Operating Instructions
LCD Television
English Please read these instructions before operating your set and retain them for future reference.
The images shown in this manual are for illustrative purposes only.
Information on Disposal for Users of Waste Electrical & Electronic Equipment
(private households)
This symbol on the products and/or accompanying documents means that used electrical and
electronic products should not be mixed with general household waste.
For proper treatment, recovery and recycling, please take these products to designated collection
points, where they will be accepted on a free of charge basis. Alternatively, in some countries you
may be able to return your products to your local retailer upon the purchase of an equivalent new
product.
Disposing of this product correctly will help to save valuable resources and prevent any potential negative
effects
on human health and the environment which could otherwise arise from inappropriate
waste handling. Please contact your local authority for further details of your nearest designated collection point.
Penalties may be applicable for incorrect disposal of this waste, in accordance with national legislation.
For business users in the European Union
If you wish to discard electrical and electronic equipment, please contact your dealer or supplier for further
information.
Information on Disposal in other Countries outside the European Union
This symbol is only valid in the European Union.
If you wish to discard this product, please contact your local authorities or dealer and ask for the correct method of
disposal.
Printed in Czech Republic
Model No. TX-26LX70P
TX-32LX70P
Matsushita Electric Industrial Co., Ltd.
Web Site : http://www.panasonic-europe.com
©2007 Matsushita Electric Industrial Co., Ltd. All Rights Reserved.
Customer’s Record
The model number and serial number of this product may be found on its rear panel. You should note this serial
number in the space provided below and retain this book, plus your purchase receipt, as a permanent record of your
purchase to aid in identification in the event of theft or loss, and for Warranty Service purposes.
Model Number Serial Number
TQB0E0402U-1

2
3
Viewing Advanced FAQs, etc.Quick Start Guide
Turn your own living room into a movie theatre!
Experience an amazing level of multi-
media excitement
Enjoy rich multi-media
Camcorder
Amplifier with
Speaker system
VCR DVD player
DVD Recorder
Personal
computer
Set top box
Contents
•Safety Precautions······································ 4
(Warning / Caution)
•Notes··························································· 5
•Maintenance ··············································· 5
Be Sure to Read
Advanced Features
•How to Use Menu Functions····················· 18
(picture, sound quality, etc.)
•
Editing and Setting Channels ······················ 22
•Control Channel Audience ························ 24
•Restore Settings ······································ 25
•Input Labels ·············································· 26
•Displaying PC Screen on TV····················· 27
•Q-Link Functions······································· 28
•HDMI Functions ······································· 29
(HDMI terminal / VIERA Link)
•External Equipment··································· 32
Basic Features
•Watching TV·············································· 12
•Watching Videos and DVDs······················ 14
•Viewing Teletext ········································ 16
Enjoy your TV!
•Technical Information ································ 34
•FAQs ························································· 37
•Licence······················································ 39
•Specifications············································ 39
FAQs, etc.
Accessories / Options·········· 6
Identifying Controls ··············· 7
Basic Connection ··················· 8
Auto Setup······························· 10
Quick Start Guide

4 5
Safety Precautions
If you find any
abnormality,
remove the mains plug
immediately!
Keep liquids away from the TV
To prevent damage which may result in fire or
shock hazard, do not expose this appliance to
dripping or splashing.
Do not place containers with water (flower vase,
cups, cosmetics, etc.) above the TV. (including on
shelves above, etc.)
Do not remove covers
NEVER modify the TV yourself
(High-voltage components may cause serious
electrical shock.)
Have the TV checked, adjusted, or repaired at your
local Panasonic dealer.
Do not place foreign objects
inside the TV
Do not let metal or flammable objects drop into the
TV through the air vents (fire or electrical shock
may result).
(Cleaning an energized TV may cause
electrical shock.)
When cleaning the TV, remove the
mains plug
Handling the mains plug and lead
Insert the mains plug fully into the socket outlet. (If the mains plug is loose, it could generate heat and cause fire.)
Ensure that the mains plug is easily accessible.
Do not touch the mains plug with a wet hand. (This may cause electrical shock.)
Do not damage the mains lead. (A damaged lead may cause fire or electrical shock.)
Do not move the TV with the lead plugged in the socket outlet.
Do not place a heavy object on the lead or place the lead near a high-temperature object.
Do not twist the lead, bend it excessively, or stretch it.
Do not pull on the lead. Hold onto the mains plug body when disconnecting lead.
Do not use a damaged mains plug or socket outlet.
Warning
Do not expose to direct sunlight
and other sources of heat
Avoid exposing the TV to direct sunlight and other
sources of heat. To prevent fire never place any
type of candle or naked flame on top or near the TV.
Caution
Blocked ventilation by curtains,
etc. may cause overheating, fire
or electrical shock.
Do not block the rear air vents
Notes
When TV will not be used for a
long time, remove the mains plug
This TV will still consume some power even
in the Off mode, as long as the mains plug is
still connected to a live socket outlet.
Electronic equipment
In particular, do not place video equipment near the
TV (electromagnetic interference may distort images
/ sound).
Use only the dedicated stands
/ mounting equipment
Using an unauthorized stand or other fixtures may
make the TV shaky, risking injury. Be sure to ask
your local Panasonic dealer to perform setup.
Use optional stands / mounts (p. 6).
Do not place the TV on sloped
or unstable surfaces
The TV may fall off or tip over.
Equipment with an infrared sensor
This TV also emits infrared rays (this may affect
operation of other equipment).
Keep the TV away from these equipment
Adjust the LCD panel to your desired
angle
15° 15°
(View from the top)
If no signal is received and no operation is
performed in TV mode for 30 minutes, the TV will
automatically go to standby mode.
Auto power standby function
Transport only in upright position
AC 220-240 V
50 / 60 Hz
Maintenance
Display panel
Cabinet
Mains plug
Regular care: Gently wipe the surface clean of dirt by using a soft cloth.
Major contamination: Wipe the surface clean using a soft cloth dampened with clean water or diluted neutral
detergent by 100 times of water. Then, using a soft dry cloth, evenly wipe the surface clean until it is dry.
Regular care: Wipe the surface clean using a soft dry cloth.
Major contamination: Dampen a soft cloth with clean water or water containing a small amount of neutral detergent.
Then, wring the cloth and wipe the surface clean with it. Finally, wipe the surface clean with a dry cloth.
Wipe the mains plug with a dry cloth at regular intervals. (Moisture and dust may lead to fire or electrical shock.)
First, remove the mains plug from the socket outlet.
Caution
•
The surface of the display panel has been specially treated and may be easily damaged.
Do not tap or scratch the surface with your fingernail or other hard object.
•
Use care not to subject the surface to bug repellent, solvent, thinner, or other volatile substances
(this may degrade surface quality).
Caution
•
Use care not to subject the TV's surfaces to detergent.
(A liquid inside the TV could lead to product failure.)
•
Use care not to subject surfaces to bug repellent, solvent, thinner, or other volatile substances
(this may deteriorate the surface by peeling the paint).
•
Do not allow the cabinet to make contact with a rubber or PVC substance for a long time.
Allow sufficient space around the
TV for radiated heat
10
10
10 10
(cm)
TV Stand
Minimum distance

