Panasonic WV-CP300 Series User manual

Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
The model number is abbreviated in some descriptions in this manual.
This illustration represents WV-CP300.
Lens: Option
Operating Instructions
Color CCTV Camera
Model No: WV-CP310, WV-CP314
WV-CP300, WV-CP304

2
Preface
About the user manuals
The operating instructions of the camera consist of 2 sets: these operating instructions (PDF)
and Installation Guide.
This document explains how to configue the settings of the camera.
Refer to the installation guide for further information about how to install the camera.
Adobe®Reader®is required to read PDF. When the Adobe®Reader® is not installed on the
PC, download the latest Adobe®Reader®from the Adobe web site and install it.
Trademarks and registered trademarks
Trademarks and registered trademarks
Adobe, Acrobat Reader and Reader are either registered trademarks or trademarks of Adobe
Systems Incorporated in the United States and/or other countries.
About notations
The following notations are used when describing the functions limited for specific models.
The functions without the notations are supported by all models.
CP310
CP310
CP300
: The functions with this notation are available when using the model WV-CP310 and
WV-CP314.
CP310
CP310
CP300
: The functions with this notation are available when using the model WV-CP300 and
WV-CP304.

3
Contents
Preface .......................................................................................................................................... 2
About the setup menus ................................................................................................................ 4
List of setup menu ...................................................................................................................... 4
Basic operation ............................................................................................................................ 5
Screen transition diagram
CP310
CP310
CP300
................................................................................................ 7
Screen transition diagram
CP310
CP310
CP300
................................................................................................ 8
Camera title setting [CAMERA ID]................................................................................................. 9
Camera operation setting [CAMERA SETUP] ............................................................................. 10
Register a scene file [SCENE1/SCENE2].................................................................................. 10
Light quantity control method selection [ALC/ELC] ................................................................. 11
Back light compensation function........................................................................................ 11
Electronic shutter setting [SHUTTER] ...................................................................................... 12
Gain control setting [AGC] ....................................................................................................... 12
Electronic sensitivity enhancement setting [SENS UP] ............................................................ 13
White balance setting [WHITE BAL] ......................................................................................... 13
Manual fine adjustment of white balance ........................................................................... 14
Digital noise reduction function setting [DNR] .......................................................................... 15
Black-and-white mode setting [D&N (IR) ]
CP310
CP310
CP300
[D&N (ELE) ]
CP310
CP310
CP300
...................................... 15
VMD setting [VMD] ................................................................................................................... 17
Set motion detection............................................................................................................ 17
Setting of scene change detection ..................................................................................... 19
Camera system setting [SYSTEM SETUP] ................................................................................. 20
Synchronization method selection [SYNC]............................................................................... 20
Privacy zone setting [PRIVACY ZONE] ..................................................................................... 20
Image stabilizer setting [STABILIZER]....................................................................................... 21
Electronic zoom setting [EL-ZOOM] ........................................................................................ 21
Upside-down setting [UPSIDE-DOWN] ................................................................................... 22
Lens distortion correction [LDC] ............................................................................................... 22
Special menu setting [SPECIAL SETUP] .................................................................................... 23
Chroma level adjustment [CHROMA GAIN] ............................................................................. 23
Aperture level adjustment [AP GAIN] ........................................................................................ 23
Pedestal level adjustment [PEDESTAL] ................................................................................... 23
Chroma phase (hue) adjustment [HUE] .................................................................................... 23
Flaw compensation [PIX OFF] .................................................................................................. 24
Communication setting [COMMUNICATION] .......................................................................... 24
Default resetting [CAMERA RESET] ......................................................................................... 25
Serial number viewing [SER.NO.] ............................................................................................. 25
Camera language selection [LANGUAGE SETUP] ..................................................................... 26
Shortcut operation ..................................................................................................................... 27

