Paser Maestro 2.0 Instructions for use

WARRANTY
THIS PRODUCT IS COVERED BY TWO-YEAR GUARANTEE FOR ANY MANUFACTURING TROUBLES.
THE WARRANTY IS VALID IF
ACCOMPAINED BY THE INVOICE OF PURCHASE
The information in this guide are purely for information purposes, therefore, are subject to change without notice. At the time of publication the information
is correct and reliable. However Paser can not be held responsible for any consequences resulting from errors or omissions in this manual. Paser reserves
the right to improve / change the product or manual without obligation to notify users.
Manufactured and distributed by:
PASER s.r.l. Strada Per Poirino 29 Villanova d'Asti (AT), 14019 Italy
Tel. [phone] Fax. [phone]
Tech service 0039 (0)141 947676
Office hours (8.30-12.30 14.30-18.30) www.paser.it; [email protected]
TROUBLESHOOTING
The radio band frequency is disturbed.
Select a different radio frequency as descried in the MENU SET UP in sub menu FREQUENCY at
pages 7 and 8.
The audio is distorted and it is too low.
Verify that the antennas plugs are correctly connected.
If the problem is with your USB, carry out a scanning of your MP3 files using MP3GAIN in order to
normalize the volume. If the problem is with the AUX IN input, adjust the volume directly on the
source.
After the connection of MAESTRO 2.0 the steering wheel commands don’t manage any functions .
Verify the correct connection of MAESTRO 2.0 to the power cables of the vehicle.
Make a RESET of MAESTRO 2.0 as described at page 6 of this manual.
Verify that the CANBUS, GMLAN or Resistive connections were done correctly.
Verify that the vehicle is in the compatibility list.
Verify that in case of resistive vehicle protocol, the self learning procedure was done correctly.
It’s not possible to carry out the self learning procedure for the resistive steering wheel commands.
Make the self learning procedure of the steering wheel commands being sure to keep pressed each
buttons for minimum 2 seconds.
Verify the vehicle compatibility consulting the connections attachment.
When the car is off, MAESTRO 2.0 doesn’t switch off.
Verify the ignition connections, if the vehicle is CANBUS the connection of the ignition wire it is not
obliged, if the vehicle is Resistive verify that the ignition wire is connected correctly.
MAESTRO 2.0 doesn’t play the files stored in the USB pen.
Be sure that the files stored are in MP3, AAC, WMA or M4A format and that the USB pen is working.
It is suggested to format the USB pen in FAT 32 mode with 512bytes sectors.
Remove files from the USB pen, format it and reload all files in the USB pen.
MAESTRO 2.0 is correctly working but it is not possible to enter the menu with the steering wheel
commands.
Verify which mode of working to use between A and B as described at pages 10 and 11. Attention
some models of swc don’t have the long press condition.
MAESTRO 2.0 doesn’t play automatically the music from the USB pen during the start up.
Some USB pens don’t allow to start the reproduction during the switch on, if it happen please remove
and insert again the USB pen.
Pag 12
INSTALLATION & USE MANUAL
MAESTRO 2.0
UNIVERSAL Interface for MP3
iPad - iPhone - iPod
USB Player and AUX IN rev. 1.14
with steering wheel commands control
MAESTRO 2.0 is a device which allows you to listen, through your car radio, the audio files
stored in different sources such as iPod, USB and MP3 player having a Jack plug connection
(AUX IN).
Below are listed the main features MAESTRO 2.0:
USB input for playing of MP3/AAC/WMA/M4A files stored on a USB pen or on a Hard disk.
USB input for playing files stored on iPod / iPhone / iPad.
3,5mm-Jack for playing of audio data through the headphones’ plug of any MP3 player.
3,5mm-Jack for playing of vocal messages from any satellite navigation device.
User menu displayed on the car radio display by the RDS.
Vocal synthesis of the main information and Menu headings.
Interface control through wireless remote .
interface control through CAN BUS steering wheel commands (upon self-selection procedure).
interface control through GMLAN steering wheel commands (upon self-selection procedure).
