Hoover Soft Wave User manual

Instruction Book
®
40003196.qxd 04/05/2005 16:59 Page 1

Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Delivery information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Do’s and Don’ts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Unpacking the Product. . . . . . . . . . . . . . . . . . . . . . . . 4
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Choose a location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Electricity supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Water supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Connecting to the cold water supply . . . . . . . . . . . . . . . . . . . . 8
Connection of the machine to the drain . . . . . . . . . . . . . . . . . 9
Moving the machine into position . . . . . . . . . . . . . . . . . . . . . 10
Adjusting the feet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Testing the installation . . . . . . . . . . . . . . . . . . . . . . 11
Washing and Drying advice . . . . . . . . . . . . . . . . . 12
Loading your washing machine . . . . . . . . . . . . . . . . . . . . . . . 12
Sorting the laundry. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Drying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
The Dispenser . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Detergent dosage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Dispensing instructions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
The Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Wash and Dry Options. . . . . . . . . . . . . . . . . . . . . . . 18
Automatic Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Programme Selector . . . . . . . . . . . . . . . . . . . . . . . . . 21
Special Programmes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Daily Programmes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Programme Guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
A Typical Wash and Dry Cycle. . . . . . . . . . . . . . . 24
Selecting the programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Starting the cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Cleaning and Routine Maintenance . . . . . . . . 26
Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Power Failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Customer Service. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Your Guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Hoovercare . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
2
Contents
40003196.qxd 04/05/2005 16:59 Page 2

Introduction
Please read and follow these instructions carefully and operate
the machine accordingly. This booklet provides important
guidelines for safe use, installation, maintenance and some
useful advice for best results when using your machine.
Keep all documentation in a safe place for future reference or
for any future owners.
Delivery information
Please check that the following items are delivered with the
appliance:
●Instruction manual
●Guarantee card
●Blanking plug
●Inlet hose & hooked end support (see Unpacking and
Installation Instructions)
●Base panel & x2 push clips
●Energy Label
Do’s
●All packaging materials used are environmentally-friendly
and recyclable. Please help dispose of the packaging via
environmentally-friendly means. Your local council will be
able to give you details of current means of disposal.
●To ensure safety when disposing of an old washing
machine disconnect the mains plug from the socket, cut
the mains power cable and destroy this together with the
plug. To prevent children shutting themselves in the
machine break the door hinges or the door lock.
●This machine is solely for domestic use, i.e. to wash, rinse
and spin dry household textiles and garments.
Don’ts
●Do not touch the appliance when hands or feet are damp
or wet.
●Do not lean on the door when loading the machine or
use the door to lift or move the machine.
●Do not use adapters, multiple connectors and or
extensions.
●Do not allow children to play with the machine or its
controls.
●Do not try to open the door when water is visible in the
drum or the door locked indicator is ON.
3
Check that no damage
has occurred to the
machine during transit.
If it has, call for service
by GIAS.
Call
08705 400 600
PLEASE NOTE
This machine only
requires a cold water
supply
If the appliance is not
running properly or
breaks down, switch it
off, disconnect the plug
from the socket, turn
off the water supply
and do not tamper with
the appliance.
Consult GIAS Service
for assistance.
Call
08705 400 600
Failure to comply with
the above can
compromise the safety
of the appliance. You
may be charged for a
service call if a problem
with your machine is
caused by misuse.
40003196.qxd 04/05/2005 16:59 Page 3

Remove the machine from its packaging close to the final
location of the machine.
1. Cut carefully around the base of the packaging.
2. Lay the machine on its back and remove the base and the
two polystyrene spacers on each side of the machine. We
recommend that a second person assist in the lifting and
manoeuvring of the machine.
3. Return the machine to the upright position, remove the
remainder of the packaging and the central screw in the
transit bar.
4
Unpacking the product
Dispose of the packaging safely. Make sure
it is out of the reach of children, it is a
potential source of danger.
40003196.qxd 04/05/2005 17:00 Page 4

4. Remove the four retaining screws in the transit bar and
pull out the transit bracket.
5. Take the base panel provided and fit the two self
adhesive strips by removing the backing paper on one
side and locating the strips on each side of the base
panel.
6. Tilt the machine forward and locate the base panel under
the front of the machine. Remove the remaining backing
paper from the self-adhesive strips and offer up the base
panel to the bottom of the cabinet.
5
We recommend you keep the transit bracket
and screws to protect the machine for future
transit.
The manufacturers will not be responsible
for any damage to the machine caused by
not following the instructions relating to
releasing the transit protection. The user is
responsible for all installation costs.
40003196.qxd 04/05/2005 17:00 Page 5