4
About the setup menus
Performing each setting item in the setup menu should be completed in advance to use this unit.
Perform the settings for each item in accordance with the conditions of the camera shooting area.
List of setup menu
Setup item Description
CAMERA ID
This item specifies the camera title. The camera title that indicates the camera
location and other information about the camera is created with alphanumeric
characters and symbol, and then displayed on the screen.
CAMERA Performs the camera operation settings.
SCENE 1/
SCENE 2
Selects a scene file. It is possible to register and save the settings as a scene file
in case that it is necessary to change the settings such when shooting at night.
ALC/ELC Selects the method of controlling the quantity of light in accordance with the lens
to be used.
SHUTTER Specifies the electronic shutter speed.
AGC Specifies gain adjustment.
SENS UP Specifies electronic sensitivity enhancement.
WHITE BAL Specifies white balance adjustment.
DNR Selects the level of the digital noise reduction function.
D&N (IR/ELE) Performs each setting regarding the black-and-white mode such as switching
between color and black-and-white images.
VMD Performs settings regarding VMD (Video Motion Detection)
SYSTEM Performs the settings regarding the camera system such as synchronization and
privacy zone.
SYNC Specities the synchronization type.
PRIVACY ZONE Hides undesired portions in the camera shooting area.
STABILIZER Decides whether or not to enable the image stabilizer.
EL-ZOOM Switches the electronic zoom on and off.
UPSIDE-DOWN Flips the camera images vertically or horizontally.
LDC Adjusts the lens distortion correction to convert the image so that it matches the
square monitor.
SPECIAL
CHROMA GAIN Adjusts the chroma level (color density).
AP GAIN Adjusts the aperture level.
PEDESTAL Adjusts the pedestal (brightness) level.
HUE Adjust the chroma phase (hue).
PIX OFF Corrects image defects such as flaws.
COMMUNICATION
Performs the communication setting of the system with a receiver into which this
unit is integrated.
CAMERA
RESET Restores the settings in the setup menu to the default settings.
SER.NO. Displays the serial number of this unit.
LANGUAGE Selects a language to be used in the setup menu.

5
Screenshot 2
The setup mode changes to "ENABLE", and
the setup menu becomes ready to be set.
Step 3
Move the cursor to the item to be set, and
press the [SET] button.
Screenshot 1
Hold down the [SET] button for about 2 sec-
onds to call up the top screen of the setup
menu.
Step 1
Press the [UP] button or the [DOWN] button
to move the cursor to "END".
Step 2
Press the [RIGHT] button to move the cursor
to "SETUP", and press the [SET] button to
change the setup mode from "DISABLE" to
"ENABLE".
MODEL WV-CP310 SERIES
CAMERA ID OFF
CAMERA
SYSTEM
SPECIAL
LANGUAGE
END SETUP DISABIE
MODEL WV-CP310 SERIES
CAMERA ID OFF
CAMERA
SYSTEM
SPECIAL
LANGUAGE
END SETUP ENABLE
The operations in the setup menu are performed with the operation buttons after calling up the
setup menu on the connected video monitor.
The description below explains how to operate the setup menu basically.
Screenshots of WV-CP310 are shown as an example.
Basic operation

6
Screenshot 3
The selected setup screen in the setup menu
appears on the screen.
Note:
 • If the top screen of the setup menu is
called up with the operation buttons
while the camera is operated, the setup
mode is always "DISABLE" to prevent
operation errors.
To perform settings in the setup menu,
change the setup mode to "ENABLE".
 • Thecursorisareverselyhighlightedpart.
Step 4
Perform the settings for each item.
 • Selectionofsettingitem:
Press the [UP] button or [DOWN] button
to move the cursor.
 • Changeofsettings:
Press the [RIGHT] button or [LEFT ] button.
 • Displayofadvancedsetupscreen:
Press the [SET] button when “ ” is
attached to the target setting item.
 • Returntoprevioussetupscreen:
Move the cursor to "RET" and press the
[SET] button.
 • Returntothetopscreen:
Move the cursor to "TOP" and press the
[SET] button, to display the top screen of
the setup menu.
Step 5
Move the cursor to “END” and press the
[SET] button to return to the camera image
screen, or wait about 5 minutes and the
setup menu will automatically close.
**CAMERA SETUP**
SCENE1
ALC/ELC ALC
SHUTTER OFF
AGC ON(HIGH)
SENS UP OFF
WHITE BAL ATW1
DNR HIGH
AUTO1
VMD
RET TOP END
D&N(IR) OFF

