ORDER NO. MTV0901843CE
LCD TV
Model No. TH-L32A10R2
Chassis: KM02
Destination: IRAN
Specifications
Power Source AC SINGLE 220 - 240V, 50/60 Hz
Power Consumption
Average use 99 W
Standby condition 0.7 W
Display panel
Aspect Ratio 16:9
Visible screen size 80 cm (diagonal)
698 mm (W) ×392 mm (H)
Number of pixels 1,049,088 (1,366 (W) ×768 (H))
Sound
Speaker Full range ×4 pcs, 8 Ω
Audio Output (10 W + 2 W) ×2, 10% THD
Headphones M3 (3.5 mm) stereo mini Jack ×1
PC Signals VGA, SVGA, XGA
SXGA ...... (compressed)
Horizontal scanning frequency 31 - 69 kHz
Vertical scanning frequency 59 - 86 Hz
Receiving Systems / Band name 17 SYSTEMS FUNCTIONS
1PAL B, G, H
Reception of broadcast transmission and
playback from video cassette tape recorders.
2PAL I
3PAL D, K
4SECAM B, G
5SECAM D, K
6SECAM K1
7NTSC M (NTSC 3.58 / 4.5MHZ)

TH-L32A10R2
2
8NTSC 4.43 / 5.5 MHz
Playback from special VCR’s or DVD.
9NTSC 4.43 / 6.0 MHz
10 NTSC 4.43 / 6.5 MHz
11 NTSC 3.58 / 5.5 MHz
12 NTSC 3.58 / 6.0 MHz
13 NTSC 3.58 / 6.5 MHz
14 SECAM I
15 PAL 60 Hz / 5.5 MHz Playback from Special Disc Players and
Special VCR’s or DVD.
16 PAL 60 Hz / 6.0 MHz
17 PAL 60 Hz / 6.5 MHz
Receiving Channels (Analogue TV)
VHF BAND 2 - 12 (PAL / SECAM B, K1)
0 - 12 (PAL B AUST.)
1 - 9 (PAL B N.Z.)
1 - 12 (PAL / SECAM D)
1 - 12 (NTSC M JAPAN)
2 - 13 (NTSC M USA)
UHF BAND 21 - 69 (PAL G, H, I / SECAM G, K, K1)
28 - 69 (PAL B AUST.)
13 - 57 (PAL D, K)
13 - 62 (NTSC M JAPAN)
14 - 69 (NTSC M USA)
CATV S1 - S20 (OSCAR)
1 - 125 (USA CATV)
C13 - C49 (JAPAN)
S21 - S41 (HYPER)
Z1 - Z37 (CHINA)
5A, 9A (AUST.)
Aerial - Rear VHF / UHF
Operating Conditions Temperature : 0°C - 40°C
Humidity : 20 % - 80 % RH (non-condensing)
Connection Terminals
AV1 Input AUDIO L-R RCA PIN Type ×2 0.5 V [rms]
VIDEO RCA PIN Type ×1 1.0 V [p-p] (75 Ω)
COMPONENT Y 1.0 V [p-p] (including synchronization)
PB/CB, PR/CR± 0.35 V [p-p]
AV2 Input AUDIO L-R RCA PIN Type ×2 0.5 V [rms]
VIDEO RCA PIN Type ×1 1.0 V [p-p] (75 Ω)
COMPONENT Y 1.0 V [p-p] (including synchronization)
PB/CB, PR/CR± 0.35 V [p-p]
AV3 Input AUDIO L-R RCA PIN Type ×2 0.5 V [rms]
VIDEO RCA PIN Type ×1 1.0 V [p-p] (75 Ω)
S VIDEO Mini DIN 4-pin Y: 1.0 V [p-p] (75 Ω) C: 0.286 V [p-p] (75 Ω)
Others HDMI 1 / 2 Input TYPE A Connectors • This TV supports “HDAVI Control 4” function.
PC Input HIGH-DENSITY D-SUB 15 PIN R, G, B / 0.7 V[p-p] (75 Ω)
HD, VD / TTL LEVEL 2.0-5.0 V [p-p] (high impedance)
Card Slot SD Card slot ×1
Monitor
Output AUDIO L-R RCA PIN Type ×2 0.5 V [rms] (High impedance)
VIDEO RCA PIN Type ×1 1.0 V [p-p] (75 Ω)
Dimensions (W x H x D) 855 mm ×553 mm ×217 mm (With Pedestal)
855 mm ×513 mm ×94 mm (TV only)
Mass 14 kg Net (With Pedestal)
12 kg Net (TV only)
Design and specifications are subject to change without notice. Weight and dimensions shown are approximate.

TH-L32A10R2
3
