Patching Panda HATZ V2 User manual

CH OH
TRIG TRIG ACC
FREQ
FREQHOLD
DECAY
DECAY
FREQFREQ
ACC LVLMETALS
HATZ V2
USER MANUAL

INTRODUCTION:
Hatz is a 2-channel analog hit-hat creation module combining 2 kinds
of sound source – LFSR noise and metallic.
The module is designed to give you a closed hat on one channel and
open on the other.
Each channel has a 2-pole Voltage-Controlled State Variable BP Filter
with individual and variable control over decay curve from linear to
exponential.
Hatz features an accent input and choke functionality with CV controlled
decay over the open hatz.
The LFSR circuit allows you design your own percussion sounds with
many kinds of textures depending on the clock rate, while the Hold input
manually opens the envelope via gates or CV.
SNR = 110dB
INSTALLATION:
* Disconnect your synth from the power source.
* Double check polarity from the ribbon cable, unfortanetly if you
damage
the module by powering in the wrong direction it will not be covered by
the warranty.
* After connecting the module check again you have connected the right
way, the red line should be on the -12V

CH OHTEXTURE
TRIG TRIG ACC
FREQ
FREQ HOLD
DECAY
DECAY
FREQFREQ
ACCLVLMETALS
3. INSTRUCTONS:
Texture input CV
Output open hat
Output closed hat
Accent input
Trigger input open hat channel
Trigger input closed hat channel
Gate input closed hat channel
CV input freq open hat channel
CV input freq closed hat channel
CV input decay open hat channel
Response curve open hat channel!
A
A
HC
G
J
M
P
I
K
L
N
O
Q
R
E
DF
B
C
B
D
E
F
G
H
I
J
K
Response curve closed hat
Decay control open hat
Frequencie control open hat
Frequencie control closed hat
Amount of
LFSR clock freq
Gain amount accent input,
(gain amount of triggers input
with no accent input)
L
N
M
O
P
Q
R
