Parkmate PM-90AHV User manual

PM-90AHV
USER MANUAL
Heavy Duty Analogue HD Rear
Camera with 1080P Resolution
YOUR SAFETY COMES FIRST™

1
CONTENTS
1.0 INTRODUCTION .............................................................................2
1.1 Component List .....................................................................2
1.2 Technical Specications: .......................................................4
2.0 WIRING DIAGRAM .........................................................................4
3.0 TESTING.........................................................................................4
3.1 How to test ............................................................................4
4.0 TROUBLESHOOTING ....................................................................5
5.0 CARE AND MAINTENANCE ..........................................................5
6.0 WARRANTY TERMS & CONDITIONS ...........................................6
7.0 INDEMNITY.....................................................................................7
8.0 WARRANTY AND WARRANTY DISCLAIMER ..............................7
9.0 LIMITATIONS OF PARKMATE LIABILITY ................................... 10
10.0 NOTES .......................................................................................... 11

2
1.0 INTRODUCTION
Thank you for purchasing Parkmate’s PM-90AHV camera. We
are certain that our product will give you trouble-free operation
while providing you with safety features that enhance your driving
experience.
DISCLAIMER
Our products are to assist and aid the driver, not to replace the
manual function of the person operating the vehicle.
Although the PM-90AHV is a visual aid and will allow you to view
what is behind the vehicle, it does not remove the responsibility
of driving the vehicle from the driver. Legal responsibility and
safe driving practise remains with the driver at all times.You have
purchased this product with the understanding that its use is as
an aid only. We highly recommend that you have this product
professionally installed to ensure that it will provide the functions it
is set out to perform.
CAUTION
• Ensure you are using your rear camera within your countries’
road laws. Please make sure you are familiar with your local
road legislation before use.
1.1 COMPONENT LIST
Heavy Duty
Rear Camera
8 Metre
Cable
Screws Allen
Key
Installation
Guide

3
IMPORTANT NOTICE
• Please read this manual carefully before using the product.
• Wire connection points should always be insulated.
• Wiring should always be installed away from heat sources and
electrical components.
• Please perform tests after nishing installation to ensure
camera is working correctly.
• This camera is intended for use as an aid when reversing
your vehicle. Drivers must always use extreme caution when
operating a vehicle.
• Specications are subject to change without notice.
WARNING
• Do not disassemble the camera or cut the camera cable
as this voids the warranty. Disassembling the camera will
compromise the waterproof seal.
PLEASE NOTE
• The Parkmate PM-90AHV is an Add-On AHD Rear Camera,
designed specically for use with the Parkmate MCPK-
502DVR and/or the Parkmate MCPK-962DVR. It will not
function as intended when used stand alone.

4
1.2 TECHNICAL SPECIFICATIONS:
Signal System: PAL
Resolution: 1080P
Minimum Illumination: 0 Lux
Diagonal Angle: 120°
Waterproof Rating: IP69K
Nominal Voltage: 12V
Working Temperature: -20°C to 65°C
2.0 WIRING DIAGRAM
3.0 TESTING
3.1 HOW TO TEST
1. Apply the parking brakes. (Safety Precaution)
2. Turn ignition on. (DO NOT TURN ON VEHICLE)
3. Shift into reverse gear.
4. Image should appear on the Mirro DVR.
5. Recorded les will be stored on the Mirror DVR SD Card
(SD Card & Mirror DVR not provided).
RED to Reversing Light + 12V
BLACK to Ground
Switching Wire
Mirror DVR Video Input Video Extension Cable

5
4.0 TROUBLESHOOTING
5.0 CARE AND MAINTENANCE
Always keep camera clear from dirt and mud. Clean camera with a
soft moist cloth.
PROBLEM SOLUTION
“No Signal” appears while
reversing
1. Check video input
connections
2. Check camera power
connections
Video image is not sharp Check camera lens for debris

