Panasonic WV-SW158 User manual

Operating Instructions
Network Camera
Model No. WV-SW158
WV-SF138
WV-SW158 WV-SF138
Before attempting to connect or operate this product, please read these instructions
carefully and save this manual for future use.
The model number is abbreviated in some descriptions in this manual.

Preface
About the user manuals
There are 2 sets of operating instructions as follows.
•Operating Instructions: Explains how to perform the settings and how to operate this camera.
•Installation Guide: Explains how to install and connect devices.
The screens used in these operating instructions show the case of WV-SW158. Depending on the model used,
the screens shown in the explanations may differ to the actual camera screens.
About notations
The following notations are used when describing the functions limited for specified models.
The functions without the notations are supported by all models.
SW158
SW158
: The functions with this notation are available when using the model WV-SW158.
SF138
SF138
: The functions with this notation are available when using the model WV-SF138.
Trademarks and registered trademarks
•Microsoft, Windows, Windows Vista, Windows Media, Internet Explorer, ActiveX and DirectX are either
registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.
•Microsoft product screen shot(s) reprinted with permission from Microsoft Corporation.
•iPad, iPhone, iPod touch, and QuickTime are trademarks of Apple Inc., registered in the U.S. and other
countries.
•Android is a trademark of Google Inc.
•Firefox is a registered trademark of the Mozilla Foundation.
•SDXC Logo is a trademark of SD-3C, LLC.
•All other trademarks identified herein are the property of their respective owners.
Abbreviations
The following abbreviations are used in these operating instructions.
Microsoft® Windows® 8 is described as Windows 8.
Microsoft® Windows® 7 is described as Windows 7.
Microsoft® Windows Vista® is described as Windows Vista.
Microsoft® Windows® XP SP3 is described as Windows XP.
Windows® Internet Explorer® 10.0, Windows® Internet Explorer® 9.0, Windows® Internet Explorer® 8.0, and
Windows® Internet Explorer® 7.0 are described as Internet Explorer.
SDXC/SDHC/SD memory card is described as SD card or SD memory card.
Universal Plug and Play is described as UPnP™.
2 Operating Instructions
Preface

Viewer software
It is necessary to install the viewer software “Network Camera View 4S” (ActiveX®) to display images on a PC.
This software can be installed directly from the camera or by selecting the [Install] button next to [Viewer
Software] on the menu of the CD-ROM provided, and then following the on-screen instructions.
IMPORTANT
•The default setting of “Automatic installation of viewer software” is “On”. Follow the instructions on
page 197 when the message is displayed on the information bar of the browser.
•When the “Live” page is displayed for the first time, the install wizard of the ActiveX control required to
display images from the camera will be displayed. Follow the instructions of the wizard.
•When the install wizard is displayed again even after completing the installation of the ActiveX, restart
the PC.
•The viewer software used on each PC should be licensed individually. The number of installations of
the viewer software from the camera can be checked on the [Upgrade] tab of the “Maintenance” page
(®page 172). Refer to your dealer for the software licensing.
Operating Instructions 3
Preface

