OPERATION AND MAINTENANCE
MANUAL
Multi-Purpose
Grinder
MODEL 06950A

1. Preface
2. Revision
2 av 23
OPERATION AND MAINTENANCE MANUAL I ENG_OMM_MULTI-PURPOSE_GRINDER_P01 I 09th November 2021
@Pandrol 2021
Thank you for choosing Multi-Purpose Grinder!
You are now the owner of a quality product from Pandrol.
This manual aims to help you get to know your new Multi-Purpose Grinder, to use it in the best way and to maintain
it properly for a long lifetime. It also presents important safety regulations and warnings.
The manual is intended for people who handle and operate the machine. It is originally written in English and
translated into the local language by Pandrol.
Pandrol reserves the right to change specications, equipment, instructions and maintenance guidelines without
prior notice.
The manual contains instructions about the following topics:
1. Installation
2. Operation
3. Safety features and warnings
4. Maintenance and troubleshooting
(1) refers to a component in a gure/illustration.
IMPORTANT
This manual contains ordered actions, e.g.
1. Do this
2. ...and then this...
3. ...and nally this
These actions must be done in the numerical order presented.
Revision Date Comments
P01 2021-11-09 New Manual

Table of Contents
1. Preface 2
2. Revision 2
3. Safety Information 4
3.1. General 4
3.2. Safety actions 4
3.3. Personal/Safety equipment 5
3.4. Safety precautions 5
3.5. Qualiedpersonnel  6
4. Summary 7
5. Operation 8
5.1. Grindingheadposition  9
5.2. Coldweatheroperation  9
6. Reviewofhydraulicprinciples  10
6.1. Hydraulicformulas  10
6.2. Backpressure  10
7. Maintenance 11
7.1. General 11
7.2. Warninglabelsandinformationsymbols 12
8. Limitedwarranty  13
8.1. Exclusionstolimitedwarranty  13
8.2. Limitation of liability 13
9. Customerinformation  14
10. Assembly  16
10.1. Partsdiagram06900A  16
10.2. Partslist06900A 17
10.3. Partsdiagram06950Aw/bolt-ontriggerbail  18
10.4. Partslist06950Aw/bolt-ontriggerbail  19
10.5. Partsdiagram06950Aw/weldedtriggerbail  20
10.6. Partslist06950Aw/weldedtriggerbail  21
11. Disclaimer 22
12. Contact 22
13. RecyclingandEnvironment  22
3 av 23
OPERATION AND MAINTENANCE MANUAL I ENG_OMM_MULTI-PURPOSE_GRINDER_P01 I 09th November 2021
@Pandrol 2021

