Panasonic i-Pro WV-SP302 User manual

SVGA/800 x 600 H.264 Network Camera
Key Features
• Super high resolution at SVGA/800 x 600 created by newly
developed 1.3 Megapixel high sensitivity MOS Sensor
• Multiple H.264 (High profile) streams and JPEG streams ensure
simultaneous real time monitoring and high resolution recording by
“UniPhier®”, Panasonic’s proprietary System LSI platform.
• Full frame (Up to 30 fps) transmission at SVGA/800 x 600 image size
• Wide Dynamic Range and ABS (Adaptive Black Stretch) technologies
deliver wider dynamic range compared with conventional cameras.
• Face Wide Dynamic Range technology ensures clear face image.
• H.264 and MPEG-4 are selectable for system migration.
• High sensitivity with Simple Day/Night function: 0.2 lx (Color), 0.13 lx
(B/W) at F1.4
• VIQS (Variable Image Quality on Specified area) technology allows
the designated area to retain higher image quality while the
excluded area will have a decreased image quality, which enables to
use lower image file size and bit rate.
• Focus Assist ensures easy installation.
• Digital Noise Reduction: 3D-DNR ensures noise reduction in various
conditions.
• Progressive scan ensures clear images with less motion blur and no
tearing even when the subject is moving.
• Superior color reproduction by primary (RGB) color filter
• Electronic sensitivity enhancement: Auto (Up to 16x) / OFF
• Selectable light control modes: Outdoor / Indoor / ELC / Fixed electronic shutter
Outdoor / Indoor: Electronic shutter and ALC lens iris control are
automatically controlled depending on the mode and luminance level.
ELC: Up to 1/10,000 Electronic shutter is automatically applied for
a fix iris lens.
Fixed electronic shutter: Up to 1/10,000 fixed electronic shutter
can be selectable.
• VMD (Video Motion Detector) with 4 programmable detection areas,
15 steps sensitivity level and 10 steps detection size
• Meta data for VMD is supplied to work with the WJ-ND400
playback VMD function.
• Privacy Zone can mask up to 2 private areas, such as house
windows and entrances/exits.
• 2x extra zoom at VGA resolution
• 2x, 4x digital zoom controlled by browser
Lens: optional
• Camera title display: Up to 20 alphanumeric characters on the
browser, Up to 20 alphanumeric characters embedded in the image
• Alarm sources including 1 terminal input, VMD and Panasonic alarm
command can trigger actions such as SDHC/SD memory recording,
FTP image transfer, E-mail notification, Indication on browser, Alarm
terminal output, and Panasonic protocol output.
• Full duplex bi-directional audio allows interactive communication
between camera site and monitoring site.
• JPEG Image compression ratio can be changed by alarm so that
higher quality image can be provided.
• Prioritized stream control: One of the video streams can be prioritized
when multiple recorders or client PCs are accessing the camera so
that the recorder or the client PC can maintain the frame rate.
• SDHC/SD Memory card slot for manual recording (H.264 / JPEG), alarm
recording (H.264 / JPEG) and backup upon network failure (JPEG)
• H.264/MPEG-4 max. bit rate/client and Total bit rate control allows
flexible network traffic management. Frame rate priority mode controls
bit rate and compression ratio to provide the specified frame rate.
• Alarm log, Manual REC log, FTP error log saved in the SDHC/SD memory
card is displayed on the browser GUI and can be downloaded to the client
PC. Playback or Image data download through the log is also available.
• Internet mode: H.264/MPEG-4 images can be transmitted over HTTP protocol.
• Multi-language: English / Italian / French / German / Spanish /
Russian / Chinese / Japanese
• IPv4/IPv6 protocol supported
• Supports DDNS (viewnetcam, RFC2136)
• Still images (JPEG) can be viewed on mobile phones via Internet.
• Analog Monitor output for easier installation
• ONVIF compliant model
• Fog compensation
Network Camera
WV-SP302
Standard Accessories
• CD-ROM*1 ......................................1 pc.
• Installation Guide ...........................1 pc.
• Code Label*2
................................. 1 pc.
The followings are for installation.
• Power Cord Plug ........................... 1 pc.
• Safety Wire Plate for Ceiling .......... 1 pc.
• Safety Wire Lug for Wall .................1 pc.
• Wire Lug Fixing Screws (M2.5 x 8)
..............................2 pcs. (incl. 1 spare)
*1 The CD-ROM contains the operating instructions
(PDFs) and different kinds of tool software programs.
*2 This label may be required for network management.
The network administrator shall retain the code label.

DISTRIBUTED BY:
Trademarks and registered trademarks
–
Microsoft, and Windows are registered trademarks of Microsoft Corporation in the U.S. and other countries.
– iPad, iPhone and iPod touch are registered trademarks of Apple Inc.
– UniPhier is a registered trademark of Panasonic Corporation.
– "i-PRO SmartHD" logo is trademarks or registered trademarks of Panasonic Corporation.
– ONVIF and the ONVIF logo are trademarks of ONVIF Inc.