6
6.0 WARRANTY TERMS & CONDITIONS
Our goods come with guarantees that cannot be excluded under
the Australian & New Zealand Consumer Law.You are entitled to
a replacement or refund for a major failure and for compensation
for any other reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired or replaced if the goods fail to
be of acceptable quality and the failure does not amount to a major
failure.
This warranty is provided in addition to your rights under the
Australian & New Zealand Consumer Law.
Directed Electronics warrants that this product is free from defects
in material and workmanship for a period of 12 months from
the date of purchase or for the period stated on the packaging.
This warranty is only valid where you have used the product in
accordance with any recommendations or instructions provided by
Directed Electronics.
This warranty excludes defects resulting from alterations of the
product, accident, misuse, abuse or neglect.
In order to claim the warranty, you must return the product to the
retailer from which it was purchased or if that retailer is part of a
National network, a store within that chain, along with satisfactory
proof of purchase. The retailer will then return the goods to Directed
Electronics. Directed Electronics will repair, replace or refurbish
the product at its discretion. The retailer will contact you when the
product is ready for collection. All costs involved in claiming this
warranty, including the cost of the retailer sending the product to
Directed Electronics, will be borne by you.
Directed Electronics Address: 115-119 Link Road Melbourne
Airport, 3045 Victoria. Australia
Ph: [phone] Email: [e-mail]

7
7.0 INDEMNITY
YOU AGREE TO DEFEND, INDEMNIFY AND HOLD HARMLESS
PARKMATE AND ITS SUBSIDIARIES AND AFFILIATES FROM
AND AGAINST ANY AND ALL CLAIMS, PROCEEDINGS,
INJURIES, LIABILITIES, LOSSES, COSTS AND EXPENSES
(INCLUDING REASONABLE LEGAL FEES), INCLUDING
BUT NOT LIMITED TO, CLAIMS ALLEGING NEGLIGENCE,
INVASION OF PRIVACY, COPYRIGHT INFRINGEMENT AND/
OR TRADEMARK INFRINGEMENT AGAINST PARKMATE AND
ITS SUBSIDIARIES AND AFFILIATES OR THE PARKMATE
SERVICES, RELATING TO OR ARISING OUT OF YOUR
BREACH OF ANY PROVISION OF THESE TERMS, YOUR
MISUSE OF THE PARKMATE OR PARKMATE SERVICES, OR
YOUR UNAUTHORIZED MODIFICATION OR ALTERATION OF
PRODUCTS OR SOFTWARE.
8.0 WARRANTY AND WARRANTY DISCLAIMER
PARKMATE HAS A LIMITED WARRANTY ON WHEREBY
PARKMATE WARRANTS TO AND ONLY TO YOU THAT THE
ON PARKMATE VEHICLE DASH CAMERAS, MIRROR DASH
CAMERAS, FRONT, REAR AND REVERSING CAMERAS AND
MIRROR MONITOR DEVICES WILL BE FREE FROM DEFECTS
IN MATERIALS AND WORKMANSHIP FOR ONE (1) YEAR FROM
THE DATE OF YOUR PURCHASE OF THE ON PARKMATE
VEHICLE DASH CAMERAS, MIRROR DASH CAMERAS, FRONT,
REAR AND REVERSING CAMERAS AND MIRROR MONITOR
DEVICES (UNLESS A LONGER WARRANTY PERIOD IS
REQUIRED BY LAW).
THE SPECIFICS OF THIS PARKMATE LIMITED WARRANTY ARE
AT HTTPS://WWW.PARKMATE.COM.AU/WARRANTY
TO THE EXTENT POSSIBLE UNDER GOVERNING LAW, OTHER
THAN THE ABOVE PRODUCT WARRANTY FOR THE PARKMATE
VEHICLE DASH CAMERAS, MIRROR DASH CAMERAS, FRONT,
REAR AND REVERSING CAMERAS AND MIRROR MONITOR
DEVICES, YOU UNDERSTAND AND AGREE THAT THE
PARKMATE SERVICES ARE PROVIDED ON AN "AS IS" AND
"AS AVAILABLE" BASIS. PARKMATE MAKES NO WARRANTY
THAT THE PARKMATE SERVICES WILL MEET YOUR
REQUIREMENTS OR THAT USE OF THE PARKMATE SERVICES

