The service technician is required to read and follow the “safety precautions”and“important safety notice” in this main manual.
Service Manual
Color Television
(NA7DM)
Simplified Manual
Copyright2002 by Matsushita Electric Corporation of
America. All rights reserved. Unauthorized copying
and distribution is a violation of law.
“WARNING! This Service Manual is designedfor experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to
service or repair the product or products dealt with in this Service Manual by anyone else could result in serious injury or death.”
Chassis
CT-20G7DF-1 DP391
CT-20D12DF-1 EP391
CT-2017F-1 DP391
Models
ORDER NO. MTNC021096A1
B1
This supplement service manual is issued to ADD the models of the NA7DM family listed above to the simplified
service manual order No. MTNC020515A1 (CT-20D12F). Included in this supplement service manual are unique
characteristics and a complete parts list. Please file and use this simplified service manual together with the simplified
service manual order No. MTNC020515A1 (CT-20D12F) and the main service manual order No. MTNC010305C1
(CT-32D11E).
Simplified
Since “-1” and non dash models have different PCB layouts and parts;
When servicing any of these models please confirm the model number
before starting service so the correct manual is used.
Important notice:

-2-
Important safety notice
Special components are used in this television set which are important for safety. These parts are identified on the
schematic diagram by the symbol and printed in BOLD TYPE on the replacement part list. It is essential that
these critical parts are replaced with the manufacturer’s specified replacement part to prevent x-ray radiation,
shock, fire or other hazards. Do not modify the original design without the manufacturer’s permission.
Safety precautions
General guidelines
An Isolation Transformer should always be used
during the servicing of a receiver whose chassis is not
isolated from AC power line. Use a transformer of
adequate power rating as this protects the technician
from accidents resulting in personal injury from
electrical shocks. It will also protect the receiver from
being damaged by accidental shorting that may occur
during servicing.
When servicing, observe the original lead dress,
especially in the high voltage circuit. Replace all
damaged parts (also parts that show signs of
overheating.)
Always replace protective devices,suchas
fishpaper, isolation resistors and capacitors, and
shields after servicing the receiver. Use only
manufacturer’s recommended rating for fuses, circuits
breakers, etc.
High potentials are present when this receiver is
operating. Operation of the receiver without the rear
cover introduces danger for electrical shock. Servicing
should not be performed by anyone who is not
thoroughly familiar with the necessary precautions
when servicing high-voltage equipment.
Extreme care should be practiced when handling the
picture tube. Rough handling may cause it to implode
due to atmospheric pressure. (14.7 lbs per sq. in.). Do
not nick or scratch the glass or subject it to any undue
pressure. When handling, use safety goggles and
heavy gloves for protection. Discharge the picture
tube by shorting the anode to chassis ground (not to
the cabinet or to other mounting hardware). When
discharging connect cold ground (i.e. dag ground lead)
to the anode with a well insulated wire or use a
grounding probe.
Avoid prolonged exposure at close range to unshielded
areas of the picture tube to prevent exposure to
x-ray radiation.
The test picture tube used for servicing the chassis at
the bench should incorporate safety glass and
magnetic shielding. The safety glass provide shielding
for the tube viewing area against x-ray radiation as well
as implosion. The magnetic shield limits the x-ray
radiation around the bell of the picture tube in addition
to the restricting magnetic effects. When using a
picture tube test jig for service, ensure that the jig is
capable of handling 35kV without causing
x-ray radiation.
Before returning a serviced receiver to the owner,
the service technician must thoroughly test the unit to
ensure that is completely safe to operate. Do not use a
line isolation transformer when testing.
Leakage current cold check
Unplug the AC cord and connect a jumper between the
two plug prongs.
Measure the resistance between the jumpered AC plug
and expose metallic parts such as screwheads,
antenna terminals, control shafts, etc.
If the exposed metallic part has a return path to the
chassis, the reading should be between 240kΩ and
5.2MΩ. If the exposed metallic part does not have a
return path to the chassis, the reading should be
infinite.
Leakage current hot check (Fig. 1)
Plug the AC cord directly into the AC outlet. Do not use
an isolation transformer during the check.
Connect a 1.5kΩ10 watt resistor in parallel with a
0.15µF capacitor between an exposed metallic part
and ground. Use earth ground, for example a
water pipe.
Using a DVM with a 1000 ohms/volt sensitivity or
higher, measure the AC potential across the resistor.
Repeat the procedure and measure the voltage
present with all other exposed metallic parts.
Verify that any potential does not exceed 0.75 volt
RMS. A leakage current tester (such a Simpson model
229, Sencore model PR57 or equivalent) may be used
in the above procedure, in which case any current
measure must not exceed 0.5 milliamp. If any
measurement is out of the specified limits, there is a
possibility of a shock hazard and the receiver must be
repaired and rechecked before it is returned to the
customer.
X-ray radiation
WARNING: The potential source of x-ray radiation in the
TV set are the high voltage section and the picture tube.
Refer to x-ray protecton circuit check in service
notes in this manual to confirm HHS voltage.
High voltage (CRT anode)
Confirm anode voltage is within limits:
Set the BRIGHTNESS, PICTURE, SHARPNESS and
COLOR to minimum (to obtain a dark image). Measure
high voltage. It should be:
26.60 ±1.25kV.
If the upper limit is out of tolerance, immediate service
and correction is required.
Note: It is important to use an accurate, calibrated
high voltage meter.
0.15µF
COLD
WATER
PIPE
(GROUND)
TO
INSTRUMENT’S
EXPOSED METAL
PARTS
1500Ω,10 W
AC VOLTMETER
Figure 1. Hot check circuit

-3-
Importantsafetynotice...................2
Safetyprecautions .................2
Generalguidelines.................2
Leakagecurrentcoldcheck..........2
Leakagecurrenthotcheck...........2
X-rayradiation.....................2
Highvoltage(CRTanode) ...........2
Servicenotes...........................4
Leadless chip component
(surfacemount) ................4
Componentremoval................4
Chip component Installation . .........4
HowtoreplaceFlat-IC ..............4
X-rayprotectioncircuitcheck.........5
Receiverfeaturetable....................6
Boardsdesignation......................7
Partslist...............................8
Foldoutsnotes.........................14
A-BoardTNP2AH048DR .................16
C-BoardTNP2AA124AF..................21
A-BoardTNP2AH048DS..................22
A&C-PCBBoard.......................28

