pascom ZONE-120 User manual

ZONE-120/240/360/480/600
Better CommunicationBetter CommunicationBetter CommunicationBetter Communication
A.T.T. 6 Zone Mixing Amplifier

Safety Precautions
CAUTION
In using the present device, please keep the following safety regulations in order to prevent
any hazard or material damage.
CAUTION Low level of risk which
could lead to minor or
moderate injury.
WARNING High level risk that could
result in death or serious
injury.
Don’t
Don’t dissemble
Keep off
Strongly Recommended
Unplug
Electricity Warning
Fire Warning
Do not plug several products in
one multi-outlet.
- This can provoke over-heating
and a fire.
Do not bend cable by force or
leave it under any heavy object.
- A damaged cable can cause
a fire.
When not in use for a long time,
leave the device unplugged.
- This is recommended to
extend device’s life.
Do not touch plug with your
hands wet.
Keep the device away from
water or humid area.
Unplug the device when in
thunderstorm.
- This might cause damage to
products and/or start a fire.
To help ventilation and avoid
over-heating, install this device
at least 5~10cm off from walls.
Don’t use non-Pascom products
connected with ours.
- It may cause damage to
products and/or start a fire.

Never dissemble or take apart
device! In case service is
needed, contact authorized
repair person only.
In case smoke or unusual noise
is found, unplug immediately
and contact authorized repair
person.
In case using DC power, make
sure to use correct power and
direction of batteries.
Make sure ventilation hole is
clear from any external metal
piece (e.g. coin) or flammable
object (e.g. paper or matchstick)
Fix plug tight into outlet.
Unstable plug might cause
a fire.
If power cable needs to be cut
and re-connected, make sure
power is off and device is
unplugged.
It can be very dangerous.
When unplugging, never pull
string. Make sure to hold plug.
Inner cable might cut inside
covering.
For installation, use only
provided screws and bolts to
fix firmly.
In case DC power is used,
make sure with power voltage
and current at every time.
DC
Make sure device is away from
heat or direct rays of the sun.
It might cause a fire.
In case AC switch breaker is
needed, be cautions with
electricity.
Clean device with only DRY
cloth.
Don’t drop any object onto the
device. Keep it away from
magnets. This might cause
damage to the device.
Device should be used only
within certified distance, by
provided cables only. This
helps performance.
Warrantee terms and conditions
vary by country and may not be
the same for all products. For
specific warranty information
about warranty or service,
contact Pascom co.,ltd directly
or authorized distributor for your
country or region.
WARNING!
CAUTION

ATT 6 ZONE MIXING AMPLIFIER
SPECIAL FUNCTION
① 6 ZONE SPEAKER OUTPUT
6 Speaker selector and 1 All Speaker button for selective zone addressing or all-area
addressing. Output power adjustable individually.
② PRIORITY FUNCTION
MIC1, MIC ALL, CHIME/SIREN and REMOTE AMP are prior to other signals.
(other sources are automatically muted)
③ 4-TONE CHIME
2 type 4-tone Chime is provided to use before and after announcement. Convenient
external chime terminal.
④ EMERGENCY ADDRESS
Automatic fire evacuation address is released as fire signal is received from contact type
fire signal receiver.
⑤ REMOTE POWER
Power is turned on/off by convenient remote control.
4. ZONE-120/240/360/480/600

ZONE-120/240/360/480/600 .5
ATT 6 ZONE MIXING AMPLIFIER
Front Panel
1.USB MEMORY TERMINAL
Compatible with USB memory or USB HDD.
(HDD has to be FAT 32 format and partitioned into 40 Gbytes to be found by the device.)
2.REMOTE SIGNAL RECEIVER
Receives remote controller signal of DVD Player remote controller.
3.VFD DISPLAY
Displays status of DVD or USB file.
4.DISC TRAY
Stores and plays disc
5. DVD, USB Play button
- OPEN/CLOSE disc tray.
- PLAY/PAUSE disc.
- STOP playing disc.
- PREV : Plays previous track
- NEXT : Plays next track.
- REPEAT files in disc or USB memory.
6. DVD VOLUME CONTROLLER
7. ZONE SELECTOR
- 6 Zone Selectors and 1 ALL CALL button.
- Attenuator adjusts output power.
①
⑭⑬ ⑮
② ③ ④ ⑤ ⑥ ⑦ ⑧
⑨
⑩
⑪
⑫
A.T.T 6 Zone Mixing Amplifier
-600
ZONE
ATTENUATOR 1 2 3 4 5 6
OUTPUT POWER 8.9V 12.5V 25V 50V 70V 100V