Table of Contents
1 Monitor images on a PC ..........................................................................7
1.1 Monitor images from a single camera .............................................................................7
1.2 About the “Live” page ......................................................................................................9
1.3 Monitor cropping images ...............................................................................................12
1.4 Monitor picture in picture images .................................................................................13
1.5 Monitor images from multiple cameras ........................................................................15
2 Monitor images on a cellular phone/mobile terminal .........................16
2.1 Monitor images on a cellular phone ..............................................................................16
2.2 Monitor images on a mobile terminal ............................................................................18
3 Record images on the SD memory card manually .............................21
4 Action at an alarm occurrence ..............................................................23
4.1 Alarm type ........................................................................................................................23
4.2 Action at an alarm occurrence .......................................................................................23
5 Transmit images onto an FTP server ...................................................25
5.1 Transmit an alarm image at an alarm occurrence (Alarm image
transmission) ...................................................................................................................25
5.2 Transmit images at a designated interval or period (FTP periodic image
transmission) ...................................................................................................................25
5.3 Save images on the SD memory card when images fail to transmit using the FTP
periodic image transmission function ..........................................................................26
6 Display the log list .................................................................................27
6.1 When “JPEG” is selected for “Recording format” of the SD memory card ..............27
6.2 When “H.264(1)” or “H.264(2)” is selected for “Recording format” of the SD memory
card ...................................................................................................................................30
7 Playback of images on the SD memory card ......................................34
7.1 When “JPEG” is selected for “Recording format” of the SD memory card ..............34
7.2 When “H.264(1)” or “H.264(2)” is selected for “Recording format” of the SD memory
card ...................................................................................................................................37
8 About the network security ...................................................................39
8.1 Equipped security functions ..........................................................................................39
9 Display the setup menu from a PC .......................................................40
9.1 How to display the setup menu .....................................................................................40
9.2 How to operate the setup menu .....................................................................................42
9.3 About the setup menu window ......................................................................................44
10 Configure the basic settings of the camera [Basic] ...........................46
10.1 Configure the basic settings [Basic] .............................................................................46
10.2 Configure the Internet settings [Internet] .....................................................................49
10.3 Configure the settings relating to the SD memory card [SD memory card] ..............51
10.4 Access copy images saved on the SD memory card onto the PC [SD memory card
images] .............................................................................................................................60
10.5 Configure the settings relating to the logs [Log] .........................................................69
10.5.1 How the logs and images are saved depending on the settings for “Alarm” ..................71
4 Operating Instructions
Table of Contents

10.5.2 How the logs and images are saved depending on the settings for “Manual/
Schedule” .......................................................................................................................72
10.5.3 How the logs and images are saved depending on the settings for “FTP error” ............74
11 Configure the settings relating to images and audio [Image/
Audio] ......................................................................................................75
11.1 Configure the settings relating to the image capture mode [JPEG/H.264] ................75
11.2 Configure the settings relating to JPEG images [JPEG/H.264] ..................................76
11.3 Configure the settings relating to H.264 images [JPEG/H.264] ..................................78
11.4 Configure the settings relating to image adjust, extra zoom, privacy zone, VIQS, and
lens distortion compensation [Image quality] ..............................................................85
11.4.1 Configure the settings relating to image quality (“Image adjust” setup menu) ...............86
11.4.2 Set mask areas ..............................................................................................................92
11.5 Adjust the angular field of view using the extra zoom function .................................96
11.6 Configure the settings relating to the privacy zone (“Privacy zone” setup
menu) ...............................................................................................................................97
11.7 Configure the VIQS setting ............................................................................................99
11.8 Configure the settings relating to lens distortion compensation ............................101
11.9 Configure the settings relating to audio [Audio] .......................................................102
12 Configure the multi-screen settings [Multi-screen] ..........................104
13 Configure the alarm settings [Alarm] .................................................106
13.1 Configure the settings relating to the alarm action [Alarm] .....................................106
13.2 Configure the settings relating to the alarm image [Alarm] ......................................107
13.3 Configure the settings relating to H.264 recording [Alarm] ......................................109
13.4 Configure the VMD settings [VMD area] .....................................................................110
13.4.1 Set the VMD areas [VMD area] ....................................................................................111
13.5 Configure the settings relating to the audio detection [Audio detection] ...............113
13.6 Configuration of the settings relating to the E-mail notification [Notification] .......115
13.7 Configure the settings relating to Panasonic alarm protocol [Notification] ...........117
14 Configure the settings related to advanced view [Advanced
view] ......................................................................................................120
14.1 Configure the settings relating to cropping [Cropping] ............................................120
14.2 Configure the picture in picture settings [PiP] ...........................................................121
15 Configure the settings relating to the authentication [User
mng.] .....................................................................................................126
15.1 Configure the settings relating to the user authentication [User auth.] ..................126
15.2 Configure the settings relating to the host authentication [Host auth.] ..................127
15.3 Configure the settings relating to the priority stream [System] ...............................128
16 Configure the settings of the servers [Server] ..................................131
16.1 Configure the settings relating to the E-mail server [E-mail] ...................................131
16.2 Configure the settings relating to the FTP server [FTP] ...........................................132
16.3 Configure the settings relating to the NTP server [NTP] ...........................................133
17 Configuring the network settings [Network] .....................................136
17.1 Configure the network settings [Network] ..................................................................136
17.2 Configure the HTTPS settings .....................................................................................144
17.2.1 Generation of the CRT key (SSL encryption key) ........................................................145
17.2.2 Generation of the self-signed certificate (security certificate) .......................................146
17.2.3 Generation of CSR (Certificate Signing Request) ........................................................148
Operating Instructions 5
Table of Contents

