Panasonic PT53WX52F - 53" PROJECTION TV HD User manual

The service technician is required to read and follow the “Safety Precautions”and“Important Safety Notice” in the Main Manual.
Service Manual
Copyright 2002 by Matsushita Electric Corporation of
America. All rights reserved. Unauthorized copying
and distribution is a violation of law.
ORDER NO. MTNC020517A1
B2
®
(P7W)
Simplified Manual
Panasonic
PT-53WX52F EP824
PT-53WX52CF EP824
PT-53WX42F EP824
PT-56WX52F FP824
PT-56WX52CF FP824
PT-56WX42F FP824
Chassis
Models
HDTV MONITOR
“WARNING! This Service Manual is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to
service or repair the product or products dealt with in this Service Manual by anyone else could result in serious injury or death.”
This Simplified Service Manual is issued to add listed models to the Simplified Service Manual order
No.MTNC020411C1 (PT-47WX52F). Included in this manual are disassembly procedures, and a complete parts list for
the serviceable boards are included in this Simplified Manual. Please file and use this manual together with Simplified
Service Manual, order No. MTNC020411C1 (PT-47WX52F).
Simplified
PT-56WX52F

-2-
ServiceManual
Important safety notice
Special components are used in this projection television which are important for safety. These components are
identified on the schematic diagram by the symbol and printed in BOLD TYPE on the replacement part list. It is
essential that these critical parts are replaced with the manufacturer’s specified replacement part to prevent x-ray
radiation, shock, fire or other hazards. Do not modify the original design without the manufacturer’s permission.
Safety precautions
General guidelines
An isolation transformer should always be used
during the servicing of a PTV whose chassis is not
isolated from AC power line. Use a transformer of
adequate power rating as this protects the technician
from accidents resulting in personal injury from
electrical shocks. It will also protect the PTV from being
damaged by accidental shorting that may occur
during servicing.
When servicing, observe the original lead dress,
especially in the high voltage circuit. Replace all
damaged parts (also parts that show signs of
overheating.)
Always replace protective devices,suchas
fishpaper, isolation resistors and capacitors, and
shields after servicing the PTV. Use only
manufacturer’s recommended rating for fuses, circuits
breakers, etc.
High potentials, as high as 32.5kV, are present when
this PTV is operating. Operation of the PTV without the
rear cover introduces danger for electrical shock.
Servicing should not be performed by anyone who is
not thoroughly familiar with the necessary precautions
when servicing high-voltage equipment.
Extreme care should be practiced when handling the
picture tube . Rough handling may cause it to implode
due to atmospheric pressure. (14.7 lbs. per sq. in.). Do
not nick or scratch the glass or subject it to any undue
pressure. When handling, use safety goggles and
heavy gloves for protection. Discharge the picture
tube by shorting the anode to chassis ground (not to
the cabinet or to other mounting hardware). When
discharging connect cold ground (i.e. DAG ground
lead) to the anode with a well insulated wire or use a
grounding probe.
X-ray precautions
The front area (between the projection tube and the
lens) is enclosed by a metal box to ensure positive
safety during normal and abnormal conditions when
checking and repairing. To fully ensure safety, the
following precautions must be observed.
1. Do not remove the lens or metal box.
2. Make sure to turn the power OFF when the lens is
removed or when checking the cleanliness of the
lens.
3. Do not remove the lens or metal box to check the
projection tube for operation by watching it directly.
Use a mirror or paper to view the image.
Before returning a serviced PTV to the owner,the
service technician must thoroughly test the unit to
ensure that is completely safe to operate. Do not use a
line isolation transformer when testing.
Leakage current cold check
Unplug the AC cord and connect a jumper between the
two plug prongs. Press the POWER switch ON.
Measure the resistance between the jumpered AC plug
and expose metallic parts such as screw heads,
antenna terminals, control shafts, etc. If the exposed
metallic part has a return path to the chassis, the
reading should be between 240kΩ and 5.2MΩ. If the
exposed metallic part does not have a return path to
the chassis, the reading should be infinite.
Leakage current hot check (see figure 1)
Plug the AC cord directly into the AC outlet. Do not use
an isolation transformer during the check.
Connect a 1.5kΩ10 watt resistor in parallel with a
0.15µF capacitor between and exposed metallic part
and ground. Use earth ground, for example a
water pipe.
Using a DVM with a 1000 ohms/volt sensitivity or
higher, measure the AC potential across the resistor.
Repeat the procedure and measure the voltage
present with all other expose metallic parts.
Verify any potential does not exceed 0.75 volt RMS. A
leakage current tester (such a Simpson model 229,
Sencore model PR57 or equivalent) may be used in
the above procedure, in which case any current
measure must not exceed 0.5 milliamp. If any
measurement is out of the specified limits, there is a
possibility of a shock hazard and the PTV must be
repaired and rechecked before it is returned to
the customer.
Insulation test
Connect an insulation tester between an exposed
metallic part and AC line.
Apply 1080VAC/60Hz for 1 second. Confirm that the
current measurement is 0.5mA ~ 2.0mA. Repeat test
with other metallic exposed parts.
X-ray radiation
WARNING: The potential source of x-ray radiation in the
PTV is in the high voltage section and the picture tube.
Note: It is important to use calibrated equipment.
Apply all black video signals (1080i) and confirm high
voltage measures 31.5 ± 1.0kV. If the high voltage is
not within the range, change C514 to 1800pF, 2000pF,
2400pF or 2700pF until the desired value is obtained.
Apply NTSC white pattern and confirm the high voltage
measures 30.1 ± 1.5kV.
Apply HD 1080I white pattern and confirm the high
voltage measures 30.1 ± 1.5kV
0.15µF
Figure 1. Hot check circuit
COLD
WATER
PIPE
(GROUND)
TO INSTRUMENT’S
EXPOSED METAL
PARTS 1500Ω,10W
AC VOLTMETER

