Service Manual
LCD Television
TX-40CS520E
TX-40CSR520
LA61 Chassis
© Panasonic Corporation 2015.
Unauthorized copying and
distribution is a violation of law.
ORDER No. PCZ1503011CE
There are special components used in this equipment which are important for safety. These parts are marked in the
Schematic Diagrams, Circuit Board Diagrams, Explorer Views and Replacement Parts List. It is essential that these
critical parts should be replaced with manufacturer´s specified parts to prevent shock, fire or other hazards. Do not
modify the original design without permission of manufacturer.
IMPORTANT SAFETY NOTICE
This service information is designed for experienced repair technicians only and is not designed for use by the general public. It does not
contain warnings or cautions to advise non-technical individuals of potencial dangers in attempting to service a product. Products
powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to service or repair the
product or products deal within this service information by anyone else could result in serious injury or death.
Warning

CONTENTS
SAFETY PRECAUTIONS........................................... 3
GENERAL GUIDE LINES...................................... 3
TOUCH – CURRENT CHECK............................... 3
PREVENTION OF ELECTROSTATIC DISCHARGE
(ESD) TO ELECTROSTATICALLY SENSITIVE (ES)
DEVICES.................................................................... 4
ABOUT LEAD FREE SOLDER (PBF)......................... 5
SUGGESTED PB FREE SOLDER........................ 5
SERVICE NAVIGATION............................................. 6
CHASSIS BOARD LAYOUT.................................. 6
SERVICE HINTS ........................................................ 7
APPLICABLE SIGNALS.............................................. 8
SPECIFICATIONS...................................................... 9
TECHNICAL DESCRIPTION ................................….11
SPECIFICATION OF KEY FOR DTCP-IP,
C2MOD, CI PLUS, DIMORA, HDCP2, NETFLIX,
WIDEVINE, FREETIME....................................... 11
GENERAL INFORMATION................................. 11
REPLACEMENT OF ICS..................................... 11
MODEL AND KEYS ............................................ 11
SETTING INSPECTION............................................ 12
SERVICE MODE FUNCTION................................... 13
SERVICE.................................................................. 14
SERVICE TOOL MODE............................................ 15
HOTEL MODE .......................................................... 16
DATA COPY BY USB MEMORY.............................. 17
DATA COPY FROM TV SET TO USB MEMORY..... 18
DATA COPY FROM USB MEMORY TO TV SET..... 19
OPTION BYTES DESCRIPTION.............................. 20
SELF CHECK ........................................................... 21
POWER LED BLINKING TIMING CHART................ 22
LCD PANEL TEST MODE........................................ 22
WIRING DIAGRAM................................................... 23
BLOCK DIAGRAM (1 OF 2)...................................... 24
PARTS LOCATION................................................... 26
LOCATION OF LEAD WIRING................................. 28
REPLACEMENT PARTS LIST NOTE....................... 29
REPLACEMENT PARTS LIST.................................. 30
SCHEMATIC DIAGRAMS NOTE.............................. 49
A-BOARD (1 OF 16) SCHEMATIC DIAGRAM.......... 50
P-BOARD (1 OF 4) SCHEMATIC DIAGRAM............ 66
K-BOARD SCHEMATIC DIAGRAM.......................... 70
CONDUCTOR VIEWS.............................................. 71
2

Safety Precautions
General Guide Lines
1. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated
or damaged by the short circuit.
2. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly
installed.
3. After servicing, make the following touch current checks to prevent the customer from being exposed to shock hazards.
Touch-Current Check
1. Plug the AC cord directly into the AC outlet. Do not use an isolation transformer for this check.
2. Connect a measuring network for touch currents between each exposed metallic part on the set and a good earth
ground such as a water pipe, as shown in Fig. 1.
3. Use Leakage Current Tester (Simpson 228 or equivalent) to measure the potential across the measuring network.
4. Check each exposed metallic part, and measure the voltage at each point.
5. Reserve the AC plug in the AC outlet and repeat each of the above measure.
6. The potential at any point (TOUCH CURRENT) expressed as voltage U1 and U2, does not exceed the following values:
For a. c.: U1 = 35 V (peak) and U2 = 0.35 V (peak);
For d. c.: U1 = 1.0 V,
Note:
The limit value of U2 = 0.35 V (peak) for a. c. and U1 = 1.0 V for d. c. correspond to the values 0.7 mA (peak) a. c. and
2.0 mA d. c.
The limit value U1 = 35 V (peak) for a. c. correspond to the value 70 mA (peak) a. c. for frequencies greater than 100
kHz.
7. In case a measurement is out of the limits specified, there is a possibility of a shock hazard, and the equipment should
be repaired and rechecked before it is returned to the customer.
Fig. 1
TO
APPLIANCES
EXPOSED
METAL PARTS
Resistance values in ohms ()
V
R0=500