17.2.4 Installation of the server certificate ...............................................................................149
17.2.5 Configuration of the connection protocol ......................................................................150
17.3 Access the camera using the HTTPS protocol ..........................................................151
17.3.1 Install the security certificate ........................................................................................151
17.4 Configure the settings relating to DDNS [DDNS] .......................................................158
17.4.1 Configuration of the DDNS service (Example of the “Viewnetcam.com” service) ........159
17.4.2 When using the “Viewnetcam.com” service .................................................................160
17.4.3 Procedure to register information for the “Viewnetcam.com” service ...........................161
17.4.4 Checking the information registered for the “Viewnetcam.com” service ......................162
17.4.5 When using “Dynamic DNS Update” ............................................................................162
17.4.6 When using “Dynamic DNS Update(DHCP)” ...............................................................163
17.5 Configure the settings relating to SNMP [SNMP] ......................................................163
17.6 Configure the settings relating to the FTP periodic image transmission [FTP img.
trans.] .............................................................................................................................164
17.7 Configure the schedule settings of the FTP periodic image transmission [FTP img.
trans.] .............................................................................................................................166
17.7.1 How to set the schedules .............................................................................................167
17.7.2 How to delete the set schedule ....................................................................................168
18 Configure the settings relating to the schedules [Schedule] ..........169
19 Maintenance of the camera [Maintenance] ........................................172
19.1 Check the system log [System log] .............................................................................172
19.2 Upgrade the firmware [Upgrade] .................................................................................172
19.3 Check the status [Status] .............................................................................................174
19.4 Reset the settings/Reboot the camera [Default reset] ...............................................175
20 Number of users that can concurrently access the unit ..................177
21 Using the CD-ROM ...............................................................................178
21.1 About the CD launcher .................................................................................................178
21.2 Installing Panasonic “IP Setting Software” ................................................................179
21.3 Installing the manuals ..................................................................................................180
21.4 Installing the Viewer software ......................................................................................180
21.5 Configure the network settings of the camera using the Panasonic “IP Setting
Software” .......................................................................................................................181
22 About the displayed system log .........................................................184
23 Troubleshooting ...................................................................................188
24 Directory structure of drive B .............................................................199
6 Operating Instructions
Table of Contents

1 Monitor images on a PC
The following are descriptions of how to monitor images from the camera on a PC.
1.1 Monitor images from a single camera
1. Start up the web browser.
2. Enter the IP address designated using the Panasonic “IP Setting Software” in the address box of the
browser.
•Example when entering an IPv4 address: http://URL registered using IPv4 address
http://192.168.0.10/
•Example when entering an IPv6 address: http://[URL registered using IPv6 address]
http://[2001:db8::10]/
<Example of IPv4 access>
<Example of IPv6 access>
IMPORTANT
•When the HTTP port number is changed from “80”, enter “http://IP address of the camera + : (colon)
+ port number” in the address box of the browser. (Example: http://192.168.0.11:8080)
•When the PC is in a local network, configure the proxy server setting of the web browser (under
[Internet Options...] under [Tools] of the menu bar) to bypass the proxy server for the local address.
Note
•Refer to page 151 for further information about the case in which “HTTPS” is selected for
“HTTPS” - “Connection” on the [Network] tab of the “Network” page (®page 136).
Operating Instructions 7
1 Monitor images on a PC

