Panasonic CY-VM6880H User manual

© 2003 Matsushita Electric Industrial Co., Ltd. All
rights reserved. Unauthorized copying and
distribution is a violation of law.
CY-VM6880H
6.5”W 1 DIN IN-DASH MONITOR
AUTOMOTIVE AFTERMARKET
Order No. ACED031204C3

1 FEATURES 2
2 REPLACING THE FUSE 2
3 MAINTENANCE 2
4 DIMENSIONS 2
5 WIRING CONNECTION 3
6 BLOCK DIAGRAM 4
7 TERMINALS DESCRIPTION 5
1 FEATURES
• • •
• 6.5 Inch TFT.
• • •
• Video input.
• • •
• 3 Video input .
• • •
• 1 Video output.
• • •
• 1 Remote output.
• • •
• PAL/NTSC Mode.
• • •
• Video-Cont,Side-Brake, Reverse input.
2 REPLACING THE FUSE
Be sure to use a fuse of the specified rating (3A) when
replacing a blown fuse. Fuses with higher capacity ratings,use
of any substitute, or connection without a fuse may result in a
fire hazard or damage to the unit.
3 MAINTENANCE
Your product is designed and manufactured to ensure a
minimum of maintenance. Use a soft cloth for routine exterior
cleaning. Never use benzine, or other solvent.
4 DIMENSIONS
8 PACKAGE AND IC BLOCK DIAGRAM 7
9 REPLACEMENT PARTS LIST (Unit) 10
10 EXPLODED VIEW (Unit) 14
11 WIRING DIAGRAM 15
12 SCHEMATIC DIAGRAM (Main Block) 19
13 SCHEMATIC DIAGRAM (Display Block) 21
14 SCHEMATIC DIAGRAM for printing with letter size 23
CONTENTS
Page Page
2
CY-VM6880H

5 WIRING CONNECTION
CY-VM6880H
3

6 BLOCK DIAGRAM
CY-VM6880H
4

7.1. Main Block
Ref.
No. Part No. Part Name & Description Remarks
U3 YEAM78F0058
Pin
No. Port Descriptions I/O Vol.(V)
1 P15 N.C. ----
2 P16 N.C. ----
3 P17 N.C. ----
4 Avss GND ----
5 P130 N.C. ----
6 P131 DIM(Dimmer Control) O 1.5
7AVref1 5V Power I 5
8 P70 RxD I 0
9 P71 TxD O 5
10 P72 N.C. ----
11 P20 N.C. ----
12 P21 N.C. ----
13 P22 N.C. ----
14 P23 N.C. ----
15 P24 OSDS(OSD IC Chip Select ) O 4.9
16 P25 N.C. ----
17 P26 OSDD(OSD IC Serial Data ) O 4.9
18 P27 OSDC(OSD IC Shift Clock ) O 4.9
19 P40 SW8(PWR Key) I 5
20 P41 SW7(ASPECT Key) I 5
21 P42 SW6(PICT Key) I 5
22 P43 SW5(BRIGHT Key) I 5
23 P44 SW4(MENU Key) I 5
24 P45 SW3(Down Key) I 5
25 P46 SW2(Up Key) I 5
26 P47 SW1(ENTER Key) I 5
27 P50 ZOOM Mode Select O 0
28 P51 JUST Mode Select O 0
29 P52 SIDE Mode Select O 0
30 P53 N.C. ----
31 P54 BP(Back Light Power
Control) O 5
32 P55 MP(Main Power Control) O 5
33 Vss1 GND ----
34 P56 N.C. ----
35 P57 N.C. ----
36 P60 SCL O 4.8
37 P61 SDA I/O 4.8
38 P62 N.C. ----
