CF-VDW07M & CF-VDW07HM
Windows 2000 and Windows XP
CONFIGURATION MANUAL
WIRELESS DISPLAY

Great user manuals database on UserManuals.info
Panasonic Wireless Display Configuration Manual
INTRODUCTION
Thank you for purchasing the Panasonic Toughbook CF-VDW07 series Wireless
Display. You are just steps away from the freedom of mobility and the power of
staying in touch. With Panasonic's Toughbook Wireless Display, you can enjoy the
constant connectivity to your laptop/desktop without being tied down to your office
chair. This configuration manual explains how to set up the Wireless Display with
your computer.
DISCLAIMER
No part of this manual may be reproduced in any form without the prior written
permission of Matsushita Electric Industrial Co., Ltd.. No patent liability is as-
sumed with respect to the use of the information contained herein. Some of the
illustrations included with the text may differ slightly in shape from the actual
items in order to make the explanation easier to understand.
Computers, computer devices, and manuals are subject to change without no-
tice. Matsushita Electric Industrial Co., Ltd. assumes no liability for damage in-
curred directly or indirectly from errors, omissions, or discrepancies between the
computer and the manuals.
Because of the nature of wireless communications, transmission and reception
of data can never be guaranteed. Matsushita Electric Industrial Co., Ltd. assumes
no liability for any inconvenience or potential loss of business which occurs as a
result of lost communication opportunities arising from external causes, such as
incorrect operation, or malfunction of the device or from loss of power, and for
damage of any kind resulting from delay or errors in data transmitted or received
using Panasonic Toughbook CF-VDW07 series Wireless Display, or for failure of
Panasonic Toughbook CF-VDW07 series Wireless Display to transmit or receive
such data. Panasonic Toughbook CF-VDW07 series Wireless Display should not
be used in situations where failure to transmit or receive data could result in
damage of any kind to the user or any other party, including but not limited to
personal injury, death, or loss of property.
TRADEMARKS
Microsoft and Windows are either registered trademarks of Microsoft Corporation
in the United States and/or other countries.
Panasonic is registered trademark of Matsushita Electric Industrial Co., Ltd..
All other brand or product names, logos, trademarks, etc. mentioned in this manual
are owned by their respective companies.
i

Great user manuals database on UserManuals.info
Panasonic Wireless Display Configuration Manual
Illustrations in this Manual:
NOTE : The Note icon points out items of interest or importance.
CAUTION : The Caution icon warns you about problems should be watched out for or precautions
should be taken.
WARNING : The Warning icon indicates the existence of a hazard that could result in damage to
equipment or property if the safety instruction is not observed.
[Start]-[Shut Down]: This illustration means to click [Start], then to click [Shut Down]. (For some
aplications, you may need to double-click.)
[Enter]: This illustration means to press the [Enter] key.
[Ctrl] + [Alt]: This illustration means to press and hold the [Ctrl] key, then press the [Alt] key.
Windows 2000 : Information for Microsoft Windows 2000 Professional users.
Windows XP : Information for Microsoft Windows XP users.
[ P.x-(x)]: This illustration means to refer to a certain instruction at certain page as indicated. For
example [ P.5-(1~3)] means please refer to instructions (1) through (3) at page 5.
* Some of the illustrations in this manual may differ slightly in shape from the actual items.
ii
TABLE OF CONTENTS
Illustrations in this Manual ........................................... ii
First-time Operation ...................................................... 1
Software Installation ...................................................... 1
AdHoc Mode Configuration ............................................ 3
Infrastructure Mode Configuration ................................ 10
Using the MeiWDS Setup Utility ................................ 16
Changing Wireless Display Settings ................................ 18
Using the Software Keyboard ........................................... 21
Uninstall the Software ........................................... 23
Limitation of Wireless Display Serial Port ..................... 23
Usage Precautions ...................................................... 24
Limited Use License Agreement ................................ 25