3. Press the [Enter] key on the keyboard.
→The “Live” page will be displayed. Refer to page 9 for further information about the “Live” page.
When “On” is selected for “User auth.”, the authentication window will be displayed before displaying live
images for the user name and password entries. The default user name and password are as follows.
User name: admin
Password: 12345
IMPORTANT
•To enhance the security, change the password for the user name “admin”. It is recommended to change
this password periodically.
•When displaying multiple H.264 images on a PC, images may not be displayed depending on the
performance of the PC.
Note
•The maximum number of concurrent access user is 14 including users who is receiving H.264 images
and users who are receiving JPEG images. Depending on the set values for “Bandwidth control(bit
rate)” and “Max bit rate (per client)”, the maximum concurrent access number may be 14 or less users.
When 14 users are concurrently accessing, the access limit message will be displayed for users who
subsequently attempt to access. When “Multicast” is selected for “Transmission type” of “H.264”, only
the first user who accessed to monitor H.264 images will be included in the maximum number. The
second and subsequent users who are monitoring H.264 images will not be included in the maximum
number.
•When “On” is selected for “H.264 transmission” (®page 80), H.264 images will be displayed. When
“Off” is selected, a JPEG image will be displayed. It is possible to display a JPEG image even when
“On” is selected for “H.264 transmission”. In this case, the refresh interval of JPEG images will be
limited to 5 fps.
•The refresh interval may become longer depending on a network environment, PC performance,
photographic subject, access traffic, etc.
<Refresh interval of JPEG images>
When “On” is selected for “H.264 transmission”
–When “2 mega pixel [16:9]” / “1.3 mega pixel [16:9]” / “1.3 mega pixel [4:3]” is selected for “Image
capture mode”: max. 5fps
–When “3 mega pixel [4:3]” is selected for “Image capture mode”: max. 5fps
When “Off” is selected for “H.264 transmission”
–When “2 mega pixel [16:9]” / “1.3 mega pixel [16:9]” / “1.3 mega pixel [4:3]” is selected for “Image
capture mode”: max. 30fps
–When “3 mega pixel [4:3]” is selected for “Image capture mode”: max. 15fps
8 Operating Instructions
1 Monitor images on a PC

1.2 About the “Live” page
NPS
QR
K
A
B
D
E
F
C
G
H
I
T
L
M
J
O
[select language] pull-down-menu
The camera’s display language can be selected. The default language can be set in the [Language] in the
[Basic] settings. (®page 46)
[Setup] button*1
Displays the setup menu. The button will turn green and the setup menu will be displayed.
[Live] button
Displays the “Live” page. The button will turn green and the “Live” page will be displayed.
[Compression] buttons
•[H.264] button: The characters “H.264” on the button will turn green and an H.264 image will be
displayed. When “On” is selected for “H.264 transmission” of “H.264(1)”, “H.264(2)”, the [H.264] button
will be displayed. (®page 80)
•[JPEG] button: The characters “JPEG” on the button will turn green and a JPEG image will be
displayed.
[Stream] buttons
These buttons will be displayed only when an H.264 image is displayed.
•[1] button: The character “1” will turn green and images in the main area will be displayed in
accordance with the setting of “H.264(1)”. (®page 80)
•[2] button: The character “2” will turn green and images in the main area will be displayed in
accordance with the setting of “H.264(2)”. (®page 80)
[Image capture size] buttons
These buttons will be displayed only when a JPEG image is displayed.
•[VGA] button: The characters “VGA” will turn green and images in the main area will be displayed in
VGA size.
•[QVGA] button: The characters “QVGA” will turn green and images in the main area will be displayed
in QVGA size.
•[1280x960] button: The characters “1280x960” will turn green and images in the main area will be
displayed in 1280 x 960 (pixels).
Operating Instructions 9
1 Monitor images on a PC

