Panasonic TX-W32R4DP User manual

Colour Television
TX-W32R4DP
EURO-4 Chassis
SPECIFICATIONS
Power Source: 220-240V a.c., 50Hz
Power Consumption: 140W
Aerial Impedance: 75Ωunbalanced, Coaxial Type
Stand-by Power
Consumption: 1,8W
Receiving System: PAL I, PAL 525/60
M.NTSC
NTSC (AV only)
Receiving Channels: UHF E21-E69
Intermediate Frequency:
Video 39,5MHz
Audio 33,5MHz, 32,95MHz
Colour 35,07MHz
Video/Audio
Terminals:
AV1 IN Video (21 pin) 1V p-p 75Ω
Audio (21 pin) 500mV rms 10kΩ
RGB (21 pin)
AV1 OUT Video (21 pin) 1V p-p 75Ω
Audio (21 pin) 500mV rms 1kΩ
AV2 IN Video (21 pin) 1V p-p 75Ω
Audio (21 pin) 500mV rms 10kΩ
S-Video IN Y: 1V p-p 75Ω
(21 pin) C: 0.3V p-p 75Ω
AV2 OUT Video (21 pin) 1V p-p 75Ω
Audio (21 pin) 500mV rms 1kΩ
Selectable Output (21 pin)
AV3 IN S-Video IN Y: 1V p-p 75Ω
(4-pin) C: 0,3V p-p 75Ω
Audio(RCAx2) 500mV rms10kΩ
Video (RCAx1) 1V p-p 75Ω
Dolby Surround Out 5 x Dolby Surround Out RCA
(Rear)
External Speaker
connections 2 x Rear
1 x Centre
High Voltage: 30,5kV ±1kV
Picture Tube: W76LFC185X06 76cm
Audio Output: Front Left/Right 2 x 20W
(Music Power) External Centre 20W
3D Sub-Woofer 26W
Surround 2 x 15W
8ΩImpedance
Headphones: 8ΩImpedance
3,5 mm
Accessories
supplied : Remote Control
2 x R6 (UM3) Batteries
TS-400DP Video cabinet / Speaker pack
Dimensions:
Height: 555mm
Width: 862mm
Depth: 553mm
Net weight: 50,5kg
Specifications are subject to change without notice.
Weights and dimensions shown are approximate.
NOTE: This Service Manual should be used in conjunction with
the EURO-4 Technical Guide.
ORDER No. SM-99002
Panasonic CS ( U.K. ) Ltd.
WILLOUGHBY ROAD,
BRACKNELL,
BERKS.,
RG12 8FT.

CONTENTS
SAFETY PRECAUTIONS..........................................................................................................................................................2
SERVICE HINTS.......................................................................................................................................................................3
SERVICE POSITION.................................................................................................................................................................4
ADJUSTMENT PROCEDURE AND SELF-CHECK ..................................................................................................................5
WAVEFORM PATTERN TABLE ...............................................................................................................................................6
ALIGNMENT SETTINGS...........................................................................................................................................................7
BLOCK DIAGRAMS..................................................................................................................................................................8
PARTS LOCATION.................................................................................................................................................................13
REPLACEMENT PARTS LIST................................................................................................................................................14
SCHEMATIC DIAGRAMS.......................................................................................................................................................26
CONDUCTOR VIEWS.............................................................................................................................................................33
SAFETY PRECAUTIONS
GENERAL GUIDE LINES
1. It is advisable to insert an isolation transformer in the
a.c. supply before servicing a hot chassis.
2. When servicing, observe the original lead dress in the
high voltage circuits. If a short circuit is found, replace
all parts that have been overheated or damaged by
the short circuit.
3. After servicing, see that all the protective devices
such as insulation barriers, insulation papers, shields
and isolation R-C combinations are correctly
installed.
4. When the receiver is not being used for a long period
of time, unplug the power cord from the a.c. outlet.
5. Potentials as high as 31,5kV are present when this
receiver is in operation. Operation of the receiver
without the rear cover involves the danger of a shock
hazard from the receiver power supply. Servicing
should not be attempted by anyone who is not
familiar with the precautions necessary when working
on high voltage equipment. Always discharge the
anode of the tube.
6. After servicing make the following leakage current
checks to prevent the customer from being exposed
to shock hazard.
LEAKAGE CURRENT COLD CHECK
1. Unplug the a.c. cord and connect a jumper between
the two prongs of the plug.
2. Turn on the receiver’s power switch.
3. Measure the resistance value with an ohmmeter,
between the jumpered a.c. plug and each exposed
metallic cabinet part on the receiver, such as screw
heads, aerials, connectors, control shafts etc. When
the exposed metallic part has a return path to the
chassis, the reading should be between 4M ohm and
20M ohm. When the exposed metal does not have a
return path to the chassis, the reading must be
infinite.
LEAKAGE CURRENT HOT CHECK
1. Plug the a.c. cord directly into the a.c. outlet. Do not
use an isolation transformer for this check.
2. Connect a 2kΩ10W resistor in series with an
exposed metallic part on the receiver and an earth,
such as a water pipe.
3. Use an a.c. voltmeter with high impedance to
measure the potential across the resistor.
4. Check each exposed metallic part and check the
voltage at each point.
5. Reverse the a.c. plug at the outlet and repeat each of
the above measurements.
6. The potential at any point should not exceed
1,4 Vrms. In case a measurement is outside the limits
specified, there is a possibility of a shock hazard, and
the receiver should be repaired and rechecked before
it is returned to the customer.
X-RADIATION WARNING
1. The potential sources of X-Radiation in TV sets are
the high voltage section and the picture tube.
2. When using a picture tube test jig for service, ensure
that the jig is capable of handling 31,5kV without
causing X-Radiation.
NOTE: It is important to use an accurate periodically
calibrated high voltage meter.
1. Set the brightness to minimum.
2. Measure the high voltage. The meter should
indicate :- 30,5kV ± 1kV. If the meter indication is out
of tolerance, immediate service and correction is
required to prevent the possibility of premature
component failure.
3. To prevent any X-Radiation possibility, it is essential
to use the specified tube.
HOT CHECK CIRCUIT
a.c. Voltmeter
WATER PIPE
(EARTH)
TO INSTRUMENT’S EXPOSED
METALLIC PARTS Fig. 1.
2kΩ10 Watts
2

SERVICE HINTS
How to remove the rear cover
1. Remove the 10 screws as shown in Fig.2.
LOCATION OF CONTROLS
3
SCREWS
Fig.2.
K - Board E - Board M - Board
Focus
Screen
H - Board
Fig.3.
C - Board
P - Board
Y - Board

HOW TO MOVE THE CHASSIS INTO SERVICE POSITION
1. Remove the bead clamper from the mains lead and affix,using back cover screw, into top right-hand cabinet rib (A),
shown in Fig.4.
2. Hold and lift the rear of the E-PCB chassis and gently pull the chassis toward you, as shown in Fig.4.
3. Release the respective wiring clips and rotate the chassis vertically through 90°, anti-clockwise.
4. Locate the base of the chassis frame into the hole (B), shown in Fig.6.
5. Clip the chassis frame onto the bead clamper, shown in Fig.5.
6. After servicing replace the bead clamper and ensure all wiring is returned to its original position before returning the
receiver to the customer.
Fig.4.
Fig.5.
Fig.6.
(
B
)
4
(
A
)