39 P63 N.C. ----
40 P64 N.C. ---- 0
41 P65 REM(Remote Output) O
42 P66 N.C. ----
43 P67 N.C. ----
44 P30 N.C. ----
45 P31 MBLK(Main Screen Blanking) 0
46 P32 N.C. ----
47 P33 N.C. ----
48 P34 N.C. ----
49 P35 N.C. ----
50 P36 N.C. ----
51 P37 N.C. ----
52 P120 REV(Reverse Sense) I 0
53 P121 N.C. ----
54 P122 N.C. ----
55 P123 ILS(ILLUMINATION Sense) I 0
56 P124 VIS(Video Control Input) I 0
57 P125 CTC(ChaneL Control C) O 0
58 P126 CTB(ChaneL Control B) O 0
59 P127 CTA(ChaneL Control A) O 0
60 RESET RST(RESET) I 5
61 P00 RMD(Remote Input Detect) I 4.8
62 P01 VSY(Vertical Sync) I
63 P02 SW0( Monitor open/close
SW) I 5.2
Ref.
No. Part No. Part Name & Description Remarks
64 P03 SBR(Side Brake Detect) 1.6
65 P04 CS(Composite Sync) I
66 P05 N.C. ---- 5
67 Vss0 GND ----
68 Vdd1 5V Power I 5
69 X2 Crystal Terminal 2 I
70 X1 Crystal Terminal 1 I
71 IC(Vpp) IC(Vpp) 0
72 XT2 N.C. ----
73 XT1 N.C. ----
74 Vdd0 5V Power I 5
75 AVref0 5V Power I 5
76 P10 Power Operating Range
Detect I
77 P11 N.C. ----
78 P12 N.C. ----
79 P13 N.C. ----
80 P14 N.C. ----
7.2. Display Block
Ref
.
No.
Part No. Part Name & Description Remarks
U7 YEAMTC200G02
I/O Vol.(V)
1 SYNC IN GND __ 0
2 HD IN HD Input I 0
3 SIDE 2 GND __ 0
4 SIDE 1 Side 1 Signal Input I 0
5 VD IN VD Input I 3.1
6 HD OUT Horizon Same Time Signal Out O 2.9
7 VD OUT Vertical Same Time Signal
Out O 3.1
8 BLK BLK Signal Output O 0
9VPOS3 Vertical Expression
Possition I 3.2
Cuts Terminal 3
10 VPOS2
(NC) __ __ __
11 VPOS1 Vertical Expression
Possition I 3.2
Cuts Terminal 1
12 ZOOM ZOOM Signal Input I 0
13 U/D (NC) __ __ __
14 POL Image Vertical Cuts Terminal
1O 1.6
15 INT/EXT GND I 0
16 CPV Gate Driver Clock Pals O 0.5
17 OEV3 Gate Output O 0
18 OEV2 Gate Output O 0
19 OEV1 Gate Output O 0
20 STV1 Gate Driver Seek Start Pals
1I/O 0
21 OEH Source Driver O 0
22 ZOOMC ZOOM Seting I 0.4
23 STH1 Source Start Pals 1 I/O 0
24 STH2 Source Start Pals 2 I/O 0
25 CPH3 Source Driver Clock Pals 3 O 1.6
26 STV2 Gate Driver Seek Start Pals
1I/O 0
27 CPH2 Source Driver Clock Pals 2 O 1.6
28 R/L Connection 3.3V I 3.2
29 CPH1 Source Driver Clock Pals 1 O 0
30 HDOT2 HDOT 1 Seting Input I 3.2
31 JUST (NC) __ __ __
32 POS SET Expression Possition Setting I 3.2
33 PD Phase Compared to Output
Terminal O 1.6
34 OVD (NC) __ __ __
35 A Vdd Power Terminal(Analog) 3V 3.2
7 TERMINALS DESCRIPTION
5
CY-VM6880H