-3- ServiceManual
About lead free solder (PbF)
Note: Lead is listed as (Pb) in the periodic table of elements.
In the information below, Pb will refer to Lead solder, and PbF will refer to Lead Free Solder.
The Lead Free Solder used in our manufacturing process and discussed below is (Sn+Ag+Cu).
That is Tin (Sn), Silver (Ag) and (Cu) although other types are available.
This model uses Pb Free solder in it’s manufacture due to environmental conservation issues. For
service and repair work, we’d suggest the use of Pb free solder as well, although Pb solder may be
used.
PCBs manufactured using lead free solder will have the “PbF” or a leaf symbol stamped on the
back of PCB.
Caution
• Pb free solder has a higher melting point than standard solder. Typically the melting
point is 50 ~ 70 °F(30~40°C) higher. Please use a high temperature soldering iron
and set it to 700 ± 20 °F(370± 10 °C).
• Pb free solder will tend to splash when heated too high (about 1100 °For600°C).
If you must use Pb solder, please completely remove all of the Pb free solder on the
pins or solder area before applying Pb solder. If this is not practical, be sure to heat the
Pb free solder until it melts, before applying Pb solder.
• After applying PbF solder to double layered boards, please check the component side
for excess solder which may flow onto the opposite side. (see figure below)
Suggested Pb free solder
There are several kinds of Pb free solder available for purchase. This product uses Sn+Ag+Cu
(tin, silver, copper) solder. However, Sn+Cu (tin, copper), Sn+Zn+Bi (tin, zinc, bismuth) solder
canalsobeused.
component
component
pin
solder
excess solder
remove all of the
slice view
0.3mm X 100g 0.6mm X 100g 1.0mm X 100g

-4-
ServiceManual
Important safety tests
Measuring H.V.
The anode caps are cemented to the CRTs. To gain
access for high voltage measurement, remove the red
CRT’s anode lead from the flyback transformer
distributor. Grasp the anode lead protective cap at its
bottom and squeeze it against the locking cap body
inside, rotate 1/4 turn counter clockwise and pull the
anode lead sleeve out of the FBT distributor. Connect a
high voltage lead (+) from your H.V. meter to the FBT
distributor, and the common (-) to cold ground ( ).
(see figure 2).
Note: Reinsert the anode lead into the FBT
distributor until it is tightly and fully seated.
Turn the locking cap clockwise to lock in place.
(EHT) Protector operation check
With the cabinet back removed, apply a nominal 120V
AC to the PTV.
Over voltage test
Preparation:
1. Turn PTV “OFF”
2. Connect a NTSC signal generator to the
antenna terminal.
3. Connect DVM (+) TPD50 and (-) TPD51 on
D Board (see figure 4)
Figure 3. Measuring H.V.
4. Connect a H.V. meter (static type, class 0.1) with
high voltage leads to high voltage distributor
on FBT. (See figure 4)
Figure 4. DVM & power supply connection.
5. Connect the 15 ~ 25 V DC variable power supply to
(+) TPD8 or IC802 pin 2 (D-Board) and (-) heat
sink of Q551 (see figure 4).
Procedures:
1. Apply a NTSC white pattern.
2. Turn PTV ON.
3. Adjust the picture or brightness controls so that the
DVM reads 12.4 volts ± 0.4 volts.
4. Increase the variable power supply until set turns
off. The set should turn off at 12.4 volts ± 0.4 volts
(DVM) and high voltage less than 36.4kV.
5. If the DVM reading is other than 12.4 volts (± 0.4
volts), readjust picture or brightness control and
repeat steps 3.
6. Turn off the variable supply and confirm that the set
will turn on with the remote control.
Figure 2. Removal of FBT leads
FBT distributor
Anode lead
Grasp protective
rubber cap
Push & rotate
cap counter-
clockwise
to remove
Discharge to
CRT chassis
3
1
2
-
+
H.V. METER
FBT Distributor
CRT
CHASSIS
Cold ground
-
+
DVM
TPD51 TPD50 D-Board
Variable
power
supply (15~25DC)
(+)
(-)
IC802 PIN 2
HEAT SINK OF Q551
MA150 D-Board
100Ω 1/2 W
OR TPD8

-5- ServiceManual
Importantsafetynotice................... 2
Safetyprecautions........................ 2
Generalguidelines................. 2
X-rayprecautions.................. 2
Leakage current cold check . . . . . . . . . . 2
Leakage current hot check . . . . . . . . . . . 2
Insulationtest..................... 2
X-rayradiation .................... 2
About lead free solder (PbF) .............. 3
SuggestedPbfreesolder............ 3
Importantsafetytests.................... 4
MeasuringH.V. ................... 4
(EHT) Protector operation check . . . . . . 4
Servicenotes........................... 6
Leadless chip component. . . . . . . . . . . . 6
Componentremoval................ 6
Chip component installation . . . . . . . . . . 6
HowtoreplaceFlat-IC.............. 6
Featuretable........................... 8
Boardsdesignation...................... 9
PTV-Locationofcontrols............... 10
Quick reference control operation . . . . 10
ConvergenceAlignment................. 11
Convergence Alignment Template. . . . 11
Disassemblyforservice................. 12
PTVScreenPreparation............ 12
Placement of Screens in
PTVscreenframe ............. 13
Frame and Customer Control
PanelInstallation.............. 14
Cabinet back lower cover removal . . . . 15
Cabinet Top and Mirror
PanelInstallation.............. 17
Partslist........................ 18
AbbreviationsGuide............... 27

