Introduction
Package Contents
Note
Please make sure the following items are included with your monitor.
If any items are missing, contact your dealer.
Contact a local dealer to buy optional items.
Unpacking
Type 1
Monitor and HAS stand
Type 2
Monitor and HAS-USB stand
Type 3
Monitor and Simple stand
Type 4

Monitor and Simple-USB stand
Note
MagicRotation program can not be provided as Simple Stand does not support Pivot function.
List of Parts
Quick Setup Guide Warranty Card
(Not available in all loca-
tions)
User's Guide
D-Sub Cable Power Cord
Option
USB Cable Cable holding ring
Sold separately
DVI Cable Stereo Cable HDMI Cable
Headphones
Introduction

Note
• USB cable is only provided when the stand type is HAS-USB or SIMPLE-USB.
• Cable holding ring is only provided when the stand type is SIMPLE or SIMPLE-USB.
Your Monitor
Initial Settings
Select the language using the up or down key.
The displayed content will disappear after 40 seconds.
Turn the power button off and on. It will be displayed again.
It can be displayed up to three (3) times. Make sure to adjust the resolution of your PC before
reaching the maximum count.
Note
The resolution displayed on the screen is the optimal resolution for this product.
Adjust your PC resolution so that it is the same as the optimal resolution for this product.
Front
Note
Touch them lightly with your fingers to use them.
Introduction

MENU button [MENU/ ]
Opens the on-screen menu and exits from the menu. Also use to exit the
OSD menu or return to the previous menu.
Customized Key
You can customize key assignment for the Custom button according to
your preferences.
Note
You can configure the Customized key for a required function via Setup >
Customized Key.
Volume button
When OSD is not on the screen, push the button to adjust volume.
>> Click here to see an animation clip
Adjust buttons [ ]
Adjust items in the menu.
Enter button [ ] / SOURCE button
Activates a highlighted menu item.
Push the ' /SOURCE', then selects the video signal while the OSD is off.
(When the /SOURCE button is pressed to change the input mode, a
message appears in the upper left of the screen displaying the current
mode -- analog or digital input signal.).
Note
If you select the digital mode, you must connect your monitor to the graphic
card's DVI port using the DVI cable.
>> Click here to see an animation clip
AUTO button
Use this button for auto adjustment.
>> Click here to see an animation clip
Power button [ ]
Use this button for turning the product on and off.
Power Indicator
This light is lit when operating normally, and blinks once when your ad-
justments are saved.
Note
See PowerSaver described in the manual for further information regarding
power saving functions. For energy conservation, turn your monitor OFF
when it is not needed or when leaving it unattended for long periods.
Speaker
You can hear sound by connecting the soundcard of your PC to the mon-
itor.
Introduction

Rear
Note
The configuration at the back of the monitor may vary from product to product.
POWER S/W / POWER
POWER S/W
Switch the product on and off.
POWER
Connect the power cord for your monitor to
the POWER port on the back of the product.
HDMI IN / DVI IN(HDCP) /
RGB IN
HDMI IN
Connect the HDMI IN terminal at the back of
your product to the HDMI terminal of your
digital output device using a HDMI cable.
DVI IN(HDCP)
Connect the DVI cable to the DVI IN
(HDCP) port on the back of your product.
RGB IN
Connect the RGB IN terminal at the back of
your product to your computer.
AUDIO IN / AUDIO OUT
Introduction

AUDIO IN
Connect the audio cable for your product to
the audio port on the back of your computer.
AUDIO OUT
Headphone output terminal
USB connection ter-
minal (Option)
UP (USB upstream port)
Connect the UP port of the product and
the USB port of the computer with the USB
cable.
DOWN (USB downstream port)
Connect the
DOWN port of the USB
product and a USB device with the USB ca-
ble.
Note
To use DOWN (Downstream Port), you
have to connect the UP (Upstream Ca-
ble ) to the PC.
Make sure to use the USB cable supplied
with this product to connect the product's
UP port and your computer's USB port.
Kensington Lock
The Kensington lock is a device used to
physically fix the system when using it in a
public place.
(The locking device has to be purchased
separately.)
Note
For using a locking device, contact where
you purchase it.
Stand Stopper (Only ap-
plied to HAS or HAS-USB
type stand.)
Introduction

Remove the fixing pin on the stand to lift the
product up and down.
Note
See Connecting Cables for further information regarding cable connections.
Package Contents
Note
Please make sure the following items are included with your monitor.
If any items are missing, contact your dealer.
Contact a local dealer to buy optional items.
Unpacking
Type 1
Monitor and HAS stand
Type 2
Monitor and HAS-USB stand
Type 3
Introduction