3. Safety Information
3.1. General
• Tooloperatorsandmaintenancepersonnelmustalwayscomplywiththesafetyprecautionsgiveninthis
manual,andwithallstickersandtagsattachedtothetoolandhoses.
• Allsafetyprecautionsaregivenforyoursafety.Readtounderstandandfollowallsafety,maintenanceand
operationinstructionsbeforeyouuseormaintainthetool.
• Reviewthemanualdailybeforeusingthetool.
• Followallsafetyguidelinesgivenyoubyyoursupervisor.Donotusethetoolifyouhaveanyquestionsabout
theoperation,safetyormaintenanceofthistool.Failuretofollowtheseinstructionscanresultinpersonal
injuryorequipmentdamage.
• Pandrolhasnocontroloverthetooluseoroperationonceitleavestheplant.Pandrolhasnocontrolover
operatorormaintainerselection.Thecustomermustassumeresponsibilityforthetoolsuitabilityforaparticular
function.
• Duringuseofthetool,goodjudgementmustbeusedtoworksafelyande󰀩cientlywithoutendangering
themselvesorbystanders.
• Understandingoftheoperationandmaintenancemanualisessentialforanyoneusingormaintainingthetool.
• Warningsandsafetyprecautionsdescribedinthisdocumentshallonlybeconsideredasaminimum.National
conditions,standardsandregulationsoverrideconditions,standardsandregulationsdescribedinthis
document.
• Workwiththemachineisonlytobecarriedoutbyqualiedpersonnel,well-informedandeducatedingeneral
railwayworkmanshipandspecicallyintheconditions,standardsandregulationsonspecicrailtrack.
• Themachinemayonlybeusedforitsspeciedpurpose.
• Anyadjustmentsorserviceonthemachineisonlyallowedtobedonebyqualiedpersonnelthathaveread
andunderstoodthismanualandhavehadtrainingandinformationfromPandrol.
3.2. Safety actions
• Readandunderstandallsafetyregulationsandwarningsbeforeinstallation,operatingorperforming
maintenanceonthismachine.
• Donotoperatethetooluntilyouhavebeenthoroughlyandproperlytrainedorunderthesupervisionofan
instructor.
• Checkpowersourcedailytodetermineifcorrectowandpressureareavailable.Neverexceedowsor
pressuresforthetoolbeingused.Personalinjuryordamagetothetoolcanresult.
• Operatorsmustcleartheworkareaofnon-essentialpersonnel.Flyingdebriscancauseseriousinjury.
• Theoperatormustbefamiliarwithallprohibitedworkareassuchasunsafegrades,poorfootingareasand
overheadhazards.
• Usestandardsandregulations,accidentpreventionregulationsandregulationsconcerningspecialambient
conditions(e.g.areaspotentiallyendangeredbyexplosivematerials,heavypollutionorcorrosiveinuences).
• Maintainbalanceandproperfootingatalltimes.Neveroverreachtotheextentthatabrokenpartorsudden
movementofthetoolcancauseyoutoloseyourbalanceandfall,orcauseinjurytoyourselforsomeoneelse.
4 av 23
OPERATION AND MAINTENANCE MANUAL I ENG_OMM_MULTI-PURPOSE_GRINDER_P01 I 09th November 2021
@Pandrol 2021

• Donotoperatethetoolatexcessiveuidtemperaturesoperatordiscomfortandpotentialburnscanresultat
highoiltemperatures.
• Donotcleaninspectorrepairthetoolwhileconnectedtothepowersource.Accidentalengagementofthetool
can cause serious personal injury.
• Oilinjectionhazardexistswiththistool.Oilinjectionisaconditionwherehydraulicoilisinjectedunderthe
skinfrompressureintheline.Alwayswearglovesandrepairanyleaksimmediately.Nevercarryatoolbythe
hoses.
• Donotusedamagedequipment.Immediatelyreplaceanydamagedhoses,ttings,orothercomponents
showingwirebraid,nicks,cuts,damageorabrasions.Failuretodosomayresultinequipmentdamageand/or
personalinjuryordeath.
• Cleanupanyoiloruidspillsimmediately.
3.3. Personal/Safety equipment
• Neverwearlooseclothingthatcangetentangledintheworkingpartsofthetoolsorbecarelesswithhands,
feetorotherbodypartsaroundtheworkingpartsofthetools.Hydraulictoolsexerthightorqueandforceand
cancauseseriousinjuryordeathifimproperlyused.
• Whenworkingnearelectricalconductors,alwaysassumethattheconductorsareenergizedandthathosesand
clothingcanconductharmfulelectricity.Usehoseslabeledandcertiedasnonconductive.
• Alwayswearsafetyequipmentsuchasoilinjectionresistantworkgloves,safetyglasses,safetyboots,ear
protectionandothersafetyappareldictatedbyyoursupervisorapplicableforthejobyouaredoingandthetool
youareusing.
• Theuseofancompressedair,whichmustbelessthan8BAR(116PSI),toblowpartscleanortoblowthem
dryafterbeingcleanedwithasolventwillcauseparticlesofdirtand/ordropletsofthecleaningsolventtobe
airborne.Theseconditionsmaycauseskinand/oreyeirritation.Whenusinganairjetdonotdirectittoward
anotherperson.Improperuseofairjetcouldresultinbodilyinjury.
3.4. Safety precautions
• Alwayswearprotectiveequipmentsuchasgloves,safetyglasses,earprotection
• Andsafetyshoes.
• Donotwearclothingwhichmaybecomeentangledinthetool.
• Alwayskeepworkareafreeoftoolsoranyotherobjectswhichmayimpair
• Soundfooting.
• Cautionoilinjectionhazardexistswiththistool.Oilinjectionisaconditionwherethehydraulicoilisforced
undertheskinthroughpressureintheline.Alwaysweargloves,donotcarrythetoolbyhydraulichoses,and
repairleaksimmediately..
• Neverchangestoneswiththepowersourcevalve(s)inthe"ON"position,turnthepowersource"OFF".
• Neverattempttocarrythegrinderwiththepowersourceinthe"ON"position,turnthepowersource"OFF".
5 av 23
OPERATION AND MAINTENANCE MANUAL I ENG_OMM_MULTI-PURPOSE_GRINDER_P01 I 09th November 2021
@Pandrol 2021

