Parkmate RVM-045DVRHD User manual

RVM-045DVRHD User Manual
4.5”REAR VIEW MIRROR MONITOR
WITH BUILT-IN FULL HD DASH CAM DVR

2
Thank you for purchasing Parkmate’s RVM-045DVRHD rear view mirror monitor with integrated
HD Dash Cam DVR. This state of the art Parkmate product is packed with features including a
front facing dash cam that can be coupled with an optional rear facing camera.
The DVR can record both video feeds simultaneously to capture incidents and accidents that
may happen in front of, or behind your vehicle. The RVM-045DVRHD will also automatically
display the rear view camera feed in your mirror monitor when reverse gear is selected.
This product uses the most advanced technology and components to provide you with a long
service life and integrates perfectly with the factory look of your vehicle to add a high level of
safety and security to your driving experience.
Please note: Although this product will allow you to view and record driving footage, and reduce
blind spots, it does not remove the responsibility of driving the vehicle from the driver. The legal
responsibility and safe driving practice remains with the driver at all times.
You have purchased this Parkmate product with the understanding that its use is intended as an
aid only. We highly recommend that you have this product professionally installed to ensure that it
will provide the functions it is set out to perform.

3
Table of contents
Chapter One: Product Introduction ..................................................................... 4
1.1 Product overview ............................................................................................................ 4
1.2 Package contents ............................................................................................................ 4
1.3 Product features .............................................................................................................. 4
1.4 Product specification ....................................................................................................... 4
1.5 Introduction to button functions........................................................................................ 5
1.6 Introduction to cables .................................................................................................. 5-6
1.7 Mounting bracket ..............................................................................................................6
Chapter Two : Product Installation ........................................................................7
2.1 How to install DVR rear view mirror................................................................................... 7
2.2 How to install (optional) rear view camera......................................................................... 8
Chapter Three: Basic Function ............................................................................. 9
3.1 Optional rear view camera................................................................................................ 9
3.2 Start-Up and Shut Down.................................................................................................. 9
3.3 Inserting a Micro SD Card ................................................................................................ 9
3.4 Removing the Micro SD Card ........................................................................................... 9
3.5 LED Indicator ................................................................................................................... 9
3.6 Remote Control.............................................................................................................. 10
Chapter Four: Adjust the settings....................................................................... 10
4.1 Using the menu.............................................................................................................. 10
4.2 Initial Settings ................................................................................................................. 11
4.2.1 Setting time & date................................................................................................ 11
4.2.2 Date Stamp (Video) ............................................................................................... 11
4.2.3 Plate Number & Video Stamp ................................................................................ 12
4.3 Video Screen.................................................................................................................. 12
Chapter Five: Video Menu ................................................................................... 13
5.1 Resolution ..................................................................................................................... 13
5.2 Dual Record ................................................................................................................... 13
5.3 Timelapse Record .......................................................................................................... 14
5.4 Motion Detection ........................................................................................................... 14
5.5 Gravity Sensing .............................................................................................................. 15
5.6 Parking Monitor...............................................................................................................15
5.7 Photo Screen ..................................................................................................................16
Chapter six: Photo Menu ..................................................................................... 16
6.1 Capture Mode.................................................................................................................16
6.2 Resolution .......................................................................................................................17
6.3 Sequence........................................................................................................................17
6.4 Anti-shaking ....................................................................................................................18
6.5 Date Stamp (photo).........................................................................................................18
6.6 Playback Screen .............................................................................................................19
Chapter Seven: Playback Menu.......................................................................... 19
7.1 Delete ....................................................................................................................... 19-20
7.2 Protect ............................................................................................................................20
7.3 Slideshow .......................................................................................................................21
Chapter Eight: Setting Menu............................................................................... 21
8.1 Date/Time .......................................................................................................................21
8.2 Format ............................................................................................................................22
8.3 Screen Saver...................................................................................................................22
8.4 Delayed Shut down.........................................................................................................23
8.5 Default Settings...............................................................................................................23
Chapter Nine: Menu ............................................................................................. 24
9.1 Video Menu.....................................................................................................................24
9.2 Photo Menu ....................................................................................................................25
9.3 Playback Menu ...............................................................................................................26
9.4 Settings Menu.................................................................................................................26