Monitor and Simple stand
Type 4
Monitor and Simple-USB stand
Note
MagicRotation program can not be provided as Simple Stand does not support Pivot function.
List of Parts
Quick Setup Guide Warranty Card
(Not available in all loca-
tions)
User's Guide
D-Sub Cable Power Cord
Option
USB Cable Cable holding ring Cleaning Cloth
Introduction

Sold separately
DVI Cable Stereo Cable HDMI Cable
Headphones
Note
• USB cable is only provided when the stand type is HAS-USB or SIMPLE-USB.
• Cable holding ring is only provided when the stand type is SIMPLE or SIMPLE-USB.
• Cleaning Cloth is only provided for highly polished black products as a product feature.
Your Monitor
Initial Settings
Select the language using the up or down key.
The displayed content will disappear after 40 seconds.
Turn the power button off and on. It will be displayed again.
It can be displayed up to three (3) times. Make sure to adjust the resolution of your PC before
reaching the maximum count.
Note
The resolution displayed on the screen is the optimal resolution for this product.
Adjust your PC resolution so that it is the same as the optimal resolution for this product.
Introduction

Front
Note
Touch them lightly with your fingers to use them.
MENU button [MENU/ ]
Opens the on-screen menu and exits from the menu. Also use to exit the
OSD menu or return to the previous menu.
Customized Key
You can customize key assignment for the Custom button according to
your preferences.
Note
You can configure the Customized key for a required function via Setup >
Customized Key.
Volume button
When OSD is not on the screen, push the button to adjust volume.
>> Click here to see an animation clip
Adjust buttons [ ]
Adjust items in the menu.
Enter button [ ] / SOURCE button
Activates a highlighted menu item.
Push the ' /SOURCE', then selects the video signal while the OSD is off.
(When the /SOURCE button is pressed to change the input mode, a
message appears in the upper left of the screen displaying the current
mode -- analog or digital input signal.).
Introduction

Note
If you select the digital mode, you must connect your monitor to the graphic
card's DVI port using the DVI cable.
>> Click here to see an animation clip
AUTO button
Use this button for auto adjustment.
>> Click here to see an animation clip
Power button [ ]
Use this button for turning the product on and off.
Power Indicator
This light is lit when operating normally, and blinks once when your ad-
justments are saved.
Note
See PowerSaver described in the manual for further information regarding
power saving functions. For energy conservation, turn your monitor OFF
when it is not needed or when leaving it unattended for long periods.
Speaker
You can hear sound by connecting the soundcard of your PC to the mon-
itor.
Rear
Note
The configuration at the back of the monitor may vary from product to product.
POWER S/W / POWER
Introduction

POWER S/W
Switch the product on and off.
POWER
Connect the power cord for your monitor to
the POWER port on the back of the product.
HDMI IN / DVI IN(HDCP) /
RGB IN
HDMI IN
Connect the HDMI IN terminal at the back of
your product to the HDMI terminal of your
digital output device using a HDMI cable.
DVI IN(HDCP)
Connect the DVI cable to the DVI IN
(HDCP) port on the back of your product.
RGB IN
Connect the RGB IN terminal at the back of
your product to your computer.
AUDIO IN / AUDIO OUT
AUDIO IN
Connect the audio cable for your product to
the audio port on the back of your computer.
AUDIO OUT
Headphone output terminal
USB connection ter-
minal (Option)
UP (USB upstream port)
Connect the UP port of the product and
the USB port of the computer with the USB
cable.
DOWN (USB downstream port)
Connect the
DOWN port of the USB
product and a USB device with the USB ca-
ble.
Introduction

Note
To use DOWN (Downstream Port), you
have to connect the UP (Upstream Ca-
ble ) to the PC.
Make sure to use the USB cable supplied
with this product to connect the product's
UP port and your computer's USB port.
Kensington Lock
The Kensington lock is a device used to
physically fix the system when using it in a
public place.
(The locking device has to be purchased
separately.)
Note
For using a locking device, contact where
you purchase it.
Stand Stopper (Only ap-
plied to HAS or HAS-USB
type stand.)
Remove the fixing pin on the stand to lift the
product up and down.
Note
See Connecting Cables for further information regarding cable connections.
Introduction

