Panasonic TH-65LFB70E User manual

Service Manual
Touch Screen LCD Display
TH-65LFB70E
LA54 Chassis
© Panasonic Corporation 2014.
Unauthorized copying and
distribution is a violation of law.
ORDER No. PCZ1406138CE
There are special components used in this equipment which are important for safety. These parts are marked in the
Schematic Diagrams, Circuit Board Diagrams, Explorer Views and Replacement Parts List. It is essential that these
critical parts should be replaced with manufacturer´s specified parts to prevent shock, fire or other hazards. Do not
modify the original design without permission of manufacturer.
IMPORTANT SAFETY NOTICE
This service information is designed for experienced repair technicians only and is not designed for use by the general public. It does not
contain warnings or cautions to advise non-technical individuals of potencial dangers in attempting to service a product. Products
powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to service or repair the
product or products deal within this service information by anyone else could result in serious injury or death.
Warning

Contents
SAFETY PRECAUTIONS........................................... 3
GENERAL GUIDE LINES...................................... 3
TOUCH – CURRENT CHECK............................... 3
PREVENTION OF ELECTROSTATIC DISCHARGE
(ESD) TO ELECTROSTATICALLY SENSITIVE (ES)
DEVICES................................................................... 4
ABOUT LEAD FREE SOLDER (PBF)......................... 5
SUGGESTED PB FREE SOLDER........................ 5
SERVICE NAVIGATION............................................. 6
CHASSIS BOARD LAYOUT ................................. 6
SERVICE HINTS ........................................................ 7
APPLICABLE INPUT SIGNALS.................................. 8
SPECIFICATIONS.................................................... 10
SERVICE MODE ...................................................... 12
CAT (COMPUTER AIDED TEST) MODE................. 12
IIC MODE.................................................................. 12
CD MODE................................................................. 13
NW MODE................................................................ 14
SD MODE, MS MODE.............................................. 15
ID MODE................................................................... 16
IIC MODE STRUCTURE...........................................17
SELF CHECK ........................................................... 18
POWER LED BLINKING TIMING CHART................ 19
LCD PANEL TEST MODE........................................ 20
DIAGNOSIS FLOW CHART ..................................... 21
DIAGNOSIS OF TOUCH PANEL.............................. 22
WIRING DIAGRAM................................................... 23
BLOCK DIAGRAM (1 OF 3)..................................... 24
PARTS LOCATION................................................... 27
LOCATION OF LEAD WIRING................................. 31
REPLACEMENT PARTS LIST NOTE....................... 32
REPLACEMENT PARTS LIST.................................. 33
SCHEMATIC DIAGRAMS NOTE.............................. 88
A-BOARD (1 OF 24) SCHEMATIC DIAGRAM.......... 89
DS-BOARD SCHEMATIC DIAGRAM ..................... 113
HX-BOARD SCHEMATIC DIAGRAM ..................... 114
H1-BOARD SCHEMATIC DIAGRAM...................... 115
V1-BOARD SCHEMATIC DIAGRAM...................... 116
V2-BOARD SCHEMATIC DIAGRAM...................... 117
CONDUCTOR VIEWS............................................ 118
2

Safety Precautions
General Guide Lines
1. When servicing, observe the original lead dress. If a short circuit is found, replace all parts which have been overheated
or damaged by the short circuit.
2. After servicing, see to it that all the protective devices such as insulation barriers, insulation papers shields are properly
installed.
3. After servicing, make the following touch current checks to prevent the customer from being exposed to shock hazards.
Touch-Current Check
1. Plug the AC cord directly into the AC outlet. Do not use an isolation transformer for this check.
2. Connect a measuring network for touch currents between each exposed metallic part on the set and a good earth
ground such as a water pipe, as shown in Fig. 1.
3. Use Leakage Current Tester (Simpson 228 or equivalent) to measure the potential across the measuring network.
4. Check each exposed metallic part, and measure the voltage at each point.
5. Reserve the AC plug in the AC outlet and repeat each of the above measure.
6. The potential at any point (TOUCH CURRENT) expressed as voltage U1 and U2, does not exceed the following values:
For a. c.: U1 = 35 V (peak) and U2 = 0.35 V (peak);
For d. c.: U1 = 1.0 V,
Note:
The limit value of U2 = 0.35 V (peak) for a. c. and U1 = 1.0 V for d. c. correspond to the values 0.7 mA (peak) a. c. and
2.0 mA d. c.
The limit value U1 = 35 V (peak) for a. c. correspond to the value 70 mA (peak) a. c. for frequencies greater than 100
kHz.
7. In case a measurement is out of the limits specified, there is a possibility of a shock hazard, and the equipment should
be repaired and rechecked before it is returned to the customer.
Fig. 1
TO
APPLIANCES
EXPOSED
METAL PARTS
Resistance values in ohms ()
V
R0=500

