Color Network Camera
WV-NP244*
• Dual MPEG-4/JPEG
selectable output
• 30 fps – VGA in MPEG-4
or JPEG mode
• Power over Ethernet:
IEEE 802.3af
• 1/3" Progressive scan CCD
• Video Motion Detection
•SD memory card slot for manual alarm or network failure recording
• One way audio (G.726)
• ALC
* lens optional
Megapixel Day/Night Color
Network Camera
WV-NP1004*
• 1.25 million pixels (1280 x 960) CCD for smooth
reproduction of moving objects
• Dual MPEG-4/JPEG
selectable output
• Day/night switching for
24-hour surveillance
•SD memory card slot for
manual alarm or network
failure recording
• Auto Back Focus for perfect focus in color or B/W mode
* lens optional
i-Pro intelligent and professional IP video security solutions make your network better.
Our expanding i-Pro Series combines Panasonic performance and quality with the latest
advancements in IP technology. And with a growing line of IP cameras network video recorders
video servers and management software you can design the system configuration that best
meets your needs today - with an eye on expansion tomorrow. Now that’s security you
can take into the future. Panasonic i-Pro. It’s what’s on your network that counts.
i-Pro: intelligent and professional IP/networking solutions
it’s what’s on your network that counts
Color Fixed Mini Dome
Network Camera
WV-NF284
• Dual MPEG-4 and JPEG selectable
output for simultaneous monitoring
and recording of images
• Progressive scan CCD for smooth
images of moving objects and
superb color reproduction
• PoE for cost-efficient cabling and easy installation
• 30 fps - VGA in MPEG-4/JPEG mode
• Video Motion Detection transmits an alarm signal
when moving objects enter monitored area
•SD memory card slot for manual alarm or network failure recording
• Built-in microphone (G.726)
Ruggedized Megapixel Day/Night
Fixed Dome Network Camera
WV-NF302
• 1280 x 960 megapixel high quality image
for superior identification
• MPEG-4/JPEG digital signal output at VGA
with up to 30 ips
• Progressive output for smooth images of
moving objects and superb color reproduction
• PoE for cost-efficient cabling and easy installation
• Adaptive Black Stretch enhances visibility of dark areas
• Focus assist function achieves best focus position on screen
• Alarm-activated dynamic compression for better
identification and bandwidth optimization
• SD memory card slot for manual alarm or network failure recording
NEW!
NEW!
Megapixel Day/Night Network Camera
WV-NP304
• 1280 x 960 megapixel high quality image
for superior identification
• MPEG-4/JPEG digital signal output
at VGA with up to 30 ips
• Progressive output for smooth
images of moving objects and
superb color reproduction
• PoE for cost-efficient cabling and easy installation
• Adaptive Black Stretch enhances visibility of dark areas
• Focus assist function achieves best focus position on screen
• Alarm-activated dynamic compression for better
identification and bandwidth optimization
• SD memory card slot for manual alarm or network failure recording
For real megapixel image
quality and variable
angle view use optional
1.3 megapixel lens
Super Dynamic III Weather Proof
Day/Night Dome Network Camera
WV-NW964
• Super Dynamic III (SDIII) technology delivers
128x wider dynamic range and Intelligent
Technology features for exceptional images
in virtually any lighting condition
• Progressive output for smooth images
of moving objects and superb color reproduction
• 360º endless panning (0.065º/s – 400º/s)
• 0.5 lux min. illumination color 0.04 lux B/W
• Auto tracking Auto Image Stabilization
• Digital slip ring ensures picture quality since no DA/AD conversion
• Dual MPEG-4/JPEG streaming
• 30x optical zoom 10x electronic (300x total)
•SD memory card slot for manual alarm or network failure recording
Super Dynamic III Day/Night
Dome Network Camera
WV-NS9 4
• Super Dynamic III (SDIII) technology delivers
128x wider dynamic range and Intelligent
Technology features for exceptional images
in virtually any lighting condition
• Progressive output for smooth images
of moving objects and superb color reproduction
• 360º endless panning (0.065º/s – 400º/s)
• 0.5 lux minimum illumination color 0.04 lux B/W
• 30x optical zoom 10x electronic (300x total)
•SD memory card slot for manual alarm or network failure recording
• Dual MPEG-4 and JPEG streaming
• Auto tracking Auto Image Stabilization
• Digital slip ring ensures picture quality since no DA/AD conversion
Super Dynamic III Vandal-Proof Day/Night
Fixed Dome Network Camera
WV-NW484S
• Super Dynamic III (SDIII) technology delivers
128x wider dynamic range and Intelligent
