THE TOUGHBOOK52
The only full-power desktop replacement laptop with legendary Toughbook durability.
In your world, what falls down must start up. Panasonic’s semi-rugged Toughbook®52 leads the way in reliability and
performance, whether on your desk or on the road. With a 15.4" high resolution WUXGA widescreen and discrete
graphics, it’s the ultimate business tool for group presentations and advanced technology to run multiple applications
without a hitch. Intel®vPro™processors add increased security and enhanced remote management, and optional
Gobi™2000 3G mobile broadband lets you work seamlessly pretty much anywhere.
Windows®. Life without Walls™. Panasonic recommends Windows 7.

ss52mk4 05/11
sOfTwarE • Genuine Windows®7 Professional (32-bit)1or
Genuine Windows®7 Professional (64-bit)1
• Panasonic Utilities, Recovery Partition
CPU • Intel®Core™i5-2540M vPro™Processor
– 2.6GHz with Turbo Boost up to 3.3GHz
– Intel Smart Cache 3MB
sTOraGE & MEMOrY • 4GB SDRAM (DDR3-1333MHz), expandable to 16GB2,3
• Shock-mounted flex-connect hard drive with quick-release
– 320GB 5400rpm (optional 500GB 5400rpm)3
DisPlaY • 15.4" widescreen WUXGA LED 1920 x 1200
• Anti-reflective and anti-glare screen treatments
• Video controllers
• ATI Radeon™ HD6750M (512MB dedicated VRAM)4
• Intel® QM67 (max. 1915MB shared VRAM for 32-bit)4
• External video support up to 1920 x 1200 at 16.7 million colors
aUDiO • Intel®high-definition audio compliant
• Integrated stereo speakers
• Convenient keyboard volume and mute controls
KEYBOarD & inPUT • 87-key with dedicated Windows®key
• Electrostatic touchpad with scrolling support
MUlTiMEDia POCKET • DVD Super MULTI Drive with Dual Layer Support
EXPansiOn slOTs • PC card type II x 1
• SD card (SDXC)
• ExpressCard/54 x 1
inTErfaCE • Docking connector Dedicated 100-pin
• VGA D-sub 15-pin
• Headphones/speaker Mini-jack stereo
• Microphone/line in Mini-jack stereo
• Serial D-sub 9-pin
• USB 2.0 (x 4) 4-pin
• IEEE 1394a (FireWire) 4-pin
• 10/100/1000 Ethernet RJ-45
• 56K Modem RJ-11
wirElEss • Optional integrated Gobi™2000 3G mobile broadband
• Intel®Centrino® Advanced-N 6205 802.11a/b/g/n
• Bluetooth® v2.1 + EDR (Class 1)
• Security
– Authentication: LEAP, WPA, 802.1x, EAP-TLS, EAP-FAST, PEAP
– Encryption: CKIP, TKIP, 128-bit and 64-bit WEP, Hardware AES
• Slide on/off switch
POwEr sUPPlY • Battery operation: 4 hours5
• Long life Li-Ion battery pack (10.8V, typical 6750mAh, minimum 6300mAh)
• Battery charging time: 2 hours5
• AC Adapter: AC 100V—240V 50/60Hz, auto sensing/switching
worldwide power supply
• Pop-up on-screen battery status reporting
POwEr ManaGEMEnT • Suspend/Resume Function, Hibernation, Standby, ACPI BIOS
sECUriTY fEaTUrEs • Password Security: Supervisor, User, Hard Disk Lock
• Cable lock slot
• Trusted platform module (TPM) security chip v.1.2
• Computrace®theft protection agent6
• Intel®Anti-Theft Technology
• Fingerprint reader (option)
• SmartCard reader (option)
warranTY • 3-year limited warranty, parts and labor
DiMEnsiOns & wEiGHT • 11.3"(L) x 14.0"(W) x 2.0"(H)
• 7.5 lbs.
inTEGraTED OPTiOns7 • Gobi™ 3G mobile broadband (EV-DO Rev. A, HSPA)
• SmartCard reader
• Fingerprint reader
1.800.662.3537 /panasonic.com/toughbook/52
Financing options now available from Panasonic Finance Solutions;
please call number above for more details.
Panasonic is constantly enhancing product specifications and accessories. Specifications subject to change without notice.
Trademarks are property of their respective owners. ©2011 Panasonic Corporation of North America. All rights reserved.
THE PanasOniC TOUGHBOOK 52.
■15.4" Widescreen LCD
■Desktop-class Performance
■Magnesium Alloy Case with Handle
■Shock-mounted Flex-connect Hard Drive
■Drop and Spill-resistant
■Mobile Broadband-ready Design
aCCEssOriEs7
• AC Adapter (3-pin) CF-AA5713AM
• Battery Charger CF-VCBTB1W
• Long Life Battery Pack CF-VZSU71U
• LIND Car Adapter 120W CF-LNDDC120
• LIND Car Adapter 120W
Mounting Bracket CF-LNDBRK120
• LIND Shutdown Timer CF-LNDLPT
• InfoCase ComUniversal
Carrying Case (large capacity) TBCCOMUNV-P
• InfoCase ComUniversal Roller TBCRLR-P
• InfoCase Backpack TBCBPK-P
• InfoCase Always-on 52 Case TBC52AOCS-P
• Desktop Port Replicator CF-VEB522M
• Memory Cards
– 2GB DDR3 CF-WMBA1002G
– 4GB DDR3 CF-WMBA1004G
– 8GB DDR3 TBD
• DisplayPort to HDMI Adapter TTDPHDMI
Please consult your reseller or Panasonic representative before purchasing.
1 A full set of Windows XP drivers are available at panasonic.com/toughbook/support.
2
Total usable memory will be less depending upon actual system configuration.
31GB = 1,000,000,000 bytes.
4
The size of the VRAM cannot be set by the user and varies by operating system as
well as size of RAM. Windows 7 64-bit max. VRAM is 2283MB with 4GB of memory.
5
Battery performance features such as charge time and life span can vary according
to the conditions under which the computer and battery are used.
Battery operation and recharge times will vary based on many factors including
screen brightness, applications, features, power management, battery conditioning
and other customer preferences. Battery testing results from MobileMark 2007.
6Requires software and activation to enable theft protection.
7
Accessories and Integrated Options may vary depending on your
notebook configuration.
