Panasonic GPRV110 - ICD CAMERA User manual

Rearview TV System
GP-RV110
Panasonic.
Before attempting to connect or Operate Tis product, please reed (hee insiructions completly.

CONTENTS
PERE GG istics hs wed cuaty sd ta panne gcc nen Saal spoken sacra cctinn tebe teens ska uabada an ci ncwoah vad va aoe Rese aaneeeabeuane ea aus 1
sr =P 2 LL | 5 Shs pee ar re eA ee Ec Oar Pe Br are eC ee ee ee 1
PE GROIN Soi cca ts ecctaa eilectaa ca enceat senettag Sacro cea elated Ree tA sec cS Salsa akc ied Sac ste he ta etea eas dae sas ced tatahe 1
PRODUCT CUE OP 5x25 72524: pomccbosusn tte napaauccevetacenches sessucit cosieussy idun ncsesoe les decesusnaicact Lan esbis lacs edeancts fac eeu eauadi au ca 3
MAJOR OPERATING CONTROLS AND THEIR FUNCTIONS oui... cceccccccseecesersecrccerscesneerascccucesectesecenesseeueneas 3
TINS EAL ATION, scistec ca cis coca cats selena day's peeing ned haa igs be aa cataeen li ab sates oig sats atich sams wa ccnsaas ehetaatonads Seaeaa asa ps Gade ecu teceulee 5
PROIUISTAMIGINT. sasacisten cs duce ts ceveca tweeted esate dante trator tacos a nawnac, «pba tite sa leh Shi Saran Lies ae Se la acheke Niacta ast 7
OPERATING -PHOCE OUI Beye 225 cavcesacayencnasecidsnyoesceues ches pas lveteseencenccistee Seesecad-apcep cae voriea wee meee vaste hee aa natones menace 8
WAEWY FRAINGEE® cb cniesstciser un ghp doen isepid vay Sepseca us acess evenoun cs tosaadauva savanssuwicas oeeusnd eae eves ais g dae hadeceatse aha ated oan, 9
SYSTEM CONNECUIOIN spices fence echot esd caidas tree aksteivem cad aiteasetamedessints oud sul depnulenctaeub ence tagualiiee Sethe meeanavatoiec lated deisieatccdre 9
IME CHANTAL DATA sssscieed sctteceetcans Gros b vests caestedenvcceusendan ads ioetene cde bd sccceueastettienttcsica whChiestey au tks caundanaieueelar encenastyint hase GuOresn 10
SRE CUE TGA WONG: ciutsiectencdaaicsecesayeaateadys.pesheite sabe ?-cancasdan Calwasssauttvactiaea eaUeieieeta dia semtuaueleaem etauaneadl tinda nue dteantaen ee eine 11
SA
1965
enclosure
that
may
be
of
sufficient
|
bottom
of
the
unit.
magnitude
to
constitute
a
risk
Of
|
You
should
note
the
serial
number
of
this
unit
in
the
electric
shock
to
persons.
|space
provided
and
retain
this
instructions
as
a
perma-
The
exclamation
point
within
an
nent
record
of
your
purchase
to
aid
identification
in
equilateral
triangle
is
intended
to
|
the
event
of
theft.
alert
the
user
to
the
presence
of
important
operating
and
mainte
Mode!
No.
GP-RV110
nance
(servicing)
instructions
in
the
SA 1966 literature accompanying the appli- Serial No.
CAUTION
RISK OF ELECTAIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELEC-
TRIC SHOCK, DO NOT REMOVE
COVER
SERVICEABLE PARTS
REFER
(OR BACK). NO USER-
INSIDE.
SERVICING TO QUALI-
FIEO SERVICE PERSONNEL.
The lightning flash with arrowhead
symbol, within an equilateral! tri-
angle, is intended to alert the user to
ihe presence of uninsulated ‘‘dan-
gerous voltage” within the product's
ance,
- designed
Warning :
This equipment generates and uses radio fre-
quency energy and if not installed and used
properly, i.e., in strict accordance with the
instructions manual, may cause harmful inter-
ference to radio communications.
It has been tested and found to comply with the
limits for a Class A computing device pursuant
to Subpart J of Part 15 of FCC Rules, which are
to provide reasonable protection
against such interference when operated in a
commercial environment.
The serial number of this product may be found on the