8
WILL BE UNINTERRUPTED, TIMELY, SECURE OR ERROR-
FREE NOR DOES PARKMATE MAKE ANY WARRANTY AS TO
THE ACCURACY OR RELIABILITY OF ANY INFORMATION
OBTAINED THROUGH THE PARKMATE SERVICES (INCLUDING
THIRD PARTY CONTENT), THAT ANY DEFECTS IN THE
PARKMATE SERVICES WILL BE CORRECTED OR THAT THE
PARKMATE PRODUCTS OR PARKMATE SERVICES WILL BE
COMPATIBLE WITH ANY OTHER SPECIFIC HARDWARE OR
SERVICE. FURTHER, PARKMATE DOES NOT WARRANT THAT
THE PARKMATE SERVICES OR THE PARKMATE SERVERS
THAT PROVIDE YOU WITH DATA AND CONTENT ARE FREE OF
VIRUSES OR OTHER HARMFUL COMPONENTS. PARKMATE
ALSO ASSUMES NO RESPONSIBILITY FOR AND SHALL NOT
BE LIABLE FOR ANY DAMAGES CAUSED BY VIRUSES THAT
MAY INFECT YOUR PARKMATE VEHICLE DASH CAMERAS,
MIRROR DASH CAMERAS, FRONT, REAR AND REVERSING
CAMERAS AND MIRROR MONITOR DEVICES, COMPUTER
SOFTWARE, OR OTHER HARDWARE.
YOU AGREE THAT PARKMATE IS NOT AN INSURER AND THAT
PARKMATE IS NOT PROVIDING ME WITH INSURANCE OF ANY
TYPE. ANY AMOUNTS THAT YOU PAY PARKMATE FOR THE
PARKMATE SERVICE ARE NOT INSURANCE PREMIUMS AND
ARE NOT RELATED TO THE VALUE OF YOUR VEHICLE OR
PROPERTY, ANYONE ELSE’S PROPERTY LOCATED IN YOUR
VEHICLE OR PREMISES, OR ANY RISK OF LOSS IN YOUR
VEHICLE OR AT YOUR PREMISES. IF YOU WANT INSURANCE
TO PROTECT AGAINST ANY RISK OF LOSS AT YOUR VEHICLE
OR PREMISES, YOU WILL PURCHASE IT. IN THE EVENT OF
ANY LOSS, DAMAGE OR INJURY, YOU WILL NOT LOOK TO
PARKMATE TO COMPENSATE YOU OR ANYONE ELSE. YOU
RELEASE AND WAIVE FOR YOURSELF AND YOUR INSURER
ALL SUBROGATION AND OTHER RIGHTS TO RECOVER
AGAINST PARKMATE ARISING AS A RESULT OF THE PAYMENT
OF ANY CLAIM FOR LOSS, DAMAGE OR INJURY.
PARKMATE’S EQUIPMENT AND SERVICES DO NOT CAUSE
AND CANNOT ELIMINATE OCCURRENCES OF CERTAIN
EVENTS, INCLUDING, BUT NOT LIMITED TO, VEHICLE
ACCIDENTS, PROPERTY DAMAGE, LOST PROPERTY, THEFT
OF VEHCLE , THEFT OF PROPERTY. PARKMATE MAKES

9
NO GUARANTEE OR WARRANTY, INCLUDING ANY IMPLIED
WARRANTY OF MERCHANTABILITY OR FITNESS FOR A
PARTICULAR PURPOSE, THAT THE PARKMATE EQUIPMENT
AND SERVICES PROVIDED WILL DETECT OR AVERT SUCH
INCIDENTS OR THEIR CONSEQUENCES. PARKMATE DOES
NOT UNDERTAKE ANY RISK THAT YOU OR YOUR VEHICLE OR
PROPERTY, OR THE PERSON OR PROPERTY OF OTHERS,
MAY BE SUBJECT TO INJURY OR LOSS IF SUCH AN EVENT
OCCURS. THE ALLOCATION OF SUCH RISK REMAINS WITH
YOU, NOT PARKMATE.
OTHER THAN THE ABOVE PRODUCT WARRANTY FOR
THE PARKMATE VEHICLE DASH CAMERAS, MIRROR DASH
CAMERAS, FRONT, REAR AND REVERSING CAMERAS
AND MIRROR MONITOR DEVICES, PARKMATE AND ITS
SUPPLIERS DISCLAIM ALL WARRANTIES OF ANY KIND,
WHETHER EXPRESS, IMPLIED, OR STATUTORY, REGARDING
THE PARKMATE EQUIPMENT AND ANY ASSOCIATED APP/
SERVICE. INCLUDING ANY IMPLIED WARRANTY OF TITLE,
MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE,
OR NONINFRINGEMENT OF THIRD PARTY RIGHTS. BECAUSE
SOME JURISDICTIONS DO NOT PERMIT THE EXCLUSION
OF IMPLIED WARRANTIES, THE LAST SENTENCE OF THIS
SECTION MAY NOT APPLY TO YOU. PARKMATE HEREBY
FURTHER EXPRESSLY DISCLAIMS ALL LIABILITY FOR ANY
CLAIMS FOR SERVICE FAILURES THAT ARE DUE TO NORMAL
PRODUCT WEAR, PRODUCT MISUSE, ABUSE, PRODUCT
MODIFICATION, IMPROPER PRODUCT SELECTION OR
YOUR NON-COMPLIANCE WITH ANY AND ALL APPLICABLE
FEDERAL, STATE OR LOCAL LAWS. THIS WARRANTY AND
WARRANTY DISCLAIMER GIVE YOU SPECIFIC LEGAL RIGHTS,
AND YOU MAY HAVE OTHER RIGHTS THAT VARY BY STATE,
PROVINCE, OR COUNTRY. OTHER THAN AS PERMITTED BY
LAW, PARKMATE DOES NOT EXCLUDE, LIMIT OR SUSPEND
OTHER RIGHTS YOU HAVE, INCLUDING THOSE THAT MAY
ARISE FROM THE NONCONFORMITY OF A SALES CONTRACT.
FOR A FULL UNDERSTANDING OF YOUR RIGHTS YOU
SHOULD CONSULT THE LAWS OF YOUR STATE, PROVINCE,
OR COUNTRY. FOR OUR AUSTRALIAN CUTOMERS: PLEASE
NOTE THAT THIS WARRANTY IS IN ADDITION TO ANY