-6-
ServiceManual
Service notes
Leadless chip component
(surface mount)
Chip components must be replaced with identical chips
due to critical foil track spacing. There are no holes in
the board to mount standard transistors or diodes.
Some chip capacitor or resistor board solder pads may
have holes through the board, however the hole
diameter limits standard resistor replacement to 1/8
watt. Standard capacitor may also be limited for the
same reason. It is recommended that identical
components be used.
Chip resistor have a three digit numerical resistance code
- 1st and 2nd significant digits and a multiplier. Example:
162 = 1600 or 1.6kΩresistor, 0 = 0Ω (jumper).
Chip capacitors generally do not have the value
indicated on the capacitor. The color on the component
indicates the general range of the capacitance.
Chip transistors are identified by a two letter code. The
first letter indicated the type and the second letter, the
grade of transistor.
Chip diodes have a two letter identification code as per
the code chart and are a dual diode pack with either
common anode or common cathode. Check the parts
list for correct diode number.
Component removal
1. Use solder wick to remove solder from component
end caps or terminal.
2. Without pulling up, carefully twist the component
with tweezers to break the adhesive.
3. Do not reuse removed leadless or chip components
since they are subject to stress fracture during
removal.
Chip component installation
1. Put a small amount of solder on the board soldering
pads.
2. Hold the chip component against the soldering pads
with tweezers or with a miniature alligator clip and
apply heat to the pad area with a 30 watts iron until
solder flows. Do not apply heat for more than
3 seconds.
How to replace Flat-IC
- Required tools -
1. Cut the pins of the defective IC with the wire cutter
pliers, and remove it completely away from the
board. If the IC is glued to the board, apply hot air to
complete the removal. CAUTION- Do not pull or
twist the pliers, it may damage the soldering pads in
the board .
2. Using the soldering Iron and the long nose pliers,
remove the IC pins that are still attached to the
board.
3. Using the de-solder braid and the soldering Iron,
remove the solder from the board soldering pads.
4. Position the new flat IC in place (apply the pins of
the flat IC to the soldering pads where the pins need
to be soldered). Properly determine the positions of
the soldering pads and pins by correctly aligning the
polarity symbol. Start aligning and soldering Pin
No.1, then align and solder the pin in the apposite
corner of the IC, this will help to align the rest of the
pins.
5. Solder all pins to the soldering pads using a fine
tipped soldering iron.
6. Check with a magnifier for solder bridge between
the pins or for dry joint between pins and soldering
pads. To remove a solder bridge, use a de-solder
braid as shown in the figure below.
Note: These components are affixed with glue. Be careful not to break or damage any foil under the
component or at the pins of the ICs when removing. Usually applying heat to the component for
a short time while twisting with tweezers will break the component loose.
c
b
e
Chip components
TRANSISTOR CAPACITOR
RESISTOR
MH DIODE
SOLDER
CAPS
SOLDER
CAPS
1ST DIGIT 2ND DIGIT
MULTIPLIER
=1600 = 1.6k
GRADE
TYPE
COMMON
ANODES
CATHODE
c
b
e
• Soldering iron • De-solder braids
• Sharp pliers (wire
cutters and long nose) • Magnifier
Flat-IC
Soldering
Iron
De-Solder
Braid
Soldering
Iron
Polarity
symbol
Soldering
Iron
Solder
De-Solder
Braid
Solder
Bridge
Soldering
Iron

-7- ServiceManual
Service notes (continued)
IMPORTANT: To protect against possible damage to
the solid state devices due to arcing or static discharge,
make certain that all ground wires and CRT DAG wire
are securely connected.
CAUTION: The power supply circuit is above earth
ground and the chassis cannot be polarized. Use an
isolation transformer when servicing the PTV to avoid
damage to the test equipment or to the chassis.
Connect the test equipment to the proper ground (( )
or ( )) when servicing, or incorrect voltages will
be measured.
WARNING: This PTV has been designed to meet or
exceed applicable safety and x-ray radiation protection
as specified by government agencies and independent
testing laboratories.
To maintain original product safety design standards
relative to X-ray radiation and shock and fire hazard,
parts indicated with the symbol on the schematic
must be replaced with identical parts. Order parts from
the manufacturer’s parts center using the parts
numbers listed in this service manual, or provide the
chassis number and the part reference number.
For optimum performance and readability, all other
parts should be replaced with components of
identical specification.

-8-
ServiceManual
Feature table
FEATURE PT-53WX52F
PT-53WX52CF PT-53WX42F PT-56WX52F PT-56WX52CF PT-56WX42F
Chassis P7W
Number of channels 181
Menu language Eng/Span/Fr
Closed caption (CC) X
V-Chip (USA/CANADA) X
Picture in Picture (PIP) 2T split
VIDEO INPUT MEMORY/SKIP SKIP
2RF X
Remote control number EUR7603Z30 EUR7603Z40 EUR7603Z30 EUR7603Z40
Screen protector W/PROT SCRN W/O PROT
SCRN W/PROT SCRN W/O PROT
SCRN
Comb filter ADV 3D Y/C (NEW)
HEC/VEC (X=BOTH) X
Color temp X
NEW YNR X
VM X(DIGITAL)
V/A norm (X=BOTH) X
DIGITAL SCAN RATE 1080i, 480p
NTSC LINE-DOUBLER 480p SMOOTH PROGRESSIVE
AIP X
PRESET/INPUT LABELING X
Video Picture Memory X
MTS/SAP/DBX X
Bass/Bl/Treb control X
AI sound X
SURROUND X
Spatializer/BBE BBE
Built-in audio power 15WX2 (10%) 10WX2 (10%) 15WX2 (10%) 10WX2 (10%)
Numberofspeakers 4242
A/V in (rear/front) 4(3/1)
A/V PROGRAM OUT X
S-VHS in (rear/front) 2/1
Audio out Fixed & Variable
COMPONENT INPUT (Y, Pb, Pr) 2
Dimensions mm
WxDxH in 1247.7x634.4x1306.3 49.12x24.97x51.43 1316x849x1401 51.42x33.42x55.15
Weight (kg/lbs) 83/182.98 80.25/183.54 116/255.73 110/242.50
Power source (V/Hz) 120V 60Hz
Anode voltage 31.5kV±1.0kV
Video input jack 1Vp-p 75Ω, phono jack
Audio input jack 500mV RMS 47kΩ
Table 1: Feature Table
Specifications are subject to change without notice or obligation.
Dimensions and weights are approximate.