•[640x360] button: The characters “640x360” will turn green and images in the main area will be
displayed in 640 x 360 (pixels).
•[320x180] button: The characters “320x180” will turn green and images in the main area will be
displayed in 320 x 180 (pixels).
•[1280x720] button: The characters “1280x720” will turn green and images in the main area will be
displayed in 1280 x 720 (pixels).
•[1920x1080] button: The characters “1920x1080” will turn green and images in the main area will be
displayed in 1920 x 1080 (pixels).
•[2048x1536] button: The characters “2048x1536” will turn green and images in the main area will be
displayed in 2048 x 1536 (pixels).
Note
•The buttons [VGA], [QVGA], and [1280x960] are displayed only when “1.3 mega pixel [4:3]” is
selected for “Image capture mode”.
•The button [2048x1536] is displayed only when “3 mega pixel [4:3]” is selected for “Image capture
mode”.
•The buttons [640x360] and [320x180] are displayed only when “2 mega pixel [16:9]” or “1.3 mega
pixel [16:9]” is selected for “Image capture mode”.
•The button [1280x720] is displayed only when “1.3 mega pixel [16:9]” is selected for “Image capture
mode”.
•The button [1920x1080] is displayed only when “2 mega pixel [16:9]” is selected for “Image capture
mode”.
•When “2048x1536”, “1920x1080”, “1280x960”, or “1280x720” is selected for the image capture
size, it may become smaller than the actual size depending on the window size of the web browser.
[Image quality] buttons
These buttons will be displayed only when a JPEG image is displayed.
•[1] button: Images in the main area will be displayed in accordance with the setting for “Quality1” of
“Image quality setting”. (®page 76)
•[2] button: Images in the main area will be displayed in accordance with the setting for “Quality2” of
“Image quality setting”. (®page 76)
[Zoom] buttons
Images will be zoomed in on with the electronic zoom by the viewer software “Network Camera View
4S”.
•[x1] button: The character “x1” will turn green and images in the main area will be displayed at x1.
•[x2] button: The character “x2” will turn green and images in the main area will be displayed at x2.
•[x4] button: The character “x4” will turn green and images in the main area will be displayed at x4.
[Brightness] buttons*2
The brightness is adjustable from 0 to 255.
• (darker) button: Images become darker.
• button: The adjusted brightness will return to the default brightness (64).
• (brighter) button: Images become brighter.
[Cropping] display
Cropping setup display is only displayed when the images set in “Cropping” on the [Cropping] tab of the
“Advanced view” page are displayed in the main area. (®page 120)
Within the full angle image, the white outlines display what position the image was cropped from. During
sequence operations, the cropping positions used by the sequence function are displayed in multiple white
outlines (the display shown in the cropping display is not updated by changes to the position of the
sequence or images).
[Rec. on SD] button*2
This button will be displayed only when “Manual” is selected for “Save trigger” on the setup menu.
(®page 54)
10 Operating Instructions
1 Monitor images on a PC

Click this button to manually record images on the SD memory card. Refer to page 21 for descriptions
of how to manually record images on the SD memory card.
[Log] button*1
[List] button will become available only when “On” is selected for “Save logs” on the setup menu.
(®page 69)
When this button is clicked, the log list will be displayed and images saved on the SD memory card can
be played. Refer to page 27 for further information about the log list and for how to play images on the
SD memory card.
[Multi-screen]
Images from multiple cameras can be displayed on a multi-screen by registering cameras on the setup
menu. (®page 15)
Camera title
The camera title entered for “Camera title” on the [Basic] tab will be displayed. (®page 46)
Alarm occurrence indication button*2
This button will be displayed and will blink when an alarm has occurred. When this button is clicked, it will
disappear. (®page 23)
Full screen button
Images will be displayed on a full screen. To return to the “Live” page, press the [Esc] key. The aspect ratio
of displayed images will be adjusted in accordance with the monitor.
Snap shot button
Click this button to take a picture (a still picture). The picture will be displayed on a newly opened window.
When right-clicking on the displayed image, the pop-up menu will be displayed. It is possible to save the
image on the PC by selecting “Save” from the displayed pop-up menu.
When “Print” is selected, printer output is enabled.
Note
•For the case of using Windows 8, Windows 7, or Windows Vista, the following settings may be
required.
Open Internet Explorer, click [Tools] ® [Internet Options] ® [Security] ® [Trusted Sites] ®
[Sites]. Register the camera address on [Website] of the displayed trusted widows.
•When it takes longer than the specified period to obtain the snap shot picture due to the network
environment, the snap shot picture may not be displayed.
Mic input button*3
Turns on/off the audio reception (hear audio from the camera on a PC). This button will be displayed only
when “Mic input” is selected for “Audio mode” on the setup menu. (®page 102)
When this button is clicked, the button will turn into the button and audio from the camera will not be
heard on the PC.
Audio volume can be adjusted (Low/ Middle/ High) by moving the volume cursor .
Note
•The volume cursor is not displayed when “Audio recording” or “Audio detection” is used.
SD recording status indicator
The status of the SD recording can be checked with this indicator.
When the SD recording starts, the SD recording status indicator will light red. It will go off when the SD
recording stops.
This indicator will be displayed when “Manual” or “Schedule” is selected for “Save trigger” on the setup
menu. (®page 51)
Main area
Images from the camera will be displayed in this area.
The current time and date will be displayed according to the settings configured for “Time display format”
and “Date/time display format”. (®page 47)
Operating Instructions 11
1 Monitor images on a PC

