Panasonic The Toughbook 31 User manual

Powerful, rugged and wireless.
Panasonic presents the Toughbook®31, the reliable laptop offering
the highest performance in its class along with the world’s most
rugged design. With drop-shock protection and a MIL-STD-810G
certification, it’s the undisputed leader in the fully-rugged category.
Its new Intel®Core™i5 and i3 processors, along with available
discrete graphics, pack a punch to deliver desktop-class performance
and improved video/3D graphics. An integrated webcam option, larger
storage capacity and up to 21 hours of battery life (with optional media
bay 2nd battery)1set the Toughbook 31 apart from the competition.
Combine six generations of delivering rugged performance plus 13
years of consistent docking compatibility, and you have a computer
that will go the distance with you anytime, anywhere.
Panasonic recommends Windows®7.
solutions for business
1.800.662.3537
panasonic.com/toughbook/31
TOUGHBOOK 31
nSunlight-viewable Touchscreen with
Panasonic CircuLumin™Technology2
nFull Magnesium Alloy Case with Handle
nDesktop-class Performance
n3G Mobile Broadband and GPS-ready Design

Power management
nSuspend/Resume Function, Hibernation, Standby, ACPI BIOS
Security featureS
nPassword Security: Supervisor, User, Hard Disk Lock
nKensington cable lock slot
nTrusted platform module (TPM) security chip v.1.22
nComputrace®theft protection agent in BIOS9
nIntel®Anti-Theft Technology2
nOptional fingerprint reader
nOptional SmartCard reader
warranty
n3-year limited warranty, parts and labor
dimenSionS & weight
n11.5"(L) x 11.9"(W) x 2.9"(H)
n7.9 or 8.2 lbs. (varies by battery type)
integrated oPtionS10
n4G LTE mobile broadband
n3G Gobi™3000 mobile broadband (EV-DO Rev. A, HSPA)
nWebcam2
nGPS receiver
nBacklit keyboard – sealed rubber or plastic emissive
n2nd LAN (10/100)2or FireWire or Modem
nSmartCard reader
nFingerprint reader
nMedia bay 2nd battery1
nHDD and battery lock
n128GB and 256GB solid state drives (SSD) with heaters
Select acceSSorieS10
nAC Adapter (3-prong) CF-AA5713AM
nLightweight Battery Pack CF-VZSU65AU
nLong Life Ion Battery Pack CF-VZSU46AU
nMedia Bay 2nd Battery1CF-VZSU1431U
nBattery Charger CF-VCBTB2W
nLIND 3-Bay Battery Charger PACH329-1857-P
nLIND Car Adapter 120W CF-LNDDC120
nLIND Car Adapter 120W Mounting Bracket CF-LNDBRK120
nLIND Shutdown Timer CF-LNDLPT
nToughMate ComUniversal
Carrying Case (large capacity) TBCCOMUNV-P
nToughMate Backpack TBCBPK-P
nToughMate Sling 31 Case TBC31CASE-P
nDVD Super MULTI Drive CF-VDM312U
nMemory Cards
– 2GB DDR3 CF-WMBA1002G
– 4GB DDR3 CF-WMBA1104G
nDesktop Dock CF-VEB311U
nVehicle Dock
– no pass-through See Dealer
– single pass-through See Dealer
– dual pass-through See Dealer
nTouchscreen Large Stylus with Tether Hole CF-VNP009U
nTether CF-VNT002U
n13.1" LCD Protector Film CF-VPF15U
Please consult your reseller or Panasonic representative before purchasing.
1Not available on 3360M.
2On i5 CPU models only.
3Tested by national independent third party lab following MIL-STD-810G Method 516.6
Procedure IV for transit drop test and IEC 60529 Sections 13.4, 13.6.2, 14.2.5 and 14.3
for IP65.
4A full set of Windows XP drivers are available at panasonic.com/toughbook/support.
5An Intel Core i7 processor is also available.
6The size of the VRAM cannot be set by the user and varies by operating system as well
as size of RAM. Windows 7 64-bit max. VRAM is 1696MB with 4GB of memory.
71GB = 1,000,000,000 bytes.
8Battery performance features such as charge time and life span can vary according to
the conditions under which the computer and battery are used. Battery operation and
recharge times will vary based on many factors, including screen brightness, applications,
features, power management, battery conditioning and other customer preferences.
Battery testing results from MobileMark 2007 running Windows 7 Professional.
9Requires software and activation to enable theft protection.
10Accessories and Integrated Options may vary depending on your notebook configuration.