-9- ServiceManual
Boards designation
BOARD PART NUMBER BOARD DESCRIPTION
A-Board TNP2AH035 signal processing
D-Board TNPH0371 power and deflection
LB-Board TNP2AA110 blue driver
LG-Board TNP2AA111 green driver
LR-Board TNP2AA112 red driver
G-Board TNP2AA090 front A/V panel
K-Board TNP2AA089 front button panel
R-Board TNPA0615AB IR receiver
Table 2: Boards designation
Note: The A-Board ( TNP2AH035 ) is non-serviceable.Exceptfor
A-Board both tuners, IC1004, IC2302, IC7001, IC7002, IC7102,
IC871, IC872, IC873. If any of these components or board is
defective replace it with a new one and take back the defective
board to the service center.
Notice: When ordering any board, add and ” S” after the board
suffix application.
Example: If Order D-Board, should be ordered as:
TNPH0371 S.

-10-
ServiceManual
PTV - Location of controls
Figure 5. Location of controls PTV
Quick reference control operation
1 2 4 53
POWER VOLUME CHANNEL ACTION TV/VIDEO
PT-53WX52F
Quick reference control operation
Power - Press to turn ON or OFF.
Volume - Press to adjust sound level, or to adjust audio menus, video menus, and
select operating features when menus are displayed
Channel - Press to select programmed channels. Press to highlight desired features
when menus are displayed. Also use to select cable converter box channels after
programming remote control infra-red codes (the TV/AUX/CABLE switch must be set
in CABLE position).
Action - Press to display main menu and access on screen feature and adjustment
menus.
TV/Video - Press to select TV or one of the video inputs, for the main picture or the PIP
frame (when PIP frame is displayed).
1
2
3
4
5

-11- ServiceManual
Convergence alignment template
The convergence alignment template is a grid
approximatelythesizeoftheviewingscreenusedto
ensure the proper size and shape of the alignment
rasters. It is 6 blocks across by 6 blocks high. The grid
dimensions vary with the mode of operation.
Apply a convergence alignment template to the
viewing screen of the PTV. Make sure the center lines
are properly aligned. If a template is not available, one
can be created by following the instructions below.
Create a convergence alignment template by
drawing a pattern, as in figure 6, in the actual
dimensions on transparent film or tracing paper. Start
with the Horizontal and Vertical Center Axis and work
outwards until the pattern is complete. Pay attention to
the actual dimensions of the pattern.
Grid specifications 53” Models
Grid specifications 56” Models
Note: The convergence alignment templates, part
number TXFQD01FSER for 53” and
TXFQD04ESER1 for 56”, are available through
Matsushita/Panasonic Services.
Mode Horizontal Vertical
480i 48.6mm 22mm
1080i 45.2mm 23.5mm
Zoom 48.7mm 28.82mm
Template Dimensions: 1173mm v660 mm
Mode Horizontal Vertical
480i 51.5mm 27.3mm
1080i 47.9mm 24.9mm
Zoom 48.7mm 28.82mm
Template Dimensions: 1240mm v698mm
1
1
1
223
2
3
3
3
2
1
Center
Center
Figure 6. Convergence adjustment grid
Important note:
In order to prevent any possible damage on the
PRT’s (burning), do not keep the PTV turned on,
after you realize the adjustment.

-12-
ServiceManual
DISASSEMBLY FOR SERVICE
PTV SCREENS PREPARATION
(56WX MODELS ONLY)
Caution: The PTV screens are made of thin plastic and can be broken or scratched easily, if not handled
properly. Work in a clean and dust free environment to insure proper and trouble free installation. Use
lint free cotton gloves while assembling the PTV screens. Do not use abrasive solutions or solvents to
clean screen. If screen is dirty or spotty wipe with a soft, lint free cloth, dampened with glass cleaner or
a similar product to clean the surface.
Note: The alignment of the screens is vital for good picture. Make sure that proper screen orientation (top/
bottom & front/back) is observed while assembling the PTV screens.
Follow the procedure below for preparation and installation. Refer to figure 7 for further information.
1. Place the Fresnel screen (circular ridges) on
top of a cushioned surface.
2. Clean impurities off the surface using an air
gun.
3. If available, apply anti-static spray to the back
of the screen as illustrated in the figure below.
4. Apply a double adhesive tape to the top front
edge of the Fresnel screen as illustrated in the
figure below.
5. Place the lenticular screen (vertical ridges) on
top of a cushioned surface.
6. Clean impurities off the surface using an air
gun.
7. Apply a thin silicon to the back along the
horizontal and vertical edges.
8. Carefully position the lenticular screen over
the Fresnel screen.
9. Remove the protective film from the protective
screen.
10. Clean impurities off the surface using an air
gun.
11. Position the horizontal and vertical felt strips
on the protective screen as illustrated in the
figure below.
12. Apply the double sided adhesive tape to the
front upper side of the protective screen as
illustrated in the figure below.
13. Assemble the PTV screens in the order
illustrated in the figure below.
Figure 7. PTV Screen Preparation.
Fresnel Screen Fresnel Screen
Fresnel Screen
Lenticular Screen
Protective Screen Protective Screen Assembled Screen
Protective Screen
Lenticular Screen
Fresnel Screen
Double Adhesive
Tape
Felt (1465mm X 2)
Felt (835mm X 2) Double Adhesive
Tape
(Front View)
Spray
Location of P/N
300mm 500mm
(1470mm)
(1470mm)
Transparent Tape
(250mm)
(4-6in from screen)
Front
Rear

