Panasonic VIERA TX-40CS520E Assembly instructions

TX-40CS520E
TX-50CS520E
TX-55CS520E
e HELP
English

- 2 -
my Home Screen
my Home Screen
•Information 10
•How to use 11
•Settings 12
•OSD Colour 14
APPS List
•Information 15
•How to use 16
•Settings 17
Watching
Basic
•Basic connection 18
•Selecting channel 21
•Information banner 22
•Option Menu 25
•Subtitle 27
•Last view 28
•Off Timer 29
•Energy saving functions 30
•Adjusting time 32
•Language 33
External equipment
•External connection 34
•Watching external input 37
•Operating with TV’s remote control 39
•HDMI features 41
•Terminal information 43
•Valid input signals 45
For best picture
•Viewing Mode 46
•Ambient Sensor 47

- 3 -
•Aspect 48
•Aspect Control Signal 50
•Basic settings 52
•Noise reduction settings 53
•Advanced Settings 54
•Option Settings 57
•Screen Settings 59
•Copy Adjustment 60
For best audio
•Sound mode 61
•Basic settings 62
•Volume settings 63
•Voice Guidance Settings 64
•Audio Description 65
•Advanced settings 66
TV Guide
•Using TV Guide 68
Teletext
•Viewing Teletext 71
•Teletext mode 73
•Teletext Character Set 74
Tuning and editing channels
•Setting menu 75
•Favourites Edit 76
•Channel List 78
•Auto Setup 80
•Manual Tuning 82
•Update Channel List 85
•New Channel Message 86
•Signal Condition 87
•Other settings 88

- 4 -
Media Player
Using Media Player
•Information 89
•Selecting device / mode 91
•Network device 93
Photo mode
•Selecting file 94
•Viewing photo 95
•Sorting photos 96
•Using Slideshow 97
Video mode
•Selecting file 101
•Watching video 102
•Video Setup 104
•Audio output settings 106
Music mode
•Selecting file 107
•Playing music 108
•Music Setup 109
Technical information
•Device handling caution 110
•USB devices 111
•Photo format 112
•Video format 113
•Music format 116
Network
Internet content
•Information 117
•Selecting internet content 118
•Note 119
DLNA
•In-House streaming 120

- 5 -
•Using DLNA 123
Network connections
•Internet connection 124
•DLNA connection 125
•Note 127
Network settings
•Network Connection 128
•Custom - Wireless 130
•Custom - Wired 133
•Custom - Wireless Access Point 135
•Network Status 136
•my Home Cloud Settings 137
•VIERA Name 138
•TV Remote App Settings 139
•Network Link Settings 140
•File Sharing Settings 141
•Mirroring Settings 142
•Software Update 143
•New Software Message 144
Photos
•Selecting file 145
•Viewing photo 146
•Using Slideshow 147
Videos
•Selecting file 149
•Watching video 150
•Video Setup 152
•Audio output settings 154
Music
•Selecting file 155
•Playing music 156
•Music Setup 157

- 6 -
DIGA Recorder
•Controlling DIGA Recorder 158
Technical information
•Photo format 159
•Video format 160
•Music format 163
Functions
Mirroring
•How to use 164
•Mirroring Settings 165
DVB-via-IP
•DVB-via-IP client connection 166
•DVB-via-IP Server Selection 168
•Note 169
VIERA Link “HDAVI Control™”
•Summary of VIERA Link 170
•Preparations 175
•Easy playback 176
•Power on Link 177
•Power off Link 178
•Standby Power Save 179
•Intelligent Auto Standby 180
•VIERA Link Control 181
•Speaker Selection 183
•Note 184
Child Lock
•Using Child Lock 185
•PIN number 186
•Parental Rating 187
Data Service Application
•Using Data Service Application 188
•Cookie 189

- 7 -
•Note 190
Common Interface
•Caution 191
•Using Common Interface 192
Shipping Condition
•Shipping Condition 193
Updating the TV Software
•Information 194
•Auto update 195
•Manual update 196
Setting characters
•Using Numeric buttons 197
Keyboard
•Keyboard 198
Settings
Setting menu
•How to use 199
•Viewing Mode 201
•Basic settings 202
•Ambient Sensor 203
•Noise reduction settings 204
•Advanced Settings 205
•Option Settings 206
•Screen Settings 208
•Copy Adjustment 209
•Reset to Defaults 210
Sound
•Mode 211
•Basic settings 212
•Volume settings 213

- 8 -
•Voice Guidance Settings 214
•Audio Description 215
•Advanced settings 216
•Reset to Defaults 217
Network
•Network Connection 218
•Network Status 219
•my Home Cloud Settings 220
•VIERA Name 221
•TV Remote App Settings 222
•Network Link Settings 223
•File Sharing Settings 224
•Mirroring Settings 225
•Other settings 226
Timer
•Off Timer 227
•Time Zone 228
•Auto Standby 229
•No signal Power off 230
Setup
•Eco Navigation 231
•USB Device Setup 232
•Child Lock 233
•Tuning Menu 234
•Language 236
•Display Settings 237
•Common Interface 239
•VIERA Link Settings 240
•Data Service Application 241
•System Menu 242
•Other Settings 243