6. ZONE-120/240/360/480/600
ATT 6 ZONE MIXING AMPLIFIER
8. MONITOR SPEAKER VOLUME CONTROLLER
9. LED DISPLAY
- EM turns on when fire alarm signal is received.
- PHANTOM turns on when PHANTOM button in rear panel is on.
- PROTECTION turns on when protective circuit recognizes error.
* TEL lamp is not in use
10. OUTPUT LEVEL LED DISPLAY
Turn down output volume in case CLIP LED turns on and helps protect the device.
11. STAND-BY/POWER LED DISPLAY
Green light is on for stand-by mode. Press POWER button to start operation, and LED
turns red.
12. POWER BUTTON
Provides power and device starts operation.
13. CONDENSER MICROPHONE VOLUME CONTROLLER
14. CONDENSER MICROPHONE
Internal condenser microphone. Talk into this part when addressing.
15. TALK
Turns on condenser microphone. Hold while address is being made. Release
when finished.
16. 6 CHANNEL EQUALIZER AND VOLUME CONTROLLER
Provides ± 10 dB control of BASS(100Hz) and TREBLE(10KHz)
17. CHIME VOLUME
2way 4-tone chime release button and its volume controller.
Useful before and after announcement is made.
18. SIREN VOLUME
In case of emergency, you can release siren and adjust its volume.
(~) : undulating tone siren
(-) : one tone siren
19. MASTER VOLUME CONTROLLER
Controls the volume of finally mixed sound by individual adjustment.

ZONE-120/240/360/480/600 .7
ATT 6 ZONE MIXING AMPLIFIER
Rear Panel
1. SPEAKER TERMINAL
Pick 4 Ω output terminals or Zone 1~6, 100V terminals, so overload is prevented.
(*Note: Only Zone 1~6 terminals are controlled by SPEAKER SELECTORS on front panel.)
40hm 100V ZONE 1~6 Maximum output power
per zone
21.9V 83.3 Ohm
ZONE- 120
31V 41.7 Ohm
ZONE- 240
37.9V 27.8 Ohm
ZONE- 360
43.8V 20.8 Ohm
ZONE- 480
49V 16.7 Ohm
83.3 Ohm
41.7 Ohm
27.8 Ohm
20.8 Ohm
16.7 Ohm
20W
40W
60W
80W
100W
ZONE- 600
MODEL
①②⑬ ③ ④
⑤ ⑥ ⑦ ⑧
- +
~AC INPUT
AC 240V/50Hz,1700W FUSE(T10AL,250V)
AC 220V/60Hz,1700W FUSE(T10AL,250V)
AC 230V/50Hz,1700W FUSE(T10AL,250V)
AUDIO OUTPUT
100V123456 Sig GND
REMOTE AMP CHIME
+485 GND
LSLCENFL Y Pb/Cb Pr/Cr
VIDEO
S-VIDEOVIDEOCOAXRSRSUBFR
5.1CH 2CH
4
10 50
POWER DC POWER
ON 24V
+
COM
56
PC LINK
L
PHANTOM PHANTOM PHANTOM
123
GAIN
PHANTOM
OFF
MIC1
ALL
RS232
EM
OUTPUT
OPT
FIRE
Sig+
REC OUT
PC IN (BAL)
PRE OUT
PC IN (ST)
AMP IN
LINE IN
R
TALK
4
MADE IN KOREA
FUSE INSIDE
GAINGAINGAIN
_
_
_ _
10 50
_ _
10 50
_ _
10 50
_ _
+
485 485 485
_
PRIORITY
MIC
S/N XX
CLASS I
LASER PRODUCT
⑨ ⑩ ⑪ ⑫
2. REMOTE CONTROL INPUT TERMINAL
- If remote address is wanted, connect REMOTE AMP terminal with remote
amplifier (DRA-9600).
- Top line: SIG+,SIG- and GND for vocal signals, FIRE terminals for automatic
emergency evacuation address by short circuit.
- Bottom line: left side 485+,485- and GND for remote amplifier and other line
signals.
(Right side 485+ and 485- are not in use)
- Connect CHIME with remote chime release button.

