Panasonic NR-BY602 User manual

AK-157181
T0911-1
Printed in Thailand
MAL
Contents
Safety precautions●................................................................................................................................2
Required action●.....................................................................................................................................4
Installation●.............................................................................................................................................5
Parts identification●................................................................................................................................6
Food storage in the freezer compartment●.............................................................................................7
How to make ice cubes●.........................................................................................................................7
Temperature control●..............................................................................................................................7
Quick freezing●.......................................................................................................................................9
ECONAVI●operation..............................................................................................................................9
How to clean the refrigerator●..............................................................................................................10
Troubleshooting●.................................................................................................................................. 11
Specifications●......................................................................................................................................12
NR-BY552 NR-BY602
Thank you for purchasing the Panasonic product.
Please read these instructions carefully and follow safety precautions page 2-3 before using this product. ●
Please make sure the date and name of store of purchase are stamped in warranty card and keep it with this ●
operating instructions.
Operating Instructions
Refrigerator
Model No. NR-BY552
NR-BY602
For Household Use
Manul_AK-157181-EN.indd 1Manul_AK-157181-EN.indd 1 1/27/12 9:55:29 AM1/27/12 9:55:29 AM

WARNING
WARNING
This sign means
[It may lead a serious injury or death.]
Safety precautions
CAUTION
Please be sure to follow these instructions.
This sign means
[It may result in injury or property damage.]
These signs mean prohibited action.
This sign means required action.
iso-butane
In case of emergency...In case of emergency...
Stop●using the refrigerator immediately
if there is an abnormality or failure.
(Otherwise it may cause smoke, a fire or
electrical shock.)
Abnormality and failure examples.
- Power cord or plug is abnormally hot.
- Power cord is deeply cut or deformed.
- There is burning smell.
- You can feel tingling electricity.
A flammable refrigerant is used. If you●
have damaged the cooling circuit (piping),
open the windows to ventilate the kitchen
and contact your dealer. (Otherwise it
may cause an electrical shock, ignition or
explosion.)
Do not●disassemble, repair or modify the
refrigerator by yourself.
If you want to repair the refrigerator, please
consult your dealer or authorized service
center.
Do not●use mechanical device or other
means to accelerate the defrosting process,
other than those recommended by the
manufacturer.
iso-butaneiso-butane
Otherwise it may cause
a fire, injury, explosion,
electrical shock.
Do not●use electrical
appliances such as a
deodorizer in the refrigerator.
(If the refrigerant leaks, then
it may catch fire due to sparks
on the contacts.)
Do not●store explosive substances such as
aerosol cans with a flammable propellant
and chemicals or scientific specimens in this
appliance.
Maintenance work only be carried out at●
workshop by well-trained maintenance worker.
Servicing personal in Queensland are hereby●
advised that Queensland installation/servicing
requirements must be followed, including
the need for a Gas Work Authorisation
(hydrocarbon refrigerants), if the gas system
of this appliance is opened or charged.
This appliance contains a small quantity of●
R600a refrigerant which is environmentally
friendly, but flammable. It does not damage
the ozone layer, nor does it increase the
greenhouse effect.
During transportation and installation, ensure●
that the tubing of the refrigerant circuit is not
damaged.
Leaking refrigerant can ignite and may●
damage the eyes.
In the event any damage does occur, avoid●
exposure to open fires and any device which
creates a spark. Disconnect the appliance
from the mains power.
Thoroughly ventilate the room in which the●
appliance is located for several minutes.
Notify (insert authorised service●
agent details) for necessary
action and advice.
The room for installing the●
appliance must be at least 1 cubic
metre per 8 grams of refrigerant.
The refrigerant quantity contained
in this appliance is noted on the
Rating Plate of the appliance.
2
Manul_AK-157181-EN.indd 2Manul_AK-157181-EN.indd 2 1/27/12 9:55:30 AM1/27/12 9:55:30 AM

