Panasonic CY-VM5800U User manual

Panasonic
5.8 Color LCD Monitor
Ecran couleur a cristaux liquides de 5,8 pouces
Monitor LCD en color de 5,8”
CY-VM5800U
Operating Instructions
Manuel destructions
Manual de instrucciones
Please read these instructions carefully before using this product and save this manual for future use.
Priere de lire ces instructions attentivement avant d'utiliser le produit et garder ce manuel pour (’utilisation ulterieure.
Lea con atencidn estas instrucciones antes de utilizar el producto y guarde este manual para poderlo consultar en el futuro.

\mSm
WARNING:
TO AVOID THE RISK OF SERIOUS INJURY OR
POSSIBLE VIOLATION OF LAWS, NOT FOR USE
WHERE VISIBLE TO DRIVER FOR ANY PURPOSE
OTHER THAN NAVIGATION OR USE WITH REAR
VIEW CAMERA.
When Driving
©The driver must not operate the color LCD
monitor. Operating the color LCD monitor may
lead to distraction and cause an accident. Stop
you car in a safe location when operating the
unit.
© The driver must not watch videos while driving.
It may lead to distraction and cause an acci¬
dent.
• Keep the unit at an appropriate sound level.
Driving with the sound at a level that prevents
you from hearing sounds outside and around
the car may cause an accident.
WARNING:
For safe driving, watching TV and video is
available only in stopped condition with the
parking brake pulled. “WARNING" will be dis¬
played while the parking brake is not engaged.
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, USE ONLY THE INCLUDED COMPO¬
NENTS.
The user should bear in mind that in some
areas there may be restrictions on how and
where this unit must be installed. Consult your
dealer for further details.
CAUTION:
When Car Washing
Do not expose the product to water or excessive
moisture. This could cause electrical shorts, fire
or other damage.
WARNING:
© Due to the extreme danger of accidents
occurring, the driver must not watch the tele¬
vision or videos while driving.
© Do not expose unit to direct sunlight or exces¬
sive heat.
[PaMlSCt^DC
MODEL NO. _ Y w Msfton ,,
N° DE MODELE CY ' VM5800U
L\ \ 1
WARNING
H- B ©
12V 3A -
Due to the extreme danger ot accidents occurring, the driver
must not watch the television or videos while driving.
YFM014C240ZA
-
Umilicluitf Cy Matatiil »Electric (Ijitia) Co, Lia
Iir[(II)i»j5 UiS( a Tjinn
Do not expose unit to direct sunlight or excessive heal.

Consignes de securite Information para su seguridad

•(PSSdD
Panasonic welcomes you to our ever growing family of electronic product owners. We know that this prod¬
uct will bring you many hours of enjoyment. Our reputation is built on precise electronic and mechanical
engineering, and our products are manufactured with carefully selected components and assembled by
0 people who take pride in their work. Once you discover the quality, reliability, and value we have built into
© thic nmHurt wnn tnn iiwill ho nrnitH tn ho a momhor nf nur familw
□ Features
o Wide-screen 16:9 aspect ratio is ideal for film
viewing.
©280 800 pixels high-definition 5.8 inches large
LCD monitor.
o TFT {Thin Film Transistor) active matrix for accu¬
rate color reproduction.
□ Components
o Operating instruction. 1 o Supplied hardware. 1 set (•=» page 36)
o Remote control unit. 1 o Warranty card. 1
o Battery (CR2025). 1
□ Contents
Safety Information . 2
Use this Product Safety. 5
Name of Controls .. . 10
Remote Control Unit Preparation. 11
Battery installation, battery notes, control reference guide
Before Using the Display Unit. 12
Input Selection . 13
Aspect Setting. 14
Brightness Setting. 15
Display Setting . 16
Black level, contrast, color, tint
Installation Guide. 18
Step-by-step procedures
Electrical Connections .. 21
Cautions, wiring diagram, basic system configuration, parking brake cord, advanced system configuration
Troubleshooting . 24
Where to get service help, troubleshooting tips
Maintenance. 26
To prevent damage to the system exterior, clean dirt by wiping lightly with a soft cloth
Specifications. 27
oCan be connected to the DVD player (CX-
DV700U), color LCD monitor/CD, DVD player (CY-
VMD9000U), video deck and other devices.
4

