Patmont Motor Werks HoverBoard II User manual

MAINTENANCE / PARTS
•AllframeandenginepartsareavailablethroughyourauthorizedGo-Ped®
reseller or the Go-Ped® website at www.goped.com.At Goped.com, you’ll be
able to locate a dealer near you as well as shop for parts for your Goped.
•Useonlymanufacturer’soriginalequipment,replacementpartswhenservicing
thisunit.These partsare availablefromyour authorized dealer.The use of non-
standard parts, or other accessories or attachments not designed for this unit
could result in serious injury to the user or damage to the unit.
Although the engine noise is virtually non-existent, it is difficult to hear vehicles
approachingyou.Beawareof your surroundings before changing direction. The
Hoverboard®andStealth® have been designed to operate on anyhard-packed,
dryand smooth surfaces.
· Avoid wet and/or oily surfaces, loose sand, gravel, potholes, etc.
· Always use both hands while riding.
YourGo-Ped®,although environmentally-friendly, is not grade-friendly.Depending
on the weight of the rider, it will not ascend certain grades, and is not designed for
descending grades in excess of 5%.
SAFETYWARNING
Do not wear loose-fitting clothes or articles such as scarves, strings, chains,
ties,etc.Donotremove rear-fender which guards drive mechanism from
foreignobjects.
Technical Support Line [phone]
Email–[email protected]or on the Internet at www.goped.com
Go-Ped® is a registered trademark of PMW.
© 1998 PMWAll rights reserved
SUPPORT
DRIVING DEFENSIVELY
WARNING
The status of your Go-Ped®, as a motor vehicle, is subject to drivers’
license, insurance requirements and registration, which varies state-
to-state. Please contact your local, law enforcement agency or
Department of Motor Vehicles for further advisement on these

HOVERBOARD / STEALTH GO-PED®s SPECIFICATIONS
*SpeedsandRunningDurationsvarysignificantlydependingontheweightof
theriderandconditionsofroadsurface,gradeandweather.
IMPORTANT! If you did not completely fill out and submit a warranty
registrationformtoyourdealeruponpurchasingyourGo-Ped®product,
return to your dealer immediately and do so. If your form is not turned into
the manufacturer, YOU DO NOT HAVEAWARRANTY.
Pay EXTRAATTENTION to the yellow, SAFETY WARNING sections of this
manual.TheseareveryimportanttounderstandbeforeyourideyourGo-
Ped®.BE SURE TO READ THESE INSTRUCTIONS CAREFULLY
BEFOREATTEMPTING TO START OR OPERATE THIS UNIT.
FREQUENTLY ASKED QUESTIONS / TROUBLESHOOTING
Question: How far does my Electric Go-Ped go?
•Approximately7-12 miles. This depends on rider weight & riding
conditions i.e. smooth/ rough surface, wind & grade (hills).
Question: How long does my Electric Go-Ped take to charge?
•3 to 4 hours
Question: Is it legal to ride on public roads or sidewalks?
•Please consult your local Law EnforcementAgencies.
Question: Is there a seat for the Hoverboard / Stealth?
•Yes, the Sat Squatch Seat which work on all Go Ped models. Visit
www.Goped.comfor more information
Question: What is the maximum weight capacity of the Hoverboard /
Stealth?
•250pounds;toprevent overheating of the motor.
Question: Is it okay to completly discharge the batteries?
•No, these Lead-Acid Batteries do not retain memory & should be topped
offbefore every ride. Fully discharging them will render them useless.
Question: How many times can I charge my Electric Go-Ped?
•TheSealedLeadAcidBatterieshavealife-cycleofapproximately300
charges.
Question: My Go-Key® doesn’t light up! What could be wrong?
•*Thebatteryconnectionsmighthavebecomeloose.
•*Fuseon the control board might been damaged.
Question: Key is luminated, but Go-Ped doesn’t work.
•Remove the Go-Key for a minimum of 30 seconds then place back in.
• Checkfrontbrakelever.Apartiallyengagedbrakeorimproperalignment
of the brake sensor will engage the engine brake system.
Question: Diminished range, will not hold a charge?
•Thebatterieshave been over-discharged or notchargedenough.One or
more batteries may need to be replaced.