WARNING
Otherwise it may cause
a fire, injury, explosion,
electrical shock.
Safety precautions Please be sure to follow these instructions.
Do not ● plug or unplug with wet hands.
Do not
● let the cord or plug be damaged. If the
supply cord is damaged, must be replaced by
service center.
Disconnect power plug when cleaning. ●
Plug into a wall outlet of the rated voltage on its ●
own with the rated current and insert plug fully.
Reserve one plug for the refrigerator only. Avoid
●
connecting many appliances to the same plug
and unroll through the length of cord.
Remove dust periodically from the power plug.
●
If you detect a gas leak, do not touch the power ●
plug and ventilate the kitchen.
If you detect burning smell, disconnect the
●
power plug and ventilate the kitchen.
Do not●damage the cooling circuit (piping
on the back.) The flammable refrigerant
may catch fire and lead to an explosion.
Do not●touch compressor or pipe, this area
is high temperature.
Do not●let any children hang the
refrigerator’s door, it may overturn to the
kid.
Children should be supervised to ensure
that they do not play with the refrigerator.
Do not●place any water container on the
top of the refrigerator.
Do not●fill the gaps around the refrigerator.
(If the refrigerant leaks, then it may catch
fire.)
This appliance is not intended to use by●
persons (including children) with reduced
physical, sensory or mental capabilities or
lack of experience and knowledge, unless
they have been supervised by responsible
person for their safety.
CAUTION
When opening/closing the doors...
While opening the●
refrigerator, be
careful not to pinch
other one’s hand
holding the door.
Mind the gap●
between the doors.
They may nip your
hand while closing the door.
When storing food...
Do not● add a high impact on
glass trays. (Otherwise those
glass trays may break and you
may be injured.)
Do not● freeze glass bottles.
(If the liquid in a glass bottle is
frozen, then the bottle may break
and the liquid may leak out.)
Hold the refrigerator tightly ●
when transporting.
Apply protective covering, etc.
●
to floors with a fragile surface.
When moving the refrigerator...
Otherwise it may
cause burn injury,
accidents.
When recycling the product... For power plug and cord...
When using...
Before taking the refrigerator to be●
recycled, please remove all the door
opening seal to prevent locking a child in it.
The warning labels mentioned above●
should be kept throughout the life of the
refrigerator.
The user manual should be handed over to
any person who would use or handle the
refrigerator whenever the refrigerator would
be transferred to another location and
delivered to a recycling plant.
Regarding to local laws, Cyclo-Pentane is●
used for insulation of this refrigerator and
flammable gas is used for refrigerant. When
you throw away this unit, please discard it
by proper method and do not dispose it by
burning.
3
Manul_AK-157181-EN.indd 3Manul_AK-157181-EN.indd 3 1/27/12 9:55:31 AM1/27/12 9:55:31 AM

When opening/closing the doors...
Do not●refrigerate items which are bigger than
tray or shelf, as the door will not close completely
causing leakage of cool air.
Do not●open refrigerator frequently or leave it open
for long time in order to prevent water dripping inside
and waste energy.
Frequently check the door opening seal, it must be●
closed to the refrigerator’s body completely.
When using...
When cleaning...
Do not●clean the refrigerator with
chemical substance or liquid. It will
cause damage and have corrosion
on the surface.
Clean the pan water evap located over the●
compressor at the back of the refrigerator every
three months to prevent the odour generated from
humidity.
10
minutes
Required action
Do not●place warm/hot foodstuff in the
refrigerator. Store warm food and drinks
after they have cooled.
Do not●overload the refrigerator.
Gap must be provided between
foodstuffs to maintain the cooling effect.
Store fruits and vegetables in vegetable●
case, where trapped moisture helps
preserve food quality for longer time
periods.
Drinking water, beverage bottles should●
be sealed to prevent the odour.
Foodstuff such as vegetable, fruits and●
fresh food should be wrapped or pack
in box before freezing and refrigerating.
Put the food such as meat or fish in●
the freezer if you want to store for an
extended period.
If you will put high moisture content●
into refrigerator, should be sealed and
wrapped to prevent dew and frost.
It is suitable for storage food and so on●
which would like to storage another food
separately.
When storing food...
Utility box
When the plug is disconnected, leave it for●
10 minutes before plugging again. If not,
the compressor may not work.
Do not●put anything on top of the
refrigerator. Otherwise, it may fall due
to vibration.
Adjust the temperature according●
to the actual operating condition for
energy saving.
If you will not be at home for several days and there●
are nothing refrigerated in the refrigerator, the plug
should be disconnected for energy saving.
4
Manul_AK-157181-EN.indd 4Manul_AK-157181-EN.indd 4 1/27/12 9:55:31 AM1/27/12 9:55:31 AM