Use this Product Safety
When Parked
• Parking in direct sunlight can produce very high
temperatures inside your car Give the interior a
chance to cool down before switching the unit on
• Do not watch the monitor with the engine off It
will consume battery power and may prevent the
engine from starting
Use the Proper Power Supply
• This product is designed to operate with a 12 V,
negative ground battery system (the normal sys¬
tem in a North American car)
Use Authorized Servicenters
• Do not attempt to disassemble or adjust this pre¬
cision product Please refer to the Servicenter list
included with this product for service assistance
For Installation
• Where and how this unit is installed differs
according to the car model concerned As
such, the information contained in this installa¬
tion guide is designed for professional
installers and is not intended for non-technical
individuals
• Be sure to install the monitor in a position that
does not obstruct the driver’s vision
• If the monitor has been installed for the rear
seat passengers, they must be careful to pre¬
vent injury by hitting their heads on the monitor
in case of an accident
• Do not install the unit in an area where it would
obstruct the operation of an air bag
• Ask a trained technician to install the unit
Installation and wiring require training and
experience
To be safe, ask the sales outlet where you pur¬
chased the unit to perform the installation
v_'_ )
Find the model number and serial number on
either the back or bottom of the unit Please
record them in the spaces below and retain this
booklet as a permanent record of your purchase
to help with identification in case of theft
MODEL NUMBER CY-VM5800U
SERIAL NUMBER _
DATE PURCHASED _
FROM
When Operating
o Be sure not to let the unit fall or be strongly
impacted since this may cause a malfunction or
fire
□ Cautions for the Liquid Crystal Panel
® Do not leave the liquid crystal panel surface facing
upwards
Storage temperature range -4 °F to 176 °F
(-20 °C to 80 °C)
When the liquid crystal panel reaches high tem¬
peratures or low temperatures, chemical changes
occur within the liquid crystal panel which may
cause malfunctions
• Do not strongly impact the liquid crystal panel
© When the temperature is very cold or very hot, the
image may not appear clearly or may move slow¬
ly Also, movement of the image may seem to be
out of synchronization or the image quality may
decline in such environments Note that this is not
a malfunction or problem
Usage temperature range 32 °F to 104 °F
(0°C to 40 °C)
• There may be red spots, blue spots and green
spots on the panel surface This is a characteristic
of liquid crystal panels and is not a problem The
liquid crystal panel is built with very high precision
technology and has at least 99 99% effective
image pixels Be aware that on 0 01 % of the panel
there may be missing pixels or constantly light
pixels
Spots
5
S©<=>(P@SGlD

Panasonic est heureuse de vous compter parmi les utihsateurs de ses appareils 6lectromques Nous pouvons vous
assurer que cet appareil vous procurera de longues heures d'agr6ment Notre reputation est fondSe sur une ingSmerie
6lectronique et mGcamque de haute precision, laquelle preside d la fabrication d’appareils ne comportant que des com-
posants de choix assembles par un personnel soucieux de la bonne reputation acquise par la qualite de son travail
Apr6s avoir d6couvert la qualite, la valeur et la fiabilite de cet appareil, vous aussi serez tier d’etre un client Panasonic
□ Caracteristiques
o Le rapport de format d'ecran large 16 9 est ideal pour le
visionnement des films
o Ecran d cristaux liquides de 5,8 pouces, a haute defini¬
tion de 280 800 pixels
□ Elements constitutifs
o Matnce active TFT (transistor a couches minces) pour
une reproduction fiddle des couleurs
o Peut etre raccorde au lecteur DVD (CX-DV700U), au
lecteur CD, DVD/6cran couleur d cristaux liquides (CY-
VMD9000U), & une platine video et a d'autres appareils
o Manuel destructions 1 o Materiel d’installation 1 ensemble {»page 36)
o Teiecommande 1 o Carte de garantie 1
° Piles (CR2025) 1
□ Table des matieres
Consignes de securite 3
Utiliser ce produit en respectant la securite 7
Noms de commandes 28
Preparation de la teiecommande 29
Mise en place de la pile, remarques sur la pile, guide de r6f6rence sur les commandes
Avant d'utiliser I'unite d'affichage 30
Selection de I'entree 31
Reglage du format 32
Reglage de la luminosite 33
Reglage de I'affichage 34
Niveau du noir, contraste, couleur, nuance
Guide d'installation 36
Procedure Stape par 6tape
Branchements electriques 39
Attention, schema de cablage, configuration systeme de base, cable de connexion du frein de stationnement, configura¬
tion systSme SvoluSe
En cas de difficulty 42
Ou obtemr le service aprSs-vente, conseils de depannage
Entretien 44
Pour Gviter des d6g3ts d I'extfineur de I’appareil, Nettoyer les souillures en frottant I6g6rement avec un linge doux
Donnees techniques 45
6