•Battery abuse, such as too heavy of a load and too steep of a incline will
causeprematureBatteryfailure.
•*Batteryconnection might have become loose.
•*Battery voltage should be in the range of 6.2 volt to 6.7 volt.
•*Batteriesshouldbe LoadTested to ensure fullAmperage(3amp)
Question: Why does my Go-Key dim when I engage throttle?
• DeadBattery(ies)
•*Remove deck and check Battery wires for loose connections.
Question: Charger light does not come on?
•*Check the 3.15 amp glass fuse on the Charger Board.
•*Check (3) spade connectors onA/C Socket Plug.
Question: Motor overheats and shuts off?
• ExceedingMaximum weight.
• Toosteep of incline (grade).
• Pumpingthethrottle lever with Go-Key inserted
• Remove the Go-Key for a minimum of 30 seconds then place back in.
• Toomuch Motor spring pressure.
Question: I need to buy parts for my Go-Ped, where should I go?
• Tofind your nearest Go-Ped® Dealer, please go to www.Goped.com and
clickon“find-a-dealer”.Analternative would be the Go-Shop section
locatedonGoped.com
*Work must be done by a Go-Ped technician for repairs. Performing any of the
procedures will void your warranty. Goto www.Goped.com to find you nearest local
dealerfortechnicalhelp.

SAFETYWARNING
Internal electrical and electronic parts can cause severe electric shock, and
shouldnot be accessed by anyone other than factory-authorized personnel.
Inspect your Go-Ped® for shipping damage, and to ensure all components are in
proper order. In the case of any damage or questions, contact your authorized Go-
Ped® reseller or call the Go-Ped® technical support line at [phone]. Office
hours are Monday-Friday 8:00 a.m. – 5:00 p.m. PST
GETTING STARTED
Your electric Go-Ped® is equipped with an automatic thermal cutoff
switch. When the vehicle is abused by running continuously over
excessive grades (inclines), over soft materials like carpet, or rubber
mats, or exceeding the recommended total weight capacity of 250 lbs.,
the motor will get overheated. The internal thermal switch will disconnect
the power from the motor until the temperature has once again reached
safe levels. The Go-Key® will have to be removed and re-inserted to reset
the electronic controllers. Operating the controls (pulling the throttle and
brake levers) continuously while standing still will also cause internal
damage.
TIRES
OVERHEATING
Non-pneumatic tires require no maintenance, but must be replaced when
normal wear and tear makes the tire diameter reach the wear limit
(“dimple”) found on the side of the tire. Inspect for damage (i.e. split,
cracked or torn tires should be replaced immediately).
BATTERY CHARGING
The Electric Go-Ped® comes partially charged. It is highly recommended that you
charge your Electric Go-Ped® for a minimum of 3 hours
beforeyourinitialuse.
The LEDA1 display on the deck is called the Flux Capacitor.
It is used to help provide battery status at times of use or
whilebeingcharged. AllfiveilluminatedLEDlightsindicate
a full charge while one indicates a dead battery.
Theprovided power cord(ora standard computerpower
cord) and a wall socket is all that is needed to charge your
Go-Ped®.Plugoneendofthepower cord into the right/rear
of the standing platformA4 and the other into the wall socket.
AlwaysremembertounplugyourGo-Key®A2 whennot in
use.
ThebatteriesusedtopoweryourGo-Ped® are Sealed
Lead-Acid. These are very similar to the technology used in
maintenance-freeautobatteries.Lead-Acidbatteries DO
NOT retain any memory, meaning you should NEVER fully
discharge your batteries to the point that your Go-Ped® is barely moving. Do not
exceed12hours of charging time. Over-dischargingand/orover-chargingLead-
Acid batteries will greatly diminish the battery cycle life. You should also try and
“Top Off” your batteries (3 to 4 hours) before setting out on a long ride. We also
recommend that you DO NOT attempt to ride the Go-Ped® uphill at full-throttle for
anextendeddurationandup5%gradesor greater.
Minimumchargetime 3hours
Best charge time 4 to 6 hours
Maximumcharge time 12 hours
DO NOT EXCEED the 12-hour max. Charge time to optimize your battery cycle
life.