6
7
Quick Start Guide
TV
OK
132
465
798
0
TV
PROGRAMME
ASPECT
INPUT
RETURN
EXIT
MENU
OK
OPTION DIRECT TV REC
VCR
132
465
798
0
REC VCR DVD
TEXT F.P. INDEX HOLD
+
-
-
+
FTV AV
Identifying ControlsAccessories / Options
•
Identifying Controls
•
Accessories / Options
Batteries for the Remote
Control Transmitter (2)
•
R6 (UM3)
Clamper Remote Control
Transmitter
•
EUR7651120
Standard accessories Check that you have the accessories and items shown
Operating Instructions Pan European Guarantee Card
Installing remote’s batteries
Caution
•
Incorrect installation may cause battery
leakage and corrosion, resulting in
damage to the remote control.
•Do not mix old and new batteries.
•Do not mix different battery types (such
as alkaline and manganese batteries).
•Do not use rechargeable (Ni-Cd)
batteries.
•
Do not burn or breakup batteries.
Using the clamper
Cursor buttons to make selections and
adjustments
Standby On / Off switch
(Switches TV On or Off standby)
Sound mute On / Off
Changes aspect ratio (p. 13)
Selects programmes in sequence
Access VIERA Link Menu (p. 31)
OK button to confirm selections and choices
Press after selecting programme positions to
quickly change programme.
VCR / DVD operations (p. 15)
Volume
Programme Information (p. 13)
Teletext Index (p. 17)
Coloured buttons used for the
selection, navigation and operation of
various functions
EXIT (Returns to TV screen)
DIRECT TV Recording
To immediately record programme in VCR /
DVD recorder with Q-Link connection
(p. 28)
Programme / channel change buttons (0-9)
and Teletext page buttons. (p. 12 and p. 16)
When in Standby mode, switches TV On.
Option menu
Sets the preferred settings of viewing
and sound options easily (p. 13)
Main Menu
Press to access VIERA Link, Picture,
Sound and Setup menus (p. 18)
Viewing a favourite teletext channel (p. 17)
Surround (p. 20)
Changes the input mode
TV - changes TV mode (p. 14)
AV - changes AV input mode (p. 14)
Returns to the previous menu
Still picture (p. 13)
Teletext Hold (p. 17)
1Pull
open
Hook
2
Note the correct
polarity (+ or -)
Close
Increases or decreases the programme
position by one. When a function is
already displayed, press to increase or
decrease the selected function. When in
Standby mode, switches TV On.
Mains power
On / Off switch
C.A.T.S. (Contrast Automatic Tracking System) sensor
(senses brightness to adjust picture quality in “Auto” Mode in Picture Menu) (p. 20)
Remote control
signal receiver
Changes the
input mode
Function select
•Volume / Contrast / Brightness /
Colour / Sharpness /
Tint (NTSC mode) / Bass / Treble /
Balance / Auto Setup (p. 22)
Power LED
•Standby: red
On: green
Teletext (p. 16)
•
Do not bundle the RF cable and mains lead together (could cause
distorted image).
•
Fix cables with clampers as necessary.
•
When using the optional accessory, follow the option’s assembly
manual to fix cables.
To tighten:
Keep the
knob pressed
Rear of the TV
To loosen:
Clamper
(Standard accessory)
Clamper
that bundle
mains lead
Bundle the
cables:
Hook the
clamper:
Tight
Lock
Bottom Sheet
Use when removing the
TV Stand (see below)
Optional accessories
Wall-hanging
bracket
TY-WK32LR2W
WARNING!
•
Failure to use a Panasonic bracket or choosing to mount the unit
yourself will be done at the risk of the consumer.
Any damage resulting from not having a professional installer
mount your unit will void your warranty.
•
Always be sure to ask a qualified technician to carry out set-up.
Incorrect fitting may cause equipment to fall, resulting in injury
and product damage.
•
Do not mount the unit directly below ceiling lights (such as
spotlights, floodlights or halogen lights) which typically give off
high heat. Doing so may warp or damage plastic cabinet parts.
How to remove the TV Stand
Remove four screws and take the
TV Stand.
Rear of
the TV
Please contact your nearest Panasonic dealer to purchase the recommended
wall-hanging bracket. For additional details, please refer to the wall-hanging
bracket installation manual.
Attach the Bottom Sheet.
Bottom of
the TV

8
9
Quick Start Guide
L
R
Y
PB
PR
PC
AUDIO OUT
V
I
D
E
O
A
U
D
I
O
C
O
M
P
O
N
E
N
T
L
R
L
R
Y
PB
PR
PC
AUDIO OUT
V
I
D
E
O
A
U
D
I
O
C
O
M
P
O
N
E
N
T
L
R
RF IN
RF OUT
RF OUTRF IN RF OUTRF INRF IN
L
R
Y
PB
PR
PC
AUDIO OUT
V
I
D
E
O
A
U
D
I
O
C
O
M
P
O
N
E
N
T
L
R
•
Basic Connection
Basic Connection
Mains lead Mains lead
SCART cable
(fully wired)
DVD Recorder or VCR
RF
cable
Aerial AerialRear of the TV Rear of the TV
External equipment and cables shown are not supplied with this TV.
Please ensure that the unit is disconnected from the mains socket before attaching or disconnecting any leads.
Example 1
Connecting aerial
Example 2
Connecting DVD Recorder / VCR
RF cable
RF cable
TV only TV, DVD Recorder or VCR
AC 220-240 V
50 / 60 Hz
AC 220-240 V
50 / 60 Hz
Note
•
Connect to AV1 / 2 for a DVD Recorder / VCR supporting Q-Link (p. 28).
DVD Recorder
or VCR
SCART cable
(fully wired)
RF cable
Aerial
Mains lead
Rear of the TV
Set top box
Example 3
Connecting DVD Recorder / VCR and Set top box
AC 220-240 V
50 / 60 Hz
RF cable
RF cable
TV, DVD Recorder / VCR and Set top box
SCART cable
(fully wired)
SCART cable
(fully wired)
RF cable

10
11
Quick Start Guide
INPUT
ASPECT
OPTION DIRECT TV REC
VCR
132
465
798
0
PROGRAMME
REC VCR DVD
TEXT F.P. INDEX HOLD
TV
RETURN
EXIT
MENU
OK
Select EXIT
Change
RETURN
Mode Music
Bass
Treble
Balance
Headphone Volume
Surround Off
Volume Correction
MPX Stereo
Sound Menu
Reset to Default Set
MENU
EXIT
RETURN
Country
Portugal
Spain
Italy
France
Austria
Germany
Netherlands
Hungary
Czech
E.Eu
Ireland
Poland
Switzerland
Belgium
Finland
Norway
Sweden
Denmark
Greece
Auto Setup
EXIT
This will take about 3 mins.
RETURN
Scan 214178
CH 29
Channel Service Name
CH 33
DOWNLOAD IN PROGRESS
PLEASE WAIT
Programme : 63
Remote control unavailable
Menüsprache
Slovenčina
Čeština
Еλληνικά
Italiano
Français
English
Srpski
Deutsch
Português
Türkçe
Suomi
Polski
Românǎ
Hrvatski
Nederlands
Slovenščina
Български
Magyar
Svenska
Dansk
Norsk
Español
Viewing Mode
Dynamic Normal Cinema Auto
Plug the TV into mains socket and switch On
(Takes a few seconds to be displayed)
1
(example: Sound Menu)
On-screen operation
guide will help you.
Auto Setup
Search and store TV channels automatically.
These steps are not necessary if the setup has been completed by your local dealer.
Auto Setup is now complete and your TV is ready for viewing.
•
You can now use the remote
control to turn On the TV or turn
the TV to standby mode.
(Power LED: On)
3
•
To edit channels
Editing and Setting Channels
(p. 22)
■
ON SCREEN HELP Instructions box
Open the main menu
Return to the previous menu
Move the cursor / select the menu
Move the cursor / adjust levels / select from a range of options
Access the menu / store settings after adjustments have been made or options
have been set
Many features available on this TV can be accessed via the On Screen Display
menu.
Note
•
If tuning have failed “Auto Setup” ( p. 22).
•
If downloading have failed “Download” ( p. 21).
•
If you turned the TV Off during Standby mode last time, the TV will be in Standby mode when you turn the TV On
with Mains power On / Off switch.
■
How to use remote control
•
Auto Setup
Using the
On Screen
Displays
Exit the menu system and return to the normal viewing screen
Select your country
4Start Auto Setup
•
If a compatible recording equipment
with Q-Link or similar technologies
(p. 28) is connected, channel
information is automatically
downloaded to the equipment.
•
Auto Setup will start to search for
TV channels and store them.
The sorted programme order
depends upon the TV signal,
the broadcasting system and
reception conditions.
2Select the language
select
store
select
•
Also possible to change the setting
in Picture Menu (p. 20)
5Select the picture setting
select
set

12
13
Viewing
INPUT
RETURN MENU
DIRECT TV REC
PROGRAMME
REC VCR DVD
TEXT F.P. INDEX
TV
ASPECT
OK
OPTION
VCR
132
465
798
0
HOLD
EXIT
1 BBS
Corontation Street
CH05 SC1 PAL
VCR
132
465
798
0
•
To select the two-digit programme number, e.g. 39
Watching TV
Select a channel
up
2
Information banner
Turn power on
Mains power On / Off switch should be On.
(Press for about 1 second)
down
or
1
•
Watching TV
HOLD
Freeze / unfreeze picture
Hold
9
(in a short time)
3
■
Other useful functions (Operate after )
Change
aspect
ratio
Select
Change EXIT
RETURN
Aspect Selection
16:9
Just
14:9
4:3 Full
4:3
Zoom1
Zoom2
Zoom3
Auto
A
SPECT
Change the aspect ratio (p. 34)
Enjoy viewing the picture at its optimum size and aspect.
Aspect Selection list
•
To change the mode
•
To change the mode using the ASPECT button only
A
SPECT
(Press repeatedly until you reach the desired mode)
Display Aspect
Selection list
A
SPECT
During the list is displayed,
select the mode Store
Volume
Display the
current
programme
status
OPTION
Check or change the current
programme status instantly
•
To change
Teletext Language
Selects teletext language
MPX
Sound Menu (p. 20)
Volume Correction
Adjusts volume of individual channel or input mode
Note
•
Also possible to change the settings in Menu list (p. 20 and p. 21).
select
change
Display
information
banner
Display programme information
For info press
Change Category
STTL Bad Signal Encrypted AD
Now
TXT
Profile 1
23:35
1 BBS
Corontation Street
Stereo 45
CH05 SC1 PAL
•
To set display timeout
“Banner Display Timeout” (p. 21)
•
Appears also when changing channel.
•
Programme information is referred to
teletext signal.
•
To select another channel
•
To hide
EXIT
Stereo sound
Off timer
Features available
Programme
Channel
Sound mute
Sound system
Colour system Teletext