4
Chapter One: Product Introduction
1.1 Product Overview
Parkmate’s RVM-045DVRHD rear view mirror monitor with integrated HD Dash Cam DVR is an
invaluable accessory that not only acts as your eyewitness on the road, it also offers potentially
life saving safety features to protect you and your family.
This product is equipped with a 120° degree wide angle camera and the integrated DVR can
record high definition video and still images from two separate camera inputs simultaneously at
30 frames per second. The 4.5 inch screen automatically adjusts to ambient lighting conditions
and is equipped with a dedicated remote control for convenient operation. Also featuring
G-Sensor and Motion Detection automatically triggered recording, the RVM-045DVRHD is a
powerful, convenient and simple to use device that will enhance your driving experience.
1.2 Package Contents
Package contents:
• 1 x 4.5” Rear-view Mirror Monitor with integrated HD Dash Cam DVR
• 1 x Rear view camera connector
• 1 x Video extension cable
• 1 x Manual
• 1 x Remote Control
• 1 x Generic Mounting Bracket
1.3 Product Features
• Factory Replacement Mirror Monitor • 4.5” Colour LCD Mirror Monitor
• In-built Digital Video Recorder • In-built Full HD Front Camera
• Automatic Start Up Record & Shut Down • Time & Date Stamped Recorded Files
• Continuous Loop Recording • Reverse Camera Ready
• Park Mode Capable • G-sensor auto file save
• Motion detection • Single or Dual Camera Display & Record
1.4 Product Specifications
Micro SD Card 32GB (Class 6 or higher)
Image Sensor High Denition
Front Camera Image Quality Full HD (1920 x 1080)
Display Resolution 720 x 526
Memory Storage Micro SD Card
Focus Range 12m - Innite
Photo Format JPEG
Video format MOV
Audio Built In - Microphone & Speaker
Working temperature -20° - 70°C
Language English, Spanish, Dutch, Chinese , Korean, Japanese, Russian

5
1.5 Introduction to Button Function
1.6 Introduction to Cables
Rear Camera Recording Display
Front Camera Recording
Light Sensor
Indicator - Flashes when recording
Auto dimming LCD
Short press: on/off screen display
Long press: on/off DVR
The front camera records video and
still images in front of your car.
Rotation angle: X-150, Y-360, Z-150
Mounting Bracket
Wire Harness
Mounting Arm
Connects to ignition / 12v
Plug connects to rear view mirror
connects to the reverse light
ground
B+
Connects to the car 12v battery
connect extension
cable to either AV1
or AV2

6
1.7 Mounting Bracket/Arm
The RVM-045DVRHD comes with a generic mounting bracket suitable for most vehicles. If your
vehicle’s mounting plate is not compatible with the generic bracket provided, Parkmate has a
range of vehicle specific mounting brackets available at www.parkmate.com.au or from your
local Parkmate dealer.
FITTING VEHICLE SPECIFIC MOUNTING BRACKETS (sold separately)
1. Unscrew the screw on the underside of the attached bracket.
2. Remove the generic bracket from the mounting arm.
If your replacement bracket includes a mounting arm continue onto step 3.
If your replacement bracket DOES NOT include a mounting arm please go to step 6.
Please note that this step is only required if the replacement
bracket includes a mounting arm.
3. Remove the screw from the barrel of the mounting arm by inserting
a Philips head screwdriver into the opening at the base of the arm
and unscrewing the screw securing the mounting arm to the mirror
monitor’s ball joint.
Please note that this step is only required if the replacement
bracket includes a mounting arm.
4. Remove the mounting arm from the mirror monitor’s ball joint.
Please note that this step is only required if the replacement
bracket includes a mounting arm.
5. Insert the replacement arm and fix to the mirror monitor’s ball joint
using the included screw.
6. Fix your replacement bracket to the mounting arm using the included
screw.
Rear view camera connector
(plug into extension cable)
To rear camera
connects to the reverse light
Extension Cable