SAFETYWARNING
• Persons without excellent vision, balance, coordination, reflex, muscle and
bone strength or good decision-making capability should not use this
product.
• This product should not be used by minors without adult supervision.
• This product should not be used by persons unwilling to take responsibility
for their actions.
• The user of this product assumes all risks, all users must wear safety
helmet,goggles,gloves, elbow and kneepads, ankle support, and
appropriateshoes.
Accessories

This product contains sealed Lead-Acid batteries that must be recycled. Local,
state or federal laws prohibit the disposal of Lead-Acid batteries in ordinary trash.
Note: Contactyourlocalwaste authority for information regarding the recycling of
yourbatteries.
*Uponremovalofthebattery, covertheterminalswithheavy-dutyadhesivetape.
Do not attempt to destroy or disassemble battery-pack, or remove any of its
components.Also, never touch both terminals with metal objects or body parts as
a short circuit may result. Keep the battery away from children. Failure to comply
with these warnings could result in fire or serious injury.
BATTERYWARNING
To reduce the risk of injury, use only batteries provided or recommended by
Go-Ped®.Other batteries may explode causing personal injury or damage.
DO NOT PLACE BATTERYNEAR AN OPEN FLAME OR EXCESSIVE
HEAT. Batteries can emit gases whilebeing charged.
BATTERY RECYCLING
BEFORE YOU RIDE – Familiarize yourself with the controls located on the “T”
handle.Theleft-handleveroperatesthebrakesB1 ,initialpressureactivatesthe
rear-wheel,anti-skiddynamic brake (located in the motor) and continued pressure
engagesthefront-wheelcaliper brake. The right-hand lever operates the throttle/
speedB2 control to accelerate. Gently squeeze the throttle lever, and continue
addingpressureuntildesiredspeedisachieved.
· Removeyour“T”handle from the “T” handle-hook, and extend it upright
until the handle-lock tube locks into place.C1
· Be certain the sliding handle lock tube is in its full down position, locking
the handlebar upright. The handle latch hooks the motor casing to hold
thehandle in the folded position for carrying or for storage.C2
· Includedinyour Owner’s Packet, you should have received a Go-Key®.
This key acts as an On / Off switch that upon insertion into the Go-Key®
receptacle turns your Go-Ped® on. This is indicated by the red LED on
the end of the Go-Key®.B3
Note: Please read and understand the disclaimers attached to the Go-Key®
before inserting it into the Go-Key® receptacle. These instructions are important
so please do not remove them.
· Each insertion of the Go-Key® into the vehicle is an independent promise
by the rider to be responsible for his/her own safety.B3
· Please remove the Go-Key® anytime your Go-Ped® is not in use or
beforefolding your “T” handledown.
Note: The Go-Key® is also a safety off switch. In case of emergency, the Go-
Key® can be removed and the Go-Ped® motor will cease operation.
CONTROLS TIPS
BEFORE YOU RIDE -Thoroughly inspect the unit for looseordamagedparts
before each use. Do not use until adjustments or repairs are made. Position your
feet in any location that is comfortable to you. Most prefer a parallel stance with
the left leg slightly behind the right and bearing most of the weight while bending
your knees. When accelerating or climbing hills you will need to lean forward a
little to keep the front wheel on the ground. Under hard braking conditions you will
need to lean back to keep the rear-wheel on the ground.
SCOOTING CAN BE anenvironmentallyuseful,safe,andfun way of reducing
trafficcongestion.
DO NOT make changes or modifications to your scooter which can make your
scooter act in an unsafe manner.
SAFETYWARNING
This vehicle does not conform to Federal Motor Vehicle Safety Standards
and is not intended for operation on public streets, roads or highways.
Seriousinjuriescanresultfromunsafeoperationofthisvehicle.Theoperator
can minimize these risks by wearing safety equipment. SAFETY HELMET,
GOGGLES, GLOVES, ELBOW & KNEEPADS, ANDAPPROPRIATE
SHOES MUST BE WORN. Do not operate this vehicle inTRAFFIC, WET,
FROZEN,OROILYSURFACES.Avoiduneven surfaces, large chuckholes,
surface cracks and obstacles.Adult supervision is strongly recommended.
