Parmco DR8WHP User manual

As part of Parmco Appliances commitment to improving and updating product ranges,
we reserve the right to alter, change and update technical specifications and appearance
attributes of all Parmco Appliances products. E&OE.
727626082022
INSTALLATION
AND OPERATING
INSTRUCTIONS
Model: DR8WHP
595mm
630mm
850mm

& OPERATED
100
0
0
EST. 1989
NZ OWNED
& OPERATED
100
0
0
EST. 1989
NZ OWNED
Dear Valued Customer,
Thank you and congratulations on purchasing your new Parmco appliance.
All Parmco products are made to the highest quality and design standards. We are sure
you will enjoy your new appliance.
As a note, please read through these instructions carefully. These will assist you in gaining
a complete understanding of the functions and features offered by your appliance.
Please take special note of all detailed technical information and installation instructions.
It is essential that you follow these instructions to ensure the safety and reliability of this
appliance.
Furthermore, not using appropriate personnel to install this appliance may affect any future
warranty claims lodged, so please check with Parmco Appliances before any installation is
carried out.
We hope you enjoy your new appliance. If you would like to find out more about this
product or any other products in Parmco’s extensive range, visit us online at
www.parmco.co.nz.
Regards,
The Parmco Team

p: 09 573 5678
f: 09 573 5699
e: [email protected].nz
w: www.parmco.co.nz
The Warranty:
• This appliance is intended for domestic use in the owners’
home. Use of the appliance for commercial purposes will limit the
warranty period (please see Parmco website for commercial
details).
• Subject to the terms and conditions contained within this
warranty, if the product is not of Acceptable Quality (as defined
in the Consumer Guarantees Act) within 7 years of the date of
original purchase, then Parmco Sales undertakes to repair or, at
it’s sole discretion, replace the product.
• The warranty does not cover the costs of transport, mileage or
travelling time if the product is located beyond 30km of a recognised
Service Agent.
• This warranty is offered as an extra benefit, and does
not affect other legal rights, which can not be modified or excluded
by agreement.
• This warranty only applies to goods supplied and installed in the
North and South Islands of New Zealand.
• The provisions of this warranty are in addition to the rights and
remedies available to consumers under the Consumer Guarantees
Act 1993.
The Warranty is not valid:
• If the product is not installed and operated in accordance with
the operating instructions.
• If the product is not installed to comply with the electrical,
gas, plumbing and other Regulations and Codes of Practice in
New Zealand.
• If the product is operated on voltages or frequencies outside the
normal range for domestic appliances in New Zealand.
• If the product is not used in normal domestic use, or if it is used in
a business as defined in the Consumer Guarantees Act.
• If any serial number has been removed or defaced.
• If proof of date of purchase is not supplied, except at the sole
discretion of Parmco Sales. Proof of purchase can be for the
product itself, or if installed with a kitchen or house then proof of
purchase can be from a Parmco reseller of products supplied by
Parmco.
• If the products are purchased in a second hand condition from
other parties (including but not limited to TradeMe, Sella, etc.)
Liability under this warranty will not be accepted for:
• Wear and tear caused by normal domestic use of the product.
• Damage in transport.
• Damage caused to the product by neglect, abuse, negligence,
wilful act or misuse.
• Any costs associated with the repair, replacement, removal or
reinstallation of products installed in a damaged condition.
• Any defect caused by accident, misuse, neglect, tampering
with or unauthorised modifications of the appliance or any a
ttempt at internal adjustment or repair by any person other than an
Authorised Service Agent.
• Service calls that relate principally to the following:
• Instruction on how to use the product.
• Repair or replacement of house fuses, electrical wiring, gas
fitting or plumbing.
• Normal or scheduled maintenance including blocked filters or
ducting.
• Consumable items such as light bulbs.
• Any damage to hobs caused by spills when cooking.
• Any breakage or damage of glass items.
• Any damage caused by non recommended product used for
cleaning, maintaining, lubricating or similar.
• Any aspect relating to the installation of the product, or damage
caused during installation including blocked access for repair.
• Any third party (including reseller) or consequential loss or
damage (direct or indirect) however arising.
Please contact Parmco at 09 573 5678 if your appliance
needs servicing under warranty. Please have your model
number and proof of purchase ready. Warranty repairs
must be authorized by Parmco.
Subject to updates without prior notice,
please visit www.parmco.co.nz for the latest version.
Product Date of purchase
Serial Number
Dealer / Retailer Name
Please retain this Warranty card together with receipt or other proof of
purchase date when seeking service during the warranty period
Parmco Appliances
extended 7 year
warranty
E&O.E. 727626082022