ADJUSTMENT PROCEDURE
Item / Preparation Adjustments
+B SET-UP
1. Receive a Greyscale signal.
2. Set the controls :-
Brightness Minimum
Contrast Minimum
Volume Minimum
1. Set the +B voltage up as follows:-
Adjust R811 so that B2 shows 148V±1V.
2. Confirm the following voltages.
B9 5 ± 0,25V B10 5 ± 0,25V
B5 12 ± 0,5V B11 33 ± 1,5V
B4 16 ± 1V B7 8 ± 0,5V
B12 26 ± 1V B8 5,5 ± 0,5V
B3 41 ± 1,5V B13 15 ± 1V
B1 200 ± 10V B14 -15 ± 1V
CUT OFF / Ug2 Test
1. Receive a Greyscale signal.
2. Degauss the tube externally.
3. Set the TV into Service Mode 1.
4. Select Cut off mode.
To adjust Cutoff connect an oscilloscope to the Blue
cathode, adjust "cutoff" value using the "Yellow" and "Blue"
buttons until the black level is 160V±5V press "STR" to store
the value. Remove the oscilloscope.
Select Ug2 adjustment and adjust the screen VR until the
display shows "O.K."
FACTORY SETTINGS
To return customer settings to factory settings and clear owner ID of all information input by the customer, enter Self-Check
mode. Press the down (-/v) button on the customer controls at the front of the TV set, at the same time pressing the STATUS
button on the remote control. To exit Self Check, switch off the TV set at the power button.
Self Check is also used to automatically check the bus lines and hexadecimal code of the TV set. If the CCU ports have
been checked and found to be incorrect or not located then " - - " will appear in place of "O.K.". For more in-depth TV
diagnostics use the LUCI interface as listed below.
Service Aids
To aid in the service of our current chassis there are a number of Service Aids which have been made available.
•LUCI interface kit (Linked Utility Computer Interface)
Part number: TZS6EZ002
This contains interface and cables for connecting TV service connector and a PC as well as diagnostic software. As new
models are introduced upgrade software will become available.
•VICI (Visual Interactive Computer Information)
These C.D.'s contain multimedia documentation providing quick access to service information.
Part No. TZS7EZ006 & TZS7EZ005
1. Service Manuals
2. Instruction Books
3. Technical Information
•TASMIN (Technically Advanced System for Multimedia Interactive Notes)
As well as providing a first step towards more interactive training this product also achieves quick access to Technical
Information.
VDP O.K.
TUN O.K.
E2 O.K.
MSP O.K.
DPL O.K.
PCB O.K.
Cab O.K.
Sum Factory use only
OPTION 1 00
OPTION 2 21
OPTION 3 02
OPTION 4 09
OPTION 5 B1
OPTION 6 A9
5
NOTE: Self Check should onl
y
be used when refurbishin
g
the TV set and not durin
g
normal repair work.

WAVEFORM PATTERN TABLE
6
Video Out
IC601 Pin 59
2V
64µs
B - Out
E8 Pin 4
64µs
4.6V
64µs
2V
H - Pulse
Base Q503
VFLB
IC451 Pin 3
1V
20ms
B - Out
IC601 Pin 39
275mV
64µs
64µs
3V
H - Out
IC601 Pin 50
Vert Out
IC601 Pin 31
20ms
0.7V
13µs
3.7V
SCL
IC1201 Pin 3
R - Out
E8 Pin 5
64µs
4.6V
HFLB
IC601 Pin 13
64µs
6.2V
R - Out
IC601 Pin 37
64µs
275mV
G - Out
IC601 Pin 38
275mV
64µs
Vert Drive
IC451 Pin 2
20ms
57V
HFLB
IC701 Pin 8
64µs
1.5V
G - Out
E8 Pin 3
64µs
4.4V
SVM Out
IC601 Pin 34
88mV
64µs
H - Out
IC701 Pin 5
30mV
64µs

ALIGNMENT SETTINGS
(The figures below are nominal and used for representative purposes only.)
Alignment Function Settings / Special features
Horizontal Position H-Pos
061 Optimum setting.
Vertical Position V-Pos
005 Optimum setting.
Horizontal Amplitude H-Amp
055 Optimum setting.
Vert. Amplitude V-Amp
054 Optimum setting.
EW-amplitude E/W-Amp1
-128 Optimum setting.
EW-amplitude E/W-Amp2
006 Optimum setting.
Trapezium-comp Trapez-1
047 Optimum setting.
Trapezium-comp Trapez-2
-128 Optimum setting.
Vertical Linearity V-Lin
006 Optimum setting.
Vertical Symmetry V-Sym
002 Optimum setting.
DVCO DVCO
-005
Receive a PAL Colour Bar Pattern. For
DVCO alignment press "Blue" button, wait
until the colours are changing slowly and
press "STR".
Cut-off DC Cut-off
0171
Ug2 Test Ug2
055
O.K.
To adjust Cutoff connect an oscilloscope to
the blue cathode, adjust "cutoff" value
using the "Yellow" and "Blue" buttons until
the black level is 160V±5V press "STR" to
store the value. Remove the oscilloscope.
Select Ug2 adjustment and adjust the
screen VR until the display shows "O.K."
Highlight
Lowlight High 0902 0777 0864 Low 0117 0132 0112 Optimum setting.
Sub-Brightness Sub-Brightness
255 Optimum setting.
7
Black Level
160V±5V
GND

VIDEO BLOCK DIAGRAM
E15
8
H1
6 6
8
2 2
Q105
AV1
IC601
9LGHR

2XW


9LGHR

,Q


AV2
Q3601
IC1101
R 37
68
CVBS
61 V IN 1
43 B IN
42 G IN
41 R IN
62 VIN 2
60 C IN
63 VIN 3
VIN 4
64 VIDEO OUT
59
B IN 47
B OUT 39 Q353
Q35
2
Q35
1
CRT
TUNER
Q104
5HG


%OXH


*UHHQ


9LGHR

,Q


$9

&


9LGHR

2XW


G OUT 38
R OUT 37
G IN 46
R IN 45
Q35
4
VM
COILS
Q905 Q907 Q909
Q908Q906
SVM OUT 34
E8
4
3
5
Y2
4
3
5
77
Q3001
G 38
B 39
Y - BOARD
E - BOARD
VIDEO
PROCESSOR
MICRO
PROCESSOR
H3E61
1 1
H - BOARD
AV3
M2
E17
66
Y
C
M - BOARD
Q305
Q303
Q301
3
2
1
7
8
9
IC351
Q306
Q304
Q302
Q950
Q951
RGB
OUTPUT
IC3401
8
3
VIDEO
SWITCHING
6
4 4
M3
H2
4
4 8
82
2 6
6
Q3402
Q3201
Q3203
Q3204
Q3205Q3206Q3208Q3209
Q3207 Q3202

AUDIO BLOCK DIAGRAM
TUNER
Q101
Q102
IC2101
AV2
AV1
DACM_R 24
SC1_OUT_R 30
SC1_OUT_L 31
1 R OUT
3 L OUT
1 R OUT
3 L OUT
2 R IN
6 L IN
2 R IN
6 L IN
47 ANA_IN1+
DACM_L 25
SC3_IN_R 38
SC1_IN_R 42
SC1_IN_L 41
SC2_OUT_R 27
SC2_OUT_L 28
SC2_IN_R 40
SC2_IN_L 39
22 DACA_L
E - BOARD
AUDIO
PROCESSOR AV3
L
R
6 R
4 L
HEADPHONE
7 R
5 L
M4
1
M5
3
E16A M1
1 1
2 2
IC251
5 R R 7
L 11
AUDIO
OUTPUT
2 L
E17 M2
10 10
8 8
M - BOARD
2 L
3 R
M6 K8
1
3
E12
3
4
5
6
7
18 I2S_DA_IN_2
12 I2S_DA_IN_1
11 I2S_DA_OUT
10 I2S_DA_WS
9 I2S_DA_CL
I2S_DA_IN_2
I2S_DA_IN_1
I2S_DA_OUT
I2S_DA_WS
I2S_DA_CL
K3
3
1
DACA_R
DACA_L
K7
Q2304
Q2302
E22

