P&C SPPS60TM-1 User manual

EN
Instructions for Use
FR
Manuel d'instructions
SPPS60TM-1

2 | EN
Contents
Grounding Instructions......................................................................................................................3
Important safety instructions ............................................................................................................4
Precautions to avoid possible exposure to excessive Microwave energy....................................6
Precautions to be observed before and during servicing to avoid possible exposure to excessive
Microwave energy...............................................................................................................................7
The advantages of microwaves.......................................................................................................10
Description of microwave oven.......................................................................................................11
Basic settings ...................................................................................................................................13
Basic Functions................................................................................................................................15
When the oven is working................................................................................................................20
Using the Browning Plate ................................................................................................................21
Defrosting..........................................................................................................................................22
Cooking with a microwave oven .....................................................................................................24
Cooking with the grill .......................................................................................................................26
What kind of ovenware can be used?.............................................................................................29
Oven Cleaning and Maintenance.....................................................................................................31
What should I do if the oven doesn’t work?...................................................................................33
Technical characteristics.................................................................................................................34
Installation instructions ...................................................................................................................35
Installation.........................................................................................................................................73

3 | EN
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of an electrical short circuit,
grounding reduces the risk of electric shock by providing an escape wire for
the electric current.
Warning! IMPROPER USE OF THE GROUNDING CAN RESULT IN A RISK OF
ELECTRICAL SHOCK.
Consult a qualified electrician or serviceman if the grounding instructions are
not completely understood, or if doubt exists as to whether the appliance is
properly grounded, and do not use an extension cord. If the power supply
cord is too short, have a qualified electrician or serviceman install an outlet
near the appliance.

4 | EN
IMPORTANT SAFETY
INSTRUCTIONS
When using electrical appliances basic safety precautions should be followed,
including the following:
Warning! To reduce the risk of burns, electric shock, fire, injury to persons,
or exposure to excessive microwave energy:
•Read all instructions before using the appliance.
•Read and follow the specific “PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE MICROWAVE ENERGY” found in this manual.
•This appliance must be grounded. Connect only to properly grounded outlet.
See “GROUNDING INSTRUCTIONS” found in this manual.
•Install or locate this appliance only in accordance with the provided installation
instructions.
•Some products such as whole eggs and sealed containers –for example,
closed glass jars are able to explode and should not be heated in this oven.
•Use this appliance only for its intended use as described in the manual. Do not
use corrosive chemicals or vapors in this appliance. This type of oven is
specifically designed to heat, cook, or dry food. It is not designed for industrial
or laboratory use.
•As with any appliance, close supervision is necessary when used by children.
•Do not operate this appliance if it is has a damaged cord or plug, if it is not
working properly, or if it has been damaged or dropped.
•This appliance should be serviced only by qualified service personnel. Contact
nearest authorized service facility for examination, repair, or adjustment.
•Do not cover or block any openings on the appliances.
•Do not store this appliance outdoors. Do not use this product near water –for
example, near a kitchen sink, in a wet basement, near a swimming pool, or
similar locations.
•Do not immerse cord or plug in water.
•Keep cord away from heated surfaces.
•Do not let cord hang over edge of table or counter.
•When cleaning surfaces of door and oven that comes in contact when closing
the door, use only mild, nonabrasive soaps, or detergents applied with a
sponge or soft cloth.

5 | EN
IMPORTANT SAFETY
INSTRUCTIONS
To reduce the risk of fire in the oven cavity:
•Do not overcook food. Carefully attend appliance when paper, plastic, or other
combustible materials are placed inside the oven to facilitate cooking.
•Remove wire twist-ties from paper or plastic bags before placing bag in oven.
•If materials inside the oven ignite, keep oven door closed, turn oven off, and
disconnect the fuse or circuit breaker panel.
•Do not use the cavity for storage purposes. Do not leave paper products,
cooking utensils, or food in the cavity when not in use.
•Liquids such as water, coffee, or tea are able to be overheated beyond the
boiling point without appearing to be boiling. Visible bubbling or boiling when
the container is removed from the microwave oven is not always present.
THIS COULD RESULT IN VERY HOT LIQUIDS SUDDENLY BOILING OVER
WHEN THE CONTAINER IS DISTURBED OR A UTENSIL IS PLACED INTO
THE LIQUID.
To avoid that type of situation when heating liquids, put a teaspoon or glass
rod inside the container.