7
Chapter Two: Product Installation
2.1 How to Install RVM-045DVRHD Rear View Mirror
Different vehicles use different mounting brackets depending on the manufacturer.
Note: While the mirror in some vehicles is easy to remove, in some it may be a difficult process.
If you find it difficult to remove your factory installed rear-view mirror, please do not force it as you
could break your windscreen. In the case of difficult mirror removal, we recommend you seek a
professional to dismantle the original rear view mirror.
Line up the mounting bracket
with the universal mount
Insert the bracket into the top of the Slide the bracket into position in the
mount aligning both edges direction specified
Fix the bracket in place by tightening
the screw in the direction specified
with a hex/allen key
It is highly recommended that you seek the professional help of an auto installer before removing
your original windscreen mirror base and fitting the RVM-045DVRHD.
Original Mirror
1
Base on windsheild
2

8
2.2 How to install the (optional) rear view camera
The rear view camera is usually installed above the middle of the license plate frame.
If your vehicle does not already have a
reverse camera installed it is recommended
you install a camera above the rear number
plate as close to the centre of the vehicle as possible. Installing a rear camera will allow for both
front and rear simultaneous recording and rear view blind spot viewing when the reverse gear is
selected. The optional rear view camera is sold separately.
If you install an optional rear view camera, please ensure
you select a high quality camera as it will be functional at
all times while the vehicle is operational and recording to
the DVR. We also recommend you select a wide angle
camera that clearly captures both rear view traffic and
reverse parking viewing angles. To view the complete
range of Parkmate rear view cameras, visit
www.parkmate.com.au
DVR rear view
mirror monitor
1. Tuck the RVM-045DVRHD’s cable
into your vehicle’s headliner.
5. Carefully remove the clips from
your vehicles pillar panel.
9. To install a rear view camera,
connect the extension cable the
wire harness.
13. Run the rear camera to the
desired installation location.
11. Run the extension cable to the
rear of your vehicle.
2. Connect the included wire
harness to the RVM-045DVRHD.
6. Run the cable along the roof and
down the pillar replacing the liner
and panel.
10. Unclip and lift your vehicle’s
floor liner.
14. Install the camera following the
rear view camera instructions.
12. Connect your rear view camera
(not included) to the extension
cable.
3. Ensure that the connection is
secure.
7. Run the cable to your vehicle’s
internal fuse box.
4. Carefully remove the clips from
your vehicle’s headliner..
8. Connect the red wire to the 12V
ignition power, and the yellow
cable to the 12V Battery power.
Cable Extension cable Rearview camera connector
(to optional camera)
Rear view Mirror Monitor
General Installation location
Camera (Not Included)

9
Chapter Three: Functions
3.1 Optional Rear View Camera
When you select reverse gear, the rear-view monitor will automatically display the (optional)
reverse camera.
3.2 Start-Up & Shut Down
Once your vehicle has powered up, your mirror monitor will start-up within 3 seconds and the
DVR (digital video recorder) will automatically start recording.
Once your vehicle is powered off, your rear view mirror will shut-down within 12 seconds.
While your vehicle is powered, you can turn off the screen by pressing the power button in the
centre bottom of the mirror or press it again to turn the screen back on.
3.3 Inserting a Micro SD Card
With the mirrored face of the monitor facing toward you insert the memory card into the slot on
the top of the Rear-view Mirror DVR with the text on the Micro SD Card facing away from you.
Using the edge of your fingernail push the Micro SD Card down until a click sound is heard and
the Micro SD card locks into place.
Please Note:
• It is recommended that you format your Micro SD
Card before use.
• The optimum Micro SD Card class and capacity is
Class 6 or higher, class 10 recommended, 32GB.
• Using Micro SD Cards with a lower class number or
higher capacity will affect the quality of the recordings.
3.4 Removing the Micro SD Card
Using the edge of your fingernail push the Micro SD Card down until a click sound is heard and
the Micro SD card ejects.
Please note:
• Do not remove or insert a memory card while the RVM-045DVRHD is powered on. This may
damage the memory card or the stored files.
• Please format the Micro SD card before initial use.
• When removing the memory card, be careful as the card may eject quickly.
3.5 LED Indicator
The LED indicator on the front of the Rear-view DVR gives indication of
operation even when the monitor is in sleep mode. While recording the
LED indicator will blink red.
Not in reverse In reverse