DOLBY BLOCK DIAGRAM
K5
1
3
5
C2
1
3
5
JK2702
E12 K3
3
4
5
Q2425
Q2426 Q2428
Q2401 Q2402
Q2403 Q2404 Q2405 Q2406
JK2401
1
3
5
7
14
12
10
8
IC2402
E22 K7
1
3
C5
1
K8 M6
1
3
IC2404 13
57
IC2704
IC2703
IC2702
K6
1
Q2410
Q2409
1
1
1
4
4
4
Audio Left
Audio Right
Headphone Left
Headphone Right
Surround
Centre
Woofer
Surround L
Centre
Surround R
JK2402
Woofer
Surround L
Centre Out
Left Front
Surround R
Right Front
Q2427
Q2423
Q2419
Q2418
Q2417
Q2421
Q2420
I2S_DA_OUT_2
I2S_DA_OUT_1
I2S_DA_IN
6
7
I2S_WS
I2S_CL
Q2704
Q2705
K - BOARD
C - BOARD
OPERATIONAL
AMPLIFIER
HEADPHONE
AMPLIFIER
AUDIO
AMPLIFIER
AUDIO
AMPLIFIER
AUDIO
AMPLIFIER
19
11
12 IC2401
25
24
22
21
27
10
9
DOLBY
PROCESSOR
Q2703

CONTROL BLOCK DIAGRAM
H3
3
E63
1
E18
6
5
4
3
SDA 1
SCL 1
SDA 2
SCL 2
SERVICE / TEST
IC1101
TUNER
IC601
IC1103
6
5
50 SCL 2
SDA 2
4
3
SDA 1
SCL 1
SDA
48 49
5
IC3401
Q451
71
60
Q854
52
Q853
74
Q1052
81
AV2
8
10
AV1
8
10
12
Q856
75
Q851
Q1106
Q1105
Q1107
Q1104
51
72
73
AV LINK
SLOW 2
SLOW 1
SCL 1
SDA 1
59
58
Q3006
Q3007
55
VPROT
KEYSCAN
ON/OFF
R.C.
L.E.D.
PROT 1
SLOW 2
OUT
IN
SLOW 1
SERVICE
SCL
SDA
H - BOARD
E - BOARD
VIDEO
SWITCHING IC2101
8
7
4AUDIO
PROCESSOR
MICRO
PROCESSOR
VIDEO
PROCESSOR
EAROM
M - BOARD
D1061
Q3401
IC1061
LED
RECEIVER
SCL
M2 E17
5 5
M1 E16A
8 8
77
Q1051
Q1062
55
66
Q3205
Q3206
Q3201
Q3203
Q3204
LOCAL
KEYS
SWITCH
MATRIX
78 79
MIX SWITCH
CHROMA SWITCH

POWER SUPPLY BLOCK DIAGRAM
H - BOARD
D868
+
~
~
IC801
T801
IC251
D850
TUNER
Q850
IC851
IC853
D454
Q853
IC1103 IC1105
IC2101
T802 RL801
5V SBY
5V SBY
5V
5V
IC601
8V
82 33 46 15 58
3
4
3
1
3
1
S4
B1
P2
P1
S5
S2
S7
10
T551
9
8
5
6
2
12V
200V
33V
-14V
14V
27V
150V
29V
7V
15V
5V
D867
Q852
Q854
Q855
1
D805
R805 R814
IC850
1
2
D862
R854
33V
16
IC1101
243 66
MICRO
PROCESSOR AUDIO
PROCESSOR VIDEO
PROCESSOR
IC1102
131 32
EPROM EAROM RESET
REG
REG
REG
IC3401
7VIDEO
SWITCHING
IC701
6
EW
CORRECTION
POWER
SUPPLY IC451
6
3
1
V-OUTPUT
AUDIO
OUTPUT
D801
E - BOARD
Y - BOARD
E3
2Y3 2
E1
4
1
E2
2
1R802
DEGAUSS
COIL
Line
Filter
E62
1H3 2
IC351
6
RGB
OUTPUT
R2715
18V
-18V
R2714 Q2702
Q2701
22V
IC2701
3IC2703
35 IC2704
35
E5
3C1 3
C - BOARD
E11
7K2 7
5 5
12V
Q2407
IC2403
12
33
IC2401
IC2402
IC2404
5
6
16
46
4
8
K - BOARD 8
K5
C2
8
D2720
POWER
SUPPLY
IC2702
35
AUDIO
AMPLIFIER
S1
S7
F1
P2
T2701
S2
AUDIO
AMPLIFIER AUDIO AMPLIFIER
REG
OPERATIONAL
AMPLIFIER
HEADPHONE
AMPLIFIER
DOLBY
PROCESSOR
M - BOARD
IC1104
2
RESET
M1
9E16A 9
IC1061
LED
RECEIVER
M2
3E17 3
D1061
Q1062
M11 41
M10 4 1
TO
PERIPHERAL
CIRCUITS
P2
1
4
P1
1
4
P - BOARD

PARTS LOCATION
13
NOTE:
The numbers on the exploded view below
refer to the mechanical section of the
Replacement Parts List.
3
29
1
28
16
26
15
35
5
23
21
22
20
7
11
8
9
18
27
6
32
30
4
2
34
33
17
14
12
13
10
25
19
31
24

Components Identified by mark have special characteristics important for safety.
* When replacing any of these components, use only manufacturers specified parts.
In case of ordering these spare parts, please always add the complete Model-Type
number to your order.
REPLACEMENT PARTS LIST
Im
p
ortant Safet
y
Notice
DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
MECHANICAL PARTS
3D WOOFER SPEAKER1 EAB10102B2 SPEAKER2 EAGG1218J2 REAR SPEAKER COMPLETE3 EAS8E002-A CENTRE SPEAKER4 EAS8E050-B TUNER5 ENG27506G REMOTE CONTROL6 EUR511210 PANASONIC BADGE7 TBM8E1728 POWER BUTTON8 TBX8E049 CRT FIXING SCREW9 THT1062 SPEAKER REFLECTOR10 TKK8E026 DOOR LID11 TKP8E1141 LEFT PANEL12 TKP8E1143 SPEAKER NET13 TKP8E1148 RIGHT PANEL (DOLBY)14 TKP8E1155 REAR AV PANEL15 TKP8E1249 BACK COVER16 TKU8E00290 CABINET17 TKY8E110 DEGAUSS COIL18 TLK8E05123 CONTROL BRACKET19 TMW8E023 CHASSIS FRAME20 TMX8E031 C P.C.B.21 TNP8EC003AD E P.C.B.22 TNP8EE009CB H P.C.B.23 TNP8EH002AB K P.C.B.24 TNP8EK005AC M P.C.B.25 TNP8EM017AB P P.C.B.26 TNP8EP015AA Y P.C.B.27 TNP8EY012AJ MODEL LABEL28 TQF8E2761 DOLBY SPEAKER WIRE 12M29 TSX8E0015S POWER CORD30 TSX8E0025 FOCUS LEAD ASSY31 TXFJTF01BMTG BATTERY COVER (REM0TE)32 UR51IEC904A C.R.T.33 W76LFC185X06 ANODE CABLE34 ZTBZAD550A F.B.T.35 ZTFM05002A
MISCELLANEOUS COMPONENTS
FIX CLIP31221212478 IC SOCKET832AG11D-ESL RELAYF9-4-220 84 PIN IC SOCKETPLCC-84-T PRESET PANELTBM8E1532-2 PRESET LABELTBM8E1900 LID CATCHTEK6940 GEOMAGNETIC COILTLK8E05124 LED HOLDERTMW8E017 OUTER CARTONTPC8E4729 TOP CUSHIONTPD8E621 BOTTOM CUSHIONTPD8E622 TV STANDTS-400DP BATTERY PACKUM-3DJ-2P DOLBY BRACKETPKN1 TMX8E022
RELAYRL801 TSE1885-1 THERMISTORR802 232266296706 C.R.T. SOCKETS351 0330550049
INSTRUCTION BOOKS
ENGLISHTQB8E2474-3
I.C.s
AUDIO OUTPUTIC251 LA4282 R.G.B. OUTPUTIC351 TDA6103Q-N3 VERTICAL OUTPUTIC451 LA7845N VIDEO PRCESSORIC601 VDP3120BPPB1 E/W CORRECTIONIC701 TEA2031A POWER SUPPLYIC801 STRF6654LF51 ERROR AMPLIFERIC850 SE140N 12V REGULATORIC851 L78M12MRB 8V REGULATORIC853 AN78L08TA LED RECEIVERIC1061 RPM-637CBRS1 MICRO PROCESSORIC1101 SDA5450C48UK EPROM *IC1102 27C2001-L01 EAROM *IC1103 X24CGL0201MA RESETIC1104 MN1381-R(TA) RESETIC1105 MN1381-T(TA) EARTH CORRECTIONIC1900 LA6515 AUDIO PROCESSORIC2101 MSP3410DPOB4 DOLBY PROCESSORIC2401 DPL3519APOA1 OPERATIONAL AMPLIFIERIC2402 AN6554 8V REGULATORIC2403 AN78L08TA HEADPHONE AMPLIFIERIC2404 NJM4556AD POWER SUPPLYIC2701 STR10006-S AUDIO AMPLIFIERIC2702 TDA2030AV AUDIO AMPLIFIERIC2703 TDA2030AV AUDIO AMPLIFIERIC2704 TDA2030AV VIDEO SWITCHINGIC3401 TEA2114
FUSES
FUSEF801 19181-3.15 FUSE HOLDERF8011 EYF52BC FUSE HOLDERF8012 EYF52BC FS LINKR2711 TSF19632
DIODES
DIODED251 MA2180BLFS DIODED253 MA700TA5 DIODED254 MA700TA5 DIODED354 1SR124-4AT82 DIODED355 1SR124-4AT82 DIODED356 1SR124-4AT82 DIODED357 MA165TA5 DIODED358 MA165TA5 DIODED359 MA165TA5 DIODED360 MTZJT-7715A DIODED361 MA165TA5 DIODED362 MA165TA5 DIODED363 MA165TA5
14