Disassembly, repair or modification can’t be carried out by people other than professional maintenance
staffs.
The household electrical supply system (the current, the voltage, the cable)such as a fuse with suitable
specifications should be provided. should meet requirements of the dryer under normal load, and safety
devices.
The power plug must be connected to a three-core socket with an earth wire and is grounded properly
and reliably.
If the supply cord is damaged, it must be replaced by the manufacture, its service agent or similarly
qualified persons in order to avoid a hazard.
Don’t disconnect the power plug by pulling the supply cord .Hold the power plug with your hand.
Don’t use the supply cord when connection of the power plug and the supply cord is loose.
Don’t touch the power plug with wet hands. Wipe dust or water drops over the power plug off with dry
cloth.
Don’t over-bend the supply cord or put it under heavy weight.
Don’t use the supply cord /socket /power plug if it is damaged or broken.
Read and understand thoroughly this safety instructions before use. The
items indicated here are very important safety precautions, which must be
followed. Any failure and losses caused by ignoring the above mentioned
items and cautions mentioned in the operation and installation instruction are
not covered by our warranty and any liability.
The appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
Children of less than 3 years should be kept away unless continuously supervised.
The rear surface of appliance shall be placed against a wall.
Do not install the appliance close to fire sources or heat sources.
Do not rest any burning candles or cigarettes on the appliance.
Do not install the appliance in places with dampness or suffer from rainfalls, lest igniting damages or
other accidents occur easily due to gathered water drops on electrical components.
Do not install the dryer in places under direct sunshine, lest the plastic components and rubber
components become aged.
Do not use water shooting at the appliance when cleaning it.
In order to avoid danger of fires caused by excessive drying, do not use the appliance to dry the
following items: Cushions, quilts and the like (these items accumulate heat).
If you have washed your laundry with stain remover, you must execute an extra rinse cycle before
loading your tumble dryer.
Please make sure that no gas lighters or matches have accidentally been left in pockets of garments to
be loaded into appliance.
Items that have been soiled with substances such as cooking oil, acetone, alcohol, petrol, kerosene,
spot removers, turpentine, waxes and wax removers should be washed in hot water with an extra
amount of detergent before being dried in the tumble dryer.
A carpet must not obstruct the openings in the base.
Exhaust air must not be discharged into a flue which is used for exhausting fumes from appliances
burning gas or other fuels.
Don’t put combustible liquid such as gasoline, petrol and alcohol into the appliance or nearby. Don’t put
clothes with that liquid into the appliance.
Don’t connect / disconnect the power plug when leakage of gas or other combustible gas occurs.
In the appliance enclosure or in the built-in structure, keep ventilation openings
clear of obstruction.
Do not damage the refrigerant circuit.
Never stop a tumble dry before the end of the drying cycle unless all items are
quickly removed and spread out so that the heat is dissipated.
The appliance must not be supplied through an external switching device, such
as a timer, or connected to a circuit that is regularly switched on and off by a utility.
This machine is not intended for use by young children or infirm persons without supervision.
The package materials may be dangerous to children. Put all package materials (e.g. the plastic bag)
to places unreachable to children.
Don’t touch laundries in the drying drum till the dryer stops working completely.
Don’t keep children or pets nearby when the dryer is working, for they may be trapped into the dryer.
Please check carefully the drum before closing the door .
This appliance is designed for domestic use .It must not be used for purposes other than those for
which it was designed.
Only wash fabrics which are designed to be machine dried. Follow the instruction on each garment
label.
Any electrical work required to install this appliance should be carried out by a qualified electrician or
competent person.
If the machine is situated on a carpeted floor, please adjust the feet in order to allow air to circulate
freely under the appliance.
Do not climb onto the dryer or rest heavy objects / heating devices or items with water or liquid leakage
on the dryer, lest deformation of the face panel and the plastic component occur.
Any objects such as coins, safety pins, nails, screws, stones or any other hard ,sharp material can
cause extensive damage and must not be placed into the machine.
After having installed the appliance, check that it is not pressing or standing on its electrical supply
cable, or vent hose.
Items such as foam rubber (latex foam), shower caps, waterproof textiles, rubber backed articles and
clothes or pillows fitted with foam rubber pads should not be dried in the tumble dryer.
Always unplug the appliance after use, clean and maintenance.
Do not overload the appliance. See the relevant section in the user manual.
Clothes which are dripping wet should not be places in the dryer.
Garments which have been in contact with volatile petroleum products should not be machine dried. If
volatile cleaning fluids are use, care should be taken to ensure that the fluid is removed from the
garment before placing in the machine.
Never use the tumble dryer if the power supply cable, the control panel, the working surface or the
base are damaged so that the inside of the tumble dryer is accessible.
The tumble dryer is not be used if industrial chemicals have been used for cleaning.
The lint must not to be allowed to accumulate around the tumble dryer.
Do not dry unwashed items in the tumble dryer.
Fabric softeners or similar products should be used as specified by the fabric softener instructions.
The final pat of a tumble dryer cycle occurs without heat (cool down cycle) to ensure that the items are
left at a temperature that ensures that the items will not be damaged.
That exhaust air must not be discharged into a flue which is used for exhausting fumes from appliances
burning gas or other fuels.
That the appliance must not be installed behind a lock able door, a sliding door or a door with a hinge
on the opposite side to hat of the tumble dryer, in such a way that a full opening of the tumble dryer
door is restricted.
Machine must be placed in a clean place , no water, ice and combustible materials there. To keep
vibration and noise to a minimum when the dryer is in use, it should be placed on a firm, level surface.
If the tumble dryer is not completely leveled, need to adjust the front feet up: to lower the dryer by
turning anti-clockwise and to ascend it by turning clockwise till the appliance will not shake.
1

Disassembly, repair or modification can’t be carried out by people other than professional maintenance
staffs.
The household electrical supply system (the current, the voltage, the cable)such as a fuse with suitable
specifications should be provided. should meet requirements of the dryer under normal load, and safety
devices.
The power plug must be connected to a three-core socket with an earth wire and is grounded properly
and reliably.
If the supply cord is damaged, it must be replaced by the manufacture, its service agent or similarly
qualified persons in order to avoid a hazard.
Don’t disconnect the power plug by pulling the supply cord .Hold the power plug with your hand.
Don’t use the supply cord when connection of the power plug and the supply cord is loose.
Don’t touch the power plug with wet hands. Wipe dust or water drops over the power plug off with dry
cloth.
Don’t over-bend the supply cord or put it under heavy weight.
Don’t use the supply cord /socket /power plug if it is damaged or broken.
Read and understand thoroughly this safety instructions before use. The
items indicated here are very important safety precautions, which must be
followed. Any failure and losses caused by ignoring the above mentioned
items and cautions mentioned in the operation and installation instruction are
not covered by our warranty and any liability.
The appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
Children of less than 3 years should be kept away unless continuously supervised.
The rear surface of appliance shall be placed against a wall.
Do not install the appliance close to fire sources or heat sources.
Do not rest any burning candles or cigarettes on the appliance.
Do not install the appliance in places with dampness or suffer from rainfalls, lest igniting damages or
other accidents occur easily due to gathered water drops on electrical components.
Do not install the dryer in places under direct sunshine, lest the plastic components and rubber
components become aged.
Do not use water shooting at the appliance when cleaning it.
In order to avoid danger of fires caused by excessive drying, do not use the appliance to dry the
following items: Cushions, quilts and the like (these items accumulate heat).
If you have washed your laundry with stain remover, you must execute an extra rinse cycle before
loading your tumble dryer.
Please make sure that no gas lighters or matches have accidentally been left in pockets of garments to
be loaded into appliance.
Items that have been soiled with substances such as cooking oil, acetone, alcohol, petrol, kerosene,
spot removers, turpentine, waxes and wax removers should be washed in hot water with an extra
amount of detergent before being dried in the tumble dryer.
A carpet must not obstruct the openings in the base.
Exhaust air must not be discharged into a flue which is used for exhausting fumes from appliances
burning gas or other fuels.
Don’t put combustible liquid such as gasoline, petrol and alcohol into the appliance or nearby. Don’t put
clothes with that liquid into the appliance.
Don’t connect / disconnect the power plug when leakage of gas or other combustible gas occurs.
In the appliance enclosure or in the built-in structure, keep ventilation openings
clear of obstruction.
Do not damage the refrigerant circuit.
Never stop a tumble dry before the end of the drying cycle unless all items are
quickly removed and spread out so that the heat is dissipated.
The appliance must not be supplied through an external switching device, such
as a timer, or connected to a circuit that is regularly switched on and off by a utility.
This machine is not intended for use by young children or infirm persons without supervision.
The package materials may be dangerous to children. Put all package materials (e.g. the plastic bag)
to places unreachable to children.
Don’t touch laundries in the drying drum till the dryer stops working completely.
Don’t keep children or pets nearby when the dryer is working, for they may be trapped into the dryer.
Please check carefully the drum before closing the door .
This appliance is designed for domestic use .It must not be used for purposes other than those for
which it was designed.
Only wash fabrics which are designed to be machine dried. Follow the instruction on each garment
label.
Any electrical work required to install this appliance should be carried out by a qualified electrician or
competent person.
If the machine is situated on a carpeted floor, please adjust the feet in order to allow air to circulate
freely under the appliance.
Do not climb onto the dryer or rest heavy objects / heating devices or items with water or liquid leakage
on the dryer, lest deformation of the face panel and the plastic component occur.
Any objects such as coins, safety pins, nails, screws, stones or any other hard ,sharp material can
cause extensive damage and must not be placed into the machine.
After having installed the appliance, check that it is not pressing or standing on its electrical supply
cable, or vent hose.
Items such as foam rubber (latex foam), shower caps, waterproof textiles, rubber backed articles and
clothes or pillows fitted with foam rubber pads should not be dried in the tumble dryer.
Always unplug the appliance after use, clean and maintenance.
Do not overload the appliance. See the relevant section in the user manual.
Clothes which are dripping wet should not be places in the dryer.
Garments which have been in contact with volatile petroleum products should not be machine dried. If
volatile cleaning fluids are use, care should be taken to ensure that the fluid is removed from the
garment before placing in the machine.
Never use the tumble dryer if the power supply cable, the control panel, the working surface or the
base are damaged so that the inside of the tumble dryer is accessible.
The tumble dryer is not be used if industrial chemicals have been used for cleaning.
The lint must not to be allowed to accumulate around the tumble dryer.
Do not dry unwashed items in the tumble dryer.
Fabric softeners or similar products should be used as specified by the fabric softener instructions.
The final pat of a tumble dryer cycle occurs without heat (cool down cycle) to ensure that the items are
left at a temperature that ensures that the items will not be damaged.
That exhaust air must not be discharged into a flue which is used for exhausting fumes from appliances
burning gas or other fuels.
That the appliance must not be installed behind a lock able door, a sliding door or a door with a hinge
on the opposite side to hat of the tumble dryer, in such a way that a full opening of the tumble dryer
door is restricted.
Machine must be placed in a clean place , no water, ice and combustible materials there. To keep
vibration and noise to a minimum when the dryer is in use, it should be placed on a firm, level surface.
If the tumble dryer is not completely leveled, need to adjust the front feet up: to lower the dryer by
turning anti-clockwise and to ascend it by turning clockwise till the appliance will not shake.
2