Note
•When operated by a lower access level user, images displayed on the screen may be changed
temporarily. This does not affect operation of the camera.
•Depending on the PC in use, screen tearing* may occur when the shooting scene drastically
changes due to the GDI restrictions of the OS.
*A phenomenon in which portions of the screen are displayed out of alignment.
*1 Only operable by users whose access level is “1. Administrator”.
*2 Only operable by users whose access level is “1. Administrator” or “2. Camera control” when “On” is selected for “User auth.”
(®page 126)
*3 Operable by users who belong to the access level selected for “Permission level of audio trans./recep.” on the [Audio] tab of the
“Image/Audio” page. Refer to page 102 for the permission level of audio.
1.3 Monitor cropping images
Full angle images and cropping images can be transmitted at the same time.
The cropping function must be configured in order to transmit cropping images. (®page 120)
H.264(2) or JPEG (VGA/QVGA/640x360/320x180) images can be set as cropping images.
By matching the settings of the [Compression] and [Stream] buttons on the “Live” page to the “Cropping”
settings (“H.264”, “JPEG(VGA)/JPEG(640x360)”, or “JPEG(QVGA)/JPEG(320x180)”) configured on the
[JPEG/H.264] tab, cropping images will be displayed on the [Cropping] display of the “Live” page and the main
area.
Cropping
A
You can crop areas that you want to monitor.
By setting multiple cropping areas, up to 4 areas can be displayed in a sequence.
12 Operating Instructions
1 Monitor images on a PC

Sequence display using the cropping function
A
B
C
ABCABC
Note
•The cropping function can be used only when “2 mega pixel [16:9]”, “1.3 mega pixel [16:9]”, or “1.3
mega pixel [4:3]” is selected for “Image capture mode”.
1.4 Monitor picture in picture images
By using the picture in picture function, a cropping image or an alarm image can be added to an image and
transmitted.
The picture in picture function must be configured before it can be used. (®page 121)
When the picture in picture function is used, combined JPEG and H.264 images with the following image
capture sizes are transmitted.
•When “2 mega pixel [16:9]” is selected for “Image capture mode”: 1920x1080
•When “1.3 mega pixel [16:9]” is selected for “Image capture mode”: 1280x720
•When “1.3 mega pixel [4:3]” is selected for “Image capture mode”: 1280x960
Note
•The picture in picture function can only be used when “2 mega pixel [16:9]”, “1.3 mega pixel [16:9]”, or
“1.3 mega pixel [4:3]” is selected for “Image capture mode”.
The type of images to be combined can be selected from “Picture in picture mode” on the [PiP] tab
(®page 121).
When “Live” is selected in “Picture in picture mode”, a predetermined area is combined as a sub image and
transmitted.
Operating Instructions 13
1 Monitor images on a PC

When an alarm action is selected in “Picture in picture mode”, a predetermined area is transmitted as a sub
image according to each setting.
A
B
Main image
Sub image
14 Operating Instructions
1 Monitor images on a PC