Great user manuals database on UserManuals.info
Panasonic Wireless Display Configuration Manual
This manual will walk you through the configurations of the Wireless Display with your
computer. In the package, please find the following items as shown in the figure below. If
any of these items is missing or not working properly, please contact Panasonic Technical
Support.
First-time Operation
1
Depending on the wireless network card you use, the Wireless Display might not
function properly with you computer. The following wireless network cards are rec-
ommended when using with the Wireless Display.
- Intel(R) PRO/Wireless LAN 2100 3B Series
- Proxim Orinoco 802.11b Silver/Gold Series
- Cisco Aironet 340/350 Series
- Symbol Spectrum24 Series
Depending on the capability of your computer's video chip-set, the Wireless Display
might not function properly with your computer. Please consult this with your system
administrator or the reseller.
NOTE
When installing software in a computer without the CD-ROM drive or PCMCIA slot,
copy all files in the Wireless Display Software CD to the hard disk, then install the
software from the hard disk.
In this manual, "L" is the CD-ROM drive letter and "x" denotes a numeral. You can
change these letters to suite your preference.
When using Windows 2000 and Windows XP please logon as the administrator.
NOTE
Install the necessary Software
II
II
I
Install MeiWDS program:
1. Select [Start] - [Run], input [L:\meiwds\setup.exe] and select [OK]. Follow the on-
screen instructions.
2. Restart the computer.
3. After restart, the Wireless Display Setup Utility (MeiWDS) icon will appear on
the System Tray.

Great user manuals database on UserManuals.info
Panasonic Wireless Display Configuration Manual
IIIIII
IIIIII
III
Install the Serial Port Driver of the Wireless Display:
Windows 2000
1. Select [Start] - [Setting] - [Control Panel] - [Add/Remove Hardware], then select
[Next].
2. Select [Add/Troubleshoot a device], then select [Next].
3. Select [Add a new device], then select [Next].
4. Select [No, I want to select the hardware from a list], then select [Next].
5. Select [Port (COM & LPT)], then select [Next].
6. Select [Have Disk].
7. Select [Browse..]. Go to [L:\wlserial\wdseral], then select [Open].
8. Click [OK].
9. Select [WDSP COM Port], then select [Next].
10. Select [Next], then select [Finish].
11. Restart the computer.
12. Select [Start] - [Setting] - [Control Panel] - [System] - [Device Manager], and confirm
that [WDSP COM Port (COMx)] is listed under [Port (COM & LPT].
Windows XP
1. Select [Start] - [Setting] - [Control Panel] - [Add Hardware], then select [Next].
2. Select [Yes, I have already connected the hardware], then select [Next].
3. Select [Add a new hardware device], then select [Next].
4. Select [Install the hardware that I manually select from a list (Advanced)], then
select [Next].
5. Select [Port (COM & LPT)], then select [Next].
6. Select [Have Disk].
7. Select [Browse...]. Go to [L:\wlserial\wdseral], then select [Open].
8. Click [OK].
9. Select [WDSP COM Port], then select [Next].
10. Select [Next], then select [Finish].
11. Restart the computer.
12. Select [Start] - [Setting] - [Control Panel] - [System] - [Device Manager], and confirm
that [WDSP COM Port (COMx)] is listed under [Port (COM & LPT].
Software Installation
2
If your are not using the serial port on the Wireless Display, you
can skip the installation of the serial port driver.
NOTE
IIII
IIII
II
Install Software Keyboard:
Select [Start] - [Run], input [L:\softkb\setup.exe] and select [OK]. Follow the on-screen
instructions.
NOTE
The softwares are installed in "C:\Program Files\Panasonic\".