7
Screen transition diagram
CP310
CP310
CP300
...I... 0
HUE
Top screen “CAMERA ID” screen
“CAMERA SETUP” screen
“SYSTEM SETUP” screen
“SPECIAL SETUP” screen
“LANGUAGE SETUP” screen
MODEL WV-CP310 SERIES
CAMERA ID OFF
CAMERA
SYSTEM
SPECIAL
LANGUAGE
END SETUP DISABLE
**LANGUAGE SETUP**
LANGUAGE ENGLISH
SET
RET TOP END
**CAMERA ID**
0123456789
ABCDEFGHIJKLM
NOPQRSTUVWXYZ
().,'":;&#!?=
+-*/%$
SPACE POSI
RET TOP END RESET
................
**SYSTEM SETUP**
SYNC INT
PRIVACY ZONE OFF
STABILIZER OFF
EL-ZOOM OFF
UPSIDE-DOWN OFF
- +
LDC I...... 0
RET TOP END
**SPECIAL SETUP**
CHROMA GAIN ....I..160
AP GAIN ...I... 32
PEDESTAL .I..... 15
- +
PIX OFF
CAMERA RESET PUSH SET
SER.NO. XXXXXXXX
COMMUNICATION COAX
RET TOP END
**CAMERA SETUP**
SCENE1
ALC/ELC ALC
SHUTTER OFF
AGC ON(HIGH)
SENS UP OFF
WHITE BAL ATW1
DNR HIGH
AUTO1
VMD
RET TOP END
D&N(IR) OFF

8
Screen transition diagram
CP310
CP310
CP300
Top screen “CAMERA ID” screen
“CAMERA SETUP” screen
“SYSTEM SETUP” screen
“SPECIAL SETUP” screen
“LANGUAGE SETUP” screen
MODEL WV-CP300 SERIES
CAMERA ID OFF
CAMERA
SYSTEM
SPECIAL
LANGUAGE
END SETUP DISABLE
**LANGUAGE SETUP**
LANGUAGE ENGLISH
SET
RET TOP END
**CAMERA ID**
0123456789
ABCDEFGHIJKLM
NOPQRSTUVWXYZ
().,'":;&#!?=
+-*/%$
SPACE POSI
RET TOP END RESET
................
**SYSTEM SETUP**
SYNC INT
PRIVACY ZONE OFF
STABILIZER OFF
EL-ZOOM OFF
UPSIDE-DOWN OFF
- +
LDC I...... 0
RET TOP END
**SPECIAL SETUP**
CHROMA GAIN ....I..160
AP GAIN ...I... 32
...I... 0
PEDESTAL
HUE .I..... 15
- +
PIX OFF
CAMERA RESET PUSH SET
SER.NO. XXXXXXXX
COMMUNICATION COAX
RET TOP END
**CAMERA SETUP**
SCENE1
ALC/ELC ALC
SHUTTER OFF
AGC ON(HIGH)
SENS UP OFF
WHITE BAL ATW1
DNR HIGH
OFF
VMD
RET TOP END
D&N(ELE) OFF

9
This item specified the camera title. The camera title is named with up to 8 characters when
using only Chinese characters, and up to 16 characters when using only English letters or num-
bers. Chinese character, English letters and numbers can be used together. The "CAMERA ID"
display can be turned on or off on the monitor screen.
Step 1
Select "ON" for "CAMERA ID", and then press the [SET] button.
→The "CAMERA ID" appears.
Important:
 • When"CAMERAID"issetto"OFF",thecameratitledoesnotappearevenaftersettingthe
camera title.
Step 2
Move the cursor to the target item with use of the [UP], [DOWN], [RIGHT], and [LEFT] buttons,
and press the [SET] button to enter the character.
→The entered characters are displayed in the editing area.
<Characterentry>
 • ToinputEnglishlettersandnumbers,movethecursortothedesiredletterornumberand
press the [SET] button, to display the screen after enter of English letters and numbers.
 • Toreviseacharacter,movethecursorto(↑) in the editing area, then move the cursor (↑) to
an incorrect character with use of the right or left button, and enter a correct character.
 • Toenterablank,movethecursorto"SPACE"andpressthe[SET]button.
 • Todeletealltheenteredcharacters,movethecursorto"RESET"andpressthe[SET]button.
Step 3
Move the cursor to "POSI" and press the [SET] button after title entered.
→The display positioning screen appears.
Step 4
Use the [UP], [DOWN], [RIGHT], and [LEFT] buttons to decide the title position and press the [SET] button.
→The title position is specified.
Camera title setting [CAMERA ID]
FLOOR 1
Editing area
Top screen "CAMERA ID" screen Display positioning screen
MODEL WV-CP310 SERIES
CAMERA ID ON
CAMERA
SYSTEM
SPECIAL
LANGUAGE
END SETUP ENABLE
**CAMERA ID**
0123456789
ABCDEFGHIJKLM
NOPQRSTUVWXYZ
().,'":;&#!?=
+-*/%$
SPACE POSI
RET TOP END RESET
................