Ref
.
No.
Part No. Part Name & Description Remarks
36 VCO I VCO Input Terminal I 1.5
37 VCO 0 VCO Output Terminal O 1.5
38 A GND Ground __ 0
39 RESET Reset Terminal I 3.5
Signal Input (4:3 Possition)
40 HDOT1 GND I 0
41 UONS Screen Pulling Extending I 0
Signal Input (4:3 Possition)
42 HPOS4
(NC) __ __ __
43 HPOS3
(NC) __ __ __
44 HPOS2 Horizon Expression Possition I 0
Cuts Terminal 3
45 HPOS1
(NC) __ __ __
46 PNI (NC) __ __ __
47 D Vdd Power Terminal(Analog) __ 3.2
48 D GND Ground Terminal (Digital) __ 0
6
CY-VM6880H

8.1. Main Block
8 PACKAGE AND IC BLOCK DIAGRAM
7
CY-VM6880H

8.2. Monitor Block
8
CY-VM6880H

9
CY-VM6880H

Ref.
No. Part No. Part Name & Description Remarks
1.IC’s and Transistors
MAIN BLOCK [E-4C902]
Q1 2SD2403T1 Transistor T
Q2 YEANC114YKT Transistor T
Q701 XN0438100L Transistor T
Q702 B1GKGDAA0001 Transistor T
Q703 B1GDCFJJ0025 Transistor T
Q704 YEAN2SJ506STR Transistor T
Q705 YEAN2SJ506STR Transistor T
Q706 B1GDCFJJ0025 Transistor T
Q707 B1GKGDAA0001 Transistor T
Q731 2SD601R Transistor T
U1 YEAMBD4729G IC T
U2 YEAMPJ78L05AC IC T
U3 YEAM78F0058 IC T
U4 YEAMM2267MT1 IC T
U5 YEAMBA7649AF IC T
U6 YEAMS24C02A IC T
U701 YEAMMB3775FP IC T
MONITOR BLOCK [E-4C903-1]
Q1 YEANRK7002 Transistor T
Q8 YEANRK7002 Transistor T
Q751 YEANIMZ1TX Transistor T
U3 AN2546FH-A IC T
U4 YEAMBA178M05 IC T
U5 YEAMM2107FT1 IC T
U6 YEAMNJM3414AM IC T
U7 YEAMTC200G02 IC T
U8 C0ZBZ0000432 IC T
U9 YEAM74LCX08FN IC T
U10 YEAM74LCX02FN IC T
U11 YEAMMB90099 IC T
U12 YEAMTC7W53FU IC T
SW/INVERTER BLOCK [E-4C903-2]
Q752 XN0438100L Transistor T
Q754 2SD2403T1 Transistor T
Q755 2SD2403T1 Transistor T
IR1 PNA4602M01MC IC T
2. Diodes
MAIN BLOCK [E-4C902]
D1 YEAD1SS355T1 Diode T
Ref.
No. Part No. Part Name & Description Remarks
D2 YEAD1N5404UT Silicon Diode T
D3 YEAD1SS355T1 Diode T
D200 YEAD1SS355T1 Diode T
D701 YEADSS14VZ Diode T
D731 B0JCMG000010 Diode T
D732 YEADSS14VZ Diode T
D733 YEADSS14VZ Diode T
D734 B0JCMG000010 Diode T
D99 YEAD1S40T Diode T
Z1 YEADUDZ56BT Zener Diode T
Z2 YEADUDZ56BT Zener Diode T
Z3 YEADUDZ56BT Zener Diode T
Z5 ERZG07DK220T1 ZNR T
Z6 YEADUDZ56BT Zener Diode T
Z7 YEADUDZ56BT Zener Diode T
Z8 YEADUDZ56BT Zener Diode T
Z9 YEADUDZ56BT Zener Diode T
Z701 YEADUDZS51BT Zener Diode T
MONITOR BLOCK [E-4C903-1]
D5 MA2X33800L Diode T
D6 YEAD1SS355T1 Diode T
D7 YEAD1SS355T1 Diode T
SW/INVERTER BLOCK [E-4C903-2]
D9 YEADRB501VT Diode T
D10 YEADRB501VT Diode T
D751 YEAD1SS355T1 Diode T
LD1 YEADSEC1401T Diode T
LD2 YEADSEC1401T Diode T
LD3 YEADSEC1401T Diode T
LD4 YEADSEC1401T Diode T
LD5 YEADSEC1401T Diode T
LD6 YEADSEC1401T Diode T
LD7 YEADSEC1401T Diode T
LD8 SML210VT LED (RED) T
LD9 SML210VT LED (RED) T
LD10 YEADSEC1401T Diode T
LD11 YEADSEC1401T Diode T
LD12 YEADSEC1401T Diode T
LD13 YEADSEC1401T Diode T
LD14 YEADSEC1401T Diode T
LD15 YEADSEC1401T Diode T
LD16 YEADSEC1401T Diode T
Z92 YEADUDZ56BT Zener Diode T
Z93 YEADUDZ56BT Zener Diode T
Z94 YEADUDZ56BT Zener Diode T
Z95 YEADUDZ56BT Zener Diode T
Z96 YEADUDZ56BT Zener Diode T
Z97 YEADUDZ56BT Zener Diode T
Z98 YEADUDZ56BT Zener Diode T
Z99 YEADUDZ56BT Zener Diode T
3.Capacitors
MAIN BLOCK [E-4C902]
C1 ECUV1C104KBV Ceramic 0.1MFD 16WV T
C10 ECUV1C105KBN Ceramic 1MFD 16WV T
C2 ECUV2A104KBM Ceramic 0.1MFD100WV T
C3 ECUV1C104KBV Ceramic 0.1MFD 16WV T
C4 ECUV1C104KBV Ceramic 0.1MFD 16WV T
C5 ECUV1C104KBV Ceramic 0.1MFD 16WV T
C6 ECUV1C105KBN Ceramic 1MFD 16WV T
C7 ECUV1C105KBN Ceramic 1MFD 16WV T
C8 ECUV1C105KBN Ceramic 1MFD 16WV T
C9 ECUV1C105KBN Ceramic 1MFD 16WV T
C11 ECUV1C105KBN Ceramic 1MFD 16WV T
C12 ECUV1C104KBV Ceramic 0.1MFD 16WV T
C13 YECUU1E106ZF Ceramic 10MFD 25WV T
C14 ECUV1H104KBV Ceramic 0.1MFD 50WV T
9 REPLACEMENT PARTS LIST (Unit)
10
CY-VM6880H