7. Take the two plastic fixing clips and fix the base panel to
the base of the machine. Bring the machine back to the
upright position.
8. Cover the central hole in the rear of the machine with the
cap enclosed in the instruction bag.
European Directive 2002/96/EC
This appliance is marked according to the European directive
2002/96/EC on Waste Electrical and Electronic Equipment
(WEEE).
By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment
and human health, which could otherwise be caused by
inappropriate waste handling of this product.
The symbol on the product indicates that this product may not
be treated as household waste. Instead it shall be handed
over to the applicable collection point for the recycling of
electrical and electronic equipment.
Disposal must be carried out in accordance with local
environmental regulations for waste disposal.
For more detailed information about treatment, recovery and
recycling of this product, please contact your local city office,
your household waste disposal service or the shop where you
purchased the product.
Choose a location
●After the machine has been installed, ensure that the
mains plug and water supply valves are easily accessible.
●Make sure there is enough space for the machine. Select a
space at least 600mm wide and 850mm high. Also leave
enough space to open the door fully so you can load and
unload it easily.
●Keep the area underneath and around the machine free
of combustible materials such as lint, paper, rags,
chemicals etc.
6
Installation
Do not plug the
machine in and switch
it on at the mains until
the installation is
completed.
40003196.qxd 04/05/2005 17:00 Page 6

Electricity supply
Washing machines are supplied to operate at a voltage of
230-240V, 50 Hz single phase. Check that the supply circuit is
rated to at least 13A.
The plug is already equipped with a 13A fuse which is BS 1362
ASTA approved. Any replacement must be the same rating and
specification. If the fuse cover is lost, do not use the plug until
it is replaced.
Electricity can be extremely dangerous.
This washing machine must be earthed.
The socket outlet and the plug on the appliance must be of
the same type.
Do not use multiple adapters and/or extension leads.
The wires in the mains lead are coloured in accordance with
the following codes:
Blue NEUTRAL
Brown LIVE
Green and Yellow EARTH
CE Appliance complies with European Directive 89/336/EEC,
73/23/EEC and subsequent amendments.
Water supply
●The cold water pressure should be between 0.5 and 8 bar
(0.05-0.8 Mpa).
●Do not connect the machine to a single outlet
instantaneous water heater.
●The water supply tap should be accessible when the
machine is installed.
●Before connecting the fill hose, check that the water is
running from the water supply tap to be used.
7
You may be charged for
a service call if a
problem with your
machine is caused by
incorrect installation.
If the mains cord on
this appliance is
damaged, it must be
replaced by a special
cord which is ONLY
obtainable from the
Hoover spares service.
It must be installed by a
competent person.
Call GIAS
01204 556111
40003196.qxd 04/05/2005 17:00 Page 7

Connecting to the cold water
supply
Only one hose is required to install this machine to a cold
water supply.
Cold fill is an energy efficient system. Only the water required
to wash the laundry is heated. There is no loss of heat in the
pipeline from the hot water tank or the boiler.
If your previous machine installation was hot and cold fill
ensure that the hot tap is firmly closed to prevent leakage.
This machine has an inlet hose with a 19mm (3/4") threaded
ferrule fitted to the end, to attach between the threaded
connector on the appliance and the water supply.
Only use the new hose supplied to connect the machine and
ensure that the sealing washers are in place inside the hose
connectors.
Do not re-use old hoses which are attached to existing
installations.
Do not over-tighten the connections. Hand tight is sufficient.
Do not trap or kink the hose.
1. Connect the elbow end of the hose provided to the
threaded inlet on the back of the machine.
Grey pipe to the white threaded inlet on the machine.
2. Hand tighten the connector.
3. Connect the straight ends of the pipes to the water
supply; ensure that there are no kinks.
4. Turn on the water supply and check for leaks. If there is a
leak, turn off the water supply, disconnect the hose and
check the sealing washers are in place. Refit the hose and
turn on the water supply.
8
This Appliance
must be
connected to a
COLD WATER
supply only.
40003196.qxd 04/05/2005 17:01 Page 8