Utiliser ce produit en respectanf
Voiture stationnee
• L’habitacle d’une voiture immobile exposSe au soleil
toutes vitres ferm6es devient rapidement tr6s chaud
Laisser rafraTchir I’mtyrieur du v6hicule avant d'utiliser
I’appareil
• Ne pas regarder le momteur lorsque le moteur est
arret6 Le fait de regarder le momteur avec le contact
moteur coups consomme beaucoup de batterie ce qui
pourrait empecher le moteur de repartir
Source d’alimentation
• Cet appareil est congu pour fonctionner sur un systSme
d’alimentation avec batterie de 12 V a masse negative
(systSme standard sur les voitures de construction
nordamericaine)
Reparation des centres de service agrSSs (Servicenters)
• Ne pas tenter de dSmonter ou d’ajuster I’appareil soi-
mSme Veuillez consulter la liste des Centres de service
agrees (Servicenter) qui accompagne ce produit en
quality de moyen d'assistance de service aprSs*vente
—
Installation
• L’endroit et la fagon d’installer cet appareil different
selon le type de vehicule dont il s’agit tes informa¬
tions de ce guide d’installation s’adressent en tait
aux mstallateurs qualifies, elles ne sont pas fourmes
a 1’intention des individus sans qualifications tech¬
niques
• Installer le momteur vidSo de telle maniSre qu'il ne
gene pas la visibility du conducteur
• Si le momteur a 6t6 install pour les passagers
arrive, ceux-ci doivent faire trSs attention de ne se
blesser a la tete en se cognant contre le momteur en
cas d'accident
• Ne pas installer le momteur a un emplacement qui
generait le dyploiement du sac gonflable
• Demander a un techmcien exp^rimenty d’installer le
momteur
Pour plus de surety, demander au d^taillant qui vous
a fourni le momteur de procyder a son installation
II est recommande de noter, dans I’espace prevu ci-
dessous, les numyros de modyie et de serie mscrits
soit a I'arriyre soil sur le fond de I’appareil, et de con-
server ce manuel comme mymorandum de I’achat afin
de permettre 1’identification de I’appareil en cas de vol
NUMERO DE MQDELE CY-VM5800U
NUMERO DE SERIE_
Pendant I’utihsation de I’appareil
o Veiller a ne pas faire tomber I’appareil m le heurter vio-
lemment ytant donny que cela peut provoquer des
pannes voire un incendie
□ Precautions a prendre avec le
panneau a cristaux liquides
® Ne pas laisser la surface du panneau a cristaux liquides
dirig§e vers lehaut
Limites de temperature destockage -20°Ca80°C ©
(-4 °F a 176°F ) _
Lorsque le panneau a cristaux liquides attemt des
tempyratures elevees ou basses, des changements
chimiques se produisent dans le panneau a cristaux
liquides meme qui peuvent eventuellement engendrer
des pannes
• Le panneau a cristaux liquides ne doit jamais soumis a
des chocs violents
• Lorsque la tempyrature est particulierement basse ou
yievye, 1'image sur I'ecran risque de ne pas Stre nette ou
encore une lente derive de 1'image peut se produire Par
ailleurs, le mouvement de 1'image risque d'apparaltre
comme ytant en desynchronisation ou encore sa quality
risque d'etre affectee dans de telles conditions II taut
cependant noter qu'il ne s'agit pas d'un defaut du
panneau m d'une anomafie
Limites de tempyrature en service 0 °C a 40 °C
(32 °Fai04 *F)
© Des points rouges, bleus et verts peuvent apparaTtre sur
le panneau Cest une des caractyristiques du panneau a
cristaux liquides et ceci ne constitue pas une anomafie
Le panneau a cristaux liquides a yty r6alis6 a partir
d'une technologie de tres haute precision et possyde au
minimum 99,99% de pixels d'lmage efficaces II con-
vient de savoir que dans 0,01% du panneau, des pixels
peuvent manquer ou bien Stre constamment allum^s
Points
A
DATE DE L’ACHAT
VENDEUR