RS=1500

CS=0.22

F
10k

0.022

F
COLD
WATER PIPE
(EARTH GROUND)
V: Voltmeter or oscilloscope
(r.m.s. or peak reading)
Measuring network for TOUCH CURRENTS
Input resistance: 1M

Input capacitance:200pF
Frequency range: 15Hz to 1MHz and d.c.respectively
U2(V)
U1(V)
3

Prevention of Electrostatic Discharge (ESD) to Electrostatically
Sensitive (ES) Devices
Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are
called Electrostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect
transistors and semiconductor "chip" components. The following techniques should be used to help reduce the incidence of
component damage caused by electrostatic discharge (ESD).
1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off any ESD on
your body by touching a known earth ground. Alternatively, obtain and wear a commercially available discharging ESD
wrist strap, which should be removed for potential shock reasons prior to applying power to the unit under test.
2. After removing an electrical assembly equipped with ES devices, place the assembly on a conductive surface such as
aluminum foil, to prevent electrostatic charge build up or exposure of the assembly.
3. Use only a grounded-tip soldering iron to solder or unsolder ES devices.
4. Use only an anti-static solder removal device. Some solder removal devices not classified as "anti-static (ESD
protected)" can generate electrical charge sufficient to damage ES devices.
5. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ES devices.
6. Do not remove a replacement ES device from its protective package until immediately before you are ready to install it.
(Most replacement ES devices are packaged with leads electrically shorted together by conductive foam, aluminum foil
or comparable conductive material).
7. Immediately before removing the protective material from the leads of a replacement ES device, touch the protective
material to the chassis or circuit assembly into which the device will be installed.
Caution
Be sure no power is applied to the chassis or circuit, and observe all other safety precautions.
8. Minimize bodily motions when handling unpackaged replacement ES devices. (Otherwise harmless motion such as the
brushing together of your clothes fabric or the lifting of your foot from a carpeted floor can generate static electricity
(ESD) sufficient to damage an ES device).
There are special components used in this equipment which are important for safety.
These parts are marked by in schematic diagrams, exploded views and replacement parts list. It is essential that
these critical parts should be replaced with manufacturer’s specified parts to prevent shock, fire, or other hazards. Do
not modify the original design without permission of manufacturer.
IMPORTANT SAFETY NOTICE
4

About lead free solder (PbF)
Note: Lead is listed as (Pb) in the periodic table of elements.
In the information below, Pb will refer to Lead solder, and PbF will refer to Lead Free Solder.
The Lead Free Solder used in our manufacturing process and discussed below is (Sn+Ag+Cu).
That is Tin (Sn), Silver (Ag) and Copper (Cu) although other types are available.
This model uses Pb Free solder in it’s manufacture due to environmental conservation issues. For service and repair work,
we’d suggest the use of Pb free solder as well, although Pb solder may be used.
PCBs manufactured using lead free solder will have the PbF within a leaf Symbol
stamped on the back of PCB.
Caution
Pb free solder has a higher melting point than standard solder. Typically the melting point is 50 ~ 70 °F (30~40°C)
higher. Please use a high temperature soldering iron and set it to 700 ± 20 °F (370 ± 10 °C).
Pb free solder will tend to splash when heated too high (about 1100 °F or 600 °C).
If you must use Pb solder, please completely remove all of the Pb free solder on the pins or solder area before
applying Pb solder. If this is not practical, be sure to heat the Pb free solder until it melts, before applying Pb solder.
After applying PbF solder to double layered boards, please check the component side for excess solder which may
flow onto the opposite side. (see Fig.2)
Suggested Pb free solder
There are several kinds of Pb free solder available for purchase. This product uses Sn+Ag+Cu (tin, silver, copper) solder.
However, Sn+Cu (tin, copper), Sn+Zn+Bi (tin, zinc, bismuth) solder can also be used. (see Fig.3)
Fig.2
Fig.3
5