6 | EN
PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE
ENERGY
(a) Do not attempt to operate this oven with the door open since open-door
operation can result in harmful exposure to microwave energy. It is important
not to interfere or tamper with the safety interlocks.
(b) Do not place any object between the oven front face and the door or allow
soil or cleaner residue to accumulate on sealing surfaces.
(c) Do not operate the oven if it is damaged. It is particularly important that the
oven door closes properly and that there is no damage to the: (1) door (bent),
(2) hinges and latches (broken or loosened), (3) door seals and sealing
surfaces.
(d) The oven should not be adjusted or repaired by anyone except properly
qualified service personnel.
Pacemakers:
Most pacemakers are shielded from interference from electronic products, including
microwaves. However, patients with pacemakers may wish to consult their
physicians if they have concerns.

7 | EN
PRECAUTIONS TO BE
OBSERVED BEFORE AND
DURING SERVICING TO AVOID
POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE
ENERGY
(a) Do not operate or allow the oven to be operated with the door open.
(b) Make the following safety checks on all ovens to be serviced before
activating the magnetron or other microwave source, and make repairs as
necessary: interlock operation, proper door closing, seal and sealing
surfaces (arcing, wear, and other damage), damage to or loosening of hinges
and latches, evidence of dropping or abuse.
(c) Before turning on microwave power for any service test or inspection within
the microwave generating compartment, check the magnetron, wave guide
or transmission line, and cavity for proper alignment, integrity and
connection.
(d) Any defective or misadjusted components in the interlock, monitor, door seal,
and microwave generation and transmission systems, shall be repaired,
replaced, or adjusted by procedures described in this manual before the
oven is released to the owner.
(e) A microwave leakage check, to verify compliance with the Federal
Performance Standard, should be performed on each oven prior to release to
the owner.

8 | EN
Microwave safety
•Warning! Never leave the oven unwatched,
especially when using paper, plastic or other
combustible materials. These materials can
char and may cause fire. FIRE RISK!
•Warning! Do not heat pure alcohol or
alcoholic drinks in the microwave. FIRE
RISK!
•Warning! Do not heat liquids or other foods
in closed containers since these may
explode readily.
•Warning! This appliance is not intended for
use by persons (including children) with
reduced physical, sensory or mental
capabilities, or lack of experience and
knowledge, unless they have been given
supervision or instruction concerning use of
the appliance by a person responsible for
their safety. Children should be supervised
to ensure that they do not play with the
appliance.
•Warning! If the oven has a combined
function mode (microwave with other means
of heating), children should not be allowed to
use the oven without adult supervision on
account of the high temperatures generated.
•Warning! The oven cannot be used if:
- The door is not closed correctly;
- The door hinges are damaged;
- The surfaces of the contact between the
door and the oven front are damaged;
- The door window glass is damaged;
- There is frequent electrical arcing inside
the oven even though there is no metal
object inside.
The oven can only be used again after it
has been repaired by a Technical
Assistance Service technician.
Beware!
•Never heat baby foods or drinks in bottles or
jars with the teats or lids on them. After
heating the food mix or shake well so that
the heat is spread evenly. Check the food
temperature before feeding this to the child.
DANGER OF BURNING!
•To avoid food overheating or burning it is
very important not to select long time
periods or power levels that are too high
when heating small quantities of food. For
example, a bread roll can burn after 3
minutes if the power selected is too high.
•For toasting, use just the grilling function and
watch the oven all the time. If you use a
combined function to toast bread it will catch
fire in a very short time.
•Make sure you never catch the power cables
of other electrical appliances in the hot door
or the oven. The cable insulation may melt.
Danger of short-circuiting!