-4-
Service notes
Leadless chip component
(surface mount)
Chip components must be replaced with identical chips
due to critical foil track spacing. There are no holes in
the board to mount standard transistors or diodes.
Some chips capacitor or resistor board solder pads
may have holes through the board, however the hole
diameter limits standard resistor replacement to 1/8
watt. Standard capacitor may also be limited for the
same reason. It is recommended that identical
components be used.
Chip resistor have a three digit numerical resistance
code - 1st and 2nd significant digits and a multiplier.
Example: 162 = 1600 or 1.6kΩresistor, 0 = 0Ω (jumper).
Chip capacitors generally do not have the value
indicated on the capacitor. The color of the component
indicates the general range of the capacitance.
Chip transistors are identified by a two letter code. The
first letter indicates the type and the second letter, the
grade of transistor.
Chip diodes have a two letter identification code as per
the code chart and are a dual diode pack with either
common anode or common cathode. Check the parts
list for correct diode number.
Component removal
1. Use solder wick to remove solder from component
end caps or terminal.
2. Without pulling up, carefully twist the component
with tweezers to break the adhesive.
3. Do not reuse removed leadless or chip
components since they are subject to stress
fracture during removal.
Chip component Installation
1. Put a small amount of solder on the board
soldering pads.
2. Hold the chip component against the soldering
pads with tweezers or with a miniature alligator clip
and apply heat to the pad area with a 30 watt iron
until solder flows. Do not apply heat for more than
3 seconds.
How to replace Flat-IC
- Required tools -
1. Cut the pins of the defective IC with the wire cutters
pliers, and remove it completely away from the
board. If the IC is glued to the board, apply hot air
to complete the removal. CAUTION- Do not pull or
twist the pliers, may damage the soldering pads in
the board.
2. Using the soldering Iron and the long nose pliers,
remove the IC pins that still attached to the board.
3. Using the de-solder braid and the soldering iron,
remove the solder from the board soldering pads.
4. Position the new Flat-IC in place (apply the pins of
the Flat-IC to the soldering pads where the pins
need to be soldered). Properly determine the
positions of the soldering pads and pins by
correctly aligning the polarity symbol. Start aligning
and soldering pin no.1, then align and solder the
pin in the apposite corner of the IC, this will help to
align the rest of the pins.
5. Solder all pins to the soldering pads using a fine
tipped soldering iron.
6. Check with a magnifier for solder bridge between
the pins or for dry joint between pins and soldering
pads. To remove a solder bridge, use a de-solder
braid as shown in the figure below.
Note: These components are affixed with glue. Be careful not to break or damage any foil under the
component or at the pins of the ICs when removing. Usually applying heat to the component for a short time
while twisting with tweezers will break the component loose.
c
b
e
Chip components
TRANSISTOR CAPACITOR
RESISTOR
MH DIODE
SOLDER
CAPS
SOLDER
CAPS
1ST DIGIT 2ND DIGIT
MULTIPLIER
=1600 = 1.6k
GRADE
TYPE
COMMON
ANODES
CATHODE
• Soldering iron • De-solder braids
• Sharpen pliers (wire
cutters and long nose) • Magnifier
Componente
plano
Cautin
malla
para desoldar
cautin
Iron
Muesca 2do punto 1er punto
Cautin con
punta fina
Soldadura
Malla
Puente
(en corto) Cautin

-5-
Service notes (continued)
IMPORTANT: To protect against possible damage to
the solid state devices due to arcing or static discharge,
make certain that all ground wires and CTR DAG wire
are securely connected.
CAUTION: The power supply circuit is above earth
ground and the chassis cannot be polarized. Use an
isolation transformer when servicing the receiver to
avoid damage to the test equipment or to the chassis.
Connect the test equipment to the proper ground ( ) or
( ) when servicing, or incorrect voltages will be
measured.
WARNING: This receiver has been designed to meet
or exceed applicable safety and x-ray radiation
protection as specified by government agencies and
independent testing laboratories.
To maintain original product safety design standards
relative to x-ray radiation and shock and fire hazard,
parts indicated with the symbol on the schematic
must be replaced with identical parts. Order parts from
the manufacturer’s parts center using the parts
numbers shown in this service manual, or provide the
chassis number and the part reference number.
For optimum performance and reliability, all other parts
should be replaced with components of
identical specification.
X-ray protection circuit check
This test must be performed as final check before the
receiver is returned to the customer. If voltage is out of
tolerance, immediate service and correction is required
to insure safe operation and to prevent the possibility of
premature component failure.
Equipment needed to check the protection circuit:
1. Isolator transformer.
2. High voltage meter.
3. Short jumper.
4. Diode connection jumper.
Use similar diode than D823, refer to parts list for
part No., (diode should support at least 150V.)
Procedure:
1. Connect receiver to isolator transformer.
2. Apply a monoscope pattern.
3. In service mode. (Refer to service mode section)
select register C0B.
4. Measure TP5 (TPs port close to tuner). Compare
the measure of TP5 and set the data for C0B
according the following table
5. Exit service mode and turn receiver OFF.
6. Connect a jumper from TPD16 to TPD17.
7. Connect the
diode jumper , cathode to TPD14
(cold GND), anode to TPD15 (hot GND).
Note: Refer to Fig. 2 for test point location.
8. Apply 75V AC to the AC input of the Insulator
transformer.Turn receiver ON.
9. Set PICTURE and BRIGTHNESS to minimum.
10. Increase the AC voltage at the input of Insulator
transformer and confirm the HHS voltage is
32.0kV, at the point set starts to loose sync,
11. Reset picture controls to original levels.
12. Turn the set OFF, and remove all jumpers and
connections from chassis.
TP5
MEASURE (V) DATA TO C0B (Hex)
0 ~ 0.93 00
0.93 ~ 0.97 01
0.97 ~ 1.01 02
1.01 ~ 1.05 03
1.05 ~ 1.09 04
1.09 ~ 1.13 05
1.13 ~ 1.17 06
1.17 ~ 1.21 07

-6-
Receiver feature table
FEATURE\MODEL CT-20G7DF-1 CT-20D12DF-1 CT-2017F-1
Chassis No DP391 EP391 DP391
Family NA7DM
Number of channels 181
Menu language ENG/SPAN/FR
Closed Caption X
V-Chip (USA/CANADA) X
75 Ωinput X
Remote Model number EUR501450 EUR511502 EUR501450
Picture tube Supplier SAMSUNG
Comb Filter 2DIG
V/A norm V
MTS/SAP/DBX X
Built-in audio power 1.5Wx2 (10%)
Number of speakers 2
AI Sound X
A/V in (rear/front) 1(1/1)
Audio Out (F:FAO/V:VAO) --- F,V ----
S-VHS In (rear/front) --- 1/0 ----
FM Radio --- X ---
EPJ/HPJ/MISC HPJ
Dimensions mm
(WxDxH) in 515.7x490.5x461.7 20.30x19.31x18.17
Weight (kg/lbs) 18/39.6
Anode voltage 26.60 ± 1.25 kV
Video input jack 1Vp-p 75Ω, phono
Audio input jack 500mV rms, 47KΩ
Table 1. Receiver features
Specifications are subject to change without notice or obligation.
Dimensions and weights are approximate.

-7-
Boards designation
Boards designation
*Note: When ordering a board, add and ”S” after the board suffix application.
Example, If order A-Board for
CT-2017F-1 , should be ordered as: TNP2AH048DRS.
MODELS BOARD PART NUMBER BOARD DESCRIPTION
CT-2017F-1
CT-20G7DF-1
A-Board TNP2AH048DR MAIN BOARD
C-Board TNP2AA124AF CRT BOARD
Table 1: Boards designation
MODELS BOARD PART NUMBER BOARD DESCRIPTION
CT-20D12DF-1 A-Board TNP2AH048DS MAIN BOARD
C-Board TNP2AA124AF CRT BOARD
Table 2: Boards designation
Since “-1” and non dash models have different PCB layouts and parts;
When servicing any of these models please confirm the model number
before starting service so the correct manual is used.
Important notice:

-8-
Parts List
REPLACEMENT PARTS LIST
Models: CT-20G7DF-1, CT-20D12DF-1, CT-2017F-1
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important for safety. When replacing
any of these components use only manufacturer’s specified parts.
302-02
PARTS LIST
REF
NO. PART NO. DESCRIPTION
CAPACITORS
C001 TCJ2VB1H103K CAP,C .01UF-K-50V
C002 TCJ2VB1H471K CAP,C 470PF-K-50V
C003 ECA1HM4R7B CAP,E 4.7UF-50V
C004 TCJ2VC1H150J CAP,C 15PF-J-50V
C005 TCJ2VC1H150J CAP,C 15PF-J-50V
C008 TCJ2VF1H104Z CAP,C .1UF-Z-50V
C009 ECA1AM470B CAP,E 47UF-10V
C010 TCJ2VF1H104Z CAP,C .1UF-Z-50V
C011 ECA1AM101B CAP,E 100UF-10V
C015 ECJ2VB1C224K CAP,C .22UF-K-16V
C016 TCJ2VC1H101J CAP,C 100PF-J-50V
C017 TCJ2VB1C104K CAP,C .1UF-K-16V
C018 TCJ2VC1H151J CAP,C 150PF-J-50V
C020 TCJ2VB1C104K CAP,C .1UF-K-16V
C022 TCJ2VC1H101J CAP,C 100PF-J-50V
C023 TCJ2VC1H151J CAP,C 150PF-J-50V
C024 ECA1AM470B CAP,E 47UF-10V
C025 TCJ2VB1C104K CAP,C .1UF-K-16V
C026 TCJ2VB1C104K CAP,C .1UF-K-16V
C027 TCJ2VC1H391J CAP,C 390PF-J-50V
C028 TCJ2VB1C104K CAP,C .1UF-K-16V
C029 ECQB1H333JF3 CAP,P .033UF-J-50V
C031 ECA1HMR22B CAP,E .22UF-50V
C032 ECA1AM470B CAP,E 47UF-10V
C033 TCJ2VC1H390J CAP,C 39PF-J-50V
C034 TCJ2VB1H103K CAP,C .01UF-K-50V
C035 ECA1HM010B CAP,E 1UF-50V
C036 TCJ2VB1H103K CAP,C .01UF-K-50V
C037 ECA1HM0R1B CAP,E 0.1UF/50V
C038 ECA1AM470B CAP,E 47UF-10V
C040 ECA1AM470B CAP,E 47UF-10V
C041 ECA1HM2R2B CAP,E 2.2UF-50V
C042 TCJ2VF1H104Z CAP,C .1UF-Z-50V
C043 ECA1AM470B CAP,E 47UF-10V
C044 TCJ2VC1H471J CAP,C 470PF-J-50V
C045 ECA1HM0R1B CAP,E 0.1UF/50V
C046 TCJ2VB1C104K CAP,C .1UF-K-16V
C047 TCJ2VC1H220J CAP,C 22PF-J-50V
C048 TCJ2VC1H220J CAP,C 22PF-J-50V
C050 ECA1AM101B CAP,E 100UF-10V
C051 TCJ2VF1H104Z CAP,C .1UF-Z-50V
C054 TCJ2VB1H103K CAP,C .01UF-K-50V
CT-20D12DF-1
C055 TCJ2VC1H560J CAP,C 56PF-J-50V
C057 TCJ2VC1H471J CAP,C 470PF-J-50V
CT-20D12DF-1
C103 ECA0JM331B CAP,E 330UF-6.3V
C104 TCJ2VB1H103K CAP,C .01UF-K-50V
C105 ECA0JM101B CAP,E 100UF-6.3V
C350 ECA1CM101B CAP,E 100UF/16V
C351 TCJ2VB1H391K CAP,C 390PF-K-50V
C352 TCJ2VB1H391K CAP,C 390PF-K-50V
C353 TCJ2VB1H471K CAP,C 470PF-K-50V
C354 ECKW3D102KBN CAP,C .001UF-K-2KVDC
C357 EEANA1E1R0B CAP,E 1.0UF-25V
C361 TCJ2VC1H151J CAP,C 150PF-J-50V
C362 TCJ2VC1H151J CAP,C 150PF-J-50V
C363 TCJ2VC1H151J CAP,C 150PF-J-50V
C451 ECA1CHG470B CAP,E 47UF-16V
C452 ECSF1EE105VB CAP,E 1.0UF-25V
C453 ECEA1HFS2R2B CAP,E 2.2UF-50V
C454 ECA1EM102E CAP,E 1000UF-25V
C455 ECA1EHG101B CAP,E 100UF-25V
C456 ECQB1H103JF3 CAP,P .01UF-J-50V
C459 ECA1VHG471B CAP,E 470UF-35V
C462 ECA1HM4R7B CAP,E 4.7UF-50V
C502 TCJ2VC1H471J CAP,C 470PF-J-50V
C503 TCJ2VB1C104K CAP,C .1UF-K-16V
C504 TCJ2VB1C104K CAP,C .1UF-K-16V
C510 ECCR2H100D5 CAP,C 10PF-D-500V
C511 ECKR2H821KB5 CAP,C 820PF-K-500V
C512 ECKR2H101KB5 CAP,C 100UF-K-500V
C530 TCJ2VF1H473Z CAP,C .047UF-Z-50V
C531 ECA1EM220B CAP,E 22UF-25V
C551 ECA1VM331B CAP,E 330UF-35V
C554 ECKR2H561KB5 CAP,C 560PF-K-500V
C555 ECA2EM220E CAP,E 22UF-250V
C556 ECA1CM471B CAP,E 470UF-16V
C557 ECKR2H222KB5 CAP,C 2200PF-K-500V
C558 ECA1HM4R7B CAP,E 4.7UF-50V
C560 EEANA1E2R2B CAP,E 2.2UF-25V
C561 ECKR2H561KB5 CAP,C 560PF-K-500V
C562 ECA1EM220B CAP,E 22UF-25V
C563 ECWH12H362JS CAP,P 3600PF-J-1250VDC
C564 ECWH12H562JS CAP,P .0056UF-J-1.2KV
C565 ECKW3D331JBR CAP,C 330PF-J-2KV
C566 ECKW3D181JBP CAP,C 180PF-J-2KV
C568 ECQM4473JZW CAP,P .047UF-J-400V
C569 ECWF2394JBB CAP,P .39UF-J-200V
C570 ECA1CM222E CAP,E 2200UF-16V
C571 ECA1EM220B CAP,E 22UF-25V
C572 ECA1CM100B CAP,E 10UF-16V
C573 ECA1CM101B CAP,E 100UF/16V
C575 ECA0JM222B CAP,E 2200UF-6.3V
C577 ECA1CM101B CAP,E 100UF/16V
C578 ECA0JM332B CAP,E 3300PF-6.3V
C579 TCJ2VC1H100D CAP,C 10PF-J-50V
C580 TCJ2VB1H152K CAP,C 1500PF-K-50V
C605 TCJ2VB1H103K CAP,C .01UF-K-50V
C606 ECA0JM221B CAP,E 220UF-6.3V
REF
NO. PART NO. DESCRIPTION