RS=1500CS=0.22

F
10k
0.022

F
COLD
WATER PIPE
(EARTH GROUND)
V: Voltmetr or oscilloscope
(r.m.s. or peak reading)
Measuring network for TOUCH CURRENTS
Input resistance: 1M

Input capacitance:200pF
Frequency range: 15Hz to 1MHz and d.c.respectively
NOTE – Appropriate measures should be taken to obtain the correct value in case of non-sinusoidal waveforms
U2(V)
U1(V)
3

Prevention of Electrostatic Discharge (ESD) to Electrostatically
Sensitive (ES) Devices
Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are
called Electrostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect
transistors and semiconductor "chip" components. The following techniques should be used to help reduce the incidence of
component damage caused by electrostatic discharge (ESD).
1. Immediately before handling any semiconductor component or semiconductor-equipped assembly, drain off any ESD on
your body by touching a known earth ground. Alternatively, obtain and wear a commercially available discharging ESD
wrist strap, which should be removed for potential shock reasons prior to applying power to the unit under test.
2. After removing an electrical assembly equipped with ES devices, place the assembly on a conductive surface such as
aluminum foil, to prevent electrostatic charge build up or exposure of the assembly.
3. Use only a grounded-tip soldering iron to solder or unsolder ES devices.
4. Use only an anti-static solder removal device. Some solder removal devices not classified as "anti-static (ESD
protected)" can generate electrical charge sufficient to damage ES devices.
5. Do not use freon-propelled chemicals. These can generate electrical charges sufficient to damage ES devices.
6. Do not remove a replacement ES device from its protective package until immediately before you are ready to install it.
(Most replacement ES devices are packaged with leads electrically shorted together by conductive foam, aluminum foil
or comparable conductive material).
7. Immediately before removing the protective material from the leads of a replacement ES device, touch the protective
material to the chassis or circuit assembly into which the device will be installed.
Caution
Be sure no power is applied to the chassis or circuit, and observe all other safety precautions.
8. Minimize bodily motions when handling unpackaged replacement ES devices. (Otherwise harmless motion such as the
brushing together of your clothes fabric or the lifting of your foot from a carpeted floor can generate static electricity
(ESD) sufficient to damage an ES device).
There are special components used in this equipment which are important for safety.
These parts are marked by in schematic diagrams, exploded views and replacement parts list. It is essential that
these critical parts should be replaced with manufacturer’s specified parts to prevent shock, fire, or other hazards. Do
not modify the original design without permission of manufacturer.
IMPORTANT SAFETY NOTICE
4

About lead free solder (PbF)
Note: Lead is listed as (Pb) in the periodic table of elements.
In the information below, Pb will refer to Lead solder, and PbF will refer to Lead Free Solder.
The Lead Free Solder used in our manufacturing process and discussed below is (Sn+Ag+Cu).
That is Tin (Sn), Silver (Ag) and Copper (Cu) although other types are available.
This model uses Pb Free solder in it’s manufacture due to environmental conservation issues. For service and repair work,
we’d suggest the use of Pb free solder as well, although Pb solder may be used.
PCBs manufactured using lead free solder will have the PbF within a leaf Symbol
stamped on the back of PCB.
Caution
Pb free solder has a higher melting point than standard solder. Typically the melting point is 50 ~ 70 °F (30~40°C)
higher. Please use a high temperature soldering iron and set it to 700 ± 20 °F (370 ± 10 °C).
Pb free solder will tend to splash when heated too high (about 1100 °F or 600 °C).
If you must use Pb solder, please completely remove all of the Pb free solder on the pins or solder area before
applying Pb solder. If this is not practical, be sure to heat the Pb free solder until it melts, before applying Pb solder.
After applying PbF solder to double layered boards, please check the component side for excess solder which may
flow onto the opposite side. (see Fig.2)
Suggested Pb free solder
There are several kinds of Pb free solder available for purchase. This product uses Sn+Ag+Cu (tin, silver, copper) solder.
However, Sn+Cu (tin, copper), Sn+Zn+Bi (tin, zinc, bismuth) solder can also be used. (see Fig.3)
Fig.2
Fig.3
5