30 cm
10 cm
5 cm
5 cm


Grounding
receptacle
Illustration for the ground
connection
Ground
wire
Installation
The top of the refrigerator and the ceiling at least 30 cm.●
The wall and the back of the refrigerator at least 10 cm.●
The side of the refrigerator and the wall at least 5 cm.●
Do not●locate the refrigerator in a humid place as rust may form and
may cause electric leakage.
Do not●locate the refrigerator exposing to direct sunlight as the heat
and sunlight will increase the temperature.
Do not●locate the refrigerator near heat source such as cooking
stove or oven.
Do not●block the openings on the circumstances of the refrigerator.
The refrigerator must be located in the place where there is good air●
circulation.
In case of placing the refrigerator on an uneven surface, adjust the●
adjustable bolt to make the refrigerator stands stably.
When moving or shifting the refrigerator, remove ice twister, ice box, top freezer●
case, pan water evap etc. and check to be sure that there is no water in the
refrigerator, adjust the adjustable bolt of refrigerator, then move the refrigerator
and install in the location, adjust adjustable bolt for locking.
The refrigerator LED lamp, specially designed for this refrigerator, does not function on individual●
replacing. If you need replacement, please contact Panasonic Service Center.
If there is no grounding wiring plug in refrigerator, it should be connected with grounding connection●
or prevent electrical hazard from electric leakage.
To bring power cord for use, pan water evap from left should be lifted up. Then bring the power cord out and●
then insert pan water evap into the block by pressing at both the sides.
The distance from the wall is installed
Area around installed
Moving or shifting
LED lamp and Grounding
Power cord setting
For safety, the ground connection should be done
(For a refrigerator with plug (2-pin plug) without any ground wire)
The ground connection will allow prevention of danger resulted from electricity leakage.
The ground connection can be performed in 2 ways as follows:
1. In the case that the grounding receptacle having been prepared
for the socket (plug socket), connect the ground wire to the screw
used for ground connection at the bottom rear of the refrigerator
(regarding the screw used for ground connection, please notice
the symbol) as shown in the illustration 1.
2. In the case that the socket (plug socket) having not been
provided with any grounding receptacle, connect the ground wire
to the screw at the bottom of the refrigerator, (as regards the
screw used for ground connection, please notice the symbol).
And then connect the other end to the ground rod as shown in the
illustration 2.
Prohibited spots for ground connection
Gas pipes and water supply pipes (dangers from electric shock or explosion).●
The ground wires of telephone cords and lightning rods (dangers from lighting).●
5
Manul_AK-157181-EN.indd 5Manul_AK-157181-EN.indd 5 1/27/12 9:55:32 AM1/27/12 9:55:32 AM