9 | EN
Microwave safety
This oven is exclusively for domestic use!
Use the oven only for preparing meals.
Avoid damaging the oven or other
dangerous situations by following these
instructions:
•Do not switch on the oven without the
turntable support, the turntable ring and
the respective plate being in place.
•Never switch on the microwave when it
is empty. If there is no food inside there
may be an electrical overcharge and the
oven could be damaged. RISK OF
DAMAGE!
•For carrying out oven programming
tests put a glass of water inside the oven.
The water will absorb the microwaves and
the oven will not be damaged.
•Use only dishes suitable for
microwaves. Before using dishes and
containers in the microwave, check that
these are suitable (see the section on
types of dishes).
•Never remove the mica cover on the
ceiling of the oven interior! This cover
stops fat and pieces of food damaging the
microwave generator.
•Do not keep any inflammable object
inside the oven as it may burn if the oven
is switched on.
•Do not use the oven as a pantry.
•Eggs with their shells and whole boiled
eggs must not be heated in microwave
ovens because they may explode.
•Do not use the oven for frying as it is
impossible to control the temperature of oil
heated by microwaves.
•To avoid being burnt, always use oven
gloves for handling dishes and containers
and touching the oven.
•Do not lean or sit on the open oven
door. This may damage the oven,
especially in the hinge zone. The door can
bear a maximum weight of 8 kg.
•The turntable and the grills can bear a
maximum load of 8 kg. To avoid damaging
the oven, do not exceed this load.
Cleaning:
•Warning! Your microwave oven must be
cleaned regularly. All food remains must
be removed (see section on Oven
Cleaning). If the microwave oven is not
kept clean its surface may deteriorate and
this may shorten the oven’s working life
and could even result in a dangerous
situation.
•The door contact surfaces (the front of the
cavity and the inside part of the doors)
must be kept very clean in order to ensure
the oven functions correctly.
•Do not use harsh abrasive cleaners or
sharp metal scrapers to clean the oven
door glass since they can scratch the
surface, which may result in shattering
of the glass.
•Do not use high pressure or stream jet
cleaning appliances.
•Please follow the instructions regarding
cleaning in the section “Oven Cleaning and
Maintenance”.
Repairs:
•Warning –Microwaves! The outer
protection of the oven must not be
removed. It is dangerous for anyone not
authorized by the manufacturer to carry
out any kind of repair or maintenance
work.
•If the power cable is damaged it should be
substituted by the manufacturer,
authorized agents or technicians qualified
for this task in order to avoid dangerous
situations. Furthermore, special tools are
required for this task.
•Repair and maintenance work, especially
of current carrying parts, can only be
carried out by technicians authorized by
the manufacturer.

10 | EN
The advantages of microwaves
In conventional ovens, heat radiated by electrical
elements or gas burners slowly penetrates the
food from outside to inside. On account of this a
major amount of energy is wasted heating the air,
the oven components and the food containers.
In a microwave oven, heat is generated by the
food itself and the heat travels from inside to
outside. No heat is lost to the air, the walls of the
oven cavity or the dishes and containers (if these
are suitable for use in microwave oven), in other
words, only the food is heated.
Microwave ovens have the following advantages:
1. Shorter cooking times; in general these are
up to 3/4 less than the time required for
conventional cooking.
2. Ultra-fast food defrosting, thus reducing the
danger of bacterial development.
3. Energy savings.
4. Conservation of the nutritional value of foods
due to the shorter cooking times.
5. Easy to clean.
How a microwave oven works
In a microwave oven there is a high tension valve
called a magnetron which converts electrical
energy into microwave energy. These
electromagnetic waves are channelled to the
interior of the oven through a wave guide and
distributed by a metallic spreader or through a
turntable.
Inside the oven the microwaves propagate in all
directions and are reflected by the metal walls,
uniformly penetrating the food.
Why food heats up
Most foods contain water and water molecules
vibrate when subjected to microwaves.
The friction between molecules produces heat
which raises the temperature of the food,
defrosting it, cooking it or keeping it hot.
Since the heat arises inside the food:
•This can be cooked with little or no liquid
or fats/oils;
•Defrosting, heating or cooking in a
microwave oven is quicker than in a
conventional oven;
•The vitamins, minerals and nutritional
substances in the food are conserved;
•The natural colour and aroma of the food
are unchanged.
Microwaves pass through china, glass, cardboard
or plastic but do not go through metal. For this
reason, metal containers or ones with metal parts
must not be used in a microwave oven.
Microwaves are reflected by metal...
... but go through glass and china...
and are absorbed by foods.

11 | EN
Description of microwave oven
1. –Door window glass
8. –Lamp
2. –Catches
9. –Control Panel
3. –Turntable support
10. –Baking Tray
4. –Turntable ring
11. –Grill Rack
5. –Turntable plate
12. –Browning plate
6. –Grill
13. –Lateral supports
7. –Mica cover
1.
Function selector
5.
”+” key
2.
Display
6.
“OK” key
3.
Thermostat knob
7.
Start key
4.
”-” key
8.
Stop key

12 | EN
Description of microwave oven
Description of Functions
Symbol
Function
Microwave
Power Output
Foods
Microwave
200 W
Slow defrosting for delicate foods; keeping food hot.
400 W
Cooking with little heat; boiling rice.
Rapid defrosting, heating baby food.
600 W
Heating and cooking food.
800 W
Cooking vegetables and food.
Cooking and heating carefully.
Heating and cooking small portions of food.
1000 W
Rapidly heating liquids.
Broiler
Broiling food.
Microwave
+ Broiler
200 W
Toasting food.
400 W
Broiling poultry and meat.
600 W
Cooking pies and cheese-topped dishes.
Hot-Air
---
Roasting and baking.
Microwaves +
Hot-Air
200-600 W
Quick meat, fish and poultry roasting.
Baking cakes.
Grill + Fan
---
Broiling meat and fish.
Broiling poultry.
Potatoes –deep-frozen, defrosting and roasting.

