Patiorama PA-02+03+04 User manual

PA-02+03+04
7-Piece Sofa Set
W
A
R
R
A
N
T
Y
1
Y
E
A
R
1
Thank you for choosing Patiorama!
Our goal is to provide high quality outdoor furniture with
outstanding customer service-all at an affordable price.
Please let us know how we are doing!
Problems?
(Missing pieces, wrong pieces...)
We will fix it Immediately. Send us an email at
[email protected]. If you are not satisfied with our
customer service, pls send your comments to
[email protected].
Happy?
Please leave us a review!
You can make others happy too!

IMPORTANT, RETAIN FOR
FUTURE REFERENCE:
READ CAREFULLY.
Safety
For domestic use only.
Don't tighten all the bolts before the product is fully assembled.



Periodic structural checks of this product should be
It would be useful to ask someone to help you assemble
the product.
undertaken, do not use if you have any doubts about its
Do not stand on the seat.
Do not sit on the armrest.
Do not let children play with this product.
Maximum load per seat: 250 lbs.
At the beginning of the season

product are secure, do not use if you have any doubts
At the end of the season
This product should be stored under cover during
prolonged spells of adverse weather (wet or cold) and
also during the winter (ideally in a garden shed or
garage).
Always clean and dry thoroughly before storage.
- 1 -

Tips for Cushions
1
3
OK
2
In order to compress the package, we put the cushions in
the gap of some parts. So there may be crinkle on the fabric.
Don’t worry. Just flap every corner of the cushion evenly and
it will get back into its original shape soon.
- 2 -

x9
x9
(A)x1 Corner Panel
(L)×1 Hex Wrench
- 3 -
(B)x1 Corner Panel (C)×1 Seat Base
M6x35 Bolt/Washer 9pcs
ASSEMBLY PARTS LIST
Corner Sofa
Corner chair is universal (used as a left or right) chair.
If you rotate it 90 degrees, the left corner chair is the right corner chair.

- 4 -
Important:
Hand tighten all the bolts to line up all the pieces .
Then tighten all the bolts down.
ASSEMBLY STEPS
A
B
Attach the corner panel (A) to the corner panel (B) with bolts (M6X35) and
washers.Do this in 2 places.
x2
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.
1
2

A
B
C
- 5 -
Attach the seat base (C) to the corner panel (A) and corner panel (B) with
bolts (M6X35) and washers. Do this in 7 places.
x7
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.
2
7

- 6 -
Tighten all 9 Bolts into place with Allen Key (L).
3
x9
L
NOTE:IF ANY SCREW HOLES CANNOT BE ALIGNED,
LOOSEN ALL THE SCREWS AND GO BACK STEP
1 AND RESTART ASSEMBLY.

x8
x8
(H)x1 Top Panel
(L)×1 Hex Wrench
(M)x1 Side Panel (R)x1 Side Panel
M6x35 Bolt/Washer 8pcs
ASSEMBLY PARTS LIST
- 7 -
Ottoman

- 8 -
Important:
Hand tighten all the bolts to line up all the pieces .
Then tighten all the bolts down.
ASSEMBLY STEPS
Attach the top panel (H) to the side panel (R) with bolts (M6X35) and washers.
Do this in 2 places.
x2
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.
1
2
H
R

- 9 -
Attach the top panel (H) to the side panel (R) with bolts (M6X35) and washers.
Do this in 2 places.
x6
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.
2
H
6
M
R

- 10 -
Tighten all 8 Bolts into place with Allen Key (L).
3
x8
L
NOTE:IF ANY SCREW HOLES CANNOT BE ALIGNED,
LOOSEN ALL THE SCREWS AND GO BACK STEP
1 AND RESTART ASSEMBLY.

x8
x8
(D)x1 Seat Back
(L)×1 Hex Wrench
- 11 -
(E)x1 Seat Base (G)×1 Side Panel
M6x35 Bolt/Washer 8pcs
ASSEMBLY PARTS LIST
Armless Sofa

- 12 -
Important:
Hand tighten all the bolts to line up all the pieces .
Then tighten all the bolts down.
ASSEMBLY STEPS
Attach the seat back (D) to the seat base (E) with bolts (M6X35) and washers.Do
this in 4 places.
x4
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.
1
4

4
- 13 -
Attach the side panel (G) to the seat back (D) and seat base (E) with bolts
(M6X35) and washers. Do this in 4 places.
x4
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.
2

- 14 -
Tighten all 8 Bolts into place with Allen Key (L).
3
x8
L
NOTE:IF ANY SCREW HOLES CANNOT BE ALIGNED,
LOOSEN ALL THE SCREWS AND GO BACK STEP
1 AND RESTART ASSEMBLY.

x8
x8
- 15 -
Table
(J)x1 Top Side
M6x35 Bolt/Washer 8pcs (L)×1 Hex Wrench
(O)×1 Side Panel (P)×1 Side Panel
ASSEMBLY PARTS LIST

- 16 -
Important:
Hand tighten all the bolts to line up all the pieces .
Then tighten all the bolts down.
ASSEMBLY STEPS
Attach the side panel (O) to the top side (J) with bolts (M6X35) and washers. Do
this in 4 places.
x4
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.
1
J
O
4

- 17 -
Attach the side panel (P) to the side panel (O) and top side (J) with bolts
(M6X35) and washers. Do this in 4 places.
x4
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.
2
O
J
4
P

- 18 -
Tighten all 8 Bolts into place with Allen Key (L).
3
x8
L
NOTE:IF ANY SCREW HOLES CANNOT BE ALIGNED,
LOOSEN ALL THE SCREWS AND GO BACK STEP
1 AND RESTART ASSEMBLY.

- 19 -