8. ZONE-120/240/360/480/600
ATT 6 ZONE MIXING AMPLIFIER
3. RS232 TERMINAL
Enables PC control in short distance.
(*Only master volume and zone selection is available)
4. DVD OUTPUT TERMINAL
Enables sound and/or visual control of DVD player. Connects with external receiver or
LCD TV.
*Refer to “HOW TO CONNECT” for detail.
5. POWER INPUT
Connects with power cable.
*Double check power voltage before connecting!
6. EM OUT
Sends fire alarm contact signal in case of emergency.
7. POWER ON
Enables remote power control.
8. DC INPUT
Connects with DC power(+24 V) battery for temporary use. Make sure with polarity(+/-).
Cables have to be diameter of 3.0mm or over, and length of 8m or less. (power loss ≤1V,
FUSE is F3, F4 on POWER PCB)
- Capacity Remarks:
ZONE-120 : T10A/250V ZONE-240 : T20A/250V
ZONE-360 : T15A/250V X 2 ZONE-480 : T20A/250V X 2
ZONE-600 : T25A/250V X 2
9. EXTERNAL DEVICE JACK
- AMP IN : When connected, all other speaker output is muted but only
signals by this connection is released.
- PRE OUT, REC OUT : Used for another external device to record sound of this device,
or used for another amplifier by parallel connection.
* REC OUT level is -10dB, PRE OUT level is 0dB.
- PC IN ST/BAL : receives sound signal from PC.
* PC connection remarks:
STEREO Jack with TIP(LEFT), RING(RIGHT), SLEEVE(GND)
BALANCE with TIP(HOT), RING(COLD), SLEEVE(GND)
- PC OUT : When connected, PC signals received can release to linked amplifier.
(BALANCED)

8. ZONE-120/240/360/480/600
ATT 6 ZONE MIXING AMPLIFIER
3. RS232 TERMINAL
Enables PC control in short distance.
(*Only master volume and zone selection is available)
4. DVD OUTPUT TERMINAL
Enables sound and/or visual control of DVD player. Connects with external receiver or
LCD TV.
*Refer to “HOW TO CONNECT” for detail.
5. POWER INPUT
Connects with power cable.
*Double check power voltage before connecting!
6. EM OUT
Sends fire alarm contact signal in case of emergency.
7. POWER ON
Enables remote power control.
8. DC INPUT
Connects with DC power(+24 V) battery for temporary use. Make sure with polarity(+/-).
Cables have to be diameter of 3.0mm or over, and length of 8m or less. (power loss ≤1V,
FUSE is F3, F4 on POWER PCB)
- Capacity Remarks:
ZONE-120 : T10A/250V ZONE-240 : T20A/250V
ZONE-360 : T15A/250V X 2 ZONE-480 : T20A/250V X 2
ZONE-600 : T25A/250V X 2
9. EXTERNAL DEVICE JACK
- AMP IN : When connected, all other speaker output is muted but only
signals by this connection is released.
- PRE OUT, REC OUT : Used for another external device to record sound of this device,
or used for another amplifier by parallel connection.
* REC OUT level is -10dB, PRE OUT level is 0dB.
- PC IN ST/BAL : receives sound signal from PC.
* PC connection remarks:
STEREO Jack with TIP(LEFT), RING(RIGHT), SLEEVE(GND)
BALANCE with TIP(HOT), RING(COLD), SLEEVE(GND)
- PC OUT : When connected, PC signals received can release to linked amplifier.
(BALANCED)
ZONE-120/240/360/480/600 .9
ATT 6 ZONE MIXING AMPLIFIER
10. LINE INPUT 5, 6 JACK
Connects with Line level device. Input Level is -20 dB (STEREO)
11. MIC, LINE INPUT 1~4.
INPUT 1~4: either microphone or line available. Individual power button for phantoms.
Input GAIN ranges -10dB ~ -50dB.
*XLR connector is needed to use phantom powered condense microphone.
(phantom power can’t be used by ¼” phone jack.)
* CAUTION!
In case phantom power is used, strong impulse noise might damage speakers.
It is recommended to minimize GAIN volume and master volume on front panel
before turning on phantom power.
Also, make sure phantom power is off before connecting/disconnecting microphone
and avoid strong impulse noise.
12. PRIORITY
ALL : Microphone and Chime/Siren are prior to other signals
MIC1 / TALK : Microphone 1, condenser microphone and Chime/Siren are prior to
other signals.
OFF : Only Chime/Siren is prior to other signals.
* General Address Priority
1. Fire Evacuation,Chime/Siren, Remote Amp, PC In.
2. Mic (Set by PRIORITY Switch)
3. Line 5/6 DVD Player.
13. TELEPHONE
Connect INPUT terminal with trunk or telephone switcher LINE.
Connect LINK terminal with regular telephone and now it is ready to use.
When ring signal is sent to INPUT terminal, ring tone will release to the selected zone.
During ring signal INPUT, double check ZONE SELECTOR lamps.
This will help avoid malfunction and operate system properly.
You can adjust Ring signal volume by Chime Volume knob on front panel.

