Parks HP2000 XTREME Series Setup guide

2 | Page

Table of Contents:
Trademarks and Exclusion for Documentation..............................................................................5
Revision, Manual, and Contact Information..................................................................................6
Introduction.................................................................................................................................7
Warranty and Registration............................................................................................................8
Manual Overview........................................................................................................................12
Safety..........................................................................................................................................13
10-Step Installation.....................................................................................................................17
Required Tools Checklist.............................................................................................................18
Step 1: Mounting the APU...........................................................................................................19
Step 2: Evaporator System and Duct Hoses.................................................................................20
Step 3: A/C Line Installation........................................................................................................22
Step 4: A/C System Vacuum and Charge......................................................................................23
Step 5: Fuel Draw Tube Installation.............................................................................................24
Step 6: Connecting Battery Cables...............................................................................................26
Step 7: Water Connections..........................................................................................................27
Step 8: Controller And Ductwork Installation..............................................................................30
Step 9: System Prime and Safety Check.......................................................................................33
Step 10: Initial Start....................................................................................................................34
System Components...................................................................................................................35
3 | Page

APU Commander.........................................................................................................................38
Troubleshooting with the Controller...........................................................................................46
Maintenance...............................................................................................................................48
Maintenance Schedule................................................................................................................49
A/C System Maintenance............................................................................................................51
Fuse Box Location.......................................................................................................................52
Owner’s Responsibility................................................................................................................53
Specifications..............................................................................................................................55
Warranty Registration Card.........................................................................................................56
Installation, Service, and Operator’s Manual Form......................................................................57
Other Provisions.........................................................................................................................58
Warranty Coverage Table............................................................................................................59
Perkins Engine Coverage.............................................................................................................60
HP2000 APU Scale.......................................................................................................................61
2-Cyl. Perkins Cross References...................................................................................................62
A/C Components Diagram...........................................................................................................63
Maintenance Components Diagram............................................................................................64
Component Notes.......................................................................................................................65
Contact Information....................................................................................................................66
4 | Page

Trademarks
HP2000TM HP2000 XtremeTM
Exclusion for Documentation
Unless specifically agreed to in writing, Parks Industries L.L.C.
(A) Makes no warranty as to the accuracy, sufficiency or suitability of any technical or
other information provided in its manuals or other documentation.
(B) Assumes no responsibility or liability for injury, losses, damages, costs or expenses,
whether special, direct, indirect, consequential or incidental, which might arise out of
the use of such information. The use of any such information will be entirely at the
user’s risk.
5 | Page

Revision information
Rev G, February, 2021
Manual Product Number
PCM002-01
Contact Information
15460 CRABTREE SCHOOL RD.
MARION, IL 62959
OFFICE PHONE  : 618-997-9608
OFFICE FAX  : 618-997-9608
https://www.hp2000apu.com
6 | Page

INTRODUCTION
Congratulations on your purchase of your new HP2000 / HP2000 Xtreme  Series Auxiliary Power Unit! Your
fuel and maintenance savings begin today! As you may already know, the HP2000 consists of a powerful, yet
lean, 2-Cyl. Perkins Tier 4 Final California Compliant Diesel Engine along with our patented heat-pump
system to keep you warm, cool and powered up!
7 | Page

WARRANTY AND REGISTRATION
A/C COMPONENT WARRANTY: Each HP2000 APU purchased comes with a 2 Year / 2,000 Hours
limited express warranty from Parks Industries LLC, unless otherwise specified on the purchase
invoice.
PERKINS ENGINE WARRANTY: Perkins gives you a 2 Year / 2,000 Hour limited express warranty on
the engine unless otherwise specified on the purchase invoice. Extended warranties are available
and can be acquired by contacting the Parks Industries LLC office at [phone]. To find the
nearest Authorized Warranty Repair Center for your engine, please visit the Perkins website at
www.perkins.com and follow the provided instructions.
Even though Parks Industries offers parts and items for sale, they can’t be used for PERKINS
warranty purposes and will not be reimbursed by Parks Industries, LLC. The components that we
offer are for out of warranty replacement only and are strictly customer pay.
8 | Page