—
Panasonic le da la bienvenida a la familia constantemente en aumento de poseedores de productos electrbnicos. Nos
esforzamos en proporcionarle las ventajas de la ingenierfa mecanica y electrbnica de precision, de una fabricacibn con
componentes cuidadosamente seleccionados, y de un montaje realizado por personas orgullosas de la reputation que
su trabajo ha cimentado para nuestra empresa. Estamos seguros de que este producto le proporcionarb muchas horas
de distraccibn y, una vez comprobada la calidad, el valor y la fiabilidad incorporados, used tambien se sentirb orgulloso
de pertenecer a nuestra familia.
□ Caracteristicas
o Pantalla panorbmica con una relacibn de aspecto de
16:9 ideal paraverpeliculas.
o Amplio monitor LCD de 5,8’ con definicibn alta de
280 800 pixeles.
o Matriz activa TFT (transistor de pelicula fina) para
reproducirfielmente el color.
□ Componentes
o Manual de instrucciones. 1 ° Hardware suministrado. 1 juego (=> pagina 54)
o Mando a distancia. 1 o Tarjeta de garantia . 1
o Pila (CR2025). 1
□ Indice
Information para su seguridad. 3
Utilization segura de este producto . 9
Nombre de los controles . 46
Preparation del mando a distancia .. . 47
Instalacion de la pila, notas sobre la pila, guta de referenda de los controles
Antes de utilizar la unidad de visualization . 48
Selection de entrada .: 49
Ajuste del aspecto . . 50
Ajuste del brillo. 51
Ajuste de la visualization . 52
Nivel del negro, contraste, color, matiz
Guia de instalacion . 54
Procedimientos paso a paso
Conexiones electricas . 57
Precauciones, diagrama de cableado, configuracibn bbsica del sistema, cable del freno de estacionamiento, configuracibn
de sistemas avanzados
o Se puede conectar al reproducer DVD (CX-DV700U),
monitor LCD en color/reproductor CD, DVD (CY-
VMD9000U), platina de video y otros aparatos.
Solution de problemas. 60
Donde obtener la ayuda del servicio de reparaciones, consejos para solucionar problemas
Mantenimiento . 62
Prevencibn de danos en el exterior del sistema, limpieza pasando suavemente un pano blando
Especificaciones. 63
8
mmm

Utilizacion segura de este producto
Durante el estacionamiento
• El estacionamiento bajo la luz solar directa puede pro¬
duce temperaturas muy altas en el interior del vehiculo
Permita que se enfne el interior del vehiculo antes de
encender el aparato
• No utilice el monitor con el motor apagado Esto con¬
sume energia de la bateria y puede impedir el arranque
del motor
Utilizacidn de la alimentacidn apropiada
• Este producto ha sido disenado para funcionar con un
sistema de bateria de 12 V con puesta a masa negativa
(el sistema normal en un vehiculo norteamericano)
Utilizacidn de los centros de servicio autorizados
• No mtente desarmar m ajustar este producto de alta
precision Consulte la lista de centros de servicio sum-
mistrada con este producto para solicitar el servicio
necesario
--->.
Instalacidn
• Ddnde y c6mo se instala este aparato cambia de
acuerdo con el modelo de vehiculo pertinente Por lo
tanto, la mformacidn contemda en esta guia de msta-
lacidn ha sido preparada para tnstaladores profe-
sionales, no para personas que carezcan de los
debidos conocimientos tecmcos
• Asegurese de instalar el monitor en una posicion
que no obstruya la vision del conductor
• Si el monitor ha sido mstalado para los pasajeros de
los asientos traseros, estos deben tener cuidado de
que sus cabezas no golpeen el monitor en caso de
producirse un accidente
• No instale el aparato en un lugar donde pueda
obstruir el funcionamiento de una bolsa de aire
• Pida a un t6cmco cualificado que mstale el aparato
La mstalaci6n y el cableado requieren preparacidn y
experience
Para su segundad, pida al comerciante a quien
adquirib el aparato que haga la instalacidn
_____J
Encuentre el numero de modelo y el numero de serie
en la parte posterior o inferior de la umdad Anbtelos en
el espacio de abajo y guarde este manual a modo de
prueba permanente de su compra, para que pueda uti-
lizarlo en el caso de que le roben la umdad
NUMERO DE MODELO _ CY-VM580QU
NUMERO DE SERIE _
FECHA DEADQUISICIQN _
VENDEUR
Durante el funcionamiento
• Asegurese de que el aparato no se caiga m reciba
golpes fuertes porque esto puede causar un fun¬
cionamiento defectuoso o un incendio
□ Cuidados para el panel de cristal
liquido
• No deje la superficie del panel de cristal liquido mirando
hacia arriba
Gama de temperaturas para guardar el aparato
-4°Fa 176 °F (-20 °Ca80 °C)
Cuando el panel de cristal liquido alcanza temperaturas
altas o bajas, se producen en 61 cambios quimicos que
pueden causar un funcionamiento defectuoso
• No golpee el panel de cristal liquido
• Cuando la temperatura sea muy fria o muy caliente, la
imagen tal vez no aparezca claramente o quiza se mueva
lentamente Ademas, en tales ambientes, el movimiento
de la imagen puede parecer que no esta smcromzado o
la calidad de la misma puede reducirse Tenga en cuen-
ta que esto no es mngun funcionamiento defectuoso o
problema
Gama de temperaturas para utilizar el aparato
32 °Fa 104 °F (0 °Ca40 °C)
• En la superficie del panel puede haber puntos rojos,
azules y verdes Esto constituye una caracteristica de
los paneles de cristal liquido y no supone mngun prob¬
lema El panel de cristal liquido se fabrica empleando
una tecnologia de alta precisidn, y dispone de un
99,99% de pixeles de imagen efectivos Tenga en cuen-
ta que en un 0,01% del panel podr6 haber pixeles que
falten o que esten constantemente encendidos
Puntos
1
■ M
VM58Q0U
4 .

