Panasonic DT50 series Assembly instructions

DT50 series
M0212-0

Media player
Get started
Information
You can view still and motion images and play music saved on a USB flash memory
and an SD card.
•SD card
•When you use an SD card, gently insert with label surface facing front.
• When you remove the SD card, press in lightly then release.
Label sur_ce
Push until a Cutout
click is heard
Press in lightly J
on SD Card,
then release.
Compliant card type (maximum capacity):
SDXC Card (64 GB), SDHC Card (32 GB), microSDHC Card (32 GB), SD Card
(2 GB), miniSD Card (2 GB), microSD Card (2 GB)
(requiring microSDHC Card/miniSD Card/microSD Card/adapter)
° If a microSDHC Card, miniSD Card or microSD Card is used, insert /remove it
together with the adapter.
•USB flash memory
•When you use a USB device, insert straight in and pull straight out.
•Media player only supports USB Mass storage class devices.
87

Media player
Get started
Media warning messages
No media. Please insert an SD memory
card or USB storage device.
No media. Device removed.
No photos/No movies/
No music files to play/
No playable media
Cannot read file
• The device is not inserted.
° The device is removed.
•The device has no data or this type of
data is not supported.
• The file is broken or unreadable.
•The TV does not support the format.
88

Media player
Get started
SD card handling cautions
•Use an SD Card meeting SD standards. If not, it may cause the TV to malfunction.
•Do not remove the card while the unit is accessing data (this can damage card or
unit).
•Do not touch the terminals on the back of the card.
• Do not subject the card to high pressure or impact.
•Insert the card in the correct direction (otherwise, card or unit may be damaged).
• Electrical interference, static electricity or erroneous operation may damage the
data or card.
• Back up the recorded data at regular intervals in case of deteriorated or damaged
data or erratic operation of the unit. (Panasonic is not liable for any deterioration or
damage of recorded data.)
89

Media player
Photos
Viewing Photos
1. Insert Media (SD card or USB flash memory)
2. Display Media player
JVIERA TOOLS J VIERA TOOLS > Media player
3. Select the SD/USB in (Displays connected drive)
Select the drive using _ /_ and press
4, Select the Photos in
Select the drive using _ /_ and press
5, Select the photo in thumbnail view
Select the data using _ /_/_/_ and
* How data is displayed differs depending on data storage conditions.
6, View
Follow the Navigation and guide to operate.
* Displayed navigation and guide may differ depending on data type.
•Other settings
Some basic menus are available after pressing the 1MENU Jbutton.
90

Media player
Photos
Photo view
•Thumbnail view
Display
,Display
Display
....,, Display '_::_::::_,_
IINFOI Information panel (File name, Date, and Size etc.)
* Information differs depending on selected data.
•Playback screen
IINFOI Display/hide Guide and Banner
Photo status: Shows current photo status
or
2D/3D status: Shows current 2D/3D status
Navigation Guide: Shows available functions.
91

Media player
Photos
Sort the photos
1. Display Sort select menu
S _ Sort select menu (i:_ _;:_ / /, _)
2. Select the sort type
Select the type using _ /V and press
3. Displayed each screen
Folders: ascending order of numeric/alphabetical
Sort by month: ascending order of the month
Sort by date: ascending order of the day
92

Media player
Photos
Options menu
In Photo view, some optional menus are available after pressing the IOPTION I
button.
1, Display
S[OPTION ] ....
2. Select the item
Select the desired menu using _ /V and press
*Ava ilable menus are displayed on (::, ,::::: depe nding on data
condition and situation,
93

Media player
Photos
Multi shot 3D /Thumbnails size
•Multi shot 3D
3D images can be created by selecting 2 photos in thumbnail view.
_:i11_;' Select first photo using <] /_/_/V and press
Select second photo using _ /_/_/V and press m
• To select the second image, the size and date must be the same as the first
image.
and are displayed at the top left-hand corner of selected photos.
4_31_.Start Conversion processing by pressing
Conversion processing message will be displayed.
•Error message will be displayed if first and second picture have no relation,
or for other reasons. (e.g. size /date is different)
<i_ 3D photo is created
_._j(_51Save the 3D image generated by the above steps to the original drive.
Confirmation message will be displayed and select Yes to save
the data. (SD card only)
•Thumbnails size
To change the number of photos on a thumbnail screen at a time.
(7x4 _ 10x6)
94

Media player
Photos
Using slideshow
1. Display
2. Adjust items
Select the item by _ /V and adjust the settings using _ /[:-_
•Picture quality may become lower depending on the slideshow settings.
•Picture setting may not work depending on the slideshow settings.
3. Start Slideshow
After adjusting each of the settings, selectil;_;:: .; _ ;_ :_ with _/V and
press
5IRETURNI.......Stopinmid-cycle
95

Media player
Photos
Slideshow settings
i_i¸i__,_!_@_i__iiiiii_i__ii!i!_iiiii_i!_i_i_
Select the Frame. (Off/Array/Collage/Drift (with
calendar)/Drift/Gallery (with calendar) /Gallery /
Cinema)
Select the display effect. (Off/Sepia/Gray scale)
Select the Transition effect shown between photos.
(Off/Fade in/Wipe _/Wipe _/Wipe _/Wipe ,--/
Slide in ._ /Slide in 1"/Slide in _/Slide in _--/
Zoom in/Comb 1_ _ /Comb -_ ,_/Dissolve/
Checker wipe/Motion/Random)
Removes the black borders that are added according to the size of
the photo being displayed. (Normal/Zoom)
Continuously plays photos that were shot. (Off/On)
:_ '_: ; set s the time each image is dispIayed in the
Slideshow mode. (ShortlFastlNormallSIowlVery slow)
Turn the Slideshow Repeat (cycle) function on or off. (Off/On)
Select the music.
(Off/Music l/Music 2/Music 3/Music 4/Music 5/
User selected/Auto)
User selected: Plays the soundtrack registered in the
menu.
Auto: Plays the songs on the SD card or USB flash memory.
96