Connection of the machine to the drain
This machine must be connected in accordance with the water supply regulations. Water byelaws
prohibit connection to a surface water drain.
Decide which plumbing option suits you best then follow the instructions below.
Option 1
Waste pipe connection (waste trap)
Fit the hooked end support to the outlet pipe. Position at least 800mm off the floor.
After removing the blanking plug or cutting the membrane from the waste system securely fix the outlet
pipe to the drainage system, using a hose clip.
Secure the hooked end support up to at least 800mm to avoid water being drawn back into the machine.
Option 2
Into a standpipe
Ensure that the standpipe (minimum diameter 38mm) is not located near an electrical socket.
Fit the hooked end support to the outlet pipe. Install the hose into the standpipe ensuring that the pipe
is at least 500mm from the floor.
Insert the outlet pipe approximately 100mm into the standpipe.
9
All machines are tested with water prior to leaving the factory so a small
amount of water may remain in the drum and drain hose.
Flooding could occur if any part of the installation is not completed correctly.
800 mm
hose clip
hooked end support sink
flexible
discharge hose
trap with hose
adaptor
100 mm
500 mm min
40003196.qxd 04/05/2005 17:01 Page 9

Moving the machine into
position
Your machine is heavy so care must be taken when moving it.
We recommend that two people move the machine to avoid
strain and possible injury.
●Take care not to damage flooring when moving the
machine.
●When moving the machine to its final position take care
not to kink or damage the hose at the back of the
machine.
Adjusting the feet
Once the machine is in place the feet should be adjusted to
ensure that the machine is level. If the machine is not level it
may become noisy or move.
Adjust the feet on the front corners of the machine until the
machine is firm and level.
When the machine is firm and level, tighten the locking nuts
on the two feet.
10
Do not drag or lift the
machine by its door.
40003196.qxd 04/05/2005 17:02 Page 10

Refer to the ‘Selecting the programme’ for details of how to
select programmes.
1. Turn on the water supply and check for leaks from the fill
hose.
2. Switch on the electricity supply.
3. Select the spin programme and then press the
START/PAUSE button to start the machine. Allow the
programme to continue for one minute and then cancel
the programme by returning the selector to the OFF
position. This will remove any water remaining in the
machine from factory testing.
4. To check for cold water filling to the machine:
Select the rinse programme and press the
START/PAUSE button to start the machine.
Allow the tumble action to continue until the water has
pumped out. Check that the drain outlet is not leaking or
overflowing.
5. Switch off the machine at the end of the cycle by turning
the programme knob to the OFF position.
6. Select the spin programme and press the
START/PAUSE button to start the machine. If the machine
takes longer than one minute to empty check the drain
hose for kinks.
Installation testing is now complete.
Now you have successfully installed the machine we advise
that you run the machine to ensure the drum is thoroughly
clean after testing and storage. Select Colourfast 60°C
programme and run the machine for a complete cycle using
only wash detergent and water. Ensure that the drying timer is
in the OFF position.
This programme will take approximately
2 hours to complete.
11
Testing the installation
40003196.qxd 04/05/2005 17:02 Page 11

The following tips are designed to assist in getting the best
results from your machine whilst using it in the most
environmentally-friendly and economical way. It is also
important to understand the items to avoid in your laundry, to
ensure the continued safe and reliable operation of your
machine.
Loading your washing machine
To make further reductions of energy, water and detergent
consumption, we recommend that you put a full load into
your machine. Energy savings of up to 50% can be achieved by
washing one full load compared to two half loads.
Do not overload the machine as this will reduce the quality of
the wash and may cause damage to the machine and your
laundry.
When is prewashing really needed?
Only with particularly dirty loads! Energy savings of 5 to 15%
are made by not selecting the prewash option for less dirty
laundry. Pre-treat awkward stains with a washable stain remover.
Which wash temperature should you
choose?
Using stain removers before machine washing reduces the
need to wash at temperatures over 60°C.
Using a 40°C wash temperature can make energy savings of up
to 50%.
Heavily soiled laundry
To ensure the best performance when washing a particularly
dirty load, we recommend that you reduce the amount of
items to be put into the machine. Allowing more space in the
drum the items can circulate more freely and will wash better.
Sorting the laundry
Items to avoid
We recommend that you do not wash underwired bras in the
machine. Should the wires become detached they could cause
damage to your clothes and the machine. If the washcare label
states that the bra is machine washable then we advise placing
it in a wash bag.
Recommendations
Always follow the wash care labelling on the garments.
Fasten zips, tie strings and close press studs to prevent
tangling. Ensure that pockets are emptied of loose change and
other small items.
12
Washing and Drying advice
40003196.qxd 04/05/2005 17:02 Page 12