Pan water evap
Compressor
Freezer control and
quick freezing mode
Parts identification
QUICK FREEZING button
FREEZER CONTROL button
INVERTER
This portion is shown at front of the product.
Product view from behind.
NR-BY602
SPECIAL FEATURE
1) NON-FLON
This unit uses totally NON-FLON MATERIALS both for refrigerant (iso-butane (R600a)) and for
insulation (Cyclo-Pentane). So, this refrigerator does not damage the earth’s ozone layer and has
almost no effect on global warming.
2) INVERTER
In accordance with temperature change inside the compartment, the motor runs at different speed.
When the temperature is stable, the motor runs at a lower speed (energy saving & lower noise).
When powerful cooling is required, the motor runs at a higher speed.
Egg shelf
Egg shelf with egg tray
Utility box
Left provision
compartment shelf
Egg shelf
(model NR-BY602)
Right provision
compartment shelf
Bottle shelf
Slide bottle stopper
LED lamp
Refrigerator temperature
control
Small tempered glass
tray
Large tempered glass
tray
Bottom freezer case
Ice box
Ice twister
Chilled case
Tempered glass tray
chilled
Large tempered glass tray
(model NR-BY602)
Vegetable case
Tempered glass tray
crisper
REFRIGERATOR
COMPARTMENT
FREEZER
COMPARTMENT
Top freezer case
Adjustable bolt
6
Manul_AK-157181-EN.indd 6Manul_AK-157181-EN.indd 6 1/27/12 9:55:33 AM1/27/12 9:55:33 AM

Temperature control
Food storage in the freezer compartment
Bottom Freezer Case
Maximum Storage
If the stored food exceeds edge of container, the
freezer door can not close completely and the
compartment may become frosted.
Remark
While operating the refrigerator for the first time, after connecting the plug, adjust the temperature to
“MED” position of each control and leave it for 24 hours for the effective cooling operation. After that,
adjust the temperature as you prefer. If you want to save the energy, do not adjust the temperature lower
than the actual operating condition.
Refrigerator compartment temperature control
The temperature can be adjusted
for MIN - MAX levels. Indicating
operate and cool level.
“MAX” Lower by approx. -19°C ~ -24°C
“MED” Approx. -17°C ~ -22°C
“MIN” Higher by approx. -13°C ~ -18°C
Freezer compartment temperature control
The temperature can be adjusted for MIN, MED and
MAX levels. Indicating number and cool level.
“MIN” Higher by approx. 5°C ~ 10°C
“MED” Approx. 2°C ~ 7°C
“MAX” Lower by approx. -1°C ~ 4°C
How to make ice cubes
STEP
1. Pull out the ice twister.
2. Fill water in the ice twister until the water level line,
then place it back.
3. To remove ice cubes.
1) Be sure to put in an ice box inside.
2) Twist the ice twister clockwise.
(The ice cubes will drop into the ice box.)
Remark
If an ice twister is twisted while ice box pulled out, ice and water will fall inside or floor.●
Please be sure to put in an ice box to receive the falling ice.
Do not pour water into the ice box for ice making, otherwise the ice box may get cracked.●
WATER LEVEL LINE
ICE TWISTER
ICE BOX
7
Manul_AK-157181-EN.indd 7Manul_AK-157181-EN.indd 7 1/27/12 9:55:33 AM1/27/12 9:55:33 AM

Temperature control
This refrigerator is specially designed for appropriate use, which can adjust the temperature level to
detailed 9 levels with the following details.
How to operate the “9 levels” mode
1. Set LED display to “MIN” with the “FREEZER CONTROL” button.
2. Press the “FREEZER CONTROL” button (for 10 seconds) until the LED display return to show at
“MIN” position.
3. Set “9 levels” mode following below table mentioned by pressing the “FREEZER CONTROL”
button.
LED Display table
To reset the setting “9 levels” mode
Repeat step 1 and 2, then the refrigerator return to normal operation mode.
Remark:
Temperature control varies depends on the changing of environment and food storage quantity.
Cooling
Level Minimum
Step 1 2 3 4 5
FREEZER
CONTROL
LED
DISPLAY
Cooling
Level Maximum
Step 6789
FREEZER
CONTROL
LED
DISPLAY
Not lightingBlinkingLighting
8
Manul_AK-157181-EN.indd 8Manul_AK-157181-EN.indd 8 1/27/12 9:55:35 AM1/27/12 9:55:35 AM

