SOFTWARE nGenuine Windows®7 Professional1
nPanasonic Utilities, Recovery DVD
CPU nIntel®Core™i5-560M vPro™Processor
– 2.66GHz with Turbo Boost up to 3.2GHz
– Intel®Smart Cache 3MB
STORAGE & MEMORY n4GB SDRAM (DDR3-800MHz) standard, expandable to 6GB2,3
n320GB hard drive (shock-mounted, flex-connect and removable)3,4
nDVD Super Multi Drive
DISPLAY n14.1" widescreen WXGA+ LED 1440 x 900
nAnti-glare screen treatment
nIntel®QM57 video controller, max. 1563MB shared VRAM with 32-bit5
nExternal video support up to 1920 x 1200 at 16.7 million colors
AUDIO nIntel®high-definition audio compliant
nIntegrated stereo speakers
nKeyboard volume and mute controls
KEYBOARD & INPUT n87-key with dedicated Windows®key
nElectrostatic touchpad with circular scrolling
EXPANSION SLOTS nPC card type II x 1 (not available with SmartCard reader)
nSD Card (SDHC)
INTERFACE nDocking connector 78-pin
nVGA D-sub 15-pin
nHeadphones/speaker Mini-jack stereo
nMicrophone/line in Mini-jack stereo
nUSB 2.0 (x 3) 4-pin
n10/100/1000 Ethernet RJ-45
n56K Modem RJ-11
WIRELESS nOptional integrated 3G Gobi™2000 mobile broadband
nIntel®Centrino®Advanced-N 6200 802.11/a/b/g/n
nBluetooth®v2.1 + EDR (Class 1)
nSecurity
– Authentication: LEAP, WPA, 802.1x, EAP-TLS, EAP-FAST, PEAP
– Encryption: CKIP, TKIP, 128-bit and 64-bit WEP, Hardware AES
nSlide on/off switch
POWER SUPPLY nLithium ion battery pack (10.8V, typical 5800mAh, minimum 5400mAh)
nBattery operation: 6.5 hours6
nBattery charging time: 3.5 hours off, 5 hours on6
nAC Adapter: AC 100V-240V 50/60Hz, auto sensing/switching
worldwide power supply
POWER MANAGEMENT nSuspend/Resume Function, Hibernation, Standby, ACPI BIOS
nEconomy mode
SECURITY FEATURES nPassword Security: Supervisor, User, Hard Disk Lock
nCable lock slot
nTrusted platform module (TPM) security chip v.1.2
nComputrace®theft protection agent in BIOS7
nIntel®Anti-Theft Technology
nOptional fingerprint reader
nOptional SmartCard reader (eliminates PC card slot)
WARRANTY n3-year limited warranty, parts and labor
DIMENSIONS & WEIGHT n9.9"(L) x 12.8"(W) x 1.0"/1.9"(H) front/rear
n3.6 lbs.
INTEGRATED OPTIONS8
n3G Gobi™2000 mobile broadband (EV-DO Rev. A, HSPA)
nSmartCard reader (eliminates PC card slot)
nFingerprint reader
SELECT ACCESSORIES8
nAC Adapter (3-prong) CF-AA6503AM
nLithium Ion Battery Pack CF-VZSU56U
nLIND Car Adapter 120W CF-LNDDC120
nLIND Car Adapter 120W
Mounting Bracket CF-LNDBRK120
nLIND Car/AC Adapter 90W
(with USB port) CF-LNDACDC90
nLIND Car Adapter 80W CF-LNDDC80
nLIND Shutdown Timer CF-LNDLPT
nToughMate ComUniversal
Carrying Case (large capacity) TBCCOMUNV-P
nToughMate Business-rugged
Top-loading Case TBCBRTL-P
nToughMate ComUniversal Roller TBCRLR-P
nToughMate Backpack TBCBPK-P
nMemory Cards
– 2GB DDR3 CF-WMBA1002G
– 4GB DDR3 CF-WMBA1004G
nMini Dock Box CF-VEBU08U
nDesktop Dock CF-VEBF81W
nDisplayPort to HDMI Adapter TTDPHDMI
Please consult your reseller or Panasonic representative before purchasing.
1A full set of Windows XP drivers are available at panasonic.com/toughbook/support.
2Total usable memory will be less depending upon actual system configuration.
31GB = 1,000,000,000 bytes.
4Hard drive removal should only be attempted by a technician with the proper equipment.
5The size of the VRAM cannot be set by the user and varies by operating system as well as
size of RAM. Windows 7 64-bit max. VRAM is 1696MB with 4GB of memory.
6Battery performance features such as charge time and life span can vary according to
the conditions under which the computer and battery are used. Battery operation and
recharge times will vary based on many factors, including screen brightness, applications,
features, power management, battery conditioning and other customer preferences.
Battery testing results from MobileMark 2007.
7Requires software and activation to enable theft protection.
8
Accessories and Integrated Options may vary depending on your notebook configuration.
Visit Panasonic website for more accessories and details.
Panasonic is constantly enhancing product specifications and accessories. Specifications subject
to change without notice. Trademarks are property of their respective owners. ©2012 Panasonic
Corporation of North America. All rights reserved. SS_TBF9_08/12