A/C Component Warranty: Parks Industries LLC provides a warranty for manufacture defects for 2 years or
2,000 hours, (whichever comes first) on the following components: A/C Compressor, Condenser Fan
Assembly, Condenser Capillary Tube, Condenser Core, Evaporator Core, Evaporator Blower, Evaporator
Check Valve Assembly, Reversing Valve Assembly, and Faulty Hoses and Tubes due to a manufacturing
defect, as well as all of the Diagnostic and Vac & Charge Labor utilized to repair such faulty components.
Additionally, Alternators and Starters carry a 1 Year or 2,000 Hour Warranty, while Electronic Components
carry a 90-Day Warranty. Warranty does not cover items such as oil, shop supplies, and miscellaneous
materials, etc. Refrigerants are only covered if a covered component fails and the refrigerant is lost, at which
point they are reimbursed as outlined in the SRT Guide. Parks Industries LLC does not pay miscellaneous
supplies and /or Hazardous Material Charges. Freon, however, is covered at $0.78 per ounce (a complete fill
is 29.6 ounces or 1.85lbs) only if the leak was caused by manufacturing defect, not by normal wear and tear.
Make yourself aware of the maintenance and customer responsibility portion of the manual, as lack of
maintenance and/or neglect are not covered under the warranty. This is the only warranty on this product,
and Parks Industries LLC hereby expressly excludes all other warranties, express or implied, including but not
limited to the implied warranty of merchantability and/or the implied warranty of fitness for a particular
purpose. Parks Industries LLC expressly excludes any claims for incidental and/or consequential damages.
9 | Page

IN ORDER FOR YOUR WARRANTY TO APPLY:
1. You must complete, sign, and submit the attached Limited Express Warranty Registration Form on page
58, as well as the Installation, Service and Operator’s Manual Form on page 59.
2. Your warranty starts on the date of installation.
3. You must promptly notify Parks Industries LLC of all Warranty Claims.
4. You must perform the Scheduled Maintenance on your APU and the Perkins Engine as listed in this
Manual.
5. You must bring the APU to Parks Industries LLC or to one of their Authorized Service Centers for Warranty
Work.
6. Parks will not pay for down-time or any consequential damages.
7. APU(s) must be Installed by an Authorized and Trained Installer.
8. Warranty is non-transferrable.
10 | Page

IMPORTANT! Without the completion and submission of both the Limited
Express Warranty Registration Form and the Installation, Service and Operator’s
Manual Form, your HP2000 is not covered under warranty. It is important that you
register your APU within fifteen (15) days of having your unit purchased and
installed, and have a copy of your registration card with the unit.
11 | Page

MANUAL OVERVIEW
This manual covers the topics of installation, operation, general
maintenance and troubleshooting for the HP2000 and the HP2000 Xtreme
Series APU by Parks Industries. The patented design of the HP2000 and the
HP2000 Xtreme’s unique features set it apart from any other unit currently
available on the market today. It provides solutions to many of the
problems faced by the transportation industry on a daily basis, yet reduces
the overall costs.
12 | Page

SAFETY
NOTE, IMPORTANT, WARNING, and CAUTION are used in this manual to emphasize important and critical
instructions.
Tips and safety warnings are listed throughout this manual. These tips and safety warnings alone cannot
eliminate all hazards that can occur. Pay close attention to instructions and use common knowledge during
maintenance procedures to prevent unnecessary accidents and injuries.
13 | Page
THIS SYMBOL IS USED TO CALL YOUR ATTENTION TO SAFETY PRECAUTIONS
THAT SHOULD BE FOLLOWED BY THE OPERATOR AND MAINTENANCE
PERSONNEL TO AVOID CARELESS ACCIDENTS. WHEN YOU SEE THIS SYMBOL
BE SURE TO OBSERVE AND FOLLOW THESE PRECAUTIONS. BE CERTAIN
THAT ANYONE OPERATING THIS MACHINE IS AWARE OF THESE SAFETY
RULES.

Follow all safety precautions listed below:
●Read this manual to familiarize yourself with the HP2000 APU. Performing maintenance on
unaccustomed machines can cause accidents.
●Wear proper safety equipment as required for the job you are performing with the
machine. Such equipment may include: hard hats, safety shoes, ear protectors, reflective
clothing, safety goggles, heavy gloves, etc., as well as safe work clothing.
●Do not wear rings, watches, jewelry, or other loose or hanging apparel that can catch on
moving parts while servicing the machine.
●The APU should only be operated or serviced by those who are qualified, responsible, and
delegated to do so.
14 | Page

Use the following safety procedures to ensure a safe workspace:
●Provide proper ventilation when operating an engine in a closed area to remove exhaust gases.
Breathing exhaust fumes may be fatal.
●Never use starting fluid around lighted smoking materials, sparks, or open flame.
●Do not place any of your body parts near a rotating fan, belt or power-driven part.
●When dealing with a servicing that pertains to the truck’s batteries, please remember that electric
storage batteries give off highly flammable hydrogen gases, and you should therefore avoid lighted
material, open flames, and/or sparks from being near the battery. Additionally, do not lay tools or
other conductive materials on the battery where they may cause short circuits and sparks.
●Use extreme caution when removing the radiator cap. Stop the engine and let it cool off before
removing the cap. When removing the cap, loosen it very slowly and avoid pressurized steam that
might be in the radiator. Coolant may be added ONLY when the engine is idling or stopped.
●Always use safety stands in conjunction with hydraulic jacks or hoists to avoid personal injury.
●Do not run the engine in an unsafe condition. If one is noticed, tag the unit so others will also know it.
●Ensure that there is a FIRE EXTINGUISHER nearby that is up to code.
●Know the location of an easy-to-access FIRST AID KIT for treatment to minor cuts and scratches.
15 | Page