Check that there are no metal objects in the laundry as these
may damage the laundry and the machine.
Place small items in a wash bag.
Drying
In addition to the above advice the guidelines below must be
followed when drying the clothes.
Sort the load for drying:
●By care symbols:
On the collar or inside seam:
Suitable for tumble drying.
Tumble drying at high temperature.
Tumble drying at low temperature only.
DO NOT tumble dry.
●By amount and thickness:
Whenever the load is bigger than the dryer capacity,
separate clothes according to thickness (e.g. towels from
thin underwear).
●By type of fabric:
Cottons/linen: Towels, cotton jersey, bed and table linen.
Synthetics: Blouses, shirts, overalls, etc. made of polyester
or polyamid, as well as for cotton/synthetic mixes.
Things to avoid
●Do not tumble dry woollens, silk, delicate fabrics, nylon
stockings, delicate embroidery, fabrics with metallic
decorations, garments with PVC or leather trimmings,
training shoes, bulky items such as sleeping bags, etc.
●Do not dry articles which have been treated with a dry
cleaning fluid or rubber clothes (danger of fire or
explosion).
●Foam rubber materials can, under certain circumstances,
when heated become ignited by spontaneous combustion.
Foam plastic, foam rubber and rubber-like material are
not suitable for tumble drying. Articles made from these
materials MUST NOT be placed in the dryer.
●Do not try to dry items that are dripping wet, this may
damage the appliance. Spin these items first.
13
Do not use the machine
to wash or dry items
that do not have a
wash label.
Do not wash or dry
items previously
treated with solvents.
40003196.qxd 04/05/2005 17:02 Page 13

Detergent dosage
Only use detergents which are suitable for use in a washing
machine. You will obtain the best results from your wash with
the minimum use of chemical products, and the best care for
your laundry if you take into consideration the degree of
soiling as well as the type of detergent to choose.
The amount of detergent to use depends on:
●Water hardness.
Depending on the hardness of the water and the type of
detergent used, it is possible to reduce the amount of
detergent.
The softer the water supply, the less detergent is
required.
●The degree of soiling.
It is possible to reduce the amount of detergent used
depending on the degree of soiling.
Use less detergent for less soiled items.
●Amount of laundry.
It is possible to reduce the amount of detergent when
washing only a small amount of laundry.
For smaller loads use less detergent.
The dosages shown on the packaging of detergents for
washing delicates often already refer to a reduced wash size.
Always follow the dosage instructions on the detergent
packaging.
14
The Dispenser
DO NOT exceed
the maximum
detergent dosage
COMPARTMENT I
Prewash detergent
Maximum dosage 100ml of powder
COMPARTMENT II
Mainwash detergent
Maximum dosage 200ml
of powder
COMPARTMENT
Fabric Conditioner
Maximum dosage 100ml
40003196.qxd 04/05/2005 17:02 Page 14

Dispensing instructions
The detergent drawer is split into 3 compartments:
●the first, labelled "I", is for detergent utilised during
Prewash.
●the second, labelled "II", is for detergent utilised during
the main wash.
●the third, labelled is for special additives such as
fabric softeners, fragrances, starch, brighteners etc.
Dispensing in the drum
Liquid detergents and some tablets are dispensed via the
machine drum using the recommended dispensing device
which is placed upright on top of the washload towards the
back of the drum. Some tablets are designed to be placed in
the dispenser drawer, check the detergent pack for details.
15
Do not put any items
into the drawer other
than detergents that
are designed to be
dispensed from the
drawer as they may
cause blockage or
damage.
40003196.qxd 04/05/2005 17:02 Page 15