REPLACEMENT PARTS LIST
Models: CT-20G7DF-1, CT-20D12DF-1, CT-2017F-1
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important for safety. When replacing
any of these components use only manufacturer’s specified parts.
-9-
302-02
PARTS LIST
Parts List
C800 ECKR3A391KBP CAP,C 390PF-K-1KVDC
C801 ECKWAE472ZED CAP,C 4700PF-Z-500V
C802 ECKWAE472ZED CAP,C 4700PF-Z-500V
C803 ECKWAE472ZED CAP,C 4700PF-Z-500V
C805 EC0S2DA221BB CAP,E 220UF/200V
C806 ECQM4103KZW CAP,P .01UF-K-400V
C807 ECKR3A821KBP CAP,C 820PF-K-1KV
C808 ECA1VM101B CAP,E 100UF-35V
C809 ECKR1H101KB5 CAP,C 100PF-K-50V
C810 ECKR1H471KB5 CAP,C 470PF-K-50V
C812 ECQU2A224MVA CAP,P .22UF-M-250VAC
C813 ECQU2A153MVA CAP,P .015UF-M-250VAC
C814 ECQU2A153MVA CAP,P .015UF-M-250VAC
C820 ECA1CM101B CAP,E 100UF/16V
C821 TCJ2VB1H103K CAP,C .01UF-K-50V
C822 ECKR3A221KBP CAP,C 220PF-K-1KV
C823 ECA1VM471E CAP,E 470UF-35V
C824 ECKR3A102KBP CAP,C 1000PF-K-1KV
C825 EEUMG2C221S CAP,E 220UF-160V
C826 ECKR3A471KBP CAP,C 470PF-K-1KV
C827 ECA1CM471B CAP,E 470UF-16V
C828 ECA160V33UE CAP,E 33UF/160V
C840 ECQB1H224JF3 CAP,P .22UF-J-50V
C2201 ECA1HM4R7B CAP,E 4.7UF-50V
C2202 ECA1HM2R2B CAP,E 2.2UF-50V
C2203 ECA1HM4R7B CAP,E 4.7UF-50V
C2204 AP106K016CAE CAP,T 10UF/16V
C2205 ECA1HMR33B CAP,E .33UF-50V
C2206 ECQB1H223JF3 CAP,P .022UF-J-50V
C2207 AP335K016CAE CAP,T 3.3UF/16V
C2208 TCJ2VB1C104K CAP,C .1UF-K-16V
C2209 TCJ2VB1C104K CAP,C .1UF-K-16V
C2210 TCJ2VB1C104K CAP,C .1UF-K-16V
C2212 ECQB1H473JF3 CAP,P .047UF-J-50V
C2213 ECA1HMR47B CAP,E .47UF-50V
C2214 ECA1AM101B CAP,E 100UF-10V
C2215 EEANA1E100B CAP,E 10UF-25V
C2216 TCJ2VC1H100D CAP,C 10PF-J-50V
C2301 ECA1EM102E CAP,E 1000UF-25V
C2302 ECEA1HN010UB CAP,E 1UF/50V
C2303 ECA1EM101B CAP,E 100UF-25V
C2304 ECA1CM100B CAP,E 10UF-16V
C2307 ECA1CM102B CAP,E 1000UF/16V
C2309 ECA1HM010B CAP,E 1UF-50V CT-20D12DF-1
C2311 ECA1EM102E CAP,E 1000UF-25V
C2312 ECEA1HN010UB CAP,E 1UF/50V
C2313 ECA1EM101B CAP,E 100UF-25V
C2314 ECA1CM100B CAP,E 10UF-16V
C2317 ECA1CM102B CAP,E 1000UF/16V
C2319 ECA1HM010B CAP,E 1UF-50V CT-20D12DF-1
REF
NO. PART NO. DESCRIPTION
C2320 ECA1CM100B CAP,E 10UF-16V
C2330 ECA1CM100B CAP,E 10UF-16V
C2350 ECA1HM100B CAP,E 10UF/50V
C3001 ECA1HM0R1B CAP,E 0.1UF/50V
C3012 ECA1HM010B CAP,E 1UF-50V
C3018 ECA1HM010B CAP,E 1UF-50V
C3050 TCJ2VB1H103K CAP,C .01UF-K-50V
CT-20D12DF-1
C3051 TCJ2VB1H103K CAP,C .01UF-K-50V
CT-20D12DF-1
DIODES
D002 MA2C165001VT DIODE
D006 MAZ43300HF DIODE, ZENER
D052 MAZ40680MF DIODE, ZENER
D053 MAZ40560MF DIODE, ZENER
D055 MAZ40560MF DIODE, ZENER
D451 B0EAKL000008 DIODE, RECTIFIER
D452 MAZ40470MF DIODE, ZENER
D453 MA2C165001VT DIODE
D454 MA2C165001VT DIODE
D456 MAZ40470MF DIODE, ZENER
D502 MAZ40470MF DIODE, ZENER
D531 B0HAHP000008 DIODE
D551 B0HAMM000072 DIODE, FAST RECOVERY
D554 AU02V0 DIODE
D556 MA2C165001VT DIODE
D558 B0HANV000008 DIODE
D559 BYD33G-113 DIODE
D561 AU02V0 DIODE
D606 MA2C165001VT DIODE
D607 MA3X152K0L DIODE
D608 MA3X152K0L DIODE
D609 MA3X152K0L DIODE
D801 D3SBA60-4103 DIODE
D806 TAP2AA0001 PTC 5-OHM
D808 SARS01V1 DIODE
D809 B0HAJP000015 DIODE
D810 B0HAJP000015 DIODE
D811 B0HAJP000015 DIODE
D812 MAZ40680MF DIODE, ZENER
D820 MA2C165001VT DIODE
D821 MAZ40470HF DIODE, ZENER
D822 B0HAMM000103 DIODE
D823 S3L60P154004 DIODE
D824 B0HAMM000072 DIODE, FAST RECOVERY
D2305 MAZ31100ML DIODE, ZENER CT-20D12DF-1
D2306 MAZ31100ML DIODE, ZENER CT-20D12DF-1
D2307 MAZ31100ML DIODE, ZENER CT-20D12DF-1
D2308 MAZ31100ML DIODE, ZENER CT-20D12DF-1
D2350 MAZ40680MF DIODE, ZENER
D2351 MA2C165001VT DIODE
REF
NO. PART NO. DESCRIPTION