• Nevertouchortrytostopamovingstone.
• Alwayschecktheworkareaforanytrashwhichmayignitefromsparks.
• Alwayschecktheareaforsmolderingtiesortrashbeforeleavingthesite.
• Whenchangingstones,followallgrindingstonemanufacturersinstructionsforsafetyandoperation.Useonly
stonesthatcomplywithansistandards.Beforeusing,runnewgrindingstoneforoneminuteatfullspeedto
checkfordefectsorvibration.
• Mosthydraulicoilshaveaashpointofapproximately450degrees(f).Makesurehosesarecompletelyclear
ofsparksandhotdebris.Haveanotherpersonstandclosetohydraulicpowersourcecontrolstoobserve
operationandforemergencyshutdownifnecessary.
3.5. Qualied personnel
Themachineisonlytobeusedbytrainedpersonnel,thoroughlyfamiliarwithandtrainedingeneralrailway
workmanship.Theequipmentshouldbeoperatedaccordingtotheconditionsandstandardregulationsapplyingto
thetracktheyareworkingon.
Theequipmentmustbeserviced,maintained,orinanywaymodiedonlybytrainedpersonnel,whoarefamiliar
withtheOperation&MaintenanceManualandhavereceivedtrainingandinformationfromPandrol.
Inordertoavoidpersonalinjuryand/ormaterialdamage,everyoneinvolvedwithassembling,starting-upor
overhaulmustpossessrelevantknowledgeoftheequipment,itsuse,maintenancerequirementsandprocedures.
6av23
OPERATION AND MAINTENANCE MANUAL I ENG_OMM_MULTI-PURPOSE_GRINDER_P01 I 09th November 2021
@Pandrol 2021

4. Summary
ThePandrolMulti-PurposeGrinderallows
operatorstoremaininanergonomicupright
positionwhileperformingeldweldgrinding.The
adjustablerearhandlepositionseasilyforthe
operatorspreferredheightandcomfortorlowered
andswiveledaroundforcompactstorage.
Flow Pressure RPM Dimensions Weight
10GPM(38LPM) 2000PSI(140BAR) 4000 A-40"(101.6cm)
B-22"(55.9cm)
C-34"(86.4cm)
43lbs(19.5kg)
Accessories:
00499-8x1x5/8Hubgrindingstone
Fig 1.
Fig 2. Fig 3.
7 av 23
OPERATION AND MAINTENANCE MANUAL I ENG_OMM_MULTI-PURPOSE_GRINDER_P01 I 09th November 2021
@Pandrol 2021