10
3.6 Remote Control
The included remote control can be used to navigate the menus and settings, cycle through the
rear-view mirror DVR’s modes, view videos and photos, and manually trigger recordings and
photos.
Chapter Four: Adjust the Settings
4.1 Using the Menu
You can customise the settings of your RVM-045DVRHD by using the included remote
control.
To use the controller to customise settings:
1. Activate your car’s ACC power, the RVM-045DVRHD should automatically power up and
start recording.
2. Press the button on the remote control to stop recording.
3. Use the button to cycle through the modes (VIDEO, PHOTO, PLAYBACK). Each
mode has its own menu which is accessed by pressing the button in the corresponding
mode.
4. When in the VIDEO, PHOTO, and PLAYBACK menus the general SETTINGS menu can
be accessed by pressing the button again. Pressing the button in the SETTINGS
menu will exit the menu screen.
5. Use the and buttons on the remote control to navigate the menu and the
button is used to select and confirm.
Please note:
• The RVM-045DVRHD will not let you enter the menu while the device is recording. Please make
sure recording is stopped by pressing the button before attempting to enter the VIDEO menu.
• Only the buttons outlined above are used to operate the RVM-045DVRHD. The menu cannot be
navigated using the arrow buttons.
• The optimum operating distance for the remote control is 1 metre, when altering the menus ensure
that the remote control is pointed towards the IR sensor and is a reasonable distance from the
device.
• DO NOT attempt to modify the settings of this device while you are driving. When using this device
please keep in mind your local road laws.
Select/Record
Menu Up
Enter Menu
Menu Down
Cycle through Modes
Power

11
4.2 Initial Settings
Before using the RVM-045DVRHD it is recommended that you enable the DATE STAMP and
PLATE NUMBER.
4.2.1 Setting the Time & Date
Once set, the time and date can then be stamped onto Videos and photos.
To set the internal clock on the RVM-045DVRHD please follow the instructions below.
1. Ensure that the Rear-view Mirror DVR is not recording and press the button to enter
the VIDEO menu and then press the button again to enter the SETTING menu.
2. Use the and buttons on the
remote control to highlight the DATE/TIME
setting and press to enter the date
and time entry screen.
3. Use the and buttons to change
the highlighted number, and press to
confirm and proceed to the next number.
4. The final customisable field is the date
format which you can change using the
and buttons.
5. Pressing after selecting your
preferred date format will return you to the
setting menu.
Please Note:
• Setting the time will not automatically stamp the time on the footage. To stamp the time and date on
the footage please follow the instructions outlined in the DATE STAMP (VIDEO) section.
• The RVM-045DVRHD will not let you enter the menu while the device is recording. Please make
sure recording is stopped by pressing the button before attempting to enter the VIDEO menu.
4.2.2 Date Stamp
To stamp your recorded videos with the time and date please follow the instructions below.
1. Using the button select the VIDEO mode (the VIDEO icon will be displayed in
the top left corner) and make sure the RVM-045DVRHD is not currently recording.
2. Press the button to enter the VIDEO menu.
3. Use the and buttons to highlight
DATE STAMP and press to enter the
date stamp menu
4. Select ON and press to confirm. You
will now be returned to the VIDEO menu.
Please Note:
• If you decide that you no longer want to have the date stamped onto your footage you can remove
this by entering the DATE STAMP menu and selecting OFF.
• The RVM-045DVRHD will not let you enter the menu while the device is recording. Please make
sure recording is stopped by pressing the button before attempting to enter the VIDEO menu.

