Panasonic E50 series Assembly instructions

E50 series
M0212-0

Watching TV
Cable /Satellite /Fiber with a box
• Initial setting 11
Antenna /Cable service without a box
• Initial setting 12
• Select channels 13
• Favorite channels (Set) 14
• Favorite channels (Display) 15
• Closed caption 16
• SAP 17
• Other 18
Blu-ray, DVD, Game Console, etc.
•Connecting and viewing (1) 19
• Connecting and viewing (2) 20
• HDMI connection notice 21
• HDMI connection caution 22
• Input signal 23
For best picture
• Picture mode 24
• Auto brightness (ECO) 25
• Aspect 26
• Aspect info. 27
For best audio
• Basic adjustments 28
• Advanced audio 29
Computer on TV
2

• Display PC screen 30
• PCadjustments (1) 31
• PCadjustments (2) 32
• Inputsignal 33
Internet services "VIERA Connect"
Connect to network
•Network connections (1) 34
• Network connections (2) 35
• Network connections (3) 36
• Network connections (4) 37
Network settings
• Setting menu 38
• Connection test 39
• Network connection 40
• Wireless network settings 41
• IP address/DNS settings 42
• Proxy settings 43
• Network link (1) 44
• Network link (2) 45
• Software update 46
• New software notice 47
• Network status 48
How to use
•Operate 49
Home network "DLNA"
Get started
•Information 50
3

Connect to network
,Network connections (1) 51
. Network connections (2) 52
• Network connections (3) 53
• Network connections (4) 54
Network settings
• Setting menu 55
• Connection test 56
• Network connection 57
• Wireless network settings 58
• IP address/DNS settings 59
• Proxy settings 60
• Network link (1) 61
• Network link (2) 62
• Software update 63
• New software notice 64
• Network status 65
Photos
•Viewing Photos 66
• Photo view 67
• Options menu 68
• Using slideshow 69
• Slideshow settings 70
Videos
• Viewing Videos 71
• Video view 72
• Options menu 73
4

Music
• Playing Music 74
• Music view 75
• Options menu 76
Data information
• Compatible Data format (1) 77
• Compatible Data format (2) 78
• Compatible Data format (3) 79
• Notice 80
Media player
Get started
• Information 81
• Media warning messages 82
• SD card handling cautions 83
Photos
• Viewing Photos 84
• Photo view 85
• Sort the photos 86
• Options menu 87
• Thumbnails size 88
• Using slideshow 89
• Slideshow settings 90
• Soundtrack settings 91
Videos
• Viewing Videos 92
• Video view 93
• Options menu 94
5

Music
• Playing Music 95
• Music view 96
• Options menu 97
Data information
• Compatible Data format (1) 98
• Compatible Data format (2) 99
• Compatible Data format (3) 100
• Notice 101
Convenience features
Using VIERA TOOLS
• Using VIERA TOOLS 102
Timer
• Setting menu 103
• Sleep (Off timer) 104
• Timer (On/Off timer) 105
Lock (parental control)
• Setting menu 106
• Lock (1) 107
• Lock (2) 108
• Password setting 109
• Parental control ratings (1) 110
• Parental control ratings (2) 111
• Parental control ratings (3) 112
Closed caption
• Setting menu 113
• Closed caption (1) 114
6

• oCI°sedcaption (2) 115
•Closed caption, notice.... 1t6
VIERA Link TM"HDAVI Control T""
• Basic feature 117
.Connectingnote(I! 118
•Connectingnote (2) 119
•V/ERA Linkconnections ol) 120
• VIERA Link connection (2) !21
.VERAL_nkconnections!3) 22
•VlERALink setting s 23
• VlERA Link setting s !eature!!) 24
• Vl ERA Link setting, feature (2) 25
• VlERA Link setting, feature (3) 126
• VIERA Unk...................... 127
.WERAL_km_nu(I) 28
.v,ERAL_kmenu(2) 29
Control by smartphone, etc.
•martphoneremot e 130
Using USB Keyboard /Gamepad
• Keyboard 131
• Gamepad 132
All settings
•menu Setting --_33
•Basic settings,, (1) 134
• Basic setting. (2) 135
•Aspect adjustments 1o36

