Parlex iMist User manual

Folded Size: H110mm x W95mm; folding; double-sided painting, 10P
iMist
SMARTAROMADIFFUSER
Controlyourdiffuserswithyourphone
UserManual
Readandsavethisinstructionmanual


OVERVIEW
iMistisanApp‐enabledBluetooth4.0Connected
SmartAromaDiffuser.UserscandownloadiMist
AppfromAppStoreorGooglePlay,andinstallit1
oniOSorAndroidDevices,useittocontrolthe
operationofiMistdiffuser.Thiselegant‐designed
aromadiffuserreleasesfragrantmistgenerated
byultrasonicwave,withgentleLEDlighting,
deliveringthearomaticluxuryfeelstoyourhome,
addingpeacefultranquilitytoyourlife.
2
1. CeramicCover
2. WaterTankLid
3. MaximumWaterLevelLine
4. WaterTank3
5. SiliconeO‐ring11
6. UnitBase104
7. PowerButton
8. BluetoothLEDIndicator95
9. LEDLight(inside)6
10. Transducer
11. AirOutlet87
12. PowerAdaptor1512
13. DCPowerJack
14. UnitBottom
15. VentilationHole1413
















1

OPERATINGINSTRUCTIONS
















1.DownloadiMistApp.2.ConnectPowerAdaptortoDCPowerJackonUnit
Bottom.ThenconnectAdaptortoawallOutlet.




















3.PoweroniMistdiffuserbypressingPower4.EnteriMistApponyoursmartdevice(makesureto
Buttononce,BluetoothLEDIndicatorwillenableBluetoothonthedevicefirst),followthe
flashinblueshowingdiffuserisreadyforinstructionsonscreenstepbysteptomakeBluetooth
Bluetoothpairingandconnecting.connectionwithdiffuser,andcontrolitsoperations
thereafter.(PleaserefertotheTutorialoniMistApp)







2



ImportantTips:
Wheneverthediffuserisconnectedsuccessfullywiththesmartdevice,itsBluetoothLEDindicator
willbealwayson.Whenevertheconnectioniscutoff,theindicatorwillturnintoflashingagain.
WheneveriMistdiffuserislackofwaterduringoperation,itwillstopworkingandtheAppwillshow
aWARNINGpopuptorequesttheusertoaddwater.PleaserefertotheINSTRUCTIONSOFHOWTO
ADDWATERonthenextpageinthisUserManualtoaddwaterintoiMistdiffuser.
Onesmartdevicecanpairwithseveraldiffusersbutcanonlyconnectandcontroloneatthesame
time.

ManualControl:

IfthereisnosmartdevicearoundoritisnotBLE‐supported,youcanstilloperateiMistdiffuserby
activatingManualControl.
PressandholdPowerButtonforaround2secondstoactivateManualControl:iMistdiffuserworks
continuouslyatmaximummistoutputandbrightestauto‐color‐changinglight,whileLEDIndicatoris
onlikeabreathinglightshowingBluetoothconnectioniscutoff.
PressthebuttononcetodeactivateManualControl:iMistdiffuserwillstopworking,whileLED
IndicatorturnsintoflashingtoshowthediffuserisreadyforBluetoothpairingandconnecting.




































3




INSTRUCTIONSOFHOWTOADDWATER

ImportantNotice:
Wheneverbeforeaddingwaterintothediffuser,makesureuseiMistApptoturnoffmistingfirst.
















2.FillWaterTankwithwatertonohigherthanMax.
WaterLevelLine.Andthenadd5‐10dropsof
essentialoilasperthePop‐upHintsoniMistApp.



1.RemovePorcelainCoverfromUnitBase
andthenliftLidfromWaterTank.


DONOTEXCEEDTHE
MAX.WATERLEVELLINE











3.ReplaceWaterTankLidandCeramicCover.Make
sureitfitwellwithSiliconO‐ring.









4


WORKINGMODESINTRODUCTIONS

AUTOMODES&MANUALMODES:
IMISTAppshowstwelveoperatingmodeschosentocontroliMistDiffuser:sixofthemare"AUTO
MODES"atwhichthediffuseroperateswithfixedsettings,whileothersixare"MANUALMODES"at
whichthediffuseroperatesduringspecifictimerswithmanualsettings:adjustablemistoutput,
adjustableLEDbrightness&color,selectableLEDcolorautochangingorfixed.

WAKEUPMODE:
iMistdiffuserwillworkatWakeupModewhenthewakeuptimesetbyiMistAppisup.

AUTO
MODES
MANUAL
MODES

Relaxation
Workscontinuouslyfor30minutes:
Mistoutput:MidLEDbrightness:Mid
LEDcolor:AutoSuggestedoil:Lemon
2HoursWorkscontinuouslyfor2hours
Sleep
Workscontinuouslyfor20minutes:
Mistoutput:SmallLEDbrightness:small
LEDcolor:YellowSuggestedoil:Lavender
4Hours Workscontinuouslyfor4hours
Energization
Workscontinuouslyfor60minutes:
Mistoutput:MaxLEDbrightness:Max
LEDcolor:RedSuggestedoil:Rosemary
8Hours
Worksatanintervalof30‐second
onand30‐secondoff
Automaticallystopsworkingafter
8hoursorlackofwater
Meditation
Workscontinuouslyfor60minutes:
Mistoutput:SmallLEDBrightness:Mid
LEDcolor:AutoSuggestedoil:Sandalwood
16Hours
works15minutesperhour
Automaticallystopsworkingafter16
hoursorlackofwater
Concentration
Workscontinuouslyfor20minutes:
Mistoutput:SmallLEDbrightness:Small
LEDColor:GreenSuggestedoil:Eucalyptus
24Hours
works10minutesperhour
Automaticallystopsworkingafter24
hoursorlackofwater
Sensuality
Workscontinuouslyfor30minutes:
Mistoutput:MidLEDbrightness:Small
LEDcolor:PinkSuggestedoil:Rose
SteadyOnWorkscontinuouslyand
automaticallystopstilllackofwater
WAKEUP
MODE
Workscontinuouslyforatleast5minutes:
Mistoutput:MaxLEDbrightness:Max
LEDColor:Auto




5

MAINTENANCE












1.PressdownPowerButtontoturnoffiMist2.RemoveCeramicCover,then
DiffuserandthenunplugPowerAdaptor.WaterTankLid.