Sffi^F^SGD
Bright button (BRIGHT)-
Used to adjust the screen brightness.
( ■ =* page 15)
Menu button (MENU)
Used to select the VTR input selection.
(«• page 13)
(on the bottom side).
[V4" (6 mm) unify screw, maximum length of 1 1 3 /i 6 " (4.5 mm)]
r
s
Note:
o This unit does not contain any speakers.

Remote Control Unit Preparation
Battery Installation (Inserting/Replacing the Batteries)
-i Remove the battery holder
Pull the holder by the position B while pushing position
A in the direction indicated by the arrow
p Install the battery on the battery holder
^ Set a new battery properly with its (+) side facing up as
shown in the figure
0 Insert the battery holder
Push in the battery holder back into its original position
Battery Notes
Lithium battery
(included)
Remove and dispose of an old battery immediately
Battery Information
• Battery type Panasonic lithium battery (CR2025) (included)
• Battery life Approximately 6 months with normal use (at room temperature)
C . .>|
Caution*
• Improper use of batteries may cause overheating, an explosion or ignition, resulting in injury or a fire
Battery leakage may damage the unit
v___/
® Do not disassemble or short the battery Do not throw a battery into a fire
• Keep batteries away from children to avoid the risk of accidents
• Be careful to the local disposal rules when you dispose of batteries
Control Reference Guide
Point the remote control unit at the remote sensor
Power button (PWR)
(=> page 12)
Menu button (MENU)
(=> page 13)
Aspect button (ASPECT)
(=» page 14)
Bright button (BRIGHT)-
(=* page 15)
Picture button (PICTURE)
(=> page 16)
Panasonic
Car AV
Select buttons (/v, v)
(=> pages 13,15,16)
Enter button (ENTER)
(=> pages 13,16)
m
‘VM5800U]
11
G9
SQB^fPSSCuD

G9
Sffi)<=>CP®SGu)
WARNING:
For safe driving, watching TV and video is available only in stopped condition with the
parking brake pulled. “WARNING” will be displayed while the parking brake is not
engaged.
.Press [POWER]
The STAND BY indicator lights is green
Press [POWER] again to switch off the power
The STAND BY indicator lights is red

