Partner OT-100 User manual

OT-100
User Manual

i
Copyright
This publication, including all photographs, illustrations and software, is protected under international
copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be
reproduced without written consent of PARTNER Tech Corp.
Disclaimer
The information in this document is subject to change without notice. The manufacturer makes no
representations or warranties with respect to the contents hereof and specically disclaims any implied
warranties of merchantability or tness for any particular purpose. The manufacturer reserves the right to
revise this publication and to make changes from time to time in the content hereof without obligation of the
manufacturer to notify any person of such revision or changes.
Trademark recognition
All product names used in this manual are the properties of their respective owners and are acknowledged.
Federal Communications Commission (FCC)
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment onto an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
Shielded interconnect cables and a shielded AC power cable must be employed with this equipment to
ensure compliance with the pertinent RF emission limits governing this device. Changes or modications not
expressly approved by the system’s manufacturer could void the user’s authority to operate the equipment.
Declaration of conformity
This device complies with part 15 of the FCC rules. Operation is subject to the following conditions:
This device may not cause harmful interference, and
This device must accept any interference received, including interference that may cause undesired operation.

ii
Revision history
Version 1.0, August 2009
Version 1.1, February 2010
About this manual
This manual is intended for system administrators who are familiar with setting up a new system and
installing programs.
The manual consists of the following sections:
Chapter 1 Getting Started: This section covers unpacking and checking the
package contents, identifying components, charging
the battery, installing the SD card, and powering on the
device.
Chapter 2 Using The Device: This section provides information on how to use the
device features.
Chapter 3 Using The Accessories: This section provides information on how to use the
accessories.
Appendix: The appendix covers troubleshooting, information
on having the OT-100 serviced, supported Bluetooth
proles, and technical specications.
Safety information
Before installing and using the OT-100, take note of the following precautions:
SAR compliance for body-worn operations requires at least 2 cm of separation between the device and
the user’s body
Request service for damaged products: Turn off the product, unplug it from the electrical outlet, and
request service from a service partner under the following conditions:
The power cord or plug is damaged.•
Liquid has been spilled into the product.•
An object has fallen into the product.•
The product has been exposed to rain or water.•
The product has been dropped or damaged.•
The product does not operate normally when you follow the operating instructions.•
Avoid hot areas: The product should be placed away from heat sources such as radiators, heat registers,
stoves, and other products (such as ampliers) that produce heat.
Allow the product to cool: Allow the product to cool before removing covers and touching internal
components.
Avoid wet areas: Never use the product in a wet location.
Avoid inserting objects into product: Never insert objects of any kind into slots or other openings in the
product.
Clean the product properly: Unplug the product from the wall outlet before cleaning it. Do not use liquid
cleaners or aerosol cleaners. Use a soft cloth dampened with water for cleaning exterior components, but
NEVER apply water directly to the product or to an LCD screen.