Great user manuals database on UserManuals.info
Panasonic Wireless Display Configuration Manual
3
AdHoc Mode Configuration
1. Insert the battery into the Wireless Display, connect the
Wireless Display to a power outlet, and turn on the Wire-
less Display.
2. For a Wireless Display that has never been configured
before, the following screen will appear on the display.
If a different screen appears on your display, please
follow step 3to get to this screen; otherwise, please
skip to step 6.
<Wireless display screen>
Select network type.
AdHoc Infrastructure Cancel
Setup the Wireless Display in AdHoc Mode
II
II
I
Get the Information You Need:
3. Press the MENU button on the Wireless Display. The
following screen is displayed.
Before setting up the Wireless Display with your computer, please make sure
your computer is wireless LAN ready. Meaning that your computer is equipped
with a properly functioning 802.11b wireless network card.
NOTE
CAUTION
If your computer has firewall protection software installed (ie. Black-Ice or
ZoneAlarm), please disable the firewall since it might prevent the Wireless
Display from establishing connection with your computer. Please consult with
your system administrator on how to configure your firewall software.
Power Switch
Menu Button
General Wireless Battery Option Version
Mode : Connect OfflineView
Backlight : LOW MID HIGH
Profile: Profile 1
81% OK Cancel

Great user manuals database on UserManuals.info
Panasonic Wireless Display Configuration Manual
4. Select [Option] using the stylus. The
screen shown here will be displayed.
5. Select [Setup]. The screen shown here
will be displayed. Wireless Display can
save up to four profiles. [Profile 1] is used
in this manual. Select [Profile 1]. Hit [OK].
4
6. Select [AcHoc]. The screen shown here will be displayed. This information is needed
to setup your computer.
CAUTION
Do not select [Connect] until step 21 is
completed.
The Wireless Display will turn off au-
tomatically after 10 minutes have
elapsed. In this case, start the proce-
dure from step 1.
NOTE
Select profile.
Profile 1
Profile 3
Profile 2
Profile 4
OK Cancel
General Wireless Battery Option Version
Wireless Connection : Setup
Power on Password : Change
Supervisor Password : Change
Touchscreen : Calibration
LCD Off Timer : 1 min
LCD Off Mode : Quick Resume
Power Off Timer : 1 min
84% OK Cancel
In this screen, you can setup the Wireless Display to work on address class A, B, or
C by selecting one of the Class A , Class B , or Class C tabs.
* Class A is used in this manual.
NOTE
Change setting on host PC to the following value,
reboot the host PC, then select "Connect" below.
Wireless LAN card
Network Type : AdHoc
SSID : cfvdw07-xxxxx
WEP Encryption : disable
TCP/IP Class A Class B Class C
IP Address : 10.57.148.205
NetMask : 255.0.0.0
MeiWDS
AES Encryption : disable
Password : wdsp
Connect Cancel

Great user manuals database on UserManuals.info
Panasonic Wireless Display Configuration Manual
AdHoc Mode Configuration
IIII
IIII
II
Create a Profile for the 802.11b Network Adapter:
5
NOTE
Depending on the brand of network card you use, the utility will appear differently.
Throughout this manual, the configuration utility, Client Manager from Orinoco
Wireless, is used as an example. Please match the settings accordingly with
your utility.
If you are using a CISCO Aironet 340/350 series wireless adapter, please dis-
able LEAP.
7. At your computer, launch the con-
figuration utility of your 802.11b wire-
less network card. Following is a
sample window that could appear
on your computer's monitor/LCD.
This screen is a sample.
Windows XP has the ability to manage profile settings for wireless network
adapters. Users can either use the Windows XP's management or the adapter's
configuration utility to create
/ edit profiles. In general, a utility bundled with the adapter
provides additional functionality.
This manual choose NOT to use the Windows XP's wireless network adapter man-
agement as examples. For how to use Windows XP's wireless network adapter
management, please refer to Windows XP user manual.
To ensure the adapter's utility is the primary management utility, please make sure
Windows XP's management is disabled:
i) Click [Start] - [Control Panel] - [Network Connec-
tions].
ii) Right click on [Wireless Network Connection x]
of the wireless network card using with the Wire-
less Display, and select [Properties].
iii) Select [Wireless Networks] tab. The window as
shown on the right side is displayed.
iV) Uncheck the "Use Windows to configure my
wireless network settings" box.
V) Click [OK] to exit out of the "Wireless Network
Connection Properties" window.
NOTE

