Panasonic CF-54 Series User manual

Useful Information
Handling and Maintenance.......................... 17
Installing Software ....................................... 21
Getting Started
Introduction..................................................... 2
Description of Parts ........................................ 4
First-time Operation........................................ 8
Turning On / Turning Off.............................. 15
Troubleshooting
Troubleshooting (Basic)............................... 27
Appendix
LIMITED USE LICENSE AGREEMENT...... 34
Specications .............................................. 36
Standard Limited Warranty.......................... 41
Useful Information
Troubleshooting
Appendix Getting Started
Contents
OPERATING INSTRUCTIONS
Basic Guide
Personal Computer
Model No. CF-54series
Please read these instructions carefully before using this product, and save this manual for future use.

2
Getting Started
Thank you for purchasing this Panasonic product. For optimum performance and safety, please
read these instructions carefully.
In these instructions, the names are referred as follows.
indicates Windows®8.1 Operating System.
indicates Windows®7 Operating System.
nTerms and illustrations in these instructions
CAUTION : Conditions that may result in minor or moderate injury.
NOTE : Useful and helpful information.
Enter
: Press [Enter] key.
Fn
+
F5
: Press and hold [Fn] key, and then press [F5] key.
lDisplay “Charm”: Align the pointer to the top right (or bottom right) corner of the
screen to display Charm menu. Alternatively, ick toward the cen-
ter of the screen from the right edge.
l- : Click (Settings) and then click (Power).
(Start) - [All Programs] : Click (Start), and then click [All Programs]. You may need to
double-click in some cases.
è: Page in these Operating Instructions or in the Reference Manual.
: Reference to the on-screen manuals.
l Some illustrations are simplied to help your understanding and may look different from the
actual unit.
lIf you do not log on as an administrator, you cannot use some functions or cannot display
some screens.
lRefer for the latest information about optional products to the catalogs, etc.
lIn these instructions, the names and terms are referred as follows.
“Windows®8.1 Pro Update 64-bit” as “Windows” or “Windows 8.1”
“Windows®7 Professional 32-bit Service Pack 1” and “Windows®7 Professional 64-bit
Service Pack 1” as “Windows” or “Windows 7”
DVD MULTI drive as “CD/DVD drive”
Circular media including DVD-ROM and CD-ROM as “discs”
“Multilanguage User Interface” as “MUI”
l
Screen messages are explained in [English (United States)].
(Depending on the language preference, some screen messages in these instructions are dif-
ferent from the actual screen messages. For example, [Flight mode] may be displayed instead
of [Airplane mode] in some language preference.)
nDisclaimer
Computer specications and manuals are subject to change without notice. Panasonic Corpora-
tion assumes no liability for damage incurred directly or indirectly from errors, omissions or dis-
crepancies between the computer and the manuals.
Introduction

3
Getting Started
nTrademarks
Microsoft®, Windows®, the Windows logo, and IntelliMouse are registered trademarks of Microsoft
Corporation of the United States and/or other countries.
Intel, Core and PROSet are either registered trademarks or trademarks of Intel Corporation.
SDXC Logo is a registered trademark of SD-3C, LLC.
Adobe, the Adobe logo and Adobe Reader are either registered trademarks or trademarks of
Adobe Systems Incorporated in the United States and/or other countries.
Bluetooth®is a registered trademark owned by Bluetooth SIG, Inc., U.S.A. and licensed to
Panasonic Corporation.
HDMI, the HDMI Logo and High-Denition Multimedia Interface are trademarks or registered
trademarks of HDMI Licensing LLC in the United States and other countries.
Names of products, brands, etc., appearing in this manual are trademarks or registered trade-
marks of their respective own companies.
nOn-screen Manual
For further information about the computer, you can refer to the on-screen manual.
lReference Manual
The Reference Manual contains the practical information to help you fully enjoy the comput-
er’s performance. Update it to the latest version for reference.
lImportant Battery Tips
The Important Battery Tips will provide you with the battery information so that you can use
the battery in the optimum condition to obtain longer operation time.
lUpdate the on-screen manuals
This describes the procedures to update the on-screen manual.
lConnect to a network
This describes the connection procedures using the network devices mounted on this unit.
To access the on-screen manuals, follow the steps below.
Double-click [Manual Selector] on the desktop, and select the on-screen manual.
Alternatively, click the [Manual Selector] tile, on the Start screen and select the on-screen manu-
al.
NOTE
[Contents] tab or [Search] tab of the on-screen manuals is displayed on the left side of the
window. Select tab and display the desired item.