Technology features for exceptional images
in virtually any lighting condition
• Progressive output for smooth images
of moving objects and superb color reproduction
• Vandal Auto Back Focus automatically adjusts
camera focus when switching from color to B/W
• PoE for cost-efficient cabling and easy installation
• High sensitivity: 0.6 lux color 0.08 lux B/W (w/clear dome)
•SD memory card slot for manual alarm or network failure recording
Super Dynamic III Day/Night
Dome Network Camera
WV-NS202A
• Super Dynamic III (SDIII) technology delivers
128x wider dynamic range and Intelligent
Technology features for exceptional images
in virtually any lighting condition
• Progressive output for smooth images
of moving objects and superb color reproduction
• 22x optical zoom for accurate capture of objects from long distances
• PoE for cost-efficient cabling and easy installation
• 0.7 lux min. illumination color 0.5 lux B/W
• Drag and zoom feature
•SD memory card slot for manual alarm or network failure recording
Network and Analog Unitized
PTZ Dome Camera
WV-NS324
• Network and analog connectivity
• 360oendless panning
• High sensitivity: 1.0 lux in color
(0.25 lux @ 4x sensitivity)
• Over 480 lines of resolution
• 10x optical zoom / 5x digital zoom
• Video Motion Detection
• 16 presets
• 24V AC
• Built-in web server

March 2008
Removable Disk
Network Video Recorder (NVR)
WJ-ND200
• Removable 2.5" HDD for easy
archiving and management
• Multi-format: JPEG
and MPEG-4
• High reliability through embedded Real-Time OS
• Mirroring recording function with 2 HDD’s
• Audio recording and playback
•SD memory card slot for manual alarm or network failure recording
• Up to 2 ruggedized HDD’s (160GB each)
• Direct video playback through a PC with optional HDD cradle
(WJ-HDC20)
• For small-mid sized applications
Network Video Recorder (NVR)
WJ-ND300A
• High speed throughput
- 3 dedicated ports
(camera/client/setup)
• Auto IP setup for Panasonic cameras
• Accepts JPEG MPEG-4 & analog cameras (w/encoder)
• MPEG-4 rate control recording - full rate “I” frame
recording only for efficient recording and viewing
• Data stream control: live/recording
• Base unit capacity 2TB; expandable to 14TB
• Live viewing and PTZ camera control
• Download pictures to PC
• Accepts other camera manufacturer’s input
• Raid 5 board (optional)
• For mid-large sized applications
i-Pro Management Software Solution
for Panasonic NVR’s & DVR’s
WV-ASM100
• Control up to 100
Panasonic recorders
• Live viewing and alarm
message pop-up
• MPEG-4 live performance
• Control of Panasonic PTZ cameras
• Multiple displays
(operation live maps)
• Joystick controller capability with optional WV-CU950
• Status/health check for recorders
• Independent camera/encoder support
i-Pro Monitoring Software
WV-ASM10
• Multi-screen software decoder
designed for control rooms
• Up to 16 recorders and
256 network cameras
can be registered
• MPEG-4 and JPEG formats
• Live display and sequence play by
1/4/6 /9/16 screen
• Open interface for external control
• Supports i-Pro cameras recorders encoders
• Camera title display – 16 characters
Network Video Recorder
WJ-ND400
• MPEG-4/JPEG
multi-format recording
• Up to 64 network cameras
can be connected and
recorded simultaneously
• Up to 9 hot-plug HDDs can be installed
• 8 recording programs and up to 6x schedule per day
• Free camera license for cost-effective camera expandability
• Browser interface can be used to view content;
no extra software required
• High reliability through embedded Real-Time OS
i-Pro 4 Channel MPEG-4/JPEG
Video Encoder
WJ-NT304
• Allows for smooth migration
to IP system utilizing
existing analog cameras
• Transmit VGA (640 x 480) images in either
MPEG-4 or JPEG up to 30 fps
• MPEG-4/JPEG dual output
• 4 channel input with 2 way audio
• Panasonic camera control over coax
•SD memory card slot for manual alarm or network failure recording
Encoder/Decoder
WJ-GXE900 / WJ-GXD900
• Video and audio encoder/decoder
• Low delay of 150ms
• Monitor images at any
location any distance
• Simultaneous monitoring of 4 channels
• Flexible architecture
• Multicast transmission ensures efficient use of network
• Provides broadcast-quality images
Visit www.panasonic.com/security for the latest product information
© Copyright 2008 Panasonic Corporation of America. All rights reserved. Specifications are subject to change without notice. Panasonic cannot be responsible for network
performance and/or other manufacturers’ products that reside on the network. These products may be subject to export control regulations.