14
15
Viewing
ASPECT
RETURN
EXIT
MENU
DIRECT TV REC OPTION
TEXT F.P. INDEX HOLD
TV
PROGRAMME
INPUT
OK
VCR
132
465
798
0
REC VCR DVD
•
Watching Videos and DVDs
Watching Videos and DVDs
2
3
Connect the external equipment (VCRs, DVD equipment, etc.) and you can watch the input.
To connect the equipment (p. 8 and p. 9)
The Remote Control is capable of operating some functions of selected Panasonic external equipment.
Select the input mode connected to the equipment
Note
•
If the external equipment has an aspect adjustment function, set to “16:9”.
•
For details, see the manual of the equipment or ask your local dealer.
■
To return to TV
Display the Input select menu
Displays the selected mode
1Turn the TV on
■
When connecting with SCART as example 2 or 3 (p. 8 and p. 9)
Receives input signals automatically when playback starts
•
Input signals are automatically identified by the SCART (pin 8)
terminal.
•
This function is also available for HDMI connections (p. 31).
■
If input mode is not switched automatically
Perform and
•
You can also select the input using the AV button on the remote
control or the top panel of the TV.
Press the button repeatedly until the desired input is selected.
•
You can label or skip each input modes “Input Labels” (p. 26)
•
Dependant on the setup of the equipment
VCR DVD
VCR DVD
VCR / DVD switch∗
Select VCR to operate Panasonic VCR or DVD equipment
Select DVD to operate Panasonic DVD equipment or Player home theatre
Standby
Set to Standby mode / Turn on
Play
Playback videocassette / DVD
Stop
Stop the operations
Rewind / Skip / Search
VCR: Rewind, view the picture rapidly in reverse
DVD: Skip to the previous track or title
Press and hold to search backward
Fast-forward / Skip / Search
VCR: Fast-forward, view the picture rapidly forward
DVD: Skip to the next track or title
Press and hold to search forward
Pause
Pause / Restart
DVD: Press and hold to play at slow speed
PROGRAMME
Programme Up / Down
Select programme
REC
Record
Start recording
Panasonic equipment connected to the TV can be directly operated with the remote control.
Note
•
Confirm correct operation after the code changed.
•
The codes will be reset to default values if batteries are replaced.
•
“DVD” means DVD player, DVD recorders and Recorder home theatre.
•
Some operations may not be possible on some equipment models.
∗Setting your remote control to operate Panasonic VCR, DVD, etc.
Set the VCR / DVD switch to the appropriate position
Press and hold during the following operations
Enter the appropriate code for the equipment
to be controlled, see table below Press
“VCR” position
Equipment Code
VCR 10 (default)
DVD 11
“DVD” position
Equipment Code
DVD 70 (default)
Player home theatre 71
Input Selection
AV1
AV2/AV2S
AV3/AV3S
COMPONENT
PC
HDMI1
HDMI2
TV
4View
select
watch
VCR
132
465
798
0

16
17
Viewing
ASPECT
INPUT
RETURN
EXIT
PROGRAMME
REC VCR DVD
OPTION DIRECT TV REC
TV
MENU
OK
VCR
132
465
798
0
TEXT F.P. INDEX HOLD
<< 01 02 03 04 05 06 07 >>
TELETEXT
INFORMATION
17:51 28 Feb
TEXT
red
green
yellow blue
VCR
132
465
798
0
Viewing Teletext
Switch to Teletext
1
Select the page
up
or
You can enjoy teletext broadcasting, including news, weather forecasts and subtitles, if this service is
provided by the broadcasters.
or
■
To return to TV
TEXT
(Corresponds to the colour bar)
•
Displays Index
(content varies
depending on the
broadcasters)
Call up a
favourite
pages
F.P.
•
Call up the page stored in “blue”.
•
Factory setting is “P103”.
down
•
Viewing Teletext
Time / date
Current
page
number
Sub page number
Colour bar
What is FLOF (FASTEXT) mode?
In FLOF mode, four differently coloured subjects are situated at the bottom of the screen. To access more
information about one of these subjects, press the appropriately coloured button. This facility enables fast access to
information on the subjects shown.
What is List mode?
In List mode, four differently coloured page numbers are situated at the bottom of the screen. Each of these
numbers can be altered and stored in the TV’s memory. (“Store frequently viewed pages”, p. 17)
■
To change mode “Teletext” in Setup Menu (p. 21)
■
To adjust contrast
MENU
As the blue bar is displayed
Reveal
hidden
data
MENU
red
•
Re-hide
red
Reveal hidden words e.g. quiz page answers
■
Using teletext conveniently
FULL /
TOP /
BOTTOM
MENU
green
Normal (FULL)(BOTTOM)
(Expand the BOTTOM half)
INDEX
INDEX
•
FLOF mode only
Return to the main index page
HOLD HOLD
If you wish to hold the current page without updating
Stop or resume automatic updating
■
To resume
HOLD
Store
frequently
viewed
pages
VCR
132
465
798
0
Store frequently viewed pages in the colour bar (List mode only)
As page is
displayed
The number changes to white.
Corresponding
colour button
■
To change stored pages
Enter new page number
Colour button you
want to change
View sub
page
0 0 0 6
•
Sub pages:
The number of sub pages varies depending on the broadcasters (up to 79 pages).
It may take some time for searching, during which time you can watch TV.
Enter the
4-digit number
example: P6
Appears at upper-left
corner of the screen
■
To view specific sub page
MENU
blue
View sub page (Only when teletext is more than one page)
Watch
TV while
waiting
for update
P108
MENU
yellow yellow
Appears
when
updating is
completed
(You cannot change the channel.)
Teletext automatically updates itself when new information becomes available.
•
The news page provides a function that indicates arrival of latest news (“News Flash”).
Changes to TV screen temporarily
View the
updated
page
View the TV picture while searching for a teletext page
2
(TOP)
(Expand the TOP half)
View in
multi
window
MENU
Watch TV and Teletext in two windows at once
•
Operations can be made only in Teletext screen.
(Press twice) •
Select Picture and text
On or Off
press
and
hold
press
and
hold

Advanced
Main Menu
VIERA Link
Sound
Setup
Picture Menu 1/2
Viewing Mode Auto
Contrast
Brightness
Colour
Sharpness
Tint
Colour Balance Warm
Colour Management Off
P-NR Off
VCR
132
465
798
0
INPUT
ASPECT
OPTION DIRECT TV REC
TEXT F.P. INDEX HOLD
PROGRAMME
REC VCR DVD
TV
RETURN
EXIT
MENU
OK
Picture Menu 1/2
Contrast
Brightness
Colour
Sharpness
Tint
Colour Balance Warm
Colour Management Off
P-NR Off
Viewing Mode Auto
Colour Balance Normal
Sharpness
Tuning Menu Access
MENU
18
19
How to Use Menu Functions
•How to Use Menu Functions
(picture, sound quality, etc.)
Display the menu
3
2
4
Various menus allow you to make settings for the picture, sound, and other functions.
•
Displays the functions that can be set
(varies according to the input signal)
Note
•
To initialize all settings
“Shipping Condition”
(p. 25)
■
To return to TV
at any time
EXIT
■
To return to the
previous screen
RETURN
Select the menu
Select the item
(example: Picture Menu)
Adjust or select
(example: Picture Menu)
(example: Picture Menu)
Changed
Number and positions
of alternatives
Moved
■
Choose from among alternatives
■
Adjust using the slide bar
1
Displays the next screen
■
Go to the next screen
■
To change menu pages
up
down
■
Overview
VIERA Link Control
Speaker Selection
VIERA Link Menu
Home Cinema
Recorder
(p. 31)
Main Menu
VIERA Link
Sound
Setup
The menu of the accessed
equipment
Picture Menu 1/2
Contrast
Brightness
Colour
Sharpness
Tint
Colour Balance Warm
Colour Management Off
P-NR Off
Viewing Mode Auto
2/2
3D-COMB Off
Reset to Default Set
Picture Menu
MPEG NR Off
(p. 20)
2/2
Reset to Default Set
Sound Menu
Mode Music
Bass
Treble
Balance
Headphone Volume
Surround Off
Volume Correction
MPX Stereo
Sound Menu
HDMI1 Input Auto
1/2
(p. 20)
1/2
AV Colour System
Q-Link Settings Access
Child Lock Access
Tuning Menu
Teletext FLOF
Access
Setup Menu
Language Access
Off Timer Off
Auto
Shipping Condition Access
Input Labels Access
Access
2/2
Banner Display Timeout 3 seconds
Software License
System Information Access
Access
Setup Menu
VIERA Link On
(p. 21)
Q-Link Settings
Q-Link AV2
AV2 out TV
Download Access
(p. 21)
Access
Tuning Menu
Auto Setup Access
Programme Edit Access
Manual Tuning Access
(p. 22)
•
Only available items can be selected.
select
access
select
change
store or access
(Required by some
functions)