Service Navigation
Chassis Board Layout
Board Name Function
A-Board AV Terminal, HDMI, USB, WIFI, Ethernet, Digital Audio Out,
TUNER A/DVB-T/T2/C, DVB-T2/T/C Dem, CI Slot, Peaks IC_sLD8A,
Speaker out, HP, NAND FLASH, STM EEPROM, DDR SDRAM
P-Board Main Input, Power Supply, Key control, Power switch, LED Driver
K-Board Remote Receiver, Power and Timer LED, C.A.T.S
A-BOARD
K-BOARD
P-BOARD
6

Service Hints
How to remove the backcover
Remove the 28 fixing screws and the backcover. (see Fig.4)
How to remove the pedestal assembly
Lay the main unit face down. (see Fig.5)
Remove the 4 fixing screws and the pedestal assembly. (see Fig.6)
Fig.4
SCREWS
(1) THEC1509 /15pcs/
(2) THTD037J /11pcs/
(3) THE5ZL002N /2pcs/
(2)
(1)
(1)
(1) (1)
(1)
(1)
(1)
(1) (1)
(1)
(2) (2)
(1)
(1)
(2) (2)
(2)
(2)
(2)
(2)
(2)
(1)
(1)
Fig.5
(3)
SCREWS
(3) THE5ZL002N /4pcs/
(3) (3)
(3)
Fig.6
(1)
(2)
(3)
(3)
7

Applicable Signals
Note:
Signals other than above may not be displayed properly.
The above signals are reformatted for optimal viewing on your display.
Signal name COMPONENT HDMI
525 (480) / 60i,60p * *
625 (576) / 50i, 50p * *
750 (720) / 60p, 50p * *
1,125 (1,080) / 60i, 50i * *
1,125 (1,080) / 60p *
1,125 (1,080) / 50p *
1,125 (1,080) / 24p *
Component (Y, Pb, Pr) (from AV2 terminal), HDMI
8

Specifications
Power Source: 220-240V AC, 50 / 60Hz
Rated Power Consumption: 54W
Stand-by Power Consumption: 0.20W
Aerial Impedance: 75unbalanced, Coaxial Type
Receiving System: CS520E
DVB-T/T2 Digital terrestrial services (MPEG2 and MPEG4-AVC(H.264))
DVB-C Digitalcableservices(MPEG2 and MPEG4-AVC(H.264))
PAL I/H, B/G,
SECAM B/G, L/L’
VHFE2-E12 VHFH1-H2 (ITALY )
VHFA-H( ITALY ) UHFE21-E69
CATV(S01-S05) CATVS1-S10(M1-M10)
CATVS11-S20(U1-U10) CATVS21-S41(HYPERBAND)
PAL D/K,
SECAM D/K
VHFR1-R2 VHFR3-R5
VHFR6-R12 UHFE21-E69
PAL 525/60 (AV only)
M.NTSC (AVonly)
NTSC (AVonly)
CSR520
DVB-T/T2 Digital terrestrial services (MPEG2 and MPEG4-AVC(H.264))
DVB-C Digitalcableservices(MPEG2 and MPEG4-AVC(H.264))
PAL D/K
SECAM D/K
VHFR1-R2 VHFR3-R5
VHFR6-R12 UHFE21-E69
PAL 525/60 (AV only)
M.NTSC (AVonly)
NTSC (AVonly)
Aerial - Rear: VHF/UHF
Operating Conditions: Temperature: 0°C 35°C
Humidity: 20%  80% RH (non condensing)
Terminals:
AV1 IN Video (21 pin) 1V p-p 75
Audio (21 pin) 500mV rms 10k
RGB (21 pin) 0.7V p-p 75
AV1 OUT Video (21 pin) 1V p-p 75
Audio (21 pin) 500mV rms 1k
AV2 IN Video (RCAx1) 1V p-p 75
(COMPONENT/VIDEO) Audio (RCAx2) 500mV rms 10k(used for HDMI_ AV2 audio IN)
Video (RCAx3) Y:1V p-p 75(including synchronisation)
Pb/Cb, Pr/Cr: ±0.35V p-p 75
HDMI1, HDMI2 Type A Connectors
HDMI1 : Content Type
HDMI 2 : Content Type, Audio Return Channel
This TV supports “HDAVI Control 5” function.
DIGITAL AUDIO OUT PCM / Dolby digital, Fibre optic
USB DC 5V, Max 500mA [Hi-Speed USB (USB 2.0)]
ETHERNET RJ45, IEEE802.3 10BASE-T / 100BASE-TX
CARD SLOT Common interface slot (Complies with CI+) x 1
9