Great user manuals database on UserManuals.info
Panasonic Wireless Display Configuration Manual 6
8. First, create a profile that will be used for commu-
nicating with the Wireless Display. Select [Actions]
- [Add/Edit Configuration Profile]. The following win-
dow is displayed.
9. Click [Add]. The following window is displayed.
Create a name for this profile in the "Profile Name"
box, and change the "Network Type" to [Peer-to-
Peer Group].
This screen is a sample.
This screen is a sample.
10. Click [Next]. The following window is displayed. In
"Network Name" box, input the SSID as shown on
your Wireless Display.
[ P.4-(6)]
This screen is a sample.
For use in Canada, set the "Channel
Numebar" to [Channel 11] only.
CAUTION
This screen is a sample.
11. Click [Next]. The following window is displayed.
Do not enable the data security for the initial setup.
The data security can be enabled after the com-
munication between the computer and the Wire-
less Display is established.

Great user manuals database on UserManuals.info
Panasonic Wireless Display Configuration Manual
AdHoc Mode Configuration
15. Click [OK] - [OK] - [Close]. Please make sure
to exit out of the "Local Area Connection x"
window so that settings take effect immedi-
ately.
14. Select "Specify IP Address", and enter the IP
Address and Subnet Mask as shown on the
Wireless Display. [ P.4-(6)]
16. Windows XP
Select [Start] - [Control Panel] - [Network Connections]. Right click on [Wireless
Netwoking Connection X] and then select [ Properties]. The window as shown on
next page is displayed.
This screen is a sample.
7
Please select the [Local Area Connection x]
of the wireless network card that will be used
with the Wireless Display.
NOTE
IIIIII
IIIIII
III
Input the IP Address:
This screen is a sample.
12. Click [Finish] to exit out the profile setting.
Please make sure to exit out of the network
adapter configuration utility so the settings
take effect immediately.
13. Windows 2000
Select [Start] - [Settings] - [Control Panel] - [Network] - [Dial-Up Connection] - [Local
Area Connection x]. The following window is displayed.

Great user manuals database on UserManuals.info
Panasonic Wireless Display Configuration Manual
17. Highlight [Internet Protocol (TCP/IP)], and then
click [Properties].
18. Select "Use the following IP address:". Enter the
IP Address and Subnet Mask as shown on the
Wireless Display. [ P.4-(6)]
19. Click [OK] - [OK] to exit out of the setting window.
This screen is a sample.
8
Please select the [Wireless Network Connec-
tion x] of the wireless network card that will be
used with the Wireless Display.
NOTE
This screen is a sample.
IVIV
IVIV
IV
Ready to Connect:
20. Left click the MeiWDS icon in the "System Tray".
The pop-up menu as shown on the right will appear.
Select [Password]. The following window will appear.
This screen is a sample.
This screen is a sample.
21. Please enter the password as shown on the Wireless Display in the "Enter pass-
word" field above. The default password is "wdsp". [ P.4-(6)]