12
4.2.3 Plate Number and Video Stamp
To set your vehicles’ number plate and have it appear on your recorded videos please follow
the instructions below.
1. Ensure that your rear-view mirror monitor is in video mode. To select video mode use the
button the VIDEO mode (the VIDEO icon will be displayed in the top left corner)
and make sure the RVM-045DVRHD is not currently recording.
2. Press the button to enter the VIDEO menu.
3. Use the and buttons to highlight the PLATE NUMBER setting.
4. Press to enter the PLATE NUMBER menu. Highlight ON and press to enter the
plate entry screen.
5. Use the and buttons to cycle
through the characters and press to
confirm and move to the next character.
6. After entering the final character pressing
one last time will return you to the VIDEO
menu
Please Note:
• When entering your plate number you can exit the entry screen by pressing the button.
• If you decide that you no longer want to have your plate number stamped into your footage you can
remove this by entering the PLATE NUMBER menu and selecting OFF.
• The RVM-045DVRHD will not let you enter the menu while the device is recording. Please make
sure recording is stopped by pressing the button before attempting to enter the VIDEO menu.
4.3 Video Screen
The VIDEO Screen is the default screen when starting up your RVM-045DVRHD and
displays the footage being recorded while driving.
While in this screen the button on the remote control is used to cycle through the
display modes of the DVR image and the image from an optional installed reverse camera
(not included).
The available modes are:
• Picture in picture (DVR large image, Reverse camera small image).
• DVR full screen.
• Picture in picture (Reverse camera large image, DVR small image).
• Reverse camera full screen.
While recording the current recording file can be protected from being recorded over by
pressing the button. When the RVM-045DVRHD is not recording the button can
be used to enter the VIDEO menu.
1. Mode (VIDEO) 9. Number Plate
2. Loop Duration 10. Recording Time/Date
3. Exposure 11. Resolution
4. Motion Detection 12. Recording Duration
5. Time Lapse 13. Parking Monitor
6. Mute/Un-mute Recording 14. Micro SD Card
7. High Dynamic Range 15. Power
8. Gravity Sensor
To cycle through PHOTO, and PLAYBACK
mode ensure that you are not recording and
press the button on the remote control.

13
Chapter Five: Video Menu
5.1 Resolution
Your selected resolution will determine the quality and size of your recordings. Higher quality
recordings will produce larger file sizes.
To change your resolution:
1. Using the button select the VIDEO mode ( VIDEO icon will be displayed in the top
left corner) and make sure the RVM-045DVRHD is not currently recording.
2. Press the button to enter the VIDEO menu.
3. Use the and buttons to highlight
the RESOLUTION setting, then press the
button.
4. Use the and buttons to select
your required resolution and then press
to confirm.
5. You will now be returned to the VIDEO
menu.
Please Note:
• The RVM-045DVRHD will not let you enter the menu while the device is recording. Please make
sure recording is stopped by pressing the button before attempting to enter the VIDEO menu
• It is recommended that you use a higher resolution setting to make sure you capture as much detail
as possible in the case of an incident.
5.2 Dual Record
DUAL RECORD allows you to activate and deactivate rear view recording simultaneously
with the front facing camera.
To activate Dual Recording:
1. Using the button select the VIDEO mode ( VIDEO icon will be displayed in the
top left corner) and make sure the RVM-045DVRHD is not currently recording.
2. Press the button to enter the VIDEO menu.
3. Use the and buttons to highlight
the DUAL RECORD setting, then press
the button.
4. Use the and buttons to select
OFF or ON and then press to confirm.
5. You will now be returned to the VIDEO
menu.
Please Note:
• The RVM-045DVRHD will not let you enter the menu while the device is recording. Please make
sure recording is stopped by pressing the button before attempting to enter the VIDEO menu.
• The RVM-045DVRHD does not include a reverse camera. To buy a Parkmate reverse camera
please visit www.parkmate.com.au or contact your local Parkmate dealer.

14
5.3 Loop Recording
Looping footage will record over the oldest video clip allowing you to keep recording when
the memory card is full. The Loop Record setting allows you to set the length of the clip.
To set Loop Record:
1. Using the button select the VIDEO mode ( VIDEO icon will be displayed in the
top left corner) and make sure the RVM-045DVRHD is not currently recording.
2. Press the button to enter the VIDEO menu.
3. Use the and buttons to highlight the
LOOP RECORDING setting, then press the
button.
4. Use the and buttons to select the
required recording duration and then press
to confirm.
5. You will now be returned to the VIDEO menu.
Please note:
• The RVM-045DVRHD will not let you enter the menu while the device is recording. Please make
sure recording is stopped by pressing the button before attempting to enter the VIDEO menu.
• Longer video loops will result in larger file sizes.
5.4 Motion Detection
Motion detection scans your camera’s field of view for movement, and when it is detected
that there is no movement in front of the camera the RVM-045DVRHD will enter standby
mode.
To activate Motion Detection:
1. Using the button select the VIDEO mode ( VIDEO icon will be displayed in the
top left corner) and make sure the RVM-045DVRHD is not currently recording.
2. Press the button to enter the VIDEO menu.
3. Use the and buttons to highlight the
MOTION DETECTION setting, then press
the button.
4. Use the and buttons to select OFF
or ON and then press to confirm.
5. You will now be returned to the VIDEO
menu.
Please note:
• The RVM-045DVRHD will not let you enter the menu while the device is recording. Please make
sure recording is stopped by pressing the button before attempting to enter the VIDEO menu.
• When motion is detected the RVM-045DVRHD takes a few moments to start recording which may
result in the first moments of activity being missed.