-10-
Parts List
REPLACEMENT PARTS LIST
Models: CT-20G7DF-1, CT-20D12DF-1, CT-2017F-1
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important for safety. When replacing
any of these components use only manufacturer’s specified parts.
302-02
PARTS LIST
D2352 MA2C165001VT DIODE
D2353 MA2C165001VT DIODE
D2354 MAZ40910MF DIODE, ZENER
D3001 MAZ31100ML DIODE, ZENER
D3003 MAZ31100ML DIODE, ZENER
D3004 MAZ31100ML DIODE, ZENER
D3005 MAZ31100ML DIODE, ZENER
D3006 MAZ31100ML DIODE, ZENER
D3017 MAZ31100ML DIODE, ZENER
D3018 MAZ31100ML DIODE, ZENER
D3019 MAZ31100ML DIODE, ZENER
D3020 MAZ31100ML DIODE, ZENER
D3021 MAZ31100ML DIODE, ZENER
D3022 MAZ31100ML DIODE, ZENER
FUSES
F801 XBA2A00101 FUSE 6.3A 125V
INTEGRATED CIRCUITS
IC001 M65584MA-104 MPU/VCJ
IC002 TVR2AJ149S EEPROM
IC003 PIC-37042SR IR RECEIVER
IC005 PQ1X331M2ZP VOLTAGE REGULATOR, 3.3V
IC006 MN1280R RESET
IC451 LA7837-TV VOUT
IC551 AN78L09 VOLTAGE REGULATOR 9V
CT-20D12DF-1
IC551 AN78M09LB VOLTAGE REGULATOR 9V
CT-20G7DF-1 , CT-2017F-1
IC552 AN78M05LB VOLTAGE REGULATOR PLUS
5V AVR
IC553 AN78M05LB VOLTAGE REGULATOR PLUS
5V AVR
IC801 STRG5623A POWER SUPPLY, 360V
IC2201 AN5829S-E1V MTS, S-AGC
IC2301 AN17800A AUDIO AMP
CT-2017F-,1,
CT-20G7DF-1
IC2301 AN17801A AUDIO AMP CT-20D12DF-1
IC2302 AN17800A AUDIO AMP
CT-2017F-,1,
CT-20G7DF-1
IC2302 AN17801A AUDIO AMP CT-20D12DF-1
COILS
L001 EXCELSA35T FERRITE BEAD
L003 TLUABTA6R8K COIL, 6.8UH
L004 TLUABTA6R8K COIL, 6.8UH
L005 EXCELDR35V FERRITE BEAD
L006 EXCELSA24T FERRITE BEAD
L007 EXCELDR35V FERRITE BEAD
L008 G0C470KA0029 COIL, PEAKING 47UH
L009 EXCELSA35V FERRITE BEAD
L010 ELESN330JA COIL, PEAKING 33UH
L011 ELESN330JA COIL, PEAKING 33UH
L013 EXCELDR35V FERRITE BEAD
L014 ELESN180KA COIL, PEAKING 18UH
REF
NO. PART NO. DESCRIPTION
L015 EXCELSA35V FERRITE BEAD
L016 EXCELSA35V FERRITE BEAD
L017 G0C100KA0029 COIL, PEAKING 10UH
L019 EXCELDR35V FERRITE BEAD
L021 G0C470KA0029 COIL, PEAKING 47UH
L022 EXCELSA39V FERRITE BEAD
L090 EXCELSA24T FERRITE BEAD
L104 G0C2R2KA0029 COIL, PEAKING 2.2UH
L108 EXCELSA35V FERRITE BEAD
L245 EXCELSA35V FERRITE BEAD
L250 EXCELSA35V FERRITE BEAD
L306 G0C2R2KA0029 COIL, PEAKING 2.2UH
L325 EXCELSA35V FERRITE BEAD
L403 G0C2R2KA0029 COIL, PEAKING 2.2UH
L416 EXCELSA39V FERRITE BEAD
L551 ELH5L4101 COIL
L801 ELF15N011A LINE FILTER
L802 ELEKE680KA COL, PEAKING 68UH
L803 TALL08T680KA COIL
L807 EXCELSA35V FERRITE BEAD
L808 EXCELSA35V FERRITE BEAD
L2305 EXCELSA35V FERRITE BEAD
L2308 EXCELSA24V FERRITE BEAD
L2350 ELESN4R7JA COIL, PEAKING 4.7UH
TRANSISTORS
Q001 2SD601ARTX TRANSISTOR
Q006 2SB709ARTX TRANSISTOR
Q007 2SB709ARTX TRANSISTOR
Q008 2SB709ARTX TRANSISTOR
Q009 2SC1473A TRANSISTOR
Q090 2SB709ARTX TRANSISTOR
Q092 2SB709ARTX TRANSISTOR
Q351 2SC3063RL TRANSISTOR
Q352 2SC3063RL TRANSISTOR
Q353 2SC3063RL TRANSISTOR
Q354 2SD601ARTX TRANSISTOR
Q355 2SD601ARTX TRANSISTOR
Q356 2SD601ARTX TRANSISTOR
Q451 2SD601ARTX TRANSISTOR
Q452 2SD601ARTX TRANSISTOR
Q453 2SD601ARTX TRANSISTOR
Q501 2SC1573AH TRANSISTOR
Q505 2SD601ARTX TRANSISTOR
Q520 2SD601ARTX TRANSISTOR
Q551 2SC562200VLA TRANSISTOR
Q605 2SB709ARTX TRANSISTOR
Q606 2SD601ARTX TRANSISTOR
Q820 2SA1767QTA TRANSISTOR
Q830 2SB1011QRL TRANSISTOR
Q2350 2SB709ARTX TRANSISTOR
REF
NO. PART NO. DESCRIPTION

REPLACEMENT PARTS LIST
Models: CT-20G7DF-1, CT-20D12DF-1, CT-2017F-1
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important for safety. When replacing
any of these components use only manufacturer’s specified parts.
-11-
302-02
PARTS LIST
Parts List
RELAYS
RL801 K6B1AGA00042 RELAY
RESISTORS
R001 ERJ6GEYJ102V RES,M 1K-J-1/10W
R003 ERJ6GEYJ105V RES,M 1M-J-1/10W
R004 ERJ6GEYJ562V RES,M 5.6K-J-1/10W
R006 ERDS2TJ101T RES,C 100-J-1/4W
R007 ERJ6GEYJ471V RES,M 470-J-1/10W
R008 ERJ6GEYJ471V RES,M 470-J-1/10W
R009 ERJ6GEYJ472V RES,M 4.7K-J-1/10W
R010 ERJ6GEYJ682V RES,M 6.8K-J-1/10W
R011 ERJ6GEYJ682V RES,M 6.8K-J-1/10W
R012 ERJ6GEYJ473V RES,M 47K-J-1/10W
R013 ERJ6GEYJ202V RES,M 2K-J-1/10W
R014 ERJ6GEYJ221V RES,M 220-J-1/10W
R015 ERJ6GEYJ221V RES,M 220-J-1/10W
R016 ERJ6GEYJ221V RES,M 220-J-1/10W
R017 ERJ6GEYJ681V RES,M 680-J-1/10W
R018 ERJ6GEYJ681V RES,M 680-J-1/10W
R019 ERJ6GEYJ681V RES,M 680-J-1/10W
R021 ERJ6GEYJ101V RES,M 100-J-1/10W
R022 ERJ6GEYJ101V RES,M 100-J-1/10W
R023 ERJ6GEYJ102V RES,M 1K-J-1/10W
R024 ERJ6GEYJ153V RES,M 15K-J-1/10W
R028 ERJ6GEYJ472V RES,M 4.7K-J-1/10W
R029 ERJ6GEYJ472V RES,M 4.7K-J-1/10W
R032 ERJ6ENF1002V RES,M 10K-F-1/10W
R033 ERJ6GEYJ222V RES,M 2.2K-J-1/10W
R034 ERJ6GEYJ222V RES,M 2.2K-J-1/10W
R035 ERJ6GEYJ332V RES,M 3.3K-J-1/10W
R036 ERJ6GEYJ562V RES,M 5.6K-J-1/10W
R037 ERJ6GEYJ103V RES,M 10K-J-1/10W
R038 ERJ6GEYJ223V RES,M 22K-J-1/10W
R039 ERJ6GEYJ102V RES,M 1K-J-1/10W
R040 ERJ6GEYJ223V RES,M 22K-J-1/10W
R041 ERJ6GEYJ153V RES,M 15K-J-1/10W
R042 ERJ6GEYJ392V RES,M 3.9K-J-1/10W
R043 ERJ6GEYJ103V RES,M 10K-J-1/10W
CT-20D12DF-1
R044 ERJ6GEYJ103V RES,M 10K-J-1/10W
CT-20G7DF-1 , CT-2017F-1
R044 ERJ6GEYJ332V RES,M 3.3K-J-1/10W
CT-20D12DF-1
R045 ERJ6GEYJ101V RES,M 100-J-1/10W
R046 ERJ6GEYJ102V RES,M 1K-J-1/10W
R077 ERJ6GEYJ103V RES,M 10K-J-1/10W
CT-20D12DF-1
R078 ERJ6GEYJ103V RES,M 10K-J-1/10W
R081 ERJ6GEYJ103V RES,M 10K-J-1/10W
R090 ERJ6GEYJ471V RES,M 470-J-1/10W
R091 ERJ6GEYJ185V RES,M 1.8MEG-J-1/10W
REF
NO. PART NO. DESCRIPTION
R092 ERJ6GEYJ473V RES,M 47K-J-1/10W
R093 ERJ6GEYJ331V RES,M 330-J-1/10W
R201 ERJ6GEYJ182V RES,M 1.8K-J-1/10W
CT-20D12DF-1
R202 ERJ6GEYJ102V RES,M 1K-J-1/10W
CT-20D12DF-1
R202 ERJ6GEYJ751V RES,M 750-J-1/10W
CT-20G7DF-1 , CT-2017F-1
R351 ERG2FJ123H RES,M 12K-J-2W
R352 ERG2FJ123H RES,M 12K-J-2W
R353 ERG2FJ123H RES,M 12K-J-2W
R354 ERDS1TJ272T RES,C 2.7K-J-1/2W
R355 ERDS1TJ272T RES,C 2.7K-J-1/2W
R356 ERDS1TJ272T RES,C 2.7K-J-1/2W
R357 ERJ6ENF4300V RES,M 430-F-1/10W
R358 ERJ6ENF4300V RES,M 430-F-1/10W
R359 ERJ6ENF4300V RES,M 430-F-1/10W
R360 ERJ6ENF7500V RES,M 750-F-1/10W
R361 ERJ6ENF7500V RES,M 750-F-1/10W
R362 ERJ6ENF7500V RES,M 750-F-1/10W
R363 ERJ6GEYJ101V RES,M 100-J-1/10W
R364 ERJ6GEYJ101V RES,M 100-J-1/10W
R365 ERJ6GEYJ101V RES,M 100-J-1/10W
R370 ERDS2TJ224T RES,C 220K-J-1/4W
R381 ERJ6GEYJ101V RES,M 100-J-1/10W
R382 ERJ6GEYJ101V RES,M 100-J-1/10W
R383 ERJ6GEYJ101V RES,M 100-J-1/10W
R384 ERJ6ENF2701V RES,M 2.7K-F-1/10W
R385 ERJ6ENF7501V RES,M 7.5K-F-1/10W
R386 ERJ6ENF1201V RES,M 1.2K-F-1/10W
R387 ERJ6ENF2701V RES,M 2.7K-F-1/10W
R388 ERJ6ENF7501V RES,M 7.5K-F-1/10W
R389 ERJ6ENF1201V RES,M 1.2K-F-1/10W
R390 ERJ6ENF2701V RES,M 2.7K-F-1/10W
R391 ERJ6ENF7501V RES,M 7.5K-F-1/10W
R392 ERJ6ENF1201V RES,M 1.2K-F-1/10W
R450 ERJ6GEYJ563V RES,M 56K-J-1/10W
R451 ERDS1FJ1R2P RES,C 1.2-J-1/2W
R454 ERJ6GEYJ473V RES,M 47K-J-1/10W
R455 ERJ6GEYJ153V RES,M 15K-J-1/10W
R456 ERJ6GEYJ472V RES,M 4.7K-J-1/10W
R457 ERJ6GEYJ152V RES,M 1.5K-J-1/10W
R458 ERJ6GEYJ333V RES,M 33K-J-1/10W
R459 ERJ6GEYJ683V RES,M 68K-J-1/10W
R460 ERDS2TJ102T RES,C 1K-J-1/4W
R462 ERJ6GEYJ473V RES,M 47K-J-1/10W
R463 ERJ6GEYJ473V RES,M 47K-J-1/10W
R465 ERJ6GEYJ303V RES,M 30K-J-1/10W
R467 ERJ6GEYJ183V RES,M 18K-J-1/10W
R468 ERJ6GEYJ103V RES,M 10K-J-1/10W
R469 ERJ6GEYJ220V RES,M 22-J-1/10W
REF
NO. PART NO. DESCRIPTION

