Patiorama PA-N17 User manual

PA-N17/PA-17GY
Corner Sofa + Armless sofa
W
A
R
R
A
N
T
Y
1
Y
E
A
R
1
Thank you for choosing Patiorama!
Our goal is to provide high quality outdoor furniture with
outstanding customer service-all at an affordable price.
Please let us know how we are doing!
Problems?
(Missing pieces, wrong pieces...)
We will fix it Immediately. Send us an email at
[email protected]. If you are not satisfied with our
customer service, pls send your comments to
[email protected].
Happy?
Please leave us a review !
You can make others happy too!

IMPORTANT, RETAIN FOR
FUTURE REFERENCE:
READ CAREFULLY.
Safety
For domestic use only.
Don't tighten all the bolts before the product is fully assembled.



Periodic structural checks of this product should be
It would be useful to ask someone to help you assemble
the product.
undertaken, do not use if you have any doubts about its
Do not stand on the seat.
Do not sit on the armrest.
Do not let children play with this product.
Maximum load per seat: 250 lbs.
At the beginning of the season

product are secure, do not use if you have any doubts
At the end of the season
This product should be stored under cover during
prolonged spells of adverse weather (wet or cold) and
also during the winter (ideally in a garden shed or
garage).
Always clean and dry thoroughly before storage.
- 1 -

Tips for Cushions
1
3
OK
2
In order to compress the package, we put the cushions in
the gap of some parts. So there may be crinkle on the fabric.
Don’t worry. Just flap every corner of the cushion evenly and
it will get back into its original shape soon.
- 2 -

- 3 -
Item
no.
Reference
Image Description Qty.
ACorner Panel
COMPONENT LIST - CORNER SOFA
1
BCorner Panel 1
CSeat Base 1
FWasher 9
KM6X35
Head Cap Screws 9
LAllen Key 1
TBack Cushion 1
T1 Short Cushion 1
SSeat Cushion 1
XAdjustable Feet 4

- 4 -
FK
Attach the corner panel (A) to the corner panel (B) with M6*35 Head Cap Screws
(K) and Washers (F). Do this in 2 places.
x2
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.
1
A
B
2
NOTE:
When tightening the Screws, tighten sequentially.
DO NOT tighten any Screws fully and then move on to the next one.
This may cause the frame to warp.
If there is still wobbles or screw holes cannot be aligned,loosen the
bolts and execute this same process.
If the Sofa is not stable it could lead to damage to the product.

- 5 -
A
B
C
FK
Attach the seat base (C) to the corner panel (A) and corner panel (B) with
M6*35 Head Cap Screws (K) and Washers (F). Do this in 7 places.
x7
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.
2
7

- 6 -
Tighten all 9 Screws into place with Allen Key (L).
3
x9
L
NOTE:IF ANY SCREW HOLES CANNOT BE ALIGNED,
LOOSEN ALL THE SCREWS AND GO BACK STEP
1 AND RESTART ASSEMBLY.

- 7 -
Place the Sofa on a level surface, and adjust height for balance.Place
the Seat Cushion (S) and Back Cushion (T) and Short Cushion (T1)
on the Sofa. Your Sofa is ready for use.
S
T
T1
5
4Complete the assembly of adjustable feet (X) as picture. Do this in
4 places.
X
4
Adjust height
for balance
Adjust low
for balance
Adjust Pre-installed levellers
height for balance

- 8 -
Item
no.
Reference
Image Description Qty.
DSeat Back
COMPONENT LIST - ARMLESS SOFA
1
ESeat Base 1
GSide Panel 1
FWasher 8
KM6X35
Head Cap Screws 8
LAllen Key 1
TBack Cushion 1
SSeat Cushion 1
NOTE:
When tightening the Screws, tighten sequentially.
DO NOT tighten any Screws fully and then move on to the next one.
This may cause the frame to warp.
If there is still wobbles or screw holes cannot be aligned,loosen the
bolts and execute this same process.
If the Sofa is not stable it could lead to damage to the product.
XAdjustable Feet 4

- 9 -
Attach the seat back (D) to the seat base (E) with M6*35 Head Cap Screws (K)
and Washers (F). Do this in 3 places.
x3
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.
1
3
E
D
F
K

- 10 -
Attach the side panel (G) to the seat back (D) and seat base (E) with M6*35
Head Cap Screws (K) and Washers (F). Do this in 5 places.
x5
NOTE:DO NOT TIGHTEN THE SCREWS COMPLETELY.
2
5
E
G
D
F
K

- 11 -
Tighten all 8 Screws into place with Allen Key (L).
3
x8
L
NOTE:IF ANY SCREW HOLES CANNOT BE ALIGNED,
LOOSEN ALL THE SCREWS AND GO BACK STEP
1 AND RESTART ASSEMBLY.

- 12 -
Place the Sofa on a level surface, and adjust height for balance.
Place the Seat Cushion (S) and Back Cushion (T) on the Sofa. Your
Sofa is ready for use.
S
T
5
4Complete the assembly of adjustable feet (X) as picture. Do this in
4 places.
Adjust height
for balance
Adjust low
for balance
Adjust Pre-installed levellers
height for balance
X
2
2
X

- 13 -
SECTIONAL SOFA CONNECTOR MANUAL
Sectional outdoor wicker patio sofa is very light weight in
nature and subject to movement.
These high quality fasteners prevents movement between
modules to maintain the aesthetically good look of your
modular patio furniture set.
Two fasteners are recommended between Two adjoining
module.
1
2