Interface control through resistive steering wheel commands (upon self-learning procedure).
FM stereo modulation with 8 selectable frequencies, with RDS information.
iPad, iPhone, iPod classic, iPod nano are trademarks of Apple Inc., registered in the U.S. and other countries.
All registered trademarks are propriety of their owners.

CONNECTIONS AND INSTALLATION
MAESTRO 2.0 kit is composed by an interface unit (A), an ANTENNA DIN (D) / DIN PLUG (C)
connection cable, a power feeding/steering wheel commands connector with JACK AUX IN input
(F).
MAESTRO 2.0 can be installed following the steps below described:
After the car radio has been removed, please connect MAESTRO 2.0 power feeding cables by
using the 22 poles-connector as below shown.
Connect MAESTRO 2.0 RED cable to the car radio 12VDC positive.
Connect MAESTRO 2.0 BLACK cable to the ground.
Connect MAESTRO 2.0 BLUE-YELLOW cable to a positive ignition output.
Once the power feeding cables have been connected, in the same connector the user can find
the cables to connect MAESTRO 2.0 to the vehicle steering wheel commands. If the vehicle is
provided with steering wheel commands, please go to STEERING WHEEL COMMANDS CON-
NECTION section. If the vehicle is not provided with steering wheel commands, please follows
the next step.
STEERING WHEEL COMMANDS POWER FEEDING CONNECTION
ATTENTION:
FOR THE CAN BUS CARS IT IS NOT NECESSARY TO CONNECT THE BLUE-YELLOW PO-
WER IGNITION CABLE.
A
GND
12 VDC
POWER
IGNITION
F
JACK
AUX IN
CANBUS
RESISTIVE
GMLAN
POWER
ANTENNA OUTPUT
Pag 2
MODE B (5 buttons with long
pressure)
SRC button Volume buttons SEEK buttons
ON/OFF SEQUENCE
Vol + / Vol -
Vol + / Vol -
Volume + Volume +
Volume - Volume -
Next Track Seek +
Previous Track Seek -
Next Playlist/Folder Seek + (long)
Previous Playlist/Folder Seek - (long)
Menu SRC (long) Seek - / Seek +/
Seek - / Seek +
Menu Up Seek + (short)
Menu Down Seek - (short)
Menu confirmation SRC (short) Seek - Seek+
Play/Pause SRC (breve)
+ — < >
SRC
Pag 11

CONTROL OF THE FUNCTION BY STEERING WHEEL COMMANDS
MAESTRO 2.0 can be controlled by the supplied remote control but also by the steering wheel
commands (according to compatibilities).
Obviously, according to the different buttons available on the steering wheel the user can control
MAESTRO 2.0 in 2 different modes: MODE A and MODE B.
The two modes are described as follow.
MODE A
Mode with Volume or SRC
present but without long
press available
SRC button Volume buttons SEEK buttons
ON/OFF SEQUENCE
Vol + / Vol -
Vol + / Vol -
Volume + Volume +
Volume - Volume -
Next Track Seek +
Previous Track Seek -
Next Playlist/Folder Seek - Seek + Seek +
Previous Playlist/Folder Not available Not available Not available
Menu Seek - / Seek +/
Seek - / Seek +
Menu Up Seek + (short)
Menu Down Seek - (short)
Menu confirmation SRC (short) Seek - Seek +
Play/Pause SRC (short)
+ — < >
SRC
Pag 10
The installation is finished.
ATTENTION B CABLE IT IS NOT SUPPLIED
PLEASE USE THE ONE SUPPLIED WITH THE IPOD
ADAPTERS TO CONNECT MAESTRO 2.0 TO ANY CAR RADIO, EITHER BY ISO CONNEC-
TION OR FAKRA CONNECTION WITH 1 OR 2 ANTENNAS, ARE AVAILABLE
The user must connect MAESTRO 2.0 in series to the vehicle antennas. Please connect the an-
tennas DIN-cable inserting it into the connector as below shown. Then, please connect in series
the antennas putting them between the car antenna and the car radio.