-12-
Parts List
REPLACEMENT PARTS LIST
Models: CT-20G7DF-1, CT-20D12DF-1, CT-2017F-1
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important for safety. When replacing
any of these components use only manufacturer’s specified parts.
302-02
PARTS LIST
R470 ERDS2TJ152T RES,C 1.5K-J-1/4W
R471 ERJ6GEYJ223V RES,M 22K-J-1/10W
R472 ERJ6GEYJ473V RES,M 47K-J-1/10W
R475 ERJ6GEYJ471V RES,M 470-J-1/10W
R502 ERJ6GEYJ562V RES,M 5.6K-J-1/10W
R504 ERDS2TJ272T RES,C 2.7K-J-1/4W
R505 ERJ6GEYJ222V RES,M 2.2K-J-1/10W
R506 ERJ6GEYJ333V RES,M 33K-J-1/10W
R507 ERJ6GEYJ103V RES,M 10K-J-1/10W
R508 ERJ6GEYJ103V RES,M 10K-J-1/10W
R510 ERG3FJ272 RES,M 2.7K-J-3W
R512 ERG2FJ562H RES,M 5.6K-J-2W
R520 ERJ6GEYJ471V RES,M 470-J-1/10W
R521 ERJ6GEYJ272V RES,M 2.7K-J-1/10W
R531 ERD25FJ470P RES,C 47-J-1/4W
R532 ERJ6ENF8871V RES,M 8.87K-F-1/10W
R533 ERJ6ENF1301V RES,M 1.3K-F-1/10W
R551 ERDS1FJ1R0T RES,C 1.0-J-1/2W
R552 ERDS1FJ1R0T RES,C 1.0-J-1/2W
R555 ERDS1FJ101T RES,C 100-J-1/2W
R556 ERG1SJ221P RES,M 220-J-1W
R557 ERJ6GEYJ103V RES,M 10K-J-1/10W
R558 ERQ2CJP2R2S RES,F 2.2-J-2W
R559 ERG2FJ683H RES,M 12K-J-2W
R562 ERG3FJ680H RES,M 68-J-3W
R563 ERG1SJ150P RES,M 15-J-1W
R564 ERDS2TJ104T RES,C 100K-J-1/4W
R565 ERDS2TJ124T RES,C 120K-J-1/4W
R566 ERJ6GEYJ103V RES,M 10K-J-1/10W
R567 ERG2FJ122H RES,M 12K-J-2W
R568 ERJ6GEYJ332V RES,M 3.3K-J-1/10W
R571 ERJ6GEYJ102V RES,M 1K-J-1/10W
R605 ERDS2TJ103T RES,C 10K-J-1/4W
R606 ERJ6GEYJ562V RES,M 5.6K-J-1/10W
R607 ERJ6GEYJ102V RES,M 1K-J-1/10W
R608 ERJ6GEYJ104V RES,M 100K-J-1/10W
R801 ERF7ZK1R5 RES,W 1.5-K-7W
R802 ERDS2TJ684T RES,C 680K-J-1/4W
R803 ERG2FJ100H RES,M 10K-J-1/2W
R804 ERG2FJ104H RES,M 100K-J-2W
R805 ERX2FZJR18H RES,M .18-J-2W
R806 ERX2FJR56H RES,M .56-J-2W
R807 ERDS2TJ681T RES,C 680-J-1/4W
R808 ERDS2TJ4R7T RES,C 4.7-J-1/4W
R809 ERDS2TJ472T RES,C 4.7K-J-1/4
R815 ERC12ZGM825D RES,S 8.2MEG-M-1/2
R817 ERX3FJ6R8 RES,F 6.8-J-3W
R821 ERDS1FJ1R5T RES,C 1.5-J-1/2W
R822 ERDS1FJ1R5T RES,C 1.5-J-1/2W
R823 ERDS1FJ272T RES,C 2.7K-J-1/2W
REF
NO. PART NO. DESCRIPTION
R824 ERDS2TJ223T RES,C 22K-J-1/4W
R825 ERDS2TJ272T RES,C 2.7K-J-1/4W
R828 ERJ6GEYJ104V RES,M 100K-J-1/10W
R830 ERDS2TJ104T RES,C 100K-J-1/4W
R831 ERDS2TJ682T RES,C 6.8K-J-1/4W
R850 ERQ12HJR56P RES,F .56-J-1/2W
R2201 ERJ6GEYJ224V RES,M 220K-J-1/10W
R2203 ERJ6GEYJ102V RES,M 1K-J-1/10W
R2204 ERJ6GEYJ102V RES,M 1K-J-1/10W
R2205 ERJ6GEYJ101V RES,M 100-J-1/10W
R2206 ERJ6GEYJ273V RES,M 27K-J-1/10W
R2301 ERQ2CJP3R9S RES,F 3.9-J-2W
R2307 ERJ6GEYJ103V RES,M 10K-J-1/10W
R2320 ERJ6GEYJ104V RES,M 100K-J-1/10W
CT-20D12DF-1
R2350 ERDS2TJ391T RES,C 390-J-1/4W
R2351 ERJ6GEYJ562V RES,M 5.6K-J-1/10W
R2352 ERJ6GEYJ683V RES,M 68K-J-1/10W
R2353 ERJ6GEYJ124V RES,M 120K-J-1/10W
R2354 ERJ6GEYJ123V RES,M 12K-J-1/10W
R2355 ERJ6GEYJ222V RES,M 2.2K-J-1/10W
R2356 ERJ6GEYJ101V RES,M 100-J-1/10W
R2357 ERJ6GEYJ472V RES,M 4.7K-J-1/10W
R2365 ERDS2TJ102T RES,C 1K-J-1/4W
R2370 ERJ6GEYJ103V RES,M 10K-J-1/10W
R2417 ERJ6GEYJ104V RES,M 100K-J-1/10W
CT-20D12DF-1
R3001 ERDS2TJ101T RES,C 100-J-1/4W
R3005 ERJ6GEYJ334V RES,M 330K-J-1/10W
R3007 ERJ6GEYJ151V RES,M 150-J-1/10W
R3008 ERJ6GEYJ151V RES,M 150-J-1/10W
R3009 ERJ6GEYJ682V RES,M 6.8K-J-1/10W
R3010 ERJ6GEYJ334V RES,M 330K-J-1/10W
R3011 ERJ6GEYJ682V RES,M 6.8K-J-1/10W
R3013 ERJ6ENF75R0V RES,M 75.0-F-1/10W
CT-20D12DF-1
R3014 ERJ6ENF75R0V RES,M 75.0-F-1/10W
CT-20D12DF-1
R3016 ERDS2TJ181T RES,C 180-J-1/4W
R3017 ERDS2TJ181T RES,C 180-J-1/4W
R3018 ERJ6GEYJ682V RES,M 6.8K-J-1/10W
R3019 ERJ6GEYJ682V RES,M 6.8K-J-1/10W
R3050 ERJ6GEYJ101V RES,M 100-J-1/10W
CT-20D12DF-1
R3051 ERJ6GEYJ101V RES,M 100-J-1/10W
CT-20D12DF-1
SWITCHES
S001 EVQPF106K SWITCH
S002 EVQPF106K SWITCH
S003 EVQPF106K SWITCH
S004 EVQPF106K SWITCH
S005 EVQPF106K SWITCH
REF
NO. PART NO. DESCRIPTION