15
5.5 Gravity Sensing (G-Sensor)
The Gravity Sensor detects vibration that could potentially be an impact to your vehicle. The
GRAVITY SENSOR setting is used to determine the required vibration to activate the RVM-
045DVRHD’s protect function. When this function is activated the current recording will be
protected from being deleted or recorded over. When a recording is protected the icon
will appear on screen while the camera is recording.
To set Gravity Sensing:
1. Using the button select the VIDEO mode ( VIDEO icon will be displayed in the top
left corner) and make sure the RVM-045DVRHD is not currently recording.
2. Press the button to enter the VIDEO menu.
3. Use the and buttons to highlight
the GRAVITY SENSING setting, then
press the button.
4. Use the and buttons to select
your required sensitivity and then press
to confirm.
5. You will now be returned to the VIDEO
menu.
Please note:
• The RVM-045DVRHD will not let you enter the menu while the device is recording. Please make
sure recording is stopped by pressing the button before attempting to enter the VIDEO menu.
• The PROTECT function will only lock the recording that in progress when an impact is detected. If it
is required that the footage following the impact also needs to be locked this footage will need to be
manually locked by pressing the button on the remote control.
5.6 Parking Monitor
When activated the PARKING MONITOR will detect any impacts to your vehicle and trigger
a recording after you have parked and powered off your vehicle.
To enable Parking Monitor:
1. Using the button select the VIDEO mode ( VIDEO icon will be displayed in the top
left corner) and make sure the RVM-045DVRHD is not currently recording.
2. Press the button to enter the VIDEO menu.
3. Use the and buttons to highlight
the PARKING MONITOR setting, then
press the button.
4. Use the and buttons to select
OFF or ON and then press to confirm.
5. You will now be returned to the VIDEO
menu.
Please note:
• The RVM-045DVRHD will not let you enter the menu while the device is recording. Please make
sure recording is stopped by pressing the button before attempting to enter the VIDEO menu.
• The PROTECT function will only lock the recording that in progress when an impact is detected. If it
is required that the footage following the impact also needs to be locked this footage will need to be
manually locked by pressing the button on the remote control.

16
5.7 Photo Screen
The PHOTO screen can be used to capture still images from the RVM-045DVRHD’s
camera.
To trigger a photo press the button on the remote control.
While in photo mode the and buttons can be used to zoom in and out.
The PHOTO menu can be accessed by pressing the button.
1. Mode (PHOTO)
2. Exposure
3. White Balance
4. ISO
5. Quality
6. Capture Mode (Timer)
7. Anti Shaking
8. Sequence
9. Micro SD Card
10. Power
To cycle through VIDEO, and PLAYBACK mode ensure that you are not recording and
press the button on the remote control.
Chapter Six: Photo Menu
6.1 Capture Mode
The CAPTURE MODE setting is used to set the delay timer for taking a photo.
When a timer is set the RVM-045DVRHD will hold for the specified time after the photo is
triggered before activating the shutter.
To set photo timer:
1. Using the button select the PHOTO mode ( PHOTO icon will be displayed in the
top left corner).
2. Press the button to enter the PHOTO menu.
3. Use the and buttons to highlight the
CAPTURE MODE setting, then press the
button.
4. Use the and buttons to select your
required timer delay and then press to
confirm.
5. You will now be returned to the PHOTO
menu.
Please note:
• To access the PHOTO menu the RVM-045DVRHD needs to be in PHOTO mode when the
button is pressed.

