All settings
Setting menu
Adjust the image or picture quality.
•Some menus are grayed out depending on the input signal or condition.
(e.g. will be grayed out if the aspect is not set to ZOOM.)
1. Display the menu
_1 M EN U I
2, Select from menu bar
Select desired menu using _ /V from menu bar and press
3, Select the item and adjust
Select desired item using /\. /V and adjust with <1 /
Shows the functions that can be adjusted.
Some functions will be disabled depending on the type of input signal.
will be grayed out if no changes are made.
139

All settings
Basic settings (1)
_IMENUI >
Reset to
defaults
Picture mode
Back light
Contrast,
Brightness,
Color, Tint,
Sharpness
Vivid/
Standard/
Cinema/
Game/
Custom
• Resets all picture adjustments to factory
default settings except for advanced settings.
° Adjusts the picture quality according to ambient
lighting conditions or situation.
° When changing picture mode from/to Game
the screen will momentarily go black. This is
normal. The blacking out of the screen is normal
and is due to a change of parameters in order to
improve the response to video games.
Adjusts the luminance of the back light.
• Adjusts the color, brightness, etc. for each
picture mode to suit your taste.
° Display range
ContrastlBrightnesslColorlSharpness ' O - 100
Tint :-50 - +50
140

All settings
Basic settings (2)
_LMENUJ >
Color temp.
Color mgmt.
A. I picture
C.A.T.S.
Video NR
Cool/
Normal/
Warm
Off/On
Off/On
Off/On
Off/On/Auto
•Selects color temperature preference, from
"cool" (bluish) to "warm" (reddish) or normal.
• On: Enhances green and blue color
reproduction, especially outdoor scenes.
• Controls dark areas without affecting the black
level or brightness in the overall picture.
• Contrast Automatic Tracking System (C.A.T.S.)
adjusts the screen brightness and contrast
according to the room's ambient light conditions.
This ECO feature automatically dims the
brightness of the screen when the room lighting is
lowered. C.A.T.S. features a built-in delay when
the lighting conditions change. The adjustment
happens gradually.
If you prefer a consistent brightness, disable
C.A.T.S. by:
•> > scroll down to C.A.T.S.
and turn it off.
Or
•> > _:::::_J::::then
select viewing mode such as Custom,
Note: Standard picture mode automatically sets
CAT.S. to On.
•Reduces noise, commonly called snow. Leave
it off when receiving a strong signal.
141

All settings
Aspect adjustments
_ IMENUI > >
Screen format
HD size
H size
FULL/H-FILL/
JUST/4:3/
ZOOM
Size l/Size 2
Size l/Size 2
• Changes the format (aspect ratio). Lets you
choose the aspect depending on the format of
received signal.
• Selects between 95 % (Size 1) or 100 %
(Size 2) for the scanning area with High Definition
signal.
• Adjusts the horizontal display range to reduce
noise of both side edges of an image.
Size 2 Adjusts the image size according to the
aspect mode to reduce noise.
Aspect mode: 4:3
•The width will be decreased on both sides to
reduce noise.
Aspect Ratio: FULLIJUST(H-FILLIZOOM)
•The width will be increased on both sides to
reduce noise.
Zoom ,, Adjusts vertical alignment and size when
adjustments aspect setting is "ZOOM".
142

All settings
PC adjustments (1)
L_ IMENU > >
Reset to
defaults
Sync H&V
On green
• Resets all PC adjustments to factory default
settings.
•The H and V sync signals are input from the
HD/VD connector.
• Uses a synchronized signal on the Video G
signal, which is input from the G connector.
Dot clock • Alleviates the problem if a picture appears to
be vertically-striped, flickers partially or is blurred.
H-position • Adjusts the horizontal position using left/right
cursor button.
V-position • Adjusts the vertical position using left/right
cursor button.
143

All settings
PC adjustments (2)
IMENUI > >
Clock phase
Input
resolution
•Alleviates the problem if the whole picture
appears to flicker or is blurred. First adjust the Dot
Clock to get the best possible picture, then adjust
the Clock phase so that a clear picture appears.
• It may not be possible to display a clear picture
due to poor input signals.
• Switches to wide display and selects the
appropriate screen resolution.
• VGA (640 x 480 pixels), WVGA (852 x 480
pixels), XGA (1,024 x 768 pixels), WXGA (1,280 x
768 pixels)
• Options change depending on signals.
H-frequency • Displays the H (Horizontal)/V (Vertical)
V-frequency frequencies.
Display range
Horizontal: 15- 110 kHz
Vertical: 48 - 120 Hz
144

All settings
HDMI settings
_ IMENUI > >
HDMI/DVI
RGB range
(HDMI)
Content type
(HDMI)
Standard
(16-235)/
Nonstandard
Off/Auto/
Photos/
Graphics
• Prevents the blown out highlights and blocked
up shadows when a wide-range signal is received.
Selects between standard RGB range (16-235
bits) or non-compliance (0-255 bits).
• Auto: Switches the RGB range (Standard
(16-235)/Nonstandard) depending on the HDMI
signal information.
• Sets content type to each HDMI input.
• Auto: Switches content type automatically
depending on the HDMI signal information.
• Photo: Best setting for JPEG viewing.
• Graphics: Best setting for On-Screen display
of connected equipment.
145

All settings
Advanced picture (1)
_ IMENUI > >
3D Y/C filter
Color matrix
Block NR
Mosquito NR
Motion picture
setting
Off/On •Minimizes rough edges (dot crawl) in the
picture from a composite source.
SD/HD ° Selects image resolution of component-
connected devices.
° SD: Standard Definition HD: High Definition
° Only used with 480p video signal.
Off/On/Auto ° Reduces noise of specific digital signals of
DVD, Cable box, etc.
Off/On ° Reduces HDTV flicker noise in the contoured
Off/Weak/
Medium/
Strong
sections of a compressed image.
° Improves motion picture quality by reducing
motion blur.
146

