Service Manual
Order DCS - NOV2003 - 001 - MS
TC-20KL03A
TC-29KL03A
Panasonic
®
Color Television
MX5ZB CHASSIS
© 2003 Panasonic da Amazônia S/A
CS Division
Technical Support
TELEVISION
Power source
Consumption
Antenna input jack
Color systems
Tuning system
Channel capability
Picture tube (Diagonal Visual)
Audio system
Video input jack
Audio input jack
Video Outlet
Audio Outlet
Dimension (width, height, depth)
Weight
TC-20KL03A
110/220 V AC, 50/60 Hz automatic switch
79 W
75 ohms - VHF/UHF/CATV
PAL-M/NTSC/PAL-N
F.S.T.
2 to 13 (VHF)
14 to 69 (UHF)
1 to125 (CATV)
Panablack 48 cm
50 W PMPO
1 (back) + 1 (front)
1 (back) + 1 (front)
1 (back)
1 (back) + 1 (earphone)
600 x 473 x 487 (mm)
17.7 kg
Supplied Accessories:
• 1 Remote Control Transmitter
• 1 300Ω/75ΩBalum
• 2 “AA” (or R6) batteries (1.5V; ABNT/IEC)
• 1 Internal antenna (for TC-20KL03A only)
Speci ications
Specifications are subject to change without notice. Weight and dimensions shown are approximate.
Remote Control Transmiter:
Power Source 3V (2 AA type batteries)
Infrared Length 9500 A (Angstron)
Number of Buttons 29 keys
Dimensions (W x H x D) (54 x 27 x 135) mm
TC-20KL03A
110/220 V AC, 50/60 Hz automatic switch
120 W
75 ohms - VHF/UHF/CATV
PAL-M/NTSC/PAL-N
F.S.T.
2 to 13 (VHF)
14 to 69 (UHF)
1 to125 (CATV)
Panablack 68 cm
82 W PMPO
1 (back) + 1 (front)
1 (back) + 1 (front)
1 (back)
1 (back) + 1 (earphone)
760 x 579 x 512 (mm)
34 kg
All manuals and user guides at all-guides.com
all-guides.com

- 15 -
TC-20KL03A / TC-29KL03A
SCHEMATIC DIAGRAMS
CRT BOARD SCHEMATIC DIAGRAM (L)
All manuals and user guides at all-guides.com

- 16 -
TC-20KL03A / TC-29KL03A
DVD CONNECTION SCHEMATIC DIAGRAM (D BOARD)
All manuals and user guides at all-guides.com

- 17 -
TC-20KL03A / TC-29KL03A
AV FRONTAL SCHEMATIC DIAGRAM (G BOARD)
REMOTE CONTROL RECEIVER SCHEMATIC DIAGRAM (R BOARD)
All manuals and user guides at all-guides.com

- 18 -
TC-20KL03A / TC-29KL03A
MAIN BOARD SCHEMATIC DIAGRAM (1/10)
Power Supply
All manuals and user guides at all-guides.com

- 19 -
TC-20KL03A / TC-29KL03A
MAIN BOARD SCHEMATIC DIAGRAM (2/10)
Power Supply
All manuals and user guides at all-guides.com
all-guides.com

- 20 -
TC-20KL03A / TC-29KL03A
MAIN BOARD SCHEMATIC DIAGRAM (3/10)
Microprocessor / YUV / Syntony
All manuals and user guides at all-guides.com

- 21 -
TC-20KL03A / TC-29KL03A
MAIN BOARD SCHEMATIC DIAGRAM (4/10)
Microprocessor / YUV / Syntony
All manuals and user guides at all-guides.com

- 22 -
TC-20KL03A / TC-29KL03A
MAIN BOARD SCHEMATIC DIAGRAM (5/10)
Audio signal process
All manuals and user guides at all-guides.com

- 23 -
TC-20KL03A / TC-29KL03A
MAIN BOARD SCHEMATIC DIAGRAM (6/10)
Audio signal process
All manuals and user guides at all-guides.com

- 24 -
TC-20KL03A / TC-29KL03A
MAIN BOARD SCHEMATIC DIAGRAM (7/10)
Vertical / Horizontal
All manuals and user guides at all-guides.com
all-guides.com

- 25 -
TC-20KL03A / TC-29KL03A
MAIN BOARD SCHEMATIC DIAGRAM (8/10)
Vertical / Horizontal
All manuals and user guides at all-guides.com

- 26 -
TC-20KL03A / TC-29KL03A
MAIN BOARD SCHEMATIC DIAGRAM (9/10)
Audio output
All manuals and user guides at all-guides.com

- 27 -
TC-20KL03A / TC-29KL03A
MAIN BOARD SCHEMATIC DIAGRAM (10/10)
Audio output
All manuals and user guides at all-guides.com
