S Earth Wire Screw 2 For Fixing Earth Wire
16 FFV0740007H Cord Clip 1
17A FFV0730016S Cord 1 LP-03,For Style A of Version A
17B FFV0730020S Cord 1 VLP-03,For Version B and Style B of Version A
18 FFV0760028S Capacitor Box 1
19 FFV7000009S Truss Tap Screw(4*8) 3 For Fixing Cord Clip(1pcs) and Capacitor Box(2pcs)
20 FFV1600059S Frame Assy. 1
21 FFV0800001S Casing Support 3
22 FFV7000064S Bind Screw(4*6) 3 For Fixing Casing Support to Frame Assy.
23 FFV0420013S Bracket Cover 1
24 FFV7000018S Truss Tap Screw(4*6) 4 For Fixing Bracket Cover to Frame Assy.
25AA FFV0000018S Adapter Assy. 1 Adapt to the Style A of Version A
25AB FFV0000044S Adapter Assy. 1 Adapt to the Style B of Version A
25B FFV0000029S Adapter Assy. 1 For Version B
26 FFV7000065S Bind Screw(4*12) 3 For Fixing Casing to Casing Support
27 FFV7020015S Hexagon Nut 1 For Earth
28A FFV0900008S Connector Plate 1 For Style A of Version A
28B FFV0900012S Connector Plate 1 For Version B and Style B of Version A
29A FFV0900002S Connector Assy. 1 LR-03,For Style A of Version A
29B FFV0900013S Connector Assy. 1 VLR-03,For Version B and Style B of Version A
30 FFV7000091S Pan Tap Screw 2 For Fixing Connector Plate and Junction Cover
31 FFV3402103S Lead Wire 1 For Earth
32 FFV2800004S Junction Cover 1
33B FFV0010151S Accessory Set 1 For USA Market,Use In Version B
(33B) FFV0010150S Accessory Set 1 For CA Market,Use In Version B
34 FFV4710210S Grille Pad Assy. 1 For Grille Assy. Packing
!
!
!
!
!
!
!
!
!
!

FV-05VQ3
15
3. Parts List
No. Part No. Part Name Q'ty Remark
35 FFV4710203S Left Pad 1 Mark With"L"
36 FFV4710204S Right Pad 1 Mark With"R"
37 FFV9000540S Packing Case Assy. 1
38 FFV0420021S Suspension Bracket IV 1 Attachment,Use In Version A
39 FFV5710011S Suspension Bracket III 1 Attachment,Use In Version A
40 FFV0420015S Suspension Bracket II 1 Attachment,Use In Version A
41 FFV0420014S Suspension Bracket I 1 Attachment,Use In Version A
42 FFV5710017S Suspension Bracket III 1 Attachment,Use In Version B
43 FFV5710018S Suspension Bracket II 1 Attachment,Use In Version B
44 FFV5710019S Suspension Bracket I 1 Attachment,Use In Version B
45A FFV2540008S Installation Instruction 1 English,Use In Version A
45B FFV2540009S Installation Instruction 1 English,Use In Version B
46 FFV2540021S Installation Instruction 1 Spanish,For USA Market,Use In Version B
(46) FFV2540030S Installation Instruction 1 French,For CA Market,Use In Version B
47 FFV0010076S Accessory A 1 Included Installation Screws
48 FFV6720003S Warranty Sheet(USA) 1 For USA Market
(48) FFV6720002S Warranty Sheet(CA) 1 For CA Market