10
Camera operation setting [CAMERA SETUP]
The following settings related to camera actions can be configured on the "CAMERA SETUP"
screen displayed from the top screen. Refer to page 5-6 for how to call up the screen.
The settings configured on the "CAMERA SETUP" screen will be saved as a scene file.
1Register a scene file [SCENE1/SCENE2]
It is possible to register 2 patterns of scene file. When different settings are to be applied
between day and night, SCENE1 can be applied in the daytime and SCENE2 at night. Change
between the scene files can be made by shortcut operation. (page 27) "SCENE1" is set as
the default setting.
Screen when "SCENE1" is selected Screen when "SCENE2" is selected
**CAMERA SETUP**
SCENE1
ALC/ELC ALC
SHUTTER OFF
AGC ON(HIGH)
SENS UP OFF
WHITE BAL ATW1
DNR HIGH
AUTO1
VMD
RET TOP END
D&N(IR) OFF
**CAMERA SETUP**
SCENE2
COPY(SCENE1)
ALC/ELC ALC
SHUTTER OFF
AGC ON(HIGH)
SENS UP OFF
WHITE BAL ATW1
DNR HIGH
AUTO1
VMD
RET TOP END
D&N(IR) OFF
Step 1
After confirming that "SCENE1" is selected, configure the settings of "ALC/ELC" through
"VMD". (page 11-19)
To change the scene files, go to step 2.
Step 2
Move the cursor to "SCENE1" and use the [RIGHT] or [LEFT] button to select "SCENE2".
→The screen changes and displays “SCENE2”.
Step 3
To configure the settings of "SCENE2" using the settings of "SCENE1", press the [SET] button
after moving the cursor to "COPY(SCENE1)".
→The settings of "SCENE1" will be copied to "SCENE2".
Step 4
Edit the settings to be changed.
The number displayed at the right side of the title on
each setting screen indicates a scene file number.
Step 5
Move the cursor to "SCENE2" and press the [RIGHT] or [LEFT ]
button to select "SCENE1" to resume normal operation.
Scene file
number
**ALC CONT**(1)
BACK LIGHT COMP
OFF
ABS
MASK SET
- +
LEVEL .I..... 0
RET TOP END
BLC ON

11
2Lightquantitycontrolmethodselection[ALC/ELC]
The method of controlling the quantity of light is selected from the following in accordance with
the lens to be used.
ALC (default): The iris of the lens is automatically adjusted in accordance with the brightness
of a subject. Select "ALC" when using an ALC lens.
ALC+: Controls the quantity of light with a combination of the electronic shutter and auto iris. This
selection is suitable at shooting a bright subject such as an outdoor subject with auto iris
lens. Be aware that flicker may occur when a subject is under fluorescent lighting.
ELC: Controls the quantity of light with the electronic shutter. This selection is suitable for use
of a lens with fixed iris or manual iris.
Back light compensation function
Follow the procedure below.
Step 1
Set “ALC/ELC” to “ALC”, and then press the [SET] button.
→The “ALC” screen appears.
Note:
 • When“ALC/ELC”issetto“ELC”or“ALC+”andthe[SET]buttonispressed,the“ELC”or
“ALC+”screenwillappear.
Step 2
Move the cursor to “BLC” and select from the following options.
ON: Automatically compensate when the background is brighter than the subject.
OFF (default): This mode is used when the area in front of the subject is extremely bright.
Step 3
Move the cursor to “ABS” and select from the following options.
ABS (Auto Black Stretch Technology)
The latest digital signal technology is applied to automatically detect the dark areas in the
image, acquire the brightness data around the dark areas, and perform real-time color adjust-
ment by calculating the best correction curve for each area. This function can be used to per-
form real-time adjustment and correction of back light and dark area, and reproduce natural,
clear images.
ON: Uses ABS.
OFF (default): Does not use ABS.
“ALC CONT” screen Mask setting screen“CAMERA SETUP” screen
**ALC CONT**(1)
BACK LIGHT COMP
OFF
ABS
MASK SET
- +
LEVEL .I..... 0
RET TOP END
BLC OFF
**CAMERA SETUP**
SCENE1
ALC/ELC ALC
SHUTTER OFF
AGC ON(HIGH)
SENS UP OFF
WHITE BAL ATW1
DNR HIGH
OFF
VMD
RET TOP END
D&N(ELE) OFF