iii
Use the product with approved equipment: Use your product only with the computers and accessories
identied as suitable for use with your product.
Adjust the volume: Turn down the volume before using headphones or other audio devices.
When device will not be used for a long period of time, please remove the battery, and store both device
and battery in a cool, dark, and dry place. For storage over a long period of time, please place product
in a dry box.
SAR compliance for body-worn operations requires at least 2 cm of separation between the device and
the user’s body.
Battery Handling Precaution
Do not attempt to disassemble or reconstruct the packs.• The battery has integrated protection circuits
and safety functions to avoid danger. If battery is damaged, it may rupture, generate heat, or cause smoke
and ame.
Do not short circuit battery.• Neither short connect the positive terminal and negative terminal with
metals, nor carry or store the battery with metal objects. If the battery is short circuited, excessive large
current will ow and generate heat, rupture or ame will occur, and also it will cause heat generation for
metals. Please cover the plug with waterproof cap when not using the battery.
Do not incinerate or heat the battery.• This will cause the insulator to melt, damage the gas release vent,
and cause loss of safety function, or electrolyte ignition. Above mentioned matters will cause battery to
rupture, generate heat, or cause smoke and ame.
Do not use near high temperature areas.• Do not use or leave battery near re, stove or heated areas of
more than 80˚C, to avoid melting of the polymer separator which would cause internal short circuits to
occur in individual cells, and cause the battery to rupture, generate heat, or cause smoke and ame.
Do not immerse the battery in water, seawater, or get it wet.• This may cause internal short circuits to
occur within individual cells, and cause the battery to rupture, generate heat, or cause smoke and ame.
Donotchargebatterynearreorundertheblazingsun.• If the battery protection circuit does not
function properly due to high temperature, or it is broken, the battery will be charged at an abnormal
current, and abnormal chemical reaction may occur, causing the battery to rupture, generate heat, or cause
smoke and ame.
Onlyusetheofcialproductchargerandobservethechargingrequirement.• If the battery is charged
in unusual conditions, it will cause loss of safety functions, or abnormal chemical reactions, causing the
battery to rupture, generate heat, or cause smoke and ame.
Do not try to damage the battery.• Do not drive a nail into the battery, strike it with a hammer, or tread on
it. The impact will cause leakage, causing the battery to rupture, generate heat, or cause smoke and ame.
Do not attempt to solder anything onto the battery.• This will cause the insulator to melt due to heat, or
cause the gas release vent to break, causing the battery to rupture, generate heat, or cause smoke and ame.
Do not connect battery to a plug socket or car-cigarette plug.• Connecting high voltage to the battery,
means excessive current will ow in it, and cause the battery to rupture, generate heat, or cause smoke and
ame.
Do not use battery for powering other equipment.• If the battery is used for powering other equipment, it
will deteriorate its performance and cycle-life. At worst, abnormal current will ow, and cause the battery
to rupture, generate heat, or cause smoke and ame.
Do not touch a leaked battery directly.• If battery leaks and hands touch leaked electrolyte, wash your
hands with soap immediately. If leaked electrolyte gets into your eyes, do not rub them, and wash eyes

iv
immediately with fresh water. Consult a doctor immediately.
Donotcontinuetochargeoverspeciedtime.• If the battery has not nished charging over recommended
time, let it stop charging. There is a possibility that the battery might be defective, and continued charging
may cause the battery to deform, generate heat, or cause smoke or ame.
Do not insert battery into a microwave or high pressure container.• This may cause battery to deform,
generate heat, or cause smoke or ame, because of sudden heat, intense pressure, or damage to the sealing
condition of the battery.
Donotputleakedbatterynearre.• If liquid leaks from the battery, or the battery give outs a bad smell,
do not leave battery near ammable objects. Otherwise, the electrolyte leaked from battery will catch on
re.
Do not use an abnormal battery.• If battery has a bad smell, changes color, deforms, or causes something
wrong during usage, remove it from equipment or charger, and do not use. If an abnormal battery is used, it
may cause battery to rupture, generate heat, or cause smoke and ame.
WARNING
Warning! Batteries may explode if not handled properly. Do not
disassemble or dispose of them in fire. Keep them away from children.
Follow local regulations when disposing of used batteries.
警告
不正確地更換電池會有爆炸的危險。僅可更換為廠商建議的相同電池或相同型
式電池。請依據廠商說明書棄置電池。
注意
用错误型号电池更换会有爆炸危险务必按照说明处置用完的电池。
注意
正しく交換しないと電池が爆発する危険があります。製造業者の推奨する電
池又は同タイプの電池と交換して下さい。使用後の電池を捨てる時は製造業
者の指示に従って下さい。