Wireless LAN:
Standard Compliance IEEE802.11a/n , IEEE802.11b/g/n
Frequency Range CS520E
IEEE802.11a/n: 5.180 GHz – 5.320 GHz
5.500 GHz – 5.580 GHz
5.660 GHz – 5.700 GHz
IEEE802.11b/g/n: 2.412 GHz – 2.472 GHz
Frequency Range CSR520
IEEE802.11a/n: 5.15 GHz – 5.35 GHz
5.47 GHz – 5.85 GHz
IEEE802.11b/g/n: 2.400 GHz – 2.4835 GHz
Security WPA2-PSK (TKIP/AES)
WPA-PSK (TKIP/AES)
WEP(64 bit/128 bit)
LCD screen: L5EDDYY00765
1920 x 1080, 16:9
Visible Diagonal 1000mm
Audio Output: 20W (2 x 10W)
Headphones: 3.5mm, 8Impedance
Accessories supplied : Remote Control
2 x R6 (UM3) Batteries
Dimensions:
Width: Height: Depth:
Including TV stand 904mm 556mm 230mm
TV set only 904mm 518mm 47mm
Mass:
Including TV stand 12.5kg
TV set only 10.5kg
Design and Specifications are subject to change without notice. Mass and dimensions shown are approximate.
This equipment complies with the EMC standards listed below:
EN55013, EN61000-3-2, EN61000-3-3, EN55020, EN55022, EN55024
10

Technical Description
Specification of KEY for DTCP-IP, C2MOD, CI Plus, DIMORA, HDCP2, Netflix, Widevine, Freetime
General information:
1.NAND FLASH (IC8900) for spare parts has the seed of KEY for each.
2.The final KEY data will be generated by sLD8A IC (IC8000) when SELF CHECK was done and are stored in both
sLD8A IC (IC8000) and NAND FLASH (IC8900).
All KEYs are not generated for all models.
The necessary KEY are only generated and stored depend on the feature of models.
Replacement of ICs:
When sLD8A IC (IC8000) is replaced, NAND FLASH (IC8900) should be also replaced with new one the same time.
When NAND FLASH (IC8900) is replaced, sLD8A IC (IC8000) is not necessary to be replaced the same time.
After the replacement of IC, SELF CHECK should be done to generate the final KEY data.
How to SELF CHECK: While pressing [VOLUME ( - )] button on the main unit, press the MENU button on the remote
control for more than 3 seconds.
TV will be forced to the factory shipment setting after this SELF CHECK.
Model and Keys:
Model No.
Keys
DTCP-IP C2MOD CI PLUS DIMORA HDCP2 Netflix
Widevine FREETIME
TX-40CS520E Yes None Yes Yes Yes Yes None
TX-40CSR520 Yes None Yes Yes Yes Yes None
11

Setting Inspection
Voltage Confirmation
A board
Description Test point
V
oltage
PNL12V TP4097 12.1V ± 0.8V
SUB3.3V TP5400 3.32V ± 0.165V
SUB1.1V TP8100 1.2V ± 0.06V
SUB1.5V TP8101 1.52V ± 0.05V
SUB5V TP5420 5.0V ± 0.25V
HDMI3.3V TP8000 3.3V ± 0.16V
STB3.3V TP5002 3.14V - 3.46V
STB5V TP5200 4.9V - 5.4V
SUB9V TP5004 9.0V ± 0.25V
TU_1.8V TP5705 1.8V ± 0.16V
FE_1.2/1.1V TP5706 1.14V ± 0.07V
P board
Description Test point
V
oltage*
V
oltage**
24V TP7407 and GND <1V 24 ± 2.4V
16V TP7410 and GND <1V 16V ± 0.6V
5VS TP7501 and GND 5.2V ± 0.2V 5.2V ± 0.2V
PFC TP7201 and GND TP7203*** <340V 390V ± 15V
* Connect AC 230V to JK7101 connector (Main switch is OFF).
** Connect DC 3.3V to TV_SUB_ON P2 connector – pin 9 /TP7416/ or set main switch is ON.
*** Beware, for testing of PFC use the GND (TP7203) in Hot area of P board – risk of electric shock.
12