Media player
Photos
Soundtrack settings
You can register the favorite songs as soundtracks
I
(_'_ Select in using _/ V
(_2_i_,Select using _/ V
(i_) Displays popup menu, then select the desired song with
_/ V and press _ to register
This song: Register current music
All songs in folder: Register the music in a folder
• Picture setting may not work depending on the slideshow settings. I
97

Media player
Videos
Viewing Videos
1. Insert Media (SD card or USB flash memory)
2. Display Media player
JVIERA TOOLS J VIERA TOOLS > Media player
3. Select the SD/USB in (Displays connected drive)
Select the drive using _ /_ and press
4, Select the Videos in i:_:::j_ _ :::i:::,:_:
Select the drive using _ /_ and press
5, Select the video in thumbnail view
Select the data using _ /_/_/_ and
* How data is displayed differs depending on data storage conditions.
6, Play
Follow the Navigation and guide to operate.
* Displayed navigation and guide will be different depending on data type.
•Other settings
Some basic menus are available after pressing the 1MENU Jbutton.
S IMENUI ..... >i::_i_,::;::_::::/__ _:_::::/i:_:
98

Media player
Videos
Video view
•Thumbnail view
Play the video
Display
{Z} Display
IINFOI :_, Information panel (File name, Date, and Size etc.)
*Information differs depending on selected data.
•Playback screen
IINFO IDisplay/hide Guide and Banner
Movie banner: Shows current Video status
(Drive type (SD/USB/DLNA), Date and time or File name and
Elapsed time.)
2D/3D status: Shows current 2D/3D status
Navigation Guide: Shows available functions.
Forward/Reverse: Five levels of speed 1 to 5 (x2, x5, x30, x70, xl00) are
available.
I * Subtitles are not supported in MKV format. I
99

Media player
Videos
Options menu
In Video view, some optional menus are available by pressing the [OPTION I button.
1, Display
t_ J0 PTIO N ] ......._ _
2. Select the item
Select the desired menu using _ /_ and press
•Repeat playback
Set play repeat function (On/Off)
* Ava ilable menus are displayed on _,:::, ,::::: depe nding on data
condition and situation,
100

Media player
Music
Playing Music
1. Insert Media (SD card or USB flash memory)
2. Display Media player
JVIERA TOOLS J VIERA TOOLS > Media player
3. Select the SD/USB in (Displays connected drive)
Select the drive using _ /_ and press
4, Select the Music in _ :::i:::,:_::
Select the drive using _ /_ and press
5, Select the music in thumbnail view
Select the data using _ /_/_/_ and
* How data is displayed differs depending on data storage conditions.
6, Play
Follow the Navigation and guide to operate.
* Displayed navigation and guide will be different depending on data type.
•Other settings
Some basic menus are available by pressing the [ MENU Jbutton.
IMENUI ....... >
101

Media player
Music
Music view
•Thumbnail view
Play folder
{Z}
Display
Display
IINFOI
•Playback screen
Information panel (File name, Date, and Size etc.)
* Information differs depending on selected data.
JlNFO J Display/hide Guide and Banner
Music Guide: Shows current Music status
(Artist name/Album name/Song name, Elapsed time)
Navigation Guide: Shows available functions.
Forward/Reverse: Five levels of speed 1 to 5 (x2, x5, x30, x70, xl00) are
available.
102

Media player
Music
Options menu
•Music options
In Music view, some optional menus are available by pressing the IOPTION Ibutton.
1, Display
IOPTION I
2. Select the item
Select the desired menu using _/V and press
(_ _)
•Repeat playback
Set play repeat function (Off/Repeat folder/One song)
*Ava ilable menus are displayed on _,:::, ,::::: depe nding on data
condition and situation,
103

Media player
Data information
Compatible Data format (1)
•Compatible Data format for Media player
(SD card/USB flash memory)/DLNA
Photo •JPEG files (DCF and EXIF standards)
Sub-sampling - 4:4:4, 4:2:2 and 4:2:0
Image resolution - 8 x 8 to 30,719 x 17,279 pixels
104

Media player
Data information
Compatible Data format (2)
Videos SD-Video files (SD-Video Standard Ver.1.31)
Modified data with a PC may not be displayed correctly.
AVCHD files
AVCHD Standard Ver.2.0 (AVCHD 3D, AVCHD Progressive)
Modified data with a PC may not be displayed correctly.
MotionJPEG files (taken with LUMIX)*
O
• MP4 files
Video codec
Audio codec
° MKV files
Video codec
Audio codec
° FLV files
Video codec
Audio codec
° 3GPP files
Video codec
Audio codec
° PS files
Video codec
H.264/MPEG1/MPEG2
MPEG Au dio/M P3/AAC/H E-AAC/AC3/E-AC3
H.264/MPEG1/MPEG2
MPEG Au dio/M P3/AAC/H E-AAC/AC3/E-AC3
H.264
MP3/AAC
H.264/MPEG1/MPEG2
AAC/HE-AAC
H.264*/MPEG1/MPEG2
Audio codec MPEG Audio/MP3*/AAC*/HE-AAC*/AC3/
E-AC3*/LPCM
° TS files
Video codec H.264/MPEG1/MPEG2
Audio codec MPEG AudiolMP3*IAAClHE-AAClAC31E-AC3
* for Media player only
105