1.5 Monitor images from multiple cameras
Images from multiple cameras can be displayed on a multi-screen. Images from 4 cameras (up to 16 cameras)
can be displayed simultaneously. To display images on a multi-screen, it is necessary to register cameras in
advance. 4 cameras can be registered as a group and up to 4 groups (16 cameras) can be registered.
(®page 104)
IMPORTANT
•When displaying images on a 16-screen, panning, tilting and zooming operations become unavailable
for images from cameras with Pan/Tilt/Zoom functions.
•When the power is turned off or the LAN cable is disconnected while displaying images, displaying
images on a multi-screen from the “Live” page will become unavailable.
Note
•When displaying images on a 4-screen, panning, tilting and zooming operations become available only
for images from cameras with Pan/Tilt/Zoom functions. Refer to our website
(http://security.panasonic.com/pss/security/support/info.html) for further information about the
compatible cameras and their versions.
•Only JPEG images can be displayed on a multi-screen. Audio will not be heard.
•When displaying the image on a multi-screen and “16:9” is selected for the aspect ratio, the image will
be displayed altered vertically to the aspect ratio of “4:3”.
•“Network Camera Recorder with Viewer Software Lite” which supports live monitoring and recording
images from multiple cameras is available. For further information, refer to our website
(http://security.panasonic.com/pss/security/support/info.html).
1. Click the desired [Multi-screen] on the “Live” page.
→Images from the registered cameras will be displayed on a selected multi-screen (screen can be split
up to 16 areas). The following are instructions when displaying on a 4-split screen.
C
AB
To show 1 camera screen, click the [Live] button.
You can also click “1” below “Multi-screen” or “Back” to display 1 screen of the camera.
Click the [Multi-screen] button to display images from cameras in a multi-screen of 4 to 16 screens.
Click a camera title. Live images from the camera corresponding to the clicked camera title will be
displayed on the “Live” page of the newly opened window.
Operating Instructions 15
1 Monitor images on a PC

2 Monitor images on a cellular phone/mobile
terminal
2.1 Monitor images on a cellular phone
It is possible to connect to the camera using a cellular phone via the Internet and monitor images (JPEG only)
from the camera on the screen of the cellular phone.
IMPORTANT
•When the authentication window is displayed, enter the user name and password. The default user
name and password are as follows.
User name: admin
Password: 12345
To enhance the security, change the password for the user “admin”. (®page 126)
•If the cellular phone in use is not compatible with UTF-8 encode, it is impossible to display the screen
correctly.
•When “3 mega pixel [4:3]” is selected for “Image capture mode”, images cannot be monitored on a
cellular phone. Select “2 mega pixel [16:9]”, “1.3 mega pixel [16:9]”, or “1.3 mega pixel [4:3]” for “Image
capture mode” to monitor images.
Note
•It is necessary to configure the network settings of the cellular phone in advance to connect to the
Internet and monitor images from the camera. (®page 136)
1. Access to “http://IP address/mobile”*1 or “http://Host name registered in the DDNS server/mobile” using a
cellular phone.
→Images from the camera will be displayed.
B
C
A
16 Operating Instructions
2 Monitor images on a cellular phone/mobile terminal

Functions Outline of functions
A Refresh control Press the dial key “5” or the [Manual Refresh] button to refresh the camera
images.
Press the [Auto Refresh] button to refresh the images from the camera in
5-second intervals.
When the dial key “5” or the [Manual Refresh] button is pressed again, the
refresh mode of the camera will return to manual refresh.
IMPORTANT
•Transmission will be periodically performed when “Auto Refresh” is
selected for the camera image. Confirm the contract plan of the
cellular phone in use before using this function.
•Depending on the cellular phone in use, “Auto Refresh” may be
unavailable.
B Resolution control Changes the image capture size by pressing the dial key “0”.
•Image in the aspect ratio of “4:3” Changes the image capture size
between 320x240 (default) and
640x480.
•Image in the aspect ratio of
“16:9”
Changes the image capture size
between 320x180 (default) and
640x360.
C Image quality
control
It is possible to change the image quality between “Quality1” and
“Quality2”. (®page 76)
Note
•Some cellular phones cannot change the image capture size even when resolution is changed by
resolution control.
•When the HTTP port number is changed from “80”, enter “http://IP address: (colon) + port number/
mobile”*1 in the address box of the browser. When using the DDNS function, access to “http://Host
name registered in the DDNS server: (colon) + port number/mobile”.
•When “HTTPS” is selected for “HTTPS” - “Connection” on the [Network] tab of the “Network” page,
enter as follows.
“https://IP address: (colon) + port number/mobile” or “https://Host name registered in the DDNS server:
(colon) + port number/mobile”
•When the authentication window is displayed, enter the user name of an administrator or user and
password. Depending on the cellular phone in use, password entry may be required each time the
screen is switched.
•It is impossible to transmit/receive audio using a cellular phone.
•Depending on the cellular phone in use, larger size images may not be displayed. In this case, selecting
“9 Low” for “Image quality setting” of “JPEG” (®page 76) may sometimes solve this problem.
•Depending on the cellular phone in use or its contract plan, it may be impossible to access.
*1 IP address is the global WAN IP address of the router that can be accessed via the Internet.
Operating Instructions 17
2 Monitor images on a cellular phone/mobile terminal

