Panasonic TH-42LRU50 Installation instructions

42-inchClass1080pHospitalityLCDHDTV
TH-42LRU50
PMY06/22/20121/2
©PanasonicCorporation2012
Productspecification(designandspecificationsubjecttochangewithoutnotice)
■DISPLAYPANEL
ScreenSize(Diagonal)
Aspectratio
Panel
Resolution(HｘV)
Brightness(Panel)
DynamicContrastRatio
ViewingAngle
ResponseTime
PanelLife
IntelligentSceneController
42.0-inch
16:9
IPS1080p(WSXGA)
EffectiveDisplayArea(WxH) 36.6"x20.6"(930x523mm)
1,920x1,080pixel
450cd/㎡
20,000:1
178degrees
7ms(GtoG)
approx.60,000hours
Yes
10W+10W(10%THD)
1way2bottomSpeakers
AVSurround
Yes
■AUDIO
AudioOutputPower
InvisibleSpeakerSystemDetails
SoundSystemType
Bass/Treble/Barancecontrols
40.2"x26.9"x12.6"(1,021x682x318mm)
40.2"x25.1"x4.2"(1,021x637x105mm)
52.0"x29.3"x9.1"(1,321x743x229mm)
approx.47.7lbs.(21.6kg)
approx.38.6lbs.(17.5kg)
approx.61.9lbs.(28.0kg)
Black(Texture)
■DIMENSIONS&WEIGHT
IncludingTVStand(WxHxD)
TVSetOnly(WxHxD)
CartonDimensions(WxHxD)
IncludingTVStand(Weight)
TVSetOnly(Weight)
Grossweight
CabinetColor
Temperature :32°Fto95°F(0℃to35℃)
Humidity :20%to80%(Noncondensation)
Temperature :-4°Fto140°F(-20℃to60℃)
Humidity :20%to90%(Noncondensation)
■ENVIRONMENTAL
Operatingenvironment
Storageenvironment
■RECEIVINGSYSTEM
ATSC/NTSC/QAM
FTGHDSupport
VHF/UHF:2-69,CATV:1-135
RequiresFMA-PA101orLocalAuthenticationbySDCard
EBL(embeddedb-LAN)
MPEG2,MPEG4/H.264
■VIDEO
VIDEOCODEC
1
RCAx1(rear),RCAx1(side) 1.0V[p-p](75Ω)
RCA(L/R)x1set(rear),x1set(side) 0.5V[rms]
RCAx1set(YPBPR)(rear) Y :withsync1.0V[p-p](75Ω)
PB,PR :±0.35V[p-p](75Ω)
RCAx1set(rear) 0.5V[rms]
HDMITYPEAconnectorx2(rear),x1(side)
MINID-sub15pinx1(Female,rear) R,G,B
 :0.7V[p-p](75Ω)
HD/VD :1.0-5.0V[p-p](highimpedance)
3.5mmjackx1(rear)
Opticalx1(rear)
3.5mmjackx1(rear) 0.5V[rms]
0.5V[rms]
1
■CONNECTIONTERMINAL
RFIN(Antenna/Cable)
VIDEOIN
AUDIOIN(L/R)
COMPONENTVIDEOIN
AUDIOIN(L/R)
HDMIIN
PCIN
AUDIOIN(L/R)
AUDIOOUT(Digital/SPDIF)
AUDIOOUT(Analog)
SDCardslot
110-127VAC,60Hz(ACPowerCable90.6"(2.3m))
205W(Energystar5.3,CEC)
0.9W
■ELECTRICAL
PowerRequirements
PowerConsumption
Stand-byPower
81W
OnmodeAveragePowerConsumption*
*BasedonIEC62087Ed.2section11.6.1measurementmethod
RJ11(6pin)x1(rear)(CompatiblewithLodgeNetgamecontroller)
3.5mmjackx1(rear),RS232C
■CONTROLTERMINAL
DATA/MTI
SERIALPort
885170077072
UPCCode

PMY06/22/20122/2©PanasonicCorporation2012
Units:inches(mm)
TH-42LRU50
DIMENSIONS
CONNECTIONTERMINAL
Rotationangleof60°
Rotationangleof30°
Rotationangleof90°
42-inchClass1080pHospitalityLCDHDTV
<rear> <side>
7.9(199)
Cautions:Thisdrawingisnotascale
40.2(1021)
2(49) 1.1(28)
7.7(195)
17.8(450)
4.2(105)
4.0(102)
3.6(94)
4.4(111)
12.2(310)
12.6(318)
26.9(682)
14.8(374)
25.1(637)
1.8(45)
12.2(310)
12.5
(316)
9.8
(248)
19.0
(483)
16.5
(418)
21.9
(555)
18.4
(466)
MAINFEATURE ACCESSORIES
INCLUDEDACCESSORIES SwivelStand(degrees:30°/60°/90°) 
Remotecontroltransmitter
BatteriesfortheRemoteControl
Transmitter(AABatteryx2)
OperatingInstruction
*VESACompliantW200xH200mm
OptionalAccessories
Wallhangingbracket(TY-WK3L2RW)
SecurityLockdownScrews
(SecurityBit:Optional)
AntitheftScrewforStand
STANDARD(CERTIFICATIONS)
SAFETYREGULATIONS
RADIATIONREGULATIONS
ENERGYSTAR5.3,CEC
UL6500Ver.2,cUL,BETS-7
FCCPart15Class-B,ICES-003,ISTA
Yes
VIERALink
TM
,HDAVIControl
TM
WelcomeImage
SDCardSlot
OFFTimer
HotelMode
Yes
Yes
ImageViewer(JPEGplayback)
Cloning
15/30/60/90minutes
InitialINPUT
InitialChannel
InitialVOLlevel
MaximumVOLlevel
ButtonLock
PowerControl
IntegratedPro:Idiom Yes
LocalAucentication Yes
FastBoot
Yes