Open the door. Place the laundry in the drum, one item at a time, shaking
them out as much as possible.
Close the door. Please check the laundry does not get caught between the
door and filter.
Attention:
Some thick clothes ( jeans, big towel ). Because of the material characteristics, some place hard to dry.
If you find that they are not completely dry at the end of the program. It is recommended to use the
“Time” program to dry again.
1.Time 2.Child Lock 3.Dry Level 4.
6.
Anti Crease 5.Buzzer
Delay Start 7.Programme Selection Knob 8.Power 9.Start/Pause
1 2 3 4 5 6 7 8 9
Product description
You can choose different programme base on your different clothes materials. The device has the
function with sensor the moisture in order to automatically adjust the drying time for optimal drying.
This drying system is fit for most programmes except “Time”, “Refresh”, “Warm Air”.
Depending on the programme, different functions can be combined. These must be selected after
choosing the desired programme and before depressing the Start/Pause button.
After turning on the appliance, the buzzer is off if you do none operation. The buzzer can be turned on or
be turned off during the process. By pressing “Anti crease” and the “Delay start” button at the same time),
the buzzer will be turned on and the corresponding pilot light comes on. when the buzzer is on, the signal
will sound in the following case:
Adequate ventilation has to be provided to avoid the back flow of gases into the room from appliances
burning other fuels, including open fires.
Items that have been soiled with substances such as cooking oil, acetone, alcohol, petrol, kerosene,
spot removers, turpentine, waxes and wax removers should be washed in hot water with an extra
amount of detergent before being dried in the tumble dryer.
Remove all objects from pockets such as lighters and matches.
Oil-affected items can ignite spontaneously, especially when exposed to heat sources such as in a
tumble dryer. The items become warm, causing an oxidation reaction in the oil.
Oxidation creates heat. If the heat cannot escape, the items can become hot enough to catch fire. Piling,
tacking or storing oil affected items can prevent heat from escaping and so create a fire hazard.
If it is unavoidable that fabrics that contain vegetable or cooking oil or have been contaminated by hair
care products be placed in a tumble dryer they should first be washed in hot water with extra detergent
- this will reduce, but not eliminate, the hazard.
Contains fluorinated greenhouse gases covered by the Kyoto Protocol.
Hermetically sealed system.
Do not vent gases into the atmosphere.
Refrigerant(Type): R-134a(GWP=1430)
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
This appliance is not intended for use by persons (including children) with reduced physical sensory or
mental capabilities, or lack of experience and knowledge, unless they have been, given supervision or
instruction concerning use of the appliance by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.
WARNING: The appliance must not be supplied through an external switching device, such as a timer,
or connected to a circuit that is regularly switched on and off by a utility.
Ensure that the electrical connections comply with the installation instructions.
Remove the poly stryrene block and any material from the drum.
Before using your tumble dryer for the first time, we recommend that you place a few damp cloths
inside the appliance and dry for 30 minutes .There may be dust inside a brand new tumble dryer.
5
1
3
4
2
6
1.Control Pane
2.Water Tank
3.Fluff filter
4.Door
5.Condenser cover
6.Adjustment leg
Turn the program selector dial to the required
program. The corresponding function lights is
on. The program will be switched off if you
have not pressed any button for 10 minutes.
Open the door during operation.
When the water container is full.
At the end of program after cooling phase.
When the buzzer is on, if you press the “buzzer” button once more, the buzzer will be switched off.
Before you start the machine, you can choose the dry level. The dry level is divided into three grades.
( Heavy Strong Normal )
This option is only suitable to the five programs: Daily, Cotton, Synthetic, Bulky Item, Towel.
Select the Dry level
3

Open the door. Place the laundry in the drum, one item at a time, shaking
them out as much as possible.
Close the door. Please check the laundry does not get caught between the
door and filter.
Attention:
Some thick clothes ( jeans, big towel ). Because of the material characteristics, some place hard to dry.
If you find that they are not completely dry at the end of the program. It is recommended to use the
“Time” program to dry again.
1.Time 2.Child Lock 3.Dry Level 4.
6.
Anti Crease 5.Buzzer
Delay Start 7.Programme Selection Knob 8.Power 9.Start/Pause
1 2 3 4 5 6 7 8 9
Product description
You can choose different programme base on your different clothes materials. The device has the
function with sensor the moisture in order to automatically adjust the drying time for optimal drying.
This drying system is fit for most programmes except “Time”, “Refresh”, “Warm Air”.
Depending on the programme, different functions can be combined. These must be selected after
choosing the desired programme and before depressing the Start/Pause button.
After turning on the appliance, the buzzer is off if you do none operation. The buzzer can be turned on or
be turned off during the process. By pressing “Anti crease” and the “Delay start” button at the same time),
the buzzer will be turned on and the corresponding pilot light comes on. when the buzzer is on, the signal
will sound in the following case:
Adequate ventilation has to be provided to avoid the back flow of gases into the room from appliances
burning other fuels, including open fires.
Items that have been soiled with substances such as cooking oil, acetone, alcohol, petrol, kerosene,
spot removers, turpentine, waxes and wax removers should be washed in hot water with an extra
amount of detergent before being dried in the tumble dryer.
Remove all objects from pockets such as lighters and matches.
Oil-affected items can ignite spontaneously, especially when exposed to heat sources such as in a
tumble dryer. The items become warm, causing an oxidation reaction in the oil.
Oxidation creates heat. If the heat cannot escape, the items can become hot enough to catch fire. Piling,
tacking or storing oil affected items can prevent heat from escaping and so create a fire hazard.
If it is unavoidable that fabrics that contain vegetable or cooking oil or have been contaminated by hair
care products be placed in a tumble dryer they should first be washed in hot water with extra detergent
- this will reduce, but not eliminate, the hazard.
Contains fluorinated greenhouse gases covered by the Kyoto Protocol.
Hermetically sealed system.
Do not vent gases into the atmosphere.
Refrigerant(Type): R-134a(GWP=1430)
If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.
This appliance is not intended for use by persons (including children) with reduced physical sensory or
mental capabilities, or lack of experience and knowledge, unless they have been, given supervision or
instruction concerning use of the appliance by a person responsible for their safety. Children should be
supervised to ensure that they do not play with the appliance.
WARNING: The appliance must not be supplied through an external switching device, such as a timer,
or connected to a circuit that is regularly switched on and off by a utility.
Ensure that the electrical connections comply with the installation instructions.
Remove the poly stryrene block and any material from the drum.
Before using your tumble dryer for the first time, we recommend that you place a few damp cloths
inside the appliance and dry for 30 minutes .There may be dust inside a brand new tumble dryer.
5
1
3
4
2
6
1.Control Pane
2.Water Tank
3.Fluff filter
4.Door
5.Condenser cover
6.Adjustment leg
Turn the program selector dial to the required
program. The corresponding function lights is
on. The program will be switched off if you
have not pressed any button for 10 minutes.
Open the door during operation.
When the water container is full.
At the end of program after cooling phase.
When the buzzer is on, if you press the “buzzer” button once more, the buzzer will be switched off.
Before you start the machine, you can choose the dry level. The dry level is divided into three grades.
( Heavy Strong Normal )
This option is only suitable to the five programs: Daily, Cotton, Synthetic, Bulky Item, Towel.
Select the Dry level
4