Turning the machine On
Turn the machine ON by selecting a programme using the
programme selector. This status will be indicated by the STOP
indicator light flashing, this light will continue to flash until
the machine has started or the machine is returned to the OFF
position.
Start/Pause
START
After selecting the programme and the required options (see the
Wash and Dry Options section of this manual) press the
START/PAUSE button once to start the cycle. The STOP light will
stop flashing and START light will illuminate and there will be a
short time delay to the start of the programme while the
machine sets the wash parameters for the selected programme
and options. If the duration of the programme you have selected
is shorter than 60 minutes, then the time remaining indicator will
illuminate accordingly. The door lock indicator light will also
illuminate a few seconds after pressing the START/PAUSE button.
PAUSE
The programme may be paused at any time during the wash
cycle by holding down the START/PAUSE button for about two
seconds. When the machine is in the paused mode, the time
remaining for the programme in the TIME TO END indicator
and option buttons will flash. The door lock indicator light will
remain illuminated for approximately 2 minutes. The door can
be opened when this indicator goes out. To restart the
programme, press the START/PAUSE button once again.
16
The Control Panel
TIME TO END Display
START/
PAUSE
OPTIONS
BUTTONS
DRYING TIME
SELECTOR
PROGRAMME
SELECTOR
The programme
selector must be return
to the OFF position to
reset the controls
between each wash
cycle.
To start another wash
cycle the programme
selector must be
returned to OFF once
again before the next
programme can be
selected and started.
40003196.qxd 04/05/2005 17:02 Page 16

Cancelling and changing the programme
To cancel the programme the programme selector should be
rotated to the OFF position.
Select a new programme and start as detailed above.
Door Locked indicator
The DOOR LOCKED indicator light is illuminated when the door
is fully closed and the machine is ON.
When START is pressed on the machine with the door closed the
indicator will flash momentarily and then illuminate. If the door
is not closed the indicator will continue to flash.
A special safety device prevents the door from being opened
immediately after the end of the cycle. Wait for 2 minutes after
the wash cycle has finished and the Door Locked light has gone
out before opening the door. As a safety measure, check that
there is no water evident in the drum. At the end of the cycle
turn the programme selector to OFF.
If the programme is paused, the door locked indicator will go
out after 2 minutes and the door can be opened. Check there is
no water evident in the drum before opening the door.
Time To End display
In order to better manage your time, this washing machine
features an indicator light system that keeps you constantly
informed on the remaining cycle time.
When a drying time or sensor drying programme is selected the
Time To End display will display the time remaining on the
washing programme when the washing is taking place and an
indication of the time remaining in the drying phase when
drying is taking place.
The indication in the drying phase is based on an average load
and will therefore vary dependent on the load size, moisture
content and temperature.
The times shown during the drying stage are approximate and
should only be used as a guide.
17
START
60'
30'
15'
STOP
Remaining time above 60 minutes
Remaining time less than 60 minutes
Remaining time less than 30 minutes
Remaining time less than 15 minutes
End of the programme
3h
6h
9h
3 hours or less remaining before the
programme commences
6 hours or less remaining before the
programme commences
9 hours or less remaining before the
programme commences
TIME TO END DISPLAY
WASHING PROGRESS DELAY START
40003196.qxd 04/05/2005 17:02 Page 17

Slow Spin
This option reduces the maximum spin speed of the machine to reduce creasing where necessary.
On the Cottons programmes the spin speed is reduced to half the maximum spin speed e.g. 1200 rpm is
reduced to 600 rpm. On the Synthetics, Acrylics and Fast Wash programmes the spin speed is reduced
from 800 rpm to 400 rpm.
Fast Wash
This option can be used on the Cottons and Synthetics programmes. By selecting the Fast Wash option,
the wash time can be reduced by up to 50 minutes, depending on the selected programme, temperature
and load, without affecting the quality of the wash.
Rinse Hold
This option is only available on synthetics, acrylics, woolmark and silk programmes.
Super Rinse
By pressing this button you can activate a special new wash cycle in the Colourfast and Mixed Fabrics
programs, thanks to the new Sensor Activa System. This option treats with care the fibres of garments
and the delicate skin of those who wear them.
The load is washed in a much larger quantity of water and this, together with the new combined action
of the drum rotation cycles, where water is filled and emptied, will give you garments which have been
cleaned and rinsed to perfection. The amount of water in the wash is increased so that the detergent
dissolves perfectly, ensuring an efficient cleaning action. The amount of water is also increased during
the rinse procedure so as to remove all traces of detergent from the fibres.
18
Wash and Dry Options
The following options should be selected BEFORE pressing the Start Pause button.
The light on each option button will come on if the option has been selected.
Programme
Synthetics
Acrylics
Woolmark
Silk
Crease Guard function
The programme is completed by a
short spin of very low speed.
The machine stops in the final rinse
stage and the option indicators blink.
The load is held in the water in the
drum, thus reducing creasing and
enabling easier ironing.
The machine stops in the final rinse
stage and the option indicators blink.
The load is held in the water in the
drum, thus reducing creasing and
enabling easier ironing.
The machine stops in the final rinse
stage and the option indicators blink.
The load is held in the water in the
drum, thus reducing creasing and
enabling easier ironing.
Action required to complete the cycle
To select a full spin cycle please turn the dial
to the required spin programme.
Press the Rinse Hold button to continue with
the programme. The machine will then pump
out the water and the programme will
conclude with a short spin. Finally, the
programme carries out a brief tumbling
action to loosen the items in the load.
Press the Rinse Hold button and the machine
will pump out the water and complete the
cycle with a short spin cycle.
Press the Rinse Hold button and the machine
will pump out the water to complete the
cycle. The load will not be spun and will
therefore be very wet.
40003196.qxd 04/05/2005 17:02 Page 18