Ref.
No. Part No. Part Name & Description Remarks
C15 ECUV1H104KBN Ceramic 0.1MFD 50WV T
C16 ECUV1H330JCN Ceramic 33PF 50WV T
C96 ECUV1H104KBV Ceramic 0.1MFD 50WV T
C97 ECUV1H104KBV Ceramic 0.1MFD 50WV T
C98 ECUV1H104KBV Ceramic 0.1MFD 50WV T
C99 ECUV1H104KBV Ceramic 0.1MFD 50WV T
C100 ECUV1H104KBV Ceramic 0.1MFD 50WV T
C101 ECUV1H104KBV Ceramic 0.1MFD 50WV T
C701 ECUV1A225KBN Ceramic 22MFD 10WV T
C702 ECUV1C105KBN Ceramic 1MFD 16WV T
C703 ECUV1H104KBV Ceramic 0.1MFD 50WV T
C704 ECEV1CA100SR Electrolytic 47PF 16WV T
C705 ECUV1H103KBN Ceramic 0.01MFD 50WV T
C706 EEVFK1C221P Electrolytic 220MFD 16WV T
C707 EEVFK1C221P Electrolytic 220MFD 16WV T
C708 YECUU1H475KX Ceramic 4.7MFD 50WV T
C709 EEVFK1C101P Electrolytic 100MFD 16WV T
C710 YECUU1H475KX Ceramic 4.7MFD 50WV T
C711 YECUU1H475KX Ceramic 4.7MFD 50WV T
C712 EEVFK1C221P Electrolytic 220MFD 16WV T
C713 ECUV1H472KBV Ceramic 4700PF 50WV T
C714 YECUU1H475KX Ceramic 4.7MFD 50WV T
C715 EEVFK1C101P Electrolytic 100MFD 16WV T
C716 YECUU1H475KX Ceramic 4.7MFD 50WV T
C717 EEVFK1C101P Electrolytic 100MFD 16WV T
C718 EEVFK1C221XP Electrolytic 220MFD 16WV T
C719 ECUV1H104KBN Ceramic 0.1MFD 50WV T
C720 ECUV1C105KBN Ceramic 1MFD 16WV T
C721 ECUV1H103KBV Ceramic 0.01MFD 50WV T
C722 ECUV1H331KBV Ceramic 330PF 50WV T
C731 EEVFC1E330P Electrolytic 33MFD 25WV T
C732 ECUV1H104KBV Ceramic 0.1MFD 50WV T
C733 ECUV1H104KBV Ceramic 0.1MFD 50WV T
C734 EEVFC1E330P Electrolytic 33MFD 25WV T
C735 EEVFK0J221P Electrolytic 220MFD 6.3WV T
C736 ECUV1H104KBV Ceramic 0.1MFD 50WV T
C737 ECUV1H104KBV Ceramic 0.1MFD 50WV T
C738 EEVFK0J221P Electrolytic 220MFD 6.3WV T
C739 EEVFK0J221P Electrolytic 220MFD 6.3WV T
C740 ECUV1H104KBV Ceramic 0.1MFD 50WV T
C741 ECUV1H104KBV Ceramic 0.1MFD 50WV T
C742 EEVFK0J221P Electrolytic 220MFD 6.3WV T
C743 EEVFC1C470P Electrolytic 47MFD 16WV T
C744 ECUV1H104KBV Ceramic 0.1MFD 50WV T
C745 ECUV1H104KBV Ceramic 0.1MFD 50WV T
C746 EEVFC1C470P Electrolytic 47MFD 16WV T
C747 EEVFC1C470P Electrolytic 47MFD 16WV T
C750 ECUV1H103KBV Ceramic 0.01MFD 50WV T
C751 ECUV1H103KBV Ceramic 0.01MFD 50WV T
C752 ECUV1H103KBV Ceramic 0.01MFD 50WV T
C753 ECUV1H103KBV Ceramic 0.01MFD 50WV T
C754 ECUV1H103KBV Ceramic 0.01MFD 50WV T
C755 ECUV1H103KBV Ceramic 0.01MFD 50WV T
C756 ECUV1H103KBV Ceramic 0.01MFD 50WV T
C757 ECUV1H103KBV Ceramic 0.01MFD 50WV T
C760 ECUV1H104KBV Ceramic 0.1MFD 50WV T
E1 ECEA1VU101B Electrolytic 100PF 35WV T
E3 ECEA1CU471B Electrolytic 470MFD 16WV T
E4 ECEA1CKS101BV Electrolytic 100PF 16WV T
E6 ECEA1CKS101BV Electrolytic 100PF 16WV T
E7 ECEA0JKS101BV Electrolytic 100MFD 6.3WV T
E8 ECEA0JKS101BV Electrolytic 100MFD 6.3WV T
E9 EEVFK1C101P Electrolytic 100MFD 16WV T
MONITOR BLOCK [E-4C903-1]
C1 ECUV1H104KBV Ceramic 0.1MFD 50WV T
C8 ECUV1H104KBV Ceramic 0.1MFD 50WV T
C9 ECUV1H104KBV Ceramic 0.1MFD 50WV T