Service Navigation
Chassis Board Layout
Board Name Function
A-Board Main Processor, HDMI, DVI-D IN, PC-IN, Audio OUT / IN, Ethernet(LAN),
WIFI,COMPONENT/RGB-IN, SPI Flash, EEP memory,
DDR memory
V2-Board Key control, Power switch
V1-Board Remote Reciever, Power and Timer LED, C.A.T.S
P-Unit Power Supply, Main Input
H1-Board USB Terminal
HX-Board Speakers Out, PC Out, Audio IN, RS-232C input
DS-Board Slot Interface
P-UNIT
V2-BOARD
A-BOARD
H1-BOARD
HX-BOARD
DS-BOARD V1-BOARD
6

Service Hints
How to remove the backcover
Lay the main unit face down. (see Fig.4)
Remove the 44 fixing screws, 4 caps and backcover (see Fig.5)
Fig.4
SCREWS
(1) THEJ025 /30 pcs /
(2) THEL0429 /14 pcs /
(3) TKKL5493 /4 pcs /
(1) (1)
(1)
(1)
(2)
Fig.5
(1)
(2)
(2)
(1)
(1) (1) (1) (1) (1) (1) (1)
(3)(3)
(3)
(3)
(1)
(1)
(1)
(1)
(1)
(1)
(1)
(1) (1) (1) (1) (1) (1) (1) (1) (1)
(2)
(2)(2)
(2)
(2) (2) (2)
(2) (2) (2) (2)
(1)
7