Great user manuals database on UserManuals.info
Panasonic Wireless Display Configuration Manual
22. The setting is completed. Select [Connect] on the Wireless Display. The display will
attempt to establish connection with the computer. If the connection is successful,
the MeiWDS icon in the "System Tray" will change from to .
The Wireless display can not connect to the computer if the password is
entered incorrectly.
The user can change the password after the initial connection is estab-
lished. The new password will be updated automatically in the "Password"
field on the system tray.
NOTE
NOTE
Windows XP
Windows XP's "Fast User Switching" function is not sup-
ported by the Wireless Display. A warning message as
shown on the right side will appear if the "Fast User
Switching" function is enabled. Click [OK] to close the
warning massage.
To disable the "Fast User Switching" function:
Click [Sart] - [Control Panel] - [User Accounts]. Click on "Change the way user log on or
off". The following window will appear.
- Uncheck "Use Fast User Switching".
- Click [Apply Options].
- Close the "User Accounts" window.
- Close the "Control Panel".
NOTE
Once the communication is established, the
"Wireless Display Setup Utility" will be become
accessible. User will then be able to launch
the "Wireless Display Setup Utility", which can
be used to modify the display's settings.
To access the utility:
Windows 2000
Click [Start] - [Programs] - [Panasonic] - [Wireless Display Setup Utility].
Windows XP
Click [Start] - [All Programs] - [Panasonic] - [Wireless Display Setup Utility].
9
AdHoc Mode Configuration

Great user manuals database on UserManuals.info
Panasonic Wireless Display Configuration Manual
Setting up the Wireless Display for Infrastructure Mode
Method 1
Setup Infrastructure Directly:
By default under Infrastructure Mode, the Wireless Display will attempt to communicate with
an access point having the SSID of "cfvdw07" and WEP encryption disabled. If you have an
access point with the same settings as described above in your network environment, the
Wireless Display can be configured in Infrastructure Mode with the computer directly.
II
II
I
Get the Information You Need:
Select network type.
AdHoc Infrastructure Cancel
1. Turn on the Wireless Display. The following screen is displayed. If a different screen
appears, please follow steps 3through 6at pages 3 and 4 on how to get to this
screen. [ P.3-(3~6)]
2. Select [Infrastructure]. The following
screen is displayed. The default SSID
is "cfvdw07" with WEP encryption dis-
abled. This information is needed to
setup the computer.
IIII
IIII
II
Create a Profile for the 802.11b Network Adapter:
3. Follow steps 7through 9on page 5 to launch the
configuration utility of the network adapter and cre-
ate a new profile. Create a profile name and change
the "Network Type" to [Access Point]. [ P.5-(7~9)]
This screen is a sample.
Isolate host PC and Accress Point (AP) from
network. Change setting on the host PC and
AP to the following value, reboot the host
PC, then select "Connect" below.
Wireless LAN card
Network Type : Infrastructure
SSID : cfvdw07
WEP Encryption : disable
TCP/IP Class A Class B Class C
IP Address : 10.57.148.205
NetMask : 255.0.0.0
MeiWDS
AES Encryption : disable
Password : wdsp
Connect Cancel
10
Infrastructure Mode Configuration

Great user manuals database on UserManuals.info
Panasonic Wireless Display Configuration Manual
II
II
I
Setup the Wireless Display in AdHoc Mode:
1. Follow the instructions on pages 3 through 8 on how to setup the display in AdHoc
mode.
IIII
IIII
II
Match the Display's Settings with the Access Point:
IVIV
IVIV
IV
Ready to Connect:
7. The Wireless Display is now ready. Follow steps 20 through 22 on page 8 on how
to establish connection with the computer. [ P.8-(20~22)]
Method 2
Configure from AdHoc mode to Infrastructure mode:
If the SSID of your Access Point is not "cfvdw07", you should first configure the Wireless
Display with the computer in AdHoc mode. Secondly, use the "Wireless Display Setup
Utility" to modify the Wireless Display to match the settings of the Access Point. Finally,
change the wireless network adapter's profile to Infrastructure mode.
Please have the information of your Access Point ready. The necessary information in-
cludes the SSID of the Access Point, and it's WEP encryption key, if WEP is enabled.
Throughout this manual, an Access Point with
SSID = OfficeAP001
64 Bit WEP Key = A24BE4190C
is used as an example. Please match the settings accordingly with your Access Point.
NOTE
11
Infrastructure Mode Configuration
5. Follow steps 11 and 12 on page 6 and 7 to
exit out of the configuration utility. [ P.6-
(11~12)]
This screen is a sample.
4. Enter the SSID as shown on the Wireless Dis-
play. [ P.10-(2)]
IIIIII
IIIIII
III
Input the IP Address:
6. Follow steps 13 through 19 on pages 7, and 8 on how to enter the IP address. [
P.7-(13~19)]