10. ZONE-120/240/360/480/600
ATT 6 ZONE MIXING AMPLIFIER
DVD PLAYER OPERATION

ZONE-120/240/360/480/600 .11
ATT 6 ZONE MIXING AMPLIFIER
REMOTE CONTROLLER
① Power On/Off
② Video mode selector(Composite, Component,
S-Video, VGA)
③ TV system mode selector (NTSC, PAL)
④ Open/close CD tray
⑤ REPEAT : One or all Track
A-B : Repeat section
RANDOM : Select and play randomly
USB/DVD : Select button
LANGUAGE : Voice language select
SUBTITLE : Caption language select
ANGLE : Convert the angle of DVD image
R/L : Right/left selector for output
⑥ REW : Rewind track during playback
FWD : Forward track during playback
PREV : Move to previous track
NEXT : Move to next track
SETUP : Setup system preference
MENU : Display DVD menu during playback
⑦ Move or select the menu title
PBC : Display index of tracks in VCD
TITLE : Display index of tracks in DVD
⑧ ZOOM : Enlarge or downsize the image in
play
PLAY/PAUSE : to play or pause
STOP : Stop playing
RETURN : stop playback and move back to
previous menu
SLOW : Play image slowly
STEP : Play video by scene
PROG : sort playlist by the title, chapter,
or music
⑨ 1~10 : Select track to play.
TIME : Displays proceeding/remaining time
in current play.
⑩ OSD : Display caption on TV in configuration
MUTE : Mute/unmute sound
VOL + - : Controls the volume
6
5
7
8
9
10
POWER VIDEO MODE N/P
OPEN/CLOSE
REPEAT A-B
LANGUAGE SUBTITLE
RANDOM USB/DVD
R/L
REV FWD PREV NEXT
ANGLE
SETUP MENU
ENTER
PBC
TITLE
ZOOM PLAY/PAUSE STOP RETURN
SLOW STEP PROG CLEAR
1 2 3 4
5 6 7 8
9 0/10 10+ TIME
OSD MUTE VOL- VOL+
1234

12. ZONE-120/240/360/480/600
ATT 6 ZONE MIXING AMPLIFIER
How to use DVD, CD DISC
Available types of media and usage
- DVD, DVD-R, DVD+R, DVD_RW, CD, HDCD, CD-R, CD+R, CD_RW, MP3 CD, AVI CD, JPG CD
① Open the tray using the OPEN/CLOSE button, and press the OPEN/CLOSE button after putting
CD or DVD into the tray.
② If CD or DVD aren't on the tray or there is some problem, the screen shows "NO DISC"
③ Play CD or DVD as pressing the PLAY/PAUSE button.
④ If you press the PLAY/PAUSE button during playing, it will pause.
⑤ If you press the STOP button once during playing, CD or DVD will stand by in the PRE STOP state.
⑥ By pressing the PLAY/PAUSE button in the PRE STOP state,
CD or DVD replay and they stop completely by pressing the STOP butthzon.
- In case DISC is already on the tray when you power on
① It reads the track on the DISC.
② After selecting the desired DISC, operate by pressing the PLAY button.
PLAY Function
① After inserting a DISC, press the PLAY button.
② Start playing the DISC.
③ By pressing the REPEAT button of the remote control,
the selected track will be played back repeatedly.
OFF ---> Repeat one ---> Repeat All ---> OFF
④ By using the A-B button of the remote control, a designated section will be repeated.
Repeat OFF ---> Repeat A- ---> Repeat A-B ---> Repeat OFF
⑤ Finish the playing when all music has played.
Repeat Function
- Become the repeat function by pressing the REPEAT button of the remote control while playing CD or DVD.
① When starting
The repeat function is OFF state. Operate it by pressing the PLAY button.
② During a general operation
The repeat function operates by pressing the REPEAT button.
OFF ---> Repeat one ---> Repeat All ---> OFF ---> ....
③ REPEAT ONE
☞ The selected track will be played back repeatedly.
④ REPEAT ALL
☞ All music of the inserted disc will be played back repeatedly.