137
,PC adjustments(!) 138
PCadjustments 2) 139
HDM| settings
.A vancedp ctu e °
Advance picture (2)........... 141
Audio 142
.Setting menu ......................... 143
. Basicsettings 144
.Advanced audio...........
--DTV !anguage. and SAP settings 145
..DIGITAL AUDIOoOUT termina!..................... 146
Network 147
.Network. settings (!) ...... 148
,Network settings (2)...... 149
•Network settings (3)............. 150
.Ne_ork settings(4) 151
•. N etwor settings (5)
Timer 152
•Setting menu............. 153
•Sleep(Off time r) 154
• Timer(On/Off timer)
Lock (parental control) 155
.Setting menu ............. 156
,Lock !1) 157
.Lock (2) 158
password setting
• Parentalcontro!_ _ratings (1) ...... 159
8

. Parentalocontrol °ratings(2) 160
•Parenta! contro!ratings (3)......... 161
Setup 162
• Setting_ menu.......... 163
• ANT/Cable setup (1) 164
• A NT/C able setup .(2) 165
• Closed caption (1)......... 166
• Closed caption (2!................ 167
• =Closed caption notice
• VlERA Link .settings (1) .............. 168
.WERAL_ks_tt_ngs(2) _69
170
• E CO/en ergy saving (1) 171
.ECO/energysav!ng (2) 172
, Advancedsetu_ 173
• Othe settings (! .) 174
,Othe settings(2)
Support /FAQ
FAQ 175
o Picture-Viewing 176
, Picture -Snowy/none 177
Picture -Distortio................. 178
, Pictu 2 - Continue 179
• pound -none 180
•Sound -Unusual ............. 181
• __ __ __etworking 182
•Software. update..................
9

• Other 183
• Menu - Gray-out 184
• Resetto default 185
Care and Cleaning
• Display panel 186
• Cabinet 187
• Pedestal /Power cord 188
Meaning of signs :
dPress the Remote control button
Letters in box • Remote control button
MENU Letters in Cyan • Menus on screen display
10

Watching TV
Cable /Satellite /Fiber with a box
Initial setting
1. Connecting
Select the wiring method connecting your box to the TV, AV IN or
Antenna/Cable in
I Tip: HDMI will provide the best HD picture I
2. Change INPUT
_ IINPUT
Press the INPUT button to select the proper connection. Wait 2 seconds.
3. Power on your Cable, Satellite or Fiber box
Use the box's remote control to change channels.
* If the box is connected to the TV using a COAX cable (Antenna/Cable in), then
set the TV channel to CH3 or CH4. Note that the picture will not be in HD.
* CC/SAP is not available when watching TV with a Cable or Satellite box
connected via HDMI.
If your box is a high definition, then check that it is outputting 720p or 1080i
signal.
Tip: press the TV's _ button to verify.
Check your box "aspect" or "format" settings. It should be set to 16:9,
Widescreen or FULL.
If the audio volume is too low, check the box's audio settings.
Contact your Cable or Satellite provider for instructions on any box settings.
11

Watching TV
Antenna /Cable service without a box
Initial setting
1. Connect coax
Connect a COAX wire from either an antenna or Basic Cable service to the TV's
"ANTENNA/CABLE IN" screw terminal.
ANTENNA/
TV CABLE IN Antenna
2. Scan the channel
_ IMENUI > >
1. Select Programming source Cable or Antenna in i,,.
2. Select and select scan mode
3. Start scanning.
If at the end of the scanning no channels are found, then check:
Antenna's position - or Availability of Cable service.
Cable, Satellite or Fiber services with a box are typically connected to the TV's
A/V inputs, preferably HDMI, for best HD picture. In such a case, the channel
scanning is not needed (set to Not used).
12

Watching TV
Antenna /Cable service without a box
Select channels
Select desired channel
_or __
• CH buttons are also available on the TV.
Select desired digital channel
To directly enter a digital channel number use
• When turning to a digital channel, press the button to enter the minor number in a
compound channel number.
(e.g. CH15-1 _ _ _ _)
13

Watching TV
Antenna /Cable service without a box
Favorite channels (Set)
Channel numbers registered in Favorite are displayed on the favorite tune screen.
Select the desired broadcast station with the cursor or use the number buttons.
I • Favorite channels cannot be set when using Cable or Satellite box
• Set the Favorite channel
[OPTION] >
Select the list number using _ /V and _ or _ _ _ directly to save the
displayed channel.
Delete a Favorite channel
_[OPTION] >
Select the list number using _ /_ and _ (press and hold) to delete.
* To change the page in
IFAVORITEIor _/_ repeatedly
I
14