Applicable Input Signals
*Mark: Applicable input signal
Signal name
Horizontal
frequency
(kHz)
Vertical
frequency
(Hz)
COMPONENT /
RGB IN/ PC IN
(Dot clock (MHz)
DVI-D IN
(Dot clock (MHz)
HDMI
1 525(480)/60i 15.73 59.94 *(13.5) *(27.0) *
2 525(480)/60p 31.47 59.94 *(27.0) *5 *(27.0) *
3 625(575)/50i 15.63 50.00 *(13.5)
4 625(576)/50i 15.63 50.00 *(27.0) *
5 625(575)/50p 31.25 50.00 *(27.0)
6 625(576)/50p 31.25 50.00 *(27.0) *
7 750(720)/60p 45.00 60.00 *(74.25) *(74.25) *
8 750(720)/50p 37.50 50.00 *(74.25) *(74.25) *
9 1,125(1,080)/60p 67.50 60.00 *(148.5) *1 *(148.5) *
10 1,125(1,080)/60i 33.75 60.00 *(74.25) *1 *(74.25) *
11 1,125(1,080)/50p 56.26 50.00 *(148.5) *1 *(148.5) *
12 1,125(1,080)/50i 28.13 50.00 *(74.25) *1 *(74.25) *
13 1,125(1,080)/24psF 27.00 48.00 *(74.25) *2
14 1,125(1,080)/30p 33.75 30.00 *(74.25) *1 *(74.25)
15 1,125(1,080)/25p 28.13 25.00 *(74.25) *1 *(74.25)
16 1,125(1,080)/24p 27.00 24.00 *(74.25) *1 *(74.25) *
17 1,125(1,080)/50i 31.25 50.00 *(74.25) *3
18 2,048x1,080/24psF *7 27.00 48.00
19 2,048x1,080/24p *7 27.00 24.00
20 640x400@70Hz 31.46 70.07 *(25.17)
21 640x480@60Hz 31.47 59.94 *(25.18) *6 *(25.18) *
22 640x480@72Hz 37.86 72.81 *(31.5)
23 640x480@75Hz 37.50 75.00 *(31.5)
24 640x480@85Hz 43.27 85.01 *(36.0)
25 800x600@56Hz 35.16 56.25 *(36.0)
26 800x600@60Hz 37.88 60.32 *(40.0) *(40.0) *
27 800x600@72Hz 48.08 72.19 *(50.0)
28 800x600@75Hz 46.88 75.00 *(49.5)
29 800x600@85Hz 53.67 85.06 *(56.25)
30 852x480@60Hz 31.47 59.94 *(33.54) *6 *(34.24) *
31 1,024x768@50Hz 39.55 50.00 *(51.89) *
32 1,024x768@60Hz 48.36 60.00 *(65.0) *(65.0) *
33 1,024x768@70Hz 56.48 70.07 *(75.0)
34 1,024x768@75Hz 60.02 75.03 *(78.75)
35 1,024x768@85Hz 68.68 85.00 *(94.5)
36 1,066x600@60Hz 37.64 59.94 *(53.0) *(53.0) *
37 1,152x864@60Hz 53.70 60.00 *(81.62) *
38 1,152x864@75Hz 67.50 75.00 *(108.0)
39 1,280x768@60Hz 47.70 60.00 *(80.14)
40 1,280x800@60Hz (1) 49.31 59.91 *(71.0) *(71.0) *
41 1,280x800@60Hz (2) 49.70 59.81 *(83.5) *(83.5) *
42 1,280x960@60Hz 60.00 60.00 *(108.0)
43 1,280x960@85Hz 85.94 85.00 *(148.5)
44 1,280x1,024@60Hz 63.98 60.02 *(108.0) *(108.0) *
45 1,280x1,024@75Hz 79.98 75.03 *(135.0)
46 1,280x1,024@85Hz 91.15 85.02 *(157.5)
47 1,366x768@50Hz 39.55 50.00 *(69.92) *
48 1,366x768@60Hz 48.36 60.00 *(86.71) *(87.44) *
49 1,400x1,050@60Hz 65.22 60.00 *(122.61) *
50 1,440x900@60Hz (1) 55.47 59.90 *(88.75) *(88.75) *
51 1,440x900@60Hz (2) 55.93 59.89 *(106.5) *(106.5) *
52 1,600x1,200@60Hz 75.00 60.00 *(162.0) *(162.0) *
53 1,600x1,200@65Hz 81.25 65.00 *(175.5)
54 1,920x1,080@60Hz 67.50 60.00 *(148.5) *4 *(148.5) *
55 1,920x1,200@60Hz 74.04 59.95 *(154.0) *
56 Macintosh 13‘‘ (640 x 480) 35.00 66.67 *(30.24)
57 Macintosh 16‘‘ (832 x 624) 49.72 74.54 *(57.28)
58 Macintosh 21‘‘ (1,152 x 870) 68.68 75.06 *(100.0)
8

*1: Based on SMPTE 274M standard.
*2: Based on SMPTE RP211 standard.
*3: Based on SMPTE 295M standard.
*4: The input signal is recognized as 1,125 (1,080) / 60p.
*5: When selected the RGB format and 525p signal input to the PC IN terminal, it is recognized as VGA 60 Hz signal.
*6: When inputted VGA 60Hz format signal from the other than PC IN terminal, it is recognized as 525p signal.
*7: Based on SMPTE 292M and 372M standards. These signals can be received when the Dual Link HD-SDI Terminal
Board (TY-FB11DHD) is installed.
Note: Signals without above specifications may not be displayed properly.
9