5. Operation
• Withthepowersourceinthe"OFF"position,connectthehoses.Donotdragtheservicehosebypulling
withthetool.Looptheservicehoseintheworkareainsuchawaytorelievestressonthehoseandquick
disconnectttingswhileworking.Beawareofhoselocationatalltimes.
• Connectthetooltothepowersource.
• Placethegrinderontherailwiththefronthookovertherailheadandthegrindingheadinthegeneralgrinding
area.
• Graspthetoolrmlybeforeengagingthetrigger.Therewillbeaslighttorquereactionwhenthestoneis
activated.
5.1. Grinding head position
Thestoneisalwaysinthehorizontalposition.Thehookisalsousedinthisposition.Thispositionisusedfor
thermiteweld,proleblend-insandremoval.
Fig 4.
NOTE!
• Refer to manufacturer’s specications for torque settings on stone
attachment
8 av 23
OPERATION AND MAINTENANCE MANUAL I ENG_OMM_MULTI-PURPOSE_GRINDER_P01 I 09th November 2021
@Pandrol 2021

5.2. Cold weather operation
Hydraulicsystemperformanceisa󰀨ectedwhenthetemperaturedropsbelow50°F.Therefore,measuresshouldbe
takentopre-warmtoolsanduidsbeforeoperating.
NOTE!
• Refer to operating procedures of this manual before starting
9av23
OPERATION AND MAINTENANCE MANUAL I ENG_OMM_MULTI-PURPOSE_GRINDER_P01 I 09th November 2021
@Pandrol 2021

6. Review of hydraulic principles
Tool circuit
6.1. Hydraulic formulas
Example:HPrequiredtodeliver10GPMat1500PSI.
EstimatedHPdeliveredbypumporusedbytool
6.2. Back pressure
Backpressuremeasuredatthetoolreturnportmustnotexceedthemanufacturersbackpressurerating.Most
manufacturerslistthemaximumbackpressurefortheirhydraulictoolsat250PSI.Backpressuremeasuredon
thereturnsideofthetoolistheforcerequiredtogettheoilbacktothetank.Inalmostallcasesthelowertheback
pressurethebetterthetoolperformance.First,thebackpressureissubtractedfromthemaximumtoolpressure
toarriveatamaximumtooloperatingpressure.Forexample,toolswith2000PSIoperatingpressureareinstalled
onasystemwith250PSIbackpressure.Thisleaves1750PSIasamaximumtoolpressure.Imagineasystem
with500PSIbackpressure.2000Minus500PSIbackpressureleavesonly1500PSIforthetool.Second,tools
aredesignedforpressuretobuildonthepressuresideofthetool.Iftoomuchpressurebuildsonthereturnside,
notonlyisperformancee󰀨ected,butsealsmayblow.Thisiswhyitisveryimportanttodirecttheowintothetool
correctly.Reversingthehosestotestmayresultinblownseals,damagetothetool,andpersonalinjury.
GPM PSI
500 1000 1500 2000 2500 3000
31.03 2.06 3.09 4.12 5.15 6.18
51.72 3.43 5.15 6.86 8.58 10.30
10 3.43 6.86 10.30 13.70 17. 2 0 20.60
15 5.15 10.30 15.40 20.60 25.70 30.90
10av23
OPERATION AND MAINTENANCE MANUAL I ENG_OMM_MULTI-PURPOSE_GRINDER_P01 I 09th November 2021
@Pandrol 2021

7. Maintenance
7.1. General
Maintenance and overhaul is to be carried out by qualied personnel only
Warranty is based on parts and spares delivered by Pandrol.
Check tools DAILY for proper operation, leaks, or damage.
Inspect hoses DAILY. Replace cut, burned, or otherwise damaged hoses.
Keep quick disconnect couplers clean and lubricated.
UsehydraulicuidsthatcomplywithHTMASpecication5.7,Thehydraulicuidshouldhaveaviscositybetween
100and400SSU(20-82centistokes)atthemaximumandminimumexpectedoperatingtemperatures.Petroleum
basedhydraulicuidswithanti-wearpropertiesandaviscosityindexofover140workforawiderangeof
operatingconditions.
Havetoolinspected,atleastannually,byPandroloraPandrolqualiedservicerepresentativetodetermineiftool
isinneedofsafetychangesorwornpartreplacement.
ContactPandrolonaperiodicbasis,atleastannually,forserviceBulletins,safetynotices,orotherimportant
informationpertainingtothistool.
Other uids that meed or exceed this specication can be used.
* See cold weather operation hydraulic oil note.
The following oils meet HTMA Specication 5.7
WARNING!
• All adjustments work, overhaul and service must take place with the
machine turned o󰀨. Failure to do so could lead to fatal injury.
• It is of great importance that qualied personnel accomplish all service and
overhaul
11 av 23
OPERATION AND MAINTENANCE MANUAL I ENG_OMM_MULTI-PURPOSE_GRINDER_P01 I 09th November 2021
@Pandrol 2021