Advanced
Menu Item Adjustments / Configurations (alternatives)
VIERA Link
VIERA Link Control Controls the connected Panasonic equipment
“Easy control only with VIERA remote control” (p. 31)
“Speaker control” (p. 31)
•
You can also access VIERA Link Menu directly using the VIERA Link button on the
remote control.
Speaker Selection
Viewing Mode Basic picture mode (Dynamic / Normal / Cinema / Auto)
•
Set for each input signal
Contrast, Brightness,
Colour, Sharpness Adjusts colour, brightness, etc. for each picture mode to suit your taste
Tint Adjusts tint of image
•
For NTSC signal reception only
Colour Balance Chooses the colour balance of the entire image (Cool / Normal / Warm)
Colour Management Automatically adjusts colours to vivid ones (Off / On)
•
Not valid on PC signal
P-NR
Picture Noise Reduction
Automatically reduces unwanted picture noise (Off / Normal / Dynamic / Auto)
•
Not valid on HDMI or PC signal
MPEG NR Automatically reduces noise for watching DTV, DVD and VCD (Off / Min /Mid / Max)
3D-COMB
Automatically makes still pictures and slow pictures look more vivid (Off / On)
•
For PAL or NTSC signal reception only
•
Not valid on RGB, S-Video, components, PC and HDMI
Reset to Default Press the OK button to reset the present Picture Mode to the default settings
Sound
Mode Basic sound mode (Music / Speech)
Bass Adjusts the output level of deep bass
Treble Adjusts the output level of high-pitch, shrill sound
Balance Adjusts volume level of right and left speakers
Headphone Volume Adjusts the volume of the headphones
Surround
Surround sound settings (Off / On)
Provides a dynamic enhancer to simulate improved spatial effects
•
Switching is also possible by the Surround button on the remote control (p. 7)
Volume Correction Adjusts volume of individual channel or input mode
MPX
Select stereo / monaural (Mono / Stereo)
•
Normally: Stereo
•
Stereo signal cannot be received: Mono
•
M1 / M2: Available while mono signal is transmitted
HDMI1 Input
Select to fit the input signal (Auto / Digital / Analogue) (p. 29)
Auto : Automatic detection of digital or analogue sound source
Digital : HDMI cable connection
Analogue : HDMI-DVI adapter cable connection
•
HDMI input mode only
•
HDMI2 terminal is for digital signal only
•
No setting for HDMI2 available
Reset to Default Press the OK button to reset the present Sound Mode to the default settings
Menu Item Adjustments / Configurations (alternatives)
Setup
AV Colour System Selects optional colour system based on video signals in AV mode
(Auto / PAL / SECAM / M.NTSC / NTSC)
Q-Link Settings
Q-Link Selects which AV terminal is to be used for data communication between this TV and a
compatible recording equipment (AV1 / AV2) (p. 28)
AV1 / AV2 out
Chooses the signal to be transmitted from the TV to Q-Link
(TV / AV1 / AV2 / AV3 / Monitor)
•
Monitor: Image displayed on screen
•
Component, PC and HDMI signals cannot be outputted
Download Downloads channel information to a Q-Link compatible equipment connected to the TV
Child Lock Locks a programme channel to prevent access to it (p. 24)
Tuning Menu
Auto Setup Automatically sets the channels received in the area (p. 22)
Programme Edit Edits channels (p. 23)
Manual Tuning Sets the channels manually (p. 23)
Off Timer Sets the time the TV automatically turns Off (Off / 15 / 30 / 45 / 60 / 75 / 90 minutes)
Language
OSD Language Changes language for on-screen displays
Teletext
Language
Selects teletext language (West / East1 / East2)
•
West: English, French, German, Greek, Italian, Spanish, Swedish, Turkish
•
East1: Czech, English, Estonian, Lettish, Rumanian, Russian, Ukrainian
•
East2: Czech, Hungarian, Lettish, Polish, Rumanian
Teletext Teletext display mode (FLOF / List) (p. 16)
Shipping Condition Resets all settings, for example, when moving house (p. 25)
Input Labels Labels or skips each input terminals (p. 26)
Banner Display
Timeout
Sets how long the information banner (p. 13) stays on screen
•
0 (No display) to 10 sec. in 1-sec. increments
VIERA Link Sets to use VIERA Link functions (Off / On) (p. 30)
Software License Displays the software licence information
System Information Displays the system information of this TV
20
21
■
Menu list
•How to Use Menu Functions
(picture, sound quality, etc.)
How to Use Menu Functions
■
Menu list
•
A different menu will be displayed while PC is used. (p. 27)
•
Only available items can be selected.

Advanced
Main Menu
VIERA Link
Sound
Setup
1/2
Q-Link Settings
Child Lock
Teletext
Shipping Condition
Input Labels
Banner Display Timeout 3 seconds
FLOF
Tuning Menu
Off Timer Off
Language
Access
Setup Menu
PROGRAMME
REC VCR DVD
TEXT F.P. INDEX HOLD
OPTION DIRECT TV REC
ASPECT
RETURN
INPUT
VCR
132
465
798
0
EXIT
MENU
OK
Access
Tuning Menu
Auto Setup Access
Programme Edit Access
Manual Tuning Access
MENU
22
23
Editing and Setting Channels
The current channel settings can be changed according to your needs and reception conditions.
•Editing and Setting Channels
Select “Setup”
2
Select “Tuning Menu”
3
Display the menu
Select a function
4
■
To return to TV
EXIT
1
Set
channels
manually
Manual
Tuning
Fine Tuning
Programme 1 [CH33]
Manual Tuning
Manual Tuning 2 78 411
■
Fine Tuning
Use to make small adjustments to the tuning of an individual channel (affected by weather
conditions, etc.)
■
Manual Tuning
Set channel manually after Auto Setup.
If a VCR is connected with only the RF cable, select programme position “0”.
Set
5
Set channels
automatically
Auto Setup
EXIT
RETURN
Start Auto Setup
All tuning data will be erased
Auto Setup
Start Auto Setup
Automatically set the channels received in the area.
If a Child Lock PIN number (p. 24) has been set, it must be entered.
•
All previous settings are erased.
•
The settings are downloaded to a Q-Link compatible equipment connected to the TV.
•
When the operation is completed, the broadcast of programme number “1” will appear.
•
If tuning has not done completely “Manual Tuning”
Auto Setup
This will take about 3 mins.
Scan 214178
CH 29
Channel Service Name
CH 33
Settings are made automatically
For Auto Setup, using the buttons on the top of the TV
Press repeatedly until “Auto Setup” appears
F
Access “Auto Setup”
TV
Start “Auto Setup”
TV
■
To return to TV
F
FTV AV
select
access
select
access
select
access
3 FTP
Corontation Street
CH05 SC1 PAL
Edit
channels
■
Delete
■
Add
■
Move
■
Change
name
■
Change
sound
system
■
Change
colour
system
Programme
Edit
Programme Edit
1 CH33
2 CH21
3 CH21
4 CH60
5 CH21
Prog. Chan. Name
1 2 3
X Y Z
F T P
4 5 6
SC1 Auto
SC1 Auto
SC1 Auto
SC1 Auto
SC1 Auto
Sound Sys. Colour Sys.
■
To change sound system based on signals
Select the
“Sound Sys.” field
Select
sound system
SC1 : PAL B, G, H / SECAM B, G
SC2 : PAL I
SC3 : PAL D, K / SECAM D, K
F : SECAM L / L’
Programme Edit
1 CH33
2 CH21
3 CH21
4 CH60
5 CH21
Prog. Chan. Name
1 2 3
X Y Z
F T P
4 5 6
SC1 Auto
SC1 Auto
SC1 Auto
SC1 Auto
SC1 Auto
Sound Sys. Colour Sys.
Programme Edit
1 CH33
2 CH21
3 CH21
4 CH60
5 CH21
Prog. Chan. Name
1 2 3
X Y Z
F T P
4 5 6
SC1 Auto
SC1 Auto
SC1 Auto
SC1 Auto
SC1 Auto
Sound Sys. Colour Sys.
■
To change the name of the broadcaster displayed when selecting channels
Cursor
Select the channel to edit
Edit
■
To delete
red
After confirming, press
red
■
To add
green
After confirming, press
green
■
To move
yellow
Select new
position
yellow
Edit the programme position settings
Programme Edit
1 CH33
2 CH21
3 CH21
4 CH60
5 CH21
Prog. Chan. Name
1 2 3
X Y Z
F T P
4 5 6
SC1 Auto
SC1 Auto
SC1 Auto
SC1 Auto
SC1 Auto
Sound Sys. Colour Sys.
Select the “Colour Sys.” field
Select colour system
■
To change colour system based on signal
•
Normally, select “Auto”
select
Channel
Name
red
Select the “Name” field
Enter the “User Input” mode
Select the character
(Maximum: five characters)
Set
Select the channelSelect the programme position
VCR
132
465
798
0
store
search
Search and store
•
To change channel number
“Manual Tuning”