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
DIODED364 MA165TA5 DIODED453 MA165TA5 DIODED454 ERA15-02V3 DIODED456 MTZJT-775.6C DIODED457 MA165TA5 DIODED501 MA165TA5 DIODED502 1SR124-4AT82 DIODED511 MA4047 DIODED552 RU3LFA1 DIODED553 1SR124-4AT82 DIODED554 1SR124-4AT82 DIODED556 MA165TA5 DIODED557 EU02 DIODED558 1SR124-4AT82 DIODED580 ERD07-15L7 DIODED601 DAN217T146 DIODED603 DAN217T146 DIODED605 DAN212KT146 DIODED606 MA165TA5 DIODED607 MA4051 DIODED609 1SR124-4AT82 DIODED615 STZ6.2NT146 DIODED616 STZ6.2NT146 DIODED701 MA165TA5 DIODED702 MTZJT-775.1C DIODED704 MA29TA5 DIODED705 MTZJT-775.6C DIODED801 RBV-608LF-B DIODED803 1SR124-4AT82 DIODED804 1SR124-4AT82 PHOTO COUPLERD805 TLP621GR-LF2 DIODED806 1SR124-4AT82 DIODED850 RU4BLF-L1 DIODED851 MTZJT776.2B DIODED852 MA165TA5 DIODED853 MA2180BLFS DIODED854 TVSRU2AMLFA5 DIODED855 FML22SLF610 DIODED856 RU4AMLF-M1 DIODED857 MTZJT-775.1C DIODED858 MA165TA5 DIODED859 MA165TA5 DIODED861 MA165TA5 DIODED862 MTZJT-7736A DIODED863 MA165TA5 DIODED865 MA165TA5 DIODED866 MA165TA5 DIODED867 EK06-V0 DIODED868 1N4150T-77 DIODED869 1N4150T-77 DIODED870 MA165TA5 DIODED871 1N4150T-77 DIODED873 MTZJT-775.6C DIODED874 1SR124-4AT82 DIODED875 BZX79A75A26A DIODED901 MA165TA5 DIODED902 MA165TA5 DIODED904 MA165TA5 DIODED905 MA165TA5 DIODED906 RLS72TE-11 DIODED1061 LN81RPHL DIODED1101 MA165TA5 DIODED1102 MA165TA5 DIODED1104 MA165TA5 DIODED1105 MA165TA5 DIODED2101 MA723TA5
DIODED2102 MA723TA5 DIODED2103 MA723TA5 DIODED2104 MA723TA5 DIODED2105 MTZJT-778.2C DIODED2401 MA165TA5 DIODED2402 MA165TA5 DIODED2403 MTZJT-7712C DIODED2404 MTZJT-7712C DIODED2405 MTZJT-7712C DIODED2406 MTZJT-7712C DIODED2409 MA165TA5 DIODED2705 EG01CV0 DIODED2706 1SR124-4AT82 DIODED2707 TVSEH1LF-F7 DIODED2708 MA4075 DIODED2709 1SR124-4AT82 DIODED2710 1SR124-4AT82 DIODED2711 RU4AMLF-M1 DIODED2712 MA165TA5 DIODED2713 MA165TA5 DIODED2714 MA165TA5 DIODED2715 MA165TA5 DIODED2716 MA165TA5 DIODED2717 MA165TA5 DIODED2718 MTZJT-779.1C DIODED2719 MA165TA5 DIODED2720 1SR124-4AT82 DIODED3201 MTZJT-778.2C DIODED3202 MTZJT-778.2C
TRANSISTORS
TRANSISTORQ101 BC847B TRANSISTORQ102 BC847B TRANSISTORQ104 BC847B TRANSISTORQ105 BC847B TRANSISTORQ251 2SD1328STX TRANSISTORQ252 2SD1328STX TRANSISTORQ253 BC847B TRANSISTORQ254 BC847B TRANSISTORQ301 BC847B TRANSISTORQ302 FMY4T148 TRANSISTORQ303 BC847B TRANSISTORQ304 FMY4T148 TRANSISTORQ305 BC847B TRANSISTORQ306 FMY4T148 TRANSISTORQ351 2SA1767 TRANSISTORQ352 2SA1767 TRANSISTORQ353 2SA1767 TRANSISTORQ354 BC857B TRANSISTORQ451 BC857B TRANSISTORQ503 2SD2398-M2 TRANSISTORQ551 2SD1577LB TRANSISTORQ552 2SC1473-RN TRANSISTORQ701 BC857B TRANSISTORQ850 2SD1273PLB TRANSISTORQ851 BC857B TRANSISTORQ852 2SC1383-S TRANSISTORQ853 BC847B TRANSISTORQ854 BC847B TRANSISTORQ855 BC847B TRANSISTORQ856 BC847B TRANSISTORQ857 2SA1018QTA TRANSISTORQ905 BC847B TRANSISTORQ906 BC847B TRANSISTORQ907 BC857B TRANSISTORQ908 2SA1535ARLB TRANSISTORQ909 2SC3944ARLB
15