NOTE:
●Hazards or unsafe practices could result in injury or death.
●Persistent inhalation of exhaust fumes may cause serious injury and/or death. Anyone suspected of
suffering from carbon monoxide inhalation should be removed from the hazardous area and given
immediate medical attention.
●Exercise extreme caution when working near fuel or flammable substances.
●Moving parts can cause severe injury and/or death. Before working on any unit, shut it off, and
make sure that the power supply is disconnected. If the power supply is not disconnected the unit
could automatically start up without warning. This could cause serious injury.
●It is not recommended for the APU to provide power to sensitive medical equipment.
16 | Page

10-STEP INSTALLATION
INSTALLATION OVERVIEW:
Before beginning installation of your HP2000, take time to inspect the unit and the desired area of installation. If you
believe you are missing a part, please consult the included checklist. Before you begin, perform an inspection of the
truck and installation area. Be sure that all batteries are fully charged and in good condition. We recommend that you
load test your battery bank prior to installation. Take your time to look over the area where you plan to install the
HP2000 and make necessary measurements to ensure proper installation. Make sure that you have at least 20.5” of
free frame rail space for power unit installation. Check to see that there is nothing behind the APU protruding more
than one inch. Also, make sure you have the necessary space available under the bunk for the evaporator unit and
cable pass through.
Before you get started, un-package your new system and all components. Inspect all components to make sure they
were not damaged during shipping. Examine your truck thoroughly, both inside and out, to locate the best place to
mount the APU. The diesel engine, A/C components and electrical controls are all contained in the frame-mounted
power unit enclosure, which measures 22.8” in height, by 20.5” in width, by 24.4” in depth. It is important to
remember that the APU location should not interfere with the driver’s access to other vital areas or crowd any wires,
air lines or fuel lines that may be nearby. While installation may vary slightly depending upon the make and model of
the truck it is installed on, proper installation will always be critical in guaranteeing proper operation of the APU system
17 | Page

REQUIRED TOOLS CHECKLIST
IMPORTANT! IT IS IMPERATIVE THAT ALL TOOLS ARE AT THE TRUCK SIDE AND NOT IN YOUR TOOL BOX
ACROSS THE SHOP. TO KEEP YOUR INSTALL TIME TO 4-5 HOURS, YOU MUST HAVE TOOLS AT THE TRUCK.
½” drive ratchet with 15/16” socket Tubing cutter 5/16” Nut Driver
15/16” wrench 3” hole saw 3/8” Drive Ratchet
Hose cutter 3 ½” hole saw Wire Ties
4 hose clamps Battery cable end crimper Drill
7/16” wrench Teflon tape Shop Vac
9/16” wrench 1 5/8” Hole Saw Cut-Off Wheel
Crescent wrench Lift cart or fork truck R134-A Refrigerant
Channel locks Torque Wrench
¼” nut driver A/C Machine
ADDITIONAL TOOLS MAY BE REQUIRED!
18 | Page

STEP 1: MOUNTING THE APU
You are now ready to install the APU. Begin by mounting the APU to the frame rail. On most installations,
the HP2000 does not require any drilling into the frame rail.
●Using a lift cart or fork truck, position the APU against the frame rail in the desired location.
Make sure that the APU is perfectly level with the frame rail. Check the back of the APU to
ensure the bolt holes align with the top and bottom of the frame rail.
●Slide the patented low-pro mounting blocks onto the top frame rail, the two blocks will
mount to the bottom of the frame.
MAKE SURE THAT THE MOUNTING BLOCKS DO NOT INTERFERE WITH AIR LINES OR WIRING INSIDE THE
FRAME RAIL.
After confirming that the APU is level, tighten the mounting bolts to 80
ft-lbs in an X pattern. Do not over tighten the bolts past 80 lbs. This can
lead to damaging of the APU and its internal components.
19 | Page

STEP 2: EVAPORATOR SYSTEM AND DUCT HOSES
The evaporator system is designed to be mounted under the bunk
in the storage area. The evaporator system measures 18” in
length by 8” in height by 10” in depth. For the A/C hoses and
power supply cable, you will need a 3-inch hole in the floor
directly beneath the hose connection side of the evaporator.
Once the install location has been determined, check underneath
the cab to be sure that there are no supports, wires, hoses, cables
or beams where the three inch hole must be cut. This hole will
serve as a pass through for cables and hoses for the evaporator
system.
20 | Page