4
Getting Started
Description of Parts
Camera
<Only for model with camera>
èReference Manual “Camera”
A: Microphone
B: Ambient Light Sensor
C: Camera Lens
D: Camera Indicator
E: LCD
<Only for model with touchscreen>
è Reference Manual “Screen Input Operation”
F: LED Indicator
: Caps lock
: Numeric Lock (NumLk)
: Scroll Lock (ScrLk)
: Drive Indicator
: SD Memory Card Indicator
(Blinking: During access or a pass-
word is requested)
è
Reference Manual “SD Memory Card”
: Wireless ready
This indicator lights when Wireless
LAN, Bluetooth, and/or Wireless WAN
are connected and ready. It does not
necessarily indicate the On/Off condi-
tion of the wireless connection.
è
Connect to a network
G: Power Switch
H: Security Lock
A Kensington cable can be connected. For
further information, read the manual that
comes with the cable.
I: Function Keys
è
Reference Manual “Key Combinations”
J: Keyboard
K: CD/DVD Drive*1 / PC Card Slot*2 /
Battery Pack Slot 2*3 / Smart Card Slot*4
*1 Only for model with CD/DVD drive
è
Reference Manual
“CD/DVD Drive”
*2 Only for model with PC card slot
è
Reference Manual
“PC Card”
*3 When using battery pack 2
è
Reference Manual
“Battery Power”
*4 Only for model with smart card slot
L: Battery Pack Slot 1
è
Reference Manual
“Battery Power”
M: Fingerprint Reader*5 / Contactless
Smart Card Reader*6
*5 Only for model with ngerprint reader
è
Reference Manual “Fingerprint Reader”
*6 Only for model with contactless smart
card reader
è
Reference Manual “Contactless Smart Card Reader”
N: Touchpad
èReference Manual “Touchpad”
O: Carrying Handle
Do not use the handle if the handle is worn
or damaged.
P: LED Indicator
: Power Indicator
Off: Power off/Hibernation, Green:
Power on, Blinking Green: Sleep
Blinking green rapidly: Cannot power
on or resume due to low temperature.
: Battery Indicator 1
: Battery Indicator 2*3
èReference Manual “Battery Power”
A
B
C
D
E
F
G
H
I
J
K
LP
O
N
Fingerprint
Reader
Contactless
Smartcard
Reader
M

5
Getting Started
A: Wireless WAN Antenna
<Only for model with wireless WAN>
è
Connect to a network “Wireless WAN”
B: GPS Antenna
<Only for model with GPS>
è
Reference Manual
“GPS”
C: Display Latch
D: Wireless LAN Antenna
<Only for model with wireless LAN>
è
Connect to a network
“Wireless LAN”
E: Speaker
F: Wireless LAN Antenna / Bluetooth Antenna
<Only for model with wireless LAN / Bluetooth>
è
Connect to a network
“Wireless LAN”
“Bluetooth”
NOTE
lThis computer contains a magnet and
magnetic products at the locations dashed
line circled in the illustration above. Avoid
leaving metallic object or magnetic media
in contact with these areas.
A
B
C
D
E
F