PREFACE
The Panasonic rearview TV System GP-RV110 consist-
ing of rearview camera GP-RV111 and driver's monitor
GP-RV112 significantly reduces dangerous blind spots.
FEATURES
o Rearview Camera GP-RV111
1. 1/2” Interline Transfer CCD Image Sensor with
422(H) x 489(V) pixels.
. 300 lines of horizontal resolution.
. 0.5 footcandles (5 tux) of minimum illumination,
. 40 dB of signal to noise ratio.
. Wide rearview field of vision by newly developed
wide angle lens f= 3.0mm, F 1.4.
. High resistance to image burning.
. Long life
. High resistance to effects of shock and vibration
. Single coaxial cable connection enables easy instalta-
tion.
om BB WwW NY
Oo OO ~l Mm
PRECAUTIONS
1. Do not attempt to disassemble the camera and
monitor.
To prevent electric shock, do not remove screws or
cover. There are no user-serviceable parts inside.
Refer servicing to quatified service personnel.
2. Do not expose the monitor to rain or moisture, and
avoid operation in wet areas.
Take immediate action if the monitor should become
wet. Set the ignition to the LOCK position or pull
the ignition key out and request servicing from
qualified service personnel.
Moisture can damage the monitor and create the
danger of electric shock.
The rearview camera and driver’s monitor have been
developed exclusively for large trucks, buses and other
commercial vehictes.
o Driver’s Monitor GP-RV1412
1. Easy-to-see Screen :
7” flat, square and non-glare screen
2. Automatic Brightness Control (ABC) to compensate
for ambient light.
* 3. Remote STANDBY/ON control by reverse position
signal
4. Manual STANDBY/ON mode selection
5. Compact designed 7° B/W monitor enables to fit
almost anywhere.
3. Keep the face of the camera lens glass clean.
Whenever cleaning the car body, clean the lens glass
of the camera using a mild dry cloth. In case the dirt
is hard to remove, use mitd detergent and wipe
gently.
4. Use both the sidemirrors and driver’s monitor when
backing the car.
Avoid use only the driver’s monitor to confirm the
back of car since the view range of the driver's
monitor is limited.
Rearview ee Z-
‘ aT | hI
“FZ 9 oO
‘Sidemirrors y, HL eet
2X

5. Note that the left and right of image on the monitor
is reversed as well as that of the rearview mirror.
Rearview Monitor
Camera
7
|
}
|
i]
1
J
'
i
I
I
6. Pay attention to the obstacle located at the same
height of the rearview camera since it is out of the
view range of the rearview camera.
7. Do not block the ventilation slits on the monitor.
Install the monitor paying attention to the ventilation
space for the monitor.
. Do not use the camera and monitor beyond its
temperature, humidity or power source ratings.
The camera is designed for outdoor use and the
monitor is designed for indoor use.
(a) The ambient temperature must not range
beyond 14°F - 131°F (—10°C - +55°C) for
the camera and monitor.
camera and monitor.
(b) Avoid using the monitor when the humidity is
above 90%,
{c) The input power source for the monitor must
be.

PRODUCT LINE-UP
GP-RV110 ee Camera GP-RV1411
Driver’s Monitor GP-RV112
Camera Cable (Sold Separately) Remote Cable for Monitor
GP-CA40 (33 ft) (Standard Accessory of GP-RV112}
GP-CA41 (66 ft)
MAJOR OPERATING CONTROLS AND THEIR FUNCTIONS
® Rearview Camera
Camera Cable

Driver’s Monitor
Rearview Camera
1. Camera Unit
The 1/2’ B/W CCD camera is inside.
Caution : Even though the camera unit is installed in
the water-proof housing, do not spray the
water jet directly to the camera unit at
cleaning.
. Lens
This auto iris wide angle lens is inside.
The focal! length is 3.0 mm and Angular of view is
100° in horizontal and 83° in vertical.
Note : Keep the lens glass always clean.
. Sun Shield
. Camera Angle Adjusting Screws
These 4 screws are used to secure the camera unit.
By changing the fixing position of these screws, the
view angle of the camera can be changed approx. 45°.
Cc
. Camera Cable Connector.
This connector is a drip-proof type connector and is
used to connect the optional camera cable,
Caution : Whenever disconnecting this connector for
maintenance, turn the ignition to the
LOCK position to turn off the power.
. Screw Holes for Camera Fixing Plates
These threaded holes are used to fix the camera fixing
plate.
. Camera Fixing Plate
@ Driver’s Monitor
11. Monitor Hood
12. Mode Indicator (STANDBY)
This indicator shows the operation made as follows.
STANDBY : The indicator will be lit up to green.
ON: The indicator will be fit up to amber.
13. Mode Selection Switch
This switch is a push-push type and is used to select
the operation mode as follows,
STANDBY : The heater of CRT on the monitor is
preheated and all other circuits includ-
ing the rearview camera are shut off.
The rearview picture will be displayed
on the monitor.
ON :
14. Contrast Controi (CONTRAST)
This control is used to adjust the contrast of the
picture on the monitor,
15. Brightness Control (BRIGHT)
This control is used to adjust the brightness of the
picture on the monitor.
16, Auto Brightness Control Sensor (ABC)
This sensor detects the ambient
compensate the brightness as follows.
Ambient luminance Brightness compensation
luminance to
Less than 0.5 footcandles Reduce it approx. 20%