Service Mode Function
MPU controls the functions switching for each IICs through IIC bus in this chassis. The following setting and adjustment can
be adjusted by remote control in Service Menu
How to enter into Service Mode
While pressing [VOLUME ( - )] button on the main unit, press the [RED] button on the remote control for 3 times within
2 seconds.
How to exit
Switch off the power with the [POWER] button on the main unit or the [POWER] button on the remote control.
13

SERVICE
S e r
v
i c e 1
216
SERVICE
ADJUST
WB-ADJ
OPTION
SRV-TOOL
DRV CHECK
ADJUST DYNAMIC
CONTRAST
YMAX
1,2:MAIN SELECT
3,4:SUB SELECT
9:PICTURE MENU SELECT
YELLOW:AUTO ADJUST
VOL :ADJUST
OK :WRITE
000 ADJUST DYNAMIC
COLOR
1,2:MAIN SELECT
3,4:SUB SELECT
9:PICTURE MENU SELECT
VOL :ADJUST
OK :WRITE
33
1,2:MAIN SELECT
3,4:SUB SELECT
9:PICTURE MENU SELECT
VOL :ADJUST
OK :WRITE
ADJUST DYNAMIC
SUB-BRT
1,2:MAIN SELECT
3,4:SUB SELECT
9:PICTURE MENU SELECT
VOL :ADJUST
OK :WRITE
800
A
DJUST DYNAMIC
BACKLGT
1,2:MAIN SELECT
3,4:SUB SELECT
9:PICTURE MENU SELECT
VOL :ADJUST
OK :WRITE
FFF
A
DJUST DYNAMIC
H-POS
1,2:MAIN SELECT
3,4:SUB SELECT
9:PICTURE MENU SELECT
VOL :ADJUST
OK :WRITE
0
A
DJUST DYNAMIC
H-AMP
1,2:MAIN SELECT
3,4:SUB SELECT
9:PICTURE MENU SELECT
VOL :ADJUST
O
K
:WRITE
0 ADJUST DYNAMIC
V-POS
1,2:MAIN SELECT
3,4:SUB SELECT
9:PICTURE MENU SELECT
VOL :ADJUST
OK :WRITE
0
A
DJUST DYNAMIC
V-AMP
1,2:MAIN SELECT
3,4:SUB SELECT
9:PICTURE MENU SELECT
VOL :ADJUST
OK :WRITE
0
WB-ADJ DYNAMIC
R-GAIN
BEFORE 80
METHOD 02
COLOR TEMP NORMAL
1,2:MAIN SELECT
3,4:SUB SELECT
7:COLOR TEMP SELECT
9:PICTURE MENU SELECT
0:WB METHOD SELECT
VOL :ADJUST
OK :WRITE/WB DIFF ADJ
80 WB-ADJ DYNAMIC
G-GAIN
BEFORE 7A
METHOD 02
COLOR TEMP NORMAL
7A WB-ADJ DYNAMIC
B-GAIN
BEFORE 73
METHOD 02
COLOR TEMP NORMAL
73 WB-ADJ DYNAMIC
R-CENT
BEFORE 82
METHOD 02
COLOR TEMP NORMAL
82 WB-
A
DJ DYNAMIC
G-CENT
BEFORE 80
METHOD 02
COLOR TEMP NORMAL
WB-
A
DJ DYNAMIC
B-CENT
BEFORE 79
METHOD 02
COLOR TEMP NORMAL
OPTION DYNAMIC
Boot
1,2:MAIN SELECT
3,4:SUB SELECT
9:PICTURE MENU SELECT
VOL :ADJUST
ROM OPTION DYNAMIC
STBY-SET
1,2:MAIN SELECT
3,4:SUB SELECT
9:PICTURE MENU SELECT
OK :POWER OFF
00 OPTION DYNAMIC
Emergency
1,2:MAIN SELECT
3,4:SUB SELECT
9 :PICTURE MENU SELECT
VOL:ADJUST
ON OPTION DYNAMIC
Y/C Delay
1,2:MAIN SELECT
3,4:SUB SELECT
9:PICTURE MENU SELECT
VOL :ADJUST