12
Note:
 • When“BLC”issetto“ON”,“ABS”displays“---”andmaynotbeoperated.
Step 4
When "BLC" is set to "OFF", bright areas of an image are masked to facilitate the visibility of
dark areas.
Move the cursor to "MASK SET" and press the [SET] button.
→ The mask setting screen appears.
Step 5
Use the [UP], [DOWN], [RIGHT ], and [LEFT ] buttons to move the flashing cursor to the area to
be masked and press the [SET] button.
When the selected area is masked, the masked area will start blinking between stripes and
white.
When the flashing cursor is moved to other areas, the masked area will be displayed in white.
Repeat the above procedure to mask other areas as necessary.
Note:
 • Todeleteamaskedarea,movetheflashingcursortotheareatobecanceledandpressthe
[SET] button. The masked area will be deleted.
Step 6
Hold down the [SET ] button for more than 2 seconds after completion of masking.
→ Return to the previous menu.
Step 7
Move the cursor to "LEVEL" and use the [RIGHT] or [LEFT] button to adjust the level.
3Electronic shutter setting [SHUTTER]
The variation in shutter speed allows users to perform the following.
Increased shutter speed prevents blurring of fast-moving subjects.
The shutter speed is selectable from the following:
OFF (1/50) (default), 1/100, 1/250, 1/500, 1/1000, 1/2000, 1/4000, 1/10000, 1/120000
Note:
 • When"ALC/ELC"issetto"ELC"or"ALC+","---"appearsandtheshutterfunctioncannot
be activated.
4Gain control setting [AGC]
Select a gain control setting from the following.
ON (HIGH) (default)/ON (MID) /ON (LOW): Automatically increases the gain to make the
screen brighter when the illuminance of the sub-
ject becomes darker. HIGH, MID and LOW indi-
cate the gain level.
OFF: Does not increase the gain.

13
Note:
 • When"SENSUP"issettotheAUTOmode,“AGC”cannotbesetto“OFF”.
5Electronicsensitivityenhancementsetting[SENSUP]
Use of the electronic sensitivity enhancement function increases the light sensitivity of the
CCD, and accordingly the image becomes brighter. The magnification is unchanged for selec-
tion of FIX, and the magnification is automatically adjusted in accordance with the illuminance
of a photographic subject for selection of AUTO. The magnification of the electronic sensitivity
is selectable from the following.
OFF (default)/X2 AUTO/X4 AUTO/X6 AUTO/X10 AUTO/X16 AUTO/X32 AUTO/OFF/X2 FIX/X4
FIX/X6 FIX/X10 FIX/X16 FIX/X32 FIX/X64 FIX/X128 FIX/X256 FIX/X512 FIX
Note:
 • When"ALC/ELC"issetto"ELC"or"ALC+",onlytheAUTOmodeisenabled.
 • When "SHUTTER" is set to options other than "OFF", the electronic sensitivity enhance-
ment setting cannot be performed and "---" appears.
 • When the magnification of "SENS UP" is increased, the screen becomes coarser, more
whitish, or more flawed. However, this phenomenon is normal.
6White balance setting [WHITE BAL]
The white balance adjustment is selectable from the following.
ATW1 (default): Activates the automatic color temperature tracking mode.
The camera continuously check the color temperature of the light source and
automatically adjusts the white balance. The adjustment of the color tempera-
ture ranges from approx. 2,700 K to 6,000 K.
ATW2: Activates the sodium lamp automatic color temperature tracking mode. The camera
automatically achieves an optimal white balance under the sodium lamp. The adjust-
ment of the color temperature ranges from approx. 2,000 K to 6,000 K.
• Ifthesituationmeetsoneofthefollowings,colormaynotbeaccuratelyreproduced.
 • Thesubjectismostlyhighly-colored.
 • Thephotographicsceneisunderthebrightblueskyoratnightfall.
 • Theilluminationofthelightilluminatingthesubjectisinsufficient.
When "AWC" is selected, follow the steps below to adjust the white balance.
"CAMERA SETUP" screen
**CAMERA SETUP**
SCENE1
ALC/ELC ALC
SHUTTER OFF
AGC ON(HIGH)
SENS UP OFF
WHITE BAL ATW1
DNR HIGH
AUTO1
VMD
RET TOP END
D&N(IR) OFF