24
Anti-creasing is a default setting while all programs are switched off. Anti-creasing can be selected while
the program is switched off or running.
This button allows you to delay the starting of the program by 24 hours max. This option must be selected
after having selected the program and before pressing Start/Pause to start the program. Every time the
button is pressed ,the time is increased by 1 hour.
It can be selected in both cases before and after selecting option programme (Buzzer, Anti-creasing). The
countdown begins after you have pressed the Start/Pause button and the corresponding light illuminates.
The display shows the remaining time. The remaining time is displayed hour by hour.
The display shows the following information:
After you have selected the program, its duration (in hours and minutes) appears on the display. It is
calculated automatically on the basis of the maximum load accepted for each type of fabric and of the
required degree of drying. When the program starts, the remaining time is displayed every 1 minutes .
Delay Start.
If you have selected a delay time by means of the relevant button, the display shows it, The countdown
is displayed hour by hour. Once you press the “Start/Pause” button ,the appliance will start the delayed
process. If you want to check the selected program, press the “Delay Start” button again. It shows the
duration of the previously selected program.
Incorrect option selection
If you select an option that is not compatible with the program you have selected, the display shows
ErS (error).
If you select other program because of incorrect operation while the program is running, the display
shows ErS (error).
Press this button to start the dryer after having selected the program and the options. If the door of the
appliance is opened while the program is running, this button must be pressed again after closing the
door in order to restart the program from the point at which it was interrupted. In this cases the light of the
Start/Pause button flashes to remind you that the start button needs to be pressed again.
These lights indicate the following functions:
Drying light " " This light indicates that the appliance is in the drying phase.
Cooling light " " This light indicates that the appliance is in the cooling phase. At the end of drying,
there is a two minutes cooling phase to cool the laundry.
End of programme light " " This light is on at the end of the cooling phase.
Anti-creasing light " " This light is on when anti-creasing programme is selected.
Filter light " " It comes on every cycle to remind you that the filter must be cleaned at the end of the
programme.
Child Lock light " " This light indicated the appliance is locked.
Buzzer light " " This light is on when buzzer programme is selected.
Delay Start light " " This light is on when delay start programme is selected.
Drying Type light, this light is on when drying programme is selected depending on the rotating speed
of washing machine.
Tank full light " " It comes on after each program and also when the water tank is full. which remind
you to empty the water container. Note! Empty the water container after each program to avoid the
alarm when use in next time.
All drying programs end with 2 minutes cooling phase. If the laundry is not removed at the end of the
cycle, the dryer performs an anti-creasing phase (duration:10 minutes maximum). If you don’t remove the
laundry, the machine will stop automatically at the end of the anti-creasing phase. The display shows
“End” and the buzzer sounds if you have selected the buzzer. Turn the program selector dial to “off ”,all
the lights go off.
When the machine is on, press meantime “Time” and “Dry level” button for several seconds, the system
will lock all the buttons. Then all buttons are invalid except “off ”. If you want to make the appliance to
return to the normal state, then press “Time” and “Dry level” button for several seconds meantime again.
The function will be released in the following cases:
Open the door during operation.
Take out filter drawer during operation.
Water tank full
You can set again the “Child Lock” function when you restart the machine.
Important!
If the drying program has to be stopped before it reaches the end, we recommend that you turn the
program selector dial to position “Air Dry” and wait until the end of this cooling phase before removing
the laundry. This will avoid a build-up of heat inside the appliance. To do this first turn the dial to “off ”
and then to “Air Dry” and depress the “Start” button.
Modifying the program
To change a program which is running, first cancel it by turning the programme selector dial to “off ”.
Select the new program and press the “Start” button.
Attention:
According to "-" for the dormant state;
- standby mode, 10 minutes later, without any operation, enter a dormant state.
- controller shows "End", 10 minutes later, without any operation, enter a dormant state.
Never tumble dry the following: Particularly delicate items such as net curtains, woolen, silk, fabrics with
metal trim, nylon tights, bulky materials such as anoraks, blankets, eiderdowns, sleeping bags, feather
quilts and any items containing rubber foam or materials similar to rubber foam.
Always follow the instructions on garment labels:
Close pillowcases and covers with fasteners to prevent small laundry items getting tangled inside them.
Close press studs, zips, hooks, tie belts, apron strings. Sort laundry according to type and degree of
drying required.
Do not over-dry laundry, this avoids creasing and saves energy.
Avoid drying dark clothes with light coloured fluffy items such as towels as they could attract fluff.
The laundry must be thoroughly spun before tumble drying.
Easy-care items, e. g. shirts, should be briefly pre-spun before drying.
Knitted textiles(knitted underwear) may shrink a little during drying. Please do not over-dry items of this
type. It is advisable to allow for shrinkage when choosing the size of new purchases.
You can also put starched items into your dryer. However, to achieve the desired starched effect,
choose the programme “Iron dry”. To remove any starch residues, wipe out the internal drum after
drying with a moist cloth and then rub it dry.
To avoid a static charge when drying is completed, use either a fabric softener when you are washing
the laundry or a fabric conditioner specifically for tumble dryers.
Remove the laundry when the dryer has finished drying.
If individual items are still damp after drying, set a brief post-drying time, but at least 30 minutes, This
will be necessary particularly for multilayered items (e.g. collars, pockets, etc.)
5