7.2. Warning labels and information symbols
Belowareexamplesofwarninglabelsandinformationsymbolsonthemachine.Ifanyoftheselabelsbecome
damagedorlost,theyaretobereplacedwithneworiginalwarninglabelsthatareavailablefromPandrol.
12 av 23
OPERATION AND MAINTENANCE MANUAL I ENG_OMM_MULTI-PURPOSE_GRINDER_P01 I 09th November 2021
@Pandrol 2021

8. Limited warranty
Pandrol,INCwarrantstotheoriginalpurchaseofthisproductthattheproductwillbefreefromdefectsinmaterial
andworkmanshipfortheperiodofone(1)yearafterthedeliveryofsuchproducttothecustomer.Otherequipment
andpartsused,butnotmanufacturedbyPandrolarecovereddirectlybythewarrantyofthemanufacturerofthose
products.Proofofpurchasemustbedocumentedincludingreferencetoaserialnumberlocatedoneachtool.
Thepurchaser’sonlyremediesunderthislimitedwarrantyshallbelimitedatPandrol’ssoleoptiontothefollowing:
repair,replacementorrefundofthepurchasepriceofthedefectiveproducts.Eachoftheseremediesrequires
timelynoticationofthedefectintheproductandsubstantiationthattheproducthasbeenproperlystored,
maintainedandused.Pandrol’sobligationshereunderextendonlytothepurchaseroftheproductandnottoany
thirdparty.
AsaconditionprecedenttoPandrol’sobligationhereunder,thedefectiveproductmustnothavebeenalteredor
modiedwithouttheexpresswrittenapprovalofPandrol.Theproductmustnothavebeensubjectedtodeliberate
damage,shippingdamage,neglect,tamperingbyunauthorizedpersonnelordamagebyimproperuse,storageor
maintenance.Serialnumbersmustnothavebeenaltered,defacedorremoved.Suchactionvoidslimitedwarranty.
8.1. Exclusions to limited warranty
Thislimitedwarrantyisexclusiveandisinlieuofanyotherwarranty,writtenororal,expressedorimplied,
including,withoutlimitation,anyimpliedwarrantyormerchantabilityortnessforaparticularpurpose.
Limitedwarrantydoesnotcovernormalwearandtearitemssuchaslters,hoses,couplers,bits,sockets,augers,
andbatteries
8.2. Limitation of liability
Exceptasprovidedabove,Pandrolshallinnoeventbeliableorresponsibleforanyinjury,lossordamage,direct,
incidentalorconsequential,arisingoutoftheuseormisuseorinabilitytousetheproduct,howevercausedand
onanytheoryofliabilityincluding,withoutlimitations,breachofcontract,tort,(includingnegligenceorstreet
liability)andnotwithstandinganyfailureofanyremedyhereinofitsessentialpurpose,evenifPandrolwasaware
ofthispossibilityofsuchdamage.Pandrol’slimitedwarrantyassetforthaboveshallnotbeenlarged,diminished
ora󰀨ectedby,andnoobligationorliabilityshallariseorgooutoftherenderingoftechnicaladviceorserviceby
Pandroloritsagents.Theforegoingmaynotbechangedexceptbywrittenagreementsignedbyanauthorized
o󰀩cerofPandrol,theremediessetforthhereinareexclusive.
13 av 23
OPERATION AND MAINTENANCE MANUAL I ENG_OMM_MULTI-PURPOSE_GRINDER_P01 I 09th November 2021
@Pandrol 2021