6
Getting Started
Description of Parts
A: Hard Disk Drive (Quick Release Drive)
è
Reference Manual “Hard Disk Drive”
B: Wireless Switch
è
Connect to a network
“Disabling/
Enabling Wireless Communication”
C: Headset Jack
A headset or headphone can be connected.
D: SD Memory Card Slot
Keep SD Memory Cards away from infants
and small children.
è
Reference Manual
“SD Memory
Card”
E: USB 3.0 Ports
è
Reference Manual
“USB Devices”
F: USB 3.0 Port (USB Charging)
Do not insert any foreign object in the USB port.
è
Reference Manual
“USB Devices”
G: LAN Port
è
Connect to a network
“LAN”
H: DC-IN Jack
I: HDMI Port
è
Reference Manual
“External Display”
J: SIM Card Slot
<Only for model with wireless WAN>
èConnect to a network “Wireless WAN”
K: Ventilation Hole (Exhaust)
L: VGA Port
<Only for model with VGA port>
èReference Manual “External Display”
M: Serial Port
<Only for model with Serial port>
è
Reference Manual
“Serial Port”
N: 2nd LAN Port*7/ USB 2.0 Port*8 /
Rugged USB 2.0 Port*9 / GPS*10
*7 Only for model with 2nd LAN port
*8 Only for model with USB 2.0 port
*9 Only for model with rugged USB 2.0 port
*10 Only for model with GPS
E I J K LM
N*8N*9 N*7
ABCD EFGH
Right side
Rear side

7
Getting Started
A: Back Cover
B: Ventilation Hole (Intake)
C: Hard Disk Latch
è
Reference Manual “Hard Disk Drive”
D: Expansion Bus Connector
è
Reference Manual
“Port replicator”
E: Battery Latch 1
è
Reference Manual
“Battery Power”
F: Battery Indicator
è
Reference Manual
“Battery Power”
G: Battery Pack Latch 2
<When using battery pack 2>
è
Reference Manual
“Battery Power”
H: External Antenna Connector
<Only for model with External Antenna Connector>
A
B
C
D
E
G
F
H
A
Bottom side

8
Getting Started
First-time Operation
nPreparation
ACheck and identify the supplied accessories.
If you do not nd the described accessories, contact your support ofce.
• AC Adaptor.....1
Model No: CF-AA5713A
• AC Cord .......1 • Battery Pack ...1
Model No: CF-VZSU0GW or
CF-VZSU0PW or
CF-VZSU0LW
<Only for model with touchscreen>
• Soft Cloth ......1
• OPERATING INSTRUCTIONS - Basic Guide (This book)................ 1
Depending on the model, the following items are supplied.
• Battery Pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Model No: CF-VZSU0KW
CAUTION
lMake sure the latch is securely locked. Otherwise the battery
pack may fall when you carry the computer.
lDo not touch the terminals of the battery pack and the com-
puter. Doing so can make the terminals dirty or damaged,
and may cause malfunction of the battery pack and the com-
puter.
1 Insert the battery pack
Insert the battery pack until it touch to the secured position.
1
<For CF-VZSU0KW>

9
Getting Started
2 Connect your computer to a power outlet
The battery charging starts automatically.
CAUTION
lDo not disconnect the AC adaptor and do not switch the
wireless switch to on until the rst-time operation procedure
is completed.
l When using the computer for the rst time, do not connect
any peripheral device except the battery pack and AC adap-
tor.
lHandling the AC adaptor
Problems such as sudden voltage drops may arise during
periods of thunder and lightning. Since this could adversely
affect your computer, an uninterruptible power source (UPS)
is highly recommended unless running from the battery pack
alone.
lWhen the DC plug is not connected to the computer, dis-
connect the AC cord from your electrical outlet. Power is
consumed simply by having the AC adaptor plugged into an
electrical outlet.
3 Open the display
APush the top of the latch (A) to release it.
BHold the side/ handle of the computer with either of your
hands and then lift up the display to open.
CAUTION
lDo not open the display wider than necessary (180° or
more), and do not apply excessive pressure to the LCD. Do
not open or close the computer holding the edge of the LCD
segment.
2
㪘1
2
3