C10 ECUV1H104KBV Ceramic 0.1MFD 50WV T
C11 ECUV1H104KBV Ceramic 0.1MFD 50WV T
C12 ECUV1H104KBV Ceramic 0.1MFD 50WV T
C13 ECUV1H104KBV Ceramic 0.1MFD 50WV T
Ref.
No. Part No. Part Name & Description Remarks
C14 ECUV1H104KBV Ceramic 0.1MFD 50WV T
C15 ECUV1H104KBV Ceramic 0.1MFD 50WV T
C17 ECUV1H104KBV Ceramic 0.1MFD 50WV T
C18 ECUV1H470JCV Ceramic 47PF 50WV T
C19 ECUV1H821KBV Ceramic 820PF 50WV T
C20 ECUV1A225KBN Ceramic 22MFD 10WV T
C21 ECUV1E474KBN Ceramic 0.47MFD 25WV T
C22 ECUV1H223KBV Ceramic 0.022MFD 50WV T
C23 ECUV1H223KBV Ceramic 0.022MFD 50WV T
C24 ECUV1H223KBV Ceramic 0.022MFD 50WV T
C27 ECUV1H101KBV Ceramic 100PF 50WV T
C34 ECUV1C105KBN Ceramic 1MFD 16WV T
C35 ECUV1C105KBN Ceramic 1MFD 16WV T
C36 ECUV1C105KBN Ceramic 1MFD 16WV T
C38 ECUV1C105KBN Ceramic 1MFD 16WV T
C42 ECUV1C105KBN Ceramic 1MFD 16WV T
C43 ECUV1C105KBN Ceramic 1MFD 16WV T
C46 ECUV1H221KBV Ceramic 220PF 50WV T
C47 ECUV1C105KBN Ceramic 1MFD 16WV T
C48 ECUV1C105KBN Ceramic 1MFD 16WV T
C49 ECUV1C105KBN Ceramic 1MFD 16WV T
C50 ECUV1C105KBN Ceramic 1MFD 16WV T
C51 ECUV1C105KBN Ceramic 1MFD 16WV T
C52 ECUV1C105KBN Ceramic 1MFD 16WV T
C53 ECUV1C105KBN Ceramic 1MFD 16WV T
C55 ECUV1C105KBN Ceramic 1MFD 16WV T
C56 ECUV1H220JCV Ceramic 22PF 50WV T
C57 ECUV1H270JCV Ceramic 27PF 50WV T
C58 ECUV1A225KBN Ceramic 22MFD 10WV T
C59 ECUV1H103KBV Ceramic 0.01MFD 50WV T
C60 ECUV1H561KBV Ceramic 560PF 50WV T
C61 ECUV1A225KBN Ceramic 22MFD 10WV T
C64 YECUU1E106ZF Ceramic 10MFD 25WV T
C65 ECUV1H104KBV Ceramic 0.1MFD 50WV T
C66 ECUV1C105KBN Ceramic 1MFD 16WV T
C67 YECUU1H475KX Ceramic 4.7MFD 50WV T
C68 ECUV1H680JCV Ceramic 68PF 50WV T
C69 ECUV1H104KBV Ceramic 0.1MFD 50WV T
C70 ECUV1A225KBN Ceramic 22MFD 10WV T
C72 ECUV1A225KBN Ceramic 22MFD 10WV T
C73 ECUV1A225KBN Ceramic 22MFD 10WV T
C74 ECUV1C105KBN Ceramic 1MFD 16WV T
C75 ECUV1C105KBN Ceramic 1MFD 16WV T
C76 ECUV1A225KBN Ceramic 22MFD 10WV T
C77 ECUV2A104KBM Ceramic 0.1MFD100WV T
C79 YECUU1E106ZF Ceramic 10MFD 25WV T
C80 ECUV1A225KBN Ceramic 22MFD 10WV T
C81 ECUV1A225KBN Ceramic 22MFD 10WV T
C82 ECUV1A225KBN Ceramic 22MFD 10WV T
C95 ECUV1C105KBN Ceramic 1MFD 16WV T
C917 ECUV1H104KBV Ceramic 0.1MFD 50WV T
C918 EEVFK1C101P Electrolytic 100MFD 16WV T
C929 ECUV1H104KBV Ceramic 0.1MFD 50WV T
T6 YECSW1C226MS Tantal 22MFD 16WV T
T7 YECSW1A476MS Tantal 47MFD 10WV T
T9 YECSW1C226MS Tantal 22MFD 16WV T
T10 YECSW1A476MS Tantal 47MFD 10WV T
T11 YECSW1C226MS Tantal 22MFD 16WV T
SW/INVERTER BLOCK [E-4C903-2]
C37 ECUV1C105KBN Ceramic 1MFD 16WV T
C54 ECUV1C105KBN Ceramic 1MFD 16WV T
C63 YECUU1H475KX Ceramic 4.7MFD 50WV T
C78 YECUU1E106ZF Ceramic 10MFD 25WV T
C94 ECUV1H101KBV Ceramic 100PF 50WV T
C750 ECEV1AA101SP Electrolytic 100PF 10WV T
C756 ECHU1H184JC9 Ceramic 0.18MFD 50WV T
T2 YECSW1C226MS Tantal 22MFD 16WV T
T14 YECSW1C226MS Tantal 22MFD 16WV T
T
4. Resistors
11
CY-VM6880H