13 | EN
Basic settings
Setting the clock
After your microwave oven is first plugged-in or after a power failure, the clock display will flash to
indicate that the time shown is not correct. Before using the microwave oven, adjust the clock through
the procedure described below but starting on Step 3. To set the clock, proceed as follows:
1. Press the “+” key until the Clock Indicator
Light starts to flash.
2. Press the OK key.
3. Press “-” and “+” keys to set the correct hour
value.
4. Press the OK key to validate the hour value.
The minute numbers will start to flash.
5. Press “-” and “+” keys to set the correct
minute value.
6. To finish, press the OK key again.
Hiding / Displaying the Clock
If the clock display disturbs you, you can hide it by proceeding as follows:
1. To hide the clock press the “+” key and the “-
“ key simultaneously for 5 seconds. The
dots that separate the hours and minutes
and the clock symbol will flash, but the rest
of the clock display will be hidden.
2. If you want to see the clock display again,
press the “+” and “-“keys again for 5
seconds.

14 | EN
Basic settings
Child lock
The oven can be blocked against improper use (e.g., to prevent children from using it).
1. To block, the oven press the Stop key for 3
seconds. The display shows the child lock
indicator light. If a key is pressed now, the
the oven will not operate.
2. To unlock, press again the Stop key for 3
seconds.
Showroom mode
In the Showroom mode the oven works like described in every function, but there will be no heating.
1. To enter the Showroom mode press
simultaneously the “-“ key and the Stop key
for 5 seconds. The display shows the
messages “”and “”intermittently
(showing the actual status).
2. Press the “-” and “+” keys to alternate status
(“”or “”).
3. Press the OK key to validate.
Note: To exit the Showroom mode proceed in
the same manner.

15 | EN
Basic Functions
Microwave
Use this function to cook and heat up vegetables, potatoes, rice, fish and meat.
1. Turn the Function Selector to the position
corresponding to the Microwave function.
2. “ ” (manual) lights on the display.
3. Press the OK key to validate the Microwave
function.
4. Using the “-” and “+” keys set the desired
operating time.
5. Press the OK key to validate.
6. Using the “-” and “+” to set the required
microwave power level.
7. Press the OK key to validate.
8. Press the Start Key. The oven will start to
operate.
Note: The cooling fan keeps on working for
some time. When the temperature has dropped
sufficiently, the fan will switch itself off.
Quick Start
Use this function to rapidly heat foods with high water content such as coffee, tea or soup.
1. Press the Start key. The oven will start to
operate at maximum power for 30 seconds.
2. If you intend to extend the operating time,
press the Start key again. Each time this key
is pressed, the operating time will increase
by 30 seconds.
Note: If the power of 1000 W is selected, the
operating time is limited to a maximum of 15
minutes.
Broiler
Use this function to brown the surface of food quickly.
1. Turn the Function Selector to the position
corresponding to the Broiler function.
2. The Operating Time Indicator Light and
the Display start to flash.
3. With the “-” and “+” keys set the desired
operating time.
4. Press the Start key. The oven will start to
operate.
Note 1: The cooling fan keeps on working for
some time. When the temperature has dropped
sufficiently, the fan will switch itself off.
Note 2: This function has the Delayed Start
option (
4
3
1
(2)
). For more information see
“Delayed Start Time” function.

16 | EN
Basic Functions
Microwave + Broiler
Use this function to cook lasagne, poultry, baked potatoes and casseroles.
1. Turn the Function selector to the
Microwave + Broiler function.
2. The Operating Time Indicator Light will
flash. The operating time will flash in the
display.
3. With the “-” and “+” keys set the desired
operating time.
4. Press the OK key to validate.
5. Using the “-” and “+” to set the required
microwave power level.
6. Press the OK key to validate.
7. Press the Start Key. The oven will start to
operate.
Note: The cooling fan keeps on working for
some time. When the temperature has dropped
sufficiently, the fan will switch itself off.
Convection
Use this function to bake food.
1. Turn the Function Selector to the
Convection position.
2. The Operating Time Indicator Light and
the Display start to flash.
3. With the “-” and “+” keys set the desired
operating time.
4. Press the OK key to validate.
5. Select the desired oven temperature using
the Thermostat selector.
6. Press the Start key. The oven will start to
operate.
Note 1: The cooling fan keeps on working for
some time. When the temperature has dropped
sufficiently, the fan will switch itself off.
Note 2: This function has the Delayed Start
option (
4
3
1
(2)
). For more information see
“Delayed Start Time” function.