10
Getting Started
First-time Operation
㻮
㻯
4
4 Turn on the computer
Press and hold the power switch (B) until the power indicator (C)
lights.
CAUTION
lDo not press the power switch repeatedly.
lThe computer will be forcibly turned off if you press and hold
the power switch for four seconds or longer.
lOnce you turn off the computer, wait for ten seconds or more
before you turn on the computer again.
lDo not perform the following operation until the drive indica-
tor turns off.
Connecting or disconnecting the AC adaptor
Pressing the power switch
Touching the keyboard, touchpad, touchscreen <only for
model with touchscreen> or external mouse
Closing the display
Turn on/off the wireless switch
lWhen the CPU temperature is high, the computer may not
start up to prevent overheating of the CPU. Wait until the
computer cools down, and then turn the power on again. If
the computer does not power on even after cooling down,
contact Panasonic Technical Support (èpages 41 - 43).
lAny changes from the default setting of the Setup Utility must
not be made until the First-time Operation is completed.
5
<For MUI OS model>
Select language and OS (32-bit or 64-bit)
CAUTION
lCarefully choose your language because you cannot change
it later. If you set a wrong language, you need to reinstall
Windows.
ASelect language and OS (32-bit or 64-bit) on “Select OS”
screen and touch [OK].
The language setting will start by touching [OK] on the
conrmation screen.
The language and OS setting will be completed in about
15 minutes.
BWhen termination screen is displayed, touch [OK] to turn
off the computer.

11
Getting Started
6 Setup Windows
Select language and click [Next].
Turn on the computer.
Follow the on-screen instructions.
lThe computer restarts several times. Do not touch the key-
board or touchpad, and wait until the drive indicator has
turned off.
lAfter the computer is turned on, the screen remains black
or unchanged for a while, but this is not a malfunction. Wait
for a moment until the Windows setup screen appears.
lDuring setup of Windows, use the touchpad and clicking to
move the pointer and to click an item.
lSetup of Windows will take approximately
5 minutes / 20 minutes.
Go to the next step, conrming each message on the dis-
play.
lYou can set the Wireless Network after the setup of
Windows is complete.
If “Get online” is displayed, select “Skip this step”.
“Join a wireless network” screen may not appear.
lVerify the time zone, date and time.
CAUTION
lYou can change the user name, password, image and secu-
rity setting after setup of Windows.
lRemember your password. If you forget the password, you
cannot use Windows. Creating a password reset disk before-
hand is recommended.
lUse standard characters as a computer name: numbers 0
through 9, uppercase and lowercase letters from A to Z, and
the hyphen (-) character. If the error message “The computer
name is not valid” appears, check if characters other than
the above are not entered. If the error message still remains
on the display, set the key entry mode to English (“EN”) and
enter characters.
<For MUI OS model>
lWhen setting up the keyboard, choose the appropriate one
to your computer.
Otherwise, input by the keyboard may become unavailable.
lDo not use the following words and characters for user
name: CON, PRN, AUX, CLOCK$, NUL, COM1 to COM9,
LPT1 to LPT9, LPT, @, &, space. In particular, if you create
a user name (account name) that includes the “@” mark, a
password will be requested at the log-on screen, even if no
password has been set. If you try to log on without entering
a password, “The user name or password is incorrect.” may
be displayed and you will not be able to sign in /
log on to Windows (èpage 30).

12
Getting Started
First-time Operation
7 Update the on-screen manual
AConnect to the internet. Sign in /
Log on to Windows as an administrator.
For further information, refer to Connect to a network.
BUpdate the on-screen manual.
Double-click [Manual Selector] on the desktop.
Alternatively, click the [Manual Selector] tile
on the Start screen.
Follow the on-screen instructions.
8 Create a recovery disc
A recovery disc allows you to install OS and restore its factory
default condition, in case, the recovery partition of the HDD is
damaged.
We recommend creating a recovery disc before you begin using
the computer.
Refer to è
Reference Manual
“Recovery Disc Creation Util-
ity” about creating the disc.