3.Emptywaterasperthedirection4.Useasoftclothorcleanswabtoclean
shownasabove.DonotemptywatertheunitandTransducer.Transducershould
fromAirOutletside.bekeptcleanofmineraldepositsandother
debrisforoptimalmisting.Neveruseany
sharpobjectstocleantransducer.








6


TROUBLESHOOTING
ProblemsPossibleReasonsSolutions
SYMPTOMPOSSIBLECAUSESOLUTION
PowerAdaptorisnotproperly
pluggedin.
PlugintheAdaptorcorrectly.Nopower
PowerButtonisnotdepressed.DepresstheButtononce.
NomistNowaterortoolittlewaterin
WaterTank.
FillWaterTanktoMax.WaterLevelLine.
NoBluetooth
connection
withflashing
LEDIndicator
TheBluetoothconnectionbetween
thesmartdeviceandIMISTDiffuser
iscutoffincidentally.
MakesureBluetoothofthesmartdevice
isturnedon.ThenenteriMistAppto
makereconnectionwithIMISTDiffuser.
NoBluetooth
connection
withbreathing
LEDIndicator
TheManualControlisactivated
accidentallybypressingandholding
PowerButton.
PressPowerButtononcetodeactivate
ManualControl.ThenenteriMistAppto
makereconnectionwithiMistDiffuser.
Thetransducerisdirty.Cleanthetransducer.
WaterishigherthanMaxWater
LevelLine.
Pourouttheexcesswater.


Reducedor
almostnomist
whenwater
tankisfull
Besidestheabovetworeasons,
confirmifyoucanhearthesound
ofthefanoperatingandseeif
theventisobstructed.
Removeanyobstacleonthevent.














7



WARNINGS

OnlyusePowerAdaptorsuppliedwiththeunit.
UseonlyasdescribedinthismanualandiMistApp.Toreducetheriskofelectricshock,donot
attempttoservicetheunitinanywayotherthanasdescribedinthe“MAINTENANCE”sectionof
thismanual.
NeveroperatetheunitifPowerAdaptorisdamaged.
Alwaysturnoffandunplugunitduringmaintenanceorwhennotinuse.
Whenmovingtheunit,holdthebaseoftheunit.
Topreventdamagetothetransducer,donotusewaterhotterthan55°C.
Topreventclogginganddamagetothetransducer,alwaysusecleanwater.
Donotmoveorshaketheunitduringoperation.
Donottrytoremoveanypartsoftheunitduringoperation.
Donotmoveortilttheunitduringoperation.
DonotpourwaterorotherliquidintoAirOutlet.
Donottouchthehighlysensitivetransducerwithbarefingers,orscrapitwithmetaltools
(otherwisemistoutputmaybereduced).
RemoveanyliquidinWaterTankaftereachuse.
DonotusetheunitifCeramicCoverisbroken.
Donotattempttorepairtheunityourself.
Alwayskeeptheunitoutofreachofsmallchildrenandpets.














8

WARRANTY
WewarrantyouriMistSmartAromaDiffuseragainstdefectsinmaterialorworkmanshipforoneyear
fromtheoriginalpurchasedate.Shouldtheproducthaveadefectinmaterialorworkmanship,wewill
repairorreplaceitwithoutchargetoyou.Ashippingandprocessingfeemayapply.Toobtainservice
underwarranty,pleasecontactthestorewhereyouboughtthedevice.Thiswarrantydoesnotcoverany
damagecausedbyaccident,misuseoranyuseotherthanasdescribedintheseinstructions,ordamage
resultingfromfailuretocareandmaintainthisdeviceasspecifiedintheseinstructions.
SPECIFICATIONS 
ModelNo.iMist01
Inputvoltage100‐240VAC
Ratedvoltage24VDC
Powerconsumption Max.12W
WirelessconnectionBluetoothV4.0
AppOSrequirediOS7.0orlater;Android4.4orabove
Watertankcapacity120ml
MistoutputAdjustable:
FromMin.15ml/HrtoMax.30ml/Hr (Approximate)
Dimensions(D)90x(H)232(mm)
NetWeight Around560grams
MaterialsCAP:MattGlazedCeramic;BASE:ABS;TANK:PP;
O‐RING:Silicone
FCC STATEMENT
1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received, including interference that may cause undesired operation.
2. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority
to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital, pursuant to Part 15 or the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may casue harmful interference to radio communications, However, there is no guarantee
that interference will not occur in a particular installation. If the equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
--- Reorient or relocate the receiving antenna.
--- Increase the separation between the equipment and receiver.
--- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
--- Consult the dealer or an experienced radio/ TV technician for help.
3.FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. In order to avoid
the possibility of exceeding the FCC radio frequency exposure limits, Human proximity to the antenna shall not be less
than 20cm(8 inches) during normal operation.