9. Customer information
Name
Company
Serial # of your Pandrol tool
Upon receiving your Pandrol tool, make sure to list serial number above so that a good record is kept for
order information.
Pandrol hydraulic tool list
AllPandrolHydraulicToolsoperateat5GPM(19LPM)or10GPM(38LPM)@2000PSI(140BAR)
Power units:
00100K–Gasolinepowered(1)10GPMor(2)5GPMcircuits
02900A–Diesel(1)10GPMor(2)5GPMcircuits(optionalcatalyticexhaust)
05500–Twinpowerdualcircuit(1)10GPMor(2)5GPMcircuits&5000wattgenerator
02050RM–Modularpowerunit(1)9GPM
03700A–Electricpower(1)10GPMor(2)5GPMcircuits
Grinders:
09200A–Precisionfroggrinder
06000–Prolegrinder
06950&06950A–Multi-purposegrinder
05900–Frog/prolegrinder(triggerversionavailable)
00700–Railsurfacingguide
04600–Straightstonegrindercwrotation(triggerversionavailable)
04700–Straightstonegrinderccwrotation(triggerversionavailable)
07500–Chamfertool
04800–6"Cupstonegrinder(triggerversionavailable)
00600–8"Cupstonegrinder
05400–Anglegrinder
09300-Headwashgrinder
14 av 23
OPERATION AND MAINTENANCE MANUAL I ENG_OMM_MULTI-PURPOSE_GRINDER_P01 I 09th November 2021
@Pandrol 2021

Track tools:
03900A–Reversingrailsaw
05100A&05100B–Powerweldshear
03500–Selffeedraildrill
04500D–1/2”Hydraulicdrillimpactwrench
08200–Tamper
02800A–60Tonbridgespreader
01200–Springanchorapplicator
01100A–Spikepuller(Single,2stage&triggerversionsavailable)
00800A–16”Railsaw
05000–Handpumpweldshear
02500–10GPM1”Impactwrench
08300–Spikedriver
01600A–5GPM1”Impactwrench
01100RM–Light-weightspikepuller
Other products:
Hydraulicmanifolds
Hydraulictestgauges
Hosereels
Hydraulichoses
Accessories
Drill bits
ShearBlades
SawBlades
GrindingStones
Sockets
15 av 23
OPERATION AND MAINTENANCE MANUAL I ENG_OMM_MULTI-PURPOSE_GRINDER_P01 I 09th November 2021
@Pandrol 2021

10.Assembly
10.1. Parts diagram 06900A
16av23
OPERATION AND MAINTENANCE MANUAL I ENG_OMM_MULTI-PURPOSE_GRINDER_P01 I 09th November 2021
@Pandrol 2021

10.2. Parts list 06900A
17 av 23
OPERATION AND MAINTENANCE MANUAL I ENG_OMM_MULTI-PURPOSE_GRINDER_P01 I 09th November 2021
@Pandrol 2021

10.3. Parts diagram 06950A w/ Bolt-on trigger bail
18 av 23
OPERATION AND MAINTENANCE MANUAL I ENG_OMM_MULTI-PURPOSE_GRINDER_P01 I 09th November 2021
@Pandrol 2021

10.4. Parts list 06950A w/ Bolt-on trigger bail
19av23
OPERATION AND MAINTENANCE MANUAL I ENG_OMM_MULTI-PURPOSE_GRINDER_P01 I 09th November 2021
@Pandrol 2021

10.5. Parts diagram 06950A w/ Welded trigger bail
20av23
OPERATION AND MAINTENANCE MANUAL I ENG_OMM_MULTI-PURPOSE_GRINDER_P01 I 09th November 2021
@Pandrol 2021