Great user manuals database on UserManuals.info
Panasonic Wireless Display Configuration Manual
3. Click [Start] - [Programs] - [Panasonic] - [Wireless Display Setup Utility] to launch
the "Wireless Display Setup Utility". The following window will appear and prompt
for password.
This screen is a sample.
2. Select [Connect] on the Wireless Display. The display will attempt to establish
connection with the computer. If the connection is successful, the MeiWDS icon in
the "System Tray" will change from to .
12
4. No default password is set for the
"Wireless Display Setup Utility".
Leave the field blank and click [OK].
The wndow as shown on the right
will appear. Settings changed in this
window will be updated in the Wire-
less Display.
This screen is a sample.
The check in this box indicates that
[Profile 1] is the current active pro-
file.
5. [Profile 1], which is the current active profile, contains settings for the AdHoc Mode.
Please write down the IP addresses in both "PC IP Addess" and "Display IP Ad-
dress" fields as they will be need later.
In the "Profile" drop-down menu, select [Profile 2], the window as shown below will
appear. We will setup [Profile 2] for Infrastructure Mode and then enable [Profile 2]
as the current active profile.
It is also possible to modify [Profile
1] to become Infrastructure Mode;
however, doing so, the AdHoc Mode
settings will be lost.
NOTE
This screen is a sample.

Great user manuals database on UserManuals.info
Panasonic Wireless Display Configuration Manual
5. A Enter the SSID of your Access Point.
B Change the network type to [Infrastructure].
C Enter the PC IP address, Display IP address, and Subnet mask. [ P.12-(4)]
D Enable the WEP to [64 bits]. (If your Access Point does not uses WEP or use
128 bits encryption, change the "WEP" to [Disabled] or [128 bits] respectively.)
E Click the [Key(s)...] button. The window shown below will appear. Enter the
WEP key of your Access Point here. Set the "Default Key" to the one you wish to
use. Click [OK] to exit out of the window.
F Enable the AES to [128 bits]. (If you do not want to use AES encryption, use 192
bits encryption, or use 256 bits encryption, change the "AES" to [Disabled], [192
bits], or [256 bits] respectively. )
G Click the [Key...] button. The window as shown below will appear. To use phrase
generated AES key, select "Phrase" and enter a phase in the box. To enter the
AES key directly, select "Binary" and enter your AES key in the box. Click [OK] to
exit out of the window.
H Check the "Use this profile now" box so that "Profile 2" will become the active
profile after the setup is completed.
This screen is a sample.
B
C
E
D
A
F
G
H
13
Infrastructure Mode Configuration

Great user manuals database on UserManuals.info
Panasonic Wireless Display Configuration Manual
6. Click [Next] - [OK] - [Next] - [OK] - [Finish] to exit out of the "Wireless Display Setup
Utility".
8. The Wireless Display is now updated with the new settings. Restart the Wireless
Display, press the MENU button on the display, then select [Wireless]. The current
settings of the Wireless Display are listed in this screen.
At this stage, the display can not establish
connection with the computer because the
display's settings have been changed.
The network adapter's profile must also
be changed to match with the display.
NOTE
General Wireless Battery Option Version
Network Type : Infrastructure
SSID : OfficeAP001
Channel :
TxRate mode : Fully Automatic
Encryption : 64bit
Rate (Tx/Rx) : /
Display IP : 10. 57.151.206
PCIP : 10. 57.151.205
Net Mask : 255. 0. 0. 0
AES Encryption : 128bit
84% OK Cancel
IIIIII
IIIIII
III
Setup the Wireless Network Adapter to Infrastructure Mode:
9. Launch the Configuration Utility of the network
adapter. Select [Action] - [Add/Edit Configura-
tion Profile] - [Add]. The following window is dis-
played. [ P.5-(7~9)]
This screen is a sample.
10. Create a profile name in the "Profile Name" box.
Change the "Network Type" to [Access Point].
This screen is a sample.
11. Click [Next]. The following window is displayed.
In the "Network Name" box, enter the SSID of
the Access Point.
14