16
FV-08/11VQ3
3. Parts List
No. Part No. Part Name Q'ty Remark
1 FFV3402111S Grille Assy. 1
2 FFV4300080S Orifice Cover 1
3 FFV4300081S Orifice 1
4 FFV0790025S Casing 1
5 FFV4610032S Sponge 1 1 For Casing and Motor Support
6 FFV7020016S Domed Cap Nut 1 For Blade
7 FFV7010003S Spring Washer 1 For Blade
8 FFV7010012S Plain Washer 1 For Blade
9 FFV4670003S Blade Set Plate 1 For Blade
10 FFV0400061S Blade 1
11 FFV3730014S Motor Support 1
12 FFV3700175S Motor Assy. 1 For FV-08VQ3(120V, 60Hz)
(12) FFV3700176S Motor Assy. 1 For FV-11VQ3(120V, 60Hz)
13 FFV7000025S Truss Tap Screw 4 For Fixing Motor Assy. to Motor Support
14 FFV7000106S Truss Pc Screw 9 For Fixing Motor Support(5pcs) and Orifice(4pcs)
15 FFV0750106S Capacitor 1 For FV-08VQ3(250V 2.2uF)
(15) FFV0750107S Capacitor 1 For FV-11VQ3(250V 3.0uF)
16 FFV2530001S Insulock Tie 1
17 FFV0900024S Connector 3
18 FFV0740007H Cord Clip 1
19A FFV0730016S Cord 1 LP-03,For Style A of Version A
19B FFV0730020S Cord 1 VLP-03,For Version B and Style B of Version A
20 FFV7030001S Earth Wire Screw 2 For Fixing Earth Wire
21 FFV0760028S Capacitor Box 1
22 FFV7000009S Truss Tap Screw(4*8) 3 For Fixing Cord Clip(1pcs) and Capacitor Box(2pcs)
23 FFV1600060S Frame Assy. 1
24 FFV0800001S Casing Support 3
25 FFV7000064S Bind Screw(4*6) 3 For Fixing Casing Support to Frame Assy.
26 FFV0420013S Bracket Cover 1
27 FFV7000018S Truss Tap Screw 4 For Fixing Bracket Cover to Frame Assy.
28AA FFV0000019S Adapter Assy. 1 Adapt to the Style A of Version A
28AB FFV0000043S Adapter Assy. 1 Adapt to the Style B of Version A
28B FFV0000030S Adapter Assy. 1 For Version B
29 FFV7000065S Bind Screw(4*12) 3 For Fixing Casing to Casing Support
30 FFV7020015S Hexagon Nut 1 For Earth
31A FFV0900008S Connector Plate 1 For Style A of Version A
31B FFV0900012S Connector Plate 1 For Version B and Style B of Version A
32A FFV0900002S Connector Assy. 1 LR-03,For Style A of Version A
32B FFV0900013S Connector Assy. 1 VLR-03,For Version B and Style B of Version A
33 FFV7000091S Pan Tap Screw 2 For Fixing Connector Plate and Junction Cover
!
!
!
!
!
!
!
!
!
!

17
FV-08/11VQ3
3. Parts List
No. Part No. Part Name Q'ty Remark
34 FFV3402103S Lead Wire 1 For Earth
35 FFV2800004S Junction Cover 1
36B FFV0010151S Accessory Set 1 For USA Market,Use In Version B
(36B) FFV0010150S Accessory Set 1 For CA Market,Use In Version B
37 FFV4710034S Grille Pad Assy. 1 For Grille Assy. Packing
38 FFV4710203S Left Pad 1 Mark With"L"
39 FFV4710204S Right Pad 1 Mark With"R"
40 FFV9000141S Packing Case Assy. 1 For FV-08VQ3
(40) FFV9000142S Packing Case Assy. 1 For FV-11VQ3
41 FFV0420021S Suspension Bracket IV 1 Attachment,Use In Version A
42 FFV5710011S Suspension Bracket III 1 Attachment,Use In Version A
43 FFV0420015S Suspension Bracket II 1 Attachment,Use In Version A
44 FFV0420014S Suspension Bracket I 1 Attachment,Use In Version A
45 FFV5710017S Suspension Bracket III 1 Attachment,Use In Version B
46 FFV5710018S Suspension Bracket II 1 Attachment,Use In Version B
47 FFV5710019S Suspension Bracket I 1 Attachment,Use In Version B
48A FFV2540008S Installation Instruction 1 English,Use In Version A
48B FFV2540009S Installation Instruction 1 English,Use In Version B
49 FFV2540021S Installation Instruction 1 Spanish,For USA Market,Use In Version B
(49) FFV2540030S Installation Instruction 1 French,For CA Market,Use In Version B
50 FFV0010076S Accessory A 1 Included Installation Screws
51 FFV6720003S Warranty Sheet(USA) 1 For USA Market
(51) FFV6720002S Warranty Sheet(CA) 1 For CA Market
!