Specifications
Power Source: 220-240V AC, 50 / 60Hz
Rated Power Consumption: 215W
Stand-by Power Consumption: 0.5W
Operating Conditions: Temperature: 0°C 40°C
Humidity: 20% 80% RH (non condensing)
Applicable signals:
Colour System NTSC, PAL, PAL60, SECAM, Modified NTSC
Scanning Format 525(480) / 60i • 60p, 625(575) / 50i • 50p, 750(720) / 60p• 50p
1125(1080) / 60i • 60p • 50i • 50p • 24p • 25p • 30p • 24psF, 1250 (1080) / 50i
PC signal VGA, SVGA, XGA, SXGA, UXGA . . . . . (compressed)
Horizontal scanning frequency 15 - 110kHz
Vertical scanning freguency 48 - 120Hz
Terminals:
AV IN
VIDEO BNC 1.0 Vp-p (75)
AUDIO 1 IN Stereo mini jack (M3) x 1 0.5 Vrms, Shared with COMPONENT/RGB IN
HDMI 1 TYPE A Connector x 2
HDMI 2
COMPONENT/RGB IN
Y/G BNC with sync 1.0 Vp-p (75)
Pb/Cb/B BNC 0.7 Vp-p (75)
Pr/Cr/R BNC 0.7 Vp-p (75)
AUDIO 1 IN Stereo mini jack (M3) x 1 0.5 Vrms, Shared with VIDEO
DVI-D IN
DVI-D 24Pin Compliance with DVI Revision 1.0
Content Protection Compatible with HDCP 1.1
AUDIO 2 IN Stereo mini jack (M3) x 1 0.5 Vrms, Shared with PC IN
PC IN
High-Density Mini D-sub 15 Pin Y or G with sync 1.0 Vp-p (75)
Y or G without sync 0.7 Vp-p (75)
Pb/Cb/B: 0.7 Vp-p (75)
Pr/Cr/B: 0.7 Vp-p (75)
HD/VD: 1.0 – 5.0 Vp-p (high impedance)
AUDIO 2 IN Stereo mini jack (M3) x 1 0.5 Vrms, Shared with DVI-D IN
SERIAL External Control Terminal
D-sub 9 Pin RS-232C compatible
PC OUT R: 0.7 Vp-p (75)
G: 0.7 Vp-p (75)
B: 0.7 Vp-p (75)
HD/VD: 1.0 – 5.0 Vp-p
USB (VIEWER) TYPE A USB connector
USB (TOUCH) TYPE B USB connector
DIGITAL LINK / LAN For RJ45 network and DIGITAL LINK connections, compatible with PJLink™
Communication method: RJ45 100BASE-TX
EXT SP 8,20W [10W + 10W] (10% THD)
Sound:
Speakers 120mm x 40mm x 2pcs
Audio Output 20W [10W + 10W] (10% THD)
10

LCD screen: L5EDDYY00643
1920 x 1080, 16:9
Visible Diagonal 1638mm
Accessories supplied : Remote Control
2 x R6 (UM3) Batteries
2 xPen
Pen Tray
Eraser
USB Cable
Dimensions: Width: Height: Depth:
1,517mm 892mm 106mm
Mass: 58.0kg
Design and Specifications are subject to change without notice. Mass and dimensions shown are approximate.
This equipment complies with the EMC standards listed below:
EN61000-3-2, EN61000-3-3, EN55022, EN55024
11

Service Mode
CAT (Computer Aided Test) Mode
IIC Mode
Select the IIC mode by Up/Down buton on the remote control at the front page of CAT mode and then press the Action
button on the remote control.
1. Select the alignment Subject by Up/Down buttons
on remote control.
2. Select the alignment Item by Left/Right buttons
on the remote control.
3. Adjust optimum setting by Volume Up/Down buttons
on the remote control.
4. The data is memorized when press the R button
on the remote control or change the alignment
Subject (or Items).
Subject and Item are mentioned on “IIC mode structure”.
To exit the IIC mode, press the R button on remote control.
CAT panel sys. 8.2
IIC Mode
CD Mode
NW Mode
SD Mode
MS Mode
ID mode
Mode Function Access Button
IIC Mode Service Alignment Action
CD (Complete
Diagnostic) Software version information EEPROM edit Mute more than 3 seconds
NW Mode LAN terminal check Action
SD (Status Display) MTBF parameter Action
MS Mode Market Select Mute
more than 3 seconds
ID Mode LSI Check Mute
more than 3 seconds
Y 525/480)/60p
16:9 STANDARD Mid
LCD W/B Adj.
R Drive
FE FE
CAT mode menu
Remote Control
MUTE
VOL Up/Down
Up/Down
R
Left/Right
A
CTION
RECALL
How to access the CAT mode.
OSD
Subject
Item
New data
Original data
How to access the CAT mode.
Method A Main unit + remote control operation
Press and hold the button on the right side of the unit and press
the RECALL button on the remote kontrol 3 times quickly within 2
seconds, this will placet he unit into the CAT mode.
Method B Remote control operation only
1.Set OFF timer except fot [0] minute by OFF TIMER button.
(30 minutes, 60 minutes, 90 minutes)
2.Set the volume level of sound to 0 by VOL down button / -button.
3.Set the RECALL button more than 3 seconds before a volume
display disappears.
To exit CAT mode, turn the power off by main unit or a remote control.
12