Ref.
No. Part No. Part Name & Description Remarks
MAIN BLOCK [E-4C902]
R1 ERJ3GEYJ302V Chip 3k ohms 1/16W T
R2 ERJ3GEYJ103V Chip 10k ohms 1/16W T
R3 ERJ3GEYJ103V Chip 10k ohms 1/16W T
R4 ERJ3GEY0R00V Chip 0 ohms 1/16W T
R5 ERJ3GEYJ103V Chip 10k ohms 1/16W T
R6 ERJ3GEYJ101V Chip 100 ohms 1/16W T
R10 ERJ3GEYJ102V Chip 1k ohms 1/16W T
R11 ERJ3GEYJ102V Chip 1k ohms 1/16W T
R12 ERJ3GEYJ102V Chip 1k ohms 1/16W T
R13 ERJ3GEYJ102V Chip 1k ohms 1/16W T
R14 ERJ3GEYJ473V Chip 47k ohms 1/16W T
R15 ERJ3GEYJ103V Chip 10k ohms 1/16W T
R16 ERJ3GEYJ512V Chip 5.1k ohms 1/4W T
R17 ERJ3GEYJ512V Chip 5.1k ohms 1/4W T
R18 ERJ3GEYJ512V Chip 5.1k ohms 1/4W T
R19 ERJ3GEYJ750V Chip 75 ohms 1/4W T
R20 ERJ6GEYJ750V Chip 75 ohms 1/10W T
R21 ERJ3GEYJ750V Chip 75 ohms 1/4W T
R22 ERJ3GEYJ750V Chip 75 ohms 1/4W T
R24 ERJ3GEYJ202V Chip 2k ohms 1/16W T
R25 ERJ3GEYJ202V Chip 2k ohms 1/16W T
R26 ERJ3GEYJ202V Chip 2k ohms 1/16W T
R27 ERJ3GEYJ302V Chip 3k ohms 1/16W T
R28 ERJ3GEYJ302V Chip 3k ohms 1/16W T
R29 ERJ3GEYJ302V Chip 3k ohms 1/16W T
R30 ERJ3GEYJ103V Chip 10k ohms 1/16W T
R31 ERJ3GEYJ303V Chip 30k ohms 1/16W T
R32 ERJ3GEYJ103V Chip 10k ohms 1/16W T
R33 ERJ3GEYJ103V Chip 10k ohms 1/16W T
R35 ERJ3GEYJ512V Chip 5.1k ohms 1/4W T
R99 ERJ3GEYJ103V Chip 10k ohms 1/16W T
R100 ERJ6GEY0R00V Chip 0 ohms 1/10W T
R101 ERJ6GEY0R00V Chip 0 ohms 1/10W T
R102 ERJ6GEY0R00V Chip 0 ohms 1/10W T
R103 ERJ6GEY0R00V Chip 0 ohms 1/10W T
R104 ERJ6GEY0R00V Chip 0 ohms 1/10W T
R105 ERJ6GEY0R00V Chip 0 ohms 1/10W T
R106 ERJ6GEY0R00V Chip 0 ohms 1/10W T
R107 ERJ6GEY0R00V Chip 0 ohms 1/10W T
R123 ERJ6GEY0R00V Chip 0 ohms 1/10W T
R124 ERJ6GEY0R00V Chip 0 ohms 1/10W T
R200 ERJ3ENF6801V Chip 6.8k ohms 1/16W T
R701 ERJ3GEYJ822V Chip 8.2k ohms 1/16W T
R702 ERJ3RBD202V Chip 2k ohms 1/4W T
R703 ERJ3GEYJ333V Chip 33k ohms 1/16W T
R704 ERJ3GEYJ153V Chip 15k ohms 1/16W T
R705 ERJ3ENF9101V Chip 820 ohms 1/16W T
R706 ERJ3ENF4700V Chip 470 ohms 1/16W T
R707 ERJ3GEYJ471V Chip 470 ohms 1/16W T
R708 ERJ3GEYJ271V Chip 270 ohms 1/16W T
R709 ERJ3GEYJ271V Chip 270 ohms 1/16W T
R710 ERJ3GEYJ471V Chip 470 ohms 1/16W T
R711 ERJ3GEYJ273V Chip 27k ohms 1/16W T
R712 ERJ3GEYJ333V Chip 33k ohms 1/16W T
R713 ERJ3GEYJ123V Chip 12k ohms 1/16W T
R714 ERJ3RBD392V Chip 3.9k ohms 1/4W T
R715 ERJ3RBD202V Chip 2k ohms 1/4W T
R716 ERJ3RBD222V Chip 2.2k ohms 1/4W T
R721 ERJ3GEYJ683V Chip 68k ohms 1/16W T
R722 ERJ12YJ0R33H Chip 0.33 ohms 1/2W T
R723 ERJ3GEYJ100V Chip 10 ohms 1/16W T
R724 ERJ12YJ0R47H Chip 0.47 ohms 1/2W T
R725 ERJ3GEYJ683V Chip 68k ohms 1/16W T
R731 ERJ3GEYJ103V Chip 10k ohms 1/16W T
R732 ERJ3GEYJ223V Chip 220 ohms 1/16W T
R750 ERJ3GEYJ101V Chip 100 ohms 1/16W T
R751 ERJ3GEYJ101V Chip 100 ohms 1/16W T
R752 ERJ3GEYJ101V Chip 100 ohms 1/16W T
R753 ERJ3GEYJ101V Chip 100 ohms 1/16W T
R754 ERJ3GEYJ101V Chip 100 ohms 1/16W T
R755 ERJ3GEYJ101V Chip 100 ohms 1/16W T