OK :WRITE
OPTION DYNAMIC
OPT 1
1,2:MAIN SELECT
3,4:SUB SELECT
5,6:BIT SELECT
9:PICTURE MENU SELECT
VOL :ADJUST
OK :WRITE
00000100 OPTION DYNAMIC
OPT 2
1,2:MAIN SELECT
3,4:SUB SELECT
5,6:BIT SELECT
9:PICTURE MENU SELECT
VOL :ADJUST
OK :WRITE
11101110 OPTION DYNAMIC
OPT 3
1,2:MAIN SELECT
3,4:SUB SELECT
5,6:BIT SELECT
9:PICTURE MENU SELECT
VOL :ADJUST
OK :WRITE
00000001
SRV-TOOL DYNAMIC
1,2:MAIN SELECT
9:PICTURE MENU SELECT
OK:ENTER
00
1
3
4
2
3 3 3
3
3
3 3
3
3
3
3
3
3
3
3
3 3 3
4
4
4
4
4
44 4
4
4
4 4
4
4
4
4 4
4
80
Key Command
Press the 3/4 button to change the adjustment values or function.
Press the 1/2 button to step up/down through the functions and adjustments
Press the numerical button VOLUME (+/-) to change of each option item.
Press the OK button after each adjustment has been made to store the required values.
A
DJUST DYNAMIC
TINT 00
PeaksSOFT *.*** OPTION1 04
Peaks EEP **.**.**** OPTION 2 ee
LSI PACKAGE *.*** OPTION 3 01
LSI DATA *.**.** OPTION 4 02
STBY SOFT *.**.** MODEL ID 0c
STBY EEP *.**.**** 0300019B
STBYROMCOR *.**.** 00000200
Ajax_CE *.**.** R/E Cnt ***/***/***
INV Cnt ****
AVSW --
1,2:MAIN SELECT
3,4:SUB SELECT
7:COLOR TEMP SELECT
9:PICTURE MENU SELECT
0:WB METHOD SELECT
VOL :ADJUST
OK :WRITE/WB DIFF ADJ
1,2:MAIN SELECT
3,4:SUB SELECT
7:COLOR TEMP SELECT
9:PICTURE MENU SELECT
0:WB METHOD SELECT
VOL :ADJUST
OK :WRITE/WB DIFF ADJ
1,2:MAIN SELECT
3,4:SUB SELECT
7:COLOR TEMP SELECT
9:PICTURE MENU SELECT
0:WB METHOD SELECT
VOL :ADJUST
OK :WRITE/WB DIFF ADJ
1,2:MAIN SELECT
3,4:SUB SELECT
7:COLOR TEMP SELECT
9:PICTURE MENU SELECT
0:WB METHOD SELECT
VOL :ADJUST
OK :WRITE/WB DIFF ADJ
1,2:MAIN SELECT
3,4:SUB SELECT
7:COLOR TEMP SELECT
9:PICTURE MENU SELECT
0:WB METHOD SELECT
VOL :ADJUST
OK :WRITE/WB DIFF ADJ
OPTION DYNAMIC
OPT 4
1,2:MAIN SELECT
3,4:SUB SELECT
5,6:BIT SELECT
9:PICTURE MENU SELECT
VOL :ADJUST
OK :WRITE
3
4
OPTION DYNAMIC
EDID-CLK
HDMI 1
1,2:MAIN SELECT
3,4:SUB SELECT
7 :HDMI SELECT
9 :PICTURE MENU SELECT
OK:WRITE
00000010
HIGH
79
1 2
1 2
1 2
DRV-CHECK DYNAMIC
USBHDD CHECK 00
1 2
1,2:MAIN SELECT
9:PICTURE MENU SELECT
OK 3sec:HDD CHK START
OPTION DYNAMIC
CLK MODE
1,2:MAIN SELECT
3,4:SUB SELECT
9 :PICTURE MENU SELECT
VOL:ADJUST
OK:WRITE
00 OPTION DYNAMIC
CLOCK 000
3
4
3
4
3
4
0
1,2:MAIN SELECT
3,4:SUB SELECT
9 :PICTURE MENU SELECT
VOL:ADJUST
OK:WRITE
14