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
TRANSISTORQ950 BC847B TRANSISTORQ951 FMY4T148 TRANSISTORQ1051 BC847B TRANSISTORQ1062 BC847B TRANSISTORQ1101 BC847B TRANSISTORQ1104 BC847B TRANSISTORQ1105 BC847B TRANSISTORQ1106 BC847B TRANSISTORQ1107 BC847B TRANSISTORQ1108 BC847B TRANSISTORQ2101 BC857B TRANSISTORQ2102 BC857B TRANSISTORQ2103 BC857B TRANSISTORQ2302 BC857B TRANSISTORQ2304 BC857B TRANSISTORQ2401 BC857B TRANSISTORQ2402 BC857B TRANSISTORQ2403 BC857B TRANSISTORQ2404 BC857B TRANSISTORQ2405 BC847B TRANSISTORQ2406 BC847B TRANSISTORQ2407 BC847B TRANSISTORQ2409 BC857B TRANSISTORQ2410 BC857B TRANSISTORQ2416 BC857B TRANSISTORQ2417 BC847B TRANSISTORQ2418 BC847B TRANSISTORQ2419 BC847B TRANSISTORQ2420 BC847B TRANSISTORQ2421 BC847B TRANSISTORQ2423 BC857B TRANSISTORQ2425 BC857B TRANSISTORQ2426 BC857B TRANSISTORQ2427 BC847B TRANSISTORQ2428 BC857B TRANSISTORQ2429 BC857B TRANSISTORQ2430 BC847B TRANSISTORQ2431 BC847B TRANSISTORQ2701 BC557B/126 TRANSISTORQ2702 2SA684R TRANSISTORQ2703 BC847B TRANSISTORQ2704 BC847B TRANSISTORQ2705 BC847B TRANSISTORQ2706 BC857B TRANSISTORQ3001 BC847B TRANSISTORQ3006 BC847B TRANSISTORQ3007 BC847B TRANSISTORQ3201 BC847B TRANSISTORQ3202 BC847B TRANSISTORQ3203 BC857B TRANSISTORQ3204 BC857B TRANSISTORQ3205 BC847B TRANSISTORQ3206 BC847B TRANSISTORQ3207 BC847B TRANSISTORQ3208 BC847B TRANSISTORQ3209 BC847B TRANSISTORQ3401 BC847B TRANSISTORQ3402 BC847B TRANSISTORQ3601 BC847B
TRANSFORMERS
TRANSFORMERT501 ETH19Y173AY TRANSFORMERT801 ETS42AE226AD TRANSFORMERT802 ETP35KAN619U TRANSFORMERT2701 ETS35AA3Y7AD
COILS
COILL104 EXCELSA35T
COILL106 TLTACT100K COILL107 TLTACT6R8K COILL301 TLTACT4R7K COILL302 TLTACT4R7K COILL451 EXCELSA35T COILL501 EXCELSA35T COILL580 ELC08D682E COILL581 ELH5L6117 COILL582 ELC18B102E COILL583 ELC18B101L COILL601 TLTACT4R7K COILL602 TLTACT4R7K COILL603 TLTACT4R7K COILL604 TLTACT4R7K COILL606 TLTACT4R7K COILL607 ELJFC2R2KF COILL701 ELC10D682E COILL850 EXCELSA35T COILL851 EXCELSA35T COILL852 ELEIE470KA COILL855 EXCELSA35T COILL856 EXCELSA39V COILL901 EXCELSA24T COILL902 EXCELSA24T COILL1061 TLT331K991R COILL1103 TLTACT100K COILL1104 EXCELSA35T COILL1105 ELJFC2R2KF COILL1900 EXCELDR25V COILL2101 TLTACT100K COILL2103 EXCELSA35T COILL2104 TLTACT4R7K COILL2401 TLTACT3R3K COILL2402 TLTACT3R3K PEAKING COILL2403 TLTACT101K COILL2404 ELC08D3R3E COILL2405 ELC08D3R3E COILL2703 EXCELSA35T COILL2704 EXCELSA35T COILL2705 EXCELSA35T COILL2706 EXCELSA35T COILL2707 EXCELSA35T COILL2708 EXCELSA35T COILL2709 EXCELSA35T COILL2710 ELC08D3R3E COILL2711 ELC08D3R3E COILL2714 ELC08D3R3E COILL2715 ELC08D3R3E COILL3001 ELEMV1R5MA COILL3002 ELEMV1R5MA COILL3003 ELEMV1R5MA COILL3004 ELEMV1R5MA COILL3005 ELEBR2R2KA COILL3006 ELEBR2R2KA COILL3007 TLTACT2R2K COILL3201 ELEBR6R8KA COILL3202 ELEBR6R8KA COILL3203 TLT390K991R COILL3204 TLT331K991R COILL3401 ELESN2R2KA COILL3402 ELESN2R2KA
FILTERS
LINE FILTERL802 ELF18N012A LINE FILTERL804 ELF18N012A
CRYSTALS
CRYSTALX601 4730007267
16

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
CRYSTALX1101 TSSA121 CRYSTALX2101 4730007158 CRYSTALX2401 4730007158
RESISTORS
SOLIDERC12GK825 0.5W 10% 8M2
S.M.CARBC101 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSE10 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA45 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA47 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA48 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA49 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA5 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA52 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA54 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA55 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA57 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA58 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA6 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA60 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSM7 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA9 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSE12 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSE18 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSE22 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSE26 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSE3 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSE33 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSE35 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSE4 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSE42 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJSM14 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA7 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA44 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA8 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA19 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA28 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA27 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA26 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA25 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA24 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA23 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA22 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA21 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA3 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA2 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA13 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA18 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA17 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA16 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA15 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA14 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA12 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA10 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA1 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA20 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA39 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA36 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA38 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA4 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA40 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA11 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA37 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBJA1 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA43 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA46 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA30 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA35 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA5 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA50 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA2 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA51 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA33 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA31 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA61 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA8 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA29 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA32 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA21 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA56 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA23 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA34 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA59 ERJ8GEY0R00 .125W 5% 0
S.M.CARBJA53 ERJ8GEY0R00 .125W 5% 0
S.M.CARBR101 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR102 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR103 ERJ6GEYJ222 0.1W 5% 2K2
S.M.CARBR104 ERJ6GEYJ332 0.1W 5% 3K3
S.M.CARBR105 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR106 ERJ6GEYJ681 0.1W 5% 680
S.M.CARBR107 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR111 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR112 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR113 ERJ6GEYJ223 0.1W 5% 22K
S.M.CARBR114 ERJ6GEYJ331 0.1W 5% 330
S.M.CARBR115 ERJ6GEYJ331 0.1W 5% 330
S.M.CARBR116 ERJ6GEYJ562 0.1W 5% 5K6
S.M.CARBR117 ERJ6GEYJ222 0.1W 5% 2K2
S.M.CARBR118 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR121 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR251 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR252 ERJ6GEYJ272 0.1W 5% 2K7
S.M.CARBR253 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR254 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR255 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR256 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR257 ERJ6GEYJ151 0.1W 5% 150
S.M.CARBR258 ERJ6GEYJ272 0.1W 5% 2K7
S.M.CARBR259 ERJ6GEYJ151 0.1W 5% 150
S.M.CARBR260 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR261 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR262 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR263 ERJ6GEYJ473 0.1W 5% 47K
S.M.CARBR264 ERJ6GEYJ103 0.1W 5% 10K
CARBONR265 ERD25TJ2R2 0.25W 5% 2R2
CARBONR266 ERD25TJ2R2 0.25W 5% 2R2
WOUNDR267 ERF7ZK4R7 7W 10% 4R7
S.M.CARBR268 ERJ6GEYJ103 0.1W 5% 10K
METALR269 ERQ14AJ101 0.25W 5% 100
S.M.CARBR271 ERJ6GEYJ103 0.1W 5% 10K
WOUNDR272 ERF7ZK4R7 7W 10% 4R7
S.M.CARBR301 ERJ6GEYJ391 0.1W 5% 390
S.M.CARBR302 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR303 ERJ6GEYJ750 0.1W 5% 75
S.M.CARBR304 ERJ6GEYJ331 0.1W 5% 330
S.M.CARBR305 ERJ6GEYJ391 0.1W 5% 390
S.M.CARBR306 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR307 ERJ6GEYJ750 0.1W 5% 75
S.M.CARBR308 ERJ6GEYJ331 0.1W 5% 330
S.M.CARBR309 ERJ6GEYJ391 0.1W 5% 390
S.M.CARBR310 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR311 ERJ6GEYJ750 0.1W 5% 75
S.M.CARBR312 ERJ6GEYJ331 0.1W 5% 330
17