14
Step 1
Set "WHITE BAL" to "AWC" and press the [LEFT] button to change to "AWC →PUSH SET".
Step 2
Press the [SET] button and adjust the white balance. "AWC →PUSH SET" is reversely high-
lighted during adjustment. When the reversely highlighted display is restored, the white balance
adjustment is completed.
Step 3
Press the [RIGHT] button to select "AWC". Refer to this page for fine adjustment of the white
balance.
Note:
 • The adjustment of the color temperature ranges from approx. 2,000 K to 10,000 K. If the range
is out of this adjustment range or lighting directed to a subject is too dark, the white balance
may not be adjusted. In such a case, "AWC →PUSH SET" stays reversely highlighted.
Manual fine adjustment of white balance
The white balance is manually fine adjusted after white balance automatically adjustment in the
automatic color temperature tracking mode (ATW1, ATW2) or automatic white balance control
mode (AWC).
Follow the procedures below.
Step 1
Set "WHITE BAL" to "ATW1", "ATW2" or "AWC" and press the [SET ] button.
→The fine adjustment screen appears.
Step 2
Move the cursor to "R" and "B" and use the [LEFT] or [RIGHT] button to fine adjust the level for
each. “R” stands for red and “B” stands for blue. When the level indicator moves in the "+"
direction, the color becomes deeper, and when the level indicator moves in the "–" direction,
the color becomes lighter.
Step 3
Move the cursor to “AREA” and press the [SET] button to enter “AREA” setting screen.
The area to detect white area of white balance can be set on the area setting screen. The area
to detect white area of white balance is displayed full-screen by default.
To change the white balance detection area, start from step 4.
**ATW1**(1)
R
- +
B
- +
AREA
RET TOP END
**ATW1 AREA**(1)
POSITION PUSH SET
RET TOP END
Area setting screen
RESET
...I... 0
...I... 0
“CAMERA SETUP” screen Fine adjustment screen
**CAMERA SETUP**
SCENE1
ALC/ELC ALC
SHUTTER OFF
AGC ON(HIGH)
SENS UP OFF
WHITE BAL ATW1
DNR HIGH
AUTO1
VMD
RET TOP END
D&N(IR) OFF

15
Step 4
Move the cursor to "POSITION" and press the [SET] button.
Step 5
Press the [UP], [DOWN], [RIGHT] and [LEFT] buttons to move to the upper-left part of the area
to be set, and press the [SET] button.
Step 6
Press the [UP], [DOWN], [RIGHT] and [LEFT] buttons to move to the lower-right part of the area
to be set, and press the [SET] button.
7Digital noise reduction function setting [DNR]
The digital noise reduction function reduces noise automatically under the condition of low illu-
minance.
The effect level of the noise reduction function is selectable from the following.
LOW: Low level of noise reduction (small residual image)
HIGH (default): High level of noise reduction (large residual image)
8Black-and-white mode setting[D&N (IR) ]
CP310
CP310
CP300
[D&N (ELE) ]
CP310
CP310
CP300
The settings relating to the black-and-white mode can be configured. Follow the procedure
below.
AUTO1
**D&N(IR) **(1)
LEVEL HIGH
DURATION TIME
S L
BURST(BW) ON
RET TOP END
.I..
“CAMERA SETUP” screen “D&N (IR)” screen
**CAMERA SETUP**
SCENE1
ALC/ELC ALC
SHUTTER OFF
AGC ON(HIGH)
SENS UP OFF
WHITE BAL ATW1
DNR HIGH
AUTO1
VMD
RET TOP END
D&N(IR) OFF
Step 1
Move the cursor to "D&N (IR)" or “D&N (ELE)” and select the mode from the following.
CP310
CP310
CP300
AUTO1 (default): Automatically switches between color and black-and-white images
in accordance with the illuminance. The black-and-white mode is
selected for dark images, and the color mode is selected for bright
images.
AUTO2: Used for environment illuminated by near-infrared lamp. (wavelength ≥800 nm)
ON: Displays black-and-white images.
OFF: Displays color images.