Watching TV
Antenna /Cable service without a box
Favorite channels (Display)
Channel numbers registered in Favorite are displayed on the favorite tune screen.
Select the desired broadcast station with the cursor or use the number buttons.
I • Favorite channels cannot be set when using Cable or Satellite box.
To display a Favorite channel
SJFAVORITE]
I
Select the list number using _ /V and _ or _ _ _ directly to displayed
on favorite screen.
* To change the page in
[FAVORITE]or _ /_ repeatedly
15

Watching TV
Antenna /Cable service without a box
Closed caption
Viewing with Closed caption
Switches the Closed caption mode.
(Closed caption Off/Closed caption On /Closed caption On mute )
*CC is not available when watching TV with a Cable or Satellite box connected
via HDMI.
* Contact your Cable or Satellite operator for instructions on enabling CC with
their box.
* The TV's CC button does not operate the Satellite or Cable box's CC function.
* For viewing the CC of digital broadcasting, set the aspect to FULL (If viewing
with H-FILL, JUST, ZOOM or 4:3; characters might be cut off).
* If the CC is set to On on both the receiver and TV when the signal is 480i
(except for the HDMI connection), the CC may overlap on the TV.
* If a digital program is being output in analog format, the CC data will also be
output in analog format.
* If the recorder or output monitor is connected to the TV, the CC needs to be set
up on the recorder or output monitor.
16

Watching TV
Antenna /Cable service without a box
SAP
Listen with SAP (Secondary Audio Programming)
QSAP is not available when watching TV with a Cable or Satellite box connected
via HDMI.
Contact your Cable or Satellite operator for instructions on enabling SAP with
their box.
The TV's _ button does not operate the Satellite or Cable box's
function.
Select the Audio mode for watching TV.
Digital mode: Select available audio service when receiving a digital channel.
Audio track is automatically selected as :i:_:_i_ in
menu.
> > _: _i_
* If you change the audio settings with the _ button, the DTV language and
SAP settings will not change.
(example)
Track number /Number of tracks
...............Current audio track information (language, audio
type)
......Audio service information
Analog mode: Select the desired Audio mode. ( Stereo /SAP /Mono )
17

Watching TV
Antenna /Cable service without a box
Other
1. Information banner
Displays TV status information. Also, when watching programs via the
Antenna/Cable input, INFO will include the channel banner.
IINFOI
Channel /Station identifier /Program title /Closed caption /SAP /
Rating level /Signal resolution /Picture mode /Aspect ratio /
Sleep timer remaining time /Clock
2, Options menu
This menu consists of shortcuts to convenient functions.
OPTION ]
C: : :, ,_ _i : ,_!::::: Specify favorites or type of channels to view when
pressing the channel up/down button.
S::/i: :: :_: :::: Set favorite channel
Edit the channel identifier
_:::_:::: : Check the antenna's signal strength
* Options menu is only available when the TV is using the Antenna/Cable input,
not when using Cable or Satellite box.
18

Watching TV
Blu-ray, DVD, Game Console, etc.
Connecting and viewing (1)
1. Connect device
Verify that the device is connected to the TV properly and connect to desired
terminal. Note which terminal the device is connected to (HDMI 1, HDMI 2,...
Component or Video)
Component and Composite (Video) in terminals are shared.
Please be careful not to confuse the connection when you use Component or
Video.
19

Watching TV
Blu-ray, DVD, Game Console, etc.
Connecting and viewing (2)
2. Select Input
1. Display menu (With the connected equipment turned ON)
IINPUTI
2. Select the input used in step 1
Select correct input source, using _ /V and press
You can also press the corresponding NUMBER button or press I INPUT I
repeatedly to cycle through the available inputs. If you are unsure which input to
select, wait 2 seconds between each selection.
Component and Composite (Video) IN
terminals are shared and must be connected
using the supplied adapter.
NOTE: One red connector is for video and the
other audio.
•
AUDIO
You need to select Video or Component.
(Default: Video)
• PressIINPUT land select
• Press _ /_ to choose Video or
Component,
VIDEO
• For your convenience, you can edit the inputs with labels that are easy to
remember.
d ._m
Edit Labels Set ANT/Cable in
3. Operate using your device's remote control.
2O