24
Anti-creasing is a default setting while all programs are switched off. Anti-creasing can be selected while
the program is switched off or running.
This button allows you to delay the starting of the program by 24 hours max. This option must be selected
after having selected the program and before pressing Start/Pause to start the program. Every time the
button is pressed ,the time is increased by 1 hour.
It can be selected in both cases before and after selecting option programme (Buzzer, Anti-creasing). The
countdown begins after you have pressed the Start/Pause button and the corresponding light illuminates.
The display shows the remaining time. The remaining time is displayed hour by hour.
The display shows the following information:
After you have selected the program, its duration (in hours and minutes) appears on the display. It is
calculated automatically on the basis of the maximum load accepted for each type of fabric and of the
required degree of drying. When the program starts, the remaining time is displayed every 1 minutes .
Delay Start.
If you have selected a delay time by means of the relevant button, the display shows it, The countdown
is displayed hour by hour. Once you press the “Start/Pause” button ,the appliance will start the delayed
process. If you want to check the selected program, press the “Delay Start” button again. It shows the
duration of the previously selected program.
Incorrect option selection
If you select an option that is not compatible with the program you have selected, the display shows
ErS (error).
If you select other program because of incorrect operation while the program is running, the display
shows ErS (error).
Press this button to start the dryer after having selected the program and the options. If the door of the
appliance is opened while the program is running, this button must be pressed again after closing the
door in order to restart the program from the point at which it was interrupted. In this cases the light of the
Start/Pause button flashes to remind you that the start button needs to be pressed again.
These lights indicate the following functions:
Drying light " " This light indicates that the appliance is in the drying phase.
Cooling light " " This light indicates that the appliance is in the cooling phase. At the end of drying,
there is a two minutes cooling phase to cool the laundry.
End of programme light " " This light is on at the end of the cooling phase.
Anti-creasing light " " This light is on when anti-creasing programme is selected.
Filter light " " It comes on every cycle to remind you that the filter must be cleaned at the end of the
programme.
Child Lock light " " This light indicated the appliance is locked.
Buzzer light " " This light is on when buzzer programme is selected.
Delay Start light " " This light is on when delay start programme is selected.
Drying Type light, this light is on when drying programme is selected depending on the rotating speed
of washing machine.
Tank full light " " It comes on after each program and also when the water tank is full. which remind
you to empty the water container. Note! Empty the water container after each program to avoid the
alarm when use in next time.
All drying programs end with 2 minutes cooling phase. If the laundry is not removed at the end of the
cycle, the dryer performs an anti-creasing phase (duration:10 minutes maximum). If you don’t remove the
laundry, the machine will stop automatically at the end of the anti-creasing phase. The display shows
“End” and the buzzer sounds if you have selected the buzzer. Turn the program selector dial to “off ”,all
the lights go off.
When the machine is on, press meantime “Time” and “Dry level” button for several seconds, the system
will lock all the buttons. Then all buttons are invalid except “off ”. If you want to make the appliance to
return to the normal state, then press “Time” and “Dry level” button for several seconds meantime again.
The function will be released in the following cases:
Open the door during operation.
Take out filter drawer during operation.
Water tank full
You can set again the “Child Lock” function when you restart the machine.
Important!
If the drying program has to be stopped before it reaches the end, we recommend that you turn the
program selector dial to position “Air Dry” and wait until the end of this cooling phase before removing
the laundry. This will avoid a build-up of heat inside the appliance. To do this first turn the dial to “off ”
and then to “Air Dry” and depress the “Start” button.
Modifying the program
To change a program which is running, first cancel it by turning the programme selector dial to “off ”.
Select the new program and press the “Start” button.
Attention:
According to "-" for the dormant state;
- standby mode, 10 minutes later, without any operation, enter a dormant state.
- controller shows "End", 10 minutes later, without any operation, enter a dormant state.
Never tumble dry the following: Particularly delicate items such as net curtains, woolen, silk, fabrics with
metal trim, nylon tights, bulky materials such as anoraks, blankets, eiderdowns, sleeping bags, feather
quilts and any items containing rubber foam or materials similar to rubber foam.
Always follow the instructions on garment labels:
Close pillowcases and covers with fasteners to prevent small laundry items getting tangled inside them.
Close press studs, zips, hooks, tie belts, apron strings. Sort laundry according to type and degree of
drying required.
Do not over-dry laundry, this avoids creasing and saves energy.
Avoid drying dark clothes with light coloured fluffy items such as towels as they could attract fluff.
The laundry must be thoroughly spun before tumble drying.
Easy-care items, e. g. shirts, should be briefly pre-spun before drying.
Knitted textiles(knitted underwear) may shrink a little during drying. Please do not over-dry items of this
type. It is advisable to allow for shrinkage when choosing the size of new purchases.
You can also put starched items into your dryer. However, to achieve the desired starched effect,
choose the programme “Iron dry”. To remove any starch residues, wipe out the internal drum after
drying with a moist cloth and then rub it dry.
To avoid a static charge when drying is completed, use either a fabric softener when you are washing
the laundry or a fabric conditioner specifically for tumble dryers.
Remove the laundry when the dryer has finished drying.
If individual items are still damp after drying, set a brief post-drying time, but at least 30 minutes, This
will be necessary particularly for multilayered items (e.g. collars, pockets, etc.)
6

Kind Notice: for drying bathrobe and toweling towel, the max load don’t exceed 6kg.
Stainless Steel Tumbler
To clean the stainless steel tumbler, use a damp cloth with a mild, non-abrasive
cleaner suitable for stainless steel surfaces.
Remove the cleaner residue and dry with a clean cloth.
Clean periodically the interior part of the door to remove any fluff. Accurate cleaning ensures correct drying.
Dryer Exterior
The enter dryer has a high-gloss finish. Clean with a soft, damp cloth. Don’t use abrasive substances.
Protect the surface from sharp objects as they may scratch or damage the finish.
Don’t place any heavy or sharp objects or a detergent box on the dryer. Keep them on the purchased
pedestal or in a separate storage box.
Open the loading door.
Remove the lint filter by putting it up and open the lint filter.
Clean lint, fibre, and cotton raveling by hand or with a soft piece of cloth.
Close the lint filter and place it back into its housing.
A layer can build up on the filter pores that can cause clogging of the filter
after using the dryer for a while. Wash the lint filter with warm water to
remove the layer that builds up on the lint filter surface. Dry the lint filter
completely before reinstalling it.
The lint trap has to be cleaned frequently. T
Always clean the lint filter and the inner surfaces of the
loading door after each drying process.
Filter case
Jeans, work clothes and so on.
Warm the clothes with low temperature and do not
feel too cold when they are put on.
Shirts
Underwear
Time
Refresh
Warm Air
Daily
Bulky Item
Towel
Wool
Duvet
Baby Care
Jeans
Drying cotton clothes.
Drying towels, bath towels and other small objects.
Drying wool clothes.
Remove the smell of clothes.
Drying shirts etc.
Synthetic
Sportswear Drying sport wears.
Air Dry For men’s underpants ,shirt ,T-shirt ,cotton trousers ,etc.
4kg Drying synthetic clothes.
Drying heavy clothes.
4kg
2kg
3kg Drying down garments, duvets.
3kg Drying baby clothes.
4kg
Drying jeans.
2kg
2kg
4kg
8kg
8kg
8kg
4kg
2kg
4kg
4kg
4.5kg
4.5kg
3kg
4kg
4kg
4.5kg
3kg
3kg
4.5kg
9kg
9kg
9kg
4.5kg
3kg
4.5kg
4.5kg
Button up pillowcases, close zip fasteners, hooks and poppers. Tie any belts or long tapes.
To avoid laundry becoming tangled:
Close zips, button up duvet covers and tie loose ties or ribbons(e.g.of aprons).
Turn items with double-layered fabrics inside out(e.g.with cotton lined anoraks, the cotton layer should be
outermost). These fabrics will then dry better.
Remove all objects from pockets such as lighters and matches.
Recommended loads are indicated in the program charts:
General rules:
Cotton, linen: drum full but not too tightly packed;
Synthetics: drum no more than half full;
Delicate fabrics and woollens: drum no more than quarter full.
Try to load the maximum capacity of the machine as small loads are uneconomical.
Bathrobe 1600g Night Dress 265g
Napkin 130g Ladies' Briefs 130g
Quilt Cover 930g Men's Work Shirt 800g
Sheet 665g Men's Shirt 265g
Pillow Case 266g Men's Pyjamas 130g
Tablecloth 330g Blouse 665g
Towelling Towel 265g Men's Underpants 130g
Tea Cloth 130g
The following weights are indicative:
You must DISCONNECT the appliance from the electricity supply, before you can carry out any
cleaning or maintenance work.
Don’t clean the dryer by directly spraying water onto the dryer. Don’t clean the dryer with benzene,
thinner, alcohol, or acetone. Otherwise, it may cause discoloration, deformation, damage. electric
shock or fire.
When cleaning the product , be sure to unplug the power cord.
Durning the drying cycle ,the control panel or the door may accumulate moisture.
Clean with a soft, damp clothes. Do not use abrasive substances.
Don’t spray cleaners directly on the panel.
The control panel finish may be damaged by some laundry pre-treatment soil and stain remover products.
Apply such products away from your dryer and wipe up any spills or overspray immediately.
Water-tank
Water container collects all of the water from condenser. Water container need to be emptied after every
drying cycle. If the water container is full, an active programme will break off automatically. the light will
comes on and the buzzer sounds. In order to continue the programme, the water container must first be
emptied.
Water container emptied
1.Pull out water container
3.Pull the water container in dryer 4.Press the Start/Pause button
2.Tip water into pool
7