v
TABLE OF CONTENTS
CHAPTER 1 GETTING STARTED................................................ 1
Unpacking the OT-100 ..................................................................................1
Checking the package contents ....................................................................2
Identifying components .................................................................................4
Charging Cradle.............................................................................................8
Setup the OT-100...........................................................................................9
Using the cradle ...........................................................................................12
Charge the device in cradle .........................................................................12
Charge the battery in cradle.........................................................................12
Changing the battery....................................................................................13
Using SD cards ............................................................................................16
Installing a SD card......................................................................................16
View the contents of a SD card....................................................................18
CHAPTER 2 USING THE DEVICE ............................................. 19
Entering text.................................................................................................19
Shortcut menus............................................................................................19
Windows CE help.........................................................................................19
Performing a reset........................................................................................20
Opening and closing programs ....................................................................20
Program switch ............................................................................................20
Status icons..................................................................................................20
Adjusting the volume....................................................................................21
Changing the device name ..........................................................................23
Entering owner information ..........................................................................24
Recalibrating the screen ..............................................................................26
Setting the date and time .............................................................................27
Turning WiFi on/off.......................................................................................29
Turning Bluetooth on/off...............................................................................31
Setting the screen rotation ...........................................................................32
Connecting to a WiFi network ......................................................................34
Automatically connect to a WiFi network .................................................34
Manually connect to a WiFi network ........................................................35
Find your IP address................................................................................36
Specify the IP address and domain name servers (DNS) .......................36
Using Settings Manager...............................................................................39
Lock Screen .................................................................................................44

vi
Upgrading OS Image or Bootloader.............................................................48
Connect device to computer ........................................................................52
Install ActiveSync (for Windows XP)........................................................52
Synchronize your data with ActiveSync and Windows XP.......................52
Copy or move les between the computer and OT-100 ..........................54
Synchronize les between the computer and OT-100 .............................55
Install and remove programs ...................................................................58
CHAPTER 3 USING THE ACCESSORIES ............................... 61
Attaching the stylus cord..............................................................................61
Attaching the hand strap ..............................................................................62
Using the leather pouch ...............................................................................63
Attaching the leather pouch cord .................................................................64
Using the high quality stylus.........................................................................65
APPENDIX .................................................................................. 67
Troubleshooting ...........................................................................................67
Tips for Troubleshooting...............................................................................67
General Problems .......................................................................................67
Having the OT-100 Serviced .......................................................................68
Guidelines for care and maintenance ..........................................................68
Using the device ......................................................................................68
Cleaning the device .................................................................................68
Transporting and storing the device.........................................................68
Bluetooth supported proles ........................................................................69
Specications...............................................................................................70

1
CHAPTER 1
GETTING STARTED
This chapter describes the procedures from unpacking the OT-100, to powering it on. The following topics are
described.
Unpacking the OT-100 on page• 1
Checking the package contents on page• 2
Identifying components on page• 4
Charging Cradle on page• 8
Setup the OT-100 on page• 9
Using the cradle on page 1• 2
Charge the device in cradle on page 1• 2
Charge the battery in cradle on page 1• 2
Changing the battery on page 1• 3
Using SD cards on page 1• 6
Install a SD card on page 1• 6
View the contents of a SD card on page 1• 8
Unpacking the OT-100
The device and accessories are packed in a cardboard carton with foam padding for protection during
shipping.
Figure 1.1 Unpacking the OT-100
Carefully unpack the machine and keep the packing materials. If you need to ship it in the future, repack it as
shown in Figure 1.1.
OT-100
Accessories
package
Cradle
Adaptor
CD-ROM

2 CHAPTER 1 GETTING STARTED
Checking the package contents
After you unpack the device check that the following items are included.
OT-100 Stylus
Battery
High quality stylus
AC adaptor
Cradle
mini-USB to USB cable

3
If any item is missing or appears damaged, contact your dealer immediately.
Leather pouch Leather pouch cord Stylus cord
2 screws
Plastic hinge
Hand strap
Shoulder strap
CD-ROM with user
manual pdf le and
API
Quick start guide
QSG