Connections
Connecting Cables
Connect the power cord for your monitor to the POWER port on the back
of the monitor.
Plug the power cord for the monitor into a nearby outlet.
Use a connection appropriate for your computer.
Using the D-sub (Analog) connector on the video card.
• Connect the signal cable to the 15-pin, D-sub port on the back of your
monitor.
[RGB IN]
Using the DVI (Digital) connector on the video card.
• Connect the DVI Cable to the DVI IN(HDCP) Port on the back of your
Monitor.
[DVI IN(HDCP)]
Connected to a Macintosh.
• Connect the monitor to the Macintosh computer using the D-sub con-
nection cable.
Connect the AUDIO IN terminal of the monitor and the speaker output
terminal of your computer's sound card using a stereo cable (sold sepa-
rately).
Note
If the monitor and the computer are connected, you can turn them on and use them.
Connecting HDMI
Note
You can connect digital output devices to your monitor.
You can enjoy better screen and sound quality.

Connecting Using a HDMI Cable
1. Input devices such as digital DVD are connected to the HDMI IN terminal of the monitor
using the HDMI cable. When all the connections are completed, connect the power cords
for the monitor and DVD (or the device connected to the digital output terminal).
Select HDMI using the SOURCE button.
Connecting Using a DVI to HDMI Cable
1. Connect the DVI output terminal of a digital output device to the HDMI IN terminal of the
monitor using a DVI to HDMI cable.
2. Connect the red and white jacks of an stereo cable to the same colored audio output
terminals of the digital output device, and connect the opposite jack to the AUDIO IN
terminal of the monitor.
3. When all the connections are completed, connect the power cords for the monitor and
DVD (or the device connected to the digital output terminal).
4. Selet HDMI using the SOURCE button.
Note
If you just connect using the DVI to HDMI cable without connecting to the sound source, you
cannot hear sound.
Connections

Connecting USB (Option)
Note
You can use a USB device such as a mouse, keyboard, Memory Stick, or external hard disk
drive by connecting them to the DOWN port of the monitor without connecting them to
the PC.
The USB port of the monitor supports High-Speed Certified USB 2.0.
High speed Full speed Low speed
Data Rate 480 Mbps 12 Mbps 1.5 Mbps
Power Consump-
tion
2.5 W
(Max., each port)
2.5 W
(Max., each port)
2.5 W
(Max., each port)
1. Connect the
UP port of the monitor and the USB port of the computer with the USB
cable.
Note
To use DOWN port, you have to connect the UP (Upstream Cable) to the PC.
Make sure to use the USB cable supplied with this monitor to connect the monitor's
UP port and your computer's USB port.
2. Connect the
DOWN port of the USB monitor and a USB device with the USB cable.
3. The use procedures are as the same as those for using an external device connecting
to the PC.
• You can connect and use a keyboard and mouse.
Connections

• You can play a file from a media device.
(Examples of media devices: MP3, digital camera, etc.)
• You can run, move, copy or delete the files on the storage device.
(Examples of storage devices: external memory, memory card, memory reader,
HDD-type MP3 player, etc.)
• You can use other USB devices that can be connected to a computer.
Note
When connecting a device to the DOWN port of the monitor, connect the device
using a cable appropriate to the device.
(For the purchase of the cable and external devices, ask the service center of the cor-
responding product.)
The company is not liable for problems or damages to an external device caused by
using an unauthorized cable for the connection.
Some products do not follow the USB standard, and it may cause a malfunction of the
device.
If the device malfunctions even if it is connected to the computer, contact the service
center of the device/computer.
Connecting Headphone
Note
You may connect your headphones to the monitor.
1. Connect your headphones to the Headphone connection terminal.
Using the Stand
Monitor Assembly (Simple stand/Simple-USB stand)
Connections

HAS Stand / HAS USB Stand
Stand Stopper
Note
When rotating the monitor screen, you should lift it to the maximum height of the stand and
then lean the top backwards.
Otherwise, the corners of the monitor screen may come into contact with the floor and become
damaged.
Swivel stand
Using ( ), You can swivel the monitor left and right at an angle of 350° to set the monitor
lengthwise. The rubber under the stand is to avoid the monitor slide.
When you try to rotate the monitor in the state of the power cord or cable connecting to the
monitor, the power cord of cable can be destroyed.
Connections

Tilt angle
HAS Stand / HAS USB Stand :
Using ( ), You can adjust the tilt angle within a range of -5° forward to 25° backward for the
most comfortable viewing angle.
Simple stand/Simple-USB stand :
Using ( ), You can adjust the tilt angle within a range of 0° forward to 23° backward for the
most comfortable viewing angle.
Attaching a Base
This monitor accepts a 200 mm x 100 mm VESA-compliant mounting interface pad.
Connections