Kind Notice: for drying bathrobe and toweling towel, the max load don’t exceed 6kg.
Stainless Steel Tumbler
To clean the stainless steel tumbler, use a damp cloth with a mild, non-abrasive
cleaner suitable for stainless steel surfaces.
Remove the cleaner residue and dry with a clean cloth.
Clean periodically the interior part of the door to remove any fluff. Accurate cleaning ensures correct drying.
Dryer Exterior
The enter dryer has a high-gloss finish. Clean with a soft, damp cloth. Don’t use abrasive substances.
Protect the surface from sharp objects as they may scratch or damage the finish.
Don’t place any heavy or sharp objects or a detergent box on the dryer. Keep them on the purchased
pedestal or in a separate storage box.
Open the loading door.
Remove the lint filter by putting it up and open the lint filter.
Clean lint, fibre, and cotton raveling by hand or with a soft piece of cloth.
Close the lint filter and place it back into its housing.
A layer can build up on the filter pores that can cause clogging of the filter
after using the dryer for a while. Wash the lint filter with warm water to
remove the layer that builds up on the lint filter surface. Dry the lint filter
completely before reinstalling it.
The lint trap has to be cleaned frequently. T
Always clean the lint filter and the inner surfaces of the
loading door after each drying process.
Filter case
Jeans, work clothes and so on.
Warm the clothes with low temperature and do not
feel too cold when they are put on.
Shirts
Underwear
Time
Refresh
Warm Air
Daily
Bulky Item
Towel
Wool
Duvet
Baby Care
Jeans
Drying cotton clothes.
Drying towels, bath towels and other small objects.
Drying wool clothes.
Remove the smell of clothes.
Drying shirts etc.
Synthetic
Sportswear Drying sport wears.
Air Dry For men’s underpants ,shirt ,T-shirt ,cotton trousers ,etc.
4kg Drying synthetic clothes.
Drying heavy clothes.
4kg
2kg
3kg Drying down garments, duvets.
3kg Drying baby clothes.
4kg
Drying jeans.
2kg
2kg
4kg
8kg
8kg
8kg
4kg
2kg
4kg
4kg
4.5kg
4.5kg
3kg
4kg
4kg
4.5kg
3kg
3kg
4.5kg
9kg
9kg
9kg
4.5kg
3kg
4.5kg
4.5kg
Button up pillowcases, close zip fasteners, hooks and poppers. Tie any belts or long tapes.
To avoid laundry becoming tangled:
Close zips, button up duvet covers and tie loose ties or ribbons(e.g.of aprons).
Turn items with double-layered fabrics inside out(e.g.with cotton lined anoraks, the cotton layer should be
outermost). These fabrics will then dry better.
Remove all objects from pockets such as lighters and matches.
Recommended loads are indicated in the program charts:
General rules:
Cotton, linen: drum full but not too tightly packed;
Synthetics: drum no more than half full;
Delicate fabrics and woollens: drum no more than quarter full.
Try to load the maximum capacity of the machine as small loads are uneconomical.
Bathrobe 1600g Night Dress 265g
Napkin 130g Ladies' Briefs 130g
Quilt Cover 930g Men's Work Shirt 800g
Sheet 665g Men's Shirt 265g
Pillow Case 266g Men's Pyjamas 130g
Tablecloth 330g Blouse 665g
Towelling Towel 265g Men's Underpants 130g
Tea Cloth 130g
The following weights are indicative:
You must DISCONNECT the appliance from the electricity supply, before you can carry out any
cleaning or maintenance work.
Don’t clean the dryer by directly spraying water onto the dryer. Don’t clean the dryer with benzene,
thinner, alcohol, or acetone. Otherwise, it may cause discoloration, deformation, damage. electric
shock or fire.
When cleaning the product , be sure to unplug the power cord.
Durning the drying cycle ,the control panel or the door may accumulate moisture.
Clean with a soft, damp clothes. Do not use abrasive substances.
Don’t spray cleaners directly on the panel.
The control panel finish may be damaged by some laundry pre-treatment soil and stain remover products.
Apply such products away from your dryer and wipe up any spills or overspray immediately.
Water-tank
Water container collects all of the water from condenser. Water container need to be emptied after every
drying cycle. If the water container is full, an active programme will break off automatically. the light will
comes on and the buzzer sounds. In order to continue the programme, the water container must first be
emptied.
Water container emptied
1.Pull out water container
3.Pull the water container in dryer 4.Press the Start/Pause button
2.Tip water into pool
8