Multi-Channel High-Definition
Video Decoder
WJ-GXD400
• HDMI video interface
• VGA image displayed
at 30ips/sec
• MPEG-4 live performance
• Registers up to 256 cameras
• Supports multicast/unicast
for efficient network usage
• High-speed network interface
• High reliability through embedded real-time OS
4 Channel MPEG-4/JPEG Video Encoder
with Video Analytics
WJ-NT314
• 4 channel MPEG-4/JPEG encoder
with 2 channel
advanced analytics
• Intruder detection
• Object detection (removed or left behind)
• Frame and track display on browser
• Automatic 3D object size calculation
•SD memory card slot for manual alarm or network failure recording
• Up to 8 detected objects can be identified (per channel)
• Progressive output
Sales Support
For all inquiries regarding dealer applications Business Link
accounts/resets return requests and general questions.
Toll-Free Phone: [phone] (option 3)
Fax: [phone]
Government Sales
GSA Contract Number
For All Security Products: GS-07F-0698N
Toll-Free Phone: [phone] (option 4)
Technical Support
For technical support on installation programming
and configuration.
Toll-Free Phone: [phone]
Toll-Free Fax: [phone]
[email protected]
Headquarters
Panasonic Security Systems
A division of Panasonic System Solutions Company
Three Panasonic Way 2H-2
Secaucus NJ 07094
Toll-Free Phone: [phone]
Training
Visit www.panasonic.com/P-Tech
Panasonic Solution Developer
Network program (PSDN)
PSDN is a cooperative program designed to offer participants
open development tools technical information and protocols to
encourage and accelerate the development of integrated and
inter-operable system solutions. Visit www.psdn.info
i-Pro Certified Reseller Program
Panasonic Security Systems offers the i-Pro Certified Reseller
(IPCR) Program to train highly capable channel resellers who can
design implement and support newly emerging opportunities in
the IP/IT security space. Key benefits include:
- Free training through P-Tech
- Easy availability of Panasonic’s leading i-Pro IP product lineup
- Subsidized demo equipment
- Resource-rich sales and marketing materials
- And more...
More detailed information about the certification process and
training requirements are available at www.panasonic.com/P-Tech.
Order Placement
To place modify or check an order or make shipping changes.
Toll-Free Phone: [phone]
Toll-Free Fax: [phone]
Technology in Detail Guide
Resources
MEG-4/J EG Selectable compression technologies.
MEG-4 is a Wavelet-based file that
delivers professional quality audio and
video streams over a wide range of
bandwidths. Defined by the Moving
ictures Expert Group (M EG) and was
standardized in October 1998. J EG is
the standard for compressing still
images. It produces high quality images
but typically requires more space for
storage. Defined by the Joint
hotographic Experts Group.
SDII Exclusive anasonic technology offers
64 times greater dynamic range
producing exceptional images even
in high contrast lighting, compared
to a conventional camera.
SDIII Offers numerous camera performance
attributes including: 128x dynamic
range; pixel-based digital contrast
correction; auto image stabilizer; scene
change detection; 30X optical zoom
(300X electronically); adaptive digital noise
reduction; 540 lines of color resolution;
and extreme low light sensitivity in color
(0.5 lux) and B/W (0.06 lux). Check
individual products for exact specifications.
SD Card “Secure Digital”- A small memory card
featuring a high data transfer rate and
encryption capability to protect content.
Up The Coax Supports Up-the-Coax (coaxial cable)
signal transmission and control.
22x optical zoom Equates to 3.8mm to 83mm focal length
lens with 10x digital zoom, providing
220x total zoom capability.
30x optical zoom Equates to 3.8mm to 114mm focal
length lens with 10x digital zoom,
providing 300x total zoom capability.
Auto Back Focus Optimizes the back focus automatically
for clear, sharp images. The CCD
position automatically adjusts when
changing from color to B/W mode,
eliminating any focus shift problems.
Day/Night Camera will automatically or manually
switch from color mode (daytime)
to B/W mode (nighttime) to achieve
optimal viewing.
Hybrid roduct with both analog and
I /networking connectivity.
I 66 “Ingress rotection 66” - the 66 refers
to ingress protection for dust, and water
from heavy seas, or water projected in
powerful jets shall not enter the
enclosure in harmful quantities.
MEGA ixel A resolution of one million pixels.
oE ower over Ethernet (IEEE802.3af).
Ready Tuff Vandal-resistant or vandal-proof
camera designation.
Super Dynamic II Day/Night
Network Camera
WV-NP472*
• Network and analog connectivity
• 480 lines color 570 lines B/W
• Wide dynamic range for
contrasted lighting
• Day/Night switching for 24-hour surveillance
• Built-in digital motion detector
• Built-in web server
• 12V DC
* lens optional
NEW!
NEW!