Ref.
No. Part No. Part Name & Description Remarks
R756 ERJ3GEYJ101V Chip 100 ohms 1/16W T
R757 ERJ3GEYJ101V Chip 100 ohms 1/16W T
T731 ETJ11K108AM Tranfer T
MONITOR BLOCK [E-4C903-1]
M1 YER14MNR301J Chip 300 ohms 1/16W T
M2 YER14MNR301J Chip 300 ohms 1/16W T
M3 YER14MNR301J Chip 300 ohms 1/16W T
R1 ERJ6GEYJ750V Chip 75 ohms 1/10W T
R3 ERJ3GEYJ471V Chip 470 ohms 1/16W T
R4 ERJ3GEYJ391V Chip 390 ohms 1/16W T
R5 ERJ3GEYJ224V Chip 220k ohms 1/16W T
R6 ERJ3ENF1002V Chip 10k ohms 1/16W T
R7 ERJ3GEYJ332V Chip 3.3k ohms 1/16W T
R8 ERJ3GEYJ105V Chip 1M ohms 1/16W T
R9 ERJ3GEYJ304V Chip 300k ohms 1/16W T
R10 ERJ3GEYJ752V Chip 7.5k ohms 1/16W T
R21 ERJ3ENF1002V Chip 10k ohms 1/16W T
R22 ERJ3ENF1002V Chip 10k ohms 1/16W T
R27 ERJ3GEYJ103V Chip 10k ohms 1/16W T
R28 ERJ3ENF1002V Chip 10k ohms 1/16W T
R29 ERJ3GEYJ103V Chip 10k ohms 1/16W T
R45 ERJ3GEYJ301V Chip 300 ohms 1/16W T
R46 ERJ3GEYJ301V Chip 300 ohms 1/16W T
R47 ERJ3GEYJ301V Chip 300 ohms 1/16W T
R48 ERJ3GEYJ301V Chip 300 ohms 1/16W T
R51 ERJ3GEYJ106V Chip 10M ohms 1/16W T
R52 ERJ3GEYJ5R1V Chip 5.1 ohms 1/4W T
R53 ERJ3GEYJ102V Chip 1k ohms 1/16W T
R54 ERJ3GEYJ470V Chip 47 ohms 1/16W T
R55 ERJ3GEYJ102V Chip 1k ohms 1/16W T
R56 ERJ3GEYJ102V Chip 1k ohms 1/16W T
R57 ERJ3GEYJ100V Chip 10 ohms 1/16W T
R58 ERJ3GEYJ100V Chip 10 ohms 1/16W T
R59 ERJ3GEYJ512V Chip 5.1k ohms 1/4W T
R60 ERJ3GEYJ105V Chip 1M ohms 1/16W T
R61 ERJ3GEYJ683V Chip 68k ohms 1/16W T
R62 ERJ3GEYJ683V Chip 68k ohms 1/16W T
R63 ERJ3GEYJ473V Chip 47k ohms 1/16W T
R64 ERJ3GEYJ473V Chip 47k ohms 1/16W T
R65 ERJ3GEYJ512V Chip 5.1k ohms 1/4W T
R68 ERJ3ENF6202V Chip 62k ohms 1/16W T
R70 ERJ3ENF2002V Chip 20k ohms 1/16W T
R71 ERJ3ENF1001V Chip 1k ohms 1/16W T
R72 ERJ3ENF2701V Chip 1.2k ohms 1/16W T
R76 ERJ3GEYJ122V Chip 1.2k ohms 1/16W T
R77 ERJ3GEYJ122V Chip 1.2k ohms 1/16W T
R78 ERJ3GEYJ122V Chip 1.2k ohms 1/16W T
R79 ERJ3GEYJ681V Chip 680 ohms 1/16W T
R80 ERJ3GEYJ681V Chip 680 ohms 1/16W T
R81 ERJ3GEYJ681V Chip 680 ohms 1/16W T
R82 ERJ3GEYJ202V Chip 2k ohms 1/16W T
R83 ERJ3GEYJ202V Chip 2k ohms 1/16W T
R84 ERJ3GEYJ202V Chip 2k ohms 1/16W T
R85 ERJ3GEYJ473V Chip 47k ohms 1/16W T
R86 ERJ3GEYJ474V Chip 470k ohms 1/16W T
R88 ERJ3GEYJ270V Chip 27 ohms 1/16W T
R92 ERJ3GEYJ101V Chip 100 ohms 1/16W T
R93 ERJ3GEYJ390V Chip39 ohms 1/16W T
R94 ERJ3GEYJ512V Chip 5.1k ohms 1/4W T
R95 ERJ3GEYJ393V Chip 39k ohms 1/16W T
R98 ERJ3GEYJ302V Chip 3k ohms 1/16W T
R100 ERJ3GEYJ101V Chip 100 ohms 1/16W T
R104 ERJ3GEYJ471V Chip 470 ohms 1/16W T
R105 ERJ3GEYJ471V Chip 470 ohms 1/16W T
R106 ERJ3GEYJ471V Chip 470 ohms 1/16W T
R107 ERJ3ENF5601V Chip 5.6k ohms 1/16W T
R108 ERJ6GEY0R00V Chip 0 ohms 1/10W T
R109 ERJ6GEY0R00V Chip 0 ohms 1/10W T
R120 ERJ6GEY0R00V Chip 0 ohms 1/10W T
R909 ERJ3GEYJ103V Chip 10k ohms 1/16W T
R910 ERJ3ENF2701V Chip 1.2k ohms 1/16W T
12
CY-VM6880H