16
CP310
CP310
CP300
AUTO: Similar to the basic functions of AUTO1, but does not change the IR filter.
Switches to black-and-white images when brightness (illuminance) around the
camera is lower than approx. 0.1 lx.
OFF (default): Displays color images.
Note:
 •
CP310
CP310
CP300
When “AUTO1” or “AUTO2” is selected, it is recommended to set “AGC” to “ON”.
 • If a subject is always moving or the screen is occupied with a uniform color, brightness
determination may not be performed successfully because the brightness is merely deter-
mined by information from the CCD image sensor. When "AUTO2" is selected, the wave
length of the light source shall be 800 nm or longer.
 • WV-CP300andWV-CP304cannotsettheswitchingbrightness(illuminance)levelofcolor
images and black-and-white images.
 • Toobtaincolorimages,asufficientlevelofilluminance(approx.30lxormore)isrequired.
Step 2
Pressthe[SET ]button.
→The "D&N (IR)" screen appears.
Step 3
Movethecursorto"LEVEL"andselectabrightnesslevelatwhichswitchingbetweencolorand
black-and-white images is performed from the following.
LOW: Switches from color to black-and-white images when the ambient brightness (illumi-
nance) of the camera is less than 0.1 lx.
HIGH (default): Switches from color to black-and-white images when the ambient brightness
(illuminance) of the camera is less than 0.2 lx.
Note:
 • Theswitchingilluminancelevelvarieswithsubjects,lightsources,andlenses.
 • TheswitchingilluminancelevelvariesinaccordancewithAGCsetting.(page 12)
 • The switching illuminances described above are reference values. The switching illumi-
nanceshallbedecidedbasedontheactualinstallationenvironment.
 • There may be repeated switching between color and black-and-white images depending
onthesettingandenvironment.
Step 4
Move the cursor to "DURATION TIME" and select a time for switching between color and
black-and-white images from the following.
2S-10S(default)-30S-60S
(S)
(L)
Step 5
Movethecursorto"BURST(BW)",anddecidewhetherornottoprovideaburstsignaloutput
in the black-and-white mode.
ON (default): Providesaburstsignaloutput.
OFF: Doesnotprovideanyburstsignaloutput.
CP310
CP310
CP300
CP310
CP310
CP300
CP310
CP310
CP300
CP310
CP310
CP300

17
Note:
 • Imagesmaynotbedisplayedappropriatelywithoutburstsignalswhencameraimagesare
displayed in the black-and-white mode depending on a monitor or VCR model to be used.
In such a case, set the burst signal output to "ON".
9VMD setting [VMD]
The VMD function allows the camera to detect object motion and hindrance to the camera.
Detection of object motion or hindrance to the camera can be announced by issuing an alarm
signal.
Important:
 • Thefollowingcircumstancesmayresultindetectionfailureorfalsedetection.Usethecam-
era after adjusting the detection area and sensitivity.
•Notenoughdifferenceinbrightnessbetweenthebackgroundandthemovingphoto-
graphic subject, or significant changes in brightness.
•Dirtorwaterdropsonthelens.
•Insufficientbrightnesswhenshootingatnight.
•Thesubjectismovingstraightatthecamera.
•Thesubjectismovingtoofastortooslow.
•Thesubjectistoosmallortoolarge.
•Therearetoomanymovingobjects.
•Lightreflectedthroughawindoworfromaroadsurface.
•Thecameraisshaking.
•Entryofoutsidelight,suchassunlightortheheadlightsofacar.
•Flickeringfluorescentlight.
 • Subjectchangedetectionmayfailinthefollowingcases.
•
The lens is partially covered or covered with a transparent item.
•Thephotographicsubjectsbeforeandafterchangingthecameradirectionaresimilar.
 • Falsedetectionmayoccurforapprox.1minuteafterturningonthepower,aftercompleting
settings in the SETUP menu, or after changing the camera view angle.
 • Motiondetectionisthedetectionfunctionwithinthescreenrangeforelectroniczoomof1x.
“MOTION DET” screen
** MOTION DET ** (1)
RET TOP END
LEVEL
2S
OFF
DWELL TIME
DISPLAY MODE
ALARM
MASK SET
....I..
20
- +
“CAMERA SETUP” screen
MOTION DET
AUTO
**CAMERA SETUP**
SCENE1
ALC/ELC ALC
SHUTTER OFF
AGC ON(HIGH)
SENS UP OFF
WHITE BAL ATW1
DNR HIGH
VMD
RET TOP END
D&N(IR)
Set motion detection
Move the cursor to “VMD”, press the [LEFT] and [RIGHT ] buttons to select “MOTION DET”.
Step 1
Move the cursor to “MOTION DET” and press the [SET] button, the “MOTION DET” menu appears.