Important
–
Safety Precaution: Carefully read the operating instructions and installation manual before using this product.
– Panasonic cannot be responsible for the performance of the network and/or other manufacturers' products used on the network.
• All TV pictures are simulated.
• Masses and dimensions are approximate.
• Specifications are subject to change without notice.
• These products may be subject to export control regulations.
• All product pictures are NTSC models.
55(2-3/
16
")
71(2-13/16")3(1/8") 1(1/16 ")
75(2-31/32")
65(2-9/
16
")
10(3/8")
132.5(5-1/ 4 ")
36(1-7/ 16 ") 18(11/ 16 ")
TV System NTSC PAL
Camera Image Sensor 1/3 type MOS Sensor
Effective Pixels Approx. 1.3 megapixel
Scanning Mode Progressive scan
Scanning Area 4.8 mm (H) x 3.6 mm (V) {3/16 inches (H) x 5/32 inches (V)}
Minimum Illumination
Color: 0.2 lx, B/W: 0.13 lx at F1.4 (Shutter: 1/30 s, AGC: High),
Color: 0.013 lx, B/W: 0.009 lx at F1.4 (Shutter: 16/30 s, AGC: High)
White Balance AWC (2,000 ~ 10,000 K), ATW1 (2,700 ~ 6,000 K), ATW2 (2,000 ~ 6,000 K)
Light Control Mode Outdoor : Automatic integration of ALC and ELC
Indoor [50 Hz]: Automatic integration of ALC and ELC (up to 1/100 s)
Indoor [60 Hz]: Automatic integration of ALC and ELC (up to 1/120 s)
ELC: (up to 1/10,000 s)
Shutter Speed Fix shutter: OFF (1/30), 3/100, 3/120, 2/100, 2/120, 1/100,
1/120, 1/250, 1/500, 1/1,000, 1/2,000, 1/4,000, 1/10,000
Wide Dynamic Range ON / OFF
Face Wide Dynamic Range ON / OFF (Only at Wide Dynamic Range: ON)
Adaptive Black Stretch
ON / OFF (Only at Wide Dynamic Range: OFF)
AGC ON (LOW, MID, HIGH ) / OFF
Electronic Sensitivity UP OFF / AUTO (Max. 2x (2/30 s), 4x (4/30 s), 6x (6/30 s), 10x (10/30 s), 16x (16/30 s))
Simple Day/Night Mode AUTO / OFF
Digital Noise Reduction
High / Low
Video Motion Detection
4 areas, Sensitivity: 15 steps, Detection size: 10 steps
Privacy Zone Up to 2 zones, Gray
VIQS ON / OFF
Camera Title (OSD) Up to 20 alphanumeric characters
Focus Adjustment Focus Assist
Browser Camera Control Brightness, AUX ON / OFF
GUI Display Mode
Spot, Quad: Image from 16 cameras can be displayed in 4 different Quad
screens or 16 split screen (JPEG only). 20 characters camera title available.
Digital Zoom 1x, 2x, 4x controlled by browser GUI
Camera Title Up to 20 alphanumeric characters
Clock Display
Time: 12H/24H, Date: 5 formats on the browser, Summer time (Auto / Manual)
Alarm Control Reset
One Shot Capture A still picture will be displayed on a newly opened window.
Audio
Mic (Line) Input: ON / OFF Volume adjustment: Low / Middle / High,
Audio Output: ON / OFF Volume adjustment: Low / Middle / High
SD Memory Data Download Still or motion Images recorded in the SDHC/SD memory card can be downloaded.
GUI/Setup Menu Language English, Italian, French, German, Spanish, Russian, Chinese, Japanese
System Log Up to 100 (Internal), Up to 4,000 (SDHC/SD memory when the
recording format is set to JPEG.) error logs
Supported OS Microsoft®Windows®8, Microsoft®Windows®7,
Microsoft®Windows Vista®,
Microsoft®Windows®XP SP3
Supported Browser Windows® Internet Explorer®10.0 (32 bit),
Windows® Internet Explorer®9.0 (32 bit),
Windows® Internet Explorer®8.0 (32 bit),
Windows® Internet Explorer®7.0 (32 bit),
Microsoft® Internet Explorer®6.0 SP3
Network Network IF 10Base-T / 100Base-TX, RJ-45 connector
Image Aspect ratio:
H.264: 800 × 600 / VGA (640 × 480) / QVGA (320 × 240), up to 30 fps
Resolution [4 : 3] MPEG-4: VGA (640 × 480) / QVGA (320 × 240), up to 30 fps
*1 *2
JPEG: 800 × 600 / VGA (640 × 480) / QVGA (320 × 240), up to 30 fps
Aspect ratio: H.264: 640 × 360 / 320 × 180, up to 30 fps
[16 : 9] JPEG: 640 × 360 / 320 × 180, up to 30 fps
H.264/
Transmission Constant bitrate / Framerate priority / Best effort / Advanced VBR
MPEG-4
Mode