13
Getting Started
NOTE
lPC Information Viewer
This computer periodically records the management information of the hard disk, etc. The maxi-
mum data volume for each record is 1024 bytes.
This information is only used for estimating the cause in the case when the hard disk goes down by
any possibility. They are never sent to outside via network nor used for any other purpose except
for the purpose described the above.
To disable the function, add the check mark for [Disable the automatic save function for manage-
ment information history] in [Hard Disk Status] of PC Information Viewer, and click [OK].
(èReference Manual “Troubleshooting (Advanced)” - “Checking the Computer’s Usage Status”)
Then follow the on-screen instructions.
<For MUI OS model>
lIn the default settings, a shortcut icon for Korean language is on the Desktop
screen. You may delete the icon if not necessary.
lIf the recovery partition is deleted, you cannot create Recovery Disc(s).
nBefore using wireless function
AOpen the cover, and then Slide the wireless switch to ON.
BDisplay “Charm” and click - [Change PC Settings] - [Network] - [Airplane mode].
Set [Airplane mode] to [Off], and then;
Set [Wi-Fi] to [On] (for wireless LAN).
Set [Mobile broadband] to [On] (for wireless WAN).
Set [GPS] to [On] (for wireless WAN).
Set [Bluetooth] to [On] (for Bluetooth).
Set [GPS\GNSS] to [On] (for GPS).
nTo change the partition structure
You can shrink a part of an existing partition to create unallocated disk space, from which you can
create a new partition.
In the default setting, you can use a single partition.
A
Right-click at the bottom left corner of the Desktop screen.
Click (Start) and right-click [Computer], then click [Manage].
lA standard user needs to enter an administrator password.
BClick [Disk Management].
CRight-click the partition for Windows (“c” drive in the default setting), and click [Shrink Vol-
ume].
l The partition size depends on the computer specications.
DInput the size in [Enter the amount of space to shrink in MB] and click [Shrink].
lYou cannot input a larger number than the displayed size.
lTo select [Reinstall Windows to the OS related partitions] in installing OS (èpage 23),
70 GB*1 / 60 GB or more is necessary for [Total size after shrink
in MB].
ERight-click [Unallocated] (the shrunk space in the step D) and click [New Simple Volume].
FFollow the on-screen instructions to make the settings, and click [Finish].
Wait until formatting is completed.
*1 For MUI OS model, 80 GB or more is necessary.

14
Getting Started
First-time Operation
NOTE
lYou can create an additional partition using remaining unallocated space or newly creating
unallocated space.
lTo delete a partition, right-click the partition and click [Delete Volume] in the step C.
n<For MUI OS model> To select language
To select a language other than the one you have selected during the rst-time operation, follow
the steps below.
APerform either of the following procedures.
lRight-click at the bottom left corner of the Desktop screen.
lClick on the Start screen.
BClick [Control Panel].
CClick [Clock, Language, and Region] - [Language] - [Add a language].
DSelect a language, and then click [Add].
Depending on the region, two or more languages are selectable. Click [Open] and select
the desired language, and then click [Add].
EClick [Options] for the language you want to use.
FClick [Make this the primary language].
NOTE
lIf [Make this the primary language] is not displayed, you cannot change to this lan-
guage. Follow the on-screen instructions.
GClick [Log off now].
HSign in to the Windows.

15
Getting Started
Turning On / Turning Off
Turning On
Press and hold the power switch (èpage 4) until the power indicator (èpage 4) lights.
NOTE
lDo not press the power switch repeatedly.
lThe computer will forcibly be turned off if you press and hold the power switch for four sec-
onds or longer.
lOnce you turn off the computer, wait for ten seconds or more before you turn on the computer
again.
lDo not perform the following operation until the drive indicator turns off.
• Connecting or disconnecting the AC adaptor
• Pressing the power switch
• Touching the keyboard, touchpad, touchscreen <only for model with touchscreen> or exter-
nal mouse
• Closing the display
• Turn on/off the wireless switch
Turning Off
You can shut down the computer by using either of the following steps.
• From the Desktop screen:
ARight-click at the bottom left corner of the Desktop screen.
BClick [Shut down or sign out] - [Shut down].
•From the Start screen:
AClick - [Shut down].
• Both the Start screen and Desktop screen:
ADisplay “Charm” and touch .
BTouch [Power] - [Shut down].
AClick (Start) - [Shutdown].
NOTE
l
To turn off the computer completely, proceed as follows.
ADisplay “Charm” and click - [Change PC settings] - [Update and recovery] - [Recovery].
BClick [Restart now] under “Advanced startup”.
CClick [Turn off your PC].