-13- ServiceManual
PLACEMENT OF SCREENS IN PTV SCREEN FRAME
(56WX MODELS ONLY)
Place the screens in the screen frame as indicate in figure 8. Make sure that all supports pieces are fully engaged
prior to attaching the PTV screen frame to the cabinet.
Figure 8. Placement of Screens in PTV Screen Frame.
Protective Screen
Lenticular Screen
Fresnel Screen
Screws (17)

-14-
ServiceManual
FRAME AND CUSTOMER CONTROL PANEL INSTALLATION
(56WX MODELS ONLY)
Note: Handle the PTV screen by holding it by its frame. Avoid scratching the delicate plastic screen.
Follow the procedure below to assemble the PTV screen and control panels to the cabinet.
1. Hold the screen assembly by its sides. Align
the sides of the PTV screen frame with the
cabinet. Lift and slightly tilt the screen and
place it over the front top edge of the cabinet.
Straighten the screen to a vertical position and
lower it until it locks into place. Screw the
bottom edge of the screen frame to the
cabinet with 3 screws as illustrated in figure 9.
2. Attach the control panel to the cabinet and
PTV screen using 3 screws, as illustrated in
thefigure9.
3. Connect the K & G boards cables to the
proper connectors.
Figure 9. Frame and Customer Controls Panel Installation.
Control Panel
Screws (3)
Screws (3)
Front Wood Filler (L)
K & G Boards

-15- ServiceManual
BACK LOWER COVER REMOVAL
53WX MODELS
Indicates screw to remove (10).
Figure 10. Back cover removal

-16-
ServiceManual
BACK LOWER COVER REMOVAL
56WX MODELS
Indicates screw to remove (10).
Figure 11. Back cover removal

-17- ServiceManual
CABINET TOP AND MIRROR PANEL INSTALLATION
(56WX MODELS ONLY)
Caution: The mirror is attached to the underside of the mirror panel. Use care not to damage the mirror. Work in
a dust free environment.
Follow the procedure below for installation. Refer to figure 12 for further instructions.
1. Attach an adhesive foam strip to the top back
cover, as illustrated in figure 12.
2. Secure the top back cover on the cabinet
using 5 screws, as illustrated in figure 12.
3. Carefully secure the mirror panel on the
cabinet using 6 screws, as illustrated in
figure 12.
Figure 12. Cabinet Top and Mirror Panel Installation.
Note: Mirror Panel and Top Back Cover are also
included in the Cabinet Wood, listed in Parts
List.
Screws (11)
Top Back Cover
Foam
Mirror Panel
Note: For Parts number, refer to
Replacement Parts List,
included in this Manual.