Input Selection
< ■ \
• Select “VIDEO” when a mobile video deck, video camera or mobile DVD player is connected
• Select “NAVIGATION” when a navigation system is connected
l_1-
Press and hold [MENU] for more than
2 seconds
VTR INPUT SELECT
IW©§@ I
NAVIGATION
(^~|[~a~) DOWN/UP (ENTER) SELECT
Default VIDEO
© Press [a] or [v] to select an item
© Press [ENTER] to set
VTR INPUT SELECT
VIDEO
SMMMMB
( ▼ || A ) DOWN/UP [ENTER] SELECT
Note
• If no operation is performed for 10 seconds, the
menu display automatically disappears
LVM580QU]
13
<E>

©
Sffie=(P®S(ul
Press [ASPECT]
o Each time this button is pressed, the display size
changes as shown below
NORMAL FULL ZOOM JUST
NORMAL (Default)
o The conventional display image has a 4 to 3 ratio
of horizontal to vertical
o In this case, a blank area remains on the right and
left sides of the display
FULL
o The screen is extended horizontally as a whole to
the aspect ratio of 16 to 9
o The extension ratio is the same at any point of the
screen
ZOOM
o The screen is fully extended at the normal aspect
ratio of 4 to 3
o The top and bottom of the screen are slightly cut
JUST
o The screen is extended horizontally to the aspect
ratio of 16 to 9
o The extension ratio increases toward the right and
left ends of the screen
Note
o In some cases, the picture looks different from the
original one due to your selection of aspect
—
Cautions
© This is to remind you that compression or extension of the screen using the aspect ratio (screen mode)
changing function of this product for commercial purpose or viewing/listenmg by the public could infringe
on the rights of the author protected by the copyright law
© If you expand a normal picture (4 to 3) by using “JUST", “ZOOM” or “FULL” aspect the full of the screen,
you might not see the periphery of the picture, or you might see deformed picture Therefore, use the
“NORMAL” mode to see the original picture as the author intended it
14

©
S©
0
(P®SGuD

a
i
Press [PICTURE]
© Press [a] or [v] to select an item
© Press [ENTER] to set
(©(Lieges iLiwsa, i
BLACK LEVEL
CONTRAST
COLOR COLOR
TINT
TINT
END
END
( V II a) down/up [enter) select
C v || a ) DOWN/UP [ENTER] SELECT
Black Level
Default 0
Setting range -30 to +30
Contrast
Default 0
Setting range -30 to +30
*
Color
Default 0
Setting range -30 to +30
-i
r-
Tint
Default 0
Setting range -30 to+30
(
-'I
Select
BLACK LEVEL
L
J
( —
Select
CONTRAST
v _
- _ *
( -
Select
>
COLOR
c .
j
16
If 'it> l t. ill k t L-i. L 118 ju

0 Press [/v] or [v) to adjust
( 2 ) Press [ENTER] to set
CONTRAST
+ 15 1 1111 1 11 1 1 1 111 1 1 |i 111111
Adjust the black level if black and white are
reversed or the screen appears too white because
of the angle of viewing
CONTRAST
+1 5 iiiimmiiiii|iiiiiii|iiiim
-direction -(-direction
Decrease the contrast Increase the contrast
between black and white between black and white
COLOR
+ 15 ii ii i n ii i ii n i|i n km|i i ii ii i
-direction
Lighten the depth of
color on the display
+direction
Deepen the depth of color
on the display
TINT
+1 5 ..| n n ii iji n u 11
-direction
Emphasize red in the
color image
+direction
Emphasize green in the
color image
• To return to the regular mode, select “END” and
then press [ENTER]
• If no operation is performed for 10 seconds, the
menu display automatically disappears
[ENTER]
[v, a] I
[PICTURE]
[PICTURE]
PWR) (MENU))
J^f^ASPECT
[A, V]
[ENTER]
Panasonic
C»r AV

©
S©«=tP®S(I3
WARNING
The installation information is designed for experienced installers and is not intended
for non-technical individuals. It does not contain warnings or cautions of the potential
dangers involved in attempting to install this product.
Any attempt to install this product in a motor car by anyone other than a qualified
installer could cause damage to the electrical system and could result in serious per¬
sonal injury or death.
□ Overview
This product should be installed by a professional
(Please refer to the “WARNING” statement
above )
o Identify and label the car wires
o Connect the car wires to the wires of the power
connector
o Check the operation of the unit
If you encounter problems, please consult your
nearest professional installer
Caution.
oThis unit operates with a 12 V DC negative
ground auto battery system only Do not
attempt to use it in any other system Doing
so could cause serious damage
^>
□ Installation Hardware
No Item Diagram Q’ty
©
Connection cord
(Length 3 m)
1
<D
Clamp connector 1
Before you begin installation, look for the following
items which are packed with your unit
o Warranty Card Fill this out promptly
o Panasonic Servicenter List for Service Directory
Keep for future reference in case the unit needs
servicing
o Installation Hardware Needed for monitor set¬
ting