18
Step 2
Move the cursor to "MASK SET" and press the [SET] button.
→The “MASK SET” screen appears.
In the masked area, no alarm will be issued even if a moving object is detected. The masked
area is set in the same way as the masked area setting in Light quantity control method selec-
tion. (page 11)
Step 3
Hold down the [SET] button for more than 2 seconds after completion of masking.
→ Return to the previous menu.
Step 4
Move the cursor to "ALARM", press the [LEFT] and [RIGHT] buttons to select "ON" or "OFF".
ON: Outputs alarm signal when in motion detection mode. Actions may be confirmed through
the motion detection mode when a moving object is detected.
OFF (default): Does not output alarm signal when in motion detection mode.
Step 5
Move the cursor to “DISPLAY MODE” and press the [SET] button. The “DISPLAY MODE”
screen appears.
If a moving object is detected in the set area, the area will be reversely highlighted. Hold down
the [SET] button for more than 2 seconds to return.
“MOTION DET” screen “MASK SET” screen
** MOTION DET **(1)
RET TOP END
LEVEL
2S
OFF
DWELL TIME
DISPLAY MODE
ALARM
MASK SET
....I..
20
- +
“DISPLAY MODE” screen
“MOTION DET” screen
** MOTION DET **(1)
RET TOP END
LEVEL
2S
OFF
DWELL TIME
DISPLAY MODE
ALARM
MASK SET
....I..
20
- +

19
Step 6
Move the cursor to “Level”. Use the [RIGHT] or [LEFT] button to adjust the level.
Repeat step 5 and 6 to adjust to optimal level.
Step 7
Move the cursor to “DWELL TIME ”. Select the dwell time from the following.
2 S (default)/5 S /10 S /30 S
Alarm signal will be issued once a continuously moving object is detected within the specified
time.
Setting of scene change detection
This function detects a change in the subject state that occurs by covering the camera with a
cloth, a cap, or others, or by changing the camera direction largely.
Follow the procedure below.
Step 1
Move the cursor to “VMD”. Use the [RIGHT] or [LEFT] button to select “SCENE CHANGE”.
“CAMERA SETUP” screen
VMD SCENE CHANGE
**CAMERA SETUP**
SCENE1
ALC/ELC ALC
SHUTTER OFF
AGC ON(HIGH)
SENS UP OFF
WHITE BAL ATW1
DNR HIGH
AUTO1
RET TOP END
D&N(IR)

20
Camera system setting [SYSTEM SETUP]
Performs the settings relating to the camera system such as synchronization and privacy zone.
The following settings can be configured on the "SYSTEM SETUP" screen displayed from the
top screen. Refer to page 5-6 for how to call up the screen.
“SYSTEM SETUP” screen
**SYSTEM SETUP**
SYNC INT
PRIVACY ZONE OFF
STABILIZER OFF
EL-ZOOM OFF
UPSIDE-DOWN OFF
- +
LDC I...... 0
RET TOP END
@Synchronization method selection [SYNC]
This unit supports the following 2 types of synchronization methods, and one of the following is selected.
(1) Multiplexed vertical drive signal (VD2)
(2) Internal synchronization (INT) (default)
Input of a multiplexed vertical drive signal (VD2) automatically switches to the VD2
synchronization even if the camera is set to other than the VD2 synchronization method.
When the VD2 synchronization is not selected, internal synchronization can be selected.
APrivacy zone setting [PRIVACY ZONE]
When undesired portions in the camera shooting area (on the screen) exist, those portions (pri-
vacy zone) can be set to be hidden. Up to 8 portions can be specified for the privacy zone.
ON (1): Grays the zone.
ON (2): Mosaics the zone.
OFF (default): Displays the zone normally.
Follow the procedure below to set the privacy zone.
Note:
• Theprivacyzonefunctionisdisabledatinitializingtheunit,i.e.rightafterturningonthepower.
Step 1
Move the cursor to "PRIVACY ZONE", select "ON (1)" or "ON (2)", and press the [SET] button.
**ZONE NUMBER 1 /8**
PUSH SET
POSITION
UPPER LEFT
RET TOP END
DEL
- +
ZONE LEVEL ..I.... 2
“SYSTEM SETUP” screen “ZONE NUMBER” screen
ON(2)
**SYSTEM SETUP**
SYNC INT
PRIVACY ZONE
STABILIZER OFF
EL-ZOOM OFF
UPSIDE-DOWN OFF
- +
LDC I......0
RET TOP END
