THE RUGGED ORIGINAL.
THE BUSINESS-RUGGED MOTTO:
WHAT FALLS DOWN
MUST START UP.
The NEW Panasonic Toughbook W7.
Presenting the next-generation mobile computing
solution for the business traveler. The business-rugged
Toughbook®W7 is built to handle up to a 30" drop, as well
as the bangs and bumps of a hectic day. And it’s well
equipped with WiFi and optional integrated mobile
broadband (3G) that connects just about anywhere
your cell phone can. Add to that increased
processing power and a spill-resistant
keyboard and touchpad, and you
get a laptop that lets you do
more than you ever expected.
And not just at your desk.

THE RUGGED ORIGINAL.
The NEW Panasonic Toughbook W7.
software • Genuine Windows Vista® Business (with XP downgrade option)
• Setup, Diagnostics, DMI Viewer, Online Reference Manual, Adobe® Reader, Hard Disk
Data Erase Utility, Recovery DVD, WinDVD 8, B’s Recorder GOLD9 BASIC, B’s CLiP 7
CPU • Intel® CoreTM 2 Duo Processor ULV U7500
– 2MB L2 cache
– Processor speed 1.06GHz
– 533MHz FSB
storaGe & MeMorY • 1024MB SDRAM (DDR2-533) standard, expandable to 2048MB*
(PC2-4200 memory is required)
• 80GB hard drive (shock-mounted and removable**)
• DVD Super MULTI Drive with Dual Layer Support
DIsPLaY • 12.1" 1024 x 768 XGA TFT active matrix color LCD
• External video support up to 2048 x 1536 at 16.7 million colors
• Intel® GM965 integrated video controller max. 384MB (DVMT) VRAM on XP*
• Anti-glare coating
aUDIo • Analog Devices AD1884 compliant audio codec
• Intel® high-definition audio compliant
• Integrated speaker
• Convenient keyboard volume controls (Fn+F5/F6 keys)
eXPaNsIoN sLots • PC card type II x 1
• Secure Digital (SDHC) card
KeYBoarD & INPUt • 83-key with dedicated Windows® key
• Electrostatic touchpad with continuous vertical scrolling support
INterfaCe • Mini dock box replicator 50-pin
• External video D-sub 15-pin
• Headphones/speaker Mini-jack stereo
• Microphone/line in Mini-jack
• USB 2.0 (x 3) 4-pin
• 10/100/1000 Ethernet RJ-45
• 56K Modem RJ-11
wIreLess • Optional integrated mobile broadband WWAN
• Intel® Wireless WiFi Link 4965AG 802.11a/b/g
• Bluetooth® v.2.0 + EDR (not available with fingerprint scanner)
• Security
– Authentication: LEAP, WPA, 802.1x, EAP-TLS, EAP-FAST, PEAP
– Encryption: CKIP, TKIP, 128-bit and 64-bit WEP, Hardware AES
• Slide on/off switch
Power sUPPLY • Lithium ion battery pack (10.8V, 5800mAh)
• Battery operation: 6.7 hours***
• Battery charging time: approximately 5 hours off, 6.5 hours on***
• AC Adapter: AC 100V-240V 50/60Hz, auto sensing/switching worldwide power supply
• Pop-up, on-screen battery status reporting
Power MaNaGeMeNt • Suspend/Resume Function, Hibernation, Standby, ACPI BIOS
• Economy mode
seCUrItY featUres • Password Security: Supervisor, User, Hard Disk Lock
• Cable lock slot
• Trusted platform module (TPM) security chip v.1.2
• Computrace® theft protection agent****
• Optional fingerprint scanner (eliminates Bluetooth®)-available at future date
warraNtY • 3-year limited warranty, parts and labor
DIMeNsIoNs & weIGHt • 1.4"/1.9"(H) x 10.7"(W) x 8.4"(D)
• 3.0 lbs.
INteGrateD oPtIoNs***** • Mobile Broadband Solutions
– EV-DO Rev. A
– HSDPA
• Fingerprint scanner (eliminates Bluetooth®)-available at future date
For more information, call 1.800.662.3537 or visit us on the Web at panasonic.com/toughbook.
Panasonic is constantly enhancing product specifications and accessories. Specifications subject to change without notice. Trademarks are property of their respective owners.
©2008 Panasonic Corporation of North America. All rights reserved.
ssW7 03/08
Ultra-lightweight, Integrated DVD Multi Drive
■Full Magnesium Alloy Case
■Shock-mounted Hard Drive
■Drop- and Spill-resistant
■Ultra-portable 3.0 lbs.
■Long-lasting 6.7-hour Battery Life
■Mobile Broadband-ready Design
aCCessorIes*****
• AC Adapter (3-pin) CF-AA1633AM
• ToughMate ComUniversal
Carrying Case (large capacity) COMUNIV-P
• ToughMate Business-rugged
Top-loading Case FM-BRTL-P
• External USB Floppy Drive CF-VFDU03U
• Lithium Ion Battery Pack CF-VZSU51W
• Memory Card
– 1GB CF-WMBA701G
• Mini Dock Box Replicator CF-VEBU05BU
• Large Venue DLP Projector PT-DW5100U
• Mobile LCD Projector PT-LB60U
Panasonic recommends Windows Vista®Business.
* Total usable memory will be less depending upon actual system
configuration. Vista max VRAM is 251MB with 1GB of memory,
or 358MB with 1.5GB or more of memory.
** Hard drive removal should only be attempted by a technician with
the proper equipment.
*** Battery performance features such as charge time and life span can
vary according to the conditions under which the computer and battery
are used. Battery operation and recharge times will vary based on many
factors, including screen brightness, applications, features, power
management, battery conditioning and other customer preferences.
Battery testing results from MobileMark 2007.
****Requires software and activation to enable theft protection.
***** Accessories and Integrated Options may vary depending on your
notebook configuration.
Please consult your reseller or Panasonic representative before purchasing.