17 | EN
Basic Functions
Microwave + Convection
Use this function to rapidly bake food.
1. Turn the Function selector to the
Microwave + Convection function.
2. The Operating Time Indicator Light will
flash and the Power Level Indicator Light
will be on. The operating time will flash in the
display.
3. With the “-” and “+” keys set the desired
operating time.
4. Press the OK key to validate.
5. The Power Level Indicator Light will flash.
6. With the “-” and “+” keys set the desired
microwave power level.
7. Press the OK key to validate.
8. Select the desired oven temperature using
the Thermostat control.
9. Press the Start key. The oven will start to
operate.
Note: The cooling fan keeps on working for
some time. When the temperature has dropped
sufficiently, the fan will switch itself off.
Broiler + Fan
Use this function to bake food evenly and at the same time brown the surface.
1. Turn the Function selector to the Broiler +
Fan function.
2. The Operating Time Indicator Light and
the Display start to flash.
3. With the “-” and “+” keys set the desired
operating time.
4. Press the OK key to validate.
5. Press the Start key. The oven will start to
operate
Note 1: The cooling fan keeps on working for
some time. When the temperature has dropped
sufficiently, the fan will switch itself off.
Note 2: This function has the Delayed Start
option (
4
3
1
(2)
). For more information see
“Delayed Start Time” function.

18 | EN
Basic Functions
Auto Defrost
Use this function to automatically defrost, meat, poultry, fish, vegetables and bread.
1. Turn the Function selector to position
corresponding to the Microwave function.
2. “” lights on the display.
3. Press the “-” or “+” key to select the “”
Defrost function (which lights on the
display).
4. Press the OK key to validate. The display
will show the type of food “F 01”.
5. Using the “-” and “+” keys, scroll through “F
01” – “F 05” until the desired food type is
selected.
6. Press the OK key to validate. The “g”
symbol will flash.
7. By using the “-” and “+” keys enter the frozen
weight of the food in ounces.
8. Press the OK key to validate.
9. Press the Start key. The oven will start to
operate.
10. Turn the food whenever the oven lets out a
beep and the display flashes the word
(“turn”). Press the Start key to
resume.
The following table shows the defrosting by weight function programmes, indicating weight intervals, and
defrosting and standing times (in order to ensure the food is of a uniform temperature).
Programme
Food
Weight (kg)
Time (min)
Standing time (min)
F 01
Meat
0.1 –2.00
2 –43
20 –30
F 02
Poultry
0.1 –2.50
2 –58
20 –30
F 03
Fish
0.1 –2.00
2 –40
20 –30
F 04
Fruit
0.1 –0.50
2 –13
10 –20
F 05
Bread
0.1 –0.80
2 –19
10 –20
Important Note: please refer to the chapter “General instructions for defrosting”.

19 | EN
Special Functions
Delayed Start Time
Use this function to program the start of the cooking to a different time.
1. Rotate the Function Selector knob to the
desired function position (This function works
with: Broiler, Convection, Broiler +
Convection).
2. Set the parameters (e.g.: operating time,
power level, temperature) as described in
the “Basic Functions”.
3. Press the “OK”key (instead of Start) to enter
the Delayed Start Time. (The Delayed Start
indicator flashes in the display.)
4. Press the keys “-“ and “+”to adjust the
delayed start time. (0:00 appears by default
on the display and you can delay the start of
the programme up to 9 hours and 59 minutes
- 9:59 ).
5. Press the Start key to validate the delayed
start time.
6. The cooking duration and delayed start (+
respective indicators) will be displayed
alternating.
7. The delayed start will start counting down.
8. The oven will start to operate when the
delayed start reaches 00:00.

20 | EN
When the oven is working...
Interrupting a cooking cycle
You can stop the cooking process at any time by
pressing the Stopkey once or by opening the
oven door.
In both cases:
•Microwave emission is stopped
immediately.
•The grill is de-activated but is still very
hot. Danger of burning!
•The timer stops automatically, indicating
the operating time that is left.
If you wish, at this time you can:
1. Turn or stir the food to ensure it will be
evenly cooked.
2. Change the process parameters.
To restart the process, close the door and press
the Start key
Altering parameters
The operating parameters
▪Time (with the “-” and “+”keys)
▪Function (with the function selector)
▪Power (with the microwave power level
selector)
can be altered when the oven is operating or
when the cooking process has been interrupted
by simply turning the respective knob to the new
value.
Cancelling a cooking cycle
If you wish to cancel the cooking process, press
the Stop key twice.
End of a cooking cycle
At the end of the process you will hear one beep
and the display will show the word “End”.