10
STATUTORY RIGHTS IN AUSTRALIA IN RELATION TO YOUR
GOODS WHICH, PURSUANT TO THE AUSTRALIAN CONSUMER
LAW, CANNOT BE EXCLUDED.
9.0 LIMITATIONS OF PARKMATE LIABILITY
UNDER NO CIRCUMSTANCES WILL PARKMATE BE LIABLE IN
ANY WAY FOR ANY CONTENT, INCLUDING, BUT NOT LIMITED
TO, THE LOSS OF CONTENT, ANY ERRORS OR OMISSIONS
IN ANY CONTENT, OR ANY LOSS OR DAMAGE OF ANY KIND
INCURRED IN CONNECTION WITH USE OF OR EXPOSURE
TO ANY CONTENT POSTED, EMAILED, ACCESSED,
TRANSMITTED, OR OTHERWISE MADE AVAILABLE VIA THE
PARKMATE APP.
PARKMATE LIABILITY FOR DAMAGES, ESPECIALLY
FOR BREACH OF DUTY OR OBLIGATION, DELAY
IN PERFORMANCE, NON-PERFORMANCE, OR
MALPERFORMANCE SHALL BE PRECLUDED, EXCEPT
WHEN THESE ARE DUE TO NEGLIGENT BREACHES OF ANY
SIGNIFICANT CONTRACTUAL DUTY OR OBLIGATION ON
THE PART OF PARKMATE. ANY LIABILITY FOR NEGLIGENCE
IS LIMITED TO DIRECT LOSSES USUALLY AND TYPICALLY
FORESEEABLE IN SUCH CASE. SHOULD THE CLAIM FOR
DAMAGES BE BASED ON WILFUL OR GROSSLY NEGLIGENT
BREACH OF CONTRACTUAL DUTY OR OBLIGATION ON THE
PART OF PARKMATE, THE PRECLUSION AND LIMITATION OF
LIABILITY MENTIONED IN THE PRECEDING SENTENCES WILL
NOT APPLY. THE PRECEDING PRECLUSION AND LIMITATION
OF LIABILITY WILL ALSO NOT APPLY TO CLAIMS FOR
DAMAGES ARISING OUT OF LOSS OF LIFE, BODILY INJURY
OR HEALTH IMPACTS FOR WHICH PARKMATE MAY BE LIABLE,
OR FOR NON-CONTRACTUAL LIABILITY.
SOME STATES AND COUNTRIES DO NOT ALLOW
THE EXCLUSION OR LIMITATION OF INCIDENTAL OR
CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION
OR EXCLUSION MAY NOT APPLY TO YOU. ADDITIONALLY,
THIS PROVISION IS NOT INTENDED TO LIMIT PARKMATE'S
LIABILITY IN THE EVENT OF PARKMATE'S WILLFUL OR
INTENTIONAL MISCONDUCT.

11
10.0 NOTES

12

13

www.directed.com.au
www.directed.co.nz
V1.0
All Images, Information and Content are Copyright © 2020
Directed Electronics Australia Pty Ltd. All Rights Reserved.
www.parkmate.com.au | www.parkmatehd.co.nz