2.2 Monitor images on a mobile terminal
It is possible to connect to the camera using a mobile terminal via the Internet and monitor images (MJPEG
only) from the camera on the screen of the mobile terminal. Images are refreshed automatically to display the
latest image.
The compatible mobile terminals are shown as follows. (As of February, 2013)
–iPad, iPhone, iPod touch (iOS 4.2.1 or later)
–Android™ mobile terminals
When an Android terminal is used, an MJPEG format image is displayed by the Firefox® browser, but a JPEG
format image is displayed by the standard browser.
For further information about compatible devices, refer to our website
(http://security.panasonic.com/pss/security/support/info.html).
IMPORTANT
•When the authentication window is displayed, enter the user name and password. The default user
name and password are as follows.
User name: admin
Password: 12345
To enhance the security, change the password for the user “admin”. (®page 126)
•When “3 mega pixel [4:3]” is selected for “Image capture mode”, images cannot be monitored on a
mobile terminal. Select “2 mega pixel [16:9]”, “1.3 mega pixel [16:9]”, or “1.3 mega pixel [4:3]” for “Image
capture mode” to monitor images.
•When “2 mega pixel [16:9]” is selected for “Image capture mode”, the maximum image capture size is
640x360.
Note
•It is necessary to configure the network settings of the mobile terminal in advance to connect to the
Internet and monitor images from the camera. (®page 136)
18 Operating Instructions
2 Monitor images on a cellular phone/mobile terminal

1. Access to “http://IP address/cam”*1 or “http://Host name registered in the DDNS server/cam”*2 using a
mobile terminal.
→Images from the camera will be displayed.
B
A
Live images area
Displays images from the camera.
Resolution ratio control area
Displays the available resolution ratio buttons.
Switch the resolution ratio by selecting the appropriate resolution ratio button.
Image capture mode
•“2 mega pixel [16:9]” images: 320x180/640x360 (default)
•“1.3 mega pixel [16:9]” images: 320x180/640x360 (default)/1280x720
•“1.3 mega pixel [4:3]” images: 320x240/640x480 (default)/1280x960
Note
•You can change the image size displayed on the mobile terminal by accessing the following addresses.
–Large display: http://IP address/cam/dl
–Medium display: http://IP address/cam/dm
–Small display: http://IP address/cam/ds
•When the resolution is changed by the resolution control, the displayed resolution changes but the
image size remains the same.
•When the HTTP port number is changed from “80”, enter “http://IP address: (colon) + port number/
cam”*1 in the address box of the browser. When using the DDNS function, access to “http://Host name
registered in the DDNS server: (colon) + port number/cam”*2.
•When “HTTPS” is selected for “HTTPS” - “Connection” on the [Network] tab of the “Network” page,
enter as follows.
Operating Instructions 19
2 Monitor images on a cellular phone/mobile terminal

“https://IP address: (colon) + port number/cam” or “https://Host name registered in the DDNS server:
(colon) + port number/cam”
•When the authentication window is displayed, enter the user name of an administrator or user and
password. Depending on the mobile terminal in use, password entry may be required each time the
screen is switched.
•It is impossible to transmit/receive audio using a mobile terminal.
•Depending on the mobile terminal in use, larger size images may not be displayed. In this case,
selecting “9 Low” for “Image quality setting” of “JPEG” (®page 76) may sometimes solve this
problem.
•Depending on the mobile terminal in use or its contract plan, it may be impossible to access.
*1 IP address is the global WAN IP address of the router that can be accessed via the Internet. However, when accessing the same
LAN as the camera with a wireless compatible mobile terminal, the IP address is the local IP address.
*2 Only when accessing the camera via the Internet.