ECONAVI lamp
Light intensity sensor
Quick freezing
ECONAVI operation
Remark :
1Effectiveness differs depending on the ambient temperature, ambient brightness, number of times
and when doors are opened and closed, and state in which food is stored.
2Darkness is detected by the light intensity sensor at approximately 3 lx to 10 lx or less
ECONAVI operation is enabled automatically only when the temperature control of the freezer●
compartment are set to “MED”.
(However, ECONAVI does not operate while quick freezing is operating.)
It is not possible to forcefully start ECONAVI operation.●
This refrigerator learns the lifestyle patterns of your family●
from opening and the time periods of infrequent use to
perform ECONAVI operation.
Remark :
The refrigerator learns your lifestyle pattern from the●
previous 3 weeks, and uses what it has learned from
the 4th week onwards. Therefore, the ECONAVI lamp
“ON/OFF” pattern may change from the 4th week
onwards.
Remarks :
If you want to stop the operation, press the button “QUICK FREEZING”.●
Blue light LED●flashing means that the defrosting system is now working
“QUICK FREEZING” mode will start right after the defrosting operation is finished.
Freezer temp. control does not operate during “QUICK FREEZING” mode.●
(The compressor rotation is at the maximum level for “QUICK FREEZING” mode)
How to operate the “QUICK FREEZING” mode
Detect opening and closing of door and brightness around refrigerator, and automatically controls
operation to save energy1.
Press the button “QUICK FREEZING” (Blue light LED●turns on) blue light LED
(150 min “QUICK FREEZING” mode.)
The system will stop operating automatically when it runs for 150 min and return to●
normal mode (Blue light LED turn off)
Setting for enabling ECONAVI operation
ECONAVI lamp is on during ECONAVI operation
The refrigerator performs ECONAVI operation when it becomes dark●2around the refrigerator, such
as when you are asleep.
The brightness of the lamp is lowered approximately 5 minutes after the lamp turns on.●
9
Manul_AK-157181-EN.indd 9Manul_AK-157181-EN.indd 9 1/27/12 9:55:36 AM1/27/12 9:55:36 AM

Removing the vegetable case
and chilled case for cleaning.
Removing the bottom freezer case
for cleaning.
Removing trays for cleaning.



1
Interior cleaning
Wipe off the stain with warm water. When stains can not be removed easily,
wipe them with warm water and soap by using a soft cloth.
Then wipe the soap off using damp soft cloth.
2
Exterior cleaning
Cleaning by using soft cloth with warm water and soap.
Then wipe off the soap.
3
Gasket door PC
Clean by wiping softly. This area, petroleum gel was applied to reduce●
the friction of the refrigerator body. Be careful not to wipe off them.
The door opening seal is replaceable when reaching end of life.●
While cleaning, push it back to the groove if it comes off.
Note: Do not use the following items. (Otherwise, the surface will be scratched.)
Removing●
1. Unhook the protrusion
at the back by lift it
upward and pull the
tray forward until
removing.
Attaching●
2. Push the tray until it
reached the end lock.
1. Pull the freezer drawer
toward yourself.
2. Raise up a bit the front
of the freezer drawer.
Then pull the freezer
drawer until stopper.
3. Lift both sides of
bottom freezer case
and move it upward to
remove.
Removing egg shelf, bottle shelf
and left/right provision compartment
shelf for cleaning.
Removing●
1. Lift it upward, alternating
between the right and
left side.
Attaching●
2. Placing it on both
supporters, and then
press until it reached the
end of supporters.
Removing●
1. Pull the case until it
reached the end of
stopper.
2. Raise up the front of
case a bit and then
completely take out.
Attaching●
1. Push the case on both
supporters.
2. Raise it up, then push
until it reached the end.
Use lukewarm
water!
Alkaline or faintly
Alkaline
Kitchen detergents
(They crack plastic!)
Cleanser or soap
powder
Benzine, thinner,
alcohol, acid, petroleum
Scrubber Hot Water
How to clean the refrigerator
Remark
When removing tray above vegetable case, ●
please pull out the vegetable case first and then
follow to removing the tray as above details.
In case of attaching the tray and it does not lock,
●
make sure that you did not attach it the wrong
tray.
Remark
To keep vegetable and fruit and to maintain its ●
vitamins, please push until it locks properly after
use or clean the vegetable case.
10
Manul_AK-157181-EN.indd 10Manul_AK-157181-EN.indd 10 1/27/12 9:55:36 AM1/27/12 9:55:36 AM