17.
18.
19.
20.
21.
22.
23.
24.
25.
Monitor Hood Fixing Screws
These 2 screws are used to secure the monitor hood.
Monitor Fixing Screws
These 4 screws are used to secure the monitor. The
tilt of the monitor can be changed approx. 30° by
loosing these screws.
Focus Control (FOCUS)
This control is used to adjust the focus of the
monitor.
Camera Cable Connector (CAMERA)
This connector. is used to connect the optional
Camera Cable GP-CA40 (33 ft) or GP-CA41 (66
ft).
REMOTE
(9) +12V, 1.5A Input
6,® Ground
Remote Input
(Reverse position —
+12V Input}
BOQ OOO
DOOOODOO®
Monitor side
Camera Cable (Sold Separately)
Power Source and Remote Connector (REMOTE)
This 14-pin connector is used to connect the sup-
plied power and Remote Cable.
Fuse Holder
Caution : When replacing the fuse, use only
specified one.
(3 Amp. Part No. YWTSC3A)
Monitor Fixing Plate
This is used to install the monitor to the car.
Fixing Holes
These 4 holes are used to fix the monitor fixing
plate to the car.
INSTALLATION
8 Mounting the Camera onto the Top of Rear-end Roof
1. Connect the camera cable to the camera cable con-
nector and secure the cable as shown below.
Secure the Cable
Connect Camera Cable
2. Secure the camera onto the rear-end of the roof using
4 bolts (prepared locally (6mm@ bolt)).
Rearview Camera
vehicle
Fix 4 Bolts
Note : Secure the camera so that the camera posi-
tions in parallel with the rear-end fine of
vehicle.
1
Lww—— Center of vehicles width
Parallet
aralle
Rear
of
Vehicle
(Top View)
Caution : In case the camera touches to the roof of
vehicle, slide the camera fixing plate as
shown below.
Approx, 18mm

® Mounting the Camera on the Top of Rear Panel
(Plate)
1. Connect the camera cable to the camera cable con-
nector and secure the cable as shown below.
Secure the cable key
as this direction ww
Connect Camera Cable
2. Change the direction of the camera fixing plate as
follows.
3. Secure the camera onto the rear panel of the vehicle.
Secure camera by
2 x 2 bolts
@ Driver’s Monitor Installation
1. Remove 4 monitor fixing screws which hold the
monitor fixing plate and remove the monitor fixing
plate.
2. Secure the monitor fixing Plate using 4 bolts {pre-
pared locally (6mm@ bolt}}.
3. Secure the monitor onto the monitor fixing plate
using supplied 4 monitor fixing screws and adjust the
tilt of the monitor.
‘Secure
screws
Adjust tilt
20° upper or
10° lower

4, Mount the monitor hood GP-Q48 (Sold separately)
using 2 monitor hood fixing screws.
Secure screws
5. Connect the optional camera cable GP-CA40 {33 ft}
or GP-CA41 (66 ft) the camera cable connector.
Connect
6. Connect the supplied remote cable for monitor to the
power and remote connector on the rear of the
monitor.
7. Connect the +12V wire (Red) to the +12V line which
is after ignition switch, the remote input wire (Blue)
to the +12V tine for the reverse tight and the ground
wire {Green} with lug to the chassis.
Camera Cable
ADJUSTMENT
The following adjustment should be made by qualified
service personnel or system installers.
1. The distance seals (for 6.6ft (2.0m) to 9.2ft (2.8m)
and 9.2ft (2.8m) and higher of body height} for the
monitor screen are attached as standard accessories.
Note : By putting the distance seal onto the monitor
screen, the ambient light may be reflected
even the monitor screen is a non-glare type.
When less reflection is required, do not put
the distance seal onto the monitor screen.
Approx. 16ft (5m) Line
Approx. 3.3ft
(1m) Line
2. Choose the distance seal which is the closest to the
body height and remove the protection seal for
scratches, F
3. Clean the monitor screen and put the distance seal
onto the monitor screen after removing the reverse
paper on the glues on the 4 corners of the seal.
Monitor Screen
Reference
Line
Rear
Bumper