CD Mode
Select the CD mode by Up/Down buton on the remote control at the front page of CAT mode and then press the Mute
button on the remote control more than 3 seconds.
Memory data change
To exit the CD mode, press the R button on the remote control.
About the serial number display
As for the serial number of A-module for repair, a dummy value is displayed.
* By the set for which A-module was exchanged, a serial number is displayed as [-----]
About the history display of SOS for the power supply system
This unit adds the history display (5 times) of power supply failure to the CD mode as PTCT.
By the self check of a signal system, only one history is displayed (After a self check disappears). But PTCT display
5 times of histories (Abnormality of the latest 3 times. First time and second time after shipment) and after a self
check does not disappear.
You can see a detailed history of power failure sometimes.
*About the display contents of PTCT
PTCT : The position of [05] is the first time after shipment.
PTCT : The position of [04] is the second time after shipment.
PTCT : The position of [03] is second from last time.
PTCT : The position of [02] is last time.
PTCT : The position of [01] is the latest.
In [Contents & Check point] of [6.1.2 Power LED Blinking timing chart], the two-digit following PTCT are displayed
by a hexadecimal number.
Blinking times Contents &Check point Display contents
Ex. 1 4 times PTCT 04 H09 04
Ex. 2 8 times PTCT 08 H029 08
0 0
A
ddress Change by Up/Down buttons on the remote control.
Change by Left/Right buttons on the remote control.
0 0
Data Change by VOL Up/Down buttons on the remote control.
The data is memorized when switch off the main power.
MONITOR-MCU(50inch) *.****LFB70 OK
MONITOR-EEPROM **.** * BB 73
MONITOR-EEPROM Change Addr 00 01
Data 01 01
MONITOR-FPGA **.**
MONITOR-FRC **
LAN MCU **.**/**.**
HD-BaseT **.**.***
TOUCH PANEL *.*.*.*
LAN-MAC (WIRED) **:**:**:**:**:**
LAN-MAC (WIRELESS) **:**:**:**:**:**
SLOT BOARD EEPROM -- -- -- --
SLOT BOARD --/--/-- -- -- --
SERIAL No **********
PTCT 01. 02. 03. 04. 05.
CD
Factory use
New data
Original data
SOS history
PTCT position: [01] [02] [03] [04] [05]
13