Humidty sensor
In the movement process, this device is used for induction clothing humidity, it means that
it must be carried on cleaning. Major cause of clean is must scour out the calcium oxide
boiler which on the sensor surface up. Clean the sensor in the tumbler (See picture).
Clean the filter drawer
Press the button to open the cover.
Unlock the fixer.
Pull out the filter drawer.
Clean lint, fiber and cotton raveling on the filter cloth by hand or with a soft piece of cloth.
When you notice a layer that may lead clogging on the filter cloth, please clean the layer by
washing in warm water. Let the filter cloth dry thoroughly before installing back the filter drawer.
Wash the filter drawer sponge by hand to remove the fiber and lint on the surface. After
washing the sponge. squeeze it by hand and remove the excess water. Well-dry the sponge
before storing it.
Clean the evaporator
Clean the lint accumulated on the fins of the evaporator located behind the filter drawer
with a vacuum cleaner or a soft brush. You can also clean by hand provided that you
wear protective gloves.
It is recommended to clean it at least twice every month.
Never attempt to clean with bare hands.Evaporator fins can harm your hand.
If you are unable to identify or solve the problem, contact our service centre. Before telephoning,
make a note of the model, serial number and purchase date of your machine: the Service Centre
will require this information.
This appliance must be earthed. In case of failure or damage, earth can provide a minimum resistance to
reduce the possibility of electric shock. The power cord has grounding wire with device and power cord
with plug. Plug must be inserted into a properly installed and grounded socket(in accordance with all local
rules and standards).
A separate earth is required by some local rules. In that case, you need buy grounding wire, clips and screws.
Caution!
Removing transport safety packaging foam
Water discharge
Procedure
Earth note
IMPORTANT: The appliance must not built-in.
Unpacking
All packing must be removed before using the appliance.
Check accessory
Open the accessory bag and check the accessories.
Care must be taken to ensure that the appliance does not stand on the electrical supply cable.
Any electrical work required to install this appliance should be carried out by a qualified electrician or
competent person.
Should the appliance be moved, it must be transported vertically.
650
220/50
Power(left-on mode)(W)
Power(off mode)(W)
Programme time at full load(min)
0.48
290
595X630X850
Ambient temperature range( )℃5 35
~
8.0
Energy efficient gear Daily
0.48
Lint and fibre that could not be captured by the lint filter are blocked in the filter drawer behind the cover.
Clean the filter drawer after each drying process. There is a two-level filter in the filter drawer. The first
level is the filter drawer sponge and the second level is the filter cloth.
IMPORTANT :
If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation,
a charge will be made even if the appliance is under guarantee.
It’s not necessary to dischargr the condensed water to the tank, it can be drained out directly.
change drainpipe
Pull out the water pipe by means of the arrow direction ,Then install the drainpipe.
Such as the pilers can be used if it is difficult to do.
Before use the machine, the packaging foam must be removed from the drum.
1.Open the loading door.
2.Pull off adhesive strips from inside machine on top of drum.
3.Remove the two packaging foam from the machine.
Check across the corner
When press on the edge, the machine should not shake up and down. (please check two direction) when
press on the top frame (across the corner), the dryer shakes, need to re-adjust the adjustable feet.
Do not put stacks of blanket or a rope on the floor, which could generrate some heat and affect the
machine running.
two packaging foam
drainpipe
manual
Quantity
It is dangerous to alter the specifications or attempt to modify this product in any way.
Malfunction Possible Cause Solution
Dryer does
not work
Drying results
unsatisfactory
Drum light does
not work(option)
Drying cycle ends
shortly after
programme starts.
"END" light
illuminated.
Drying cycle lasts
an unusually long
time
Mains plug is not plugged in.
Loading door is open.
Have you pressed the button?
Wrong programme selected.
Filter clogged.
Incorrect volume of laundry.
The sediment on humidity sensor.
Light bulb is defective.
Not enough washing loaded or
washing load is too dry for selected
programme.
Load volume is too big.
Select a different programme the next time
you dry(see "Drying Programme "section).
Clean lint filter.
Observe recommended loading volumes.
Washed hunidity sensor surface.
Replace light bulb.
Select higher drying level(e. g. Heavy instead
of Strong)
Reduce load volume.
Plug in at main socket.
Close loading door.
Press the button again.
DR8WHP
9

Humidty sensor
In the movement process, this device is used for induction clothing humidity, it means that
it must be carried on cleaning. Major cause of clean is must scour out the calcium oxide
boiler which on the sensor surface up. Clean the sensor in the tumbler (See picture).
Clean the filter drawer
Press the button to open the cover.
Unlock the fixer.
Pull out the filter drawer.
Clean lint, fiber and cotton raveling on the filter cloth by hand or with a soft piece of cloth.
When you notice a layer that may lead clogging on the filter cloth, please clean the layer by
washing in warm water. Let the filter cloth dry thoroughly before installing back the filter drawer.
Wash the filter drawer sponge by hand to remove the fiber and lint on the surface. After
washing the sponge. squeeze it by hand and remove the excess water. Well-dry the sponge
before storing it.
Clean the evaporator
Clean the lint accumulated on the fins of the evaporator located behind the filter drawer
with a vacuum cleaner or a soft brush. You can also clean by hand provided that you
wear protective gloves.
It is recommended to clean it at least twice every month.
Never attempt to clean with bare hands.Evaporator fins can harm your hand.
If you are unable to identify or solve the problem, contact our service centre. Before telephoning,
make a note of the model, serial number and purchase date of your machine: the Service Centre
will require this information.
This appliance must be earthed. In case of failure or damage, earth can provide a minimum resistance to
reduce the possibility of electric shock. The power cord has grounding wire with device and power cord
with plug. Plug must be inserted into a properly installed and grounded socket(in accordance with all local
rules and standards).
A separate earth is required by some local rules. In that case, you need buy grounding wire, clips and screws.
Caution!
Removing transport safety packaging foam
Water discharge
Procedure
Earth note
IMPORTANT: The appliance must not built-in.
Unpacking
All packing must be removed before using the appliance.
Check accessory
Open the accessory bag and check the accessories.
Care must be taken to ensure that the appliance does not stand on the electrical supply cable.
Any electrical work required to install this appliance should be carried out by a qualified electrician or
competent person.
Should the appliance be moved, it must be transported vertically.
650
220/50
Power(left-on mode)(W)
Power(off mode)(W)
Programme time at full load(min)
0.48
290
595X630X850
Ambient temperature range( )℃5 35
~
8.0
Energy efficient gear Daily
0.48
Lint and fibre that could not be captured by the lint filter are blocked in the filter drawer behind the cover.
Clean the filter drawer after each drying process. There is a two-level filter in the filter drawer. The first
level is the filter drawer sponge and the second level is the filter cloth.
IMPORTANT :
If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation,
a charge will be made even if the appliance is under guarantee.
It’s not necessary to dischargr the condensed water to the tank, it can be drained out directly.
change drainpipe
Pull out the water pipe by means of the arrow direction ,Then install the drainpipe.
Such as the pilers can be used if it is difficult to do.
Before use the machine, the packaging foam must be removed from the drum.
1.Open the loading door.
2.Pull off adhesive strips from inside machine on top of drum.
3.Remove the two packaging foam from the machine.
Check across the corner
When press on the edge, the machine should not shake up and down. (please check two direction) when
press on the top frame (across the corner), the dryer shakes, need to re-adjust the adjustable feet.
Do not put stacks of blanket or a rope on the floor, which could generrate some heat and affect the
machine running.
two packaging foam
drainpipe
manual
Quantity
It is dangerous to alter the specifications or attempt to modify this product in any way.
Malfunction Possible Cause Solution
Dryer does
not work
Drying results
unsatisfactory
Drum light does
not work(option)
Drying cycle ends
shortly after
programme starts.
"END" light
illuminated.
Drying cycle lasts
an unusually long
time
Mains plug is not plugged in.
Loading door is open.
Have you pressed the button?
Wrong programme selected.
Filter clogged.
Incorrect volume of laundry.
The sediment on humidity sensor.
Light bulb is defective.
Not enough washing loaded or
washing load is too dry for selected
programme.
Load volume is too big.
Select a different programme the next time
you dry(see "Drying Programme "section).
Clean lint filter.
Observe recommended loading volumes.
Washed hunidity sensor surface.
Replace light bulb.
Select higher drying level(e. g. Heavy instead
of Strong)
Reduce load volume.
Plug in at main socket.
Close loading door.
Press the button again.
DR8WHP
10