OPERATING PROCEDURE
4. Adjust the camera tile by loosing 4 hex bolts so that 1. Turn the ignition to ON position and confirm that
the rear bumper positions on the reference line of the the Mode Indicator (12) LEO lights to green
distance chart on the monitor screen. (STANDBY mode).
2. Whenever changing the gear shift to the reverse
position, the Mode Indicator (12) LED turns into
amber {ON mode) and the rearview picture. can
Reference automatically be seen on the monitor screen in few
seconds.
Caution : The distance lines indicated on the distance 4. Whenever changing the gear shift to other than
seal are distances on the ground level. reverse position, the Mode Indicator (12) LED turns
The obstacles in the mid air may be seen into green and the picture on the monitor will dis-
more distance than that in the actual fact. appear.
5, Even the gear shift positions other than reverse
position, the rearview picture can be seen by pressing
the Mode Selection Switch (13) once.
6. To reset the monitor to standby mode, press the
Mode Selection Switch (13) once again.
7. Adjust the Brightness and Contrast controls for the
clear picture.

VIEW RANGE
9.2ft
(2.8m)
75
ft
(22.8m)
———_——___+4
16.5ft (Sm)
16.5ft (5m)
SYSTEM CONNECTION
MONITOR
CAMERA
BATTERY 14-pin
Fuse Box CONNECTOR oO Camera Cable =
. GP-CA40 (33 ft)
(Red) Remote GP-CA41 (66 ft)
Chassis (GROUND) (Green)
To Reverse Light
Reverse
Switch
(Shift Gear)

MECHANICAL DATA
= CAMERA
{Unit : mm)
= MONITOR
(Unit : mm}
221.5
S4o=

SPECIFICATIONS
® Overall Specifications GP-RV110
Power Source :
DC Input Voltage for Power Source :
Grounding :
Scanning :
Scanning Lines :
Horizontal Scanning Frequency :
Vertical Scanning Frequency :
Synchronization :
Horizontal Resolution :
Signal to Noise Ratio :
Minimum flumination :
Vibration Resistance :
Ambient Temperature :
Ambient Humidity :
# Camera GP-RV111
Power Source :
Pick-up Device :
Lens :
Angular Field of View :
Dimensions :
Weight :
® Monitor GP-RV112
Power Source :
DC Input Voltage for Power Source :
Cathode Ray Tube :
Automatic Brightness Control :
Dimensions :
{Excluding Hood and Fixing Plate}
Weight :
DC 12V,1.5A
DC 10V ~ 16V
Minus (—) Ground
2:1 interlace
525 lines
15.734 kHz
60 Hz
Internal Sync by Built-in Syne Generator
300 lines at center
40 dB
0.5 footcandies (5 lux)
4 4G (10Hz - 100Hz)
14°F - 131°F (—10°C - +55°C)
Less than 90%
Supplied from Monitor GP-RV112 DC 200mA, Approx. DC 12V
1/2" Interline Transfer CCD with 422(H) x 489(V) pixels
F1.4, 3.0mm, Auto Iris Control Lens
100° (H) x 83° (V)
9-1/4" (W) x 3-9/16” (H) x 7-1/4" (D}
(236(W) x 93(H} x 185(D) mm)
4.2 Ibs (1.89 kg)
DC 12V, 1.5A
DC 10V ~ 16V
7" Flat, Square and Non-glare Screen
Yes
8-11/16"' (W) x 5-9/16” (H) x 8-3/16" (OD)
(221 (W) x 142{(H) x 208(D} mm)
9.55 Ibs (4.3 kg)
Weights and Dimensions indicated are approximate.
Specifications are subject to change without notice.
STANDARD ACCESSORIES
o Remote Cable for Monitor
OPTIONAL ACCESSORIES
o Camera Cable GP-CA40 (33 ft)
o Camera Cable GP-CA41 (66 ft)
o Monitor Hood GP-Q48
1 pe
ee fi

Panasonic
industrial Company
Division of Matsushita Electric Corporation of America
INDUSTRIAL CAMERA DIVISION
Executive Office: One Panasonic Way, Secaucus New Jersey 07094 [phone]
PANASONIC HAWAII INC.
91-238 Kauhi Street Ewa Beach P.O. Box 774 Honolulu, Hawaii 96808-0774 [phone]
MATSUSHITA ELECTRIC OF CANADA LIMITED
5770 Ambler Drive, Mississauga, Ontario, Canada L4W 2T3 [phone]
PANASONIC SALES COMPANY
DIVISION OF MATSUSHITA ELECTRIC OF PUERTO RICO, INC.
Ave 65 de Infanteria, Km, 9.7, Victoria Industrial Park, Carolina, Puerto Rico 00630 [phone]
N1087-0 YWV8QA1490AN
Printed in Japan
®3