Visit Panasonic website for more accessories and details.
durability nMIL-STD-810G certified (6' drop, shock, vibration, rain, dust, sand, altitude,
freeze/thaw, high/low temperature, temperature shock, humidity, explosive atmosphere)3
nMIL-STD-461F certified
nIP65 certified sealed all-weather design3
nHard drive heater
nFull magnesium alloy case with handle
nShock-mounted flex-connect hard drive with quick-release
nReinforced locking port covers
nPre-installed replaceable screen film for touchscreen protection
Software nGenuine Windows®7 Professional 32-bit4or
Genuine Windows®7 Professional 64-bit4
nPanasonic Utilities, Recovery Partition
cPu5nIntel®Core™i5-3360M vPro™Processor
– 2.8GHz with Turbo Boost up to 3.5GHz
– Intel Smart Cache 3MB
nIntel®Core™i5-3320M vPro™Processor
– 2.6GHz with Turbo Boost up to 3.3GHz
– Intel Smart Cache 3MB
nIntel®Core™i3-3110M Processor
– 2.4GHz
– Intel Smart Cache 3MB
Storage & memory ni5 models: 4GB SDRAM (DDR3L-1333MHz), expandable to 8GB6,7
ni3 model: 2GB SDRAM (DDR3L-1333MHz), expandable to 8GB6,7
nShock-mounted flex-connect hard drive with quick-release
– 500GB 7200rpm (i5 models), 320GB 5400rpm (i3 model)7
– Optional 128GB and 256GB solid state drives (SSD) with heaters7
diSPlay n13.1" XGA sunlight-viewable touchscreen LED 1024 x 768
– Panasonic CircuLumin™technology
– 2-1200 nit
– Circular polarizer2
– Anti-reflective and anti-glare screen treatments
n3360M CPU with switchable graphics in BIOS:
– ATI Radeon™HD7750, 512MB dedicated VRAM
– Intel QM77 video controller, max. 1785MB shared VRAM with 32-bit6
n3320M CPU:
– Intel QM77 video controller, max. 1419MB shared VRAM with 32-bit6
n3110M CPU:
– Intel HM75 video controller, max. 1419MB shared VRAM with 32-bit6
nExternal video support up to 1280 x 1024 at 16.7 million colors
nConcealed mode
audio nIntel®high-definition audio compliant
nIntegrated front-facing speaker
nKeyboard volume and mute controls
keyboard & inPut nTouchscreen
nIntegrated stylus holder
n87-key with dedicated Windows®key
nOptional backlit keyboard
– Sealed rubber or plastic emissive
nPressure-sensitive touchpad with vertical scrolling support
multimedia bay nOptional DVD Super MULTI Drive or 2nd battery
eXPanSion SlotS nPC card type II x 1
nSD card (SDXC)
nExpressCard/54 x 1
interface nDocking connector 80-pin
nHDMI Type A
nVGA D-sub 15-pin
nHeadphones/speaker Mini-jack stereo
nMicrophone/line in Mini-jack stereo
nSerial D-sub 9-pin
nExt. antenna conn. 50 ohm coaxial
ni5 models: USB 3.0 (x 1), USB 2.0 (x 3) 4-pin
ni3 models: USB 2.0 (x 4) 4-pin
nOptional IEEE 1394a (FireWire) 4-pin
n10/100/1000 Ethernet RJ-45
nOptional 10/100 2nd LAN (Ethernet) RJ-45
nOptional 56K Modem RJ-11
wireleSS nOptional integrated 4G LTE mobile broadband
nOptional integrated 3G Gobi™3000 mobile broadband
nIntel®Centrino®Advanced-N 6235 802.11a/b/g/n
nBluetooth®v4.0 + EDR (Class 1)
nSecurity
– Authentication: LEAP, WPA, 802.1x, EAP-TLS, EAP-FAST, PEAP
– Encryption: CKIP, TKIP, 128-bit and 64-bit WEP, Hardware AES
nUser-selectable antenna pass-through (dual standard, single optional)
nSlide on/off switch
Power SuPPly ni5 CPU:
– Battery operation: 14.5 hours (3320M), up to 12 hours (3360M)8
– Long life Li-Ion battery pack (10.65V, typical 8550mAh, minimum 8100mAh)
– Battery charge time: 3.5 hours off, 4.5 hours on8
ni3 CPU:
– Battery operation: 9 hours (with lightweight battery)8
– Lightweight Li-Ion battery pack (10.8V, typical 4500mAh, minimum 4200mAh)
– Battery charge time: 2 hours off, 2.5 hours on8
nOptional media bay 2nd battery: 6.5 additional hours (3320M and 3110M models)1
nAC Adapter: AC 100V-240V 50/60Hz, auto sensing/switching
worldwide power supply
Panasonic is constantly enhancing product specifications and accessories. Specifications subject
to change without notice. Trademarks are property of their respective owners. ©2012 Panasonic
Corporation of North America. All rights reserved. SS_TB31_09/12