Great user manuals database on UserManuals.info
Panasonic Wireless Display Configuration Manual
Infrastructure Mode Configuration
15
12. Click [Next]. The following window is displayed.
Check "Enable Data Security," and enter the
Access Point's WEP key.
13. Click [Next] - [Finish] to exit out of the profile
setting. Please make sure to exit out of the
network adapter configuration utility so the
settings take effect immediately.
IVIV
IVIV
IV
Ready to Connect:
Some adapters' Configuration Utilities can
store more than one profile. Make sure
the profile you just created is selected as
default.
NOTE
14. The setting is complete. Restart the display, and the computer will now connect to
the display through the Access Point.
This screen is a sample.

Great user manuals database on UserManuals.info
Panasonic Wireless Display Configuration Manual
Using the MeiWDS Setup Utility
Unlike the "Wireless Display Setup Utility", which is used to modify the settings of the
Wireless Display, the "MeiWDS Setup Utility" is used to modify the settings on the host
computer side. Different from the "Wireless Display Setup Utility", the "MeiWDS Setup
Utility" can be launched regardless if the Wireless Display is communicating with the
host computer.
ATo Disable the Password field on System Tray:
To launch the "MeiWDS Setup Utility", click
[Start] - [Programs] - [Panasonic] - [MeiWDS
setup Utility]. The following window will appear
and prompt for the supervisor password.
This screen is a sample.
This screen is a sample.
The default supervisor password is "supervisor", all lower case. Enter the password.
Click [OK]. The following window will appear.
A
B
D
C
1. Uncheck the "Enable tray menu" box. Click [Next] - [Finish] to exit out of the "MeiWDS
Setup Utility".
2. Left click on the MeiWDS icon on the system tray.
The pop-up menu as shown on the right will appear.
The "Password" selection has been disabled. The
purpose of disabling the "Password" field is to pre-
vent user from accidentally changing the password
and stopping the communication to the Wireless Dis-
play.
This screen is a sample.
16

Great user manuals database on UserManuals.info
Panasonic Wireless Display Configuration Manual
BTo change the MeiWDS Setup Utility Password:
1. The default supervisor password for the "MeiWDS Setup Utility" is "supervisor". To
change the password, click the [Change Supervisor Password] button. The follow-
ing window will appear.
2. Enter the current password in the "Enter Current Password" field. Enter the new
password in both of the "Enter New Password" and "Confirm New Password" fields.
Click [OK] - [Next] - [Finish] to exit out of the utility.
CTo change the AES Encryption Key Lifetime:
1. If AES encryption is enabled in "Wireless Display Setup Utility", the AES key length
and AES key will be automatically updated in the "Key Length :" and [AES Key...]
fields in the "MeiWDS Setup Utility".
Use the drop-down menu to select a different key lifetime. Click [Next] - [Finish].
The default AES key lifetime is [ 1 hour ].
DTo change the AES key of the host PC side:
1. User can select [Disable], [128 bits], [192 bits] or [256 bits] AES encryption using
the "Key Length :" drop-down menu.
2. Click the [AES Key...] button. the window as shown on
the right will appear. Enter the AES key in this screen.
Click [OK] - [OK] - [Finish].
This screen is a sample.
This screen is a sample.
The Wireless Display's default setting is with AES en-
cryption disabled. If the Wireless Display has been re-
set to factory default. Please select [Disable] in the
"Key Length :" field at D.
NOTE
17
Using the MeiWDS Setup Utility