17
6.2 Photo Resolution
Your selected resolution will determine the quality and size of your photos. Higher quality
photos will produce larger file sizes.
To change the resolution size:
1. Using the button select the PHOTO mode ( PHOTO icon will be displayed in the
top left corner).
2. Press the button to enter the PHOTO menu.
3. Use the and buttons to highlight
the RESOLUTION setting, then press the
button.
4. Use the and buttons to select your
required resolution and then press to
confirm.
5. You will now be returned to the PHOTO
menu.
Please note:
• To access the PHOTO menu the RVM-045DVRHD needs to be in PHOTO mode when the
button is pressed.
• It is recommended that you use a higher resolution setting to make sure you capture as much detail
as possible in the case of an event.
6.3 Sequence
The SEQUENCE setting is used to take a series of three photos when the camera is
triggered.
To activate the sequence mode:
1. Using the button select the PHOTO mode ( PHOTO icon will be displayed in the
top left corner).
2. Press the button to enter the PHOTO menu.
3. Use the and buttons highlight
the SEQUENCE setting then press the
button.
4. Use the and buttons to select OFF
or ON and then press to confirm.
5. You will now be returned to the PHOTO
menu.
Please note:
• To access the PHOTO menu the RVM-045DVRHD needs to be in PHOTO mode when the
button is pressed.

18
6.4 Anti-shaking
The ANTISHAKING setting is used to stabilise the image sensor when you are taking a
photo reducing motion blur caused by the camera shaking.
To activate Anti-shaking mode:
1. Using the button select the PHOTO mode ( PHOTO icon will be displayed in the
top left corner).
2. Press the button to enter the PHOTO menu.
3. Use the and buttons highlight the
ANTISHAKING setting then press the
button.
4. Use the and buttons to select OFF
or ON and then press to confirm.
5. You will now be returned to the PHOTO
menu.
Please note:
• To access the PHOTO menu the RVM-045DVRHD needs to be in PHOTO mode when the
button is pressed.
6.5 Date Stamp (Photo)
A time and date stamp can be added to the produced photos by enabling the DATE
STAMP setting.
To activate Date Stamp:
1. Using the button select the PHOTO mode ( PHOTO icon will be displayed in the
top left corner).
2. Press the button to enter the PHOTO menu.
3. Use the and buttons to highlight the
DATE STAMP setting then press .
4. Use the and buttons to select OFF,
DATE or DATE/TIME and then press to
confirm.
5. You will now be returned to the PHOTO
menu.
Please note:
• To access the PHOTO menu the RVM-045DVRHD needs to be in PHOTO mode when the
button is pressed.
• The time and date cannot be set in this setting. To set the time and date use the DATE/TIME setting
in the SETTINGS menu.

19
6.6 Playback Screen
The PLAYBACK screen is used to review and delete photos and videos.
Playback controls:
• In this screen the and buttons are used to navigate through the stored videos and
photos on the inserted Micro SD Card.
• Videos can be played by highlighting a video and pressing the button.
Video controls
• The controls below can be used while a video is being played on the RVM-045DVRHD.
• The button is used to stop a video while it is playing.
• The button is used to pause a video while it is playing.
• The and buttons can be used to fast forward and rewind a video while it is
playing.
1. Mode (PLAYBACK)
2. Play
3. Stop
4. Rewind
5. Fast Forward
6. Duration
7. File Name
8. Resolution
9. Power
To cycle through VIDEO, PHOTO and PLAYBACK modes ensure that you are not recording
and press the button on the remote control.
Chapter Seven: Playback Menu
7.1 Delete
The DELETE menu is used to delete the selected file or all unprotected files.
To Delete one file:
1. Using the button select the PLAYBACK mode ( PLAYBACK icon will be
displayed in the top left corner).
2. Use the and buttons to highlight the photo or video you would like to delete.
3. Press the button to enter the PLAYBACK menu.
4. Use the and buttons to highlight
the DELETE setting and press the
button to confirm.
5. Use the and buttons to select
DELETE CURRENT and press the
button to confirm.
6. The selected file will now be deleted and
you will be returned to the PLAYBACK
menu.
To Delete all unlocked files :
1. Using the button select the PLAYBACK mode ( PLAYBACK icon will be
displayed in the top left corner).
2. Press the button to enter the PLAYBACK menu.