16
Getting Started
Turning On / Turning Off
Precautions against Starting Up/Shutting Down
lDo not do the following
• Connecting or disconnecting the AC adaptor
• Pressing the power switch
• Touching the keyboard, touchpad, touchscreen <only for model with touchscreen> or exter-
nal mouse
• Closing the display
• Turn on/off the wireless switch
NOTE
lTo conserve power, the following power saving methods are set at the time of purchase.
• The screen automatically turns off after :
10 minutes (when AC adaptor is connected) of inactivity
5 minutes (when operating on battery power) of inactivity
• The computer automatically enters sleep*1 after :
20 minutes (when AC adaptor is connected) of inactivity
15 minutes (when operating on battery power) of inactivity
*1 Refer to Reference Manual “Sleep or Hibernation Functions” about resuming from sleep.

17
Useful Information
Handling and Maintenance
Operation environment
l Place the computer on a at stable surface not subject to shock, vibration, and danger of
dropping. Do not place the computer upright or turn it over. If the computer is exposed to an
extremely strong impact, it may become damaged.
lOperating environment
Temperature: Operation : -10 °Cto 50 °C(IEC60068-2-1, 2)*1
Storage : -20 °Cto 60 °C
Humidity: Operation : 30% to 80% RH (No condensation)
Storage : 30% to 90% RH (No condensation)
Even within the above temperature/humidity ranges, operation for a long time in extreme en-
vironments, smoking nearby, or operation in places where oil is used or where there is a lot of
dust will result in the product deterioration and will shorten the product life.
*1 Do not expose the skin to this product when using the product in a hot or cold environment.
(èOPERATING INSTRUCTIONS - Read Me First)
If the computer is wet in temperatures of 0 °Cor below, freeze damage may occur. Make sure to dry off
the computer in such temperatures.
lDo not place the computer in the following areas, otherwise the computer may be damaged.
Near electronic equipment. Image distortion or noise may occur.
In extremely high or low temperature.
lAs the computer can become hot during operation, keep it away from items that are sensitive
to heat.
Handling cautions
This computer is designed to minimize shock to parts such as the LCD and the hard disk drive
and equipped with a drip-proof keyboard, but no warranty is provided against any trouble caused
by shock. Be extremely careful when handling the computer.
lWhen carrying the computer:
Turn off the computer.
Remove all external devices, cables, PC Cards and other protruding objects.
Remove a disc in the CD/DVD drive (Only for model with CD/DVD drive).
Do not drop or hit the computer against solid objects.
Do not leave the display open.
Do not grip the display part.
lDo not put anything (e.g., a piece of paper) between the display and keyboard.
lWhen you board an airplane, take the computer with you and never put it in your checked lug-
gage. When using the computer on airplane, follow the airline’s instructions.
lWhen carrying a spare battery, put it in a plastic bag to protect its terminals.
l The touchpad is designed to be used by nger tip. Do not place any object on its surface and
do not press down strongly with sharp-pointed or hard objects that may leave marks (e.g.,
nails, pencils and ball point pens).
lAvoid any harmful substances such as oil from getting into the touchpad. The pointer may not
work correctly.
lBe careful not to get injured by dropping or getting hit when carrying the computer.
<Only for model with touchscreen>
lUse only the pen (optional) to touch the screen. Do not place any object on its surface and do
not press down strongly with sharp-pointed or hard objects that may leave marks (e.g., nails,
pencils and ball point pens).
lDo not use the screen when dust or dirt (e.g., oil) is on the screen. Otherwise foreign particles
on the screen/pen (optional) can scratch the screen surface or obstruct the pen (optional)
operation.