Ref.
No. Part No. Part Name & Description Remarks
R911 ERJ3RBD222V Chip 2.2k ohms 1/4W T
SW/INVERTER BLOCK [E-4C903-2]
R30 ERJ3GEYJ221V Chip 220 ohms 1/16W T
R37 ERJ8GEYJ121V Chip 120 ohms 1/8W T
R38 ERJ8GEYJ121V Chip 120 ohms 1/8W T
R39 ERJ8GEYJ121V Chip 120 ohms 1/8W T
R67 ERJ3ENF1002V Chip 10k ohms 1/16W T
R75 ERJ3ENF1002V Chip 10k ohms 1/16W T
R74 ERJ3GEYJ101V Chip 100 ohms 1/16W T
R87 ERJ8GEYJ121V Chip 120 ohms 1/8W T
R88 ERJ3GEYJ270V Chip 27 ohms 1/16W T
R121 ERJ6GEY0R00V Chip 0 ohms 1/10W T
R151 ERJ8GEYJ121V Chip 120 ohms 1/8W T
R152 ERJ8GEYJ121V Chip 120 ohms 1/8W T
R153 ERJ8GEYJ121V Chip 120 ohms 1/8W T
R761 ERJ3GEYJ471V Chip 470 ohms 1/16W T
R762 ERJ3GEYJ152V Chip 1.5k ohms 1/16W T
R763 ERJ3GEYJ152V Chip 1.5k ohms 1/16W T
5.Connectors
MAIN BLOCK [E-4C902]
CN1 YEAE54104402 Connector T
CON1 YEAE4CCON013 Connector T
PROG1 YEAE4CCON047 Connector T
MONITOR BLOCK [E-4C903-1]
CN2 YEAE54104402 Connector T
CN3 YEAE54104402 Connector T
SW/INVERTER BLOCK [E-4C903-2]
CN4 YEAE54104402 Connector T
CN5 YEAE5243530 Connector T
CN751 YEAE4CCON019 Connector T
6. Electric Parts
SWITCHES
SW0 YEAS210300 Switch T
SW1 YEASPAE010 Switch T
SW2 YEASPAE010 Switch T
SW3 YEASPAE010 Switch T
SW4 YEASPAE010 Switch T
SW5 YEASPAE010 Switch T
SW6 YEASPAE010 Switch T
SW7 YEASPAE010 Switch T
SW8 YEASPAE010 Switch T
CRYSTAL
X1 YEXL4C419TT Crystal OSC T
X2 H0J357400043 Crystal T
ZZ443400009 Crystal T
COILS
L2 YELTH4N560KF Coil T
L3 FBK1608HM102 Coil T
L4 FBK1608HM102 Coil T
L5 FBK1608HM102 Coil T
F701 VLP0321A601T BDEB T
L702 YELQ104R330NC Coil T
L731 YELT03N470JT Coil T
L732 YELT03N100JT Coil T
L733 YELT03N100JT Coil T
L734 YELT03N101JT Coil T
DR1 YETQ012G126 Choke Coil T
L1 YELT03N270JT Coil T
L6 YELT03N101JT Coil T
Ref.
No. Part No. Part Name & Description Remarks
L7 YELT03N2R2JT Coil T
F1 FBK1608HM102 Coil T
L751 YELQ10S560M Coil T
T751 YETQ024C058V Choke Coil T
7. Accessories
PRINTING
YFM284C415ZA Operating Instructions T
INSTALLATION PARTS
BISKIT6880HC Screw Kit T
ZZBISVM6880HC Screw Kit T
YFG044C002ZA Rear Support Strap T
YAJ024C099ZA Power Connector T
8. Mechanical Parts
MISCELLANEOUS
F1 EE0007 Fuse, 3A T
1YFC024C634ZA Rear Panel T(4-B)
2YJT034C027ZA Screw (M2x8) T(4-C)
3RHD006TZA Screw T(4-C)
4YFX214C352ZA FPC Cover T(4-C)
5WYREK035FF Wire T(4-B)
6EDTCA32QKF LCD Panel For Monitor T(4-B)
7YEAEFPC022 FPC (40P U TYPE 80mm) T(4-B)
8YFE134C470ZA Button (PRINTING) T(4-A)
9YFE134C468ZA Sensor Covere T(3-B)
10 YFX214C803ZC Escape Case T(3-C)
11 YFC024C637ZA Front Panel T(4-A)
12 YFX994C104ZA Free Stop (L) T(3-B)
13 YFX994C105ZA Free Stop ® T(3-B)
14 YFX024C083ZA Tray Cover T(3-B)
15 YJT034C031ZA Screw (M2x5) T(3-B)
16 YEJS064C001 Screw(M3x3) T(3-B)
17 YFX994C064YA Earth (L) T(3-B)
18 YFX994C063YA Earth (R) T(3-B)
19 YFX214C301ZB Lock Panel ( L ) T(3-A)
20 YFX214C302ZB Lock Panel ( R ) T(2-B)
21 YFX994C067ZA Collar T(3-A)
22 YFS014C054ZA Scar Prevent Sheet T(2-C)
23 YFX994C093ZA Vibrate Tape T(2-C)
24 YFV014C062ZA Chassis Sheet T(3-C)
25 YFX054C063ZB Spring Plate (L) T(2-B)
26 YFX054C064ZB Spring Plate (R) T(2-C)
27 XSS5+8FXS Screw T(2-C)
28 XSB2+3FZ Screw (M2x3) T(3-A)
29 YFX214C299ZA Lock Panel T(3-A)
30 YFX214C300YA John Trepan T(2-A)
31 YFX014C068ZA O Washer T(2-A)
32 YFX054C054ZA Mechanics Lock Spring T(2-A)
33 YEAEFPC006 FPC (40P x 105mm) T(2-A)
34 YFV014C061ZA Insulator (TFT) T(1-A)
36 YFC054C062ZA Trim Plate T(1-A)
37 YFJ014C123ZA Badge Panel T(2-B)
38 YFX994C106ZA Panel Tape T(2-B)
39 YFC024C635ZA Escucheon T(2-B)
40 YFV014C069ZA Sheet T(2-B)
41 XUC3FN E Washer T(2-C)
42 YFX994C066ZB Lock Earth T(2-C)
43 YFX054C044ZA Lock Spring T(2-C)
44 YFA034C049ZA Upper Cover T(2-C)
45 XTN3+6FFX Tapping Screw 3 x 6mm T(2-C)
46 YFX214C355ZA Power Cord Bracket T(2-C)
47 YJS064C001ZB Screw T(1-C)
48 YFA054C039ZA Bottom Cover T(1-C)
49 AAPB903A0-2 SW/Inverter Assy T(4-
B)/RTL
50 AAPB903A0-1 Monitor PCB Assy T(2-
A)/RTL
51 AAPB902A0 Main PCB Assy T(2-C)
/RTL
13
CY-VM6880H

10 EXPLODED VIEW (Unit)
14
CY-VM6880H

11 WIRING DIAGRAM
11.1. Main Block-1
[E-4C902][TOP VIEW]
CY-VM6880H MAIN PCB
15
CY-VM6880H