18
FV-15VQ4
3. Parts List
No. Part No. Part Name Q'ty Remark
1 FFV3402111S Grille Assy. 1
2 FFV4300080S Orifice Cover 1
3 FFV4300082S Orifice 1
4 FFV0790026S Casing 1
5 FFV4610032S Sponge 1 1 For Casing and Motor Support
6 FFV7020016S Domed Cap Nut 1 For Blade
7 FFV7010003S Spring Washer 1 For Blade
8 FFV7010012S Plain Washer 1 For Blade
9 FFV4670003S Blade Set Plate 1 For Blade
10 FFV0400062S Blade 1
11 FFV3730015S Motor Support 1
12 FFV3700177S Motor Assy. 1 120V, 60Hz
13 FFV7000025S Truss Tap Screw 3 For Fixing Motor Assy. to Motor Support
14 FFV7000106S Truss Pc Screw 9 For Fixing Motor Support(5pcs) and Orifice(4pcs)
15 FFV0750108S Capacitor 1 250V 4.0uF
16 FFV2530001S Insulock Tie 1
17 FFV0900024S Connector 3
18 FFV0740007H Cord Clip 1
19A FFV0730016S Cord 1 LP-03,For Style A of Version A
19B FFV0730020S Cord 1 VLP-03,For Version B and Style B of Version A
20 FFV7030001S Earth Wire Screw 2 For Fixing Earth Wire
21 FFV0760028S Capacitor Box 1
22 FFV7000009S Truss Tap Screw(4*8) 3 For Fixing Cord Clip(1pcs) and Capacitor Box(2pcs)
23 FFV1600060S Frame Assy. 1
24 FFV0800001S Casing Support 3
25 FFV7000064S Bind Screw(4*6) 3 For Fixing Casing Support to Frame Assy.
26 FFV0420013S Bracket Cover 1
27 FFV7000018S Truss Tap Screw(4*6) 4 For Fixing Bracket Cover to Frame Assy.
28AA FFV0000022S Adapter Assy. 1 For Style A of Version A
28AB FFV0000042S Adapter Assy. 1 For Style B of Version A
28B FFV0000031S Adapter Assy. 1 For Version B
29 FFV7000065S Bind Screw(4*12) 3 For Fixing Casing to Casing Support
30 FFV7020015S Hexagon Nut 1 For Earth
31A FFV0900008S Connector Plate 1 For Style A of Version A
31B FFV0900012S Connector Plate 1 For Version B and Style B of Version A
32A FFV0900002S Connector Assy. 1 LR-03,For Style A of Version A
32B FFV0900013S Connector Assy. 1 VLR-03,For Version B and Style B of Version A
33 FFV7000091S Pan Tap Screw 2 For Fixing Connector Plate and Junction Cover
34 FFV3402103S Lead Wire 1 For Earth
35 FFV2800004S Junction Cover 1
!
!
!
!
!
!
!
!
!

19
FV-15VQ4
3. Parts List
No. Part No. Part Name Q'ty Remark
36B FFV0010151S Accessory Set 1 For USA Market,Use In Version B
(36B) FFV0010150S Accessory Set 1 For CA Market,Use In Version B
37 FFV4710034S Grille Pad Assy. 1 For Grille Assy. Packing
38 FFV4710203S Left Pad 1 Mark With"L"
39 FFV4710204S Right Pad 1 Mark With"R"
40 FFV9000143S Packing Case Assy. 1
41 FFV0420021S Suspension Bracket IV 1 Attachment,Use In Version A
42 FFV5710011S Suspension Bracket III 1 Attachment,Use In Version A
43 FFV0420015S Suspension Bracket II 1 Attachment,Use In Version A
44 FFV0420014S Suspension Bracket I 1 Attachment,Use In Version A
45 FFV5710017S Suspension Bracket III 1 Attachment,Use In Version B
46 FFV5710018S Suspension Bracket II 1 Attachment,Use In Version B
47 FFV5710019S Suspension Bracket I 1 Attachment,Use In Version B
48A FFV2540008S Installation Instruction 1 English,Use In Version A
48B FFV2540009S Installation Instruction 1 English,Use In Version B
49 FFV2540021S Installation Instruction 1 Spanish,For USA Market,Use In Version B
(49) FFV2540030S Installation Instruction 1 French,For CA Market,Use In Version B
50 FFV0010076S Accessory A 1 Included Installation Screws
51 FFV6720003S Warranty Sheet(USA) 1 For USA Market
(51) FFV6720002S Warranty Sheet(CA) 1 For CA Market