REPLACEMENT PARTS LIST
Models: CT-20G7DF-1, CT-20D12DF-1, CT-2017F-1
Important Safety Notice: Components printed in BOLD TYPE have special characteristics important for safety. When replacing
any of these components use only manufacturer’s specified parts.
-13-
302-02
PARTS LIST
Parts List
S008 EVQPF106K SWITCH
S009 EVQPF106K SWITCH
TRANSFORMERS
T501 ETH19Y211AZ TRANSFORMER
T551 KFT3AA341F TRANSFORMER, FLYBACK
T801 ETS29AS183NC TRANSFORMER
CRYSTALS/FILTERS
X001 TSSA092 CRYSTAL OSCILLATOR
X002 AF080005BE CRYSTAL
OTHERS
TNR001 ENG36604GR TUNER
CT-2017F-,1,
CT-20G7DF-1
TNR001 ENG36610G TUNER CT-20D12DF-1
M001 TSX2AA0111-1 LINE CORD (SPT2)
M002 A51KRE89XDT CRT 20”
M003 TJSC00300 CRT SOCKET
M004 0FMK014ZZ CONVERGENCE
CORRECTOR STRIP
M005 JH291U-009 YOKE, CONVERGENCE
DY TLY2AA001 DEFLECTION YOKE
M006 TMM2A30702 WEDGE, YOKE
M007 TXF3A011DB2 ASSY. DAG GROUND
DEG TSP2AA008 COIL, DEGAUSSING 20 INCH
M008 TSN63115-4 MAGNET, PURITY
M009 TAS2AA0012 SPEAKER 16-OHM 1.5W
M010 TXFKU05ESER ASSY, CABINET BACK
CT-20G7DF-1
M011 TXFKU06BSER ASSY, CABINET BACK
CT-2017F-1
M012 TXFKU06ESER ASSY, CABINET BACK
CT-20D12DF-1
REF
NO. PART NO. DESCRIPTION
M013 TBM2A10141 BADGE, PANASONIC
M014 TBX2AA0121 BUTTON, 7-KEY
CT-20G7DF-1
CT-20D12DF-1
M015 TBX2AA1701GS BUTTOM, 7-KEY CT-2017F-1
M016 TKX2AA00401 IR GUIDE CT-2017F-1
M017 TKX2AA00404 IR GUIDE
CT-20G7DF-1
CT-20D12DF-1
M018 TXFKY06ESER ASSY, CABINET FRONT
CT-2017F-1
M019 TXFKY09FSER ASSY, CABINET FORNT
CT-20G7DF-1 , CT-20D12DF-1
JK3001 TJB2A9063B ASSY. JACK 1A/V
CT-20D12DF-1
JK3001 TJB2A9064B ASSY. JACK A/V
CT-2017F-,1,
CT-20G7DF-1
JK3002 TJB2AA0046 TERMINAL, FRONT A/V
JK3003 TJB2AA0171 TERMINAL, S-VHS
CT-20D12DF-1
ACCESORIES
M020 EUR501450 REMOTE CONTROL
CT-20G7DF-1, CT-2017F-1
M021 EUR511502 REMOTE CONTROL
CT-20D12DF-1
M022 UR50EC1190A BATTERY COVER, REMOTE CONTROL CT-2017F-,1,
CT-20G7DF-1
M023 UR51EC975A BATTERY COVER, REMOTE
CONTROL
CT-20D12DF-1
M024 TQB2AA0370-2 OWNERS MANUAL
CT-2017F-1
M025 TQB2AA0431-2 OWNERS MANUAL
CT-20G7DF-1 , CT-20D12DF-1
REF
NO. PART NO. DESCRIPTION
DESCRIPTION OF ABBREVIATIONS GUIDE
RES, C 270-J-1/4
CAP, P .068UF-K-50V
RESISTOR
TYPE TOLERANCE
C Carbon F±1%
FFuseJ±5%
M Metal Oxide K ± 10%
S Solid M ± 20%
W Wire Wound G±2%
CAPACITOR
TYPE TOLERANCE
C Ceramic C ± 0.25pF
E Electrolytic D ± 0.5pF
P Polyester F ± 1pF
SStyrolJ±5%
T Tantalum K ± 10%
L ± 15%
M ± 20%
P +10% -0%
Z +80% -20%