All settings
Advanced picture (2)
J IMENUI > >
Black level
3:2 pulldown
24p Direct in
(3D mode only)
Light/Dark
Off/On/Auto
60Hz/48Hz
•Select Dark when details are washed out in
dark areas of picture from external source. Valid
only for external input signals.
° Reduces motion jitter in film-based content by
transforming 24 fps to 30 fps (non-HDMI).
° 48Hz: Achieves more cinematic playback by
reproducing the movie contents at twice the
speed of 24 frames per second.
147

All settings
Audio
Setting menu
Adjust audio quality.
1. Display the menu
_1 M EN U I
2. Select from menu bar
Select desired menu using _ /V from menu bar and press
3, Select the item and adjust
Select desired item using _ /V and adjust with _ /
Shows the functions that can be adjusted.
Some functions will be disabled depending on the type of input signal.
will be grayed out if no changes are made.
148

All settings
Audio
Basic settings
_ IMENUI >
Reset to
defaults
Bass
Treble
Balance
•Resets Bass, Treble, and Balance adjustments
to factory default settings.
• Increases or decreases the bass response.
• Increases or decreases the treble response.
° Emphasizes the left /right speaker volume.
149

All settings
Audio
Advanced audio
_[MENUJ > >
A.I. sound
Surround
Volume leveler
Distance to
wall
TV speakers
Off/On
Off/On
Over lft(30cm)/
Up to lft(30cm)
Off/On
• Equalizes overall volume levels across all
channels and external inputs.
• Enhances audio L/R response when listening
to stereo. Ideal for music and action movies.
°Minimizes volume disparity after switching to
external inputs.
• Over lft(30cm): TV is on a stand. Keeps
current setup.
° Up to lft(30cm): TV is mounted. Reduces low
frequency level to prevent resonance.
° Enables the TV's built-in speakers.
° Switches to "Off" when using external
speakers.
° "A.I. sound", "Surround", "Volume leveler", and
"Distance to wall" do not work if "Off" is selected.
HDMI in Digital/ ° The default setting is "Digital" for the HDMI
Comp./Video connection. (Digital input signal)
• Select audio input terminal when a DVl cable is
connected along with an analog audio input
signal.
150

All settings
Audio
DTV language and SAP settings
_ IMENUI > >
Preferred English/
language Spanish/
French
Preferred audio Main Audio/
type Hearing
Impaired/
Visually
Impaired
Selected preferred language is used for automatic
selection of audio service.
Selected preferred audio type is used for
automatic selection of audio service.
151

All settings
Audio
DIGITAL AUDIO OUT terminal
You can enjoy your Home Theater by connecting a Dolby Digital (5.1 channel) decoder
and "Multi Channel" amplifier to the DIGITAL AUDIO OUT terminals.
• Depending on your DVD player and DVD-Audio software the copyright protection
function may operate and disable optical output.
• When an ATSC channel is selected, the output from the DIGITAL AUDIO OUT jack
will be Dolby Digital. When an NTSC channel is selected, the output will be PCM.
° When playing a movie on SD Card Movie player, when the sound has been
recorded in Dolby Digital, the output from the DIGITAL AUDIO OUT terminal will be
Dolby Digital. When the sound is recorded in other formats, the output will be PCM.
152

All settings
Network
Network settings (1)
_ IMENUI >
Connection test
Network
connection Ethernet cable/Wireless
(WiFi)
• Checks for proper network connection, settings
and communication to the Internet & server.
• Select Network type.
153

All settings
Network
Network settings (2)
_ IMENUI >
Wireless •This setting is performed only when "Wireless
network (WiFi)" is selected in
settings • Select the Access point from the list or select
Connection method with color key.
• Follow the directions on screen to complete
the setting.
154

All settings
Network
Network settings (3)
_ IMENUI >
IP address/
DNS settings IP setting
mode/
IP address/
Subnet mask/
Default
gateway/
DNS setting
mode/
DNS/
Proxy setting
• Select
and set to Automatic, then each IP
address is acquired Automatically.
[Manual setting]
• Select __::'_::/©_i
and set to Manual, then select item and
press OK.
• Check the specifications of the broadband
router and enter each IP address. Or Enter each
IP address as was specified by the provider.
• Proxy setting
• Set only if specified by the provider. It is not
required for normal household use
Proxy address/Proxy port: Setting is only required
if specified by the provider.
155

All settings
Network
Network settings (4)
_ IMENUI >
Network link
(Stream and
control content
from networked
portable
devices.)
Vl ERA
network name
DLNA remote
control
DLNA remote
volume control
Network
remote control
• Sets your favorite name for this TV. This name
be displayed on the screen of the other
Network compatible equipment.
• Enables Digital Media Renderer for playback of
DLNA content.
° Sets volume setting in DMR operation
° Available only when Enable is selected in
• Switches remote control of network device
such as a smartphone to Disable or Enable.
156

All settings
Network
Network settings (5)
/_ IMENUI >
Software •Press OK to start the Software update screen.
update And follow directions on the screen.
• Set first.
New software Off/On • On: When TV is turned On, update message is
notice displayed if available. Follow the directions on the
screen to download.
Network status ° Displays Current settings and status screen.
(Network type/Wireless settings/MAC address/IP
Address etc.)
• Displayed items differ depending on the type of
network connection.
157
