Partner PAT-120 User manual
PAT-120 Quick Start Guide
Identifying components
Docking
10.1
Touch Panel
Front Camera
Vol- Vol+ Power*
DC-in Jack
DC-in Jack
LAN
Cash Drawer USB
USB
COM
Power Switch*
Micro USB 3.0
Rear Camera SIM Slot (optional)
Speakers
Mini HDMI
Headphone +
Mic 3.5mm
Feed Button
Printer Door
Release Button
Printer Door
MSR (optional)
IC Card Reader
(optional)
Fingerprint
(optional)
RFID (optional)
Note
* Tablet can only be powered off when Docking Power Switch has been turned
off.
Federal Communications Commission (FCC) Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This device has been tested and found to comply with the limits for a Class B digital device, pursuant to part
15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Non-modification Statement
Changes or modifications not expressly approved by the manufacturer responsible for compliance could void the
user
s authority to operate the equipment.
SAR notice
The highest SAR value for the device as reported to the FCC less than 1.6W/kg (limit set by the FCC is 1.6W/kg)
when placed next to the body. The FCC has granted an Equipment Authorization for this device with all reported
SAR levels evaluated as in compliance with the FCC RF exposure guidelines.
Taiwan NCC
( 12
14 )
• (NCC)
•
Battery Warning
Li-ion batteries can be dangerous. There is a danger of explosion if the battery is incorrectly replaced. Do not
expose to fire or water.
To reduce the risk of fire or burns, do not disassemble, crush, puncture, or short external contacts. Dispose of
used batteries according to state or local hazardous waste requirements.
Safety information
Before installing and using the machine, take note of the following precautions:
• Do not place the unit on an unstable surface, cart, or stand.
• Do not block the slots and opening on the unit, which are provided for ventilation.
• Only use the power source indicated on the marking label. If you are not sure, contact your dealer or the
Power Company.
• When replacing parts, ensure that your service technician uses parts specified by the manufacturer.
• Do not place anything on the power cord. Place the power cord where it will not be in the way of foot
traffic.
PAT-120 Specification
Item Tablet
Processor Intel®Processor Atom™ x5-Z8350 1.44GHz (2M Cache, up to 1.92 GHz)
OS Android 5.1Windows 10
Memory 2GB 4GB
Storage 16GB 64GB
Display 10.1", 1280x800, 300 nits
Touch Projected capacitive touch (Multi Touch)
Bluetooth V4.0+HS
WiFi 802.11 b/g/n
Camera Front Camera 2.0MP AF, Rear Camera 8.0MP AF
Battery Rechargeable Li-ion battery 3.8V, 7900mAh
Working time 8 hours@ film with speaker, 75% brightness, WiFi/BT on
Speaker Internal, 1*0.7W
WWAN (optional) UMTS (WCDMA) : 900/2100MHz, GSM/GPRS/EDGE : 900/1800MHz
Sensor G-sensor
I/O
1* SIM slot (optional) 2* Volume Up and Down button
1* Micro USB 3.01* Mini HDMI
1* Headphone + Mic 3.5mm 1* DC in
1* Power button
1* POGO Pins (for Docking), including charging function
Power Adaptor (optional) AC Input : 100~240V~0.5A, 50-60HzDC Output: 5V, 3A
Temperature Operation temperature: 0C ~ 40CStorage temperature: -20C ~ 60C
Humidity 5% to 85% (non condensing)
Dimension 262 (W) x 11.1(D) x 175 (H) mm
Weight 790g
Certification CE/FCC/BSMI/NCC/VCCI/TELEC/CCC
Docking Specification
Item Docking
I/O
1x DC jack 1x Ethernet
1x RJ-11 for cash drawer 5x USB type A
1x RS-232 Male 9pins 1x Power Switch
1x Paper roll cover release button 1x Paper feed button
LED
1x Green LED for power indication
1x Red/Green LED for charging indication
1x Red LED for paper empty indication
Power Adaptor AC Input : 100V-240V, 2A, 50-60Hz
DC Output: 24V, 3A
Printer
Front paper out 80mm 203 DPI 160mm/s
58mm spacer (optional)
Auto cutterPaper near end sensorPaper end sensor
Optional Peripherals
(Factory options) MSR IS07811-Track 1,2,3, IC Card, RFID, FingerprintPSAM
Dimension 269 (W) x 249 (D) x 295 (H) mm
Weight 2.475kg
Contact Information
Partner Tech Corporation
10F., No.233-2, Baoqiao Rd.,
Xindian Dist., New Taipei City
231, Taiwan
www.partner.com.tw