-18-
Parts List
REPLACEMENT PARTS LIST
Models: PT-53WX52F, PT-53WX52CF, PT-53WX42F, PT-56WX52F, PT-56WX52CF, PT-56WX42F.
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important for safety. When replacing
any of these components use only manufacturer’s specified parts.
130-02
PARTS LIST
REF
NO. PART NO. DESCRIPTION
CAPACITORS
C051 EEUFC1E470B CAP,E 47UF-25V
C052 ECKR1H103ZF5 CAP,C .01UF-Z-50V
C301 F2A2E100A025 CAP,E 10UF-250V
C302 ECCR1H221JC5 CAP,C 220PF-J-50V
C304 ECKW2H103PU8 CAP,C .01UF-P-500V
C305 F2A1H470A162 CAP,E 47UF-50V
C306 F2A2E100A025 CAP,E 10UF-250V
C307 ECKR1H103ZF5 CAP,C .01UF-Z-50V
C312 ECKC3D102KBN CAP,C 1000PF-K-2KV
C313 ECKR2H102KB5 CAP,C 1000PF-K-500V
C331 F2A1H470A162 CAP,E 47UF-50V
C332 ECKR1H103ZF5 CAP,C .01UF-Z-50V
C333 F2A1H470A162 CAP,E 47UF-50V
C334 F2A2E470A026 CAP,E 47UF-250V
C335 ECCR1H221JC5 CAP,C 220PF-J-50V
C336 F2A1H470A162 CAP,E 47UF-50V
C337 F2A2E470A026 CAP,E 47UF-250V
C339 ECKW2H103PU8 CAP,C .01UF-P-500V
C340 ECKR1H103ZF5 CAP,C .01UF-Z-50V
C341 F2A2E100A025 CAP,E 10UF-250V
C345 ECKC3D102KBN CAP,C 1000PF-K-2KV
C346 ECKR2H102KB5 CAP,C 1000PF-K-500V
C361 F2A1C101A159 CAP,E 100UF-16V
C362 ECCR1H221JC5 CAP,C 220PF-J-50V
C364 ECKW2H103PU8 CAP,C .01UF-P-500V
C365 F2A2E100A025 CAP,E 10UF-250V
C366 F2A1H470A162 CAP,E 47UF-50V
C367 ECKR1H103ZF5 CAP,C .01UF-Z-50V
C372 ECKC3D102KBN CAP,C 1000PF-K-2KV
C373 ECKR2H102KB5 CAP,C 1000PF-K-500V
C374 F2A1C101A159 CAP,E 100UF-16V
C405 F2A1E102A134 CAP,E 1000UF-25V
C406 F2A1E102A134 CAP,E 1000UF-25V
C407 TCJ2VF1H103Z CAP,C .01UF-Z-50V
C408 TCJ2VF1H103Z CAP,C .01UF-Z-50V
C411 TCJ2VB1H822K CAP,C 8200PF-K-50V
C412 ECQB1224KF3 CAP,P .22UF-K-100V
C413 F2A1H1R0A162 CAP,E 1.0UF-50V
C414 TCJ2VB1H272K CAP,C 2700PF-K-50V
C417 TCJ2VB1H103K CAP,C .01UF-K-50V
C418 ECQB1H183JF3 CAP,P .018UF-J-50V
C421 ECEA1CN220UB CAP,E 22UF-16V
C461 F2A1H221A162 CAP,E 220UF-50V
C501 F2A1V101A127 CAP,E 100UF-35V
C502 ECQV1H105JL3 CAP,P 1.0UF-J-50V
C503 ECKR2H102KB5 CAP,C 1000PF-K-500V
C509 ECWF2474JSR CAP,P .47UF-J-200V
C511 ECWH20222JVY CAP,P 2200PF-J-2KV
C512 ECWH20102JVY CAP,P 1000PF-J-2KV
C513 ECQF4103JZH CAP,P .01UF-J-400V
C514 ECWH20222JVY CAP,P 2200PF-J-2KV
C518 ECKW3D221JBP CAP,C 220PF-J-2KVDC
C519 ECKW3D221JBP CAP,C 220PF-J-2KVDC
C520 ECQB1H103JF3 CAP,P .01UF-J-50V
C522 ECWH20182JVY CAP,P 1800PF-J-2KV
C523 ECWH20182JVY CAP,P 1800PF-J-2KV
C524 ECQB1224JF3 CAP,P .22UF-J-100V
C525 ECEA1HN220UB CAP,E 22UF/50V
C526 F2A2E101A026 CAP,E 100UF-250V
C527 ECKR2H102KB5 CAP,C 1000PF-K-500V
C528 F2A1H470A162 CAP,E 47UF-50V
C531 ECA160V33UE CAP,E 33UF/160V
C532 ECQB1H103JF3 CAP,P .01UF-J-50V
C533 ECKR2H101KB5 CAP,C 100UF-K-500V
C535 F2A1H471A162 CAP,E 470UF-50V
C601 EEUFC1C331B CAP,E 330UF-16V
C602 TCJ2VF1H103Z CAP,C .01UF-Z-50V
C603 TCJ2VF1H103Z CAP,C .01UF-Z-50V
C605 F2A1H1R0A162 CAP,E 1.0UF-50V
C606 F2A1H1R0A162 CAP,E 1.0UF-50V
C608 ECQB1H103JF3 CAP,P .01UF-J-50V
C609 TCJ2VC1H820J CAP,C 82PF-J-50V
C610 ECQB1H473JF3 CAP,P .047UF-J-50V
C611 ECQV1H105JL3 CAP,P 1.0UF-J-50V
C613 F2A1C221A159 CAP,E 220UF-16V
C614 TCJ2VF1H103Z CAP,C .01UF-Z-50V
C616 ECQB1H104JF3 CAP,P .10UF-J-50V
C617 F2A1C221A159 CAP,E 220UF-16V
C618 TCJ2VF1H103Z CAP,C .01UF-Z-50V
C619 TCJ2YC1H272J CAP,C 2700PF-J-50V
C620 TCJ2VF1H103Z CAP,C .01UF-Z-50V
C621 ECQB1H681JF3 CAP,P 680PF-J-50V
C622 TCJ2VC1H221J CAP,C 220PF-J-50V
C623 ECQB1H473JF3 CAP,P .047UF-J-50V
C624 TCJ2VB1H152K CAP,C 1500PF-K-50V
C625 TCJ2VC1H820J CAP,C 82PF-J-50V
C627 ECQB1H183JF3 CAP,P .018UF-J-50V
C629 ECQV1H474JL3 CAP,P .47UF-J-50V
C631 ECSF1EE225VB CAP,E 2.2UF-25V
C632 TCJ2VF1H103Z CAP,C .01UF-Z-50V
C701 F2A1C221A159 CAP,E 220UF-16V
C702 ECKR3D271KBP CAP,C 270PF-K-2KV
C703 ECQM2104KZW CAP,P .1UF-K-200V
C704 ECKR2H391KB5 CAP,C 390PF-K-500V
C705 ECKR2H561KB5 CAP,C 560PF-K-500V
C707 TCJ2VF1H103Z CAP,C .01UF-Z-50V
C708 ECQE1685KFB CAP,P 6.8UF-K-100V
C801 ECQU2A104MNB CAP,P .10UF-M-250VAC
C802 ECQU2A823MNB CAP,P .082UF-M-250VAC
REF
NO. PART NO. DESCRIPTION