Advanced
Main Menu
VIERA Link
Sound
Setup
1/2
Q-Link Settings
Child Lock Access
Tuning Menu
Off Timer Off
Language
Teletext
Shipping Condition
Input Labels
Banner Display Timeout 3 seconds
FLOF
Setup Menu
PROGRAMME
REC VCR DVD
TEXT F.P. INDEX HOLD
OPTION DIRECT TV REC
ASPECT
INPUT
RETURN
EXIT
MENU
OK
VCR
132
465
798
0
Main Menu
VIERA Link
Sound
Setup
1/2
Q-Link Settings
Child Lock
Tuning Menu
Off Timer Off
Language
Teletext
Shipping Condition Access
Input Labels
Banner Display Timeout 3 seconds
FLOF
Setup Menu
ASPECT
INPUT
RETURN
VCR
132
465
798
0
OPTION DIRECT TV REC
PROGRAMME
REC VCR DVD
TEXT F.P. INDEX HOLD
EXIT
MENU
OK
MENU
MENU
24
25
Control Channel Audience
Select “Setup”
Select “Child Lock”
3
2
Display the menu
4Set
You can lock specific channels and control who watches them.
(When a channel is selected, a message appears; by entering the PIN number, you can watch the
channel.)
■
To return to TV
EXIT
1
3
2
4
Select “Setup”
Select “Shipping Condition”
Display the menu
Set
■
To return to TV
EXIT
Restore Settings
Shipping
Condition
Restore
Settings
Resets the TV to its original condition, i.e. no channels tuned in.
All settings (channels, picture, sound quality, etc.) are reset.
1
Check the message and initialise
Follow the on-screen instructions
•
“Auto Setup” will automatically start. (p. 10)
■
To re-tune TV channels only, e.g. after moving house
“Auto Setup” (p. 22)
EXIT
RETURN
Confirm
All tuning data will be erased
Are you sure?
Are you sure?
Shipping Condition
set
•Restore Settings
•Control Channel Audience
select
access
select
access
select
access
select
access
Control
channel
audience
1 of 2Child Lock-PIN Entry
Please enter new PIN
PIN * * * *
Child Lock
Service List
Change PIN
Access
Wed 12/05/04 10:46Child Lock Service List
BBC One Wales1
BBC THREE7
E414
CBBC Channel70
Cartoon Nwk72
BBCi80
BBC Radio Wales85
BBC Radio Cymru90
Service Name Lock
VCR
132
465
798
0
■
To change the PIN number
Select “Change PIN” in and enter a new PIN number twice.
Appears when the channel is locked
Enter the PIN number (4 digits)
Select “Service List”
•
To cancel
Select the locked channel
•
To lock all channels
yellow
•
To cancel all channel locks
blue
Select the channel to be locked
Note
•
Setting “Shipping Condition” (p. 25) erases the PIN number and all settings.
•
Enter the PIN number twice at first
setting.
•
Make a note of the PIN number in
case you forget it.
access
select
set
select
Child Lock

Advanced
Menu Item Adjustments / Configurations (options)
Advanced
PC
Settings
R-Gain Adjusts the white balance for red areas
G-Gain Adjusts the white balance for green areas
B-Gain Adjusts the white balance for blue areas
Gamma (2.0 / 2.2 / 2.5)
Setup
PC
Setup
Input
Resolution
Switches to a wide view
•
VGA (640 × 480 pixels), WVGA (852 × 480 pixels),
XGA (1,024 × 768 pixels), WXGA (1,366 × 768 pixels)
•
Options change depending on signals
Clock Set to the minimum level if noise occurs
H-pos
Adjusts horizontal position
V-pos
Adjusts vertical position
Clock Phase Eliminates flicker and distortion
•
Adjust after Clock adjustment • Set to the minimum level if noise occurs
Sync
Chooses another synchronous signal if the image is distorted (H & V / On G)
•
H & V : by the horizontal and vertical signals from your PC
On G : by the green signal from your PC (if available)
ASPECT
RETURN
EXIT
MENU
OPTION DIRECT TV REC
VCR
132
465
798
0
INPUT
OK
Input Selection
AV1
AV2/AV2S
AV3/AV3S
COMPONENT
PC
HDMI1
HDMI2
TV
Main Menu
VIERA Link
Sound
Setup
1/2
Q-Link Settings
Child Lock
Tuning Menu
Off Timer Off
Language
Teletext
Shipping Condition
Input Labels
Banner Display Timeout 3 seconds
FLOF
Access
Setup Menu
ASPECT
INPUT
RETURN
PROGRAMME
OPTION DIRECT TV REC
VCR
132
465
798
0
REC VCR DVD
TEXT F.P. INDEX HOLD
TV
EXIT
MENU
OK
1 of 2Input Labels
AV1 DVD
AV2/AV2S AV2/AV2S
AV3/AV3S AV3/AV3S
COMPONENT COMPONENT
PC PC
HDMI1 HDMI1
HDMI2 HDMI2
MENU
26
27
•Displaying PC Screen on TV
•Input Labels
■
To return to TV
Displaying PC Screen on TV
Select the external input
Select “PC”
2
The screen of the PC connected to the TV can be displayed on the TV.
You can also listen to PC sound with the audio cable connected. To connect PC (p. 32)
•
Corresponding signals (p. 36)
•
If “H-freq.” or “V-freq.” is shown in red,
the signals may not be supported.
■
PC menu setting (changed as desired)
•
To make settings “How to Use Menu Functions” to (p. 18)
•
Other items p. 20 and p. 21
1
Input Labels
2
3
4
Select “Setup”
Select “Input Labels”
Display the menu
Select a input terminal and set
■
To return to TV
EXIT
For easier identification and selection of the input mode, you can label each input terminals or skip
terminal that is not connected to any equipment.
(To select the input mode p. 14)
1
The labels you set will be displayed in “Input Selection” menu (p. 14) or banner.
•
If “Skip” is selected, you cannot select the mode.
access
select
store
select
select
access
select
access
select
set
select
access
1 of 2User Input
AV1
ABCDEFGH I JKLMN
UVWXYZ 0123456
abcde f gh i j k lmn
uvwxyz( )+- . *_
OPQRST
789! : #
opq r s t
■
User Input
You can name each input terminals freely.
Select “User Input” Set characters
(maximum: ten characters)