ANTENNA CABLES CONNECTION
Once the antennas cable has been connected, it’s necessary to connect USB device as below
described.
IPOD / USB CONNECTION
TO THE RADIO TO THE
CAR ANTENNA
C/D
B
Pag 3

ACTIVATION AND TUNING
First of all, tune the radio-frequency.
Control that the RDS function is activate.
Now set the frequency on FM 87.70 mhz.
87.7 mHz
Now, switch on the ignition and the radio, MAESTRO 2.0 will switch on automatically.
MAESTRO 2.0 will pronounce the welcome message:
“WE WISH YOU GOOD LISTENING”.
If there are no audio devices connected (iPod, Usb or Mp3 Player in playing), the unit will pro-
nounce: “NO SOURCES AVAILABLE”
Once an audio device has been connected, the unit will pronounce:
“PLAYING FROM IPOD / USB / AUX IN” and the playing will start.
The same message is pronounced at the switching on, if a device is already connected to MAE-
STRO 2.0 .
If the user doesn’t connect any devices to MAESTRO 2.0 , the unit will switch off after 30
seconds and it will pronounce “GOODBYE”
All functions handled by MAESTRO 2.0 are also written in English on the display.
Menu headings and files titles contained into the audio sources are displayed thanks to MAE-
STRO 2.0 RDS handling function.
So, with the RDS function activated, all operations are also visualized on the radio display and, in
case of OEM radio, they are visualized also on the vehicle display (if the OEM radio can write
also on this one).
The displayed menu headings are the same for all the languages and they are set by default in
English. Instead, for what concerning files titles, MAESTRO 2.0 controls the information deriving
from the mp3 TAG: if the TAG is present the unit displays up to a maximum of 64 characters; if it
is not available, MAESTRO 2.0 will display the file name but up to a maximum of 64 characters!
Folders name are displayed on the display too; also in this case, MAESTRO 2.0 displays only the
first 64 characters, so it’s advisable to name the folders with maximum of 64 characters.
Memorize the frequency for the quick recall.
1 87.7 mHz
Pag 4
REMOTE FUNCTIONS
Remote controls allows us to manage all the functions available with the steering wheel com-
mands. Below please find the functions manageable.
ON SHORT PRESS OF BUTTON D
OFF SELECT OFF FUNCTION FROM
THE MENU or LONG PRESS OF
BUTTON D
Next Track SHORT PRESS OF BUTTON C
Previous Track SHORT PRESS OF BUTTON B
Next Playlist/Folder LONG PRESS OF BUTTON C
Previous Playlist/Folder LONG PRESS OF BUTTON B
Enter Menu LONG PRESS OF BUTTON A
Menu scroll ahead SHORT PRESS OF BUTTON C
Menu scroll back SHORT PRESS OF BUTTON B
Menu confirmation SHORT PRESS OF BUTTON A
Play/Pause SHORT PRESS OF BUTTON A
A
B C D
E
F
ON PRESS OF BUTTON C
OFF SELECT OFF FUNCTION FROM
THE MENU
Next Track SHORT PRESS OF D BUTTON
Previous Track SHORT PRESS OF B BUTTON
Next Playlist/Folder LONG PRESS OF D BUTTON
Previous Playlist/Folder LONG PRESS OF B BUTTON
Enter Menu SHORT PRESS F KNOB
Menu scroll ahead CLOCKWISE F KNOB ROTATION
Menu scroll back ANTICLOCKWISE F KNOB ROTA-
TION
Menu confirmation SHORT PRESS OF A BUTTON or
KNOB F
Exit one level menu SHORT PRESS OF E BUTTON
Exit from the menu LONG PRESS OF E BUTTON
Play/Pause PRESS OF BUTTON C
MODEL A - Product Code: KITTX/MD
MODEL B - Product Code: ARLTX/4T
A
B C
D
Pag 9

MAIN MENU SUB-MENU 1 SUB-MENU 2 SUB-MENU 3
SETUP VOICE LANGUAGE ITALIANO
INGLESE
LANG3
LANG4
BACK
EXIT
WELCOME MESSAGE ON
OFF
BACK
EXIT
MENU MESSAGE ON
OFF
BACK
EXIT
EVENTS MESSAGE ON
OFF
BACK
EXIT
VERSION BACK
EXIT
UPGRADE VOICE INSERT KEY
BACK
EXIT
BACK
EXIT
SYSTEM VERSION BACK
EXIT
UPGRADE SYSTEM
VERSION
INSERT KEY
BACK
EXIT
BACK
EXIT
EXIT BACK
EXIT
AUTO PWR ON
OFF
BACK
EXIT
RDS MODE LEGACY
TEXT
BACK
EXIT
In case of an incorrect working of the steering wheel commands
functions, please make a RESET of MAESTRO 2.0, as described be-
low, by pressing the button of the unit till the LED of the module
switch OFF.