ZONE-120/240/360/480/600 .13
ATT 6 ZONE MIXING AMPLIFIER
A-B Section-Repeat Function
- By designating the area of section-repeat using the A-B button, it plays the designated section repeatedly.
① When starting
Operate by pressing the PLAY button.
② During a general operation
Designate by pressing the A-B button at the start point of the repeat section.
Designate by pressing the A-B button at the end point of the repeat section.
☞ - Repeat Cancel ---> set A point(press A-B button) --->
set B point(press A-B button) ---> A-B Repeat....
RANDOM Function
- Select and play a music of the inserted disc at discretion by pressing RANDOM button.
SEARCH Function
-Wind faster forward or backward by pressing the SEARCH button ◀◀,▶▶ during playback.
☞ The winding speed is adjusted by X2, X4, X8, X20 in speed unit as pressing this button once.
STEP Function
-A movie changes to a pause picture by each scene as pressing the
STEP button once while playing DVD movie.
SLOW Function
-A movie changes to a pause picture by each scene as pressing the SLOW button while playing DVD movies.
☞ It is adjusted by 1/2, 1/3, 1/4, 1/5, 1/6, 1/7 in 6 step as pressing the SLOW button.
ZOOM Function
- Enlarge/Reduce the picture screen by pressing the ZOOM button while playing DVD movies.
☞ It is adjusted by zoom2, zoom3, zoom4, zoom1/2, zoom1/3, zoom1/4 in 6 step as pressing
the SLOW button.

14. ZONE-120/240/360/480/600
ATT 6 ZONE MIXING AMPLIFIER
How to operate USB
- Play MP3 file
You can play USB Memory or HDD.
HDD has to be formatted with FAT32.
Especially, external HDD has to be partitioned into every 40 Gb, too.
3.5 inch HDD with its own power supply is recommended. 2.5 inch HDD might not be found when
its power consumption is bigger than power supply.
USB Memory made by certain manufacturers might not be found.
- Play AVI file
You can play DIVX of AVI format. Clips might break up, play slowly or won't start according to
capacity and resolution of each file.
- Play JPG file
You can play JPG images in USB memory or HDD.

How to connect with Channel System
◆ Make sure that this device and Receiver are both turned off and unplugged.
LSLCENFL Y Pb/Cb Pr/Cr
OPT VIDEO
S-VIDEOVIDEOCOAXRSRSUBFR
5.1CH 2CH
1 2 3 4 5 6
7
1. 5.1 CH Analog Speaker Jack
2. Stereo Jack(Regular TV, 2CH)
3. COAXAL jack
4. Regular TV VIDEO jack
5. S-Video Logic
6. Optical terminal
7. Component Jack for HD TV
CD
R
L
5.1IN
FL
FR
CE
SW
SL
SR
LSLCENFL Y Pb/Cb Pr/Cr
OPT VIDEO
S-VIDEOVIDEOCOAXRSRSUBFR
5.1CH 2CH
▶ By provided RCA cable, you can connect with receiver, amplifier or other stereo input Jack.
Red into Right, White into Left.
Receiver
rear panel
ZONE-120/240/360/480/600 .15
ATT 6 ZONE MIXING AMPLIFIER