Advanced
Connection
Function VIERA Link and Q-Link VIERA Link only Q-Link only
Easy playback
OOO
Power on link OOO
Power off link OOO
Speaker control
O
(not via SCART)
O
-
Easy control only with
VIERA remote control
O
(not via SCART)
O
-
Direct TV Recording
O
(not via HDMI)
-
O
Channel download
O
(not via HDMI)
-
O
(HDMI) (SCART) (HDMI) (SCART)
28
29
•HDMI Functions
•Q-Link Functions
Q-Link Functions
Q-Link connects the TV and VCR / DVD recorder, enables easy recording and playback.
■
Condition
■
Features available
Some recording equipments are not applicable. Read the manuals of the equipment.
Information
/ Message
Recording information or if recording is not possible, a message is displayed.
(Only when the programme number is “0” or “AV mode” for some equipment.)
Power
on link
and Easy
playback
When VCR or DVD recorder starts playback or direct navigator / function menu
for the equipment are activated, the TV is turned on and input mode is switched
automatically so that you can view the content. (Only when TV is in Standby mode.)
Power off
link
When TV is set to Standby mode, the recording equipment is also automatically
set to Standby. (Only when the videocassette or DVD is not active.)
•
Use the VCR / DVD recorder with the following logos:
“Q-Link”, “NEXTVIEWLINK”, “DATA LOGIC”, “Easy Link”, “Megalogic”, or “SMARTLINK”
•
Connect the equipment to this TV’s AV1 or AV2 terminal via a “fully-wired” SCART cable. (p. 32)
•
Q-Link terminal setup in Setup menu (Q-Link, AV1 / AV2 out). (p. 21)
What you
see is
What you
record
OPTION
132
465
798
0
VCR
INPUT
ASPECT
RETURN MENU
OK
EXIT
DIRECT TV REC
Direct TV Recording:
Recording the current programme in VCR / DVD recorder
immediately.
•
When Direct TV Recording is performed, the
recording equipment is automatically turned on if it
is in Standby mode.
•
The recording equipment is recording from its own
tuner. You can turn the TV off during recording.
•
If you turn the TV off during recording from an AV
source, the recording will be stopped.
• “DATA LOGIC” (a trademark of Metz Corporation) • “Megalogic” (a trademark of Grundig Corporation)
• “Easy Link” (a trademark of Philips Corporation) • “SMARTLINK” (a trademark of Sony Corporation)
Read the manuals of the equipment too.
■
Download channel settings
•
Perform Auto Setup. (p. 22)
When first using this TV, see “Auto Setup”. (p. 10)
•
Perform download to the equipment. (p. 21)
(∗1): The HDMI logo is displayed on HDMI-compliant equipment.
(∗2): Enquire at your local digital equipment retailer shop.
HDMI (high-definition multimedia interface) allows you to enjoy high-definition digital images and high-
quality sound by connecting the TV and the equipment.
HDMI-compatible equipment (∗1) with an HDMI or DVI output terminal, such as a set top box or a DVD
player, can be connected to the HDMI terminal using an HDMI compliant (fully wired) cable.
About connections, see “External Equipment” (p. 32).
Note
•
HDMI is the world’s first complete digital consumer AV interface complying with a non-compression standard.
•
If the external equipment has only a DVI output, connect to the HDMI1 terminal via a DVI to HDMI adapter cable (
∗
2).
•
When the DVI to HDMI adapter cable is used, connect the audio cable to the audio input terminal (HDMI1: use
COMPONENT-AUDIO terminals).
•
Audio settings can be made on the “HDMI1 Input” menu screen. (p. 20)
•
Applicable audio signal sampling frequencies (2ch L.PCM): 48 kHz, 44.1 kHz, 32 kHz
•
HDMI2 terminal is for digital audio signal only.
•
Use with a PC is not assumed.
•
If the connected equipment has an aspect adjustment function, set the aspect ratio to “16:9”.
•
These HDMI connectors are “type A”.
•
These HDMI connectors are compatible with HDCP (High-Bandwidth Digital Content Protection) copyright
protection.
•
An equipment having no digital output terminal may be connected to the input terminal of either “Component”,
“S-VIDEO”, or “Video” to receive analogue signals.
•
The HDMI input terminal can be used with only the following image signals:
480i, 480p, 576i, 576p, 720p, 1080i and 1080p. Match the output setting of the digital equipment.
•
For details of the applicable HDMI signals, see p. 36.
HDMI Functions
■
Summary of Control functions
Connecting with an HDMI cable to Panasonic equipment with VIERA Link function, you can control the equipment
(p. 30). You can use VIERA Link and Q-Link functions together.
DIRECT TV REC

Advanced
•HDMI Functions
Off
Setup Menu 2/2
VIERA Link
System Information
Software License
On
132
465
798
0
REC
VCR
DIRECT TV REC
ASPECT
INPUT
TEXT F.P. INDEX HOLD
PROGRAMME
VCR DVD
RETURN
EXIT
MENU
OK
OPTION
MENU
30
31
∗Enjoy additional HDMI Inter-Operability with Panasonic products which have “HDAVI Control” function.
This TV supports “HDAVI Control 2” function.
Connections to some Panasonic equipment (DVD Recorder DIGA, HD Video Camera, Player theatre,
Amplifier, etc.) with HDMI cables allow you to interface them automatically.
The equipment with “HDAVI Control” function enables the following operations:
•
Easy playback (p. 31)
•
Power on link (p. 31)
•
Power off link (p. 31)
•
Speaker control (p. 31)
In addition, the equipment with “HDAVI Control 2” function enables the following operation:
•
Easy control only with VIERA remote control (p. 31)
These features are limited to models incorporating Panasonic’s “HDAVI Control” and “VIERA Link”.
VIERA Link “HDAVI Control”, based on the control functions provided by HDMI which is an industry
standard known as HDMI CEC (Consumer Electronics Control), is a unique function that we have
developed and added. As such, its operation with other manufacturers’ equipment that supports HDMI
CEC cannot be guaranteed.
Refer to individual manuals for compatibility information. About applicable equipment, consult your local
Panasonic dealer.
VIERA Link “ ControlTM”∗
HDMI Functions
■
HDMI cable
This function needs an HDMI compliant (fully wired) cable. Non-HDMI-compliant cables cannot be utilized.
It is recommended that you use Panasonic’s HDMI cable. Recommended part number:
•RP-CDHG15 (1.5 m)
•RP-CDHG30 (3.0 m)
•RP-CDHG50 (5.0 m)
Easy
playback
Automatic Input switching-When the connected Panasonic equipment is operated, input
mode is switched automatically. When it is stopped operating, input mode is returned.
Power on
link
When the connected Panasonic equipment starts playback or direct navigator /
function menu for the equipment are activated, the TV is automatically turned on.
(Only when TV is in Standby mode.)
Power off
link
When TV is set to Standby mode, the connected Panasonic equipment is also
automatically set to Standby.
•
This function will work even if the TV enters standby mode automatically by Off Timer
function or auto power standby function.
■
Preparations
Setup the equipment to enable this function. Read the manuals of the equipment.
About connections, see “External Equipment” (p. 33). Read the manuals of the equipment too.
Speaker
control
You can control the theatre speaker with TV’s remote control.
This function is available when Panasonic Amplifier or Player theatre is connected.
•
If you cannot access the menu, check the
settings and the equipment (p. 30).
■
TV
TV speakers are active.
■
Home Cinema
Adjustment for equipment
(automatically turned on if it is in
Standby mode).
Volume up / down
Mute
•
The sound of TV speakers is mute.
•
When the equipment is turned off,
TV speakers will be active.
Easy
control
only with
VIERA
remote
control
You can control some functions of the
connected Panasonic equipment with
this TV remote control (point the remote
control at the TV’s signal receiver).
•
If you cannot access the menu, check the
settings and the equipment (p. 30).
•
Example:
•
About the operations for the equipment, read the manual of the equipment.
DVD Recorder DIGA HD Video Camera Player theatre
HDD
FUNCTION MENU
Playback
Recording
Delete
Copy
To Others
ALL
DATE/TIME 2006.12. 1 10:46
8 / 8
Listen
Start
Watch
Import/Record
Setup
Move the cursor / select the
menu
Move the cursor / access /
adjust
Store / Set / Access
RETURN
Return to the previous
menu
EXIT
Exit the menu
OPTION
The same functions with
the OPTION button of the
equipment
red green yellow blue
Access when the key words
are displayed on colour bar
•
Available VIERA remote control buttons:
(depending on the connected equipment)
select
Display “VIERA Link Menu”
Select “Speaker Selection”
Set to “Home Cinema” or
“TV”
set
VIERA Link Control
Speaker Selection
VIERA Link Menu
Home Cinema
Recorder
Access the menu of the equipment
Display “VIERA Link Menu”
Select the
equipment you
want to access access
select
Operate the menu of the equipment
VIERA Link Control
Speaker Selection
VIERA Link Menu
Home Cinema
Recorder
Select “VIERA Link Control”
select
Set to “On”
(default is On)
Select “Setup”
Select “VIERA Link”
2
1
3
Display the menu
4
■
For the first time / When adding new equipment, reconnecting equipment or changing setup
After connection turn the equipment on and then switch the TV on.
Select the input mode to HDMI1 or HDMI2 (p. 14), and make sure that an image is displayed
correctly.
Main Menu
VIERA Link
Sound
Setup
select
access
select
set

Advanced
•External Equipment
Connector
Recording / Playback
(equipment)
AV1 AV2 AV3
COMPONENT
Y
PB
PR
L
R
AUDIO OUT
(Side of TV)
12
To record / playback videocassettes / DVDs
(VCR / DVD recorder)
To watch DVDs (DVD player)
To watch camcorder images (Video camera)
To watch satellite broadcasts (Set top box)
To play games (Game equipment)
To use amplifier with speaker system
Q-Link
Direct TV Recording
VIERA Link
VIDEO
RGB
S VIDEO
VIDEO
RGB
AV2AV1
L
R
Y
PB
PR
PC
AUDIO OUT
V
I
D
E
O
A
U
D
I
O
C
O
M
P
O
N
E
N
T
L
R
HDMI 1 HDMI 2
32
33
These diagrams show our recommendations for how to connect the TV to your various equipment.
For other connections, consult the instructions for each piece of equipment, the table below, and the
specifications (p. 39).
(VIDEO)
or
(S-VIDEO)
(AUDIO)
: Recommended Connection
Headphones
Camcorder / Game equipment
■Types of connectable equipment to each connector
External Equipment
■
To adjust volume
“Headphone
Volume” in the
Sound Menu
(p. 20)
(M3 stereo
mini plug)
Computer
Amplifier with speaker system
PC
(Viewing)
(Listening)
To listen with speakers
Conversion adapter
(if necessary)
Set top box DVD Recorder / VCR
SCART
cable
RF cable
SCART cable
To watch satellite broadcasts To record / playback
To watch DVDs
DVD player
SCART
cable
(Viewing)
(Listening)
■
Easy playback, Easy control
only with VIERA remote control
■
Home Cinema
Panasonic DVD Recorder,
HD Video Camera, etc.
Panasonic
Amplifier
Panasonic DVD Recorder
Speaker system
Panasonic
Player theatre
HD Video Camera
•
Use fully wired HDMI compliant cable.
•
Read the manuals of the equipment too.
or
VIERA Link (p. 30)
Speaker system
Fully wired HDMI
compliant cable
This slot is for services
by the Panasonic dealer.