-14-
Notes
SCHEMATIC NOTES
1. Resistors are carbon 1/4W unless noted
otherwise.
2. Capacitors are ceramic 50V unless noted
otherwise.
3. Coil value notes is inductance in µH.
4. Test point indicated by ; Test point but no
pin .
5. Components indicated with are critical
parts and replacement should be made
with manufacture specified replacement
parts only.
6. (BOLD LINE) indicates the route
of B+ supply.
7. The schematic diagrams are current at
the time of printing and are subject to
change without notice.
8. Ground symbol indicates HOT
GROUND CONNECTION;
indicates COLD GROUND.
NOTE: All other component symbols are
used for engineering design
purposes.
WAVEFORM MEASUREMENTS
1. indicates waveform measurement.
(Measurement can be taken at the best
accessible location in common to the
indicated point.)
2. Taken with an NTSC signal generator
connected to the antenna terminal.
(NTSC color bar pattern of 8 bars of EIA
colors, 100 IRE white and 7.5 IRE black.)
3. Customer Controls (Picture/Audio Menu) are
set to Normalize. Volume is set to “MIN”.
4. All video and color waveforms are taken
with a wideband scope and a probe
with low capacitance (10 to 1). Shape
and peak altitudes may vary
depending on the type of Oscilloscope
used and its settings.
5. Ground symbol shown on waveform
number indicates (Hot) ground lead
connection of the Oscilloscope.
CAUTION: Incorrect ground connection of
the test equipment will result in erroneous
readings.
3
VOLTAGE MEASUREMENTS
1. Voltage measurement:
- AC input to the Receiver is 120V.
NTSC (HD, 1125i & 525P when
applicable) signal generator is
connected to the antenna of the
Receiver. (Color bar pattern of 100
IRE white and 7.5 IRE black.)
- All Picture and Audio adjustments are
set to Normalize.
TV ANT/CABLE - (Set-Up Menu) in
TV/ANT Mode
Volume - Min.
TV/Video SW - TV position
Audio Mode - Stereo
- Voltage readings are nominal and
may vary ±10% on active devices.
Some voltage reading will vary
with signal strength and picture
content.
- Supply voltages are nominal.
2. Ground symbol indicates ground lead
connection of meter.
Incorrect ground connection will result
in erroneous readings.
CAUTION: Incorrect ground connection
of the test equipment will result in
erroneous readings.
IMPORTANT SAFETY NOTICE
THIS SCHEMATIC DIAGRAM INCORPORATES SPECIAL
FEATURES THAT ARE IMPORTANT FOR PROTECTION FROM
X-RADIATION, FIRE AND ELECTRICAL SHOCK HAZARDS.
WHEN SERVICING IT IS ESSENTIAL THAT ONLY
MANUFACTURERS SPECIFIED PARTS BE USED FOR THE
CRITICAL COMPONENTS DESIGNATED WITH A IN THE
SCHEMATIC.
B
EC
CHIP TRANSISTOR
LEAD DESIGNATION

Notas:
-15-
PARTS LIST
NOTAS DE LOS DIAGRAMAS
1. Las Resistencias son de Carbón de 1/4W, a
menos que se indique otra característica.
2. Los Capacitores son de Cerámica para
50V, a menos que se indique otra
característica.
3. El valor indicado de las Bobinas es la
inductancia expresada en µH.
4. Los puntos de prueba en la terminal de
algún componente son indicados por Los
puntos de prueba fuera de los
componentes se indican con .
5. Los componentes señalados con el
símbolo son considerados
componentes críticos y deben ser
reemplazados sólo con las partes
especificadas por el fabricante.
6. (LINEA GRUESA) indica las
líneas de alimentación de los Voltajes
B+.
7. Los diagramas eléctricos están sujetos a
cambio sin previo aviso.
8. El símbolo indica que es una
conexión a Tierra Caliente y el símbolo
indica conexión a Tierra Fría.
NOTA: Los demas símbolos de
componentes incluidos son
usados con fines de diseño.
MEDICIÓN DE VOLTAJES
1. Medición de voltaje:
- El voltaje de entrada al Receptor es de
120V de Corriente Alterna. Un
generador de patrones con formato
NTSC se conecta a la entrada de la
antena. (Patrón de Barras de Colores
con 100 IREs para el Blanco y 7.5 IREs
para el Negro.)
- Los ajustes de los Menus Picture y
Audiosenormalizan.
EnelMenúSet-Up,enlaopción
ANTENA, se selecciona el modo de
CABLE.
El nivel de Volumen se minimiza.
De los modos TV y Video, seleccionar el
modo TV.
Seleccionar modo Estereo del Audio.
- Las mediciones de los voltajes son
nominales y pueden variar hasta
10% en componentes en
funcionamiento. Las lecturas de los
voltajes pueden variar por la
potencia de la señal y el contenido
de la imagen.
- Las fuentes de voltajes son
nominales.
2. El símbolo indica el tipo de tierra que
se utiliza en la conexión del medidor.
PRECAUCION: SI no se utiliza la
conexión a la tierra adecuada, se
obtendrán mediciones equivocadas y
podría dañar el equipo de medición.
MEDICIÓN DE FORMAS DE ONDA
1. Un símbolo como indica el punto para medir
una señal. (La medición puede hacerse en
el punto con mayor accesibilidad, siempre
que sea común al indicado.)
2. Se midieron utilizando un generador con
formato NTSC conectado a la terminal de la
antena. (Patrón de 8 Barras de Colores
EAI, formato NTSC de 100 IREs para el
Blanco y 7.5 IREs para el Negro.)
3. Los ajustes de usuario de los Menus
PICTURE y AUDIO se normalizaron.
Posteriormente el nivel de volumen se
ajusta al mínimo.
4. Las formas de onda de Video y Color
fueron tomadas con un osciloscopio de
banda alta y con un punta de prueba de
baja capacitancia (10 a 1). La forma y
amplitud de las ondas puede variar
según el tipo de osciloscopio que se
utilice y sus características.
5. El símbolo de tierra que aparece junto al
número de la forma de onda, indica que
se utiliza conexión a Tierra Caliente en
el extremo negativo de la punta de
prueba.
PRECAUCION: Si no se utiliza la conexión
a la tierra adecuada, se obtendrán
mediciones equivocadas y podría dañar el
equipo de medición.
3
NOTA DE SEGURIDAD
LOS DIAGRAMAS ELÉCTRICOS INCLUYEN
CARACTERÍSTICAS ESPECIALES MUY IMPORTANTES
PARA LA PROTECCIÓN CONTRA RAYOS-X,
QUEMADURAS Y DESCARGAS ELÉCTRICAS. CUANDO
SE DE SERVICIO ES IMPORTANTE USAR PARA
REEMPLAZO DE COMPONENTES CRITICOS, SOLO
PARTES ESPECIFICADAS POR EL FABRICANTES. LOS
COMPONENTES CRITICOS ESTAN SEÑALADOS EN LOS
DIAGRAMAS POR EL SIMBOLO .
B
EC
IDENTIFICACIÓN DE TERMINALES
PARA TRANSISTORES EN
CHIP

-16 -
TNP2AH048DR CT-2017F-1, CT-20G7DF-1

-17 -TNP2AH048DRCT-2017F-1, CT-20G7DF-1

-18 -
TNP2AH048DR CT-2017F-1, CT-20G7DF-1

-19 -TNP2AH048DRCT-2017F-1, CT-20G7DF-1

-20 -
TNP2AH048DR CT-2017F-1, CT-20G7DF-1