The hot air emitted by the tumble dryer can reach temperature of up to 60℃. The
appliance must therefore not be installed on floors which are not resistant to high
temperatures.
Any electrical work required to install this appliance should be carried out by aqualified electrician or competent
person.
THIS APPLIANCE MUST BE EARTHED.
The manufacturer declines any liability should this safety measure not be observed.
Before switching on, make sure the electricity supply voltage is the same as that indicated on the
appliance’s rating plate.
Should the plug need to be replaced for any reason, proceed as described below.
The wires in the mains lead are colored in accordance with the following code:
Green and Yellow-Earth
Blue -Neutral
Brown-Live
The wire colored green and yellow must be connected to the terminal marked with the letter or by the
earth symbol or colored green and yellow.
A cut off plug inserted into a socket is a serious safety (shock) hazard.
Ensure that the cut off plug is disposed of safety.
Permanent connection
In the case of permanent connection it is necessary that you install a double pole switch.
The switch must not break the yellow and green earth cable at any point.
The materials marked with the symbol are recyclable.
>PE<=polyethylene
>PS<=polystyrene
>PP<=polypropylene
This means that they can be recycled by disposing of them properly in appropriate collection containers.
Old machine
Use authorized disposal sites for your old appliance. Help to keep your country tidy!
The symbol on the product or on its packaging indicates that this product may not be treated
as household waste. Instead it should be taken to the appropriate collection point for the recycling of
electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment and human health, which could
otherwise be caused by inappropriate waste handling of this product. For more detailed information
about recycling of this product, please contact your local council, your household waste disposal
service or the shop where you purchased the product.
The Symbol mean: caution, risk of fire Oil-affected items can ignite spontaneously, especially when
exposed to heat sources such as in a tumble dryer. The items become warm, causing an oxidation
reaction in the oil. Oxidation creates heat. If the heat cannot escape, the items can become hot enough
to catch fire. Piling, stacking or storing oilaffected items can prevent heat from escaping and so create a
fire hazard. If it is unavoidable that fabrics that contain vegetable or cooking oil or have been contaminated
by hair care products be placed in a tumble dryer they should first be washed in hot water with extra
detergent - this will reduce, but not eliminate, the hazard.
Standard guarantee conditions
Do not over-dry laundry,this avoids creasing and saves energy.
Select the drying programme according to the type of laundry and the required degree of dryness.
Clean the filters regularly to avoid excessive drying times and high electricity consumption.
Ventilate the room well.
To save energy and to help protect the environ ment, we recommend that you follow these hints:
Try to load the maximum capacity of the machine as small loads are uneconomical.
We undertake that if within 12 months of the date of the purchase this appliance , we will, at our option
repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that:
The appliance has been correctly installed and used only on the electricity supply stated on the rating
plate.
The appliance has been used for normal domestic purposes only, and in accordance with the
manufacturer's instructions.
The appliance has not been serviced, maintained, repaired, taken apart or tampered with by any
person not authorised by us.
This guarantee is in addition to your statutory and other legal rights.
This guarantee does not cover
Damage or calls resulting from transportation, improper use or neglect, the replacement of any light
bulbs or removable parts of glass or plastic.
Appliances found to be in use within a commercial environment, plus those which are subject to rental
agreements.
Products of our manufacture which are not marketed by us.
Marking explanation
CE marking
VVolt
WHz
Tested safety
Watt Hertz
Alternating current
risk of fire
~
11

The hot air emitted by the tumble dryer can reach temperature of up to 60℃. The
appliance must therefore not be installed on floors which are not resistant to high
temperatures.
Any electrical work required to install this appliance should be carried out by aqualified electrician or competent
person.
THIS APPLIANCE MUST BE EARTHED.
The manufacturer declines any liability should this safety measure not be observed.
Before switching on, make sure the electricity supply voltage is the same as that indicated on the
appliance’s rating plate.
Should the plug need to be replaced for any reason, proceed as described below.
The wires in the mains lead are colored in accordance with the following code:
Green and Yellow-Earth
Blue -Neutral
Brown-Live
The wire colored green and yellow must be connected to the terminal marked with the letter or by the
earth symbol or colored green and yellow.
A cut off plug inserted into a socket is a serious safety (shock) hazard.
Ensure that the cut off plug is disposed of safety.
Permanent connection
In the case of permanent connection it is necessary that you install a double pole switch.
The switch must not break the yellow and green earth cable at any point.
The materials marked with the symbol are recyclable.
>PE<=polyethylene
>PS<=polystyrene
>PP<=polypropylene
This means that they can be recycled by disposing of them properly in appropriate collection containers.
Old machine
Use authorized disposal sites for your old appliance. Help to keep your country tidy!
The symbol on the product or on its packaging indicates that this product may not be treated
as household waste. Instead it should be taken to the appropriate collection point for the recycling of
electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help
prevent potential negative consequences for the environment and human health, which could
otherwise be caused by inappropriate waste handling of this product. For more detailed information
about recycling of this product, please contact your local council, your household waste disposal
service or the shop where you purchased the product.
The Symbol mean: caution, risk of fire Oil-affected items can ignite spontaneously, especially when
exposed to heat sources such as in a tumble dryer. The items become warm, causing an oxidation
reaction in the oil. Oxidation creates heat. If the heat cannot escape, the items can become hot enough
to catch fire. Piling, stacking or storing oilaffected items can prevent heat from escaping and so create a
fire hazard. If it is unavoidable that fabrics that contain vegetable or cooking oil or have been contaminated
by hair care products be placed in a tumble dryer they should first be washed in hot water with extra
detergent - this will reduce, but not eliminate, the hazard.
Standard guarantee conditions
Do not over-dry laundry,this avoids creasing and saves energy.
Select the drying programme according to the type of laundry and the required degree of dryness.
Clean the filters regularly to avoid excessive drying times and high electricity consumption.
Ventilate the room well.
To save energy and to help protect the environ ment, we recommend that you follow these hints:
Try to load the maximum capacity of the machine as small loads are uneconomical.
We undertake that if within 12 months of the date of the purchase this appliance , we will, at our option
repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that:
The appliance has been correctly installed and used only on the electricity supply stated on the rating
plate.
The appliance has been used for normal domestic purposes only, and in accordance with the
manufacturer's instructions.
The appliance has not been serviced, maintained, repaired, taken apart or tampered with by any
person not authorised by us.
This guarantee is in addition to your statutory and other legal rights.
This guarantee does not cover
Damage or calls resulting from transportation, improper use or neglect, the replacement of any light
bulbs or removable parts of glass or plastic.
Appliances found to be in use within a commercial environment, plus those which are subject to rental
agreements.
Products of our manufacture which are not marketed by us.
Marking explanation
CE marking
VVolt
WHz
Tested safety
Watt Hertz
Alternating current
risk of fire
~
12

13 14
Electric diagram
PE
Red
White
Brown
N
L
Humidity sensor
Outlet temperature
Heating tube temperature
CN12
CN14
pump
CN10
MOTOR
Fan
CN9
Lamp
F
CN6
P
M
White
CN8
White White
White
CN20
Door
Buoy
S6
S5
S4_1
CN3
White Blue
CN5
Compressor
White
CN4
PE
PE
L
LED
Power switch
CN2
SW1
S1
CN1
CN1
White
Programme selector dial
Operating panel
White
White
Filter Drawer
13