How to connect with a regular TV
◆ Make sure that this device and TV are both turned off and unplugged.
VIDEO
Yellow
VIDEO
SOUND
SOUND
White
L
Red
L R
R
▶ Plug in 3-colored RCA connector cable into female jack on the rear panel of the device.
▶ Yellow is for [VIDEO] jack, red is right sound channel for [R] jack, and white is left
sound channel for [L] jack. In case of mono TV, either red or white is fine.
▶ Change TV mode to [EXTERNAL INPUT] mode by your TV remote controller.
LSLCENFL Y Pb/Cb Pr/Cr
OPT VIDEO
S-VIDEOVIDEOCOAXRSRSUBFR
5.1CH 2CH
16. ZONE-120/240/360/480/600
ATT 6 ZONE MIXING AMPLIFIER

ZONE-120/240/360/480/600 .17
ATT 6 ZONE MIXING AMPLIFIER
How to connect with a HD TV
◆ Make sure that this device and TV are both turned off and unplugged.
◆ In case of component connection, change video setting to [COMPONENT]mode.
You can adjust on [SETTING] or by using device remote controller's [VIDEO MODE] button.
▶ Plug in each connector into relevant component jack on rear panel of the device.
Green into Y, blue into Pb/Cb, Red into Pr/Cr.
▶ Plug in 3 colored RCA connector cable into 2CH jack on rear panel of the device.
Red into L, White into R. (Yellow is not used)
▶ Turn on TV and the device, change video mode on SETTING: [SYSTEM SETUP]☞
[VIDEO]☞[P-SCAN YPBPR]. If there is no signal, use device remote controller's
[VIDEO MODE] button and change to [P-SCAN YPBPR] mode.
LSLCENFL Y Pb/Cb Pr/Cr
OPT VIDEO
S-VIDEOVIDEOCOAXRSRSUBFR
5.1CH 2CH
SOUND VIDEO
White Red
L R Y Pb/Cb Pr/Cr
Green Blue Red

5.1 How to connect with Channel Analog System
◆ Make sure that this device and receiver are both turned off and unplugged.
▶ Connect 5.1CH output signal with receiver as the picture above and enjoy spectacle 3D sound.
▶ Connector cable is not provided in this package. Please purchase separately.
5.1IN CD
R
LFL
FR
CE
SW
SL
SR
LSLCENFL Y Pb/Cb Pr/Cr
OPT VIDEO
S-VIDEOVIDEOCOAXRSRSUBFR
5.1CH 2CH
Receiver
rear panel
18. ZONE-120/240/360/480/600
ATT 6 ZONE MIXING AMPLIFIER

SPECIFICATION
■ OUTPUT POWER ------------------------------------------------------------ 360W
■ INPUT SENSITIVITY
MIC 1~4 ------------------------------------------------------------------ -54dB
LINE 1~4 ----------------------------------------------------------------- -14dB
LINE 5~6 ----------------------------------------------------------------- -16dB
PC IN(ST) ----------------------------------------------------------------- -10dB
PC IN(BAL) ---------------------------------------------------------------- -10dB
■ FREQUENCY RESPONSE
MIC 1~4 ----------------------------------------------------------- 100Hz ~ 14KHz
LINE 1~4 ------------------------------------------------------------ 90Hz ~ 16KHz
LINE 5~6 ------------------------------------------------------------ 90Hz ~ 18KHz
SIREN ---------------------------------------------------------------- 630Hz
■ SIGNAL TO NOISE (on WTD 30KHz)
MIC ------------------------------------------------------------- Better than 55dB
LINE ------------------------------------------------------------- Better than 70dB
■ TOTAL HARMONIC DISTORTION (on WTD 20KHz) ---------------------------- Less than 1 %
■ POWER SOURCE --------------------------------------------- ~AC 230V/50Hz, DC 24V
■ POWER CONSUMPTION ----------------------------------- ZONE-360 : 380W(1/8 POWER)
■ DIMENSION -------------------------------------------------- 482(W)x88(H)X340(D)mm
■ WEIGHT -------------------------------------------------------------------- 21 Kg
ZONE-120/240/360/480/600 .19
ATT 6 ZONE MIXING AMPLIFIER

NOTE.
20. ZONE-120/240/360/480/600
ATT 6 ZONE MIXING AMPLIFIER