Service Tool Mode
How to access
1. Select [SRV-TOOL] in Service Mode.
2. Press [OK] button on the remote control.
SRV-TOOL
Flash ROOM: AD – F1
PTCT:00.00.00.00.00 Time 00051:30 On/Off 0000042
Display of SOS History
SOS History (Number of LED blinking) indication.
From left side; Last SOS, before Last, three occurrence before, 2nd occurrence after shipment, 1st occurrence after shipment.
This indication will be cleared by [Self/check indication and forced to factory shipment setting].
Power ON Time, On/Off
Note: To display TIME/COUNT menu, highlight position, then press MUTE for 3sec.
Time: Cumulative power on time, indicated hour: minute by decimal.
On/Off: Number of On/Off switching by decimal.
Note: This indication will not be cleared by either of the self-checks or any other command.
Exit
Disconnect the AC cord from wall outlet or switch off the power with [Power] button on the main unit.
Display of Flash ROM maker code
Display of SOS History POWER ON TIME/COUNT
Press [MUTE] button (3sec)
15

Hotel Mode
1. Purpose
Restrict a function for hotels.
2. Access command to the Hotel mode setup menu.
In order to display the Hotel mode setup menu,
please enter the following command (within 2 second).
[TV] : Vol.[Down] + [REMOTE] : AV (3 times)
Then, the Hotel mode setup menu is displayed.
3. To exit the “Hotel mode”:
Switch off the power with the [POWER] button
on the main unit or the [POWER] button
on the remote control or pressing [EXIT] button
on the remote control.
4. Explain the Hotel mode setup menu.
ITEM Function
Hotel Mode Select hotel mode ON/OFF
Initial INPUT Select input signal modes.
Set the input, when each time power is switched on.
Selection:
Off/DVB-T/AV1/AV2/HDMI1/HDMI2
*Off: give priority to the last memory. However, Euro
Model is compulsorily set to TV.
Initial POS Select programme number.
Selection:
Off/0 to 99
*Off: give priority to the last memory
Initial VOL Level Adjust the volume when each time power is
switched on.
Selection/Range:
Off/0 to 100
*Off: give priority to the last memory
Maximum VOL
Level Adjust maximum volume. Range:
0 to 100
Button Lock Select local key conditions.
Selection:
Off/SETUP/MENU
*Off: altogether valid
*Setup: only F-key is invalid
(Tuning guide (menu) can not be selected.)
*MENU: only F-key is invalid
(only Volume/Mute can be selected.)
Remote Lock Select remote control key conditions.
Selected”
Off/SETUP/MENU
*Off: altogether valid
*Setup: only Setup menu is invalid
MENU: Picture/Sound/Setup menu are invalid
Private
Information Select private information for VIERA Cast is Keep or Reset if Hotel mode is set to [On] when TV power
on.
Selection :
Keep/Reset
•Keep: private information for VIERA Cast is keep
•Reset: private information for VIERA Cast is reset
Hotel mode
Hotel mode Off
nitial INPUT
Off
Initial POS Off
Initial VOL Level Off
Maximum VOL Level 100
Button Lock Off
Remote Lock Off
Private Information Keep
Select
RETURN
Chan
g
e
16

Data Copy by USB Memory
Purpose
a) Board replacement (Copy the data when exchanging A-board):
When exchanging A-board, the data in original A-board can be copied to USB Memory and then copy to new A-board.
b) Hotel (Copy the data when installing a number of units in hotel or any facility):
When installing a number of units in hotel or any facility, the data in master TV can be copied to USB Memory and the
copy
to other TVs.
Preparation
Make pwd file as startup file for (a) or (b) in an empty USB Memory.
1. Insert an empty USB Memory to your PC.
2. Right-click a blank area in a USB Memory window, point to New, and then click text document. A new file is created
by default (New Text Document.txt).
3. Right-click the new text document that you just created and select rename, and then change the name and
extension of the file to the following file name (a) or (b) and press ENTER.
File name:
(a) For Board replacement: boardreplace.pwd
(b) For Hotel: hotel.pwd
Note:
Please make only one file to prevent the operation error.
No any other file should be in USB Memory.
(After exchanging)
Copy back from USB Memory
TV
A-board USB
(Before exchanging)
Copy to USB Memory
Following data can be copied.
User setting data
(inc. Hotel mode setting data)
Channel scan data
Adjustment and factory preset data
Master TV Other TV Other TV
Copy to USB Memory Copy from USB Memory
USB
Memory
Following data can be copied.
User setting data
(inc. Hotel mode setting data)
Channel scan data
Other TV
17