FAQs, etc.
•Technical Information
Signal name
Aspect modes
Aspect Control Signal
Widescreen signal (WSS)
Control signal through SCART
(pin 8) or HDMI terminal
Auto 16:9 14:9 Just 4:3
4:3
Full Zoom1 Zoom2 Zoom3
TV AV1 AV2 AV3 Component AV1 AV2 HDMI
1
HDMI
2
TV/AV1/AV2/AV3
PAL OOOOO
-
OOOOOOO
-
OO
--
PAL 525/60 OOOOO
-
OOO
---- -
OO
--
M.NTSC OOOOO
-
OOO
---- -
OO
--
NTSC(AV input only) OOOOO
-
OOO
---- -
OO
--
Component/HDMI
SD
525(480)/60i OOOOO
-
OOO
---- - - -
OO
525(480)/60p OOOOO
-
OOO
---- - - -
OO
625(576)/50i OOOOO
-
OOO
----
O
--
OO
625(576)/50p OOOOO
-
OOO
----
O
--
OO
HD
750(720)/50p OOOOOO O O O
---- - - -
OO
750(720)/60p OOOOOO O O O
---- - - -
OO
1125(1080)/50i OOOOOO O O O
---- - - -
OO
1125(1080)/60i OOOOOO O O O
---- - - -
OO
1125(1080)/50p OOOOOO O O O
---- - - -
OO
1125(1080)/60p OOOOOO O O O
---- - - -
OO
PC input
-
O
--
O
- - - - ---- - - - - -
34
35
Technical Information
Aspect Ratio
Note
•
The ratio varies depending on the programme, etc. If the ratio is greater than the standard “16:9”, black bands
may appear at the top and bottom of the screen.
•
If the screen size looks unusual when a widescreen-recorded programme is played back on a VCR, adjust the
tracking of the VCR. (See the VCR manual.)
•
Aspect mode can be memorized for SD (Standard definition) and HD (High definition) signals separately.
•
To select the ratio manually: (Only “16:9” or “4:3” in PC mode)
The optimum size and aspect can be chosen, and you can enjoy finer images. (p. 13)
■
Auto: Auto aspect determines the best aspect ratio to use to fill your screen. It does this using a four step process
to determine if the picture being viewed is a widescreen picture.
Just
14:916:9
Zoom3Zoom2Zoom1
Directly displays
the image at
“16:9” without
distortion
(anamorphic).
Displays a “16:9”
letterbox or “4:3”
image without
distortion.
Displays the image
at the standard
“14:9” without
enlargement.
Displays a
“16:9” letterbox
(anamorphic)
image full-screen
without distortion.
Displays a 4:3
image full-screen.
Stretching is only
noticeable at
the left and right
edges.
Displays a
“2.35:1” letterbox
(anamorphic)
image full-screen
without distortion.
At “16:9”, displays
the image at its
maximum (with
slight enlargement).
Auto
The best ratio is
chosen and the
picture expanded
to fill the screen.
If Auto aspect detects a widescreen signal it switches into the appropriate 16:9 or 14:9 widescreen mode. If Auto aspect
does not detect a widescreen signal then this advanced TV enhances the picture for optimum viewing pleasure.
The text shown on the screen indicates how Auto aspect determined which ratio to use:
“WIDE” appears in the top left of the screen if a widescreen identification signal (WSS) is found or a signal found
through a SCART terminal. Auto aspect switches to the appropriate 16:9 or 14:9 widescreen ratio. This function
will also work in any aspect mode. “Auto” appears in the top left of the screen if black stripes above and below
the picture are detected. Auto aspect chooses the best ratio and expands the picture to fill the screen. This
process can take several minutes, depending on the darkness of the picture.
•
This function may not work normally depending on the equipment condition.
•
Image or sound may not be available for the first few seconds when the playback starts.
•
Image or sound may not be available for the first few seconds when Input mode is switched.
•
Volume function will be displayed when adjusting the volume of the equipment.
•
Easy playback is also available by using the remote control for Amplifier or Player theatre. Read the manuals of
the equipment.
•
If you connect the same kind of equipment at once (for example: one DIGA to HDMI1 / another DIGA to HDMI2),
VIERA Link is available for the terminal with the smaller number.
•
“HDAVI Control 2” is the newest standard (current as of February, 2007) for Panasonic’s HDAVI Control
compatible equipment. This standard is compatible with Panasonic’s conventional HDAVI equipment.
HDMI connections to some Panasonic equipment allow you to interface them automatically. (p. 30)
VIERA Link “ ControlTM”
4:3 Full
Displays a “4:3”
image enlarged
horizontally to fit
the screen.
4:3
Displays the
image at the
standard “4:3”
without distortion.
SCART, S-VIDEO and HDMI terminal information
Socket Earth
CVBS out (video)
CVBS earth
Red in
Red earth
Green in
Green earth
Blue in
Blue earth
Audio out (L)
Audio out (R)
CVBS in (video)
RGB status earth
Status RGB
Earth
--
Q-Link data
Status CVBS
Audio in (L)
Audio earth
Audio in (R)
21
19
17
15
13
11
9
7
5
3
1
20
18
16
14
12
10
8
6
4
2
■
AV1 SCART terminal
(RGB, VIDEO, Q-Link)
Suitable inputs for AV1 include RGB (Red / Green / Blue).
Chrominance in
Socket Earth
CVBS out (video)
CVBS earth
Red in, S.C. - in
Red earth
Green in
Green earth
Blue in
Blue earth
Audio out (L)
Audio out (R)
CVBS in (video)
RGB status earth
Status RGB
Earth
--
Q-Link data
Status CVBS
Audio in (L)
Audio earth
Audio in (R)
21
19
17
15
13
11
9
7
5
3
1
20
18
16
14
12
10
8
6
4
2
Luminance in
Chrominance earth Luminance earth
■
AV3 S-VIDEO 4 pin terminal
■
AV2 SCART terminal
(RGB, VIDEO, S-VIDEO, Q-Link)
AV2 - Pins 15 and 20 are dependent on AV2 S-VHS /
VIDEO switching.
Hot Plug Detect
DDC/CEC Ground
SCL
CEC
TMDS Clock Shield
TMDS Data0−
TMDS Data0+
TMDS Data1 Shield
TMDS Data2−
TMDS Data2+
+5V Power
SDA
Reserved (in cable but N.C. on device)
TMDS Clock−
TMDS Clock+
TMDS Data0 Shield
TMDS Data1−
TMDS Data1+
TMDS Data2 Shield
19
17
15
13
11
9
7
5
3
1
18
16
14
12
10
8
6
4
2
■
HDMI terminal