*1 Frame Rate 1 / 3 / 5 / 7.5 / 10 / 12 / 15 / 20 / 30 fps
Bit Rate/ 64 / 128 / 256 / 384 / 512 / 768 / 1,024 / 1,536 / 2,048 / 3,072 /
Client 4,096 kbps / Unlimited
Image Quality LOW / NORMAL / FINE
Refresh Interval 0.2 s / 0.25 s / 0.33 s / 0.5 s / 1 s / 2 s / 3 s / 4 s / 5 s
Transmission Type UNICAST / MULTICAST
JPEG
Image Quality 10 steps
Transmission Type PULL / PUSH
Audio Compression G.726 (ADPCM) 32 kbps / 16 kbps, G.711 64 kbps
Audio Mode
OFF / Mic (Line) input / Audio output / Interactive (Half duplex) / Interactive (Full duplex)
Authentication for Audio Level 1 only / Level 2 higher / All users
Total Bit Rate
64 / 128 / 256 / 384 / 512 / 768 / 1,024 / 2,048 / 4,096 / 8,192 kbps / Unlimited
Supported Protocol IPv6: TCP/IP, UDP/IP, HTTP, RTP, FTP, SMTP, DNS, NTP,
SNMP, DHCPv6, ICMPv6
IPv4: TCP/IP, UDP/IP, HTTP, RTSP, RTP, RTP/RTCP, FTP, SMTP,
DHCP, DNS, DDNS, NTP, SNMP, UPnP, IGMP, ICMP, ARP
FTP Client Alarm image transfer, Periodic image transfer, Active/Passive
selectable (When the FTP periodic transmission is failed,
backup on an optional SDHC/SD memory card is available.)
No. of Simultaneous Users Up to 14 users (Depends on network conditions)
TV System NTSC PAL
Network
SDHC/SD Memory Card H.264 recording: Manual REC / Alarm REC (Pre/Post)
(Option)
JPEG recording: Manual REC / Alarm REC (Post) / Backup upon
network failure Compatible SD (SDHC) card: Panasonic 256 MB,
512 MB, 1 GB, 2 GB, 4 GB*, 8 GB*, 16 GB*, 32 GB* model * SDHC card
Cellular Phone Compatibility JPEG image
Mobile Terminal Compatibility
*3
iPad, iPhone, iPod touch (iOS 4.2.1 or later) , AndroidTM mobile terminals
Alarm Alarm Source 1 terminal input, VMD, Command alarm
Alarm Actions
SDHC/SD memory recording, E-mail notification, Alarm terminal output,
Indication on browser, FTP image transfer, Panasonic protocol output
Alarm Log With SDHC/SD memory card: 5,000 logs, without SDHC/SD memory card: 1,000 logs
Schedule Alarm / VMD / Access permission / H.264 recording
Input/ Monitor Output 1.0 V [p-p] / 75 Ω, 1.0 V [p-p] / 75 Ω,
Output (for adjustment) NTSC composite, RCA Jack PAL composite, RCA Jack
Microphone/Line Input MIC IN and Line IN are selectable. ø3.5 mm stereo mini jack
(monaural input) (Applicable microphone; Plug-in power type)
Supply voltage: 2.5 V ±0.5 V input impedance: approx. 2 kΩ
Audio Output ø3.5 mm stereo mini jack (monaural output) Line level
External I/O Terminals ALARM IN, ALARM OUT, AUX OUT
General Safety/EMC Standard
UL (UL60065), FCC (Part15 ClassA), CE (EN55022 ClassB, EN55024)
C-UL (CAN/CSA C22.2 No.60065),
DOC (ICES003 ClassA)
Power Source and Consumption 12 V DC: 270 mA, PoE (IEEE 802.3af): 3.4 W (Class 2 device)
Ambient Operating
- 10 °C ~ +50 °C (14 °F ~ 122 °F),
Temperature/Humidity Less than 90 % (no condensation)
Dimensions
75 mm (W) x 65 mm (H) x 132.5mm (L) (2-31/32" (W) x 2-9/16" (H) x 5-1/4" (L))
Mass (approx.) 390 g (0.86 lbs.)
2-1/4-20UNC for Tripods (Depth 10 mm)
*1 H.264 and MPEG-4 are alternative.
*2 [4 : 3] and [16 : 9] are alternative.
*3 For further information about compatible devices, refer to our website
(http://security.panasonic.com/pss/security/support/info.html).
Appearance
Unit: mm (inches)
Specifications
Slide Cover
SDHC/SD Memory Card Slot
ALC Lens Connector
Focus Assist Button
Clamp for SDHC/SD Memory Card
Network Connector (RJ-45)
Access Indicator
Link Indicator
Monitor Out Connector for Adjustment
External I/O Terminals
Audio Output Connector
Microphone/Line Input Connector
INITIAL SET Button
Power Indicator
12 V DC Power Cable Terminals
SDHC/SD Memory Card Error Indicator /
Focus Assist (FA) Indicator
Part Names and Functions
Side View
Rear View
* When the slide cover is opened.
http://security.panasonic.com
http://www.facebook.com/PanasonicNetworkCamera
Printed in Japan (2A-059JL)