REPLACEMENT PARTS LIST
Models: PT-53WX52F, PT-53WX52CF, PT-53WX42F, PT-56WX52F, PT-56WX52CF, PT-56WX42F.
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important for safety. When replacing
any of these components use only manufacturer’s specified parts.
-19-
130-02
PARTS LIST
Parts List
C803 ECKCNA222ME7 CAP,C 2200PF-M-125V
C804 ECKCNA222ME7 CAP,C 2200PF-M-125V
C805 ECKR2H472PU7 CAP,C 4700PF-P-500V
C806 ECKR2H472PU7 CAP,C 4700PF-P-500V
C807 ECKR2H472PU7 CAP,C 4700PF-P-500V
C808 F2A1V101A127 CAP,E 100UF-35V
C809 TCJ2VB1E223K CAP,C .022UF-K-25V
C810 EETED2D102C CAP,E 1000PF-200V
C812 ECA1EHG471B CAP,E 470UF-25V
C814 ECKW3D102KBP CAP,C 1000PF-K-2KV
C815 ECQB1H152JF3 CAP,P 1500PF-J-50V
C816 ECKW3D821KBP CAP,C 820PF-K-2KV
C817 ECKW3D102KBP CAP,C 1000PF-K-2KV
C819 ECQB1H102JF3 CAP,P 1000PF-J-50V
C820 ECQV1H334JL3 CAP,P .33UF-J-50V
C821 ECQB1H272KF3 CAP,P 2700PF-K-50V
C822 F2A1H220A162 CAP,E 22UF-50V
C823 TCJ2VC1H151J CAP,C 150PF-J-50V
C824 EEUFC1V151B CAP,E 150UF-35V
C825 ECKCNA102MBB CAP,C .001UF-M-125V
C826 TCJ2VB1E104K CAP,C .1UF-K-25V
C830 EETHC2C471B CAP,E 470PF-160V
C831 ECKR3D821KBP CAP,C 820PF-K-2KV
C832 TCJ2VF1H103Z CAP,C .01UF-Z-50V
C834 EEUFC1V222E CAP,E 2200UF-35V
C836 ECKR3A331KBP CAP,C 330PF-K-1KVDC
C837 F2A1E472A135 CAP,E 4700UF-25V
C838 F2A1E471A134 CAP,E 470UF-25V
C839 ECKR3A331KBP CAP,C 330PF-K-1KVDC
C840 F2A1E471A134 CAP,E 470UF-25V
C841 F2A1E472A135 CAP,E 4700UF-25V
C842 ECKR3A331KBP CAP,C 330PF-K-1KVDC
C843 F2A1V222A128 CAP,E 2200UF-35V
C844 ECKR3A331KBP CAP,C 330PF-K-1KVDC
C845 F2A1V222A128 CAP,E 2200UF-35V
C846 ECKR3A331KBP CAP,C 330PF-K-1KVDC
C848 F2A1C101A159 CAP,E 100UF-16V
C849 ECKR1H223ZF5 CAP,C .022UF-Z-50V
C851 ECQV1H104JL3 CAP,P .10UF-J-50V
C852 F2A1V101A127 CAP,E 100UF-35V
C854 F2A1C221A159 CAP,E 220UF-16V
C855 TCJ2VB1E104K CAP,C .1UF-K-25V
C883 ECQV1H474JL3 CAP,P .47UF-J-50V
C890 TCJ2VF1H103Z CAP,C .01UF-Z-50V
C897 ECQV1H474JL3 CAP,P .47UF-J-50V
C898 TCJ2VF1H103Z CAP,C .01UF-Z-50V
C902 ECQM2103KZ3 CAP,P .01UF-K-200V
C903 ECKR1H103ZF5 CAP,C .01UF-Z-50V
C904 ECKR1H103ZF5 CAP,C .01UF-Z-50V
C906 ECQM2103KZ3 CAP,P .01UF-K-200V
REF
NO. PART NO. DESCRIPTION
C907 F2A2C100A023 CAP,E 10UF-160V
C908 F2A1C101A159 CAP,E 100UF-16V
C909 F2A1C101A159 CAP,E 100UF-16V
C910 F2A2C100A023 CAP,E 10UF-160V
C912 F2A1H220A162 CAP,E 22UF-50V
C939 ECKR1H103ZF5 CAP,C .01UF-Z-50V
C940 ECQM2103KZ3 CAP,P .01UF-K-200V
C941 ECKR1H103ZF5 CAP,C .01UF-Z-50V
C942 ECQM2103KZ3 CAP,P .01UF-K-200V
C943 F2A2C100A023 CAP,E 10UF-160V
C944 F2A1C101A159 CAP,E 100UF-16V
C945 F2A1C101A159 CAP,E 100UF-16V
C947 F2A2C100A023 CAP,E 10UF-160V
C962 ECKR1H103ZF5 CAP,C .01UF-Z-50V
C963 ECQM2103KZ3 CAP,P .01UF-K-200V
C965 ECKR1H103ZF5 CAP,C .01UF-Z-50V
C966 ECQM2103KZ3 CAP,P .01UF-K-200V
C967 F2A2C100A023 CAP,E 10UF-160V
C968 F2A1C101A159 CAP,E 100UF-16V
C969 F2A1C101A159 CAP,E 100UF-16V
C970 F2A2C100A023 CAP,E 10UF-160V
C972 F2A1H220A162 CAP,E 22UF-50V
C1502 ECQE6104KFB CAP,P 100UF-K-100V
C1503 ECQE6104KFB CAP,P 100UF-K-100V
C1504 ECQB1H103JF3 CAP,P .01UF-J-50V
C1505 F2A1C221A159 CAP,E 220UF-16V
C1506 TCJ2VF1H103Z CAP,C .01UF-Z-50V
C1508 ECQB1H223JF3 CAP,P .022UF-J-50V
C1510 TCJ2VF1H103Z CAP,C .01UF-Z-50V
C1511 TCJ2VC1H471J CAP,C 470PF-J-50V
C1512 TCJ2VF1H103Z CAP,C .01UF-Z-50V
C1513 ECEA1EN101UB CAP,E 100UF-25V
C1514 F2A1C101A159 CAP,E 100UF-16V
DIODES
D081 LN21RCPHL DIODE, LED
D082 MA4056MTA DIODE
D083 MA4056MTA DIODE
D301 MA167TA5 DIODE
D302 MA4150HTA DIODE
D303 TVSRM1V1 DIODE
D304 MA165TA5VT DIODE, SWITCHING
D306 MA165TA5VT DIODE, SWITCHING
D307 MA165TA5VT DIODE, SWITCHING
D312 MA188TA5 DIODE
D313 MA188TA5 DIODE
D314 MA188TA5 DIODE
D315 MA188TA5 DIODE
D331 MA165TA5VT DIODE, SWITCHING
D334 MA165TA5VT DIODE, SWITCHING
D335 MA165TA5VT DIODE, SWITCHING
REF
NO. PART NO. DESCRIPTION