□ Before Installation
Warning
• Do not install the monitor in a location which
obstructs driving, visibility or which is prohibited
by applicable laws and regulations
If the monitor is installed in a location which
obstructs forward visibility or operation of the air
bag or other safety equipment or which interferes
with operation of the car, it may cause an acci¬
dent
• Never use bolts or nuts from the car’s safety
devices for installation
If bolts or nuts from the wheel, brakes or other
safety devices are used for installation of the mon¬
itor, it may cause an accident
• Attach the wires correctly
If the wiring is not correctly performed, it may
cause a fire or an accident In particular, be sure to
run and secure the lead wire so that it does not get
tangled with a screw or the moving portion of a
seat rail
• Use with 12 V DC negative ground car
This unit is only for use with a 12 V DC negative
ground car It cannot be used in large trucks or
diesel cars which are 24 V DC car If it is used in
the wrong type of car, it may cause a fire or an
accident
( -^
Cautions.
• Use the specified fuse
Be sure to always use the specified fuse If a
fuse other than the specified fuse is used, it
may cause a fire or an accident
• Do not damage the cord by pinching or
pulling it
Do not pull or damage the cord If the cord is
not treated properly, it will short out or be
severed and may cause a fire or an accident
□ Required Tools
You’ll need the following
12 V DC test Electrical tape Slide-cut
bulb pliers
□ Identify All Leads
The first step in installation is to identify all the car
wires you’ll use when hooking up your LCD monitor
As you identify each wire, we suggest that you label
it using masking tape and a permanent marker This
will help avoid confusion when making connections
later
Note.
• Do not connect the power connector until you
have made all connections If there are no plastic
caps on the hooking wires, insulate all exposed
leads with electrical tape until you are ready to use
them Identify the leads in the following order
Power Lead
If your car has a radio or is pre-wired for one
Cut the connector wires one at a time from the plug
(leaving the leads as long as possible) so that you
can work with individual leads
Turn on the ignition to the accessory position, and
ground one lead of the test bulb to the chassis
Touch the other lead of the test bulb to each of the
exposed wires from the radio connector plug Touch
one wire at a time until you find the outlet that caus¬
es the test bulb to light
Now turn the ignition off and then on If the bulb also
turns off and on, that outlet is the car power lead
If your car is not wired for an audio unit
Go to the fuse block and find the fuse port for acces¬
sory (ACC), or ignition (IGN)
[CQIV15800U]
19

S©
<=>
(P®SIID
(continued)
nil
□ Connect All Leads
Now that you have identified all the wires in the car,
you're ready to begin connecting them to the con¬
troller unit wires. The connection diagram (o pages
21, 22) shows the proper connections and color
coding of the leads.
We strongly recommend that you test the unit
before making a final installation.
You can set the unit on the floor and make tempo¬
rary connections to test the unit. Use electrical tape
to cover all exposed wires.
—
Important:
o Connect the red power lead last, after you
have made and insulated all other connec¬
tions.
i -J
Ground
Connect the black ground lead of the power connec¬
tor to the metal car chassis.
Power
Connect the red power lead to the correct car radio
wire or to the appropriate fuse port on the fuse
block.
If the LCD monitor functions properly with all these
connections made, disconnect the wires and pro¬
ceed to the final installation.
□ Final Installation
Lead Connections
Connect all wires, making sure that each connection
is insulated and secure. Bundle all loose wires and
fasten them with tape so they won’t fall down later.
Congratulations! After making a few final checks,
you are ready to enjoy your new auto LCD monitor.
□ Final Checks
1. Make sure that all wires are properly connected
and insulated.
2. Turn on the ignition to check the unit for proper
operation.
If you have difficulties, consult your nearest autho¬
rized professional installer for assistance.
clnstallation Example>
----- _____ >
Warning
o Where and how this unit is installed differs according to the car model concerned. As such, the informa¬
tion contained in this installation guide is designed for professional installers and is not intended for non¬
technical individuals.
V___
20