Check if the refrigerator is located on a stable floor or is installed properly. ●
Check if there is any object in contact with the refrigerator.●
The refrigerator
generates noise.
Do you put the food near cold air duct?●
Do you adjust the temperature control at “MAX”? Adjust to “MIN”.●
Do you put food in chilled case?●
Food becomes frozen
Check that the plug and its socket are in good condition.●
Check if there is any problem on main fuse and electrical system of●
the house.
Check by unplug and wait for 5 minutes before plugging it back in.●
The refrigerator does
not operate.
Check to be sure that the temperature control lever is at the proper●
position.
Check to see if the refrigerator is overloaded with stuff or there is●
any hot foodstuff refrigerated inside.
Is the refrigerator exposed directly to sunlight or heat source?●
Is the refrigerator door completely closed?●
Is the refrigerator door opened frequently?●
The refrigerator does
not cool enough.
Condensation may appear on the surface of cabinet when humidity ●
is high, e.g. during rainy season or the air circulation is not good.
If there is condensation inside, check if the door is completely
● closed.
Is the refrigerator frequently opened or left open for a long time?
Is there any hot foodstuff refrigerated inside?
Vapor generated
inside and outside the
cabinet / surface of
door.
Is the quick freezing operating?●
Are the temperature setting of freezer compartment set to●
something other than “MED” ?
Did you open the doors frequently, or store very hot food?●
The learning function may automatically disable ECONAVI●
operation during times of frequent use.
ECONAVI does not
operate.
(the ECONAVI lamp
does not light)
Is there a power failure?●
If a power failure occurs, the leaning function data collected
up until that will be lost. ECONAVI operation will rarely be
performed until the learning function has collected the data
again.
ECONAVI operation is
rarely performed.
ECONAVI operation
is stopped part way
though.
If for example, defrosting (auto) is turned on during●
ECONAVI operation, the normal cooling operation will need
to be performed afterwards so ECONAVI operation may be
stopped.
The learning function may be sometimes●
restart the normal cooling operation.
Is the light intensity sensor hidden?●
Is there dirt scratches on the control panel●
(light intensity section)?
ECONAVI operation may be performed●
while the refrigerator is being used
depending on the conditions of use, but the
cooling performance is maintained.
ECONAVI operation is
performed too often
(the ECONAVI lamp
rarely turns off).
The ECONAVI lamp does not light properly.
Troubleshooting
11
Manul_AK-157181-EN.indd 11Manul_AK-157181-EN.indd 11 1/27/12 9:55:38 AM1/27/12 9:55:38 AM

Model No. NR-BY552 NR-BY602
Freezer Star Rating
Capacity (L)
Total 551 602
Freezer 153 153
Refrigerator 398 449
Outside Dimensions
Width x Depth x Height (mm) 775 × 745 × 1,714 775 × 745 × 1,846
Net Weight (kg/lb) 80 / 176 86 / 190
Refrigerant Type R600a
Rated Voltage (V)
Rated Frequency (Hz) Refer to the rating label attached inside the cabinet
Specifications
Memo
PanasonicCorporation
Website:http://panasonic.net
©PanasonicAppliances(Thailand)Co.,Ltd.2012
Manul_AK-157181-EN.indd 12Manul_AK-157181-EN.indd 12 1/27/12 9:55:39 AM1/27/12 9:55:39 AM