NW Mode
Note:
To use the network function, set each “Network Setup” setting and make sure to set the “Control I/F” to “LAN”
or “RS232C”
Select the NW mode by Up/Down buton on the remote control at the front page of CAT mode and then press the Action
button on the remote control.
*1: If you move a cursor to “Firmware” and press an Action button, “Only receiving side information display” and
“Receiving side / Transmitting side information simultaneous display” can be switched.
*2: The value of “Max Count” is resettable if you move a cursor to “Max Count” and press an Action button.
[Example of Receiving / Transmitting side information simultaneous display]
To exit the NW mode, press the R button on the remote control.
TEST OK
Version xx.xx/xx.xx
MAC(WIRED) xx:xx:xx:xx:xx:xx
MAC(WIRELESS) xx:xx:xx:xx:xx:xx
Control I/F Select xxxxxxxxxxxxxxx
DIGITAL LINK
Firmware xx.xx.xxx
Link Status No link
HDMI Status HDMI on
BER V_/A_/B_/C_
Max Count A X/B X/C X/D X
Est. Cable Length x (m)
Signal Quality
A - xx (dB)
B - xx (dB)
C - xx (dB)
D - xx (dB)
Min - xx (dB)
Max - xx (dB)
Model Name xxxxxxxx
NW
*1
*2
Press the Action button to start TEST (Check of Ping).
Check to show “OK” in TEST column.
If “G_NG” shows, it is failure for Ping process.
If “L_NG” shows, it is failure for Link process.
Software Version
DIGITAL LINK: Checking signal quality
Mac address
Control I/F Select
Link Status : Connection state
No link : No connection
DIGITAL LINK : In DIGITAL LINK operation
Ethernet : In Ethernal operation
HDMI Status : Display the information of HDMI ON/OFF and HDCP
No HDMI : Can not be recognized as a signal of the HDMI
HDMI on : Non HDCP HDMI signal
HDCP on : HDCP HDMI signal
Error ratio of the transmission path information
V : VIDEO BER
A : AUDIO BER
B : BLANK BER
C : CONTROL BER (Max: 10)
Standard of momentary signal quality aggravation
When it is over 64, the imagine may have broken off.
(Max: 255)
Signal Quality: Display the signal quality at the time of
DIGITAL LINK operation
OK/LOW/NG is displayed as each
Channel (A,B,C,D, Min, Max)
-12 dB or more : Normal receivable range
-11 to -8 dB : Partial damage of data (possible image output)
-7 dBor less : Synchronization disorder occurrence
(impossible image output)
TEST OK
Version xx.xx/xx.xx
MAC(WIRED) xx:xx:xx:xx:xx:xx
MAC(WIRELESS) xx:xx:xx:xx:xx:xx
Control I/F Select xxxxxxxxxxxxxxx
DIGITAL LINK
Firmware xx.xx.xxx / xx.xx.xxx
Link Status DIGITAL LINK/DIGITAL LINK
HDMI Status HDMI on / HDMI on
BER V_/A_/B_/C_/T_
Max Count A X/B X/C X/D X
Est. Cable Length x (m)
Signal Quality
A - xx (dB)
B - xx (dB)
C - xx (dB)
D - xx (dB)
Min - xx (dB)
Max - xx (dB)
Model Name xxxxxxxx
NW
T: total ber (Transmitting side)
Transmitting side information is displayed on right-hand side.
14

SD Mode
Select the SD mode by Up/Down button on the remote control at the front page of CAT mode and then press
the Action button on the remote control.
To exit the SD mode, press the R button on the remote control.
MS Mode
Select the MS mode by Up/Down button on the remote control at the front page of CAT mode and then press the Mute
button on the remote control more than 3 seconds.
To exit the MS mode, press the R button on the remote control.
Caution:
Market Select should be set after exchange of A-Board.
Destination number:
Number Destination
0 Japan
1 US(North America)
2 Europe
3 Asia,
Oceania,ME,Africa
18 China
Inputcommand
check
MTBF Parameter WT PT
TE
Condition
Sensor
SD
History of remote control command.
(Factory use).
Cumulative Time for power on condition. (unit :hour)
Temperature (unit :degrees)
OSD
** ** ** ** ** ** **
** ** ** ** ** ** **
** ** ** ** ** **
** **
+**
Counter of power on. (unit :time)
Market select **.** 2 2
MS Change by Left/Right buttons on the
remote control and press the action button
to confirm.
Present number
EEPROM data version
--- Illumination sensor value
* Counter of backlight OFF during abnormally high temperature(unit:time)
***
BL Backlight Limit Value
Remote Control Mode A B
15

ID Mode
Select the ID mode by Up/Down button on the remote control at the front page of CAT mode and then press the Mute
button on the remote control more than 3 seconds.
To exit the ID mode, press the R button on the remote control.
A H90MEM1 OK DS H51RTC OK
H65AVSW OK
H61ADV OK
H62TEMP OK
H63CPG OK
H66HDMIRX OK
H93LAN OK
H92MEM2 OK
H56LVDSRX OK
H67DLK OK
H68FRC OK
ID IIC1 IIC2 IIC3 IIC4
16