-20-
Parts List
REPLACEMENT PARTS LIST
Models: PT-53WX52F, PT-53WX52CF, PT-53WX42F, PT-56WX52F, PT-56WX52CF, PT-56WX42F.
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important for safety. When replacing
any of these components use only manufacturer’s specified parts.
130-02
PARTS LIST
D339 MA188TA5 DIODE
D340 MA188TA5 DIODE
D341 MA188TA5 DIODE
D342 MA188TA5 DIODE
D361 MA165TA5VT DIODE, SWITCHING
D363 MA165TA5VT DIODE, SWITCHING
D364 MA165TA5VT DIODE, SWITCHING
D369 MA188TA5 DIODE
D370 MA188TA5 DIODE
D371 MA188TA5 DIODE
D372 MA188TA5 DIODE
D407 MA152KTX DIODE
D409 MA165TA5VT DIODE, SWITCHING
D410 MA152KTX DIODE
D411 MA165TA5VT DIODE, SWITCHING
D451 AM01ZV0 DIODE
D452 AM01ZV0 DIODE
D453 AM01ZV0 DIODE
D454 AM01ZV0 DIODE
D455 AM01ZV0 DIODE
D456 AM01ZV0 DIODE
D458 ERA15-01V3 DIODE, RECTIFIER
D501 D1NL40V70 DIODE
D502 MA4150MTA DIODE
D503 FMV-3GULF730 DIODE
D504 MA4270MTA DIODE
D509 MA165TA5VT DIODE, SWITCHING
D510 MA4068LTA DIODE
D511 ERA18-04V3 DIODE
D512 D1NL40V70 DIODE
D513 MA165TA5VT DIODE, SWITCHING
D515 D1NL40V70 DIODE
D516 EU2YXV0 DIODE
D519 AU02ZV0 DIODE
D634 MA165TA5VT DIODE, SWITCHING
D650 MA4110MTA DIODE, ZENER
D651 MA4110MTA DIODE, ZENER
D656 MA4110MTA DIODE, ZENER
D657 MA4110MTA DIODE, ZENER
D659 MA4110MTA DIODE, ZENER
D660 MA4110MTA DIODE, ZENER
D662 MA4110MTA DIODE, ZENER
D663 MA4110MTA DIODE, ZENER
D702 D1NL40V70 DIODE
D801 RBV-408 BRIDGE, RECTIFIER
D802 ERZC10VK361G VARISTOR
D815 MA165TA5VT DIODE, SWITCHING
D816 MA700TA DIODE
D817 AU01ZV0 DIODE
D818 MA3270LTX DIODE
REF
NO. PART NO. DESCRIPTION
D819 TMPG10G3 DIODE
D822 ERA22-02V3 DIODE
D825 FMLG16SLF116 DIODE
D827 RL4ZLF-J6 DIODE
D828 B0HBRM000012 DIODE
D829 B0HBRM000012 DIODE
D830 RL4ZLF-J6 DIODE
D831 RL4ZLF-J6 DIODE
D835 TVSA81004V3 DIODE
D837 MA152KTX DIODE
D895 MA165TA5VT DIODE, SWITCHING
D902 MA188TA5 DIODE
D933 MA188TA5 DIODE
D953 TVSSR2KNV DIODE, ZENER
D962 MA188TA5 DIODE
D973 TVSSR2KNV DIODE, ZENER
D983 TVSSR2KNV DIODE, ZENER
D1502 RP1H DIODE
D1503 MA4030HTA DIODE
D1504 RP1H DIODE
D1505 MA29-BTA DIODE
D1506 MA4051HTA DIODE
D1599 MA152KTX DIODE
FUSES
F801 XBA1C63NU100 FUSE 6.3A/125V
INTEGRATED CIRCUITS
IC451 LA78045 VERTICAL OUT
IC601 C0ZAZ0000091 HORIZONTAL OUT
IC602 TA8859AP VSAW
IC603 BA15218F-E2 OP AMP
IC701 AN6914 OP AMP
IC801 AN8029 MAIN REG
IC802 SE139NLF4 ERROR AMP
IC803 AN78L12TA 9V REGULATOR
IC804 TVSS1WBS20 DIODE, BRIDGE RECTIFIER
IC805 AN78M09LB 9V REGULATOR
IC811 0N3171RLF OPTO ISOLATOR
IC871 SI-8050J 5V REGULATOR
IC872 SI-8090J 5V REGULATOR
IC873 C0DAAZG00006 2.5V REGULATOR
IC880 AN78N12LB 12V REGULATOR
IC1501 AN6562S-E1 OP AMP
IC2302 TDA7490 AUDIO AMP L/R
IC7001 STK392-110 CONVERGENCE AMP
IC7002 STK392-110 CONVERGENCE AMP
IC1004 TVR2AJ128S MAIN EEPROM
IC7102 TVR2AJ139S CONVERGENCE EEEPROM
(ADJUSTED)
PT-53WX52F/CF
PT-53WX42F
REF
NO. PART NO. DESCRIPTION