4 CHAPTER 1 GETTING STARTED
Identifying components
This section describes the parts and connectors on the OT-100.
Front panel components
1
234
Figure 1.2 Front view
Component Description
1 4.3-inch touch screen
2Power indicator (Green: power on, Red: charging)
3Bluetooth indicator (Blue: Bluetooth is enabled)
4WiFi indicator (Green: WiFi is enabled)

5
Top and bottom panel components
1
Figure 1.3 Top and bottom view
Component Description
1 Top hand strap eyelet
2 3.5mm microphone jack
3 Mini-USB port
4 Cradle connector
5 DC power jack
6 3.5mm headphone jack
3
2
4
6
5

6 CHAPTER 1 GETTING STARTED
Left and right side components
Figure 1.4 Left and right side view
4
1
2
3
Connector Description
1 Reset button
2 Leather pouch strap eyelet
3 Standby button
4 Stylus dock

7
Back panel components
4
1
2
3
Connector Description
1 Top hand strap eyelet
2 Speaker
3 Battery cover
4 Bottom hand strap eyelet
Figure 1.5 Back view

8 CHAPTER 1 GETTING STARTED
Charging Cradle
This section introduces the charging cradle for the OT-100.
The charging cradle is used to charge the OT-100. A second slot is also available for charging a spare battery.
Top and front view of the cradle
4
1
2
3
Connector Description
1 DC power connector
2 Battery slot
3 OT-100 socket
4 Battery slot charging indicator
Figure 1.6 Top view of the cradle
Figure 1.7 Front view of the cradle

9
Setup the OT-100
Refer to the following to setup the OT-100.
Remove the battery1.
cover.
Slide the cover downwards to open.
Lift up to remove the battery cover.

10 CHAPTER 1 GETTING STARTED
Install the battery.2.
Align the battery connectors on the battery with the pins in the battery
compartment and insert the battery.
Replace the battery3.
cover.
Slide the battery cover back until it locks.
Install the screw if4.
required.

11
Insert the plastic hinge,5.
or attach the hand strap.
(Refer to Chapter
3 - Attaching the hand
strap).
Charge the battery.6.
Open the power jack cover. Plug the AC adaptor power cord into an
electrical outlet, then connect the DC plug of the adaptor cable to the
OT-100. It takes approximately 6 hours to fully charge the battery for the
rst time. Subsequent charges might take longer.
CAUTION
To avoid damaging OT-100 or the AC adaptor,
make sure all connectors are properly
connected.
Device will7.
automatically start up
when charged battery or
adaptor is inserted. The
Standby button can be
used to enter and exit
Standby mode.

12 CHAPTER 1 GETTING STARTED
Using the cradle
The charging cradle allows a more convenient way to charge OT-100. You can charge a spare battery
(optional) individually or simultaneously as well.
Charge the device in cradle
Plug the AC adaptor power cord into an electrical1.
outlet, then connect the DC plug of the adaptor
cable to the power jack at the back of cradle.
Insert OT-100 into the cradle with front of device on2.
same side as front of cradle.
When device is inserted into cradle correctly, the3.
Power LED on top left of device should turn red.
Device charging is complete when the device Power
LED turns green.
Charge the battery in cradle
Plug the AC adaptor power cord into an electrical outlet, then connect the DC plug of the adaptor cable to1.
the power jack at the back of cradle.
Align the battery connectors on the battery with the2.
pins in the second battery slot of the cradle, then
install the battery in the direction of the arrow.
When battery is inserted into cradle correctly, the3.
battery LED on the cradle should light up red.
Battery charging is complete when the battery LED
on the cradle turns green.
IMPORTANT
To protect and prolong the life of the battery, do not charge it for 24
hours or longer at a time.
If battery is not used, please store in dry area, ideally with storage
temperature around 25˚C, or within a temperature range of -10˚C ~
30˚C to maximize longetivity.
IMPORTANT