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
S.M.CARBR351 ERJ6GEYJ302 0.1W 5% 3K
S.M.CARBR352 ERJ6GEYJ302 0.1W 5% 3K
S.M.CARBR353 ERJ6GEYJ302 0.1W 5% 3K
S.M.CARBR354 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR355 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR356 ERJ6GEYJ102 0.1W 5% 1K
CARBONR357 ERDS1TJ114 0.5W 5% 110K
CARBONR358 ERDS1TJ114 0.5W 5% 110K
CARBONR359 ERDS1TJ114 0.5W 5% 110K
CARBONR363 ERD25TJ103 0.25W 5% 10K
CARBONR364 ERD25TJ103 0.25W 5% 10K
CARBONR365 ERD25TJ103 0.25W 5% 10K
CARBONR366 ERDS1TJ152 0.5W 5% 1K5
CARBONR367 ERDS1TJ152 0.5W 5% 1K5
CARBONR368 ERDS1TJ152 0.5W 5% 1K5
CARBONR369 ERD25TJ472 0.25W 5% 4K7
S.M.CARBR370 ERJ6GEYJ102 0.1W 5% 1K
FUSIBLER372 ERQ12AJ121 0.5W 5% 120
S.M.CARBR373 ERJ6GEYJ220 0.1W 5% 22
CARBONR374 ERD25TJ274 0.25W 5% 270K
S.M.CARBR375 ERJ6GEYJ684 0.1W 5% 680K
S.M.CARBR376 ERJ6GEYJ183 0.1W 5% 18K
FUSIBLER377 ERQ12HKR22 0.5W 5% R22
S.M.CARBR378 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR379 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR380 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR381 ERJ6GEYJ473 0.1W 5% 47K
S.M.CARBR451 ERJ6GEYJ223 0.1W 5% 22K
S.M.CARBR452 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR453 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR454 ERJ6GEYJ752 0.1W 5% 7K5
S.M.CARBR455 ERJ6GEYJ222 0.1W 5% 2K2
S.M.CARBR456 ERJ6GEYJ104 0.1W 5% 100K
S.M.CARBR457 ERJ6GEYJ223 0.1W 5% 22K
CARBONR458 ERD25TJ1R5 0.25W 5% 1R5
S.M.CARBR459 ERJ6GEYJ101 0.1W 5% 100
CARBONR460 ERDS1TJ331 0.5W 5% 330
WOUNDR461 ERW2PK1R2 2W 10% 1R2
CARBONR463 ERD25TJ222 0.25W 5% 2K2
S.M.CARBR464 ERJ6GEYJ182 0.1W 5% 1K8
S.M.CARBR465 ERJ6GEYJ681 0.1W 5% 680
S.M.CARBR502 ERJ6GEYJ511 0.1W 5% 510
CARBONR506 ERD25TJ560 0.25W 5% 56
METALR507 ERG2FJ470H 2W 5% 47
CARBONR509 ERDS1TJ152 0.5W 5% 1K5
CARBONR510 ERDS1FJ152 0.5W 5% 1K5
METALR555 ERQ12HKR33 0.5W 5% R33
CARBONR558 ERDS1TJ124 0.5W 5% 120K
METALR559 ERQ12HKR33 0.5W 5% R33
S.M.CARBR560 ERJ6GEYJ274 0.1W 5% 270K
S.M.CARBR561 ERJ6GEYJ273 0.1W 5% 27K
S.M.CARBR563 ERJ6GEYJ684 0.1W 5% 680K
S.M.CARBR564 ERJ6GEYJ623 0.1W 5% 62K
S.M.CARBR566 ERJ6GEYJ563 0.1W 5% 56K
WOUNDR567 ERF7ZK1R0 7W 10% 1
METALR580 ERG1SJ101 1W 5% 100
METALR581 ERG1SJ152 1W 5% 1K5
METALR582 ERG3FJ102H 3W 5% 1K
S.M.CARBR601 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR602 ERJ6GEYJ821 0.1W 5% 820
S.M.CARBR603 ERJ8GEYJ103 .125W 5% 10K
S.M.CARBR604 ERJ6GEYJ101 0.1W 5% 100
CARBONR605 ERD25TJ331 0.25W 5% 330
CARBONR606 ERD25TJ331 0.25W 5% 330
S.M.CARBR607 ERJ6GEYJ821 0.1W 5% 820
S.M.CARBR608 ERJ6GEYJ271 0.1W 5% 270
S.M.CARBR609 ERJ6GEYJ122 0.1W 5% 1K2
S.M.CARBR610 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR611 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR612 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR613 ERJ6GEYJ152 0.1W 5% 1K5
S.M.CARBR622 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR636 ERJ6GEYJ750 0.1W 5% 75
S.M.CARBR645 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR647 ERJ6GEYJ472 0.1W 5% 4K7
S.M.CARBR648 ERJ6GEYJ152 0.1W 5% 1K5
S.M.CARBR650 ERJ6GEYJ750 0.1W 5% 75
S.M.CARBR651 ERJ6GEYJ750 0.1W 5% 75
S.M.CARBR652 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR654 ERJ6GEYJ622 0.1W 5% 6K2
S.M.CARBR655 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR658 ERJ6GEYJ153 0.1W 5% 15K
S.M.CARBR659 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR660 ERJ6GEY0R00 0.1W 5% 0
FUSIBLER701 ERQ12AJ101 0.5W 5% 100
FUSIBLER702 ERQ12HJ330 0.5W 5% 33
METALR703 ERG2FJ821 2W 5% 820
S.M.CARBR704 ERJ6GEYJ563 0.1W 5% 56K
S.M.CARBR705 ERJ6GEYJ104 0.1W 5% 100K
S.M.CARBR706 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR707 ERJ6GEYJ391 0.1W 5% 390
S.M.CARBR708 ERJ6GEYJ393 0.1W 5% 39K
S.M.CARBR709 ERJ6GEYJ393 0.1W 5% 39K
S.M.CARBR710 ERJ6GEYJ273 0.1W 5% 27K
METALR711 ERG1SJ101 1W 5% 100
S.M.CARBR712 ERJ6GEYJ102 0.1W 5% 1K
SOLIDR801 ERC12ZGK335D 0.5W 10% 3M3
SOLIDR803 ERC12ZGK335D 0.5W 10% 3M3
CARBONR805 ERD25TJ473 0.25W 5% 47K
CARBONR806 ERD25TJ100 0.25W 5% 10
CARBONR807 ERD25TJ332 0.25W 5% 3K3
CARBONR809 ERD25TJ681 0.25W 5% 680
WOUNDR810 ERW2PKR27 2W 10% R27
WOUNDR811 ERW2PKR27 2W 10% R27
CARBONR812 ERD75TAJ825 0.75W 5% 8M2
WOUNDR813 ERF7ZK2R7 7W 20% 2R7
CARBONR814 ERD25TJ473 0.25W 5% 47K
CARBONR815 ERD25TJ222 0.25W 5% 2K2
CARBONR850 ERD25TJ122 0.25W 5% 1K2
S.M.CARBR852 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR853 ERJ6GEYJ102 0.1W 5% 1K
METALR854 ERG2FJ223 2W 5% 22K
S.M.CARBR855 ERJ6GEYJ752 0.1W 5% 7K5
S.M.CARBR857 ERJ6GEYJ752 0.1W 5% 7K5
S.M.CARBR858 ERJ6GEYJ752 0.1W 5% 7K5
S.M.CARBR859 ERJ6GEYJ753 0.1W 5% 75K
FUSIBLER860 ERQ1CJP2R2 1W 10% 2R2
CARBONR861 ERD25TJ221 0.25W 5% 220
CARBONR862 ERD25TJ272 0.25W 5% 2K7
CARBONR863 ERDS1TJ560 0.5W 5% 56
CARBONR864 ERDS1TJ680 0.5W 5% 68
S.M.CARBR865 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR867 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR868 ERJ6GEYJ223 0.1W 5% 22K
S.M.CARBR869 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR870 ERJ6GEYJ272 0.1W 5% 2K7
S.M.CARBR871 ERJ6GEYJ153 0.1W 5% 15K
METALR872 ERG1SJ183 1W 5% 18K
METALR873 ERG1SJ223 1W 5% 22K
CARBONR874 ERD25TJ104 0.25W 5% 100K
S.M.CARBR876 ERJ6GEYJ103 0.1W 5% 10K
WOUNDR877 ERW2PKR47 2W 10% R47
18