IIC Mode Structure
(following items value is sample data)
Panel W/B Adj. R DRIVE
FE G DRIVE
FC B DRIVE
FA
by left / right button
DIGITAL LINK Update
by up / down button
Update Not
Ready Update Ready
EDID Write Protect Protect
Front Panel key Check
PICTURE Sub Adjust
White + Time, Temperature
WHITE
RED
GREEN
BLUE
BLACK
Key Check --
TEMP CONTROL Adj
Main Contrast1
0 R sub Bright1
0 G sub Bright1
0
Chroma Control GUN OFF
0
Pos./Size H Position
81 V Position
80 H Size
80
B DRIVE
00
Aging Panel Color
These are selected by Action buton of Remote control and press the R button to exit.
B sub Bright1
0
Threshold Temp
52 Offset Temp
3
WHITE Ramp
RED Ramp
GREEN Ramp
BLUE Ramp
Color Bar
Scrolling Vertical Window
17

Self Check
Display Indication
1. Self check is used to automatically check the bus line controlled circuit of the LCD display.
2. To get into the Self check mode, press the volume down button on the customer controls at the right side of the set, at the
same time pressing the OFF TIMER button on the remote control, and the screen will show.
Method A Self-Check only ( A shipment setup is not carried out )
Select ID mode by UP/Down button on the remote control at the front page of CAT mode and then press the Mute button
on the remote control more then 3 seconds.
Method B Self-Check + Shipment setup
Press and hold the volume down button on the right side of the unit and press the OFF-TIMER button on the remote
control.
If the IIC ports have been checked and found to be incorret, or not located then “- -” will appear in place “OK”
“01” in the lie of the “PTCP” means the number of blinks of the Power LED is 1. (Reference_Power LED blinking timing
chart)
“H09” in the line of the “PTCP” is the error code
To exit the CAT mode switch off the main power.
Note:
The line of the “PTCP” display when you get into the Self check mode for first time only after the Power LED blinks.
A H90MEM1 OK DS H51RTC OK
H65AVSW OK
H61ADV OK
H62TEMP OK
H63CPG OK
H66HDMIRX OK
H93LAN OK
H92MEM2 OK
H56LVDSRX OK
H67DLK OK
H68FRC OK
ID IIC1 IIC2 IIC3 IIC4
18

Power LED blinking timing chart
1. Subject
Information of LED Flashing timing chart.
2. Contents
When abnormality has occurred the unit, the protection circuit operates and reset to the stand by mode. At this time, the
defective block can be identified by number of blinking of the Power LED on the front panel of the unit.
Blinking times Contents & Check point Check point
1 PTCT 01 H09]*
PANEL SOS LCD PANEL
2
(PTCT E2 H09)*
POWER SOS P-Board
A-Board
(PTCT 04 H09)*
POWER SOS
4 (PTCT 04 H09)
PANEL 12V SOS A-Board LCD Panel
8 (PTCT 0A H09)
FRC SOS A-Board
10 (PTCT 0B H09)*
FAN SOS DS-Board SLOT Board
11 (PTCT 0B H09)
FAN SOS FAN A-Board
13
(PTCT 0D H09)*
REGULATOR SOS (A2 SOS)
A-Board
(PTCT 1D H09)*
REGULATOR SOS (5V SOS)
(PTCT 2D H09)*
REGULATOR SOS (A2 SOS)
(PTCT 4D H09)*
AUDIO SOS
19

LCD Panel test mode
The failure-diagnosis by LCD Panel test mode
To find the possible failure point where in LCD Panel or Printed Circuit Board when the abnormal picture is displayed.
How to display the test pattern:
(A) Main unit + remote control operation
1. While pressing [VOLUME (-)] button of the main unit, press [R] button of the remote control three times within 2 seconds.
2. Test pattern is displayed and Power LED lights red and orange alternately.
How to Exit: Turn off the unit.
(B) Remote control only
1. Press [Recall] button of the remote control.
2. Press [R] button of the remote control.
3. Press [N] button of the remote control for over 3 seconds.
4. Test pattern is displayed and Power LED lights red and orange alternately.
How to Exit: The unit automatically turns off after around 10 seconds.
[Display pattern]
It is unfixed from which color it starts.
WHITE MAGENTA YELLOW CYAN BLACK
20