- 9 -
Support
Help menu
•Using Help menu 244
FAQs
•Picture 245
•Digital TV 247
•Analogue TV 248
•Sound 249
•HDMI 250
•Network 251
•Other 253
Maintenance
•Care and Cleaning 254
Optional accessories
•Wall-hanging bracket 255
Licence
•Licence 256
OK Letters enclosed in brackets indicate remote control buttons.
Menu Letters in cyan indicate on-screen display items.
References in this eHELP
●The images shown in this eHELP are for illustrative purposes only.

my Home Screen
my Home Screen
Information
“my Home Screen” is a gateway to the TV, applications, and more.
It provides easy access to special features such as Media Player, videos,
games, communication tools, etc. as shown below (example).
HOME
OK
OK HOME
Home Screen
Selected content screen (TV, application, etc.)
Home Screen Selection
– Your preferred Home Screen can be selected.
- 10 -

How to use
Home Screen provides access to special features such as Media Player, TV,
internet content, data services, communication tools, etc.
1. Display Home Screen with HOME.
(Example)
●The last viewed Home Screen is displayed when the TV is turned on.
●Press again to select or add your preferred Home Screen layout.
my Home Screen > my Home Screen > Settings
2. Select a feature and press OK to access.
●To watch full-screen TV
1) Select the TV viewer.
(Example)
2) Press OK to watch.
(Example)
●Also refer to Tutorial from the tool guide.
- 11 -

Settings
Select the setup menu from the tool guide on the top of the screen.
(Example)
●Display the tool guide with HOME if it is not displayed.
■Home Screen Selection
1. Display Home Screen Selection with HOME.
(Example)
2. Select the screen and press OK to set.
Full Screen TV:
Displays full-screen TV.
TV Home Screen:
To make your TV experience more convenient and comfortable
Lifestyle Screen:
Displays the TV with useful information and services for everyday life.
Info Screen:
Enjoy internet content while watching TV.
■Settings
You can customise any Home Screen. (For example, changing the wallpaper,
renaming freely, editing applications, setting the screen launched when the
TV is turned on, etc.)
1. Select Settings from the tool guide.
2. Follow the on-screen instructions.
- 12 -

■Search
You can search the content from various features.
1. Select Search from the tool guide.
2. Follow the on-screen instructions.
= Note =
●To change the colour type of on-screen displays, set OSD Colour.
my Home Screen > my Home Screen > OSD Colour
●A broadband network environment is required to be able to use this
function fully. Ensure the network connections and network settings are
completed.
Network > Network connections
Network > Network settings
●Be sure to update the software when a software update notice is displayed
on the TV screen. If the software is not updated, you may not be able to
use my Home Screen. You can update the software later manually.
Network > Network settings > Software Update
- 13 -

OSD Colour
1. Display the menu with MENU.
2. Select Setup > Display Settings > OSD Colour and press OK to access.
3. Set the item and press OK to store.
OSD Colour
(Jet black / Pale grey / Organic brown / Sand beige)
Selects the preferred colour type of on-screen displays.
●This function is available for the information banner, menu screen, Home
Screen, etc.
- 14 -

APPS List
Information
Various applications (internet content, network content, Media Player, etc.)
can be accessed easily from APPS List.
■APPS List
(Example)
= Note =
●APPS List is subject to change without notice.
- 15 -

How to use
You can access special features such as internet content, network content,
Media Player, etc. from APPS List.
1. Display APPS List with APPS.
(Example)
●To exit APPS List
EXIT
2. Select an icon of the features and press OK to access.
Internet content
Network > Internet content
Netflix
●You can also access the service pressing NETFLIX.
●A broadband network environment is required to be able to use this
function fully.
●This service may be stopped or changed without notice.
Media Player
Media Player > Using Media Player > Selecting device / mode
Media Server
Network > DLNA > Using DLNA
VIERA Link
Functions > VIERA Link “HDAVI Control™”
- 16 -

Settings
You can customise APPS List (screen settings, etc.).
1. Display APPS List with APPS.
2. Select the icon for settings on APPS List and press OK to access.
3. Follow the on-screen instructions.
= Note =
●Setup menu items may be changed without notice.
- 17 -

Watching
Basic
Basic connection
Please ensure that the unit is disconnected from the mains socket before
attaching or disconnecting any cables.
●External equipment and cables shown are not supplied with this TV.
■Aerial
Terrestrial / cable terminal
RF cable
Terrestrial aerial / Cable
●For DVB-C, DVB-T, Analogue
- 18 -

■DVD Recorder / VCR
Terrestrial / cable terminal
RF cable
DVD Recorder / VCR
Terrestrial aerial / Cable
AV1 (SCART) terminal
SCART cable
- 19 -

■DVD Recorder (VCR) / Set top box
HDMI terminal
HDMI cable
Set top box
Satellite dish
AV1 (SCART) terminal
SCART cable
Terrestrial / cable terminal
RF cable
DVD Recorder / VCR
Terrestrial aerial / Cable
= Note =
●For details of DVB-via-IP connections
Functions > DVB-via-IP
●For details of VIERA Link connections
Functions > VIERA Link “HDAVI Control™” > Summary of VIERA Link
●Please also read the manual of the equipment being connected.
●Keep the TV away from electronic equipment (video equipment, etc.) or
equipment with an infrared sensor, otherwise distortion of image / sound
may occur or operation of other equipment may be affected.
●Use a fully wired HDMI compliant cable.
●Use a fully wired SCART cable.
●Check the terminal type and cable plugs are correct for connection.
- 20 -