Pag 8
AUDIO QUALITY
MAESTRO 2.0 is able to handle the audio files with a re production quality similar to the CD one.
To have this result, the user must use excellent quality audio files.
About the iPod, MAESTRO 2.0 respects the audio levels decided by Apple; this means that the
user will have a perfect listening result only if the tracks have been elaborated by iTunes.
In case of a low quality file, it should happen some distortions (if the recording volume is too high)
or some worsening about the ratio between the signal and the noise (if the recording volume is
too low).
About the USB, MAESTRO 2.0 respects the audio levels decided by Paser; this means that the
user will have a perfect listening result only if the track have been regulated according to an AU-
DIO LEVEL, by using the free software called MP3GAIN, available on the web site www.paser.it.
Please regulate the audio level at 89.0dB
About the track of different origin, the quality is good, even if the user can find some differences
about the volume among the playing of a file and another.
In case of a low quality file, it should happen some distortions (if the recording volume is too high)
or some worsening about the ratio between the signal and the noise (if the recording volume is
too low).
About the JACK AUX IN input, it’s possible to regulate the audio quality directly from the device
that the user will connect.
Paser can’t guarantee that all available USB pens will be compatible with MAESTRO 2.0 .
In the case that the module cannot recognize a USB pen, please format it in FAT32 and try
again.
Pag 5

MENU
MAESTRO 2.0 has a user-menu that is displayed on the radio display trough the RDS; the same
menu is pronounced by the vocal synthesis.
The menu can be run down by a remote control (available in two version) or by the steering wheel
commands (for the compatible versions).
To enter the menu with the remote control, please check the function at page 9. With the steer-
ing wheel commands, the user can enter the menu by pressing for a long the SRC button or, if
this button it is not available, by doing the sequence SEEK - / SEEK + / SEEK - / SEEK +.
To scroll down the menu headings, the user can use the remote control indicators buttons or the
steering wheel commands, by pressing the seek buttons.
To entry into the sub-menus or to confirm a choice, please do a short pressure on the remote
control on the central button or, through the steering wheel commands, please do a short pres-
sure on the SRC button. If this button is not available, please do the sequence SEEK - / SEEK +.
The menu managing allows to do all desired settings.
All possible handlings are displayed on the radio display and pronounced by the vocal synthesis
too.
The menu includes various sub-menus.
Menu organization is tree-shaped and it’s handled as described in the following table.
Wireless remote can be optional or included, it depends from the package requested.
MODELLO A
MODELLO B
MODELLO A
MODELLO B
MODELLO A
MODELLO B
Pag 6
MAIN MENU SUB-MENU 1 SUB-MENU 2 SUB-MENU 3
OFF
MUSIC USB FIRST
ROOT
FOLDER
BACK
EXIT
FOLDER LIST
SOURCE IPOD
USB
AUXIN
BACK
EXIT
SETUP USB RANDOM OFF
TRACK
BACK
EXIT
REPEAT OFF
ONE
ALL
BACK
EXIT
BACK
EXIT
AUX IN MODE NAVI
PLAYER
BACK
EXIT
BACK
EXIT
FREQUENCY 87.70
87.90
88.10
88.30
88.50
88.70
88.90
89.10
BACK
EXIT
Pag 7