This function has been specifically designed for people with delicate and sensitive skin, for whom even a
very small amount of detergent can cause irritation or allergy. You are advised to also use this function
for children's clothing and for delicate fabrics in general, or when washing garments made of towelling,
where the fibres tend to absorb a greater quantity of detergent.
To ensure the best performance for your wash, this function is
always activated on the Delicates and Woollens programs.
Drying Selector
The Hoover Sensor Washer Dryer gives many options for drying
the laundry to suit all circumstances.
The table below lists the programmes and the function of each
programme.
For tumble drying select the appropriate drying programme via
the Programme Selector. For drying cotton fabrics select the
High Dry option and for synthetic fabrics select the Low Dry
option. Turn the drying time selector until the indicator aligns
with the drying programme or desired time. Do not mix cottons
and synthetics to avoid damage to the laundry.
Note: If the drying time is selected before the wash cycle is
completed the machine will automatically commence the drying
programme. Refer to the Programme Guide to identify which
drying programme will be automatically selected after the wash
programme. To protect your laundry certain programmes (eg Silk)
cannot be followed automatically by a drying programme.
The drying time can be reduced at any time during the cycle
but cannot be increased.
Note: If you do not need to dry after the wash cycle ensure the drying selector is switched OFF ( )
Drying Time Guide
The times given below are indicative and will vary with the exact level of dryness required (eg for ironing
or ready to hang) and the size and composition of the load.
19
Sensor Drying
Programmes
Timed Drying
programmes
Programme
Extra Dry
Store Dry
Iron Dry
120'
60'
30'
Airing
Description
Select the degree of dryness that you require.
This ranges from Extra Dry for bath towels and bathrobes, through
Cupboard Dry for items that will be put away without ironing, to
iron dry that leaves the laundry suitable for ironing.
120 minutes of drying
60 minutes of drying
30 minutes of drying
Tumbling of the laundry in cool air
No drying programme selected
Only a maximum of
3kg of laundry
can be loaded
Type of fabric
Cottons, linen
Synthetics and mixed fabrics
Load Size
3kg
2kg
2kg
1kg
1200/1300 rpm
120 minutes
80 minutes
70 minutes
50 minutes
1500/1600 rpm
90 minutes
70 minutes
60 minutes
40 minutes
Spin Speed
40003196.qxd 04/05/2005 17:02 Page 19

Automatic Features
Automatic Variable Capacity (Half Load)
The washing machine is fitted with a self adjusting water level
system. This system enables the machine to use the optimum
amount of water needed to wash and rinse the laundry in
relation to the particular load. This results in a reduction of the
water and electricity used without in any way compromising
the washing and rinsing performance. The amount of water
and electricity used will always be appropriate for the clothes
load.
The washing machine automatically ensures excellent washing
results at minimum cost whilst respecting the environment.
Out of Balance protection
This model is fitted with an electronic sensor device that
checks if the load is balanced correctly. If the load is slightly
unbalanced the machine will re-balance it automatically to
then carry out the normal spin.
If, after several attempts, balance is not restored a reduced
spin speed will be used.
If loads are seriously unbalanced the spin stage will be
cancelled. This helps limit vibration, reduce noise and improve
the washing machine's reliability and life.
20
40003196.qxd 04/05/2005 17:02 Page 20