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
S.M.CARBR878 ERJ6GEYJ473 0.1W 5% 47K
S.M.CARBR913 ERJ6GEYJ473 0.1W 5% 47K
S.M.CARBR914 ERJ6GEYJ822 0.1W 5% 8K2
S.M.CARBR915 ERJ6GEYJ152 0.1W 5% 1K5
S.M.CARBR916 ERJ6GEYJ391 0.1W 5% 390
FUSIBLER919 ERQ14AJW390 0.25W 5% 39
FUSIBLER920 ERQ14AJW390 0.25W 5% 39
CARBONR921 ERD25TJ471 0.25W 5% 470
CARBONR922 ERD25TJ393 0.25W 5% 39K
CARBONR923 ERD25TJ393 0.25W 5% 39K
CARBONR924 ERDS1FJ390 0.5W 5% 39
S.M.CARBR925 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR926 ERJ6GEY0R00 0.1W 5% 0
CARBONR927 ERD25TJ471 0.25W 5% 470
CARBONR928 ERD25TJ5R6 0.25W 5% 5R6
CARBONR929 ERDS1FJ471 0.5W 5% 470
CARBONR930 ERD25TJ5R6 0.25W 5% 5R6
CARBONR931 ERDS1FJ390 0.5W 5% 39
FUSIBLER935 ERQ14AJW3R9 0.25W 5% 3R9
FUSIBLER936 ERQ1CJP331 1W 5% 330
S.M.CARBR951 ERJ6GEYJ391 0.1W 5% 390
S.M.CARBR952 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR953 ERJ6GEYJ750 0.1W 5% 75
S.M.CARBR954 ERJ6GEYJ391 0.1W 5% 390
S.M.CARBR1051 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR1062 ERJ6GEYJ271 0.1W 5% 270
S.M.CARBR1063 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR1101 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1102 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR1103 ERJ6GEYJ331 0.1W 5% 330
S.M.CARBR1104 ERJ6GEYJ331 0.1W 5% 330
S.M.CARBR1105 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1106 ERJ6GEYJ104 0.1W 5% 100K
S.M.CARBR1107 ERJ6GEYJ104 0.1W 5% 100K
S.M.CARBR1108 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR1109 ERJ6GEYJ472 0.1W 5% 4K7
S.M.CARBR1110 ERJ6GEYJ472 0.1W 5% 4K7
S.M.CARBR1111 ERJ6GEYJ473 0.1W 5% 47K
S.M.CARBR1112 ERJ6GEYJ473 0.1W 5% 47K
S.M.CARBR1113 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1114 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1115 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR1116 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1117 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1118 ERJ6GEYJ472 0.1W 5% 4K7
S.M.CARBR1119 ERJ6GEYJ472 0.1W 5% 4K7
S.M.CARBR1120 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1121 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1123 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1125 ERJ6GEYJ472 0.1W 5% 4K7
S.M.CARBR1126 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1127 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1128 ERJ6GEYJ682 0.1W 5% 6K8
S.M.CARBR1129 ERJ6GEYJ682 0.1W 5% 6K8
S.M.CARBR1130 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR1131 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR1132 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1133 ERJ6GEYJ273 0.1W 5% 27K
S.M.CARBR1136 ERJ6GEYJ823 0.1W 5% 82K
S.M.CARBR1137 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR1138 ERJ6GEYJ474 0.1W 5% 470K
S.M.CARBR1139 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR1140 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR1141 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR1145 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1146 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1147 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1148 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1149 ERJ6GEYJ223 0.1W 5% 22K
S.M.CARBR1151 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1152 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1156 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1157 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR1158 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR1159 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR1160 ERJ6GEYJ223 0.1W 5% 22K
S.M.CARBR1161 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR1163 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR1164 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR1165 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR1167 ERJ6GEYJ100 0.1W 5% 10
S.M.CARBR1168 ERJ6GEYJ473 0.1W 5% 47K
S.M.CARBR1169 ERJ6GEYJ472 0.1W 5% 4K7
S.M.CARBR1170 ERJ6GEYJ273 0.1W 5% 27K
S.M.CARBR1171 ERJ6GEYJ224 0.1W 5% 220K
S.M.CARBR1172 ERJ6GEYJ223 0.1W 5% 22K
S.M.CARBR1173 ERJ6GEYJ104 0.1W 5% 100K
S.M.CARBR1174 ERJ6GEYJ221 0.1W 5% 220
S.M.CARBR1175 ERJ6GEYJ225 0.1W 5% 2M2
S.M.CARBR1177 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR1178 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR1251 ERJ6GEYJ222 0.1W 5% 2K2
S.M.CARBR1252 ERJ6GEYJ222 0.1W 5% 2K2
S.M.CARBR1253 ERJ6GEYJ332 0.1W 5% 3K3
S.M.CARBR1254 ERJ6GEYJ512 0.1W 5% 5K1
S.M.CARBR1255 ERJ6GEYJ912 0.1W 5% 9K1
FUSIBLER1900 ERQ12HJ150 0.1W 5% 15
S.M.CARBR1901 ERJ6GEYJ273 0.1W 5% 27K
S.M.CARBR1902 ERJ6GEYJ472 0.1W 5% 4K7
S.M.CARBR1903 ERJ6GEYJ103 0.1W 5% 10K
CARBONR1904 ERDS1TJ6R8 0.5W 5% 6R8
S.M.CARBR1905 ERJ6GEYJ104 0.1W 5% 100K
S.M.CARBR1906 ERJ6GEYJ513 0.1W 5% 51K
S.M.CARBR1907 ERJ6GEYJ753 0.1W 5% 75K
S.M.CARBR1908 ERJ6GEYJ753 0.1W 5% 75K
CARBONR1909 ERDS1TJ6R8 0.5W 5% 6R8
S.M.CARBR2101 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR2102 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR2103 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR2104 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR2105 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR2106 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR2107 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR2108 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR2109 ERJ6GEYJ183 0.1W 5% 18K
S.M.CARBR2110 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR2111 ERJ6GEYJ221 0.1W 5% 220
S.M.CARBR2112 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR2113 ERJ6GEYJ562 0.1W 5% 5K6
S.M.CARBR2114 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR2115 ERJ6GEYJ222 0.1W 5% 2K2
S.M.CARBR2116 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR2117 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR2118 ERJ6GEYJ222 0.1W 5% 2K2
S.M.CARBR2119 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR2120 ERJ6GEYJ222 0.1W 5% 2K2
S.M.CARBR2305 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR2311 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR2401 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR2402 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR2403 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR2404 ERJ6GEYJ222 0.1W 5% 2K2
19