Data Copy from TV set to USB Memory
1. Turn on the TV set.
2. Insert USB Memory with a startup file (pwd file) to USB Terminal.
On-screen Display will be appeared according to the startup file automatically.
3. Input a following password for (a) or (b) by using remote control.
(a) For Board replacement: 2770
(b) For Hotel: 4850
Data will be copied from TV set to USB Memory.
It takes around 2 to 6 minutes maximum for copying.
4. After the completion of copying to USB Memory, remove USB Memory from TV set.
5. Turn off the TV set.
Note:
Following new folder will be created in USB Memory for data from TV set.
(a) For Board replacement: user_setup
(b) For Hotel: hotel
Data copy
(Board replacement) or (Hotel)
Input Password
2770 or 4850
Performin
g
Com
p
letion
Performing
Data Copy(Board replacement )
Input password -----
Data Copy(Board replacement )
Input password -----
Data Copy(Board replacement )
Copy TV to Media
Please wait for a while
Please do not remove the Media GETTING
Data Copy(Board replacement )
Data copy has been successful
Please remove Media FINISH
18

Data Copy from USB Memory to TV set
1. Turn on the TV set.
2. Insert USB Memory with Data to USB Terminal.
On-screen Display will be appeared according to the Data folder automatically.
3. Input a following password for (a) or (b) by using remote control.
(a) For Board replacement: 2771
(b) For Hotel: 4851
Data will be copied from USB Memory to TV set.
4. After the completion of copying to USB Memory, remove USB Memory from TV set.
(a) For Board replacement: Data will be deleted after copying (Limited one copy).
(b) For Hotel: Data will not be deleted and can be used for other TVs.
5. Turn off the TV set.
Note:
1. Depending on the failure of boards, function of Data for board replacement does not work.
2. This function can be effective among the same model numbers.
Performing
Input Password
2771 or 4851
Performin
g
Performing
Data Copy(Board replacement )
Input password -----
Data Copy(Board replacement )
Copy Media to TV
Please wait for a while
Please do not remove the Media
WRITING
Data Copy(Board replacement )
Data copy has been successful
Please turn off the TV for system
initializing FINISH
19

Option Bytes Description
OPTION1
b1 TEXT Ch Refresh ON (1) / OFF (0)
b2 ID-1 ON (1) / OFF (0)
b3 Macrovision Auto-judge ON (1) / OFF (0)
b5 Reserved -
b6 Enable HDMI force reset ON (1) / OFF (0)
b7 Reserved -
OPTION2
b0 Adjust Igain enable ON (1) / OFF (0)
b1 A2 BG enable (5.5MHz) ON (1) / OFF (0)
b2 A2 DK1 enable (6.26MHz) ON (1) / OFF (0)
b3 A2 DK3 enable (5.742MHz) ON (1) / OFF (0)
b4 NICAM scan ON (1) / OFF (0)
b5 NICAM BG enable (5.5MHz) ON (1) / OFF (0)
b6 NICAM I enable (6.0MHz) ON (1) / OFF (0)
b7 NICAM DK enable (6.5MHz) ON (1) / OFF (0)
OPTION3
b0 NICAM priority ON (1) / OFF (0)
b1 Reserved -
b2 Reserved -
b3 A2 DK2 enable ON (1) / OFF (0)
b4 Inhibition of countermeasure for SIF signal drop ON (1) / OFF (0)
b5 Get onid from physical CH (CHINA) ON (1) / OFF (0)
b6 SSU search enable for HOTEL model ON (1) / OFF (0)
b7 SASO mute (ASIA) ON (1) / OFF (0)
OPTION4
b0 Countermeasure for Taiwan NTSC noise sound ON (1) / OFF (0)
b2 3DYC color motion detect ON (1) / OFF (0)
b3 RF Clamp Current minimum (TAIWAN) ON (1) / OFF (0)
b4 Reserved -
b5 Reserved -
b6 Reserved -
b7 Enable workaround for Polsat CAM problem (POLAND) ON (1) / OFF (0)
OPTION16
b0 PIP (derivate models) ON (1) / OFF (0)
b1 “Bass Boost” sound menu enable (derivate models) ON (1) / OFF (0)
b2 “Digital Remaster” sound menu enable (derivate models) ON (1) / OFF (0)
b3 “XR-Audio Pro Surround” sound menu enabel (derivate models) ON (1) / OFF (0)
b4 “Ambience” sound menu enable (derivate models) ON (1) / OFF (0)
b5 Reserved -
b6 Reserved -
b7 Reserved -
20