FAQs, etc.
•Frequently Asked Questions
•Technical Information
36
37
Technical Information
Input signal that can be displayed
Note •
Signals other than above may not be displayed properly.
•
The above signals are reformatted for optimal viewing on your display.
•
Applicable input signal for PC is basically compatible to VESA standard timing.
•
PC signal is magnified or compressed for display, so that it may not be possible to show fine detail
with sufficient clarity.
Signal name COMPONENT HDMI
525 (480) / 60i ∗∗
525 (480) / 60p ∗∗
625 (576) / 50i ∗∗
625 (576) / 50p ∗∗
750 (720) / 60p ∗∗
750 (720) / 50p ∗∗
1,125 (1,080) / 60i ∗∗
1,125 (1,080) / 50i ∗∗
1,125 (1,080) / 60p ∗
1,125 (1,080) / 50p ∗
Signal name Horizontal frequency (kHz) Vertical frequency (Hz)
640 × 400 @70 Hz 31.47 70.07
640 × 480 @60 Hz 31.47 59.94
640 × 480 @75 Hz 37.50 75.00
800 × 600 @60 Hz 37.88 60.32
800 × 600 @75 Hz 46.88 75.00
800 × 600 @85 Hz 53.67 85.06
852 × 480 @60 Hz 31.44 59.89
1,024 × 768 @60 Hz 48.36 60.00
1,024 × 768 @70 Hz 56.48 70.07
1,024 × 768 @75 Hz 60.02 75.03
1,024 × 768 @85 Hz 68.68 85.00
1,280 × 1,024 @60 Hz 63.98 60.02
1,366 × 768 @60 Hz 48.39 60.04
Macintosh13” (640 × 480) 35.00 66.67
Macintosh16” (832 × 624) 49.73 74.55
Macintosh21” (1,152 × 870) 68.68 75.06
∗Mark: Applicable input signal
COMPONENT (Y, PB, PR), HDMI
PC (D-sub 15P)
Pin No. Signal Name Pin No. Signal Name Pin No. Signal Name
R GND (Ground) NC (not connected)
G GND (Ground) NC (not connected)
B GND (Ground) HD
NC (not connected) NC (not connected) VD
GND (Ground) GND (Ground) NC (not connected)
1
678
3
9
45
10
15 14 13 12 11
2
PC connection
A PC may be connected to this TV so that the PC screen is displayed and sound is heard from the TV.
•
PC signals that can be inputted: Horizontal scanning frequency 31 to 69 kHz; vertical scanning frequency
59 to 86 Hz (more than 1,024 signal lines could result in incorrect display of the image).
•
A PC adapter is not necessary for the DOS/V-compliant D-sub 15-pin connector.
Note
•
Some PC models cannot be connected to this TV.
•
When using PC, set the colour display quality of PC to the highest position.
•
For details of the applicable PC signals, see below.
•
Max. display resolution
•
D-sub 15-pin connector signal
Aspect 4:3 1,024 × 768 pixels
16:9 1,366 × 768 pixels
FAQs
Before requesting service or assistance, please follow these simple guides to resolve the problem.
If problem still persists, please contact your local Panasonic dealer for assistance.
White spots or shadow
images (noise)
•Check the position, direction, and
connection of the aerial.
Neither image nor
sound is produced
•
Is the TV in “AV mode”?
•
Is the mains lead plugged into the socket
outlet?
•
Is the TV turned On?
•
Check Picture Menu (p. 20) and volume.
•
Check all required SCART cables and
connections are firmly in place.
Auto aspect
•
Auto aspect is designed to provide you
with the best aspect ratio to use to fill your
screen. For user control please see p. 34.
S-Video / black and
white picture
•
Using AV button please confirm your
selection is S-Video I.e. AV2/AV2S
(p. 14).
On Screen messages
- I.e. EC/AV1
•
You can simply clear these by pressing
the button .
Press again to redisplay.
Direct TV record / Q-Link
functions not recording
•
Please confirm SCART cable and connection. Also
please set “AV1 / AV2 out” in the Setup Menu (p. 21).
There may be red spots, blue
spots, green spots and black
spots on the screen
•
This is a characteristic of liquid crystal panels and is
not a problem. The liquid crystal panel is built with very
high precision technology giving you fine picture details.
Occasionally, a few non-active pixels may appear on the
screen as a fixed point of red, green, blue or black.
Please note this does not affect the performance of your
LCD.
The LCD panel moves slightly
when it is pushed with a finger
Clattered sound might be heard
•
There are some looseness around the panel to prevent
the damage to the panel.
The panel might move slightly when it is pushed with a
finger, and clattered sound might be heard. This is not a
malfunction.

FAQs, etc.
•Licence •Specifications
•Frequently Asked Questions
TX-26LX70P TX-32LX70P
Power Source AC 220-240 V, 50 / 60 Hz
Power Consumption
Average use 100 W 134 W
Standby condition 0.4 W
Display panel
Aspect Ratio 16:9
Visible screen size 66 cm (diagonal) 80 cm (diagonal)
575 mm (W) × 323 mm (H) 697 mm (W) × 392 mm (H)
Number of pixels 1,049,088 (1,366 (W) × 768 (H))
Sound
Speaker 120 mm × 60 mm × 2 pcs
Audio Output 20 W (10 W + 10 W)
Headphones M3 (3.5 mm) stereo mini Jack × 1
PC signals
VGA, SVGA, XGA
SXGA ······ (compressed)
Horizontal scanning frequency 31 - 69 kHz
Vertical scanning frequency 59 - 86 Hz
Receiving Systems /
Band name
PAL B, G, H, I, SECAM B, G, SECAM L / L’
VHF E2 - E12 VHF H1 - H2 (ITALY)
VHF A - H (ITALY) UHF E21 - E69
CATV (S01 - S05) CATV S1 - S10 (M1 - M10)
CATV S11 - S20 (U1 - U10) CATV S21 - S41 (Hyperband)
PAL D, K, SECAM D, K
VHF R1 - R2 VHF R3 - R5
VHF R6 - R12 UHF E21 - E69
PAL 525/60 Playback of NTSC tape from some PAL Video recorders (VCR)
M.NTSC Playback from M. NTSC Video recorders (VCR)
NTSC (AV input only) Playback from NTSC Video recorders (VCR)
Aerial - Rear VHF / UHF
Operating Conditions Temperature : 0 °C - 35 °C
Humidity : 20 % - 80 % RH (non-condensing)
Connection Terminals
AV1 (Scart terminal) 21 Pin terminal (Audio/Video in, Audio/Video out, RGB in, Q-Link)
AV2 (Scart terminal) 21 Pin terminal (Audio/Video in, Audio/Video out, RGB in, S-Video in, Q-Link)
AV3
VIDEO RCA PIN Type × 1 1.0 V[p-p] (75 Ω)
S-VIDEO Mini DIN 4-pin Y:1.0 V[p-p] (75 Ω) C:0.286 V[p-p] (75 Ω)
AUDIO L - R RCA PIN Type × 2 0.5 V[rms]
COMPONENT
VIDEO Y1.0 V[p-p] (including synchronization)
PB, PR±0.35 V[p-p]
AUDIO L - R RCA PIN Type × 2 0.5 V[rms]
Others
HDMI1 / 2 TYPE A Connectors
PC HIGH-DENSITY D-SUB 15PIN R,G,B/0.7 V[p-p] (75 Ω)
HD, VD/TTL Level 2.0 - 5.0 V[p-p] (high impedance)
Output AUDIO L - R RCA PIN Type × 2 0.5 V[rms] (high impedance)
Dimensions ( W × H × D ) 657 mm × 525 mm × 216 mm (With TV Stand)
657 mm × 473 mm × 117 mm (TV only)
791 mm × 615 mm × 248 mm (With TV Stand)
791 mm × 563 mm × 117 mm (TV only)
Mass 14.0 k Net 17.5 k Net
38
39
Problem Actions
Screen Sound HDMI
Chaotic image, noisy •
Set “P-NR” in the Picture Menu (to remove noise). (p. 20)
•
Check nearby electrical products
(car, motorcycle, fluorescent lamp).
No image can be
displayed •
Is “Colour” or “Contrast” in the Picture Menu set to the minimum?
(p. 20)
•
Check Colour system. (p. 23)
Blurry or distorted image
(no sound or low volume) •
Reset channels. (p. 22)
No sound is produced •
Is “Sound mute” active? (p. 7)
•
Is the volume set to the minimum?
Sound level is low
or sound is distorted •
Sound signal reception may be deteriorated.
•
Set “MPX” (p. 20) in the Sound Menu to “Mono”.
•
Check Sound system. (p. 23)
Sound is unusual •
Set the sound setting of the connected equipment to
“2ch L.PCM”.
•
Check the “HDMI1 Input” setting in the Sound Menu. (p. 20)
•
If digital sound connection has a problem, select analogue sound
connection. (p. 29)
Pictures from external
equipment are unusual
when the equipment is
connected via HDMI
•
Is the HDMI cable connected properly? (p. 32)
•
Turn Off the TV and equipment, then turn them On again.
•
Check an input signal from the equipment. (p. 36)
•
Use an equipment compliant with EIA/CEA-861/861B.
Unusual image is displayed •
Turn off the TV with Mains power On / Off switch, then turn it on
again.
TV goes into
“Standby mode” •
Off Timer function is activated.
•
The TV enters “Standby mode” about 30 min. after broadcasting
ends.
The remote control
does not work •
Are the batteries installed correctly? (p. 6)
•
Has the TV been switched On?
Other
An error message appears •
Follow the message’s instructions.
•
If the problem persists, contact the authorized Service Centre.
FAQs Licence
Trademark Credits
•
VGA is a trademark of International Business Machines Corporation.
•
Macintosh is a registered trademark of Apple Computer, USA.
•
S-VGA is a registered trademark of the Video Electronics Standard Association.
Even if no special notation has been made of company or product trademarks, these trademarks have been fully
respected.
•
HDMI, the HDMI Logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI
Licensing LLC.
•
HDAVI ControlTM is a trademark of Matsushita Electric Industrial Co., Ltd.
Specifications
Note
•
Design and Specifications are subject to change without notice. Weight and Dimensions shown are approximate.
•
This equipment complies with the EMC standards listed below.
EN55013, EN61000-3-2, EN61000-3-3, EN55020, EN55022, EN55024.
•
This TV supports “HDAVI Control 2” function.