DescriptionCct Ref Parts Number DescriptionCct Ref Parts Number
S.M.CARBR2405 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR2406 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR2407 ERJ6GEYJ222 0.1W 5% 2K2
S.M.CARBR2408 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR2409 ERJ6GEYJ222 0.1W 5% 2K2
S.M.CARBR2410 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR2411 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR2412 ERJ6GEYJ222 0.1W 5% 2K2
S.M.CARBR2413 ERJ6GEYJ562 0.1W 5% 5K6
S.M.CARBR2414 ERJ6GEYJ473 0.1W 5% 47K
S.M.CARBR2415 ERJ6GEYJ682 0.1W 5% 6K8
S.M.CARBR2416 ERJ6GEYJ472 0.1W 5% 4K7
S.M.CARBR2417 ERJ6GEYJ821 0.1W 5% 820
S.M.CARBR2418 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR2419 ERJ6GEYJ470 0.1W 5% 47
S.M.CARBR2420 ERJ6GEYJ332 0.1W 5% 3K3
S.M.CARBR2421 ERJ6GEYJ472 0.1W 5% 4K7
S.M.CARBR2422 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR2423 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR2424 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR2425 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR2426 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR2427 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR2428 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR2429 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR2430 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR2431 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR2432 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR2436 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR2437 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR2438 ERJ6GEYJ104 0.1W 5% 100K
S.M.CARBR2439 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR2440 ERJ6GEYJ104 0.1W 5% 100K
S.M.CARBR2441 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR2442 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR2445 ERJ6GEYJ183 0.1W 5% 18K
S.M.CARBR2446 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR2448 ERJ6GEYJ104 0.1W 5% 100K
S.M.CARBR2449 ERJ6GEYJ104 0.1W 5% 100K
S.M.CARBR2450 ERJ6GEYJ183 0.1W 5% 18K
S.M.CARBR2451 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR2454 ERJ6GEYJ222 0.1W 5% 2K2
S.M.CARBR2455 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR2463 ERJ6GEYJ222 0.1W 5% 2K2
S.M.CARBR2464 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR2475 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR2476 ERJ6GEYJ104 0.1W 5% 100K
S.M.CARBR2477 ERJ6GEYJ273 0.1W 5% 27K
S.M.CARBR2478 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR2479 ERJ6GEYJ332 0.1W 5% 3K3
S.M.CARBR2480 ERJ6GEYJ473 0.1W 5% 47K
S.M.CARBR2481 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR2482 ERJ6GEYJ332 0.1W 5% 3K3
S.M.CARBR2483 ERJ6GEYJ473 0.1W 5% 47K
S.M.CARBR2484 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR2485 ERJ6GEYJ332 0.1W 5% 3K3
S.M.CARBR2486 ERJ6GEYJ473 0.1W 5% 47K
S.M.CARBR2487 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR2488 ERJ6GEYJ332 0.1W 5% 3K3
S.M.CARBR2489 ERJ6GEYJ473 0.1W 5% 47K
S.M.CARBR2490 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR2491 ERJ6GEYJ332 0.1W 5% 3K3
S.M.CARBR2492 ERJ6GEYJ473 0.1W 5% 47K
S.M.CARBR2493 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR2498 ERJ6GEYJ222 0.1W 5% 2K2
S.M.CARBR2499 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR2505 ERJ6GEYJ222 0.1W 5% 2K2
S.M.CARBR2506 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR2507 ERJ6GEYJ222 0.1W 5% 2K2
S.M.CARBR2508 ERJ6GEYJ471 0.1W 5% 470
S.M.CARBR2509 ERJ6GEYJ472 0.1W 5% 4K7
S.M.CARBR2510 ERJ6GEYJ104 0.1W 5% 100K
S.M.CARBR2511 ERJ6GEYJ332 0.1W 5% 3K3
S.M.CARBR2512 ERJ6GEYJ104 0.1W 5% 100K
S.M.CARBR2513 ERJ6GEYJ104 0.1W 5% 100K
S.M.CARBR2514 ERJ6GEYJ222 0.1W 5% 2K2
S.M.CARBR2515 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR2516 ERJ6GEYJ104 0.1W 5% 100K
S.M.CARBR2517 ERJ6GEYJ273 0.1W 5% 27K
S.M.CARBR2518 ERJ6GEYJ183 0.1W 5% 18K
S.M.CARBR2519 ERJ6GEY0R00 0.1W 5% 0
S.M.CARBR2520 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR2521 ERJ6GEYJ102 0.1W 5% 1K
S.M.CARBR2523 ERJ6GEYJ681 0.1W 5% 680
S.M.CARBR2524 ERJ6GEYJ681 0.1W 5% 680
S.M.CARBR2525 ERJ6GEYJ104 0.1W 5% 100K
S.M.CARBR2526 ERJ6GEYJ104 0.1W 5% 100K
S.M.CARBR2527 ERJ6GEYJ332 0.1W 5% 3K3
S.M.CARBR2528 ERJ6GEYJ332 0.1W 5% 3K3
S.M.CARBR2529 ERJ6GEYJ473 0.1W 5% 47K
S.M.CARBR2530 ERJ6GEYJ473 0.1W 5% 47K
S.M.CARBR2531 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR2532 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR2533 ERJ6GEYJ473 0.1W 5% 47K
S.M.CARBR2534 ERJ6GEYJ473 0.1W 5% 47K
S.M.CARBR2535 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR2536 ERJ6GEYJ103 0.1W 5% 10K
S.M.CARBR2537 ERJ6GEYJ472 0.1W 5% 4K7
CARBONR2702 ERDS1TJ154 0.5W 5% 150
CARBONR2703 ERDS1TJ184 0.5W 5% 180
METALR2704 ERG5FJ473 5W 5% 47K
CARBONR2705 ERD2FCVJ4R7P 2W 5% 4R7
METALR2706 ERG1FJ101P 1W 5% 100
METALR2707 ERG1FJ101P 1W 5% 100
CARBONR2708 ERD2FCVJ4R7P 2W 5% 4R7
WOUNDR2709 ERW12PKR33 0.5W 10% R33
METALR2712 ERG3FJ101 3W 5% 100
METALR2713 ERG3FJ101 3W 5% 100
CARBONR2714 ERDS1TJ2R2 0.5W 5% 2R2
CARBONR2715 ERD25TJ101 0.25W 5% 100
CARBONR2716 ERD25TJ202 0.25W 5% 2K
CARBONR2717 ERDS1TJ103 0.5W 5% 10K
S.M.CARBR2718 ERJ6GEYJ562 0.1W 5% 5K6
S.M.CARBR2719 ERJ6GEYJ104 0.1W 5% 100K
S.M.CARBR2720 ERJ6GEYJ101 0.1W 5% 100
S.M.CARBR2721 ERJ6GEYJ222 0.1W 5% 2K2
S.M.CARBR2722 ERJ6GEYJ393 0.1W 5% 39K
S.M.CARBR2724 ERJ6GEYJ1R0 0.1W 5% 1
S.M.CARBR2725 ERJ6GEYJ223 0.1W 5% 22K
S.M.CARBR2726 ERJ6GEYJ331 0.1W 5% 330
METALR2727 ERG3FJ471 3W 5% 470
METALR2728 ERG3FJ471 3W 5% 470
S.M.CARBR2729 ERJ6GEYJ822 0.1W 5% 8K2
S.M.CARBR2730 ERJ6GEYJ223 0.1W 5% 22K
S.M.CARBR2731 ERJ6GEYJ2R2 0.1W 5% 2R2
S.M.CARBR2732 ERJ6GEYJ223 0.1W 5% 22K
S.M.CARBR2733 ERJ6GEYJ331 0.1W 5% 330
S.M.CARBR2734 ERJ6GEYJ123 0.1W 5% 12K
S.M.CARBR2735 ERJ6GEYJ153 0.1W 5% 15K
S.M.CARBR2736 ERJ6GEYJ2R2 0.1W 5% 2R2
S.M.CARBR2737 ERJ6GEYJ332 0.1W 5% 3K3
S.M.CARBR2738 ERJ6GEYJ102 0.1W 5% 1K
20