18
Useful Information
Handling and Maintenance
lUse the pen (optional) only for touching the screen. Using it for any other purpose may dam-
age the pen (optional) and result in scratches on the screen.
nWhen using peripheral devices
Follow these instructions and the Reference Manual to avoid any damage to the devices. Care-
fully read the instruction manuals of the peripheral devices.
l Use the peripheral devices conforming to the computer’s specications.
lConnect to the connectors in the correct direction.
lIf it is hard to insert, do not try forcibly but check the connector’s shape, direction, alignment of
pins, etc.
lIf screws are included, fasten them securely.
lRemove the cables when you carry the computer. Do not pull the cables forcibly.
nPreventing your computer from unauthorized use via wireless LAN/Bluetooth/wireless
WAN
<Only for model with wireless LAN/Bluetooth/wireless WAN>
lBefore using wireless LAN/Bluetooth/wireless WAN, make the appropriate security settings
such as data encryption.
nBattery Recalibration
lThe battery recalibration may take a long time due to the large battery capacity. This is not a
malfunction.
<When performing “Battery Recalibration” after shutting down Windows>
Full charge: Approximately 2.5 hours
Complete discharge: Approximately 4 hours (with CF-VZSU0GW / CF-VZSU0PW /
CF-VZSU0LW) / Approx. 3 hours (with CF-VZSU0KW)
When performing “Battery Recalibration” without shutting down Windows, it may take more
time to charge / discharge.
nBattery duration
lNote that the computer consumes electricity even when the computer power is off. If the bat-
tery pack is fully charged, the battery will fully discharge in the following period of time:
Status Discharge period
CF-VZSU0GW / CF-VZSU0PW CF-VZSU0LW
When power is off Approx. 5 weeks Approx. 3.5 weeks
In sleep*2 Approx. 2.5 days Approx. 2 days
In hibernation*2 Approx. 12 days Approx. 8.5 days
*2 When “Wake Up from wired LAN” is enabled.
The battery duration while the USB port continuous charging function is not used.
Maintenance
To clean the LCD panel
If drops of water or other stains get on the surface of the LCD panel, wipe them off immediately.
Failure to do so may result in staining.
<Only for model with touchscreen>
Use the soft cloth included with the computer. (For further information, refer to “Suggestions
About Cleaning the LCD Surface”. Reference Manual “Screen Input Operation”)
<Only for model without touchscreen>
Wipe with a soft dry cloth such as gauze.

19
Useful Information
To clean areas other than the LCD panel
Wipe with a soft dry cloth such as gauze. When using detergent, dip a soft cloth in water-diluted
detergent and wring it thoroughly.
CAUTION
lDo not use benzene, thinner, or rubbing alcohol since it may adversely affect the surface caus-
ing discoloration, etc. Do not use commercially-available household cleaners and cosmetics,
as they may contain components harmful to the surface.
lDo not apply water or detergent directly to the computer, since liquid may enter inside of the
computer and cause malfunction or damage.
Dispose of Computer
nPreparation
lRemove all peripherals and SD memory card, etc.
l
Erase the stored data. (èReference Manual “Hard Disk Data Erase Utility”)
<Only for model with Built-in Bridge Battery>
<For Europe and U.S.A./Canada>
Attention Customers
Don’t remove the battery by yourself. The battery must be removed by qualied professionals.
When disposing of this product, be sure to contact qualied professionals to remove the battery.
Attention Qualied professionals to remove the battery
Dispose of this product correctly in accordance with the local regulations after removing the
battery as shown in the following procedure.
CAUTION
lNever disassemble the computer except before disposal.
lRefer to the precautions when disposing of the computer
(èOPERATING INSTRUCTIONS - Read Me First).
nRemove the built-in battery
1. Turn off the computer, and disconnect the AC adaptor.
2. Turn over the computer, remove the battery pack.
3. Remove the screws and the cover (A).
A
A
<Model with 2nd LAN/USB 2.0 port/
Rugged USB port/VGA port/Serial port/
Discrete Video Controller>

20
Useful Information
Handling and Maintenance
4. Remove the cover (B) and lift the expansion bus connector (C).
BC
è
5. Remove the connectors on the built-in bridge battery (F), and then remove the screw (D)
and the circuit (E).
D
E
F
6. Pull out the built-in bridge battery with the sheet cover.
7. Open the sheet cover (G) and remove the built-in bridge battery (H). And conrm the re-
cycle mark of the built-in battery.
8. Insulate the connectors of the built-in bridge battery by covering them with plastic tape, for example.
H
G
